Yetter 2967-031 User Manual

2967-031

RESIDUE MANAGER ATTACHMENT

FOR

2960-130 - UNIT MOUNTED

DOUBLE ARM

CONSERVATION

YETTER MANUFACTURING CO.
FOUNDED 1930

Colchester, IL 62326-0358
Toll free: 800/447-5777
309/776-3222 (Fax)

Website: www.yetterco.com
E-mail: [e-mail]

COULTER

FOREWORD

You’ve just joined an exclusive but rapidly
growing club.

For our part, we want to welcome you to the
group and thank you for buying a Yetter product.

We hope your new Yetter products will help you
achieve both goals-increase your productivity
and increase your efficiency so that you may
generate more profit.

This operator’s manual has been designed into
four major sections: Foreword, Safety
Precautions, Installation Instructions and Parts
Breakdown.

This SAFETY ALERT SYMBOL indicates

important safety messages in the manual.
When you see this symbol, be alert to the
possibility of PERSONAL INJURY and carefully
read the message that follows.

The word NOTE is used to convey information
that is out of context with the manual text. It
contains special information such as
specifications, techniques and reference
information of a supplementary nature.

The word IMPORTANT is used in the text when
immediate damage will occur to the machine due
to improper technique or operation. Important
will apply to the same information as specified by
note only of an immediate and urgent nature.

WARRANTY

Yetter Manufacturing warrants all products manufactured and sold by it against defects in material. This
warranty being expressly limited to replacement at the factory of such parts or products as shall appear to be
defective after inspection. This warranty does not obligate the Company to bear cost of labor in replacement of
parts. It is the policy of the Company to make improvements without incurring obligations to add them to any
unit already sold. No warranty is made or authorized to be made, other than herein set forth. This warranty is in
effect for one year after purchase.

Dealer ___________________________________________________

Yetter Manufacturing warrants its own products only and cannot be responsible for damages to
equipment on which mounted.

It is the responsibility of the user to read the
operator’s manual and comply with the safe and
correct operating procedure and to lubricate and
maintain the product according to the
maintenance schedule in the operator’s manual.

The user is responsible for inspecting his
machine and for having parts repaired or
replaced when continued use of the product
would cause damage or excessive wear to the
other parts.

It is the user’s responsibility to deliver his
machine to the Yetter dealer who sold him the
product for service or replacement of defective
parts, which are covered by the warranty policy.

If you are unable to understand or follow the
instructions provided in this publication, consult
your local Yetter dealer or contact:

YETTER MANUFACTURING CO.

309/776-4111
800/447-5777

309/776-3222 (FAX)
Website: www.yetterco.com
E-mail: [e-mail]

2

SAFETY

A brief description of signal words that may be used in this manual:

CAUTION: Used as a general reminder of good safety practices or to direct attention to unsafe practices.

WARNING: Denotes a specific potential hazard.

DANGER: Denotes the most serious specific potential hazard.

SAFETY PRECAUTIONS

You can make your farm a safer place to live and work if you observe the

safety precautions given. Study these precautions carefully and insist

that they be followed by those working with you and for you.

Finally, remember this: an accident is usually caused by someone’s carelessness, neglect or oversight.

WARNING

Never clean, lubricate or adjust a machine that is in motion. Always

lower or block the implement before performing service.

If machine must be serviced in the raised position, jack or block it up to prevent it from accidentally falling and
injuring someone.

Do not allow riders on the tractor or implement.

Use speeds and caution dictated by the terrain being traversed. Do not operate on any slope steep enough to
cause tipping or loss of control.

Be sure all personnel are clear of the immediate area before operating.

Read and understand the operator’s manual and require all other persons who will operate the equipment to do
the same.

Be familiar with all tractor and implement controls and be prepared to stop engine and implements quickly in an
emergency.

CAUTION

Consult your implement and tractor operator’s manual for correct and safe operating practices.

Beware of towed implement width and allow safe clearance.

FAILURE TO HEED MAY RESULT IN PERSONAL INJURY OR DEATH.

3

INSTALLATION

1. Attach the 2967-585 adjustment plate to the coulter arm using 2) ½” x 1 ¼” bolts and lock
nuts.

2. Remove the ½” x 5” bolt which attaches the coulter arms to the mounting brackets
through the slot. Save the ½” lock nut and the ½” flat washers for later use.

CAUTION: DO NOT USE SPACER STRAP ON COMBO ARM W.A. AS A

HANDLE, FINGERS MAY BE SERIOUSLY INJURED ON SHARP EDGE OF

BLADE. USE ½” SQ. DRIVE SOCKET TOOLS TO ADJUST THIS PART.

3. Assemble the 2967-190 Residue Manager wheel/arm assembly to the coulter with the ½”
x 8” bolt and 2967-586 spacers. Use the ½” locknut and flat washers removed in step 1.
Tighten this bolt securely. The ½” x 8” bolt must be through the TOP
arms.

4. Check the alignment of all holes in the 2967-280 combo arm and the 2967-585
adjustment plate with the combo adjustment pin. Securely tighten all bolts.

hole of the coulter

4

PARTS IDENTIFICATION

5
