Yifang Digital Technology NEXT2 User Manual

Precautions

z Do not subject the device to severe impact or drop it from high position. z Do not use the player in extreme hot or cold, dusty or damp field. Do not expose

it to direct sunshine.

z Excessive sound pressure from earphones and headphones can cause hearing

loss.

z Avoid using the player in strong magnetic field. z Keep the device away from water or other liquids. In the event that water or

other liquids enter the device, power off the product immediately, and clean the device.

z Do not use chemical solution to clean the device in order to avoid corrosion.

Clean it with a dry cloth.

z We are not responsible for the damages or lost data caused by malfunction,

misusing, repairing the device or battery replacement.

z Do not attempt to disassemble, repair or modify the product. This will invalidate

guarantee.

z When not using the device for an extended period of time, please charge the

battery at least once per month to extend the battery life.

z Do not use the device in extremely hot, cold, dusty or damp environments. z Avoid dropping or striking the unit .This may cause external and internal

physical damage to the player.

z Charge the battery if:

a) The battery level icon displays (An empty battery) b) The device powers off automatically and off again when restarted. c) No response when pressing keys with keys unlocked and battery installed.

z To prevent damage from static shock, never use the device in very dry

conditions.

z When the device is being formatted or transferring a file, do not interrupt the

connection. Otherwise, data may be corrupt of lost.

z When the device is used as a portable HD, please use only per instructions.

Otherwise, permanent data loss could occur.

z This manual may not reflect the actual device’s operation since it is subject to

change without prior notification. Please comply with your actual device’s operations always.

z Please use and install the exclusive supply apparatus only according to

manufacturer’s instruction.

z Please refer the information on exterior bottom enclosure for electrical and

safety information before installing or operating the apparatus.

z To reduce the risk of fire or electric shock, do not expose this apparatus to rain

or moisture. The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall not be placed on apparatus.

z Danger of explosion if battery is incorrectly replaced. Replace only with the

same or equivalent type.

z The battery (battery or batteries or battery pack) shall not be exposed to

excessive heat such as sunshine, fire or the like.

z Excessive sound pressure from earphones and headphones can cause hearing

loss.

z The direct plug-in adaptor is used as disconnect device, the disconnect device

shall remain readily operable.

z Only use attachments/accessories specified or provided by the manufacturer

(such as supply adapter, battery etc).

z The adaptor is CLASS II apparatus with double insulation, and no protective

earth provided.

- This lightning flash with arrowhead symbol within an equilateral triangle is

intended to alert the user to the presence of non-insulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock.

- To reduce the risk of electric shock, do not remove cover (or back) as there are no user-serviceable parts inside. Refer servicing to qualified personnel.

- The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance instructions in the literature accompanying the appliance.

z Correct Disposal of this product. This marking indicates that this product

should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact the retailer where the product was purchased. They can take this product for environmental safe recycling.

z Do not install this equipment in a confined space such as a book case or similar

unit. The ventilation should not be impeded by covering the ventilation openings with items such as newspaper, table-cloths, curtains etc.

z No naked flame sources, such as lighted candles, should be placed on the

apparatus.

z Attention should be drawn to environmental aspects of battery disposal. z Use the apparatus in moderate climates.

Listening Cautions

z Do not play your earphones or headphones at a high volume. Hearing experts

advise against continuous extended play.

z If you experience a ringing in your ears, reduce volume or discontinue use. z Do not use while operating a motorized vehicle. It may create a traffic hazard

and is illegal in many areas.

z You should use extreme caution or temporarily discontinue use in potentially

hazardous situations.

z Even if your headphones or earphones are the open-air type designed to let

you hear outside sounds, don’t turn up the volume so high that you can’t hear what’s around you.

z Sound can be deceiving. Over time you hearing “comfort level” adapts to

higher volumes of sound. So what sounds “normal” can actually be loud and harmful to your hearing. Guard against this by setting your equipment at a safe level BEFORE your hearing adapts. To establish a safe level:

a. Start your volume control at a low setting. b. Slowly increase the sound until you can hear it comfortably and clearly,

and without distortion. Once you have established a comfortable sound level, leave it there.

