Operators Manual
Model Series
370 thru 389
Rotary Mowers
IMPORTANT: READ SAFETY RULES AND INSTRUCTIONS CAREFULLY
Warning:
covered, brush-covered or grass-covered land unless the engine’s exhaust system is equipped with a spark arrester meeting
applicable local or state laws (if any). If a spark arrester is used, it should be maintained in effective working order by the operator.
In the State of California the above is required by law (Section 4442 of the California Public Resources Code). Other states may have
similar laws. Federal laws apply on federal lands. A spark arrester for the muffler is available through your nearest engine authorized
service dealer or contact the service department, P.O. Box 368022 Cleveland, Ohio 44136-9722.
This unit is equipped with an internal combustion engine and should not be used on or near any unimproved forest-
MTD PRODUCTS INC. P.O. BOX 368022 CLEVELAND, OHIO 44136-9722
PRINTED IN U.S.A.
FORM NO. 770-0420A
10/97
2
SECTION 1: IMPORTANT SAFE OPERATION PRACTICES
WARNING: THIS SYMBOL POINTS OUT IMPORTANT SAFETY INSTRUCTIONS WHICH, IF
NOT FOLLOWED, COULD ENDANGER THE PERSONAL SAFETY AND/OR PROPERTY OF
YOURSELF AND OTHERS. READ AND FOLLOW ALL INSTRUCTIONS IN THIS MANUAL
BEFORE ATTEMPTING TO OPERATE YOUR LAWN MOWER. FAILURE TO COMPLY WITH
THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY. WHEN YOU SEE THIS
SYMBOL, HEED ITS WARNING.
WARNING: The Engine Exhaust from this product contains chemicals known to
the State of California to cause cancer, birth defects or other reproductive harm.
DANGER: Your lawn mower was built to be operated according to the rules for safe operation in
this manual. As with any type of power equipment, carelessness or error on the part of the operator
can result in serious injury. This lawn mower is capable of amputating hands and feet and throwing
objects. Failure to observe the following safety instructions could result in serious injury or death.
1. GENERAL OPERATION
• Read this operator’s manual carefully in its entirety
before attempting to assemble this machine. Read,
understand, and follow all instructions on the
machine and in the manual(s) before operation. Be
completely familiar with the controls and the proper
use of this machine before operating it. Keep this
manual in a safe place for future and regular
reference and for ordering replacement parts.
• Your rotary mower is a precision piece of power
equipment, not a plaything. Therefore, exercise
extreme caution at all times. Your unit has been
designed to perform one job: to mow grass. Do not
use it for any other purpose.
• Never allow children under 14 years old to operate
a power mower. Children 14 years old and over
should only operate mower under close parental
supervision. Only responsible individuals who are
familiar with these rules of safe operation should
be allowed to use your mower.
• Keep the area of operation clear of all persons,
particularly small children and pets. Stop engine
when they are in the vicinity of your mower to help
prevent blade contact or thrown object injury.
Although the area of operation should be
completely cleared of foreign objects, an object
may have been overlooked and could be
accidentally thrown by the mower in any direction
and cause serious personal injury to the operator
or any others allowed in the area.
• Wear sturdy, rough-soled work shoes and closefitting slacks and shirts. Shirts and pants that cover
the arms and legs and steel-toed shoes are
recommended. Do not wear loose fitting clothes or
jewelry. They can be caught in moving parts.
Never operate a unit in bare feet, sandals, slippery
or light weight (e.g. canvas) shoes.
• Always wear safety glasses or safety goggles
during operation or while performing an adjustment
or repair, to protect eyes from foreign objects that
may be thrown from the machine in any direction.
• Thoroughly inspect the area where the equipment
is to be used. Remove all stones, sticks, wire,
bones, toys and other foreign objects which could
be picked up and thrown by the mower in any
direction and cause serious personal injury to the
operator or any others allowed in the area. Plan
your mowing pattern to avoid discharge of material
toward roads, sidewalks, bystanders and the like.
To help avoid a thrown objects injury, keep
children, bystanders and helpers at least 75 feet
from the mower while it is in operation.
• Do not put hands or feet near or under rotating
parts. Keep clear of discharge opening at all times
as the rotating blade can cause injury.
• Many injuries occur as a result of the mower being
pulled over the foot during a fall. Do not hang on to
the mower if you are falling; release the handle
immediately.
• Never pull the mower toward you while you are
walking. If you must back the mower away from a
wall or obstruction first look down and behind, and
then follow these steps:
• Step back from the mower to fully extend your
arms.
• Be sure you are well balanced with sure
footing.
• Pull the mower back slowly, no more than half
way toward you.
• Repeat these steps as needed.
• Do not operate the mower while under the
influence of alcohol or drugs.
3
• Do not engage the self-propelled mechanism on
units so equipped while starting engine.
• The blade control handle is a safety device. Never
attempt to bypass its operation. Doing so makes
the safety device inoperative and may result in
personal injury through contact with the rotating
blade. The blade control handle must operate
easily in both directions and automatically return to
the disengaged position when released.
• Never operate the mower in wet grass. Always be
sure of your footing. A slip and fall can cause
serious personal injury. Keep a firm hold on the
handle and walk, never run. If you feel you are
losing your footing, RELEASE THE BLADE
CONTROL HANDLE IMMEDIATELY and the
blade will stop rotating within three seconds.
• Mow only in daylight or good artificial light.
• Stop the blade when crossing gravel drives, walks
or roads.
• If the equipment should start to vibrate abnormally,
stop the engine and check immediately for the
cause. Vibration is generally a warning of trouble.
• Shut the engine off and wait until the blade comes
to a complete stop before removing the grass
catcher or unclogging the chute. The cutting blade
continues to rotate for a few seconds after the
engine is shut off. Never place any part of the body
in the blade area until you are sure the blade has
stopped rotating.
• Never operate mower without proper guards, grass
catcher, plates or other safety protective devices in
place.
• Muffler and engine become hot and can cause a
burn. Do not touch.
• Only use accessories approved for this machine
by the manufacturer. Read, understand, and follow
all instructions provided with the approved
accessory.
• If situations occur which are not covered in this
manual, use care and good judgment. Contact
your dealer for assistance. Telephone 1-800-8007310 for the name of your nearest dealer.
2. SLOPE OPERATION
For your safety, use the slope gauge included as part of
this manual to measure slopes before operating this unit
on a sloped or hilly area. If the slope is greater than 15
degrees as shown on the slope gauge, do not operate this
unit on that area or serious injury could result.
DO:
• Mow across the face of slopes; never up and
down. Exercise extreme caution when changing
direction on slopes.
• Watch for holes, ruts, hidden objects, or bumps.
Tall grass can hide obstacles.
• Always be sure of your footing. A slip and fall can
cause serious personal injury. If you feel you are
losing your balance release the blade control
handle immediately and the blade will stop in less
than 3 seconds.
DO NOT:
• Do not mow near drop-offs, ditches or
embankments. The operator could lose footing or
balance.
• Do not mow slopes greater than 15 degrees as
shown on the slope gauge.
• Do not mow on wet grass. Reduced footing could
cause slipping.
3. CHILDREN
Tragic accidents can occur if the operator is not alert to
the presence of children. Children are often attracted to
the mower and the mowing activity. Never assume that
children will remain where you last saw them.
