Included In This Package
Clearholic Speaker
Micro USB Cable
3.5mm Aux Cable
User Manual
Overview
Troubleshooting
LED Indicators
Indicator Status
RED Charging
GREEN Fully Charged
BT Flashing BLUE Pairing Mode
[Pair with
single
Clearholic
BTS800]
BLUE Connected
Clearholic BTS800
Bluetooth Speakers
User Manual
Front view Back view
L / R Pairing
Button
LED
Indicator
Micro USB
Power
Input
Line-in
Power Button
Indicator Status
BT
[Pair with 2
Clearholic
BTS800]
Volume Control
After Paired with the Smartphone device
Press L each time to volume DOWN
Press R each time to volume UP
DO NOT HOLD THE L/R BUTTON FOR VOLUME
UP/DOWN, BECAUSE IT WILL ENTER TO THE
SEARCHING MODE FOR STEREO FUNCTION
How to Charge Clearholic BTS800
1.Plug the Clearholic BTS800 into your computer
or USB compatible wall charger via the included
Micro USB Cable.
2.When the Clearholic BTS800 is fully charged,
disconnect the cable.
Note: Approximately 3 – 4 hours required for full
Press “L” on one
BTS800 and press
“R” on the other
one BTS800,
ashing red LED
to represent
linking up with
another BTS800
Speaker
Paired between 2
BTS800 and ready
for pair with the
music device
Connected and
can play for stereo
mode
Flashing RED
RED on one
BTS800 and
Flashing BLUE on
the other BTS800
RED on one
BTS800 and BLUE
on the other
BTS800
charge. Battery will last up to 6 hours of
continuous playback.
Getting Connected for Bluetooth Pairing
1. Press the power button for three seconds to
turn on the speaker. The BT LED indicator
blinks blue and the speaker is discoverable
and ready for pairing.
2. On your Bluetooth music device, turn on
Bluetooth and scan for devices in its
Bluetooth menu.
3. When the “Ye!! – BTS800” appears on the
device list of your device, select “Ye!! –
BTS800”. The BT LED indicator turns solid
blue after pairing is established. The speaker
is now ready to play music.
Power Button
240mm (W) x 115mm (H)
Computer
(not included)
USB Compatible
Wall charger
(not included)
or
C
M
Y
CM
MY
CY
CMY
K
Stereo Pairing Setup ***An additional
Clearholic BTS800 speaker is required***
The Clearholic BTS800 speaker is equipped
with Stereo Pairing feature. To connect two
Clearholic speakers together with a true left /
right stereo signal:
1. Press the power button on both BTS800 for
three seconds to turn on the speakers. The
BT LED indicators blink red.
2. Press the “L” pairing button from one
Clearholic speaker and “R” pairing button on
the other set of speaker for three seconds at
the same time.
3. The BT LED indicator on one speaker turns
solid red once the speakers linked up with
each other and the other speaker keeps
blink blue.
4. On your Bluetooth music device, turn on
Bluetooth and scan for devices in its
Bluetooth menu.
5. When the “Ye!! – BTS800” appears on the
device list of your device, select “Ye!! –
BTS800”. The BT LED indicator turns solid
blue after pairing is established. The
speakers are now ready to play music in
stereo mode.
Reconnecting Bluetooth Device
Keep in mind that the Bluetooth Speaker has a
Bluetooth device, the Bluetooth Speaker will
disconnect from your device. To reconnect,
simply follow the instruction in the “Getting
Connected” section.
Changing Connected Bluetooth Device
1. Disable the Bluetooth function of your
Bluetooth device.
2. The Bluetooth Speaker can now be
3. Following the instructions in the “Getting
Connected” section
Play Audio from Non-Bluetooth Device
Turn on the speaker, connect the Bluetooth
Speaker and your non-Bluetooth audio device
via the included 3.5 mm Aux cable. The
speaker is ready to play music.
Model No.: BTS800
Output Power: 3W + 5W
Input Voltage: DC 5V / 1A
Charge Time: 3 - 4 hours
Input: Wireless Bluetooth &
3.5mm wired auxiliary
Playback Time: Up to 6 hours on
Bluetooth
Bluetooth Version: Bluetooth 3.0 with EDR
Operating Distance: Up to 33 feet (10 metres)
Dimensions: 175 x 90 x 75 mm
Weight: 460 grams
Troubleshooting
No connection between Bluetooth Speaker
and your Bluetooth device.
• Make sure the Bluetooth Speaker is fully
charged
• Make sure the press and hold the power
button to activate the pairing mode.
• Make sure your Bluetooth device is available
and supports Bluetooth Advance Audio
• Make sure the Bluetooth Speaker is within
range of your Bluetooth device.
Audio is not coming out from the Bluetooth
Speaker after Bluetooth device successfully
paired.
• Make sure the Bluetooth device volume is set
to a comfortable listening level.
Audio is not coming out from the Bluetooth
Speaker after the non-Bluetooth device
connected with the 3.5 mm Aux cable.
• Make sure the 3.5 mm Aux cable is correctly
Speaker and non-Bluetooth device.
• Make sure the non-Bluetooth device is set to
a comfortable listening level.
Precautions
1. The radio waves emitted by the Bluetooth
operation of nearby electronics including
medical devices.
2. Keep the unit in a cool, dry place.
For more information, please visit
www.yelltowin.com
Designed by Ye!! in Hong Kong
Assembled in China