Table of Content

Listening Cautions...............................................................................................3

Introduction.......................................................................................................... 5

Feature Summary................................................................................................ 5

Package Content.................................................................................................5

Buttons & Ports....................................................................................................5

Charging Battery..................................................................................................6

Installing Memory Card........................................................................................7

Transferring Files.................................................................................................7

Turning On/Off..................................................................................................... 7

Home Screen.......................................................................................................8

Using the Touch Screen ......................................................................................9

Reading E-Books ................................................................................................9

Access Internet.................................................................................................. 12

Playing Video.....................................................................................................18

Viewing Photos.................................................................................................. 19

File Explorer ......................................................................................................20

E-mail ................................................................................................................21

Manage Applications .........................................................................................23

System Settings.................................................................................................23

Troubleshooting................................................................................................. 25

FCC Warning Statement.................................................................................... 25

Specifications ....................................................................................................26

Introduction

This device can give you amazing e-book reading experience – allowing you to read large quantities of e-books stored in this device. Furthermore, this latest generation of small, powerful, highly portable device combines many great capabilities - Wi-Fi connectivity, music player, movie player, photo viewer etc. with the convenience of a pocket-sized solution for your life on-the-go.

Feature Summary

E-book Reader Allow you to read large quantities of e-books stored in the device.

Wi-Fi Connectivity

With the latest Wi-Fi technology, this device can connect you to the Internet wherever you are.

7” Touch Screen

Touch or slide your finger in the screen, the screen responds instantly.

Third-party Application Support

This device supports the most popular applications. You can install or uninstall applications on this device, such as MSN, YouTube, g-email etc.

Built-in G-sensor

Allows the user interface to rotate its orientation to landscape or portrait automatically once this device is rotated.

Entertainment

Allows you to enjoy music, movie or pictures.

Package Content

z Main Unit z USB cable z AC Adaptor

z Operation Instruction z Warranty Card

Buttons & Ports

Front View

a b

a. Previous – press to go back to the

previous page.

b. Next – press to go forward to the

next page.

c. LCD Display

Bottom View

d. DC-IN port – connect to any standard electric source through the

e. SD Card Slot – acommodate any standard SD memory card. f. Earphone Port – connect to stereo earphones (not provided with

g. USB Port – connect to computer through USB cable. h. Power – press and hold to turn on or off the device; briefly press

Rear View

provided AC adaptor.

the unit. )

to turn on or off the screen.

i. Reset pin hole – used to reset your

device when the device freezes.

j. Built-in Speakers

i j j

Charging Battery

The device has built-in rechargeable battery. No extra battery installation is required. Just charge the device when it indicates low battery. To charge the battery, plug the AC adaptor to any standard wall outlet and the DC-IN port of the device. It takes about 3 hours to fully charge the battery.

Note:

a. You can operate the device even when it is being charged. But for extending the battery

life, you are suggested NOT to use the device when it is in charge. b. You are recommended to charge the battery when you use the device for the first time. c. For maximum performance, lithium-ion batteries need to be used often. If you don’t use

the device often, be sure to recharge the battery at least once per month.

Installing Memory Card

Besides the built-in memory, this device features a memory card slot to extend its memory space. You can read e-book, music, image or video files from a SD card directly. To install a memory card, find the card slot at the bottom of the machine, and then insert the memory card into the slot with the correct direction. To access the memory card, enter the Explorer mode and select the “SDCard” directory.

Transferring Files

Before reading or playing files, you need to transfer media files from computer to this device. (1) Connect this device to a computer with the supplied USB cable. This device will

turn on and ask you if you want to connect it or not. Choose “Connect” to connect

it. (2) Once connected, two removable disk drives appear in your computer. One

represents the internal memory of this device, and the other represents the

memory card inserted into this device. Now you can copy files from or to these

disk drives. (3) Once the data transfer completes, drag from the top bar downwards to display the

USB notification message.

(4) Choose “Turn off USB Storage” and then tap on “Turn Off” to disconnect the

device from computer.

Drag downwards

(5) Remove the player from the PC safely.

a) Left-click the icon at the right bottom corner of the computer desktop. b) Click the pop-up mini-window with message of “Stop the USB Mass Storage

Device – Drive (X)”.

c) Remove the player from the computer.

Turning On/Off

To turn on the device, press and hold the Power button on the unit until you see the

boot-up screen. It may take a few minutes to start up the system, please wait before you proceed.

To turn off the device, press and hold the Power button until you see the option “Power Off”, tap on “Power Off” and then tap on “OK”.

Tip: This device will sleep with the screen off if it stays inactive for a few seconds. You can briefly press the Power button to turn on the screen and wake it up.

Home Screen

Indications

a b c d e f g

a. Go to Home Screen. b. USB Connection c. WIFI available d. Battery incidation e. Time

f. MENU: display overlay menu g. Return: go back to the previous screen or