• Keep children out of the mowing area and under
the watchful care of a responsible adult other than
the operator.
• Be alert and turn mower off if a child enters the
area.
• Before and while moving backwards, look behind
and down for small children or other objects.
• Never allow children under age 14 to operate the
mower. Children 14 years of age and above
should read and understand the operation
instructions and safety rules in this manual.
• Use extreme care when approaching blind
corners, shrubs, trees, or other objects that may
obscure your vision of a child or hazard.
4. SERVICE
• Use extreme care in handling gasoline and other
fuels. They are extremely flammable and the
vapors are explosive.
• Use only an approved gasoline container.
• Never remove gas cap or add fuel while the engine
is running. Allow engine to cool at least two
minutes before refueling.
• Replace gasoline cap securely and wipe off any
spilled gasoline before starting the engine as it
may cause a fire or explosion.
• Extinguish all cigarettes, cigars, pipes and other
sources of ignition.
• Never refuel machine indoors because flammable
vapors will accumulate in the area.
• Never store the machine or fuel container inside
where there is an open flame or spark such as a
gas water heater, space heater, or furnace.
• Never run an engine inside a closed area.
4
• To reduce fire hazard, keep mower free of grass,
leaves, or other debris build-up. Clean up oil or
fuel spillage. Allow mower to cool at least 5
minutes before storing.
• Before cleaning, repairing, or inspecting, make
certain the blade and all moving parts have
stopped. Disconnect the spark plug wire, and keep
the wire away from the spark plug to prevent
accidental starting.
• Check the blade and engine mounting bolts at
frequent intervals for proper tightness. Also,
visually inspect blade for damage (e.g., bent,
cracked or worn). Replace with blade which meets
original equipment specifications listed in this
manual.
• Keep all nuts, bolts, and screws tight to be sure
the equipment is in safe working condition.
• Never tamper with safety devices. Check their
proper operation regularly.
• After striking a foreign object, stop the engine,
remove the wire from the spark plug, and
thoroughly inspect the mower for any damage.
Repair the damage before starting and operating
the mower.
• Never attempt to make a wheel or cutting height
adjustment while the engine is running.
• Grass catcher components are subject to wear,
damage and deterioration, which could expose
moving parts or allow objects to be thrown. For
safety protection, frequently check components
and replace with manufacturer’s recommended
parts, when necessary.
• Mower blades are sharp and can cut. Wrap the
blade(s) or wear gloves, and use extra caution
when servicing them.
• Do not change the engine governor setting or
overspeed the engine. Excessive engine speeds
are dangerous.
WARNING - YOUR RESPONSIBILITY: Restrict the use of this power machine to persons who
read, understand and follow the warnings and instructions in this manual and on the machine.
Figure 1 Safety Labels Found On Lawn Mower
SLOPE GAUGE
Do not mow on inclines with a slope in excess of 15 degrees (a rise of approximately 2-1/2 feet every 10 feet). A riding mower
could overturn and cause serious injury. If operating a walk-behind mower on such a slope, it is extremely difficult to maintain
your footing and you could slip, resulting in serious injury.
Operate RIDING mowers up and down slopes, never across the face of slopes.
Operate WALK-BEHIND mowers across the face of slopes, never up and down slopes.
WARNING
SIGHT AND HOLD THIS LEVEL WITH A VERTICAL TREE
A POWER POLE
A CORNER OF A BUILDING
OR A FENCE POST
F
O
L
D
O
N
D
O
T
T
E
D
L
I
N
E
,
R
E
P
R
E
S
E
N
T
I
N
G
A
1
5
°
S
L
O
P
E
USE THIS PAGE AS A GUIDE TO DETERMINE SLOPES WHERE YOU MAY NOT OPERATE SAFELY.
15°
5
6
SECTION 1: FINDING YOUR MODEL NUMBER
This Operator’s Manual is an important part of your new walk behind. It will help you assemble, prepare and
maintain your walk behind. Please read and understand what it says.
Before you start to prepare your walk behind for its first use, please locate the model plate and copy the
information from it in this Operator’s Manual. The information on the model plate is very important if you need
help from your dealer or the MTD customer support department.
• Every walk behind has a model plate. You can locate it by standing behind the unit in the operating
position and looking down at the rear of the deck.
• The model plate will look like Figure 1.
This is where your model number will be.
XXX-X-XXX-X-XXX XXXXXXXXXXX
This is where your serial number will be.
Copy the model number here:
MTD PRODUCTS INC
CLEVELAND, OHIO 44136
Copy the serial number here:
Figure 1
SECTION 2: CALLING CUSTOMER SUPPORT
If you are having difficulty assembling this product or if you have any question regarding the controls,
operation or maintenance of this unit, please call the Customer Support Department. You can reach them by
calling:
1-800-800-7310
Before you call, make sure that you have your model and serial numbers ready. By having the model and
serial numbers ready, you help the Customer Support Representative give you faster service. To find your
unit’s model and serial number, see SECTION 2: FINDING YOUR MODEL NUMBER.
SECTION 3: UNPACKING INSTRUCTIONS
REMOVE UNIT FROM CARTON
• See Figure 2.
• Remove staples, break glue on top flaps, or cut tape at carton end and peel along top flap to open
carton.
• Remove loose parts if included with unit (i.e., owner’s manual, etc.).
• Cut along dotted lines and lay carton down flat.
• Remove packing material.
Roll or slide unit out of carton. Check carton thoroughly for loose parts.
REMOVE MANUAL & LOOSE PARTS
PUSH
Figure 2
DISCONNECT SPARK PLUG WIRE
Before setting up your lawn mower, disconnect the spark plug wire from the spark plug, and ground it against
the engine by attaching rubber boot to a bolt or metal clip to the grounding post on the engine. See Figure 3
Spark Plug Wire
Figure 3
Spark Plug
7
SECTION 4: SET-UP INSTRUCTIONS
This guide covers models 370 - 379 single speed self propelled mowers and 380 - 389
six speed self propelled mowers. Much of this guide pertains to both models.
However, there are some areas where only one model is covered. Use only the
information that is appropriate for your model.
ITEMS REQUIRED FOR ASSEMBLY
• Pair of Pliers (Not necessary, but helpful)
• Motor Oil
• Fresh Gasoline
IMPORTANT: This unit is shipped WITHOUT GASOLINE or OIL in the engine. Be certain to service
engine with gasoline and oil as instructed in the separate engine manual before operating your mower.
NOTE: Reference to right or left hand side of the mower is observed from the operating position.
SET-UP YOUR LAWN MOWER
Follow steps 1 through 10 to set up your lawn mower.
Step 1. Remove grass bag from unit and set it
out of the way.
Grass Bag
Step 2. Lift upper handle. Align it with lower
handle.
Upper Handle
8
Step 3. Tighten wing nuts.
C
L
I
C
K
Step 4. Raise complete handle assembly until it
clicks into place. Make sure not to kink
the control cables.
HERE
Step 5. Pinch lower handle against mounting
bracket with pliers.
Step 6. Move hairpin clip from outer to inner
hole on handle mounting bracket.
Handle Assembly
Control Cables
Step 7. Attach control cables to handle with pull
ties found on the handle.
