Yifang Digital Technology M1011FP User Manual
Safety Precautions
z Do not subject the device to severe impact or drop it from heights.
z Do not use the device in extreme hot or cold, dusty or damp conditions. Do not
expose it to direct sunlight.
z Avoid using the device near strong magnetic fields.
z Normal functioning of the product may be disturbed by ESD. If so, simply reset
and restart the device following the instruction manual. During file transmission,
please handle with care and operate in a static-free environment.
z Keep the device away from water and other liquids. In the event that water or
other liquids enter the device, power off the product immediately and clean the
device.
z Do not use chemicals to clean the device in order to avoid corrosion. Clean it
with a dry cloth.
z Do not install this equipment in a confined space such as a book case or similar
unit. The ventilation should not be impeded by covering the ventilation openings
with items such as newspaper, table-cloths, curtains etc.
z No naked flame sources, such as lighted candles, should be placed on the
apparatus.
z Use the apparatus in moderate climates.
z Attention should be drawn to environmental aspects of battery disposal.
z We are not responsible for damage or lost data caused by malfunction, misuse,
modification of the device or battery replacement.
z Do not attempt to disassemble, repair or modify the product. This will invalidate
the warranty.
z If the device will not be used for an extended period of time, please charge the
battery at least once per month to maintain battery life.
z Charge the battery if:
a) The battery level icon displays (An empty battery)
b) The device powers off automatically when restarted.
c) There is no response when pressing keys with keys unlocked and battery full.
z Do not interrupt the connection when the device is being formatted or
transferring files. Otherwise, data may be corrupted or lost.
z When the device is used as a portable HD, please use only per the instructions.
Otherwise, permanent data loss could occur.
z Please use and install data using the attachments/accessories provided and only
according to the manufacturer’s instruction.
z Please refer to the information on the bottom of the device for electrical and
safety information before installing data or operating the device.
z To reduce the risk of fire or electric shock, do not expose this device to rain or
moisture. The device should not be exposed to dripping or splashing. Never
place objects filled with liquids, such as vases, on the device.
z There is danger of explosion if the battery is replaced incorrectly. Replace only
with the same or equivalent type.
1
The battery (battery or batteries or battery pack) should not be exposed to
z
excessive heat such as sunlight, fire or the like.
z Please follow responsible procedures for battery disposal.
z If the power adaptor disconnected from the device, the device will remain
operable as long as the battery has sufficient charge.
z The power adaptor is a CLASS II apparatus with double insulation, and no
external ground is provided.
z Safety symbol explanation:
- The lightning flash with arrowhead symbol within an equilateral triangle is
intended to alert the user to the presence of non-insulated “dangerous
voltage” within the product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock.
- To reduce the risk of electric shock, do not remove the cover (or back) as
there are no user-serviceable parts inside. Refer servicing to qualified
personnel.
- The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance instructions in
the literature accompanying the device.
Correct Disposal of this product. This marking indicates that this
product should not be disposed of with other household waste in the EU. To
prevent possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to promote the
sustainable reuse of material resources. To dispose of your used device,
please use the return and collection systems available in your area or
contact the retailer where the product was purchased. They can take this
product for safe environmental recycling.
2
Listening Cautions
z This product respects the current regulations for limiting the output volume of
consumer audio devices to a safe level. By listening to your device with
headphones or earbuds at high volumes, you run the risk of permanent damage
to your ears. Even if you get used to listening at high volumes and it seems
normal to you, you still risk the possibility of damaging your hearing. Reduce the
volume of your device to a reasonable level to avoid permanent hearing damage.
If you hear ringing in your ears, reduce the volume or shut off your device. This
device has been tested with the supplied earphones. In order to preserve your
hearing, it is advised that you use only the following headphone models: the
earphones supplied with your device, or any other headphones that respect the
current regulations. Other types of headphones may produce higher volume
levels.（At full power ,the prolonged listening of the walkman can damage the ear
of the use）
z Maximum output voltage<=150mv
z Do not use while operating a motorized vehicle. It may create a traffic hazard
and is illegal in many areas.
z You should use extreme caution or temporarily discontinue use in potentially
hazardous situations created by obstructed hearing.
z Even if your headphones or earphones are the open-air type designed to let you
hear outside sounds, don’t turn up the volume so high that you can’t hear what’s
around you.
z Sound can be deceiving. Over time your hearing “comfort level” adapts to higher
volumes of sound. What sounds “normal” can actually be loud and harmful to
your hearing. Guard against this by setting the volume of your device at a safe
level BEFORE your hearing adapts.
To establish a safe volume level:
a. Start your volume control at a low setting.
b. Slowly increase the sound until you can hear it comfortably and clearly,
and without distortion. Once you have established a comfortable sound
level, leave it there.
This manual may not reflect your actual device’s operation. All infor mation is subject to change
without prior notification. Please follow your actual device’s operational procedures.
