model number 060-1723-0 | contact us: 1.866.523.5218
IMPORTANT:
Read and follow all safety rules and operating
instructions before using this product.
Instruction
Manual
12 AMP ELECTRIC LAWN MOWER
3025736
model number 060-1723-0 | contact us: 1.866.523.5218
3
TECHNICAL DATA
Rated Voltage 120 V~ 60 Hz
Rated Power 12 A
No Load Speed 3500 RPM
Deck Diameter 20’’ (50.8 cm)
Cutting Path 19’’ (48 cm)
Front Wheel Diameter 7’’ (18 cm)
Rear Wheel Diameter 10’’ (25 cm)
Cutting Height 1 1/4 –4” (3.1–10.1 cm)
Cutting Height Positions 7
Grass Collection Capacity 1.4 bushels (50L)
Mower Weight 43 lb 11 oz (19.8 kg)
Technical Data 3
Product Safety 4
Know Your Lawn Mower 10
Accessories 10
Exploded View 11
Parts List 12
Assembly & Operation 14
Mulching Mowing Tips 19
Maintenance 19
Troubleshooting 21
Symbols 22
Warranty 24
Table of ContentsTechnical Data
model number 060-1723-0 | contact us: 1.866.523.5218model number 060-1723-0 | contact us: 1.866.523.5218
4
READ ALL INSTRUCTIONS
WARNING: When using electric lawn
mowers, basic safety precautions should
always be followed to reduce the risk of re,
electric shock, and personal injury, including
the following:
WARNING: Risk of injury could occur if the
lawn mower is operated without the catcher
assembly attached.
WARNING: The use of any other accessory
or attachment might increase the risk of
injury.
a) FOR ALL DOUBLE-INSULATED LAWN
MOWERS
1) Replacement Parts
When servicing use only identical
replacement parts.
2) Polarized Connections
To reduce the risk of electric shock, this
mower has a polarized plug (one blade is
wider than the other) and will require the use
of a polarized extension cord. The plug will t
into a polarized extension cord only one way.
If the plug does not t fully into the extension
cord, reverse the plug. If the plug still does
not t, obtain a correct polarized extension
cord. A polarized extension cord will require
the use of a polarized wall outlet. This plug
will t into the polarized wall outlet only one
way. If the plug does not t fully into the wall
outlet, reverse the plug. If the plug still does
not t, contact a qualied electrician to install
the proper wall outlet. Do not change the
mower plug, extension cord receptacle, or
extension cord plug in any way.
b) FOR ALL LAWN MOWERS
1) Avoid dangerous envirionments - Don’t
use lawn mowers in damp or wet
locations.
2) Don’t use in rain.
3) Keep children away - All visitors should
be kept a safe distance from work area.
4) Dress properly - Do not wear loose
clothing or jewellery. They can be caught
in moving parts. Use of rubber gloves
and footwear is recommended when
working outdoors.
5) Use safety glasses - Always use face or
dust mask if operation is dusty.
6) Use right lawn mower - Do not use lawn
mower for any job except that for which it
is intended.
7) Ground Fault Circuit Interrupter (GFCI)
protection should be provided on the
circuit(s) or outlet(s) to be used for the
lawn mower. Receptacles are available
having built-in GFCI protection and may
be used for this measure of safety.
8) Warning - To prevent electric shock use
only with an extension cord suitable for
!
WARNING: Read all instructions.
!
WARNING: When using electric garden products, basic safety precautions
should always be followed to reduce the risk of re, electric shock, and personal
injury, including the following:
Product Safety
5
Product Safety
outdoor use, such as SW, SOW, STW,
STOW, SJW, SJOW, SJTW, or SJTOW.
9) Extension Cord - Make sure your
extension cord set is in good condition.
When using an extension cord, be sure
to use one heavy enough to carry the
current your product will draw. For
lengths less than 25’ or 50’ (7.2 m or
15.2 m) feet, No. 16/16 AWG extension
cord should be used. An undersized cord
will cause a drop in line voltage resulting
in loss of power and overheating.
(NOTE: Table 1 shows the correct size
to use depending on cord length and
nameplate ampere rating. If in doubt, use
the next heavier gauge. The smaller the
gauge number the heavier the cord.) To
reduce the likelihood of disconnection
of lawn mower cord from the cord set
during operating:
i) Make a knot as shown in Figure 1, or
iI) Use one of the plug-receptacle
retaining straps or connectors described
in this manual.