HERE
PINCH HERE
Step 8. Loosen the wing nut holding the rope guide to the upper handle.
Step 9. Squeeze the blade control handle against the upper handle and pull out starter rope, slowly!
Step 10. Thread starter rope into rope guide.
Step 11. Tighten wing nut.
SQUEEZE
Blade Control Handle
Look Here
Starter Rope
Upper Handle
Rope Guide
Wing Nut
9
SECTION 5: CONTROLS
Models 380 - 389All Models
Blade Control Handle
Recoil Starter
Cutting Height Adjustment Lever
Drive Clutch Control
Throttle Control
Shift Lever
Figure 4
BLADE CONTROL HANDLE
The blade control handle is located on the upper handle of the mower. See Figure 4. The blade control
handle must be depressed in order to start and operate the unit. Release the blade control handle to stop the
engine and blade.
WARNING: The blade control handle is a safety device. Never attempt to bypass its operations.
The blade will be rotating whenever the engine is running.
THROTTLE CONTROL
The throttle control is located on the left side of the upper handle. It is used to regulate the engine speed.
See Figure 4.
• Push the throttle lever forward for fast.
• Pull the throttle lever back for slow.
WARNING: The throttle control cannot be used to stop the engine.
RECOIL STARTER
The recoil starter handle is attached to the upper handle. See Figure 4. Stand behind the unit in the operating
position to start the unit.
DRIVE CLUTCH CONTROL
Squeezing the drive clutch control engages the drive system. Releasing the clutch control disengages the
drive system. Release the clutch control to slow down when negotiating an obstacle, making a turn or
stopping.
SHIFT LEVER (Models 380 - 389)
The shift lever is located on the drive clutch control housing on the upper handle. See Figure 4. This lever is
used to select the forward speed of the mower. When changing your speed selection, release the drive
clutch control.
10
NOTE: Only move the shift lever when the engine is running. Changing the shift lever setting with the
engine off can cause damage to the mower.
CUTTING HEIGHT ADJUSTMENT LEVER
The cutting height adjustment lever is located above the left rear wheel. To adjust the cutting height, pull the
lever out and away from the mower and then move it forward or back for a new cutting height. See Figure 5.
LOWER
Cutting Height Adjustment Lever
HIGHER
Figure 5
NOTE: For rough or uneven lawns, move the height adjustment lever to a higher position. This will help
stop scalping.
ENGINE CONTROLS
See the engine manual for the location and function of the controls located on the engine.
SECTION 6: OPERATION
WARNING: Keep hands and feet away from the chute area on cutting deck. See Figure 1. The
operation of any lawn mower can result in foreign objects being thrown into the eyes, which can
result in severe eye damage. Always wear safety glasses or eye shields.
NOTE: For best results raise the cutting position until it is determined which height is best for your lawn.
See CUTTING HEIGHT ADJUSTMENT LEVER in the CONTROLS section.
GAS AND OIL FILL-UP
Service the engine with gasoline and oil as instructed in the separate engine manual. Read all instructions
carefully.
WARNING: Never fill fuel tank indoors, with engine running or until the engine has been allowed
to cool for at least two minutes after running.
11
EACH TIME BEFORE YOU START YOUR MOWER
• Attach spark plug wire to spark plug. Make certain the metal cap on the end of the spark plug wire is
fastened securely over the metal tip on the spark plug.
• Check for proper drive clutch operation using the NEUTRAL ADJUSTMENT TEST.
NEUTRAL ADJUSTMENT TEST
To perform the NEUTRAL ADJUSTMENT TEST answer the following questions.
• With the drive clutch control released, push mower forward and pull it backward. Does it move freely?
• Squeeze the drive clutch control and pull the mower backward. Do the rear wheels lock (not turn)?
• Is the drive clutch control cable free of kinks or sharp bends?
If you answered “yes” to all three questions, your mower passed the test and you can start your mower. If
you answered “no” to any of the three questions, you need to go through the DRIVE CLUTCH CONTROL
ADJUSTMENT found in the ADJUSTMENTS section.
TO START ENGINE AND ENGAGE BLADE
• Move the throttle control lever all the way forward.
• Prime engine as instructed in the separate engine manual.
• Stand behind the unit, squeeze and hold the blade control handle against the upper handle.
• Grasp starter handle and pull rope out slowly until engine reaches start of compression cycle (rope will
pull slightly harder at this point). Let the rope rewind slowly.
• Pull rope with a rapid, continuous, full arm stroke. Keep a firm grip on starter handle. Return it slowly to
the rope guide.
• After engine starts, move throttle control to desired engine speed. (The mower is designed to be
operated at full throttle.)
NOTE: If any problems are encountered, refer to the TROUBLE SHOOTING Section of this manual.
TO STOP ENGINE AND BLADE
• Release the blade control handle to stop the engine and blade.
WARNING: The blade continues to rotate for a few seconds after the engine is shut off.
USING YOUR ROTARY MOWER
Be sure that lawn is clear of stones, sticks, wire, or other objects which could damage the lawn mower or
engine. Such objects could be accidently thrown by the mower in any direction and cause serious personal
injury to the operator and others.
For the best results, do not cut wet grass because it tends to stick to the underside of the mower, preventing
proper discharge of grass clippings, and could cause you to slip and fall. New grass, thick grass or wet grass
may require a narrower cut.
For a healthier lawn, never cut off more than one-third of the total length of the grass. Your lawn should be
cut in the fall as long as there is growth.
This mower is designed to be operated at full throttle to give you the best cut and do the most effective job of
mowing or mulching.
WARNING: If you strike a foreign object, stop the engine. Remove wire from spark plug,
thoroughly inspect the mower for any damage, and repair the damage before restarting and
operating the mower. Extensive vibration of the mower during operation is an indication of damage.
The unit should be promptly inspected and repaired.
12
BAGGING GRASS CLIPPINGS
This mower can bag grass clippings. Follow steps 1 and 2 to ready the mower for bagging.
Step 1. Remove mulching plug, if installed. Step 2. Hang grass bag on mower.
LIFT
PULL
HERE
EMPTYING A FULL BAG OF GRASS
Once the grass bag is full it will need to be emptied, follow steps 3 and 4 to empty the grass bag.
Step 3. Lift flap and pull bag away from mower. Step 4. Lift bag up and away from mower.
Dump the grass clippings.
LIFT
LIFT
PULL
MULCHING GRASS CLIPPINGS
This mower can also mulch grass clippings. Follow step 1 to ready this mower for mulching.
Mulching plug top and bottom view.
This side up
This side down
Step 1. Lift rear flap, remove grass bag, if
installed, and insert mulching plug.
LIFT
13
PUSH
SIDE DISCHARGING GRASS CLIPPINGS (Optional)
Side Discharge Top and Left View.
This side up
SECTION 7: ADJUSTMENTS
WARNING: Do not at any time make any adjustment to lawn mower without first stopping engine
and disconnecting spark plug wire.
Step 1. Lift rear flap, remove grass bag, or
mulch plug if installed,. Hang side
discharge chute.
LIFT
Hang
HANDLE HEIGHT ADJUSTMENT
Lower Handle
Notch
Figure 6
Your mower is shipped with the handle in the higher height position. To lower the handle height, proceed as
follows.
• Remove the starter rope from the rope guide.
