S03 Normal Voice List

PRESET

Bank Select MSB=63, LSB=0

No. Category Voice Name Variation Type

1 Pf StPiano1 2Band EQ on on on on 2 Pf StPiano2 2Band EQ on on on on 3 Pf WarmStPf Early Ref1 on on 4 Pf Dark Pf 3Band EQ on 5 Pf Mono Pf 3Band EQ on 6 Pf Dance Pf 2Band EQ on on 7 Pf Pf+Road Celeste1 on on on 8 Pf Pf+DxEp Chorus1 on on on

9 Pf StPf+Str 2Band EQ on on on on 10 Pf StPf+Pad 2Band EQ on on on on 11 Pf Honky Pf 3Band EQ on on 12 Pf Montuno Gate Reverb on on on 13 Pf Brite Pf 3Band EQ on 14 Pf CP80 3Band EQ on 15 Pf FlangeCP Flanger1 on 16 Pf CP80+DX Celeste1 on on 17 Pf NtrlRoad 3Band EQ on on on 18 Pf SoftRoad 3Band EQ on 19 Pf Mid Road 3Band EQ on on on 20 Pf CrstRoad 2Band EQ on on 21 Pf StereoEP 2Band EQ on on 22 Pf Pan EP Auto Pan on on on 23 Pf PhaserEP Phaser1 on on on 24 Pf Wurli 2Band EQ on 25 Pf AmpWurli Amp Simulator on 26 Pf AtkWurli Celeste4 on on 27 Pf Fulltine 3Band EQ on on 28 Pf TX816 Chorus1 on on on on 29 Pf ToneBars 3Band EQ on on 30 Pf Urban DX 3Band EQ on 31 Pf Dream EP Auto Pan on on 32 Pf DXEP+Pad 2Band EQ on on on 33 Pf Dx+Road 3Band EQ on on on on 34 Pf CP30 Phaser2 on on 35 Pf Wah EP Auto Wah on on on 36 Pf GranHrps Early Ref1 on on 37 Pf PhazClav Phaser2 on 38 Pf Wah Clav Auto Wah on 39 Cp CrystBel Symphonic on on 40 Cp PetitBel Chorus2 on on on 41 Cp ST Bell Delay L.C.R on on on 42 Cp MeloVibe Tremolo on 43 Cp EurpTubl Echo on 44 Cp Kalimba Early Ref2 on on 45 Or Rock Rotary Speaker on on on 46 Or Full 4 Rotary Speaker on on on on 47 Or Feet Rotary Speaker on on on on 48 Or FastOrgn Rotary Speaker on on on on 49 Or Drive 2Band EQ on on 50 Or Warm Celeste1 on on on 51 Or Swish 2Band EQ on on 52 Or Ballad Celeste1 on on on 53 Or Gospel Rotary Speaker on on on on 54 Or Soul Phaser2 on on 55 Or TopBotom Celeste4 on on on 56 Or Slow Rotary Speaker on on on on 57 Or Cool ! Room2 on 58 Or 4 Bars Rotary Speaker on on on on 59 Or 4Bar+Prc Rotary Speaker on on on on 60 Or RockPerc Celeste4 on on on on 61 Or JazzPerc No Effect on on on 62 Or Dist OverDrive on on on on 63 Or BassWalk Rotary Speaker on on on 64 Or Falf Amp Simulator on

Element Switch

1234

No. Category Voice Name Variation Type

65 Or FuzFalf Amp Simulator on 66 Or VxOrgan 2Band EQ on 67 Or Dance 2Band EQ on on on 68 Or Pipes 2Band EQ on on on on 69 Or Church 2Band EQ on on 70 Or Cathedrl Hall1 on on on 71 Gt Nylon 3Band EQ on 72 Gt Steel 3Band EQ on 73 Gt 12 Strng 2Band EQ on on 74 Gt AttackAG Early Ref1 on on 75 Gt Clean Echo on on 76 Gt Dist Amp Simulator on on on 77 Gt AltPower OverDrive on on on on 78 Gt DistSolo Amp Simulator on 79 Gt Pwr Dist Amp Simulator on on 80 Gt Cry-Wow A uto W ah on on 81 Ba VelFingr 2Band EQ on on 82 Ba Amped RW Amp Simulator on on 83 Ba FuzzPick Amp Simulator on 84 Ba VelSlap 2Band EQ on on 85 Ba SoftSlap OverDrive on on 86 Ba HardSlap Distortion on on 87 Ba MeloFrls Flanger1 on on 88 Co PadFrtls Chorus3 on on on 89 Co G&B Unsn Flanger1 on on on on 90 Co Frls&ClG Celeste1 on on 91 St Rich St 2Band EQ on on on 92 St Stereo 1 2Band EQ on on 93 St Stereo 2 2Band EQ on on 94 St Presto 2Band EQ on on 95 St Overture 2Band EQ on on 96 St Small 2Band EQ on on on 97 St Quartet Early Ref2 on on on on 98 St CelloSol Early Ref2 on

99 St Solo Bow 2Band EQ on on on 100 St Pizz Oct 2Band EQ on on 101 St OrchHarp 3Band EQ on 102 St Symphony 2Band EQ on on on on 103 St Filharmo 2Band EQ on on on on 104 St Tape Str 2Band EQ on 105 Pd Oooo 2Band EQ on on 106 Pd OooAah Chorus4 on on on 107 Pd OohLR Flanger3 on on 108 Pd OooWarm Flanger3 on on 109 Pd Mixed No Effect on on 110 Pd 5thVoice Chorus4 on on 111 Pd SwellChr Phaser1 on on on on 112 Pd CmpChoir 2Band EQ on 113 Pd Itopia Chorus4 on 114 Pd Padpia Chorus4 on 115 Br BriteSec 2Band EQ on on 116 Br Warm Sec 2Band EQ on on 117 Br Big Sect 2Band EQ on on on on 118 Br SmallSec Gate Reverb on on on on 119 Br 7th 11th Gate Reverb on on on on 120 Br FrenchHr Room2 on on on 121 Br Real&Syn 2Band EQ on on on on 122 Br Solo Tp Early Ref1 on 123 Br SoloMute Reverse Gate on 124 Rp MeloSop Delay L.R on 125 Rp Alto 3Band EQ on 126 Rp SoftTnr OverDrive on 127 Rp NtrHarmo Delay L.R on 128 Rp AndesPan Delay L.R on on

Element Switch

1234

USER

Bank Select MSB=63, LSB=8

No. Category Voice Name Variation Type

1 St Synth St 2Band EQ on on 2 St Pro-Ana Phaser2 on on 3 St AnaStrg1 2Band EQ on on 4 St AnaStrg2 2Band EQ on on on 5 St SynCh&St Flanger3 on on on 6 St Rich Oct 2Band EQ on on on on 7 St SynSymph Gate Reverb on on on on 8 St Solings Symphonic on on

9 Pd Over Pad Chorus4 on on 10 Pd Soft Syn 2Band EQ on on 11 Pd Pulse Phaser1 on on 12 Pd JunePad 2Band EQ on 13 Pd SoftSaw Chorus1 on on 14 Pd CSBrssPd Delay L.R on on 15 Pd Warmer Chorus2 on on 16 Pd Unstable Chorus4 on on 17 Pd Sine Pad Chorus4 on on 18 Pd Tri Pad Delay L.R on on 19 Pd Silent Phaser2 on on on on 20 Pd 4D-Space Phaser2 on on 21 Pd Sunbeams Chorus3 on on on 22 Pd Expand Chorus1 on on on 23 Pd SoliPhaz Phaser1 on 24 Pd Bright Celeste2 on on 25 Pd Fantasia 3Band EQ on on on on 26 Pd FingOrgn Flanger1 on on on on 27 Pd OuterSpc Chorus1 on on on 28 Pd Whisper Flanger2 on on on 29 Pd DigiAna Symphonic on on on 30 Pd ObrDrone 2Band EQ on on on 31 Pd GrandP&M 3Band EQ on 32 Pd Crystal 2Band EQ on on 33 Br CS80 Symphonic on 34 Br VntgAna1 Early Ref1 on on 35 Br VntgAna2 Gate Reverb on on 36 Br SquSaw 2Band EQ on on 37 Br WarmSyn 2Band EQ on on 38 Br Reso Syn Echo on 39 Br Dark Syn 3Band EQ on on 40 Br Over Hrn 2Band EQ on on 41 Br J Stabs 2Band EQ on on 42 Br Pure Syn Delay L.R on on on on 43 Br NewRoman Symphonic on on 44 Br Oct Syn Echo on on 45 Br Syn Tp Delay L.R on 46 Ba EleSynBs Phaser1 on on 47 Ba CS Unisn 2Band EQ on on 48 Ba DX Hard Flanger1 on on 49 Ba Mg Funk 2Band EQ on on 50 Ba J Square 2Band EQ on on 51 Ba Min Ana 2Band EQ on on 52 Ba Min Fat 2Band EQ on on 53 Ba Wound Chorus1 on on 54 Ba Smooth 3Band EQ on 55 Ba PhatRamp 3Band EQ on on 56 Ba Happy 3Band EQ on on 57 Ba Travel Phaser2 on on 58 Ba Phat50% 3Band EQ on on 59 Ba HipOct1 2Band EQ on on 60 Ba HipOct2 2Band EQ on on 61 Ba DarkHip 2Band EQ on on 62 Ba Maximum Distortion on on 63 Ba FunkVox 2Band EQ on on on 64 Ba BottomUp 2Band EQ on on

Element Switch

1234

No. Category Voice Name Variation Type

65 Ld Saw Delay L.C.R on 66 Ld DarkSync Phaser1 on 67 Ld BritSync Echo on on 68 Ld SP Sync 3Band EQ on 69 Ld Porta Ld Delay L.R on on 70 Ld Squ-Mono Delay L.R on on 71 Ld Pulse Phaser1 on 72 Ld Reminis Echo on 73 Ld Magical Echo on on on on 74 Ld BritReso Chorus4 on on 75 Ld LandMoon Flanger1 on on 76 Ld DigiVox 3Band EQ on on 77 Ld LowCut! 3Band EQ on 78 Ld Dgtalian 3Band EQ on on 79 Ld SynHarmo Delay L.R on on 80 Ld WarmSolo Delay L.R on on 81 Ld DistReso Distortion on 82 Me GranBlue Delay L.R on on on on 83 Me Spiral Flanger on on on on 84 Me Phantom Flanger3 on on on on 85 Me Emperor Chorus4 on on on on 86 Me TimeTrvl Flanger2 on on on 87 Me EastWind Celeste4 on on on 88 Me Ripple Phaser2 on on on 89 Me Maya 2Band EQ on on on 90 Me GlassChr Chorus4 on on on on 91 Me Electro Phaser1 on on 92 Me Jet Phaser2 on on 93 Me Aqua Celeste4 on on on on 94 Me TinMellw Delay L.R on on on 95 Me Ancient Cross Delay on on on 96 Me Cloudy Chorus2 on on 97 Sc SynPfCmp Delay L.R on 98 Sc SynBrCmp Early Ref1 on on

99 Sc SynVcCmp Dealy L.R on on 100 Sc SynMalet Echo on on 101 Sc SynMrmba Echo on on on 102 Sc SynCrstl Celeste1 on on 103 Sc UrbnGard Reverse Gate on on on 104 Sc SynVox Echo on on 105 Sc Oriental Echo on on 106 Sc WoodyCmp Delay L.C.R on on 107 Sc PulseSeq Delay L.R on on 108 Sc HappyVox Cross Delay on on on 109 Sc FMClkOrg 2Band EQ on on 110 Sc FM Compy Early Ref1 on on 111 Sc Pianet Flanger3 on on 112 Se Big Hit Gate Reverb on on on on 113 Se Industry Phaser2 on on on 114 Se Scream Distortion on on 115 Se Spring Flanger3 on on on 116 Se Haunted Delay L.R on on on on 117 Se SpceShip Phaser1 on on 118 Se Increase Distortion on on 119 Se a Blow Distortion on on 120 Se Fire Distortion on on 121 Dr BassPerc 2Band EQ on 122 Co PianoCmb Gate Reverb on on on on 123 Co EG Combo Early Ref1 on on on on 124 Co IndiaSet Early Ref2 on on on on 125 Co AsianSet Early Ref2 on on on on 126 Co JamicSet Early Ref2 on on 127 Co AfrcaSet Early Ref1 on on on 128 Co MdEstSet Gate Reverb on on on on

Element Switch

1234

XG Normal Voice List

Bank Select MSB=00, LSB=Bank Number

Instrument

Pgm#

Group

Piano 1 Acoustic Grand Piano GrandPno 1 GrndPnoK 1 MelloGrP 1

Chromatic 9 Celesta Celesta 1 Percussion 10 Glockenspiel Glocken 1

Organ 17 Drawbar Organ 1 DrawOrgn 1

Guitar 25 Acoustic Guitar (nylon) 1 NylonGtr 1 NylonGt2 1

Bass 33 Acoustic Bass Aco.Bass 1

Strings 41 Violin Violin 1 Slow Vln 1

Ensemble 49 String Ensemble 1 Strings1 1 S.Strngs 2 Slow Str 1 Arco Str 2

Brass 57 Trumpet Trumpet 1 Trumpet2 1 BriteTrp 2

Reed 65 Soprano Sax SprnoSax 1

Pipe 73 Piccolo Piccolo 1

Synth Lead 81 Lead 1 (square) SquareLd 2 SquarLd2 1 LMSquare 2 Hollow 1 Shroud 2

Synth Pad 89 Pad 1 (new age) NewAgePd 2

Synth Effects 97 FX 1 (rain) Rain 2

100 FX 4 (atmosphere) Atmosphr 2 WarmAtms 2 HollwRls 2 101 FX 5 (brightness) Bright 2 102 FX 6 (goblins) Goblins 2 103 FX 7 (echoes) Echoes 2 Echoes 2 2 Echo Pan 2

Ethnic 105 Sitar Sitar 1

Percussive 113 Tinkle Bell TnklBell 2

Sound Effects 121 Guitar Fret Noise FretNoiz 2

104 FX 8 (sci-ﬁ) Sci-Fi 2 106 Banjo Banjo 1

107 Shamisen Shamisen 1 108 Koto Koto 1 109 Kalimba Kalimba 1 110 Bagpipe Bagpipe 2 111 Fiddle Fiddle 1 112 Shanai Shanai 1

114 Agogo Agogo 2 115 Steel Drums SteelDrm 2 116 Woodblock Woodblok 1 117 Taiko Drum TaikoDrm 1 118 Melodic Tom 1 MelodTom 2 119 Synth Drum Syn Drum 1 120 Reverse Cymbal RevCymbl 1

122 Breath Noise BrthNoiz 2 123 Seashore Seashore 2 124 Bird Tweet T weet 2 125 Telephone Ring Telphone 1 126 Helicopter Helicptr 1 127 Applause Applause 1 128 Gunshot Gunshot 1

: Same as Bank 0 : No sound E : Element number

Bank 0

Bank Select LSB=00

2 Bright Acoustic Piano BritePno 1 BritPnoK 1 3 Electric Grand Piano El.Grand 2 ElGrPnoK 2 4 Honky-tonk Piano HnkyTonk 2 HnkyTnkK 2 5 Electric Piano 1 E.Piano1 2 El.Pno1K 1 MelloEP1 2 6 Electric Piano 2 E.Piano2 2 El.Pno2K 1 7 Harpsichord Harpsi. 1 Harpsi.K 1 8 Clavi Clavi. 2 Clav K 1

11 Music Box MusicBox 2 12 Vibraphone Vibes 1 Vibes K 1 13 Marimba Marimba 1 MarimbaK 1 14 Xylophone Xylophon 1 15 Tubular Bells TubulBel 1 16 Dulcimer Dulcimer 1

18 Percussive Organ PercOrgn 1 70sPcOr1 2 19 Rock Organ RockOrgn 2 20 Church Organ 1 ChrchOrg 2 21 Reed Organ ReedOrgn 1 22 Accordion Acordion 2 23 Hamonica Harmnica 1 24 Tango Accordion TangoAcd 2