10) Don’t abuse cord - Never pull lawn
mower by cord or yank it to disconnect
from receptacle. Keep cord from heat,
oil, and sharp edges.
11) Don’t force lawn mower - It will do the job
properly and safer at the rate for which it
was designed.
12) Don’t overreach - Keep proper footing
and balance at all times.
13) Stay alert - Watch what you are doing.
Use common sense. Do not operate
lawn mower when you are tired.
14) Disconnect lawn mower - Disconnect
the lawn mower from the power supply
when not in use, before servicing, when
changing accessories such as blades,
and the like.
15) Store idle lawn mower indoors - When
not in use, lawn mower should be stored
in an indoor dry and locked-up place out of reach of children.
16) Maintain lawn mower with care - Keep
cutting edges sharp and clean for
best and safest performance. Follow
instructions for lubricating and changing
accessories. Inspect lawn mower cord
periodically and if damaged, have it
repaired by an authorized service facility.
Inspect extension cords periodically and
replace if damaged. Keep handles dry,
clean, and free from oil and grease.
17) Keep guards in place and in working
order.
18) Keep blades sharp.
19) Keep hands and feet away from cutting
area.
20) Objects struck by the lawn mower blade
can cause severe injuries to persons.
The lawn should always be carefully
examined and cleared of all objects prior
to each mowing.
!
WARNING: Read all safety warnings and instructions. Failure to follow
the warnings and instructions may result in electric shock, re and/or
serious injury.
model number 060-1723-0 | contact us: 1.866.523.5218
6
21) If lawn mower strikes a foreign object,
follow these steps:
i) Stop lawn mower. Release the switch.
ii) Unplug power cord.
iii) Inspect for damage.
iv) Repair any damage before restarting
and operating the lawn mower.
22) Use identical replacement blades only.
Table 1
Minimum gauge for extension cords
Volts Total length of cord
120 V
25’
7.2 m
50’
15.2 m
100’
30.4 m
150’
45.7 m
Ampere
rating
more than
not more
than
AWG
0-6
18 16 16 14
6-10
18 16 14 12
10-12
16 16 14 12
12-16
14 12
Not
recommended
Figure 1
Method of securing cord set
CORD SET
APPLIANCE CORD
(A) TIE CORD AS
SHOWN
(B) CONNECT PLUG
AND RECEPTACLE
SAFETY
INSTRUCTIONS FOR WALK-BEHIND
MOWERS
IMPORTANT
Safe Practices for Walk-Behind Mowers
I. GENERAL OPERATION
1. Read, understand, and follow all
instructions on the mower and in the
manual(s) before starting.
2. Do not put hands or feet near or under
the mower. Keep clear of the discharge
opening at all times.
3. Only allow responsible adults, who are
familiar with the instructions, to operate
this mower.
4. Clear the area of objects such as rocks,
wire, toys, etc., which could be thrown by
the blade. Stay behind the handle when
the motor is running.
5. Be sure the area is clear of bystanders
before operating. Stop mower if anyone
enters the area.
6. Do not operate mower barefooted or
while wearing sandals. Always wear
proper footwear.
7. Do not pull mower backward unless
absolutely necessary. Always look down
and behind before and while moving
backward.
8. Never direct discharged material toward
anyone. Avoid discharging material
against a wall or obstruction. Material
may ricochet back toward the operator.
Stop the blade when crossing gravel
surfaces.
9. Do not operate mower without the entire
grass catcher, discharge guard, rear
guard, or other safety protective devices
in place and working.
SAVE THESE INSTRUCTIONS!
Product Safety
7
10. Never leave a running mower
unattended.
11. Stop the motor and wait until the blade
comes to a complete stop before
cleaning the mower, removing grass
catcher, or unclogging the discharge
guard.
12. Operate mower only in daylight or good
articial light.
13. Do not operate mower while under the
inuence of alcohol or drugs.
14. Never operate mower in wet grass.
Always be sure of your footing; walk,
never run.
15. Disengage the drive system, if so
equipped, before starting the motor.
16. If the mower should start to vibrate
abnormally, stop the motor and check
for the cause immediately. Vibration is
generally a warning of trouble.
17. Always wear eye protection when
operating mower.
18. See manufacturer’s instructions for
proper operation and installation of
accessories. Only use accessories
approved by the manufacturer.