• Remove the upper handle by removing the hand knobs and carriage bolts. Lay the upper handle out of
the way, being careful not to bend or kink the cables.
• Remove the hairpin clips from the weld pins on the handle brackets. Press out on the legs of the lower
handle. Remove lower handle from the mower.
• Turn the lower handle around so the notch on the bottom of the lower handle is facing forward as
shown in Figure 6. Reassemble, placing the bottom holes in the handle over the weld pins in the
handle mounting bracket.
• Reassemble the upper handle to the lower handle.
• Place the hairpin clips in the inner holes in the weld pins and attach the starter rope as instructed in the
Set-Up Instructions.
14
THROTTLE CONTROL ADJUSTMENT
Screw
Cable
Clamp
Figure 7
If the throttle control requires adjustment or if it has been replaced, adjust the throttle control as follows.
• Remove the screw shown in Figure 7. Remove the cable clamp from the cable.
• Push the throttle control lever on the handle all the way forward as far as it will go, then back it off one
“click”. Make certain the throttle control lever remains in this position.
• Push the control lever on the engine as far toward the rear of the engine as it will go. Secure the cable
in this position with the cable clamp and screw.
Control
Lever
On Engine
DRIVE CLUTCH CONTROL ADJUSTMENT
The drive clutch control adjustment wheel is located in the drive clutch control handle housing and is used to
tighten or loosen the drive belt. You will have to adjust the drive clutch control if any of the following happens:
• The mower does not propel itself with the drive clutch engaged.
• The mower’s drive wheels hesitate with the drive clutch engaged.
To resolve the above problems, rotate the adjustment wheel with your fingers. Clockwise to tighten the cable
and counter-clockwise to loosen the cable. See Figure 8.
Models 380 - 389Models 370 - 379
Bottom View
Adjustment Wheel
Figure 8
Note: For some people the drive clutch handle may not be in a comfortable position. You can adjust the
handle out by tightening the adjustment wheel.
15
SECTION 8: LUBRICATION
WARNING: Always stop engine and disconnect spark plug wire before cleaning, lubricating or
doing any kind of work on the lawn mower.
Blade Control Handle
LUBRICATE
Wheels
Engine
SEE ENGINE MANUAL
Figure 9
Blade Control: Lubricate the pivot points on the blade control handle and the brake cable at least once a
season with light oil. See Figure 9. The blade control must operate freely in both directions.
Wheels: Lubricate the wheel at least once a season with light oil (or engine oil). Also, if the wheels are
removed for any reason, lubricate the surface of the axle bolt and the inner surface of the wheel with light oil.
See Figure 9.
Engine: Follow engine manual for lubrication instructions.
SECTION 9: MAINTENANCE
WARNING: Be sure to disconnect and ground the spark plug wire before performing any repairs
or maintenance.
NOTE: When tipping the unit, empty the fuel tank and keep engine, spark plug side up. Never tip the
mower more than 90 degrees and do not leave the mower tipped for any length of time. Oil can drain into
the upper part of the engine causing a starting problem.
ENGINE
Refer to the separate engine manual for all engine maintenance instructions.
• Maintain engine oil as instructed in the separate engine manual packed with your unit. Read and follow
instructions carefully.
• Service air cleaner every 25 hours under normal conditions. Clean every few hours under extremely
dusty conditions. Poor engine performance and flooding usually indicates that the air cleaner should
be serviced. To service the air cleaner, refer to the separate engine manual packed with your unit.
• The spark plug should be cleaned and the gap reset once a season. Spark plug replacement is
recommended at the start of each mowing season; check engine manual for correct plug type and gap
specifications.
• Clean the engine regularly with a cloth or brush. Keep the cooling system (blower housing area) clean
to permit proper air circulation which is essential to engine performance and life. Be certain to remove
all grass, dirt and combustible debris from muffler area.
16
DECK
The underside of the mower deck should be cleaned after each use to prevent a buildup of grass clippings,
leaves, dirt or other matter. If this debris is allowed to accumulate, it will invite rust and corrosion, and may
prevent proper mulching, discharge or bagging.
The deck may be cleaned by tilting the mower and scraping clean with a suitable tool (make certain the spark
plug wire is disconnected).
CUTTING BLADE REMOVAL, REPLACEMENT AND SHARPENING
Blade Adapter
Figure 10
• When removing the cutting blade for sharpening or replacement, protect hands by using heavy gloves
or a rag before grabbing the blade.
• Remove the bolt and blade bell support which hold the blade and adapter to the engine crankshaft.
• Remove the blade and adapter from the crankshaft.
Blade Bell Support
Hex Bolt
WARNING: Periodically inspect the blade adapter for cracks, especially if you strike a foreign
object. Replace when necessary.
When sharpening the blade, follow the original angle of grind as a guide. It is extremely important that each
cutting edge receives an equal amount of grinding to prevent an unbalanced blade. An unbalanced blade will
cause excessive vibration when rotating at high speeds. It may cause damage to the mower, and it could
break causing personal injury.
The blade can be tested by balancing it on a round shaft screwdriver. Remove metal from the heavy side
until it balances evenly. It is recommended that the blade always be removed from the adapter for the when
testing for balance.
Before reinstalling the blade and the blade adapter to the unit, lubricate the engine crankshaft and the inner
surface of the blade adapter with light oil.
• Be sure to install the blade with the side of the blade marked “Bottom” (or with part number) facing the
ground when the mower is in the operating position.
• Slide blade adapter onto engine crankshaft.
• Place blade on adapter. Be certain the blade is aligned with and seated onto the blade adapter
flanges.
• Place blade bell support on blade. Make sure the notches on the blade bell support are aligned with
the small hole in the blade.
• Replace hex bolt.
• Tighten hex bolt to torque: 450 in. lbs. min., 600 in. lbs. max.
NOTE: To ensure safe operation of your unit, the blade bolt must be checked periodically for correct torque.
TROUBLE SHOOTING
Refer to the trouble shooting section of this manual for helpful information.
17
SHIFT LEVER CABLE ADJUSTMENT (Models 380 - 389 Only)
Periodic adjustment of the six speed shift cable may be required due to normal wear on the cable.
Adjustment is needed if all six speeds do not work.
The adjustable cable bracket is located on the left side of the mower, beside the engine. Follow steps 1
through 7 to adjust the shift lever.
Step 1. Start engine.
Step 2. Place speed control in the sixth speed position.
Step 3. Stop engine.
Step 4. Disconnect the spark plug wire and ground it.
Bottom View
Speed Control Lever
Step 5. Loosen hex nut (A) which secures the adjustable cable bracket.
Step 6. Push back on the adjustable cable bracket.
Step 7. Tighten hex nut (A).
Adjustable Cable Bracket
Hex Nut (A)
PUSH
18
DRIVE BELT REMOVAL AND REPLACEMENT (Model 370 Series)
If you need to replace a worn or broken drive belt, follow steps 1 through 22.
Step 1. Disconnect the spark plug and ground it.
Step 2. Drain the fuel tank.
Step 3. Remove rear hub caps and wheels.
Step 4. Remove eight phillips head screws.
5
4
(Behind Wheel)
1
2
3
6
7
8
Step 5. Tip mower back on its handle and block
securely.
Step 6. Remove blade and blade adapter.