26 Acoustic Guitar (steel) SteelGtr 1 SteelGt2 1 27 Electric Guitar (jazz) Jazz Gtr 1 MelloGtr 1 28 Electric Guitar (clean) CleanGtr 1 29 Electric Guitar (muted) Mute.Gtr 1 30 Overdriven Guitar Ovrdrive 1 31 Distortion Guitar Dist.Gtr 1 32 Guitar Harmonics GtrHarmo 1

34 Electric Bass (ﬁnger) FngrBass 1 FingrDrk 2 35 Electric Bass (pick) PickBass 1 36 Fretless Bass Fretless 1 37 Slap Bass 1 SlapBas1 1 38 Slap Bass 2 SlapBas2 1 39 Synth Bass 1 SynBass1 1 SynBa1Dk 1 FastResB 1 AcidBass 1 40 Synth Bass 2 SynBass2 2 MelloSBa 1 Seq Bass 2 ClkSynBa 2 SynBa2Dk 1

42 Viola Viola 1 43 Cello Cello 1 44 Contrabass Contrabs 1 45 Tremolo Strings Trem.Str 1 SlwTrStr 1 46 Pizzicato Strings Pizz.Str 1 47 Orchestral Harp Harp 1 48 Timpani Timpani 1

50 String Ensemble 2 Strings2 1 51 Synth Strings 1 Syn.Str1 2 52 Synth Strings 2 Syn.Str2 2 53 Choir Aahs ChoirAah 1 S.Choir 2 Ch.Aahs2 2 54 Voice Oohs VoiceOoh 1 55 Synth Voice SynVoice 1 56 Orchestra Hit Orch.Hit 2

58 Trombone Trombone 1 Trmbone2 2 59 Tuba Tuba 1 Tuba 2 1 60 Muted Trumpet Mute.Trp 1 61 French Horn Fr. Horn 2 FrHrSolo 1 62 Brass Section 1 BrasSect 1 63 Synth Brass 1 SynBrss1 2 Quack Br 2 RezSynBr 2 PolyBrss 2 64 Synth Brass 2 SynBrss2 1 Soft Brs 2

66 Alto Sax Alto Sax 1 67 Tenor Sax TenorSax 1 68 Baritone Sax Bari.Sax 1 69 Oboe Oboe 2 70 English Horn Eng.Horn 1 71 Bassoon Bassoon 1 72 Clarinet Clarinet 1

74 Flute Flute 1 75 Recorder Recorder 1 76 Pan Flute PanFlute 1 77 Blown Bottle Bottle 2 78 Shakuhachi Shakhchi 2 79 Whistle Whistle 1 80 Ocarina Ocarina 1

82 Lead 2 (sawtooth) Saw Ld 2 Saw Ld 2 1 ThickSaw 2 Dyna Saw 1 Digi Saw 2 Big Lead 2 HeavySyn 2 83 Lead 3 (calliope) CaliopLd 2 84 Lead 4 (chiff) Chiff Ld 2 85 Lead 5 (charang) CharanLd 2 86 Lead 6 (voice) Voice Ld 2 SynthAah 2 87 Lead 7 (ﬁfths) Fifth Ld 2 88 Lead 8 (bass+lead) Bass&Ld 2 Big&Low 2

90 Pad 2 (warm) Warm Pad 2 ThickPad 2 Soft Pad 2 Sine Pad 2 91 Pad 3 (polysynth) PolySyPd 2 92 Pad 4 (choir) ChoirPad 2 93 Pad 5 (bowed) BowedPad 2 94 Pad 6 (metallic) MetalPad 2 95 Pad 7 (halo) Halo Pad 2 96 Pad 8 (sweep) SweepPad 2 Shwimmer 2

98 FX 2 (soundtrack) SoundTrk 2 99 FX 3 (crystal) Crystal 2 SynDrCmp 2 Popcorn 2 TinyBell 2

KSP Stereo Single Slow Fast Decay Double Attack Bright Dark Rsonant Attack

Bank 0 E Bank 1 E Bank 3 E Bank 6 E Bank 8 E Bank 12 E Bank 14 E Bank 16 E Bank 17 E Bank 18 E Bank 19 E Bank 20 E Bank 24 E

S.SlwStr 2 LegatoSt 2

Instrument

Pgm#

Group

Piano 1 Acoustic Grand Piano GrandPno 1 PianoStr 2

Chromatic 9 Celesta Celesta 1 Percussion 10 Glockenspiel Glocken 1

Organ 17 Drawbar Organ 1 DrawOrgn 1 DetDrwOr 2 60sDrOr1 2 60sDrOr2 2 70sDrOr1 2 DrawOrg2 2 60sDrOr3 2 Even Bar 2 16+2"2/3 2

Guitar 25 Acoustic Guitar (nylon) 1 NylonGtr 1 NylonGt3 2

Bass 33 Acoustic Bass Aco.Bass 1 JazzRthm 2

Strings 41 Violin Violin 1

Ensemble 49 String Ensemble 1 Strings1 1 60sStrng 2 Orchestr 2

Brass 57 Trumpet Trumpet 1 Warm Trp 2

Reed 65 Soprano Sax SprnoSax 1

Pipe 73 Piccolo Piccolo 1

Synth Lead 81 Lead 1 (square) SquareLd 2

Synth Pad 89 Pad 1 (new age) NewAgePd 2

Synth Effects 97 FX 1 (rain) Rain 2

100 FX 4 (atmosphere) Atmosphr 2 101 FX 5 (brightness) Bright 2 102 FX 6 (goblins) Goblins 2 103 FX 7 (echoes) Echoes 2

Ethnic 105 Sitar Sitar 1 DetSitar 2 Sitar 2 2

Percussive 113 Tinkle Bell TnklBell 2

Sound Effects 121 Guitar Fret Noise FretNoiz 2

104 FX 8 (sci-ﬁ) Sci-Fi 2 106 Banjo Banjo 1 MuteBnjo 1

107 Shamisen Shamisen 1 108 Koto Koto 1 109 Kalimba Kalimba 1 110 Bagpipe Bagpipe 2 111 Fiddle Fiddle 1 112 Shanai Shanai 1

114 Agogo Agogo 2 115 Steel Drums SteelDrm 2 116 Woodblock Woodblok 1 117 Taiko Drum TaikoDrm 1 118 Melodic Tom 1 MelodTom 2 119 Synth Drum Syn Drum 1 120 Reverse Cymbal RevCymbl 1

122 Breath Noise BrthNoiz 2 123 Seashore Seashore 2 124 Bird Tweet T weet 2 125 Telephone Ring Telphone 1 126 Helicopter Helicptr 1 127 Applause Applause 1 128 Gunshot Gunshot 1

Bank 0

Bank Select LSB=00

2 Bright Acoustic Piano BritePno 1 3 Electric Grand Piano El.Grand 2 Det.CP80 2 LayerCP1 2 4 Honky-tonk Piano HnkyTonk 2 5 Electric Piano 1 E.Piano1 2 Chor.EP1 2 HardEl.P 2 6 Electric Piano 2 E.Piano2 2 Chor.EP2 2 DX Hard 2 DXLegend 2 DX Phase 2 7 Harpsichord Harpsi. 1 Harpsi.2 2 8 Clavi Clavi. 2 ClaviWah 2

11 Music Box MusicBox 2 12 Vibraphone Vibes 1 13 Marimba Marimba 1 14 Xylophone Xylophon 1 15 Tubular Bells TubulBel 1 16 Dulcimer Dulcimer 1 Dulcimr2 2

18 Percussive Organ PercOrgn 1 DetPrcOr 2 Lite Org 2 PercOrg2 2 19 Rock Organ RockOrgn 2 20 Church Organ 1 ChrchOrg 2 ChurOrg3 2 ChurOrg2 2 NotreDam 2 21 Reed Organ ReedOrgn 1 Puff Org 2 22 Accordion Acordion 2 AccordIt 2 23 Hamonica Harmnica 1 Harmo. 2 2 24 Tango Accordion TangoAcd 2

26 Acoustic Guitar (steel) SteelGtr 1 12StrGtr 2 Nyln&Stl 2 27 Electric Guitar (jazz) Jazz Gtr 1 Jazz Amp 2 28 Electric Guitar (clean) CleanGtr 1 ChorusGt 2 29 Electric Guitar (muted) Mute.Gtr 1 FunkGtr1 2 30 Overdriven Guitar Ovrdrive 1 31 Distortion Guitar Dist.Gtr 1 FeedbkGt 2 32 Guitar Harmonics GtrHarmo 1

34 Electric Bass (ﬁnger) FngrBass 1 35 Electric Bass (pick) PickBass 1 36 Fretless Bass Fretless 1 Fretles2 2 Fretles3 2 Fretles4 2 37 Slap Bass 1 SlapBas1 1 ResoSlap 1 PunchThm 2 38 Slap Bass 2 SlapBas2 1 39 Synth Bass 1 SynBass1 1 Clv Bass 2 TechnoBa 2 40 Synth Bass 2 SynBass2 2

42 Viola Viola 1 43 Cello Cello 1 44 Contrabass Contrabs 1 45 Tremolo Strings Trem.Str 1 Susp.Str 2 46 Pizzicato Strings Pizz.Str 1 47 Orchestral Harp Harp 1 YangChin 2 48 Timpani Timpani 1

50 String Ensemble 2 Strings2 1 51 Synth Strings 1 Syn.Str1 2 52 Synth Strings 2 Syn.Str2 2 53 Choir Aahs ChoirAah 1 MelChoir 2 ChoirStr 2 54 Voice Oohs VoiceOoh 1 55 Synth Voice SynVoice 1 SyVoice2 2 56 Orchestra Hit Orch.Hit 2 OrchHit2 2

58 Trombone Trombone 1 59 Tuba Tuba 1 60 Muted Trumpet Mute.Trp 1 61 French Horn Fr. Horn 2 FrHorn 2 1 HornOrch 2 62 Brass Section 1 BrasSect 1 Tp&TbSec 2 BrssSec2 2 63 Synth Brass 1 SynBrss1 2 64 Synth Brass 2 SynBrss2 1 SynBrss4 2

66 Alto Sax Alto Sax 1 Sax Sect 2 67 Tenor Sax TenorSax 1 BrthTnSx 2 68 Baritone Sax Bari.Sax 1 69 Oboe Oboe 2 70 English Horn Eng.Horn 1 71 Bassoon Bassoon 1 72 Clarinet Clarinet 1

74 Flute Flute 1 75 Recorder Recorder 1 76 Pan Flute PanFlute 1 77 Blown Bottle Bottle 2 78 Shakuhachi Shakhchi 2 79 Whistle Whistle 1 80 Ocarina Ocarina 1

82 Lead 2 (sawtooth) Saw Ld 2 WaspySyn 2 PulseSaw 2 83 Lead 3 (calliope) CaliopLd 2 84 Lead 4 (chiff) Chiff Ld 2 85 Lead 5 (charang) CharanLd 2 86 Lead 6 (voice) Voice Ld 2 87 Lead 7 (ﬁfths) Fifth Ld 2 Big Five 2 88 Lead 8 (bass+lead) Bass&Ld 2

90 Pad 2 (warm) Warm Pad 2 91 Pad 3 (polysynth) PolySyPd 2 92 Pad 4 (choir) ChoirPad 2 93 Pad 5 (bowed) BowedPad 2 94 Pad 6 (metallic) MetalPad 2 95 Pad 7 (halo) Halo Pad 2 96 Pad 8 (sweep) SweepPad 2 Converge 2

98 FX 2 (soundtrack) SoundTrk 2 Prologue 2 99 FX 3 (crystal) Crystal 2 RndGlock 2 GlockChi 2

Release Rezo Sweep Muted Detune 1 Detune 2 Detune 3 Octave 1 Octave 2 5th 1 5th 2 Bend Tutti

Bank 0 E Bank 25 E Bank 27 E Bank 28 E Bank 32 E Bank 33 E Bank 34 E Bank 35 E Bank 36 E Bank 37 E Bank 38 E Bank 39 E Bank 40 E

Harpsi.3 2

FlangeBa 2 Ba&DstEG 2

Reso Str 2

SynBrss3 2 JumpBrss 2

MutePkBa 1

SmthSynB 2 ModulrBa 2

Warm Str 2

Nylon EP 2

: Same as Bank 0 : No sound E : Element number

Instrument

Pgm#

Group

Piano 1 Acoustic Grand Piano GrandPno 1 Dream 2

Chromatic 9 Celesta Celesta 1 Percussion 10 Glockenspiel Glocken 1

Organ 17 Drawbar Organ 1 DrawOrgn 1 Organ Ba 1 70sDrOr2 2 CheezOrg 2 DrawOrg3 2

Guitar 25 Acoustic Guitar (nylon) 1 NylonGtr 1 VelGtHrm 2

Bass 33 Acoustic Bass Aco.Bass 1 VXUprght 2

Strings 41 Violin Violin 1

Ensemble 49 String Ensemble 1 Strings1 1 Orchstr2 2 TremOrch 2 Velo.Str 2

Brass 57 Trumpet Trumpet 1

Reed 65 Soprano Sax SprnoSax 1

Pipe 73 Piccolo Piccolo 1

Synth Lead 81 Lead 1 (square) SquareLd 2 Mellow 2 SoloSine 2 SineLead 1

Synth Pad 89 Pad 1 (new age) NewAgePd 2 Fantasy 2

Synth Effects 97 FX 1 (rain) Rain 2 ClaviPad 2 HrmoRain 2 AfrcnWnd 2 Carib 2

100 FX 4 (atmosphere) Atmosphr 2 101 FX 5 (brightness) Bright 2 FantaBel 2 102 FX 6 (goblins) Goblins 2 GobSynth 2 Creeper 2 Ring Pad 2 Ritual 2 ToHeaven 2 Night 2 Glisten 2 103 FX 7 (echoes) Echoes 2 EchoBell 2 Big Pan 2 SynPiano 2 Creation 2 StarDust 2 Reso&Pan 2

Ethnic 105 Sitar Sitar 1

Percussive 113 Tinkle Bell TnklBell 2

Sound Effects 121 Guitar Fret Noise FretNoiz 2

104 FX 8 (sci-ﬁ) Sci-Fi 2 Starz 2 106 Banjo Banjo 1

107 Shamisen Shamisen 1 108 Koto Koto 1 109 Kalimba Kalimba 1 110 Bagpipe Bagpipe 2 111 Fiddle Fiddle 1 112 Shanai Shanai 1 Shanai 2 1

114 Agogo Agogo 2 115 Steel Drums SteelDrm 2 116 Woodblock Woodblok 1 117 Taiko Drum TaikoDrm 1 118 Melodic Tom 1 MelodTom 2 Mel Tom2 1 Real Tom 2 Rock Tom 2 119 Synth Drum Syn Drum 1 Ana T om 1 ElecPerc 2 120 Reverse Cymbal RevCymbl 1

122 Breath Noise BrthNoiz 2 123 Seashore Seashore 2 124 Bird Tweet T weet 2 125 Telephone Ring Telphone 1 126 Helicopter Helicptr 1 127 Applause Applause 1 128 Gunshot Gunshot 1

Bank 0

Bank Select LSB=00

2 Bright Acoustic Piano BritePno 1 3 Electric Grand Piano El.Grand 2 LayerCP2 2 4 Honky-tonk Piano HnkyTonk 2 5 Electric Piano 1 E.Piano1 2 VX El.P1 2 60sEl.P1 1 6 Electric Piano 2 E.Piano2 2 DX+Analg 2 DXKotoEP 2 VX El.P2 2 7 Harpsichord Harpsi. 1 8 Clavi Clavi. 2 PulseClv 1 PierceCl 2

11 Music Box MusicBox 2 Orgel 2 12 Vibraphone Vibes 1 HardVibe 2 13 Marimba Marimba 1 SineMrmb 2 14 Xylophone Xylophon 1 15 Tubular Bells TubulBel 1 16 Dulcimer Dulcimer 1