II. SLOPE OPERATION
Slopes are a major factor related to slip and
fall accidents, which can result in severe
injury. Operation on all slopes requires extra
caution. If you feel uneasy on a slope, do not
mow it.
1. Mow across the face of slopes; never
up and down. Exercise extreme caution
when changing direction on slopes.
2. Watch for holes, ruts, bumps, rocks, or
other hidden objects. Uneven terrain
could cause a slip and fall accident. Tall
grass can hide obstacles.
3. Do not mow on wet grass or excessively
steep slopes. Poor footing could cause a
slip and fall accident.
4. Do not mow near drop-offs, ditches,
or embankments. You could lose your
footing or balance.
III. CHILDREN
Tragic accidents can occur if the operator
is not alert to the presence of children.
Children are often attracted to the mower
and the mowing activity. Never assume that
children will remain where you last saw
them.
1. Keep children out of the mowing
area and under the watchful care of
a responsible adult other than the
operator.
2. Be alert and turn mower off if a child
enters the area.
3. Never allow children to operate the
mower.
4. Use extra care when approaching blind
corners, shrubs, trees, or other objects
that may block your view of a child.
IV. SERVICE
GENERAL SERVICE
1. Keep all nuts and bolts tight to be sure
the mower is in safe working condition.
2. Never tamper with safety devices. Check
their proper operation regularly.
3. Keep mower free of grass, leaves, or
other debris build-up.
4. If you strike a foreign object, stop and
inspect the mower. Repair, if necessary,
before starting.
5. Never make any adjustments or repairs
with the motor running.
Product Safety
model number 060-1723-0 | contact us: 1.866.523.5218
8
6. Always unplug electric mowers before
adjusting, cleaning, or repairing.
7. Check grass catcher components
and the discharge guard frequently
and replace with manufacturer’s
recommended parts, when necessary.
8. Mower blades are sharp. Wrap the blade
or wear gloves, and use extra caution
when servicing them.
9. Maintain or replace safety and
instruction labels, as necessary.
Safe operation practices for walk-behind
1. Safety Instructions
1.1 Training
a) Read the operating and service
instruction manual carefully. Be
thoroughly familiar with the controls and
the proper use of the mower.
b) Never allow children to operate a power
mower.
c) Keep the area of operation clear of all
persons, particularly small children, and
pets.
d) Do not use a mower for any job except
that for which it is intended.
1.2 Preparation
a) Thoroughly inspect the area where the
mower is to be used and remove all
stones, sticks, wires, bones, and other
foreign objects.
b) Do not operate the mower when barefoot
or wearing sandals. Always wear proper
footwear.
c) Disengage the self-propelled
mechanism or drive clutch on units so
equipped before starting the motor.
d) Never attempt to make a wheel height
adjustment while the motor is running.
e) Mow only in daylight or in good articial
light.
f) Never operate the mower on wet grass.
Always be sure of your footing. Keep a
rm hold on the handle and walk, never
run.
1.3 Operation
a) Do not put hands or feet near or
under rotating parts. Keep clear of the
discharge opening at all times.
b) Stop the blade(s) when crossing gravel
drives, walks, or roads.
c) After striking a foreign object, stop the
motor, unplug, thoroughly inspect the
mower for any damage, and repair the
damage before restarting and operating
the mower.
d) If the mower should start to vibrate
abnormally, stop the motor and check
immediately for the cause. Vibration is
generally a warning of trouble.
e) Stop the motor and unplug whenever
you leave the mower, before cleaning
the mower housing, and before making
any repairs or inspections.
f) Shut the motor off and wait until the
blade comes to a complete stop before
removing the grass catcher or before
unclogging the chute.
g) Mow across the face of slopes, never
up and down. Exercise extreme caution
when changing direction on slopes. Do
not mow excessively steep slopes.
h) Never operate the mower without proper
guards, plates, or other safety protective
devices in place.
i) Do not wash with a hose, avoid
getting water in motor and electrical
connections.
Product Safety
9
1.4 Maintenance
a) Check the blade and the motor mounting
bolts at frequent intervals for proper
tightness.
b) Keep all nuts, bolts, and screws tight
to ensure the mower is in safe working
condition.
c) Check bag frequently for deterioration
and wear, and replace worn bags.
Check that replacement bags comply
with the original manufacturer’s
recommendations or specications.
d) Replace the blade if it is bent or cracked.