Step 7. Remove three hex head screws holding
small baffle.
Step 8. Remove small baffle.
Step 9. Remove large baffle.
Small Baffle
Blade Adapter
Blade
Large Baffle
Step 10. Loosen hex lock nut holding idler bearing.
Step 11. Push back and rotate belt keeper.
Step 12. Remove and replace belt.
Step 13. Replace belt keeper to its original
position. Tighten the hex lock nut.
Belt Keeper
Hex Lock Nut
Mower shown tipped on engine for clarity.
Remember, only tip mower back on its handle with
the spark plug facing up. Otherwise, oil will spill if
turned upside down.
Hex Head Screw
19
Step 14. Replace large baffle.
Step 15. Replace small baffle and three hex head
screws holding it in place.
Step 16. Replace blade adapter and blade. See
the Blade Removal, Sharpening and
Replacement Section for proper
assembly.
Small Baffle
Blade Adapter
Blade
Large Baffle
Step 17. Replace the eight phillips head screws
that hold the large baffle in place.
Step 18. Replace the rear wheels, rear wheel gears
and hub caps. The gears need to be put
on in the right way for the self propelled
mechanism to work. Check the
installation of the gear by spinning the
wheel. It should spin freely in one
direction but not the other. If the wheel
spins freely in both directions, flip the
gear over.
Step 19. Tip mower back onto its wheels
Step 20. Go through the neutral adjustment test in
Section 7 - Operation.
Hex Head Screw
20
DRIVE BELT REMOVAL AND REPLACEMENT (Model 380 Series)
If you need to replace a worn or broken drive belt, follow steps 1 through 30.
Step 1. Disconnect the spark plug and ground it.
Step 2. Drain the fuel tank.
Step 3. Remove rear hub caps and wheels.
Step 4. Remove eight phillips head screws.
5
4
(Behind Wheel)
1
2
3
6
7
8
Step 5. Tip mower back on its handle and block
securely.
Step 6. Remove blade and blade adapter.
Step 7. Remove three hex head screws holding
small baffle.
Step 8. Remove small baffle.
Step 9. Remove large baffle.
Small Baffle
Blade Adapter
Blade
Large Baffle
Step 10. Loosen hex lock nut holding idler bearing.
Step 11. Using a pair of pliers, pull back and rotate
belt keeper bracket from the slot on idler
pulley.
Step 12. Slide the belt out from between the Belt
Keeper Bracket and the idler pulley.
Transmission
Pulley
Belt
Belt Keeper
Bracket
Idler Pulley
Bracket
Idler Pulley
Bolt and
Locknut
Transmission
Hex Head Screw
21
Step 13. Squeeze the belt together and push belt
forward. Press the control arm inward towards
the deck and remove the six speed cable from
the slot.
Six-Speed
Cable Slot
Belt
Control
Arm
Step 18. Pivot the control arm down away from the
pulley and belt.
Six-Speed
Cable Slot
Control
Arm
Step 14. Place the new belt over the transmission
pulley. Start the belt in pulley groove and rotate
pulley until belt is seated in transmission pulley.
Step 15. Place belt between idler pulley and the belt
keeper bracket.
Step 16. Using pliers, rotate the belt keeper bracket
so that it snaps into slot on the idler bracket.
Step 17. Tighten the idler pulley bolt and locknut
using two 7/16” wrenches.
Transmission
Pulley
Belt
Belt Keeper
Bracket
Idler Pulley
Bracket
Idler Pulley
Bolt and
Locknut
Transmission
Step 19. Lift off the lower pulley assembly and
remove the old belt from around the crankshaft.
Lower Pulley
Half
Crankshaft
Belt
Step 20. Place belt between the two pulley halves on
the crankshaft. Make sure to route the belt
inside the belt guard pin.
Upper
Pulley
Half
Tab
Belt
Guard
Pin
IMPORTANT: When changing the belt, do not disassemble
the lower pulley assembly.
Belt
Lower
Pulley
Half
22
Step 21. Pinch belt together so that it is not in the
pulley groove, and the lower pulley can be
pushed towards the engine.
Lower Pulley
Half
Belt
Belt
Guard
Pin
Step 22. Pivot the control arm back to its original
position and reinstall the six-speed cable into
the slot.
Step 23. Check and make sure the belt is routed
inside the pulley halves and the belt guard pin.
Step 24. Replace large baffle.
Step 25. Replace small baffle and three hex
head screws holding it in place.
Step 26. Replace blade adapter and blade. See
the Blade Removal, Sharpening and
Replacement Section for proper
assembly.
Small Baffle
Blade Adapter
Blade
Large Baffle
Step 27. Replace the eight phillips head screws
that hold the large baffle in place.
Step 28. Replace the rear wheels, rear wheel
gears and hub caps. The gears need to
be put on in the right way for the self
propelled mechanism to work. Check
the installation of the gear by spinning
the wheel. It should spin freely in one
direction but not the other. If the wheel
spins freely in both directions, flip the
gear over.
Step 29. Tip mower back onto its wheels
Step 30. Go through the neutral adjustment test
in Section 7 - OPERATION.
Hex Head Screw
23
SECTION 10: OFF-SEASON STORAGE
The following steps should be taken to prepare lawn mower for storage.
• Clean and lubricate mower thoroughly as described in the lubrication instructions.
• Refer to engine manual for correct engine storage instructions.
• Coat mower’s cutting blade with chassis grease to prevent rusting.
• Store mower in a dry, clean area. Do not store next to corrosive materials, such as fertilizer.
NOTE: When storing any type of power equipment in an poorly ventilated or metal storage shed, care should be
taken to rust-proof the equipment. Using a light oil or silicone, coat the equipment, especially cables and all moving
parts.
SECTION 11: TROUBLE SHOOTING GUIDE
Trouble Possible Cause(s) Corrective Action
Engine fails to start Blade control handle disengaged.
Spark plug wire disconnected.
Throttle control lever not in correct
starting position.
Fuel tank empty, or stale fuel.
Blocked fuel line.
Faulty spark plug.
Engine flooded.
Engine runs erratic Unit running in START position.
Spark plug wire loose.
Blocked fuel line or stale fuel.
Vent in gas cap plugged.
Water or dirt in fuel system.
Dirty air cleaner.
Carburetor out of adjustment.
Engine overheats Engine oil level low.
Air flow restricted.
Carburetor not adjusted properly.
Occasional skip (hesitates) at
high speed
Idles poorly Spark plug fouled, faulty or gap too
Excessive vibration Cutting blade loose or unbalanced.
Mower will not mulch grass Engine speed too low.
Uneven cut Wheels not positioned correctly.
Spark plug gap too close. Adjust gap to .030”.
wide.
Carburetor improperly adjusted.
Dirty air cleaner.
Bent cutting blade.
Wet grass.
Excessively high grass.
Dull blade.
Dull blade.
Engage blade control handle.
Connect wire to spark plug.
Move throttle lever to FAST or START position.
Fill tank with clean, fresh gasoline.
Clean fuel line.
Clean, adjust gap or replace.
Crank engine with throttle in FAST position.
Move throttle lever to FAST position.
Connect and tighten spark plug wire.
Clean fuel line; fill tank with clean, fresh
gasoline.
Clear vent.
Drain fuel tank. Refill with fresh fuel.