18 Percussive Organ PercOrgn 1 19 Rock Organ RockOrgn 2 RotaryOr 2 SloRotar 2 FstRotar 2 20 Church Organ 1 ChrchOrg 2 OrgFlute 2 TrmOrgFl 2 21 Reed Organ ReedOrgn 1 22 Accordion Acordion 2 23 Hamonica Harmnica 1 24 Tango Accordion TangoAcd 2 TngoAcd2 2

26 Acoustic Guitar (steel) SteelGtr 1 Stl&Body 2 27 Electric Guitar (jazz) Jazz Gtr 1 28 Electric Guitar (clean) CleanGtr 1 29 Electric Guitar (muted) Mute.Gtr 1 MuteStlG 2 FunkGtr2 2 Jazz Man 1 30 Overdriven Guitar Ovrdrive 1 Gt.Pinch 2 31 Distortion Guitar Dist.Gtr 1 FeedbkG2 2 32 Guitar Harmonics GtrHarmo 1 GtFeedbk 1 GtrHrmo2 1

34 Electric Bass (ﬁnger) FngrBass 1 FngrSlap 2 FngBass2 2 Mod.Bass 2 35 Electric Bass (pick) PickBass 1 36 Fretless Bass Fretless 1 37 Slap Bass 1 SlapBas1 1 38 Slap Bass 2 SlapBas2 1 VeloSlap 2 39 Synth Bass 1 SynBass1 1 Orbiter 2 Sqr.Bass 1 RubberBa 2 40 Synth Bass 2 SynBass2 2 DX Bass 2 X WireBa 2

42 Viola Viola 1 43 Cello Cello 1 44 Contrabass Contrabs 1 45 Tremolo Strings Trem.Str 1 46 Pizzicato Strings Pizz.Str 1 47 Orchestral Harp Harp 1 48 Timpani Timpani 1

50 String Ensemble 2 Strings2 1 Kingdom 2 70s Str 1 Strings3 1 51 Synth Strings 1 Syn.Str1 2 Syn Str4 2 Syn Str5 2 52 Synth Strings 2 Syn.Str2 2 53 Choir Aahs ChoirAah 1 54 Voice Oohs VoiceOoh 1 55 Synth Voice SynVoice 1 Choral 2 AnaVoice 1 56 Orchestra Hit Orch.Hit 2 Impact 2

58 Trombone Trombone 1 59 Tuba Tuba 1 60 Muted Trumpet Mute.Trp 1 61 French Horn Fr. Horn 2 62 Brass Section 1 BrasSect 1 Hi Brass 2 MelloBrs 2 63 Synth Brass 1 SynBrss1 2 AnVelBr1 2 AnaBrss1 2 64 Synth Brass 2 SynBrss2 1 ChoirBrs 2 AnVelBr2 2 AnaBrss2 2

66 Alto Sax Alto Sax 1 HyprAlto 2 67 Tenor Sax TenorSax 1 SoftTenr 2 TnrSax 2 1 68 Baritone Sax Bari.Sax 1 69 Oboe Oboe 2 70 English Horn Eng.Horn 1 71 Bassoon Bassoon 1 72 Clarinet Clarinet 1

74 Flute Flute 1 75 Recorder Recorder 1 76 Pan Flute PanFlute 1 77 Blown Bottle Bottle 2 78 Shakuhachi Shakhchi 2 79 Whistle Whistle 1 80 Ocarina Ocarina 1

82 Lead 2 (sawtooth) Saw Ld 2 Dr. Lead 2 VeloLead 2 83 Lead 3 (calliope) CaliopLd 2 PureLead 2 84 Lead 4 (chiff) Chiff Ld 2 Rubby 2 85 Lead 5 (charang) CharanLd 2 DistLead 2 WireLead 2 86 Lead 6 (voice) Voice Ld 2 Vox Lead 2 87 Lead 7 (ﬁfths) Fifth Ld 2 88 Lead 8 (bass+lead) Bass&Ld 2 Fat&Prky 2 Soft Wrl 2

90 Pad 2 (warm) Warm Pad 2 Horn Pad 2 RotarStr 2 91 Pad 3 (polysynth) PolySyPd 2 PolyPd80 2 ClickPad 2 Ana. Pad 2 SquarPad 2 92 Pad 4 (choir) ChoirPad 2 Heaven 2 Itopia 2 CC Pad 2 93 Pad 5 (bowed) BowedPad 2 Glacier 2 GlassPad 2 94 Pad 6 (metallic) MetalPad 2 Tine Pad 2 Pan Pad 2 95 Pad 7 (halo) Halo Pad 2 96 Pad 8 (sweep) SweepPad 2 PolarPad 2 Celstial 2

98 FX 2 (soundtrack) SoundTrk 2 Ancestrl 2 99 FX 3 (crystal) Crystal 2 ClearBel 2 ChorBell 2 SynMalet 1 SftCryst 2 LoudGlok 2 ChrstBel 2 VibeBell 2 DigiBell 2 AirBells 2 BellHarp 2

Bank 0 E Bank 41 E Bank 42 E Bank 43 E Bank 45 E Bank 64 E

Velo-Switch Velo-Xfade other wave

NylnHarp 2 Harp Vox 2 AtmosPad 2 Planet 2

Bank 65 E Bank 66 E Bank 67 E Bank 68 E Bank 69 E Bank 70 E Bank 71 E

: Same as Bank 0 : No sound E : Element number

Instrument

Pgm#

Group

Piano 1 Acoustic Grand Piano GrandPno 1

Chromatic 9 Celesta Celesta 1 Percussion 10 Glockenspiel Glocken 1

Organ 17 Drawbar Organ 1 DrawOrgn 1

Guitar 25 Acoustic Guitar (nylon) 1 NylonGtr 1 Ukulele 1

Bass 33 Acoustic Bass Aco.Bass 1

Strings 41 Violin Violin 1

Ensemble 49 String Ensemble 1 Strings1 1

Brass 57 Trumpet Trumpet 1

Reed 65 Soprano Sax SprnoSax 1

Pipe 73 Piccolo Piccolo 1

Synth Lead 81 Lead 1 (square) SquareLd 2

Synth Pad 89 Pad 1 (new age) NewAgePd 2

Synth Effects 97 FX 1 (rain) Rain 2

100 FX 4 (atmosphere) Atmosphr 2 101 FX 5 (brightness) Bright 2 Smokey 2 102 FX 6 (goblins) Goblins 2 BelChoir 2 103 FX 7 (echoes) Echoes 2

Ethnic 105 Sitar Sitar 1 Tambra 2 Tamboura 2

Percussive 113 Tinkle Bell TnklBell 2 Bonang 2 Altair 2 Gamelan 2 S.Gamlan 2 Rama Cym 2 AsianBel 2

Sound Effects 121 Guitar Fret Noise FretNoiz 2

104 FX 8 (sci-ﬁ) Sci-Fi 2 106 Banjo Banjo 1 Rabab 2 Gopichnt 2 Oud 2

107 Shamisen Shamisen 1 108 Koto Koto 1 Taisho-k 2 Kanoon 2 109 Kalimba Kalimba 1 110 Bagpipe Bagpipe 2 111 Fiddle Fiddle 1 112 Shanai Shanai 1 Pungi 1 Hichriki 2

114 Agogo Agogo 2 115 Steel Drums SteelDrm 2 GlasPerc 2 ThaiBell 2 116 Woodblock Woodblok 1 Castanet 1 117 Taiko Drum TaikoDrm 1 Gr.Cassa 1 118 Melodic Tom 1 MelodTom 2 119 Synth Drum Syn Drum 1 120 Reverse Cymbal RevCymbl 1

122 Breath Noise BrthNoiz 2 123 Seashore Seashore 2 124 Bird Tweet T weet 2 125 Telephone Ring Telphone 1 126 Helicopter Helicptr 1 127 Applause Applause 1 128 Gunshot Gunshot 1

Bank 0

Bank Select LSB=00

2 Bright Acoustic Piano BritePno 1 3 Electric Grand Piano El.Grand 2 4 Honky-tonk Piano HnkyTonk 2 5 Electric Piano 1 E.Piano1 2 6 Electric Piano 2 E.Piano2 2 7 Harpsichord Harpsi. 1 8 Clavi Clavi. 2

11 Music Box MusicBox 2 12 Vibraphone Vibes 1 13 Marimba Marimba 1 Balimba 2 Log Drum 2 14 Xylophone Xylophon 1 15 Tubular Bells TubulBel 1 ChrchBel 2 Carillon 2 16 Dulcimer Dulcimer 1 Cimbalom 2 Santur 2

18 Percussive Organ PercOrgn 1 19 Rock Organ RockOrgn 2 20 Church Organ 1 ChrchOrg 2 21 Reed Organ ReedOrgn 1 22 Accordion Acordion 2 23 Hamonica Harmnica 1 24 Tango Accordion TangoAcd 2

26 Acoustic Guitar (steel) SteelGtr 1 Mandolin 2 27 Electric Guitar (jazz) Jazz Gtr 1 28 Electric Guitar (clean) CleanGtr 1 29 Electric Guitar (muted) Mute.Gtr 1 30 Overdriven Guitar Ovrdrive 1 31 Distortion Guitar Dist.Gtr 1 32 Guitar Harmonics GtrHarmo 1

34 Electric Bass (ﬁnger) FngrBass 1 35 Electric Bass (pick) PickBass 1 36 Fretless Bass Fretless 1 SynFretl 2 SmthFrtl 2 37 Slap Bass 1 SlapBas1 1 38 Slap Bass 2 SlapBas2 1 39 Synth Bass 1 SynBass1 1 Hammer 2 40 Synth Bass 2 SynBass2 2

42 Viola Viola 1 43 Cello Cello 1 44 Contrabass Contrabs 1 45 Tremolo Strings Trem.Str 1 46 Pizzicato Strings Pizz.Str 1 47 Orchestral Harp Harp 1 48 Timpani Timpani 1

50 String Ensemble 2 Strings2 1 51 Synth Strings 1 Syn.Str1 2 52 Synth Strings 2 Syn.Str2 2 53 Choir Aahs ChoirAah 1 54 Voice Oohs VoiceOoh 1 55 Synth Voice SynVoice 1 56 Orchestra Hit Orch.Hit 2

58 Trombone Trombone 1 59 Tuba Tuba 1 60 Muted Trumpet Mute.Trp 1 61 French Horn Fr. Horn 2 62 Brass Section 1 BrasSect 1 63 Synth Brass 1 SynBrss1 2 64 Synth Brass 2 SynBrss2 1

66 Alto Sax Alto Sax 1 67 Tenor Sax TenorSax 1 68 Baritone Sax Bari.Sax 1 69 Oboe Oboe 2 70 English Horn Eng.Horn 1 71 Bassoon Bassoon 1 72 Clarinet Clarinet 1

74 Flute Flute 1 75 Recorder Recorder 1 76 Pan Flute PanFlute 1 77 Blown Bottle Bottle 2 78 Shakuhachi Shakhchi 2 79 Whistle Whistle 1 80 Ocarina Ocarina 1

82 Lead 2 (sawtooth) Saw Ld 2 Seq Ana. 2 83 Lead 3 (calliope) CaliopLd 2 84 Lead 4 (chiff) Chiff Ld 2 85 Lead 5 (charang) CharanLd 2 86 Lead 6 (voice) Voice Ld 2 87 Lead 7 (ﬁfths) Fifth Ld 2 88 Lead 8 (bass+lead) Bass&Ld 2

98 FX 2 (soundtrack) SoundTrk 2 99 FX 3 (crystal) Crystal 2 Gamelmba 2

Bank 0 E Bank 72 E Bank 96 E Bank 97 E Bank 98 E Bank 99 E Bank 100 E Bank 101 E

: Same as Bank 0 : No sound E : Element numberî

Drum Voice List

Bank Slelect LSB=0

Bank MSB# 127 127 127 127 127 127 127 127 127 127

Note# Note Key off

Program # 1 2 9 17 25 26 28 33 41 49

13 C#-1 3 Surdo Mute 14 D-1 3 Surdo Open 15 D-1# Hi Q 16 E-1 Whip Slap 17 F-1 4 Scratch H 18 F#-1 4 Scratch L 19 G-1 Finger Snap 20 G#-1 Click Noise 21 A-1 Mtrnm Click 22 A#-1 Mtrnm Bell 23 B-1 Seq Click L 24 C0 Seq Click H 25 C#0 Brush Tap 26 D0 O Brush Swirl 27 D#0 Brush Slap 28 E0 O BrushTapSwrl ReversCymbal ReversCymbal ReversCymbal 29 F0 O Snare Roll 30 F#0 Castanet Hi Q 2 Hi Q 2 Hi Q 2 31 G0 Snare Soft Snare Soft 2 Snare Noisy SnrSnpyElctr SnareNoisy 4 Snare Techno Snare Jazz H Brush Slap 2 32 G#0 Sticks 33 A0 Kick Soft Kick 3 Kick 3 KickTechno Q Kick Soft 2 34 A#0 OpenRimShot RimShotHShrt Rim Gate RimShotLight 35 B0 Kick Tight Kick 2 Kick Gate KickAnlgShrt KickTechno L Gran Cassa 36 C1 Kick Kick Short Kick Gate KckGateHeavy Kick Analog KickTechno 2 Kick Jazz Kick Jazz GranCassa Mu 37 C#1 Side Stick Stick Light SideStickAn SideStickAn Stick Light Stick Light 38 D1 Snare Snare Short Snare Snappy Snare Rock SnareNoisy 2 SnareAnalog Snare Clap Snare Jazz L Brush Slap 3 Band Snare 39 D#1 Hand Clap 40 E1 Snare Tight SnareTight H SnrTightSnpy SnrRockTight SnareNoisy 3 SnareAnalog2 Snare Dry Snare Jazz M Brush Tap 2 Band Snare 2 41 F1 Floor Tom L Tom Room 1 Tom Rock 1 TomElectro 1 Tom Analog 1 Tom Analog 1 Tom Brush 1 42 F#1 1 Hi-HatClosed HatCloseAnlg Hi-HatCls 3 43 G1 Floor Tom H Tom Room 2 Tom Rock 2 TomElectro 2 Tom Analog 2 Tom Analog 2 Tom Brush 2 44 G#1 1 Hi-Hat Pedal HatCloseAn 2 HatCloseAn 3 45 A1 Low Tom Tom Room 3 Tom Rock 3 TomElectro 3 Tom Analog 3 Tom Analog 3 Tom Brush 3 46 A#1 1 Hi-Hat Open HatOpen Anlg Hi-HatOpn 3 47 B1 Mid T om L Tom Room 4 Tom Rock 4 TomElectro 4 Tom Analog 4 Tom Analog 4 Tom Brush 4 48 C2 Mid Tom H Tom Room 5 Tom Rock 5 TomElectro 5 Tom Analog 5 Tom Analog 5 Tom Brush 5 49 C#2 CrashCymbal1 Crash Analog Crash Analog Hand Cymbal 50 D2 High Tom 51 D#2 RideCymbal 1 HandCymShort 52 E2 Chinese Cym 53 F2 Ride Cym Cup 54 F#2 Tambourine 55 G2 SplashCymbal 56 G#2 Cowbell Cowbell Anlg Cowbell Anlg 57 A2 CrashCymbal2 HandCymbal 2 58 A#2 Vibraslap 59 B2 RideCymbal 2 HandCym2Shrt 60 C3 Bongo H 61 C#3 Bongo L 62 D3 Conga H Mute Conga Anlg H Conga Anlg H 63 D#3 Conga H Open Conga Anlg M Conga Anlg M 64 E3 Conga L Conga Anlg L Conga Anlg L 65 F3 Timbale H 66 F#3 Timbale L 67 G3 Agogo H 68 G#3 Agogo L 69 A3 Cabasa 70 A#3 Maracas Maracas 2 Maracas 2 71 B3 O SambaWhistlH 72 C4 O SambaWhistlL 73 C#4 Guiro Short 74 D4 O Guiro Long 75 D#4 Claves Claves 2 Claves 2 76 E4 Wood Block H 77 F4 Wood Block L 78 F#4 Cuica Mute Scratch H 2 Scratch H 2 Scratch H 2 79 G4 Cuica Open Scratch L 2 Scratch L 2 Scratch L 2 80 G#4 2 TriangleMute 81 A4 2 TriangleOpen 82 A#4 Shaker 83 B4 Jingle Bells 84 C5 Bell Tree 85 C#5 86 D5 87 D#5 88 E5 89 F5 90 F#5 91 G5