An unbalanced blade causes vibration
that could damage the motor drive unit
or cause personal injury.
e) Sharpen a dull blade equally at each
end to maintain the balance.
f) Clean the blade thoroughly and check
its balance by supporting it horizontally
on a thin nail through its centre hole.
The nail should also be in a horizontal
position. If either end of the blade rotates
downward, remove some metal from
the heavy or lower end until the blade
is balanced. It is balanced when neither
end drops.
Product Safety
model number 060-1723-0 | contact us: 1.866.523.5218
10
8
7
6
5
2
3
4
1
9
10
11
1. Handle Bar
2. Grass Collection Bag
3. Handle Knob
4. Handle Height Adjusting Knob
5. Motor Cover
6. Safety Flap
7.
Safety Button
8. Operating Bail
9. Side-Discharge Cover
10. Side-Discharge Chute
11.
Mulching Plug
12. Blade Bolt (See Fig. K1)
13 Blade (See Fig. K1)
14 Spacer (See Fig. K1)
Grass collection bag
1
Mulch plug 1
Side-discharge chute 1
Spanner 1
We recommend that you purchase your accessories listed in the above list
from the same store that sold you the lawn mower. Refer to the accessory
packaging for further details. Store personnel can assist you and offer advice.
Know Your Lawn MowerAccessories
11
95
96
97
98
99
136
103
113(4)
94
90
U
S
89
T
R
100
93
92
91
P M
Q
N
83(2)
51
49
50(2)
47
46
40
44
43(2)
45
53
41
42
13
M
N
23
27
18
17
16
15
22(6)
21(4)
20(4)
1
2(4)
3
4
5(4)
301(2)
7(2)
9(2)
6
1011302
8(46)
12
19
306
66
67
37
137
138
113(4)
113(2)
139(2)
113(2)
140
144
143
142
307
67
118
66
37
118
126
125
124
114
43
141(4)
113(15)
130
111
110
131109
107
106
108
112
105(2)
65
78
77
76(2)
62(3)
79(2)
43(5)
80
102
81(2)
82(2)
52
86
84
Q
P
85
R
S
U
T
102
101
104
305
14
37
38
39
37
38
39
48(6)
304
Exploded View
model number 060-1723-0 | contact us: 1.866.523.5218model number 060-1723-0 | contact us: 1.866.523.5218
12
1 Ball Bearing 1
2 Spring 4
3 Brake Bracket 2
4 Brake Disc i 2
5
Self Tapping Screw
ST3.0×10
4
6 Big Belt Wheel 1
7 Press Plate i 2
8 Steel Ball 46
9 Shaft Cover 2
10 Cylindrical Pin 1
11 Output Shaft 1
12 Retaining Ring 1
13 Side Discharge Deector 1
14 Mulch Plate 1
15 Bracket 1
16 Ball Bearing 1
17 Washer 1
18
Screw Washer Assembly
4X16
1
19 Timing Belt 1
20
Self Tapping Screw
ST4.8×25
4
21
External Teeth Lock
Washer
4
22
Self Tapping Screw
ST4.2×25
6
23
Screw Washer Assembly
M5X80
2
27
Timing Pinion 1
37 Retaining Ring 4
38 Tire 250 1
39 Wheel 240 1
40 Side Discharge Door 1
41 Spring 1
42 Cylindrical Pin 1
43 Screw M5X12 8
44 Angle Bracket 1
45 Front Decorate Cover 1
46 Name Plate 1
47 Right Support Plate 1
48 Bolt M8X12 6
49 Spring 1
50 Bolt M8X50 2
51 Guard Flap 1
52 Spring 1
53 Top Housing 1
65 Spanner 1
66 Tire 180 1
67 Wheel 170 1
76 Filter 2
77 Transmission Fixed 1
78 Rear Axle 1
79 Anti Grinding Plate 2
80 Rear Cover 1
81 Insulation Cover 2
82 Knob Assembly 2
83 Terminal_port12 2
84 Wire 1
85 Inner Wire 1
86 Clip 1
89
Self Tapping Screw
ST2.9x8
1
90 Backupring 1
91 Switch Cover i 1
92 Spring 1
93 Switch Button 1
94 Sleeve 1
95 Link Rod 1
96 Steel Wire 1
Parts List
Item Description QTY. Item Description QTY.