Clean air cleaner.
Adjust carburetor.
Fill crankcase with proper oil.
Remove blower housing and clean.
Adjust carburetor.
Reset gap to .030” or replace spark plug.
Adjust carburetor.
Clean air cleaner.
Tighten blade and adapter. Balance blade.
Replace blade.
Set throttle between 3/4 and full throttle.
Do not mow when grass is wet; wait until
later to cut.
Mow once at a high cutting height, then
mow again at desired height or make a narrower cutting swath (1/2 width).
Sharpen or replace blade.
Place all four wheels in same height position.
Sharpen or replace blade.
Refer to separate engine manual packed with your mower for more engine related information.
NOTE: For repairs beyond the minor adjustments listed above, contact your nearest authorized service dealer or
call 1-800-800-7310 for the Customer Support Center.
24
Models 370 thru 389
Front Axle Assembly & Height Adjuster
REF.
NO. PART NO. DESCRIPTION
1 611-0060 Axle Ass’y, Frt.
2 710-1348 AB Pan Scr. 1/4-14 x .50 Lg.
3 714-0104 Cotter Pin .072 x 1.12 Lg.
4 732-0820 Ext. Spring
5 747-0920 Adj. Rod
6 736-0105 Spr. Washer
7 738-0102 Shl. Bolt .498 x 1.445 3/8-16
8 †† Wheel Ass’y - Complete
9 † Hub Cap
† See Wheel and Hub Cap Chart on Page 6
REF.
NO. PART NO. DESCRIPTION
1 712-3025 Hx. Jam Nut 5/16-24
2 736-0425 Bell Wash. .325 x .930 x .045
3 756-0656 Pulley
4 736-3084 Fl. Wash. .510 x 1.120 x .060
5 712-0896 Hx. Jam Nut 1/4-28
6 782-7598 Belt Keeper
7 741-0600 Bearing
8 750-1050 Flange Spacer
9 682-0027A Idler Bracket Ass’y.
10 710-0299 Hx. Cap Scr. 1/4-28 x 1.00 Gr. 5
11 732-0849A Torsion Spring
12 741-0682A Bearing Sleeve
13 736-0570 Fl. Wash. .885 x 1.145 x.030
14 721-0329 Oil Seal
15 618-0253 Upper Housing Ass’y.
16 736-0616 Fl. Wash. .504 x .700 x .030
17 717-1487 Pinion Shaft 10 T.
18 736-0314 Thr. Wash. 3/8 x .70 x .030
19 736-0569 Thr. Wash. .388 x .625 x .062
20 618-0252 Lower Housing Ass’y.
21 710-0642 Hx. Scr. 1/2-20 x .75
22 782-7601A Cable Bracket
23 741-0674 Bearing
24 611-0066 Shaft Ass’y.
25 721-0325 Plug
26 717-1469 Gear 34 T.
27 711-1168 Output Shaft 6 T.
28 741-0673 Flange Bearing
29 721-0329 Oil Seal
30 782-7595 Pivot Bracket
31 741-0324 Flange Bearing
32 736-0369 Wash. Fl. .508 I.D. x 1.00 O.D. x .020
33 741-0690 Thrust Bearing
- 618-0263A Transmission Complete
25
Models 370 thru 379
8” x 2” Link Tread
Yellow (5-1/2” Dia.)
Size
8” x 1.75” Bar Tread 634-0020 - - - 634-0020
8” x 1.75” “T” Tread 734-1268 741-0484 734-1412
8” x 2” “S” Wave 734-1790
8” x 2” “S” Wave 734-1821 741-0484 734-1826
8” x 2” “S” Wave 734-1826 - - - 734-1826
†† WHEEL ASSEMBLY CHART
Tread
Type
Front Wheels
Part No. Bearings
(Yellow Rim)
734-1819 741-0484 734-1824
Rear Wheels
Part No.
741-0484 734-1791
(Yellow Rim)
26
† OPTIONAL HUB CAPS
Description Part No.
Gray (3-1/2” Dia.) 720-0249
Black (4-1/4” Dia.) 731-0354
Gray (4-1/4” Dia.) 731-0355A
Gray (5-1/2” Dia.) 731-0981A
731-1426
Models 370 thru 379
REF.
NO. PART NO. DESCRIPTION
1 747-0824 Control Handle Ass’y (Std.)
647-0004 Control Handle Ass’y (Deluxe)
2 731-1639 Baffle
3 710-0605 Oval C-Sunk Mach.-Scr.
4 736-0501 Spr.Wash.66” I.D.
5 720-0279 Handle Knob 1/4-20 Thd.
6 646-0875 Throttle Body
7 712-0324 Hex L-Nut 1/4-20
8 749-0439B Upper Handle
9 746-0876 Throttle Lever
12 746-0843 Throttle Control Wire-55”
746-0848 Throttle Control Wire-47”
746-0841 Throttle Control Wire-60”
13 710-1205 Rope Guide
14 732-0700 Wire-47” Lg.
15 720-0276 Hand Knob
16 746-0555 Control Cable-55”
746-0551 Control Cable-43”
17 726-0240 Cable Tie
18 710-1174 Cr.Hd. Bolt 5 / 16-18 x 2” Lg.
19 749-0907A Lower Handle
20 811-00185 Throttle Box Comp. (Incl. Ref. 3,
4,6,7,9)
21 710-1237 Hex Self-Tap Scr. #10-32 x .62”
710-0871 Hex Sems Scr. #10-32 x .3” Lg.
22 735-0639 Spark Plug Boot
23 751B213146 Cable Clamp (B&S)
7510007775 Cable Clamp (TEC)
24 710-1220 Screw H.L. 12-24
25 710-0351 Screw Mach. B Tapp.
27 -- Engine
28 731-1714 Belt Cover
35 714-0104 Int. Cotter Pin 5/15” Dia.
37 747-0922 Pivot Rod
38 750-1068 Spacer .385 I.D.
39 732-0809 Torsion Spring L.H.
44 782-3029 Handle Brkt. Ass’y - L.H.
45 710-0653 Screw, Tap 1/4-20
47 712-0400 U-Nut
48 782-3030 Handle Brkt. Ass’y - R.H.
49 710-1348 Screw AB 1/4-20
52 710-0654A Hex L-Wash. Hd. Scr. 3/8-16 x 1”
53 682-0037 21” Deck Ass’y w/o MTD Icon
682-0075 21” Deck Ass’y W/ MTD Icon
56 731-1236 Rear Flap 17.77 Lg.
57 782-7599A Rear Chute Door
58 782-9050 Brkt. Mtg. Grassbag - Black
59 731-0068 Hdtop Bag Cover
731-0066 Hdtop Bag Cover w/Icon
631-0077 Hdtop Bag Cover w/Flo Ind.
631-0078 Hdtop Bag Cover w/Flo Ind. / Icon
61 747-0919 Catcher Frame
62 664-0080 Grass Bag - Black
664-0079 Grassbag- Soft top w/MTD Logo
72 736-0524A Blade Bell Support
73 742-0741 21” Mulching Blade w/Star
742-0641 21” Std. Blade W/Star
74 753-0609 Blade Adaptor Kit w/Star
75 710-1257 Hex Bolt 3/8-24 x 2.5 Lg.