: Same as Standard Kit : No sound

Alternate

assign

StndKit1

(Standard Kit)

StndKit2

(Standard2 Kit)

Room Kit Rock Kit

Tom Room 6 Tom Rock 6 TomElectro 6 Tom Analog 6 Tom Analog 6 Tom Brush 6

ElctrKit

(Electro Kit)

AnalgKit

(Analog Kit)

Dance Kit Jazz Kit Brush Kit

(Symphony Kit)

SymphKit

Bank MSB# 127 127 127 127 127 127 127 127 126 126

Note# Note Key off

Program # 121 122 123 124 125 126 127 128 1 2

13 C#-1 3 14 D-1 3 15 D-1# 16 E-1 17 F-1 4 18 F#-1 4 19 G-1 20 G#-1 21 A-1 22 A#-1 23 B-1 24 C0 25 C#0 26 D0 O Noise Dark 1 Noise Dark 1 Noise Dark 2 27 D#0 28 E0 O ReversCymBal ReversCymBal ReversCymBal ReversCymBal 29 F0 O 30 F#0 Hi Q 2 Hi Q 2 Hi Q 2 Castanet 2 31 G0 Snare Studio SnareSnpyElctr Snare Techno Snare Tmbr 1 Snare Hip 1 32 G#0 Stick Dark Stick Dark Stick Dark 33 A0 Kick 3 Kick Bass Kick Bass Kick Bass 34 A#0 Rim Hard Rim Tight Snare Funk 1 OpenRimVari1 Rim Timber OpenRimVari2 35 B0 Kick Hard Kick Tight 2 Kick Stuidio1 Kick ElNoiz Kick Funk 1 KickTechno L Kick Timber KickTechno 2 36 C1 Kick Attack Kick Tight 3 Kick Studio2 Kick ElPop Kick Funk 2 Kick Noise Kick Noise Kick Hip CuttingNoiz Phone Call 37 C#1 ElSideStick SideStickR&B SideStkTmber SideStickHip CuttingNoiz Door Squeak 38 D1 Snare High Snare Tight2 Rim Studio 1 Snare ElPop Snare Funk 2 Snare R&B Snare Tmbr 2 Snare Hip 2 Door Slam 39 D#1 Clap ElPop String Slap Scratch Cut 40 E1 Snare Snap Snare Tight3 Rim Studio 2 Snare ElPop SnareRimFunk SnareClapR&B Snare Tmbr 3 Snare Hip 3 Scratch H 3 41 F1 Tom Studio 1 TomElectro 1 T om V ari 1 Tom Vari 1 Tom Vari 1 Wind Chime 42 F#1 1 HatCloseFunk HatClose R&B HatCloseTmbr HatCloseHip Telephone 2 43 G1 Tom Studio 2 TomElectro 2 Tom Vari 2 Tom Vari 2 T om V ari 2 44 G#1 1 HatPedal Hard HatPedalTght HatPedalFunk HatCloseAn 2 HatPedalTmbr HatPedalHip 45 A1 Tom Studio 3 TomElectro 3 Tom Vari 3 Tom Vari 3 T om V ari 3 46 A#1 1 HatOpen Low HatOpenTight HatOpenFunk HatOpen R&B HatOpenTmbr HatOpenHip 47 B1 Tom Studio 4 TomElectro 4 Tom Vari 4 Tom Vari 4 T om V ari 4 48 C2 Tom Studio 5 TomElectro 5 Tom V ari 5 Tom Vari 5 T om V ari 5 49 C#2 Crash Analog Crash Analog Crash Hip 1 50 D2 Tom Studio 6 TomElectro 6 Tom V ari 6 Tom Vari 6 T om V ari 6 51 D#2 RideCymbal 3 RideCymbal 3 Ride Hip 1 52 E2 Fl.Key Click CarEngnIgnit 53 F2 54 F#2 Tambourine 2 Tambourine 3 Tambourine 2 Car Passing 55 G2 56 G#2 Cowbell Anlg Cowbell Anlg Cowbell Siren 57 A2 58 A#2 59 B2 RideCym Vari RideCym Vari Ride Hip 2 Starship 60 C3 61 C#3 62 D3 63 D#3 64 E3 Conga Anlg L Conga Anlg L Conga Anlg L 65 F3 66 F#3 67 G3 68 G#3 Shower Laugh 69 A3 70 A#3 71 B3 O 72 C4 O 73 C#4 74 D4 O 75 D#4 Claves 2 Claves 2 Claves 2 76 E4 77 F4 78 F#4 Scratch H 2 Scratch H 2 Scratch H 2 79 G4 Scratch L 2 Scratch L 2 Scratch L 2 80 G#4 2 81 A4 2 82 A#4 83 B4 JingleBells2 JingleBells2 JingleBells2 84 C5 Dog Machine Gun 85 C#5 Horse Laser Gun 86 D5 Bird T weet 2 Explosion 87 D#5 88 E5 89 F5 90 F#5 Gorst 91 G5 Maou

Alternate

assign

NwStndKt

(New Standard Kit)

TightKit

StudioKt

(Studio Kit)

ElPopKit

(Electro Pop Kit)

Funk Kit R&B Kit

Ride Cup Vari Ride Cup Vari CarTireSqeal

Conga Anlg H Conga Anlg H Conga Anlg H Submarine Conga Anlg M Conga Anlg M Conga Anlg M

Cabasa 2 Cabasa 2 Cabasa 2 Thunder Scream Maracas 3 Maracas 3 Maracas 3 Wind Punch

TimberKt

(Timber Kit)

Telphone 1 Stream Heartbeat Telphone 2 Bubble Footsteps

HvyHipKt

(Heavy Hip Kit)

Crash Hip 2 Trai n

SFX Kit 1 SFX Kit 2

Car Crash

Jet Plane

Burst Coaster

Feed

FireWork

: Same as Standard Kit : No sound

Wave List

No. Category/WaveName No. Category/WaveName No. Category/WaveName No. Category/WaveName No. Category/WaveName

1 Pf:PianoL@ 101 Or:1 1/3 201 Pd:SynVoice 301 Dr:Stick 401 Wv:Bel2Wv 2 Pf:PianoL@2 102 Or:1 202 Cp:Celesta 302 Dr:SdQ 402 Wv:Ep1 3 Pf:Hrpscd@ 103 Or:Rotar 203 Cp:Glocken 303 Dr:T8SdA 403 Wv:Ep2 4 Or:Reed@ 104 Or:Clack 204 Cp:NewAge 304 Dr:T8SdB 404 Wv:Ep3 5 Gt:Jazz@ 105 Or:RotNz 205 Cp:Vibra 305 Dr:T9Snapy 405 Wv:Ep4 6 Gt:Harm@ 106 Or:SftTmp 206 Cp:Marimba 306 Dr:SdTekk 406 Wv:Ep5 7 Gt:Harm@2 107 Or:Perc 207 Cp:Xylophon 307 Dr:TomF 407 Wv:Ep6 8 St:Vln@ 108 Or:Perc+ 208 Cp:TublrBl 308 Dr:TomL 408 Wv:VoxE3 9 St:TrStr@ 109 Or:Perc- 209 Cp:Dulcimer 309 Dr:TomM 409 Wv:VoxG2 10 St:Strngs1@ 110 Or:Cool! 210 Cp:Bowed 310 Dr:TomH 410 Wv:Org1Wv 11 St:Strngs2@ 111 Gt:Nylon1 211 Cp:Kalimba 311 Dr:TomLp 411 Wv:Org2Wv 12 St:Strngs4@ 112 Gt:Nylon2 212 Cp:XyloLoop 312 Dr:TomRmA 412 Wv:Org3Wv 13 Br:Trmbn@ 113 Gt:NylnHi 213 Cp:TnklBel1 313 Dr:TomRmB 413 Wv:Mallet 14 Br:Tuba@ 114 Gt:Nylhrm 214 Cp:TnklBel2 314 Dr:TomRmC 414 Se:CutngNz 15 Br:Fr.Horn@ 115 Gt:Steel 215 Pc:Agogo1 315 Dr:TomRmD 415 Se:StrSlap 16 Rp:Alto@ 116 Gt:MtlStl 216 Pc:Agogo2 316 Dr:TomJzL 416 Se:Fl.Kclik 17 Rp:Shkhaci@ 117 Gt:12StrGt 217 Pc:StlDrm 317 Dr:TomJzH 417 Se:Shower 18 Rp:Ocarna@ 118 Gt:Jazz 218 Pc:Wdblck 318 Dr:AnaTomA 418 Se:Thunder 19 Or:TngAcc@ 119 Gt:Clean1 219 Pc:Wdblck2 319 Dr:AnaTomB 419 Se:Wind 20 Rp:Bagpip1@ 120 Gt:Clean2 220 Pc:Taiko 320 Dr:AnaTomC 420 Se:Stream 21 Rp:Bagpip2@ 121 Gt:Mute 221 Pc:BongoL 321 Dr:AnaTomD 421 Se:Bubble 22 Cp:Glocken@ 122 Gt:OverDriv 222 Pc:BongoH 322 Dr:T8TomA 422 Se:Dog 23 Cp:NewAge@ 123 Gt:Dist1 223 Pc:CongaL 323 Dr:T8TomB 423 Se:Horse 24 Cp:Vibra 124 Gt:Dist2 224 Pc:CongaH 324 Dr:T8TomC 424 Se:Tweet 25 Cp:Xylophn@ 125 Gt:DistCl 225 Pc:CongaT 325 Dr:HHCl1 425 Se:Tweet2 26 Cp:Dulcmer@ 126 Gt:DistMt 226 Pc:Cowbel 326 Dr:HHCl2 426 Se:PhonCall 27 Pc:StlDrm@ 127 Gt:Harm 227 Pc:GuiroS 327 Dr:HHCl3 427 Se:DorSqwk 28 En:OrcHit@ 128 Gt:Sitar 228 Pc:GuiroL 328 Dr:HHCl4 428 Se:DorSlam 29 En:OrcHit@2 129 Gt:Banjo 229 Pc:Tmbls 329 Dr:T8HHCl 429 Se:Scratch 30 Pf:PianoL 130 Gt:Shamisen 230 Pc:CuicaL 330 Dr:T9HHCl 430 Se:WndChim 31 Pf:PianoR 131 Gt:Koto 231 Pc:CuicaH 331 Dr:HHPdl1 431 Se:Telphone 32 Pf:GrandL 132 Gt:Harp 232 Pc:Cabasa 332 Dr:HHPdl2 432 Se:Telphon2 33 Pf:GrandR 133 Ba:Acstic 233 Pc:ClavesL 333 Dr:HHPdl3 433 Se:CarElgnt 34 Pf:GrandMn 134 Ba:Fing 234 Pc:ClavesH 334 Dr:HHOpn1 434 Se:CarTSqel 35 Pf:HonkyL 135 Ba:Pick 235 Pc:Castnt1 335 Dr:HHOpn2 435 Se:CarPass 36 Pf:Brite 136 Ba:Frtles 236 Pc:Castnt2 336 Dr:HHOpn3 436 Se:CarCrsh 37 Pf:CP80 137 Ba:Slap1 237 Pc:Maracs 337 Dr:T8HHOpn 437 Se:Train 38 Pf:Rds1 138 Ba:Slap2 238 Pc:Maracs2 338 Dr:T9HHOpn 438 Se:Laugh 39 Pf:Rds2S 139 Ba:Slap3 239 Pc:Shaker 339 Dr:HHTip 439 Se:Scream 40 Pf:Rds2H 140 Ba:SynBa1 240 Pc:Tmborn 340 Dr:DncTip 440 Se:Punch 41 Pf:RdsRanS 141 Ba:SynBa2 241 Pc:TriOpn 341 Dr:Ride1 441 Se:Heart 42 Pf:RdsRanS+ 142 St:Vln 242 Pc:VbSlp 342 Dr:Ride2 442 Se:FootStp 43 Pf:RdsRanS- 143 St:Viola 243 Pc:JnglBl 343 Dr:Cup 443 Se:MchinGun 44 Pf:RdsRanM 144 St:Cello 244 Pc:Clap 344 Dr:Crash1 444 Se:FretNoiz 45 Pf:RdsRanM+ 145 St:Cello2 245 Pc:Whistl 345 Dr:Crash2 445 Se:BrthNoiz 46 Pf:RdsRanM- 146 St:Cntrabs 246 Pc:Bltree 346 Dr:T8Crsh 446 Se:Seashore 47 Pf:RdsRanH 147 St:TrStr 247 Pc:FngSnap 347 Dr:HndCym 447 Se:Helicptr 48 Pf:RdsRanH+ 148 St:Pizz 248 Pc:Mtrnm1 348 Dr:DncCrshA 448 Se:Aplause 49 Pf:RdsRanH- 149 St:Strings1 249 Pc:Mtrnm2 349 Dr:DncCrshB 449 Se:Gunshot 50 Pf:RdsTeaS 150 St:Strings2 250 Pc:Scrch 350 Dr:RevCym 450 Se:Noise 51 Pf:RdsTeaM 151 St:Strings3 251 Pc:WhipSlp 351 Dr:China 451 Se:Melow 52 Pf:RdsTeaH 152 St:Strings4 252 Dr:Bd1 352 Dr:T8Cwbl 452 Se:BigSyn 53 Pf:60sEp 153 St:StrL 253 Dr:Bd2 353 Dr:Timpni1 453 Se:VxAlk 54 Pf:Wurli 154 St:StrLA 254 Dr:Bd3 354 Dr:Timpni2 55 Pf:Wurli+ 155 St:StrR 255 Dr:Bd4 355 Dr:CncrtBd 56 Pf:Wurli- 156 St:StrRA 256 Dr:Bd5 356 Dr:OrchHit 57 Pf:DX1 157 St:SmlEns 257 Dr:BdSoft 357 Wv:ObStr 58 Pf:DX2 158 St:SmlEns+ 258 Dr:BdKlick 358 Wv:SyzStr 59 Pf:FulTineS 159 St:SmlEns- 259 Dr:BdPop 359 Wv:Padd 60 Pf:FulTineH 160 Br:Trmpt 260 Dr:BdHby 360 Wv:SyncLd 61 Pf:Clav 161 Br:Trmbn 261 Dr:BdToni 361 Wv:CS80Br 62 Pf:Hrpscd 162 Br:Tuba 262 Dr:BdAna 362 Wv:MgBs1 63 Pf:MltPno 163 Br:MuteTp 263 Dr:BdAna2 363 Wv:MgBs2 64 Or:Jazz1 164 Br:Fr.Horn 264 Dr:BdHiQ 364 Wv:MgBs3 65 Or:Jazz2 165 Br:BrssSect 265 Dr:BdHip 365 Wv:FMBs1 66 Or:PercOrgn 166 Br:SectnL 266 Dr:T8Bd 366 Wv:FMBs2 67 Or:Rock1 167 Br:SectnR 267 Dr:Surdo 367 Wv:FMBs3 68 Or:Rock2 168 Br:SctnL- 268 Dr:SdMx1 368 Wv:Pulse10 69 Or:Rock2+ 169 Br:SctnR- 269 Dr:SdMx2 369 Wv:P50-1 70 Or:Rock2- 170 Rp:Soprn 270 Dr:SdSoft 370 Wv:P50-2 71 Or:Church1 171 Rp:Alto 271 Dr:SdSft2 371 Wv:P50-3 72 Or:Church2 172 Rp:Tenor 272 Dr:SdRoomA 372 Wv:P50Low 73 Or:Reed 173 Rp:Baritone 273 Dr:SdRoomB 373 Wv:Square 74 Or:Puff 174 Rp:Oboe 274 Dr:SdRoomC 374 Wv:Saw 75 Or:Warm 175 Rp:EngHorn 275 Dr:SdLw 375 Wv:SawMod 76 Or:Elctrnc 176 Rp:Basoon 276 Dr:SdMl 376 Wv:MtrxSaw 77 Or:Elctrnc- 177 Rp:Clari 277 Dr:SdMx 377 Wv:Tri 78 Or:VoxOrg 178 Rp:Piccolo 278 Dr:SdOpnRm 378 Wv:Oscar 79 Or:VxOrg- 179 Rp:Flute 279 Dr:SdLight 379 Wv:Sine 80 Or:Swith 180 Rp:SprnRcrd 280 Dr:SdMidum 380 Wv:Digi01 81 Or:Swith- 181 Rp:PanFlute 281 Dr:SdRim 381 Wv:Digi02 82 Or:1+3 182 Rp:Bottle 282 Dr:SdAkstk 382 Wv:Digi03 83 Or:1+3+ 183 Rp:Shakhaci 283 Dr:SdFsnH 383 Wv:Digi04 84 Or:1+3- 184 Rp:Whistle 284 Dr:SdLdwH 384 Wv:Digi05 85 Or:2+4 185 Rp:Ocarina 285 Dr:SdSonA 385 Wv:Digi06 86 Or:2+4+ 186 Rp:Calliope 286 Dr:SdSonB 386 Wv:Digi07 87 Or:2+4- 187 Rp:Acrdn 287 Dr:SdPclH 387 Wv:Digi08 88 Or:Even 188 Rp:BlsHarp1 288 Dr:SdPcBH 388 Wv:Digi09 89 Or:Even+ 189 Rp:BlsHarp2 289 Dr:SdRim1 389 Wv:Digi10 90 Or:Even- 190 Rp:TngAcc 290 Dr:SdRim2 390 Wv:Digi11 91 Or:Odd 191 Rp:Bagpipe1 291 Dr:SdDry 391 Wv:Digi12 92 Or:Odd+ 192 Rp:Bagpipe2 292 Dr:SdRoll 392 Wv:DgVox1 93 Or:Odd- 193 Rp:Shanai 293 Dr:SdRol2 393 Wv:DgVox2 94 Or:16 194 Pd:SynStrg1 294 Dr:SdBrs 394 Wv:DgVox3 95 Or:5 1/3 195 Pd:SynStrg2 295 Dr:BrHard 395 Wv:DgVox4 96 Or:8 196 Pd:Aah 296 Dr:BrSoft 396 Wv:DgVox5 97 Or:4 197 Pd:Ooh 297 Dr:C.Rim1 397 Wv:MgRamp 98 Or:2 2/3 198 Pd:Oooo 298 Dr:C.Rim2A 398 Wv:SawSqu 99 Or:2 199 Pd:Oooo+ 299 Dr:C.Rim2B 399 Wv:SquSaw