13
97
Pushing Rod 1
98
Spring 1
99
Fixed Assembly 1
100
Switch 1
101
Sliding Seat 1
102
Cord Clamp 2
103
Bag Frame 1
104
Dust Bag 1
105
Self Tapping Screw
ST3.9x20
2
106
Handle Cover ii 1
107
Handle Substrate 1
108
Handle Cover i 1
109
Spring 1
110
Washer 1
111
Spring Pin 1
112
Deck 1
113
Self Tapping Screw
ST3.9x16
27
114
Wind Deector 1
118
Nut M6 3
124
Locking Knob 1
125
Blade 1
126
Washer 1
130
Left Support Plate 1
136
Switch Cover ii 1
137
Fore Cover 1
138
Clamping Plate 1 1
139
Press Plate 2
140
Clamping Plate 2 1
141
Bolt 4
142
Front Wheel Axle 1
143
Linkage 1
144
Drag Spring 1
301
Brake Disc 2
302
Output Shaft Assembly 1
304
Right Rear Wheel 1
305
Left Rear Wheel 1
306
Right Front Wheel 1
307
Left Front Wheel 1
Item Description QTY. Item Description QTY.
Parts List
model number 060-1723-0 | contact us: 1.866.523.5218model number 060-1723-0 | contact us: 1.866.523.5218
14
ASSEMBLY AND OPERATION
ACTION FIGURE
ASSEMBLE
Assembling the handle bar See Fig. A1
Adjusting the height of the handle See Fig. A2
Assembling the grass collection bag See Fig. B
Assembling the grass collection bag to the lawn mower See Fig. C1, C2, C3
Removing/emptying the grass collection bag See Fig. C4
Installing side-discharge chute See Fig. D1, D2
Installing mulching plug See Fig. E1, E2
OPERATION
Starting See Fig. F1,F2
Stopping See Fig. F3
Adjusting the cutting height See Fig. G
STORAGE
See Fig. H1,H2
Assembly & Operation
15
2
1
A2
A1
B
C1
C2
Assembly
model number 060-1723-0 | contact us: 1.866.523.5218
16
1
2
2
1
B
C1
C2
C3
C4
D1 D2
E1 E2
Assembly
17
1
2
1——1-1/2”(40mm)
2——2” (50mm)
3——2-1/4”(60mm)
4——2-3/4”(70mm)
5——3-1/4”(80mm)
6——3-1/2”(90mm)
7——4”(100mm)
2
1
1
2
3
4
5
6
7
F1
F2
F3
G
H1
H2
Assembly
model number 060-1723-0 | contact us: 1.866.523.5218model number 060-1723-0 | contact us: 1.866.523.5218
18
J-1
J-2
J-3
12
1
2
GRASS SIDE
1——1-1/2”(40mm)
2——2” (50mm)
3——2-1/4”(60mm)
4——2-3/4”(70mm)
5——3-1/4”(80mm)
6——3-1/2”(90mm)
7——4”(100mm)
2
1
13
14
1
2
3
4
5
6
7
F1
F2
F3
G
H1
H2
K1
K2
I
J
Assembly
19
MULCHING MOWING TIPS
While mulching, your new mower is
designed to cut the grass clippings into small
pieces and distribute them back onto the
lawn. Under normal conditions, the mulched
grasses will biodegrade quickly to provide
nutrients to the lawn.
Please review the following
recommendations for optimum mulching
performance.
1. Avoid mowing when the grass is wet
from rain or dew. Wet grass may
form clumps which interfere with the
mulching action and reduce runtime.
The best time to mow grass is in the late
afternoon when the grass is dry and the
newly cut area will not be exposed to
direct sunlight.
2. For best mulching performance, set
the cutting height to remove about one
third of the grass blade length, ideally
no more than 1 1/2” (3.1 cm) in. at one
time. If the lawn is overgrown, it may be
necessary to increase the cut height to
reduce the pushing effort and prevent
overloading the motor. For extremely
heavy mulching, it is advisable to rst
cut at a high cut height setting, and then
re-cut to the nal cut height. Otherwise,
make narrower cuts and mow slowly.
3. For best performance, keep the mower
housing free of built-up grass. From
time to time turn off mower and wait for
the blade to come to a complete stop.
Using an object such as a stick, wipe out
any accumulation of grass in the blade
area. Be careful of the sharp edges of
the blade. Clean often in wet, new grass,
and always after every use.
4. Certain types of grass or grass
conditions may require that an area
be mulched a second time to fully
disperse the grass throughout the lawn.