3
Table of Contents
Safety Precautions...................................................................................................... 1
Listening Cautions ...................................................................................................... 3
Feature Summary ....................................................................................................... 5
Accessories ................................................................................................................5
Buttons & Ports........................................................................................................... 5
Charging Battery......................................................................................................... 5
Installing Memory Card............................................................................................... 6
Transferring Files........................................................................................................ 6
Turning On/Off the Device ..........................................................................................6
Unlocking the Screen.................................................................................................. 7
Home Screen.............................................................................................................. 7
Tips of touching screen............................................................................................... 9
Accessing Internet ...................................................................................................... 9
Using the Virtual Keyboard.......................................................................................10
Reading E-Books...................................................................................................... 11
Playing Music............................................................................................................ 12
Playing Video............................................................................................................ 13
HDMI Output......................................................................................................13
Viewing Photos.........................................................................................................14
Using the Camcorder/Camera .................................................................................. 15
Exploring Files .......................................................................................................... 15
Sending/Receiving E-mails....................................................................................... 17
Managing Apps.........................................................................................................19
Managing Tasks........................................................................................................ 20
Troubleshooting........................................................................................................20
Specifications............................................................................................................ 20
4
Feature Summary
● Wi-Fi & 3G network ● 10.1” Touch Screen ● 3
● Built-in Webcam ● Built-in G-sensor ● Media Player
rd
Party Apps Support
Accessories
z Main Unit ● USB cable ● AC Adaptor
z User Manual ● Warranty Card
Buttons & Ports
1. Earphone socket– Connects to stereo earphone.
2. Micro USB port–Connects to PC through USB cable; to USB keyboard, mouse, U disk or 3G
Dongle through USB host cable.
3. HDMI jack–Connects to HD TV that support HDMI connection.
4. TF card slot– Accommodate the TF (Micro SD) card.
5. DC IN socket– Connects to any standard outlet through the provided AC adaptor.
6. Built-in microphone
7. Power button–Press and hold to turn on/off the device; briefly press to turn on/off the screen;
long press for about ten seconds to reset the device.
8. Vol+/- – Turn up/down the volume.
9. Charge indicator
10. Front camera
11. Rear Camera
12. Touch screen
13. Built-in speakers
Charging Battery
The device has a built-in rechargeable battery. No extra battery installation is required.
Just charge the device when it indicates low battery.
To charge the battery, connect the device to any standard wall outlet via the DC-IN
5
port using the power adaptor. It takes about 5 hours to fully charge the battery. The
charge indicator should light red during charging, and should light green as the battery
is fully charged.
Note:
a. You are strongly recommended to charge the battery immediatel y when the devic e indica tes the batt ery
is lower than 15%!
b. For extended battery life, it is suggested NOT to use the device when it is charging.
c. For maximum performance, lithium-ion batteries need to be used often. If you don’t use the device
often, be sure to recharge the battery at least once per month.
d. Be sure to use only the dedicated power adaptor provided with the unit for charging.
Installing Memory Card
This device can read files directly from memory card.
To use a memory card, find the card slot on the device and then insert the memory
card into the slot in the correct orientation. To access the files stored in the memory
card, enter the Explorer/ASTRO mode by tapping the Explorer /ASTRO icon and
select the “SD Card” directory.
Transferring Files
Before reading or playing files, you may need to transfer media files from a computer
to the device.
(1) Connect the device to a computer with the supplied USB cable. Two removable
disks will be added to the computer, respectively referring to the internal flash
memory and the SD card.
(2) Once the connection is done, turn on the USB storage.
(3) Open a removable disk, then copy files from the PC to it.
Note:
Since pre-installed applications and Android OS occupies a considerable part of capacity – about 2.0GB, it
is normal that you see huge difference between available memory space and total capacity.
Turning On/Off the Device
To turn on the device, press and hold the Power button on the unit before you see the
boot-up screen then release. It may take one or two minutes to start up the system,
please be patient before you proceed.
To turn off th e dev ice, press and hold the Power button to bring up the option “Power
Off”, then tap on “Power Off” and then tap on “OK”.
6
Tip: For the sake of power saving, this device may sleep with the screen display locked
when there is no touch action for a while (depending on the actual setting of Screen
Timeout). You can briefly press the Power button to wake it up.
The screen will be locked after the device is idle for a few seconds. You need
to unlock the screen by dragging the lock icon
continue to use the device.
rightwards before you
Home Screen
Unlocking the Screen
b
c
The Extended Home Screen
The Home Screen consists five separate screens for positioning the shortcuts, widgets etc..
Slide your finger left or right on the screen to go to the extended screens.
Customizing Home Screen Items
y To add a Home Screen item (shortcut, widget etc.), you can tap the application icon to
display all applications and widgets.
y Hold your tap on an item to place it on the home page. (Note: If current page of Home
Screen has no enough room for a shortcut or widget, you will be prompted that there is no
more room.)
a
a. Apps Button- Enter the apps menu
page.
b. Return
c. Home-Go to the Home Page.
d. Recently Opened Apps
e. Battery Level
e
7
Loading...