100 Or:1 3/5 200 Pd:Oooo- 300 Dr:T8Side 400 Wv:Bel1Wv

Original Kit List

No. Original Kit Name

1 StndKit1 (Standard1 Kit) 2 StndKit2 (Standard2 Kit) 3 Room Kit 4 Rock Kit 5 ElctrKit (Electro Kit) 6 AnalgKit (Analog Kit) 7 Dance Kit 8 Jazz Kit

9 Brush Kit 10 SymphKit(Symphony Kit) 11 NwStndKt (New Standard Kit) 12 TightKit (Tight Kit) 13 StudioKt (Studio Kit) 14 ElPopKit (Electro Pop Kit) 15 Funk Kit 16 R&B Kit 17 TimberKt (Timber Kit) 18 HvyHipKt (Heavy Hip Kit) 19 SFX Kit 1 20 SFX Kit 2

Multi List

Bank Select MSB=63, LSB=64

Number Category Name

1 2 3 4 5 6 7 8

9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32

PF DigiRich PF RosePad OR Minister GT Gtr+Pad ST Str+Bell PD SuperPad BR FatBrass RP PipePad SC AtkComp CO SynBa_Ep CO Gt_SynLd CO Pizz_Str CO Pad_Dist CO FBass_Or CO Ep_Trpt CO Org_Lead

-- Pops

-- Ballad

-- R&B

-- HipHop

-- ClubJazz

-- Techno

-- House

-- Fusion

-- 80sDance

-- FunkRock

-- HardRock

-- Blues

-- Big Band

-- Salsa

-- Trance

-- DrmnBass

Control List

Controller

Name No. Remarks

PITCH BEND Pitch Bend MODULATION WHEEL (1) Set in the Utility Mode FOOT CONTROLLER (11) Set in the Utility Mode FOOT SWITCH (64) Set in the Utility Mode

The control numbers in the parentheses are the defaults.

Control Change Number List

No. Controller or function

000 Bank select MSB (off) 001 Modulation wheel 002~004 Unused 005 Portamento time 006 Data entry MSB 007 Volume control 008~009 Unused 010 Panpot 011 Expression 012~031 Unused 032 Bank select LSB (off) 033~037 Unused 038 Data entry LSB 039~063 Unused 064 Hold 1 (Sustain) 065 Portamento switch 066 Sostenuto 067 Soft pedal 068~070 Unused 071 Harmonic Content 072 Release Time 073 Attack Time 074 Brightness 075~083 Unused 084 Portamento Control 085~090 Unused 091 Effect1 Depth (Reverb Send Level) 092 Unused 093 Effect3 Depth (Chorus Send Level) 094 Effect4 Depth (Variation Effect Send Level) 095 Unused 096 Data Increment 097 Data Decrement 098 NRPN LSB 099 NRPN MSB 100 RPN LSB 101 RPN MSB 102~119 Unused 120 All Sounds Off 121 Reset All Controllers 122 Unused 123 All Notes Off 124 Omni Off 125 Omni On 126 Mono 127 Poly

Effect Type List

REVERB

No. MSB LSB Effect Type Features

0 00H 00H No Effect Effect turned off. 1 01H 00H Hall 1 Reverb simulating the resonance of a hall. 2 01H 01H Hall 2 3 02H 00H Room 1 Reverb simulating the resonance of a room. 4 02H 01H Room 2 5 02H 02H Room 3 6 03H 00H Stage 1 Reverb appropriate for a solo instrument. 7 03H 01H Stage 2 8 04H 00H Plate Reverb simulating a metal plate reverb unit.

9 10H 00H White Room A unique short reverb with a bit of initial delay. 10 11H 00H Tunnel Simulation of a tunnel space expanding to left and right. 11 13H 00H Basement

CHORUS

No. MSB LSB Effect Type Features

0 00H 00H No Effect Effect turned off.

1 41H 00H Chorus 1 Conventional chorus program that adds natural spaciousness.

2 41H 01H Chorus 2

3 41H 02H Chorus 3

4 41H 08H Chorus 4 Chorus with stereo input. The pan setting speciﬁed for the Part will also apply to the effect sound.

5 42H 00H Celeste 1 A 3-phase LFO adds modulation and spaciousness to the sound.

6 42H 01H Celeste 2

7 42H 02H Celeste 3

8 42H 08H Celeste 4 CELESTE with stereo input. The pan setting speciﬁed for the Part will apply to the effect sound.

9 43H 00H Flanger 1 Adds a jet-airplane effect to the sound. 10 43H 01H Flanger 2 11 43H 08H Flanger 3

A bit of initial delay followed by reverb with a unique resonance.

VARIATION

When the effect type is set to “No Effect” while the Insertion effect is used, no sound is output. If you don't want to use the Variation effect, select “Thru” to pass the signal through

the Variation effect without applying any effect.

No. MSB LSB Effect Type Features

0 00H 00H No Effect Effect turned off.

1 01H 00H Hall 1 Reverb simulating the resonance of a hall.

2 01H 01H Hall 2

3 02H 00H Room 1 Reverb simulating the resonance of a room.

4 02H 01H Room 2

5 02H 02H Room 3

6 03H 00H Stage 1 Reverb approproate for a solo instrument.

7 03H 01H Stage 2

8 04H 00H Plate Reverb simulating a metal plate reverb unit.

9 05H 00H Delay L,C,R A program that creates three delay sounds; L, R, and C (center). 10 06H 00H Delay L,R A program that creates two delay sounds; L and R. Two feedback delays are provided. 11 07H 00H Echo Two delays (L and R) and independent feedback delays for L and R. 12 08H 00H Cross Delay A program that crosses the feedback of two delays. 13 09H 00H EarlyRef 1 An effect that produces only the early reﬂection component of reverb. 14 09H 01H EarlyRef 2 15 0AH 00H Gate Reverb A simulation of gated reverb. 16 0BH 00H Reverse Gate A program that simulates gated reverb played backwords. 17 14H 00H Karaoke 1 A delay with feedback of the same type as used for karaoke reverb. 18 14H 01H Karaoke 2 19 14H 02H Karaoke 3 20 41H 00H Chorus 1 A conventional chorus program, providing natural spaciousness. 21 41H 01H Chorus 2 22 41H 02H Chorus 3 23 41H 08H Chorus 4 Chorus with stereo input. 24 42H 00H Celeste 1 A 3-phase LFO adds modulation and spaciousness to the sound. 25 42H 01H Celeste 2 26 42H 02H Celeste 3 27 42H 08H Celeste 4 28 43H 00H Flanger 1 Adds a jet-airplane effect to the sound. 29 43H 01H Flanger 2 30 43H 08H Flanger 3 31 44H 00H Symphonic A multi-phase version of CELESTE. 32 45H 00H Rotary Speaker A simulation of a rotary speaker. You can use an AC1 (assignable controller) etc. to controll the speed of rotation. 33 46H 00H Tremolo An effect that cyclically modulates the volume. 34 47H 00H Auto Pan A program that cyclically moves the sound image to left and right, front and back. 35 48H 00H Phaser 1 Cyclically changes the phase to add modulation to the sound. 36 48H 08H Phaser 2 Phaser with stereo input. 37 49H 00H Distortion Adds a sharp-edged distortion to the sound. 38 4AH 00H Overdrive Adds mild distortion to the sound. 39 4BH 00H Amp Simulator A simulation of a guitar amp. 40 4CH 00H 3Band EQ(Mono) A mono EQ with adjustable LOW, MID, and HIGH equalizing. 41 4DH 00H 2Band EQ(Stereo) A stereo EQ with adjustable LOW and HIGH. Ideal for drum Parts. 42 4EH 00H Auto Wah(LFO) Cyclically modulates the center frequency of a wah ﬁlter. With an AC1 etc. this can function as a pedal wah. 43 40H 00H Thru Bypass without applying an effect.

●

Effect Parameter List

Parameters marked with a ● in the “Control” column can be controlled from an AC1 (assignable controller 1) etc. However, this is valid only for a Variation effect

(when selected for Insertion).

HALL1,HALL2 ROOM1,ROOM2,ROOM3 STAGE1,STAGE2 PLATE (reverb, variation block)

No. Parameter Display Value See Table Control

1 Reverb Time 0.3 - 30.0s 0 - 69 table#4 2 Diffusion 0 - 10 0 - 10 3 Initial Delay 0.1 - 99.3ms 0 - 63 table#5 4 HPF Cutoff Thru - 8.0kHz 0 - 52 table#3 5 LPF Cutoff 1.0k - Thru 34 - 60 table#3 6 7 8 9

10 Dry/Wet D63>W - D=W - D<W63 1 - 127

11 Rev Delay 0.1 - 99.3ms 0 - 63 table#5 12 Density 0 - 4 0 - 4 13 Er/Rev Balance E63>R - E=R - E<R63 1 - 127 14 15 Feedback Level -63 - +63 1 - 127 16

WHITE ROOM TUNNEL BASEMENT (reverb block)

No. Parameter Display Value See Table Control

1 Reverb Time 0.3 - 30.0s 0 - 69 table#4 2 Diffusion 0 - 10 0 - 10 3 Initial Delay 0.1 - 99.3ms 0 - 63 table#5 4 HPF Cutoff Thru - 8.0kHz 0 - 52 table#3 5 LPF Cutoff 1.0k - Thru 34 - 60 table#3 6 Width 0.5 - 10.2m 0 - 37 table#8 7 Heigt 0.5 - 20.2m 0 - 73 table#8 8 Depth 0.5 - 30.2m 0 - 104 table#8 9 Wall Vary 0 - 30 0 - 30

11 Rev Delay 0.1 - 99.3ms 0 - 63 table#5 12 Density 0 - 4 0 - 4 13 Er/Rev Balance E63>R - E=R - E<R63 1 - 127 14 15 Feedback Level -63 - +63 1 - 127 16

DELAY L,C,R (variation block)

No. Parameter Display Value See Table Control

1 Lch Delay 0.1 - 715.0ms (variation block) 1 - 7150 2 Rch Delay 0.1 - 715.0ms (variation block) 1 - 7150 3 Cch Delay 0.1 - 715.0ms (variation block) 1 - 7150 4 Feedback Delay 0.1 - 715.0ms (variation block) 1 - 7150 5 Feedback Level -63 - +63 1 - 127 6 Cch Level 0 - 127 0 - 127 7 High Damp 0.1 - 1.0 1 - 10 8 9

10 Dry/Wet D63>W - D=W - D<W63 1 - 127

11 12 13 EQ Low Frequency 50Hz - 2.0kHz 8 - 40 table#3 14 EQ Low Gain -12 - +12dB 52 - 76 15 EQ High Frequency 500Hz - 16.0kHz 28 - 58 table#3 16 EQ High Gain -12 - +12dB 52 - 76

DELAY L,R (variation block)

No. Parameter Display Value See Table Control

1 Lch Delay 0.1 - 715.0ms (variation block) 1 - 7150 2 Rch Delay 0.1 - 715.0ms (variation block) 1 - 7150 3 Feedback Delay 1 0.1 - 715.0ms (variation block) 1 - 7150 4 Feedback Delay 2 0.1 - 715.0ms (variation block) 1 - 7150 5 Feedback Level -63 - +63 1 - 127 6 High Damp 0.1 - 1.0 1 - 10 7 8 9

10 Dry/Wet D63>W - D=W - D<W63 1 - 127

11 12 13 EQ Low Frequency 50Hz - 2.0kHz 8 - 40 table#3 14 EQ Low Gain -12 - +12dB 52 - 76 15 EQ High Frequency 500Hz - 16.0kHz 28 - 58 table#3 16 EQ High Gain -12 - +12dB 52 - 76

ECHO (variation block)

No. Parameter Display Value See Table Control

1 Lch Delay1 0.1 - 355.0ms (variation block) 1 - 3550 2 Lch Feedback Level -63 - +63 1 - 127 3 Rch Delay1 0.1 - 355.0ms (variation block) 1 - 3550 4 Rch Feedback Level -63 - +63 1 - 127 5 High Damp 0.1 - 1.0 1 - 10 6 Lch Delay2 0.1 - 355.0ms (variation block) 1 - 3550 7 Rch Delay2 0.1 - 355.0ms (variation block) 1 - 3550 8 Delay2 Level 0 - 127 0 - 127 9

10 Dry/Wet D63>W - D=W - D<W63 1 - 127

11 12 13 EQ Low Frequency 50Hz - 2.0kHz 8 - 40 table#3 14 EQ Low Gain -12 - +12dB 52 - 76 15 EQ High Frequency 500Hz - 16.0kHz 28 - 58 table#3 16 EQ High Gain -12 - +12dB 52 - 76

CROSS DELAY (variation block)

No. Parameter Display Value See Tab le Control

1 L->R Delay 0.1 - 355.0ms (variation block) 1 - 3550 2 R->L Delay 0.1 - 355.0ms (variation block) 1 - 3550 3 Feedback Level -63 - +63 1 - 127 4 Input Select L, R, L&R 0 - 2 5 High Damp 0.1 - 1.0 1 - 10 6 7 8 9