76 748-0358 Spacer
77 736-0514 Fl. Wash. .885 x 1.85 x .06
REF.
NO. PART NO. DESCRIPTION
78 736-0513 Spr. Wash. .890 x .7x .04
79 756-0962 Pulley Half - Upper
80 756-0979 Pulley Half - Lower
81 †† Wheel Assembly
82 638-0005 Axle Assy: RR
83 682-7518 Axle Assy: Trans.
84 682-7524 Cover Ass’y - Chain
85 710-0604 Scr. TT 5/16-18
86 710-0653 Scr. TT 1/4-20
87 710-0751 Hx Cap Screw 1/4-20
88 710-0896 Scr. AB 1/4-20
89 710-1315 Scr 3/8 - 16 x 1.25
90 711-0835 Pin - Clv. .500 Dia.x.4.62 Lg.
91 713-0421 Chain:Endless 48:.500P x 22 Lg.
92 714-0474 Pin-Cotter .125 O.D. x .75
93 720-0230 Grip-Foam
94 732-0803 Spring Lever
95 732-0818 Torsion Spring
96 736-0270 Bell Washer .265 x 75 x .062
97 736-0369 Wash.Flat .508 I.D. x 1.0 O.D.:.020
98 738-0529 Nut - Shoulder .625 x .165 Lg.
99 741-0324 Bearing-Flg Hex
100 741-0522 Bearing-Flg. Hex
101 741-0978 Bearing-Sleeve
102 748-0318 Ratchet Wheel
103 750-0807 Spacer - .385 x .625 x .700
104 750-1056 Spacer-Shld. .385 I.D.x .715 Lg.
105 750-1075 Spacer Slv. .520 I.D. x .950 Lg.
106 782-0566 Pivot Arm
107 782-0568 Spring Bracket
108 746-0711A S.P. Cable 51”
109 731-1059 Mounting Cap
110 731-1057 Control Cover - Upper
111 731-1058 Control Cover - Lower
112 731-0620 Lever
113 710-0841 Scr. AB #10-12:.75 Lg.
114 712-0414 Weld Top L. 1/4-20
115 16855 Pawl Plate
116 748-0188B Pawl L.H. (Not Shown
748-0381 Pawl R.H.
117 738-0137A Shldr. Scr. .340x.285
118 10622B Spring, Ratchet
119 † Hub Cap
120 731-1685 Mulch Plug
121 731-1461 Chute Deflector
122 747-0958 Chute Mounting Rod
123 712-0324 Hex-L-Nut 1/4-20 thd.
124 710-0924 Mach. Scr. 1/4-20
125 720-0294 Foam Grip (Optional)
126 754-0271 Belt
127 710-0896 Scr. 1/4-14: .625 Hxindwsh
128 782-7018 Pulley Cover
129 710-1026 Scr. TT1/4-20:1.750 Hx IndWash
130 736-0329 Lockwasher 1/4” Reg.
131 736-3020 Fl. Wash. .271 x ..630 x .065
132 712-0287 Nut 1/4-20
133 631-0060 Flo Indicator Ass’y
134 731-1644 Flo Indicator Ball
135 731-1738 Flo Indicator Housing
136 710-1270 Scr. 1/4-20:1.31 Lg.
137 746-0883 Housing (w/o Throttle)
27
Model 380 thru 389
28
Model 380 thru 389
REF.
NO. PART NO. DESCRIPTION
1 747-0824 Control Handle Ass’y (Std)
647-0004 Control Handle Ass’y (Deluxe)
2 731-1639 Baffle
3 710-0605 Oval C-Sunk Mach.-Scr.
4 736-0501 Spr.Wash..66” I.D.
5 720-0279 Handle Knob 1/4-20 Thd.
6 646-0875 Throttle Body
7 712-0324 Hex L-Nut 1/4-20
8 749-0439B Upper Handle
9 746-0876 Throttle Lever
12 746-0843 Throttle Control Wire-55”
746-0848 Throttle Control Wire-47”
746-0841 Throttle Control Wire-60”
13 710-1205 Rope Guide
14 732-0700 Wire-47”Lg.
15 720-0276 Hand Knob
16 746-0554 Control Cable-40.5”
746-0555 Control Cable-55”
746-0551 Control Cable-43”
17 726-0240 Cable Tie
18 710-1174 Curved Hd. Bolt 5/16-18x2” Lg.
19 749-0907A Lower Handle
20 811-00185 Throttle Box Comp. (Incl. Ref.
3,4,6,7,9)
21 710-1237 Hex Self-Tap Scr. #10-32 x .62”
Lg. (B&S)
710-0871 Hex Sems Scr. #10-32 x .3” Lg.
(Tec.)
22 735-0639 Spark Plug Boot
23 751B213146 Cable Clamp (B&S)
7510007775 Cable Clamp (Tec.)
24 710-1220 Screw H.L. 12-24
25 710-0351 Screw Mach. B Tapp.
27 -- Engine
28 731-1714A Belt Cover
29 710-0167 Scr. 1/4-20: .50 Lg.
30 710-0896 Scr.:AB 1/4-20: .625 Lg.
31 712-0287 Hex Nut: 1/4-20
32 736-0270 Bell Wash. .265 x .75 x .062
33 736-0329 Lock Wash. 1/4
35 714-0104 Int. Cotter Pin 5/15” Dia.
37 747-0922 Pivot Rod
38 750-1068 Shoulder Spacer
39 732-0809 Torsion Spring L.H.
40 756-0625 Roller Cable
41 782-7574 6 Sp. Cable Adj. Bracket
42 782-7575 6 Sp. Cable Mtg. Bracket
43 656-0613 Pulley Assembly
44 782-3029 Handle Brkt. Ass’y - L.H.
45 710-0653 Screw, Tap 1/4-20
46 711-1114 Pivot Shaft
47 712-0400 U-Nut
48 782-3030 Handle Brkt. Ass’y- R.H.
49 710-1348 Screw AB 1/4-20
REF.
NO. PART NO. DESCRIPTION
50 732-0807 Torsion Spring
51 736-0526 Wv.Wash.1.38 O.D. x .88 I.D:.029
52 710-0654A Hx L-Wash Hd. Scr. 3/8-16 : 1” Lg.
53 682-0037 21” Deck Ass’y w/ Icon
682-0075 21” Deck Ass’y w/o Icon
56 731-1236 Rear Flap 17.77 Lg.
57 782-7599A Rear Chute Door
58 782-9050 Brkt. Mtg. Grassbag - Black
59 731-0068 Hdtop Bag Cover
731-0066 Hdtop Bag Cover w/MTD Logo
731-0077 Hdtop Bag Cover w/Flo Ind.
731-0078 Hdtop Bag Cover w/Flo Ind. / Logo.
61 747-0919 Catcher Frame
62 664-0080 Grass Bag - Black
664-0079 Grassbag- Soft top w/ Logo
72 736-0524A Blade Bell Support
73 742-0741 21” Mulching Blade w/Star
74 753-0609 Blade Adaptor Kit w/Star
75 710-1257 Hex Bolt 3/8-24 x 2.5 Lg.
76 750-1070 Spacer - Sleeve
77 750-1071 Spacer - Sleeve
78 782-7596 6 Sp. Control Arm
79 782-7597 6 Sp. Pivot Bracket
81 †† Wheel Assembly
82 638-0005 Axle Ass’y: RR
83 682-7518 Axle Ass’y: Trans.
