How to Connect MyPBX to NeoGate TE100 via SIP Trunking
How to Connect MyPBX to NeoGate
TE100 via SIP Trunking
Version: 1.0
Yeastar Technology Co., Ltd.
Date: January, 2014
http://www.yeastar.com 1/11
Page 2
How to Connect MyPBX to NeoGate TE100 via SIP Trunking
Contents:
1. Introduction ................................................................................................................................. 3
2. Connect MyPBX to NeoGate TE100 ....................................................................................... 4
2.1 Create a Service Provider SIP Trunk on MyPBX ....................................... 4
2.2 Create a VoIP Trunk on NeoGate TE100 ................................................. 5
2.3 Setup E1 trunk on NeoGate TE100 referring to the E1 trunk provider ........ 6
3. Outgoing Call from MyPBX Extension via E1 ........................................................................ 7
3.1 Create an Outbound Route on MyPBX .................................................... 7
3.2 Create Route on NeoGate TE100 ........................................................... 8
3.3 Set DOD for MyPBX Extensions on MyPBX .............................................. 9
4. Incoming Call from E1 to MyPBX .......................................................................................... 10
4.1 Create ‘FromTEToMyPBX’ Route on NeoGate TE100 ............................... 10
4.2 Create an Inbound Route on MyPBX .................................................... 11
http://www.yeastar.com 2/11
Page 3
How to Connect MyPBX to NeoGate TE100 via SIP Trunking
1. Introduction
This application note shows how to connect MyPBX to NeoGate TE100 via SIP trunking.
Target：
1. Make outbound calls from MyPBX extension through the E1 trunks of NeoGate TE100
directly.
2. Receive calls from E1 trunks of NeoGate TE100 at MyPBX.
Description：
IP address of MyPBX: 192.168.5.142
IP address of NeoGate TE100: 192.168.5.239
E1 DID range: 5551000-5551099
E1 DOD range: 5551000-5551099
Figure 1
http://www.yeastar.com 3/11
Page 4
How to Connect MyPBX to NeoGate TE100 via SIP Trunking
2. Connect MyPBX to NeoGate TE100
2.1 Create a Service Provider SIP Trunk on MyPBX
Path: PBX→Trunks→VoIP Trunk→Add Service Provider
Figure 2
Trunk Type: Service Provider
Provider Name: NeoGateT100
Hostname/IP: 192.168.5.239
After save and apply the changes, you will see the trunk is ‘ok’ in ‘Line Status’ page.
Path:Status→Line Status→Trunk Status
Figure 3
http://www.yeastar.com 4/11
Page 5
How to Connect MyPBX to NeoGate TE100 via SIP Trunking
2.2 Create a VoIP Trunk on NeoGate TE100
Path: Gateway→VoIP Settings→VoIP Trunk→Add VoIP Trunk
Choose "Service Provider" mode, and fill in MyPBX IP address.
Figure 4
Trunk Type: Service Provider
Provider Name: MyPBX
Hostname/IP: 192.168.5.142
After save and apply the changes, you will see the trunk is ‘ok’ in ‘Line Status’ page.
Path:Status→System Status→Trunk Status
Figure 5
http://www.yeastar.com 5/11
Page 6
How to Connect MyPBX to NeoGate TE100 via SIP Trunking
2.3 Setup E1 trunk on NeoGate TE100 referring to the
E1 trunk provider
Figure 6
After save and apply changes, please check the E1 trunk status on Status -> System
Status -> Trunk status
Figure 7
http://www.yeastar.com 6/11
Page 7
How to Connect MyPBX to NeoGate TE100 via SIP Trunking
3. Outgoing Call from MyPBX Extensions
through E1
Figure 8
3.1 Create an Outbound Route on MyPBX
Path: PBX→ Outbound call control → outbound routes
Choose the VoIP trunk "NeoGateTE100" and set the rule for the outbound as the picture
shows, which allows users to dial out any number out.
http://www.yeastar.com 7/11
Page 8
How to Connect MyPBX to NeoGate TE100 via SIP Trunking
Figure 9
3.2 Create Route on NeoGate TE100
Path: GatewayRoutes SettingsRoutes List
Figure 10
http://www.yeastar.com 8/11
Page 9
How to Connect MyPBX to NeoGate TE100 via SIP Trunking
Simple Mode: Yes
Call Comes in From: ServiceProvider-MyPBX.
Send Call Through: Trunk—E1Trunk1.
3.3 Setup DOD for MyPBX Extensions on MyPBX
Figure 11
For example, we set extension 301 as DOD number 5551001.When you use extension
301 to make outgoing call through NeoGate TE100, callee will see the caller ID number
5551001.
http://www.yeastar.com 9/11
Page 10
How to Connect MyPBX to NeoGate TE100 via SIP Trunking
4. Incoming Call from E1 to MyPBX
Figure 12
4.1 Create ‘FromTEToMyPBX’ Route on NeoGate
TE100
Path: Gateway→Routes Settings→Routes List
Figure 13
Simple Mode: Yes
Call Comes in From: Trunk—E1Trunk1.
Send Call Through: ServiceProvider-MyPBX.
http://www.yeastar.com 10/11
Page 11
How to Connect MyPBX to NeoGate TE100 via SIP Trunking
4.2 Create an Inbound Route on MyPBX
Path: PBX→Inbound Call Control→Inbound Routes
In this guide, we set the DID number as 5551001 and set destination to extension 301.
Figure 14
DID number: 5551001 (which is same to the E1 trunk external number)
Set Destination: 301
After saving the settings, you can dial the E1 DID number 5551001 from the mobile phone,
the call will be routed to the extension 301 on MyPBX.
<End>