10 Dry/Wet D63>W - D=W - D<W63 1 - 127

11 12 13 EQ Low Frequency 50Hz - 2.0kHz 8 - 40 table#3 14 EQ Low Gain -12 - +12dB 52 - 76 15 EQ High Frequency 500Hz - 16.0kHz 28 - 58 table#3 16 EQ High Gain -12 - +12dB 52 - 76

EARLY REF1,EARLY REF2(variation block)

No. Parameter Display Value See Tab le Control

1 Type S-H, L-H, Rdm, Rvs, Plt, Spr 0 - 5 2 Room Size 0.1 - 7.0 0 - 44 table#6 3 Diffusion 0 - 10 0 - 10 4 Initial Delay 0.1 - 99.3ms 0 - 63 table#5 5 Feedback Level -63 - +63 1 - 127 6 HPF Cutoff Thru - 8.0kHz 0 - 52 table#3 7 LPF Cutoff 1.0k - Thru 34 - 60 table#3 8 9

10 Dry/Wet D63>W - D=W - D<W63 1 - 127

11 Liveness 0 - 10 0 - 10 12 Density 0 - 3 0 - 3 13 High Damp 0.1 - 1.0 1 - 10 14 15 16

GATE REVERB REVERSE GATE (variation block)

No. Parameter Display Value See Tab le Control

1 Type TypeA,TypeB 0 - 1 2 Room Size 0.1 - 7.0 0 - 44 table#6 3 Diffusion 0 - 10 0 - 10 4 Initial Delay 0.1 - 99.3ms 0 - 63 table#5 5 Feedback Level -63 - +63 1 - 127 6 HPF Cutoff Thru - 8.0kHz 0 - 52 table#3 7 LPF Cutoff 1.0k - Thru 34 - 60 table#3 8 9

10 Dry/Wet D63>W - D=W - D<W63 1 - 127

11 Liveness 0 - 10 0 - 10 12 Density 0 - 3 0 - 3 13 High Damp 0.1 - 1.0 1 - 10 14 15 16

●

KARAOKE1,2,3 (variation block)

No. Parameter Display Value See Tab le Control

1 Delay Time 0.1 - 400ms 0 - 127 table#7 2 Feedback Level -63 - +63 1 - 127 3 HPF Cutoff Thru - 8.0kHz 0 - 52 table#3 4 LPF Cutoff 1.0k - Thru 34 - 60 table#3 5 6 7 8 9

10 Dry/Wet D63>W - D=W - D<W63 1 - 127

11 12 13 14 15 16

CHORUS1,2,3,4 CELESTE1,2,3,4 (chorus, variation block)

No. Parameter Display Value See Tab le Control

1 LFO Frequency 0.00Hz - 39.7Hz 0 - 127 table#1 2 LFO Depth 0 - 127 0 - 127 3 Feedback Level -63 - +63 1 - 127 4 Delay Offset 0.0 - 50 0 - 127 table#2 5 6 EQ Low Frequency 50Hz - 2.0kHz 8 - 40 table#3 7 EQ Low Gain -12 - +12dB 52 - 76 8 EQ High Frequency 500Hz - 16.0kHz 28 - 58 table#3 9 EQ High Gain -12 - +12dB 52 - 76

10 Dry/Wet D63>W - D=W - D<W63 1 - 127

11 12 13 14 15 Input Mode mono/stereo 0 - 1 16

ROTARY SPEAKER (variation block)

No. Parameter Display Value See Tab le Control

1 LFO Frequency 0.00Hz - 39.7Hz 0 - 127 table#1 2 LFO Depth 0 - 127 0 - 127 3 4 5 6 EQ Low Frequency 50Hz - 2.0kHz 8 - 40 table#3 7 EQ Low Gain -12 - +12dB 52 - 76 8 EQ High Frequency 500Hz - 16.0kHz 28 - 58 table#3 9 EQ High Gain -12 - +12dB 52 - 76

10 Dry/Wet D63>W - D=W - D<W63 1 - 127

11 12 13 14 15 16

TREMOLO (variation block)

No. Parameter Display Value See Tab le Control

1 LFO Frequency 0.00Hz - 39.7Hz 0 - 127 table#1 2 AM Depth 0 - 127 0 - 127 3 PM Depth 0 - 127 0 - 127 4 5 6 EQ Low Frequency 50Hz - 2.0kHz 8 - 40 table#3 7 EQ Low Gain -12 - +12dB 52 - 76 8 EQ High Frequency 500Hz - 16.0kHz 28 - 58 table#3 9 EQ High Gain -12 - +12dB 52 - 76

11 12 13 14

LFO Phase Difference -180 - +180deg 4 - 124 15 Input Mode mono/stereo 0 - 1 16

resolution=3deg.

FLANGER1,2,3 (chorus, variation block)

No. Parameter Display Value See Tab le Control

1 LFO Frequency 0.00Hz - 39.7Hz 0 - 127 table#1 2 LFO Depth 0 - 127 0 - 127 3 Feedback Level -63 - +63 1 - 127 4 Delay Offset 0.0 - 6.3 0 - 63 table#2 5 6 EQ Low Frequency 50Hz - 2.0kHz 8 - 40 table#3 7 EQ Low Gain -12 - +12dB 52 - 76 8 EQ High Frequency 500Hz - 16.0kHz 28 - 58 table#3 9 EQ High Gain -12 - +12dB 52 - 76

10 Dry/Wet D63>W - D=W - D<W63 1 - 127

11 12 13 14

LFO Phase Difference -180 - +180deg 4 - 124 15 16

SYMPHONIC (variation block)

No. Parameter Display Value See Tab le Control

1 LFO Frequency 0.00Hz - 39.7Hz 0 - 127 table#1 2 LFO Depth 0 - 127 0 - 127 3 Delay Offset 0.0 - 50 0 - 127 table#2 4 5 6 EQ Low Frequency 50Hz - 2.0kHz 8 - 40 table#3 7 EQ Low Gain -12 - +12dB 52 - 76 8 EQ High Frequency 500Hz - 16.0kHz 28 - 58 table#3 9 EQ High Gain -12 - +12dB 52 - 76

10 Dry/Wet D63>W - D=W - D<W63 1 - 127

11 12 13 14 15 16

resolution=3deg.

AUTO PAN (variation block)

No. Parameter Display Value See Tab le Control

1 LFO Frequency 0.00Hz - 39.7Hz 0 - 127 table#1 2 L/R Depth 0 - 127 0 - 127 3 F/R Depth 0 - 127 0 - 127 4 PAN Direction

5 6 EQ Low Frequency 50Hz - 2.0kHz 8 - 40 table#3 7 EQ Low Gain -12 - +12dB 52 - 76 8 EQ High Frequency 500Hz - 16.0kHz 28 - 58 table#3 9 EQ High Gain -12 - +12dB 52 - 76

11 12 13 14 15 16

PHASER 1 (variation block)

No. Parameter Display Value See Tab le Control

1 LFO Frequency 0.00Hz - 39.7Hz 0 - 127 table#1 2 LFO Depth 0 - 127 0 - 127 3 Phase Shift Offset 0 - 127 0 - 127 4 Feedback Level -63 - +63 1 - 127 5 6 EQ Low Frequency 50Hz - 2.0kHz 8 - 40 table#3 7 EQ Low Gain -12 - +12dB 52 - 76 8 EQ High Frequency 500Hz - 16.0kHz 28 - 58 table#3 9 EQ High Gain -12 - +12dB 52 - 76

10 Dry/Wet D63>W - D=W - D<W63 1 - 127

11 Stage 6 - 10 6 - 10 12 13 14 15 16

L<->R, L->R, L<-R, Lturn, Rturn, L/R

0 - 5

●

PHASER 2 (variation block)

No. Parameter Display Value See Tab le Control

10 Dry/Wet D63>W - D=W - D<W63 1 - 127

11 Stage 3 - 5 3 - 5 12 13

LFO Phase Difference -180deg - +180deg 4 - 124 14 15 16

DISTORTION OVERDRIVE (variation block)

No. Parameter Display Value See Tab le Control

1 Drive 0 - 127 0 - 127 2 EQ Low Frequency 50Hz - 2.0kHz 8 - 40 table#3 3 EQ Low Gain -12 - +12dB 52 - 76 4 LPF Cutoff 1.0k - Thru 34 - 60 table#3 5 Output Level 0 - 127 0 - 127 6 7 EQ Mid Frequency 500Hz - 10.0kHz 28 - 54 table#3 8 EQ Mid Gain -12 - +12dB 52 - 76 9 EQ Mid Width 1.0 - 12.0 10 - 120

10 Dry/Wet D63>W - D=W - D<W63 1 - 127

11 Edge(Clip Curve) 0 - 127 0 - 127 mild - sharp 12 13 14 15 16

resolution=3deg.

2BAND EQ(STEREO) (variation block)

No. Parameter Display Value See Tab le Control

1 EQ Low Frequency 50Hz - 2.0kHz 8 - 40 table#3 2 EQ Low Gain -12 - +12dB 52 - 76 3 EQ High Frequency 500Hz - 16.0kHz 28 - 58 table#3 4 EQ High Gain -12 - +12dB 52 - 76 5 6 7 8 9

11 12 13 14 15 16

AUTO WAH (variation block)

No. Parameter Display Value See Tab le Control

1 LFO Frequency 0.00Hz - 39.7Hz 0 - 127 table#1 2 LFO Depth 0 - 127 0 - 127 3

Cutoff Frequency Offset 0 - 127 0 - 127 4 Resonance 1.0 - 12.0 10 - 120 5 6 EQ Low Frequency 50Hz - 2.0kHz 8 - 40 table#3 7 EQ Low Gain -12 - +12dB 52 - 76 8 EQ High Frequency 500Hz - 16.0kHz 28 - 58 table#3 9 EQ High Gain -12 - +12dB 52 - 76

10 Dry/Wet D63>W - D=W - D<W63 1 - 127

11 12 13 14 15 16

AMP SIMULATOR (variation block)

No. Parameter Display Value See Tab le Control

1 Drive 0 - 127 0 - 127 2 AMP Type Off,Stack,Combo,Tube 0 - 3 3 LPF Cutoff 1.0k - Thru 34 - 60 table#3 4 Output Level 0 - 127 0 - 127 5 6 7 8 9

10 Dry/Wet D63>W - D=W - D<W63 1 - 127

11 Edge(Clip Curve) 0 - 127 0 - 127 mild - sharp 12 13 14 15 16

3BAND EQ(MONO) (variation block)

No. Parameter Display Value See Tab le Control

1 EQ Low Gain -12 - +12dB 52 - 76 2 EQ Mid Frequency 500Hz - 10.0kHz 28 - 54 table#3 3 EQ Mid Gain -12 - +12dB 52 - 76 4 EQ Mid Width 1.0 - 12.0 10 - 120 5 EQ High Gain -12 - +12dB 52 - 76 6 EQ Low Frequency 50Hz - 2.0kHz 8 - 40 table#3 7 EQ High Frequency 500Hz - 16.0kHz 28 - 58 table#3 8 9

11 12 13 14 15 16

Effect Data Assign Table

table#1 LFO Frequency

Data Value Data Value

0 0.00 64 2.69 1 0.04 65 2.78 2 0.08 66 2.86 3 0.13 67 2.94 4 0.17 68 3.03 5 0.21 69 3.11 6 0.25 70 3.20 7 0.29 71 3.28 8 0.34 72 3.37

9 0.38 73 3.45 10 0.42 74 3.53 11 0.46 75 3.62 12 0.51 76 3.70 13 0.55 77 3.87 14 0.59 78 4.04 15 0.63 79 4.21 16 0.67 80 4.37 17 0.72 81 4.54 18 0.76 82 4.71 19 0.80 83 4.88 20 0.84 84 5.05 21 0.88 85 5.22 22 0.93 86 5.38 23 0.97 87 5.55 24 1.01 88 5.72 25 1.05 89 6.06 26 1.09 90 6.39 27 1.14 91 6.73 28 1.18 92 7.07 29 1.22 93 7.40 30 1.26 94 7.74 31 1.30 95 8.08 32 1.35 96 8.41 33 1.39 97 8.75 34 1.43 98 9.08 35 1.47 99 9.42 36 1.51 100 9.76 37 1.56 101 10.1 38 1.60 102 10.8 39 1.64 103 11.4 40 1.68 104 12.1 41 1.72 105 12.8 42 1.77 106 13.5 43 1.81 107 14.1 44 1.85 108 14.8 45 1.89 109 15.5 46 1.94 110 16.2 47 1.98 111 16.8 48 2.02 112 17.5 49 2.06 113 18.2 50 2.10 114 19.5 51 2.15 115 20.9 52 2.19 116 22.2 53 2.23 117 23.6 54 2.27 118 24.9 55 2.31 119 26.2 56 2.36 120 27.6 57 2.40 121 28.9 58 2.44 122 30.3 59 2.48 123 31.6 60 2.52 124 33.0 61 2.57 125 34.3 62 2.61 126 37.0 63 2.65 127 39.7

table#2 Modulation Delay Offset

Data Value Data Value

0 0.0 64 6.4 1 0.1 65 6.5 2 0.2 66 6.6 3 0.3 67 6.7 4 0.4 68 6.8 5 0.5 69 6.9 6 0.6 70 7.0 7 0.7 71 7.1 8 0.8 72 7.2

9 0.9 73 7.3 10 1.0 74 7.4 11 1.1 75 7.5 12 1.2 76 7.6 13 1.3 77 7.7 14 1.4 78 7.8 15 1.5 79 7.9 16 1.6 80 8.0 17 1.7 81 8.1 18 1.8 82 8.2 19 1.9 83 8.3 20 2.0 84 8.4 21 2.1 85 8.5 22 2.2 86 8.6 23 2.3 87 8.7 24 2.4 88 8.8 25 2.5 89 8.9 26 2.6 90 9.0 27 2.7 91 9.1 28 2.8 92 9.2 29 2.9 93 9.3 30 3.0 94 9.4 31 3.1 95 9.5 32 3.2 96 9.6 33 3.3 97 9.7 34 3.4 98 9.8 35 3.5 99 9.9 36 3.6 100 10.0 37 3.7 101 11.1 38 3.8 102 12.2 39 3.9 103 13.3 40 4.0 104 14.4 41 4.1 105 15.5 42 4.2 106 17.1 43 4.3 107 18.6 44 4.4 108 20.2 45 4.5 109 21.8 46 4.6 110 23.3 47 4.7 111 24.9 48 4.8 112 26.5 49 4.9 113 28.0 50 5.0 114 29.6 51 5.1 115 31.2 52 5.2 116 32.8 53 5.3 117 34.3 54 5.4 118 35.9 55 5.5 119 37.5 56 5.6 120 39.0 57 5.7 121 40.6 58 5.8 122 42.2 59 5.9 123 43.7 60 6.0 124 45.3 61 6.1 125 46.9 62 6.2 126 48.4 63 6.3 127 50.0

table#3 EQ Frequency

Data Value

0 THRU(20) 122 225 328 432 536 640 745 850

956 10 63 11 70 12 80 13 90 14 100 15 110 16 125 17 140 18 160 19 180 20 200 21 225 22 250 23 280 24 315 25 355 26 400 27 450 28 500 29 560 30 630 31 700 32 800 33 900 34 1.0k 35 1.1k 36 1.2k 37 1.4k 38 1.6k 39 1.8k 40 2.0k 41 2.2k 42 2.5k 43 2.8k 44 3.2k 45 3.6k 46 4.0k 47 4.5k 48 5.0k 49 5.6k 50 6.3k 51 7.0k 52 8.0k 53 9.0k 54 10.0k 55 11.0k 56 12.0k 57 14.0k 58 16.0k 59 18.0k 60 THRU(20.0k)

table#4 Reverb time

Data Value Data Value

0 0.3 64 17.0 1 0.4 65 18.0 2 0.5 66 19.0 3 0.6 67 20.0 4 0.7 68 25.0 5 0.8 69 30.0 6 0.9 7 1.0 8 1.1