84 682-7524 Cover Ass’y - Chain
85 710-0604 Scr. TT 5/16-18
86 710-0653 Scr. TT 1/4-20
87 710-0751 Hx Cap Screw 1/4-20
88 710-0896 Scr. AB 1/4-20
89 710-1315 Scr 3/8-16 x 1.25
90 711-0835 Pin - Clv. .500 Dia. x .4.62 Lg.
91 713-0421 Chain: Endless 48:.500P x 22L
92 714-0474 Pin-Cotter .125 O.D. x .75
93 720-0230 Grip-Foam
94 732-0803A Spring Lever
95 732-0818 Torsn Spring
96 736-0270 Bell Washer .265 x .75 x .062
97 736-0369 Wash.-Fl .508 I.D. x 1.0 O.D. x.020
98 738-0529 Nut - Shoulder .625 x .165Lg.
99 741-0324 Bearing-Flg Hex
100 741-0522 Bearing-Flg. Hex
101 741-0978 Bearing-Sleeve
102 748-0318 Rachet Wheel
103 750-0807 Spacer - .385 x .625 x .700
104 750-1056 Spacer-Shoulder .385I.D.x.715Lg.
105 750-1075 Spacer Sleeve .520 I.D. x .950 Lg.
106 782-0566 Pivot Arm
107 782-0568 Spring Bracket
108 731-0904 Upper Control Housing
109 731-0924 6 Speed Shift Lever
110 713-0397 Gear Insert
111 710-0841 C-Sunk Tap Scr. #10 x .75” Lg.
29
REF.
NO. PART NO. DESCRIPTION
112 732-0627 Shift Lever Spring
113 16864 6 Sp. Rack Cable Bracket
114 712-0414 Weld Top L. 1/4-20
115 16855 Pawl Plate
116 748-0381 Pawl R.H.
748-0188B Pawl L.H. (Not Shown)
117 738-0137A Shldr Scr. .340 x .285
118 10622B Spring, Rachet
119 † Hub Cap
120 731-1685 Mulch Plug
121 731-1461 Chute Deflector
122 747-0958 Chute Mounting Rod
123 712-0324 Hex-L-Nut 1/4-20 thd.
124 710-0924 Mach. Scr. 1/4-20
REF.
NO. PART NO. DESCRIPTION
125 720-0294 Foam Grip (Optional)
126 731-0905 Lower Control Housing
127 731-0906 Cable Mounting Cap
128 746-0711A S.P. Cable
129 731-0620 Control Lever
130 746-0939 6 Speed Cable - 53” Lg.
131 754-0271 Belt
132 782-7018 Pulley Cover
133 712-0138 Nut 1/4-28
134 738-0924 Sh. Scr. 1/4-28:.375 Lg.
135 631-0060 Flo Indicator Ass’y
136 731-1644 Flo Indicator Ball
137 731-1738 Flo Indicator Housing
30
Shroud Chart
Part No.
751B281439
751B281440
751B281443
Hardware:
710-1256 (Screw)
Part No.
731-1402A
731-1694
731-1695
731-1934
Hardware:
710-1258 (Screw)
Color
Dark Red
Black
Bright Red
Color
Yellow
Black
Silver
Charcoal
Part No.
731-1395A
731-1396A
731-1397A
Hardware:
710-1256 (Screw)
Part No.
7510143208
Hardware:
7510042823 (Screw)
Color
Red
Black
Gray
Color
Black
Part No.
731-1587A
731-1603A
731-1610A
731-1620A
Hardware:
710-1184 (Screw)
Part No.
731-1585B
Hardware:
710-1274 (Screw)
Color
Black
Yellow
Pewter
Gray
Color
Black
Part No.
731-1561
Hardware:
7510042823 (Screw)
Part No.
731-1586B
731-1612A
Hardware:
7510042823 (Screw)
Color
Black
Color
Black
Red
Part No.
751B281451
Hardware:710-1256 Hardware:710-1237 Hardware: - - Hardware:
Color
Gray
Part No.
751B281476
751B281777
Color
Black
Yellow
Part No.
7511681311
7511681911
7511682011
Color
Black
Red
Gray
Part No. Color
31
MANUFACTURER’S LIMITED WARRANTY FOR:
For TWO YEARS from the date of retail purchase
within the United States of America, its possessions
and territories, MTD PRODUCTS INC will, at its
option, repair or replace, for the original purchaser,
free of charge, any part or parts found to be
defective in material or workmanship. This warranty
covers units which have been operated and
maintained in accordance with the operating
instructions furnished with the unit, and which have
not been subject to misuse, abuse, commercial use,
neglect, accident, improper maintenance or
alteration.
Normal wear parts or components thereof are
subject to separate terms as noted below in the “No
Fault Ninety Day Consumer Warranty” clause.
All normal wear part failures will be covered on this
product for a period of 90 days regardless of cause.
After 90 days, but within the two year period, normal
wear parts failures will be covered ONLY IF caused
by defects in material or workmanship of OTHER
component parts. Normal wear parts are defined as
batteries*, belts, blades, blade adapters, grass
bags, rider deck wheels, seats, snow thrower skid
shoes, shave plates and tires.
How to obtain service: Warranty service is
available, with proof of purchase, through your local
authorized service dealer. To locate the dealer in
your area, please check the yellow pages or contact
the Customer Service Department of MTD
PRODUCTS INC, P. O. Box 368022, Cleveland,
Ohio 44136-9722. Phone 1 (800) 800-7310. The
return of a complete unit will not be accepted by the
factory unless prior written permission has been
extended by the Customer Service Department of
MTD PRODUCTS INC.
Transportation charges: Transportation charges
for the movement of any power equipment unit or
attachment are the responsibility of the purchaser.
Units exported out of the United States: MTD
PRODUCTS INC does not extend any warranty for
products sold or exported outside of the United
States of America, its possessions and territories,
except those sold through MTD PRODUCTS INC’s
authorized channels of export distribution.
Other Warranties:
1. The engine or component parts thereof carry
separate warranties from their manufacturers.
Please refer to the applicable manufacturer’s
warranty on these items.
2. *Batteries are covered by a 90-day replacement
warranty.
3. Log splitter pumps, valves and cylinders or
component parts thereof are covered by a one
year warranty.
4. All other warranties, express or implied,
including any implied warranty of
merchantability or fitness for a particular
purpose, are hereby expressly disclaimed in
their entirety.
5. The provisions as set forth in this warranty
provide the sole and exclusive remedy of MTD
PRODUCTS INC’s obligations arising from the
sales of its products. MTD PRODUCTS INC will
not be liable for incidental or consequential loss
or damage.
How state law relates to this warranty: This
limited warranty gives you specific legal rights, and
you may also have other rights which vary from
state to state. Certain disclaimers are not allowed in
some states and therefore they may not apply to
you under all circumstances.
NOTE: This warranty does not cover routine
maintenance items such as lubricants, filters, blade
sharpening and tune-ups, or adjustments such as
brake adjustments, clutch adjustments or deck
adjustments. Nor does this warranty cover normal
deterioration of the exterior finish due to use or
exposure.
Loading...