If cutting a second time, it is advisable
to cut perpendicular (across) the rst
cut pattern. DO NOT CHANGE CUT
PATTERN IN ANY WAY THAT WOULD
CAUSE MOWING DOWN A HILL.
5. Change your cutting pattern from week
to week. This will help prevent matting
and graining of the lawn.
!
CAUTION: Do not attempt to unclog the
blade chamber by dropping or tapping
the mower on the ground. This can damage
the unit. Keep hands clear of blade when
cleaning.
MAINTENANCE
WARNING: Stop the mower and unplug
the lawn mower before performing any
maintenance.
NOTE: To ensure long and reliable
service, perform the following maintenance
procedures regularly. Check for obvious
defects such as a loose, dislodged or a
damaged blade, loose ttings, and worn
or damaged components. Check that the
covers and guards are all undamaged and
are correctly attached to mower. Carry
out any necessary maintenance or repairs
before operating mower. If the mower should
happen to fail despite regular maintenance,
please call our customer helpline for advice
1-866-523-5218.
Mulching Mowing TipsMaintenance
model number 060-1723-0 | contact us: 1.866.523.5218model number 060-1723-0 | contact us: 1.866.523.5218
20
BLADE SHARPENING
Keep blade sharp for best mower
performance. A dull blade does not cut grass
cleanly or mulch properly.
Wear proper eye protection while removing,
sharpening, and installing blade.
Sharpening the blade twice during a mowing
season is usually sufcient under normal
circumstances. Sand causes the blade to
dull quickly. If your lawn has sandy soil,
more frequent sharpening may be required.
Replace bent or damaged blade
immediately.
WHEN SHARPENING THE BLADE: (See
Fig I, page 18)
1. Make sure blade remains balanced.
2. Sharpen blade at the original cutting
angle.
3. Sharpen cutting edges on both ends
of blade to keep it balanced, removing
equal amounts of material from both
ends.
NOTE: 1. Be sure the mower is turned off
and unplugged.
2. Place the mower in stand up
storage mode.
BLADE BALANCING (See Fig J, page 18)
Check balance of blade by placing center
hole in blade J-1 over a nail or screwdriver
shank J-2, clamped horizontally in a vice J-3.
If either end of the blade rotates downward,
le that end. Blade is properly balanced
when neither end drops.
BLADE MAINTENANCE (See Fig. K1, K2)
Replace your metal Blade after 50 hours
mowing or 2 years, which ever is soonerregardless of condition.
Follow these procedures to remove and
replace the Blade. You will need garden
gloves (not provided) and a spanner wrench
(provided) to remove the Blade. Hold the
Blade and unscrew the Blade Bolt counterclockwise using a spanner wrench, and then
remove the Blade.
To re-assemble, position the Blade with the
cutting edges towards the ground. Then
securely tighten the Blade Bolt.
STORAGE (See Fig. H1, H2)
Stop the mower and unplug.
Clean the exterior of the mower thoroughly
using a soft brush and cloth. Do not use
water, solvents or polishes. Remove all
grass and debris, especially from the
ventilation slots.
Turn the mower on its side and clean the
blade area. If grass cuttings are compacted
in the blade area, remove with a wooden or
plastic implement.
Store the mower in a dry place. Do not place
other objects on top of the mower.
To aid storage, release the handle knob and
rotate or fold the upper handle.
Ensure cables are not stuck or entangled
when folding or unfolding upper handles. do
not drop the handles.
Maintenance
21
TROUBLE SHOOTING
PROBLEM SOLUTION
1. Mower doesn’t run when
operation bail is activated.
Release switch lever to turn mower off. Remove safety key,
turn mower over and check that blade is free to turn. If not
free, return to an authorized servicer. Blade should turn freely.
2. Motor stops while
mowing.
A. Release switch lever to turn mower off. Remove safety key,
turn mower over and check that blade is free to turn. If not
free, return to an authorized servicer. Blade should turn freely.
B. Raise cutting height of wheels to highest position and start
mower.
C. Avoid overloading the mower. Slow down the cutting pace
by pushing mower slower or raise the cutting height. Or both.
3. Mower runs but
cutting performance is
unsatisfactory, or does
not cut entire lawn.
A. Release operating bail to turn mower off. Turn mower over
and check: Blade for sharpness - Keep blade sharp. Deck and
discharge chute for clogging.
B. Wheel height adjustment may be set too low for grass
condition. Raise cutting height.
4. Mower is too hard to
push.
A. Raise cutting height to reduce deck drag on grass. Check
each wheel for free rotation.