9 1.2 10 1.3 11 1.4 12 1.5 13 1.6 14 1.7 15 1.8 16 1.9 17 2.0 18 2.1 19 2.2 20 2.3 21 2.4 22 2.5 23 2.6 24 2.7 25 2.8 26 2.9 27 3.0 28 3.1 29 3.2 30 3.3 31 3.4 32 3.5 33 3.6 34 3.7 35 3.8 36 3.9 37 4.0 38 4.1 39 4.2 40 4.3 41 4.4 42 4.5 43 4.6 44 4.7 45 4.8 46 4.9 47 5.0 48 5.5 49 6.0 50 6.5 51 7.0 52 7.5 53 8.0 54 8.5 55 9.0 56 9.5 57 10.0 58 11.0 59 12.0 60 13.0 61 14.0 62 15.0 63 16.0

table#5 Delay Time(200.0ms)

Data Value Data Value

0 0.1 64 100.8 1 1.7 65 102.4 2 3.2 66 104.0 3 4.8 67 105.6 4 6.4 68 107.1 5 8.0 69 108.7 6 9.5 70 110.3 7 11.1 71 111.9 8 12.7 72 113.4

9 14.3 73 115.0 10 15.8 74 116.6 11 17.4 75 118.2 12 19.0 76 119.7 13 20.6 77 121.3 14 22.1 78 122.9 15 23.7 79 124.4 16 25.3 80 126.0 17 26.9 81 127.6 18 28.4 82 129.2 19 30.0 83 130.7 20 31.6 84 132.3 21 33.2 85 133.9 22 34.7 86 135.5 23 36.3 87 137.0 24 37.9 88 138.6 25 39.5 89 140.2 26 41.0 90 141.8 27 42.6 91 143.3 28 44.2 92 144.9 29 45.7 93 146.5 30 47.3 94 148.1 31 48.9 95 149.6 32 50.5 96 151.2 33 52.0 97 152.8 34 53.6 98 154.4 35 55.2 99 155.9 36 56.8 100 157.5 37 58.3 101 159.1 38 59.9 102 160.6 39 61.5 103 162.2 40 63.1 104 163.8 41 64.6 105 165.4 42 66.2 106 166.9 43 67.8 107 168.5 44 69.4 108 170.1 45 70.9 109 171.7 46 72.5 110 173.2 47 74.1 111 174.8 48 75.7 112 176.4 49 77.2 113 178.0 50 78.8 114 179.5 51 80.4 115 181.1 52 81.9 116 182.7 53 83.5 117 184.3 54 85.1 118 185.8 55 86.7 119 187.4 56 88.2 120 189.0 57 89.8 121 190.6 58 91.4 122 192.1 59 93.0 123 193.7 60 94.5 124 195.3 61 96.1 125 196.9 62 97.7 126 198.4 63 99.3 127 200.0

table#6 Room Size

Data Value

0 0.1 1 0.3 2 0.4 3 0.6 4 0.7 5 0.9 6 1.0 7 1.2 8 1.4

9 1.5 10 1.7 11 1.8 12 2.0 13 2.1 14 2.3 15 2.5 16 2.6 17 2.8 18 2.9 19 3.1 20 3.2 21 3.4 22 3.5 23 3.7 24 3.9 25 4.0 26 4.2 27 4.3 28 4.5 29 4.6 30 4.8 31 5.0 32 5.1 33 5.3 34 5.4 35 5.6 36 5.7 37 5.9 38 6.1 39 6.2 40 6.4 41 6.5 42 6.7 43 6.8 44 7.0

table#7 Delay Time(400.0ms)

Data Value Data Value

0 0.1 64 201.6 1 3.2 65 204.8 2 6.4 66 207.9 3 9.5 67 211.1 4 12.7 68 214.2 5 15.8 69 217.4 6 19.0 70 220.5 7 22.1 71 223.7 8 25.3 72 226.8

9 28.4 73 230.0 10 31.6 74 233.1 11 34.7 75 236.3 12 37.9 76 239.4 13 41.0 77 242.6 14 44.2 78 245.7 15 47.3 79 248.9 16 50.5 80 252.0 17 53.6 81 255.2 18 56.8 82 258.3 19 59.9 83 261.5 20 63.1 84 264.6 21 66.2 85 267.7 22 69.4 86 270.9 23 72.5 87 274.0 24 75.7 88 277.2 25 78.8 89 280.3 26 82.0 90 283.5 27 85.1 91 286.6 28 88.3 92 289.8 29 91.4 93 292.9 30 94.6 94 296.1 31 97.7 95 299.2 32 100.9 96 302.4 33 104.0 97 305.5 34 107.2 98 308.7 35 110.3 99 311.8 36 113.5 100 315.0 37 116.6 101 318.1 38 119.8 102 321.3 39 122.9 103 324.4 40 126.1 104 327.6 41 129.2 105 330.7 42 132.4 106 333.9 43 135.5 107 337.0 44 138.6 108 340.2 45 141.8 109 343.3 46 144.9 110 346.5 47 148.1 111 349.6 48 151.2 112 352.8 49 154.4 113 355.9 50 157.5 114 359.1 51 160.7 115 362.2 52 163.8 116 365.4 53 167.0 117 368.5 54 170.1 118 371.7 55 173.3 119 374.8 56 176.4 120 378.0 57 179.6 121 381.1 58 182.7 122 384.3 59 185.9 123 387.4 60 189.0 124 390.6 61 192.2 125 393.7 62 195.3 126 396.9 63 198.5 127 400.0

table#8 Reverb Width;Depth;Height

Data Value Data Value

0 0.5 64 17.6 1 0.8 65 17.9 2 1.0 66 18.2 3 1.3 67 18.5 4 1.5 68 18.8 5 1.8 69 19.1 6 2.0 70 19.4 7 2.3 71 19.7 8 2.6 72 20.0

9 2.8 73 20.2 10 3.1 74 20.5 11 3.3 75 20.8 12 3.6 76 21.1 13 3.9 77 21.4 14 4.1 78 21.7 15 4.4 79 22.0 16 4.6 80 22.4 17 4.9 81 22.7 18 5.2 82 23.0 19 5.4 83 23.3 20 5.7 84 23.6 21 5.9 85 23.9 22 6.2 86 24.2 23 6.5 87 24.5 24 6.7 88 24.9 25 7.0 89 25.2 26 7.2 90 25.5 27 7.5 91 25.8 28 7.8 92 26.1 29 8.0 93 26.5 30 8.3 94 26.8 31 8.6 95 27.1 32 8.8 96 27.5 33 9.1 97 27.8 34 9.4 98 28.1 35 9.6 99 28.5 36 9.9 100 28.8 37 10.2 101 29.2 38 10.4 102 29.5 39 10.7 103 29.9 40 11.0 104 30.2 41 11.2 42 11.5 43 11.8 44 12.1 45 12.3 46 12.6 47 12.9 48 13.1 49 13.4 50 13.7 51 14.0 52 14.2 53 14.5 54 14.8 55 15.1 56 15.4 57 15.6 58 15.9 59 16.2 60 16.5 61 16.8 62 17.1 63 17.3

MIDI Data Format

1. Channel messages

1.1 Note on/note off

These messages convey keyboard performance data. Range of note numbers received = 0 (C-2)...60 (C3)...127 (G8)

Velocity range = 1...127 (Velocity is received only for note-on) When the Multi Part parameter "Rcv NOTE MESSAGE" = OFF, that part will not receive

these messages. For a drum part*, key-off is not received if the DrumSetup parameter Rcv NOTE OFF = OFF. For a drum part, key-on is not received if the DrumSetup parameter Rcv NOTE ON = OFF.

* Drum Part indicates that the Multi Part parameter PART MODE is "set to DRUM,

DRUMS1, DRUMS2."

1.2 Control changes

These messages control volume or pan etc. Their functions are differentiated by the control number (Ctrl#).

If the Multi Part parameter Rcv CONTROL CHANGE = OFF, that part will not receive control changes.

1.2.1 Bank Select

This message selects the voice bank.

Control# Parameter Data Range 0 Bank Select MSB 0, 63, 64, 126, 127

32 Bank Select LSB 0...127

The Bank Select data will be processed only after a Program Change is received, and then voice bank will change at that time. If you wish to change the voice bank as well as the voice, you must transmit Bank Select and Program Change messages as a set, in the order of Bank Select MSB, LSB, and Program Change.

Not received when Receive Bank Select in Native System Parameters is set to off.

1.2.2 Modulation

This message is used primarily to control the depth of vibrato, but the depth of the following 7 types of effect can be controlled.

The effect of this message can be changed by the following parameters.

• Multi Part Parameter

1. MW PITCH CONTROL

2. MW FILTER CONTROL

3. MW AMPLITUDE CONTROL

4. MW LFO PMOD DEPTH

5. MW LFO FMOD DEPTH

6. MW LFO AMOD DEPTH

• Effect1 Parameter

7. MW VARIATION CONTROL DEPTH (Valid when Variation Effect is assigned to a part as Insertion)

Control# Parameter Data Range 1 Modulation 0...127

If the Multi Part parameter Rcv MODULATION = OFF, that part will not receive Modulation. If the receive channel is a drum part, effects 5 and 6 will not apply.

1.2.3 Portamento Time

This message controls the degree of Portamento (refer to 1.2.9).

Control# Parameter Data Range 5 Portamento Time 0...127

When Portamento (control number 065) is ON, this regulates the speed of the pitch

change.

A value of 0 is the shortest portamento time, and 127 is the longest portamento time.

If the receive channel is a drum part, Portamento Time is not received.

1.2.4 Data Entry

This message sets the value of the parameter which was specified by RPN MSB/LSB (see

1.2.22) and NRPN MSB/LSB (see 1.2.21).

Control# Parameter Data Range 6 Data Entry MSB 0...127 38 Data Entry LSB 0...127

1.2.5 Main Volume

This message controls the volume of each part. This is used to adjust the volume balance between parts.

Control# Parameter Data Range 7 Main Volume 0...127

When the Multi Part parameter Rcv VOLUME = OFF, that part will not receive Main Volume. With a value of 0 there will be no sound, and a value of 127 will be the maximum volume.

1.2.6 Panpot

This message control the panning (stereo location) of each part.

Control# Parameter Data Range 10 Pan 0...64...127

When the Multi Part parameter Rcv PAN = OFF, that part will not receive Panpot. 0 is left, 64 is center, and 127 is right.

(Normal voice, Native voice, SFX voice, SFX kit, Drum kit)

1.2.7 Expression

This message controls expression (dynamics within a musical line) for each part. It is used to create volume changes during a song.

Control# Parameter Data Range 11 Expression 0...127

If the Multi Part parameter Rcv EXPRESSION = OFF, that part will not receive Expression.

1.2.8 Hold1

This message controls sustain pedal on/off.

Control# Parameter Data Range 64 Hold1 0...63,64...127

When this is ON, currently-sounding notes will continue to sound even if note-off messages are received. If the Multi Part parameter Rcv HOLD1 = OFF, that part will not receive Hold1.

1.2.9 Portamento

This message controls portamento on/off.

Control# Parameter Data Range 65 Portamento 0...63,64...127

When this is ON, the pitch will change smoothly between notes. The time over which the pitch changes is adjusted by Portamento Time (see 1.2.3). Also, when the Multi Part parameter MONO/POLY MODE = MONO, the tone will also change smoothly (legato) if Portamento = ON. If any of the following Multi Part parameter settings apply, that part will not receive Portamento.

• Rcv PORTAMENTO = OFF

• PART MODE=DRUM, DRUMS1, 2

1.2.10 Sostenuto

This message controls sostenuto pedal on/off.

Control# Parameter Data Range 66 Sostenuto 0...63,64...127

If sostenuto is turned on while a note is sounding, that note will be sustained until sostenuto is turned OFF. Sostenuto for the specified part is not received when Rcv SOSTENUTO of the part in Multi Part Parameters is set to off.

1.2.11 Soft Pedal

This message controls soft pedal on/off.

Control# Parameter Data Range 67 Soft Pedal 0...63,64...127

The sound will become mellower when Soft Pedal is ON. If any of the following Multi Part parameter settings apply, that part will not receive the Soft Pedal.

• Rcv SOFT PEDAL=OFF

• PART MODE=DRUMÅA DRUMS1ÅA2

1.2.12 Harmonic Content

This message adjusts the resonance of the filter that is specified for the sound.

Control# Parameter Data Range 71 Harmonic Content 0...64...127

Since this is a relative change parameter, it specifies a boost or cut relative to 64. Higher values will produce a more distinctive sound. For some sounds, the effective range may be less than the possible range of settings.

1.2.13 Release Time

This message adjusts the EG release time that was specified by the sound data.

Control# Parameter Data Range 72 Release Time 0...64...127

Since this is a relative change parameter, it specifies an increase or decrease relative to

64. Increasing this value will lengthen the release that follows a note-off.

1.2.14 Attack Time

This message adjusts the EG attack time that was specified by the sound data.

Control# Parameter Data Range 73 Attack Time 0...64...127

Since this a relative change parameter, it specifies an increase or decrease relative to 64. Increasing this value will make the attack more gradual, and decreasing this value will make the attack sharper.

1.2.15 Brightness

This message adjusts the cutoff frequency of the low pass filter specified by the sound data.

Control# Parameter Data Range 74 Brightness 0...64...127

Since this is a relative change parameter, it specifies an increase or decrease relative to

64. Lower values will produce a more mellow sound. For some sounds, the effective range may be less than the possible range of settings.

(OFF, ON)

(-64...0...+63)

1.2.16 Portamento Control

This message specifies the portamento source key number (the key number at which portamento will begin). Data of 0...127 specifies the portamento source key. When Portamento Control is received, the currently-sounding pitch will change at a Portamento Time of 0 to the key of the next-received note-on of the same channel.

Control# Parameter Data Range 84 Portamento Control 0...127

(C-2...G8)

This is received even if Rcv PORTAMENTO = OFF.

1.2.17 Effect1 Depth (Reverb Send Level)

This message specifies the send level for the reverb effect.

Control# Parameter Data Range 91 Effect1 Depth 0...127

Increasing this value will produce a richer reverb. The effect of the value will depend on the state of the reverb effect.

1.2.18 Effect3 Depth (Chorus Send Level)

This message specifies the send level for the chorus effect.

Control# Parameter Data Range 93 Effect3 Depth 0...127

Raising this value will increase the modulation or spaciousness. The effect of the value will depend on the state of the chorus effect.

1.2.19 Effect4 Depth (Variation Effect Send Level)

This message specifies the send level for the variation effect.

Control# Parameter Data Range 94 Effect4 Depth 0...127

However, this is not received if the Variation Effect parameter Variation Connection = 0 (Insertion).

1.2.20 Data Increment/Decrement (for RPN)

This message increases or decreases the parameter value specified for RPN (see 1.2.22), by increments of 1.

Control# Parameter Data Range 96 RPN Increment -97 RPN Decrement --

The data byte is ignored.

1.2.21 NRPN (Non-registered parameter number)

This message is used to specify a sound parameter (such as vibrato, filter, EG, drum setup etc.) as an offset value. Use NRPN MSB and NRPN LSB to specify the parameter that you wish to modify, and then use Data Entry (see 1.2.4) to set the value for the specified parameter.

Control# Parameter Data Range 98 NRPN LSB 0...127 99 NRPN MSB 0...127

If the Multi Part parameter Rcv NRPN = OFF, that part will not receive NRPN. The following NRPN messages can be received.

NRPN MSB LSB

01H 08H mm --

01H 09H mm -- Vibrato depth

01H 0AH mm -- *3Vibrato delay

01H 20H mm -- Low pass filter cutoff frequency

01H 21H mm -- Low pass filter resonance

01H 63H mm -- EG attack time

01H 64H mm -- EG decay time

01H 66H mm -- EG release time

14H rr mm -- Drum low pass filter cutoff frequency

15H rr mm -- Drum low pass filter resonance

16H rr mm -- Drum EG attack rate

17H rr mm -- Drum EG decay rate

18H rr mm -- Drum instrument pitch coarse

Data Entry

MSB LSB Parameter name and value range

Vibrato rate

mm : 00H - 40H - 7FH (-64...0...+63)

rr : drum instrument note number mm : 00H - 40H - 7FH (-64...0...+63)

rr : drum instrument note number mm : 00H - 40H - 7FH (-64...0...+63) The effect will apply both to Decay 1 and 2.

rr : drum instrument note number mm : 00H - 40H - 7FH (-64...0...+63)

NRPN MSB LSB

19H rr mm -- Drum instrument pitch fine

1AH rr mm -- Drum instrument level

1CH rr mm -- Drum instrument panpot

1DH rr mm -- Drum instrument reverb send level

1EH rr mm -- Drum instrument chorus send level

1FH rr mm -- Drum instrument variation send level

MSB 14H - 1FH (for drums) is received when Multi Part parameter PART MODE = DRUMS1, 2.