5. Mower is abnormally
noisy and vibrates.
A. Release operating bail to turn mower off. Turn mower
on side and check blade to ensure it has not been bent or
damaged. If blade is damaged, replace with a replacement
blade. If the underside of the deck is damaged return mower
to an Authorized service centre.
B. If there is no visible damage to the blade and the mower
still vibrates: Release switch lever to turn mower off, remove
blade. Rotate blade 180 degrees and retighten. If mower still
vibrates, return the mower to an authorized service centre.
6. Mower not picking up
clippings with the Grass
Collection Bag.
A. Remove mulch plate when bagging.
B. Chute clogged. Release operating bail to turn mower off.
Clear chute of grass clippings.
C. Too much cut grass. Raise cutting height of wheels to
shorten length of the cut.
D. Bag full. Empty bag more often.
7. When mulching there
are clippings visible.
A. Too much cut grass. Raise cutting height of wheels to
shorten length of the cut. Do not cut off more than 1/3 of total
blade length.
B. Check blade for sharpness. Always keep blade sharp.
Troubleshooting
model number 060-1723-0 | contact us: 1.866.523.5218model number 060-1723-0 | contact us: 1.866.523.5218
22
SAVE THESE INSTRUCTIONS!
V Volts Voltage
A Amperes Current
Hz Hertz Frequency (cycles per second)
W Watts Power
min Minutes Time
Alternating Current Type of current
Direct Current Type of current
Class II Construction Double-insulated construction
/min
Per Minute Revolutions, strokes, surface speed, orbits etc., per minute.
Read The Operator’s
Manual
To reduce the risk of injury, user must read instruction manual.
Ear Protection Wear ear protection.
Operation condition Do not expose to rain.
KEEP HANDS AND FEET AWAY
GARDER MAINS ET PIEDS À DISTANCE
WARNING CPSC Danger label
WARNING Severing of toes or ngers-Rotary mower blade
WARNING Thrown objects from mower deck
WARNING Keep bystanders/children away
WARNING Safety alert
WARNING Sippery on slopes
Symbol Name Designation/Explanation
Symbols
23
WARNING Read the operator’s manual
WARNING
Blade continues to rotate after the mower is switched off. Wait
until all mower components have completely stopped before
touching them.
WARNING Wear protective gloves
WARNING
Before performing any work on the mower, pull the power plug
from the outlet.
Symbols
model number 060-1723-0 | contact us: 1.866.523.5218
24
Warranty
4-YEAR LIMITED EXCHANGE WARRANTY
Four (4) years from the date of purchase
within Canada, YARDWORKS CANADA
will, at its option, repair or replace for the
original purchaser, free of charge, any part
or parts found to be defective in material or
workmanship.
THIS WARRANTY DOES NOT COVER
1. Any part that has become inoperative
due to misuse, commercial use, abuse,
neglect, accident, improper maintenance,
or alteration;
2. The unit, if it has not been operated and/
or maintained in accordance with the
owner’s manual;
3. Normal wear, except as noted below;
4. Routine maintenance items such as
lubricants, blade sharpening; or
5. Normal deterioration of the exterior nish
due to use or exposure.
FULL ONE HUNDRED TWENTY (120) DAYS
WARRANTY ON NORMAL WEAR PARTS
Normal wear parts are dened as blade
adaptors, blades, grass bags and tires.
These parts are warranted to the original
purchaser to be free from defects in material
and workmanship for a period of
one hundred twenty (120) days from the
date of retail purchase.
HOW TO OBTAIN SERVICE
Warranty service is available by calling
the toll-free helpline, at 1.866.523.5218.
The factory will not accept the return of a
complete unit unless prior written permission
has been extended by YARDWORKS
CANADA.
TRANSPORTATION CHARGES
Transportation charges for the movement
of any power mower unit or attachment
are the responsibility of the purchaser.
The purchaser must pay transportation
charges for any part submitted for
replacement under this warranty unless
such return is requested in writing by
YARDWORKS CANADA.
OTHER WARRANTIES
All other warranties, express or implied,
including any implied warranty of
merchantability is limited in its duration to
that set forth in this express limited warranty.
The provisions as set forth in this warranty
provide the sole and exclusive remedy of
YARDWORKS CANADA obligations arising
from the sale of its products.
Made in China
Imported by Yardworks Canada,
Toronto Canada M4S 2B8
Loading...