*1 Refer to 1.2.4 *2 '--' indicates that the setting value is ignored. *3 Adjusts the time after the note is played until vibrato begins to take effect. The effect

will begin more quickly for higher values, and more slowly for higher values.

Data Entry

MSB LSB Parameter name and value range

rr : drum instrument note number mm : 00H - 40H - 7FH (-64...0...+63)

rr : drum instrument note number mm : 00H - 7FH (0...maximum)

rr : drum instrument note number mm : 00H, 01H-40H-7FH (RND, L63...C...R63)

rr : drum instrument note number mm : 00H - 7FH (0...maximum)

rr : drum instrument note number mm : 00H - 7FH (0...maximum) (when Variation Connection = SYSTEM) mm : 00H, 01H-7FH (OFF, ON) (when Variation Connection = INSERTION)

1.2.22 RPN (Registered parameter number)

This message is used to specify part parameters such as Pitch Bend Sensitivity or Tuning etc. as an offset value. Use RPN MSB and RPN LSB to specify the parameter that you wish to modify, and then use Data Entry (see 1.2.4) to set the value of the specified parameter.

Control# Parameter Data Range 100 RPN LSB 0...127 101 RPN MSB 0...127

If the Multi Part parameter Rcv RPN = OFF, that part will not receive this message. The following RPN messages can be received.

NRPN MSB LSB

00H 00H mm --

00H 01H mm ll Fine tuning

00H 02H mm -- Coarse tuning

7FH 7FH -- -- RPN Null

*1 Refer to 1.2.4 *2 '--' indicates that the setting value is ignored.

Data Entry

MSB LSB Parameter name and value range

Pitch bend sensitivity

mm:00-18H (0...+24 semitones) Specify up to 2 octaves in semitone steps\

mm ll: 00H 00H -100 cents : : mm ll: 40H 00H 0 cents : : mm ll: 7FH 7FH +100 cents

[Note] mm ll: 00H 7FH (= -87.5) cents is followed by 01H 00H (= -87.4) cents.

mm:28H - 40H - 58H (-24...0...+24 semitones)

This sets RPN and NRPN numbers to an unset state. Internal data is not affected.

1.2.23 Assignable controller

By assigning a control change number of 0...95 to a part, the specified effect can be controlled. This device allows two control change numbers (AC1 and AC2) to be specified for each part. The following parameters specify the effect of AC1 and AC2.

• Multi Part Parameter

1. AC1, AC2 PITCH CONTROL

2. AC1, AC2 FILTER CONTROL

3. AC1, AC2 AMPLITUDE CONTROL

4. AC1, AC2 LFO PMOD DEPTH

5. AC1, AC2 LFO FMOD DEPTH

6. AC1, AC2 LFO AMOD DEPTH

• Effect1 Parameter

7. AC1, AC2 VARIATION CONTROL DEPTH

(Valid if Variation Effect is assigned to a part as Insertion) The AC1 control change number is specified by the Multi Part parameter AC1 CONTROLLER NUMBER, and the AC2 control change number is specified by the Multi Part parameter AC2 CONTROLLER NUMBER.

1.3 Channel mode messages

These messages specify the basic operation of a part.

1.3.1 All Sound Off

This message silences all currently-sounding notes on the corresponding channel. However, the settings of channel messages such as Hold 1 and Sostenuto will be maintained.

Control# Parameter Data Range 120 All Sound Off 0

1.3.2 Reset All Controllers

This message resets the following controllers to their default values.

Controller Value

Pitch bend change ±0 (center) Channel Aftertouch 0 (off) Polyphonic Aftertouch 0 (off) Modulation 0 (off) Expression 127 (maximum) Hold 0 (off) Portamento 0 (off) Sostenuto 0 (off) Soft pedal 0 (off) Portamento control RPN Number unset, internal data is not affected. NRPN Number unset, internal data is not affected.

The following data is not changed. Parameter values specified by program change, bank select MSB/LSB, volume, pan, effect send levels 1, 3, 4, RPN and NRPN.

Control# Parameter Data Range 121 Reset All Controllers 0

1.3.3 All Note Off

This message turns off all notes which are currently on for the corresponding part. However, if Hold 1 or Sostenuto are on, notes will continue to sound until these are turned off.

Control# Parameter Data Range 123 All Note Off 0

1.3.4 Omni Off

Perform the same processing as when All Note Off is received.

Control# Parameter Data Range 124 Omni Off 0

1.3.5 Omni On

Perform the same processing as when All Note Off is received.

Control# Parameter Data Range 125 Omni On 0

1.3.6 Mono

Perform the same processing as when All Sound Off is received, and if the value (mono number) is in the range of 0...16, set the corresponding channel to Mode4* (m = 1).

Control# Parameter Data Range 126 Mono 0...16

*Mode4 is a state in which only channel messages on the specified channel will be received, and notes will be sounded individually (monophonically).

1.3.7 Poly

Perform the same processing as when All Sound Off is received, and set the corresponding channel to Mode3*.

Control# Parameter Data Range 127 Poly 0

*Mode3 is when channel messages will be received only on the specified channel, and will be sounded polyphonically.

Reset the portamento source note number that was received.

1.4 Program change

This message reports sound selection changes and changes the program number of the receiving channel.

In order to include changes to the voice bank, Program Change and Bank Select messages must be sent as a set (see 1.2.1). When RevPROGRAM CHANGE = OFF for Multi Part Parameter, the program change for that part is not received. Not received when Receive Program Change in Native System Parameters is set to off.

1.5 Pitch bend

This message conveys movements of the pitch bender. This message is generally used to modify the pitch of a part, but the depth of the following

seven effects can be controlled. The effect of this message can be modified by the following parameters.

• Multi Part Parameter

1. BEND PITCH CONTROL

2. BEND FILTER CONTROL

3. BEND AMPLITUDE CONTROL

4. BEND LFO PMOD DEPTH

5. BEND LFO FMOD DEPTH

6. BEND LFO AMOD DEPTH

• Effect1 Parameter

7. BEND VARIATION CONTROL DEPTH

(Valid when Variation Effect is assigned to a part as Insertion) By default, the Pitch Control effect is applied. If the receive channel is a drum part, effects 5 and 6 will not apply. If the Multi Part parameter Rcv PITCH BEND CHANGE = OFF, that part will not receive pitch bend messages.

1.6 Channel aftertouch (Receive only)

This message conveys the pressure which is applied to the keyboard after playing a note in order to create tonal changes (for an entire MIDI channel).

The pressure can be controlled for each part. This message will affect the currentlysounding notes. The effect of this message will be determined by the settings of the following parameters.

• EMulti Part Parameter

1. CAT PITCH CONTROL

2. CAT FILTER CONTROL

3. CAT AMPLITUDE CONTROL

4. CAT LFO PMOD DEPTH

5. CAT LFO FMOD DEPTH

6. CAT LFO AMOD DEPTH

• Effect1 Parameter

7. CAT VARIATION CONTROL DEPTH

(Valid when the Variation Effect is assigned to a part as Insertion) By default, there will be no effect. If the receive channel is a drum part, effects 5 and 6 will not apply. If the Multi Part parameter Rcv CHANNEL AFTER TOUCH = OFF, that part will not receive Channel Aftertouch.

1.7 Polyphonic aftertouch (Receive only)

This message conveys the pressure that is applied to the keyboard after playing a note (for individual note numbers).

The pressure can be controlled independently for each note. This message will affect currently-sounding notes. The effect of this message is determined by the following Multi Part parameters.

1. PAT PITCH CONTROL

2. PAT FILTER CONTROL

3. PAT AMPLITUDE CONTROL

4. PAT LFO PMOD DEPTH

5. PAT LFO FMOD DEPTH

6. PAT LFO AMOD DEPTH By default, there will be no effect. The effect will apply to note numbers 36...97. In the case of either of the following Multi Part parameter settings, that part will not receive Polyphonic Aftertouch. Rcv CHANNEL AFTER TOUCH = OFF PART MODE = DRUM, DRUMS1, 2

2. System exclusive messages

2.1 Parameter changes

This devices uses the following parameter changes.

[UNIVERSAL REALTIME MESSAGE]

[UNIVERSAL NON REALTIME MESSAGE]

1) Master Volume

1) General MIDI System On [XG PARAMETER CHANGE]

1) XG System on

2) XG System parameter change

3) Multi Effect1 parameter change

4) Multi Part parameter change

5) Drums Setup parameter change [NATIVE PARAMETER CHANGE]

1) Native System parameter change

2) Remote Switch parameter change

3) Normal Voice parameter change

4) Drum Voice parameter change [Others]

1) Master tuning

2.1.1 Universal realtime messages

2.1.1.1 Master Volume

11110000 F0H = Exclusive status 01111111 7FH = Universal Real Time 01111111 7FH = ID of target device 00000100 04H = Sub-ID #1=Device Control Message 00000001 01H = Sub-ID #2=Master Volume

*0sssssss SSH = Volume LSB

0ttttttt TTH = Volume MSB 11110111 F7H = End of Exclusive

or,

11110000 F0H = Exclusive status 01111111 7FH = Universal Real Time 0xxxnnnn XNH = n:Device Number, x=don’t care 00000100 04H = Sub-ID #1=Device Control Message 00000001 01H = Sub-ID #2=Master Volume 0sssssss SSH = Volume LSB 0ttttttt TTH = Volume MSB 11110111 F7H = End of Exclusive

When this is received, the Volume MSB will be reflected by the System parameter MASTER VOLUME.

*The binary expression 0sssssss is expressed in hexadecimal as SSH. The same applies

elsewhere.

2.1.2 Universal non-realtime messages

2.1.2.1 General MIDI System On

11110000 F0H = Exclusive status 01111110 7EH = Universal Non-Real Time 01111111 7FH = ID of target device 00001001 09H = Sub-ID #1=General MIDI Message 00000001 01H = Sub-ID #2=General MIDI On 11110111 F7H = End of Exclusive

or,

11110000 F0H = Exclusive status 01111110 7EH = Universal Non-Real Time 0xxxnnnn XNH = n:Device Number, x:don’t care 00001001 09H = Sub-ID #1=General MIDI Message 00000001 01H = Sub-ID #2=General MIDI On 11110111 F7H = End of Exclusive

When this message is received, the SOUND MODULE MODE is set to XG, and all MIDI messages defined by GM will be received. All data except for MIDI Master Tuning will be restored to the default value. Since approximately 50[ms] is required in order to process this message, be sure to allow an appropriate interval before sending the next message.

2.1.2.2 Identity Request

11110000 F0H = Exclusive status 01111110 7EH = Universal Non-Real Time 0mmmmmmm MMH = Device Number 00000110 06H = Sub-ID #1=General Information 00000001 01H = Sub-ID #2=Identity Request 11110111 F7H = End of Exclusive

When this message is received, this device will transmit an Identity Reply message as described in the following section2.1.2.3.

2.1.2.3 Identity Reply

11110000 F0H = Exclusive status 01111110 7EH = Universal Non-Real Time 0mmmmmmm MMH = Device Number 00000110 06H = Sub-ID #1=General Information 00000010 02H = Sub-ID #2=Identity Reply 01000011 43H = YAMAHA ID 00000000 00H = Device Family Code LSB S03 ID #1 01000001 41H = Device Family Code MSB S03 ID #2 01110111 77H = Device Number Code LSB S03 ID #3 00000100 04H = Device Number Code MSB S03 ID #4 00000000 00H 00000000 00H 00000000 00H 00000001 01H = Tone Generator Code=XG 11110111 F7H = End of Exclusive

This device will transmit this message when it receives the Identity Request message of

2.1.2.2.

2.1.3 XG parameter change

This message sets XG-related parameters. Each message can set a single parameter. The message format is as follows.

11110000 F0H Exclusive status 01000011 43H YAMAHA ID 0001nnnn 1NH N:device Number 01001100 4CH Model ID 0ggggggg GGH Address High 0mmmmmmm MMH Address Mid 0lllllll LLH Address Low 0sssssss SSH Data : : 11110111 F7H End of Exclusive

For parameters whose Data Size is 2 or 4, the appropriate amount of data will be transmitted as indicated by Size

2.1.3.1 XG System On

11110000 F0H Exclusive status 01000011 43H YAMAHA ID 0001nnnn 1NH N:device Number 01001100 4CH Model ID 00000000 00H Address High 00000000 00H Address Mid 01111110 7EH Address Low 00000000 00H Data 11110111 F7H End of Exclusive

When On is received, the SOUND MODULE MODE will be set to XG. Since approximately 50[ms] are required in order to execute this message, please allow an appropriate interval before transmitting the next message.

2.1.3.2 XG System parameter change

This message sets the XG SYSTEM block (refer to tables <1-1>, <1-2>).

2.1.3.3 Multi Effect1 parameter change

This message sets the MULTI EFFECT1 block (refer to tables <1-1>, <1-4>). The S03 responds to this message only when it is set to the Multi mode.

2.1.3.4 Multi Part parameter change

This message sets the MULTI PART block (refer to tables <1-1>, <1-5>). The S03 responds to this message only when it is set to the Multi mode.

2.1.3.5 Drums Setup parameter change

This message sets the DRUMS SETUP block (refer to tables <1-1>, <1-6>). The S03 responds to this message only when it is set to the Multi mode.

2.1.4 S03 native parameter change

This message sets parameters unique to the S03. Each message sets a single parameter. Each message modifies a single parameter. The message format is as follows.

11110000 F0H Exclusive status 01000011 43H YAMAHA ID 0001nnnn 1NH N:device Number 01101100 6CH Model ID 0ggggggg GGH Address High 0mmmmmmm MMH Address Mid 0lllllll LLH Address Low 0sssssss SSH Data : : 11110111 F7H End of Exclusive

For parameters whose Data Size is 2 or 4, the number of data bytes indicated by Size are transmitted.

2.1.4.1 Native System parameter change

This message sets the NATIVE SYSTEM block (refer to tables <2-1>, <2-3>).

2.1.4.2 Remote Switch parameter change

This message sets the REMOTE SWITCH block(refer to tables <2-1>, <2-5>).

2.1.4.3 Normal Voice parameter change

This message sets the NORMAL VOICE (Edit Buffer) block (refer to tables <2-1>, <2-9>, <2-10>). The S03 responds to this message only when it is set to the Voice mode.

2.1.4.4 Drum Voice parameter change

This message sets the Drum VOICE (Edit Buffer) block (refer to tables <2-1>, <2-11>, <212>). The S03 responds to this message only when it is set to the Voice mode.

2.1.5 Other parameter changes

2.1.5.1 Master tuning

This message simultaneously modifies the tuning of all channels.

11110000 F0H Exclusive status 01000011 43H YAMAHA ID 0001nnnn 1NH N:device Number 00100111 27H Model ID 00110000 30H Address High 00000000 00H Address Mid 00000000 00H Address Low 0000mmmm 0MH Master Tune MSB 0000llll 0LH Master Tune LSB 0xxxxxxx XXH don’t care 11110111 F7H End of Exclusive

Normally, the XG SYSTEM message MASTER TUNE should be used (refer to table <12>).

2.2 Bulk dump

This device uses the following bulk dump messages. [XG BULK DUMP]

1) XG System bulk dump

2) System Information bulk dump

3) Multi Effect1 bulk dump

4) Multi Part bulk dump

5) Drums Setup bulk dump

[NATIVE BULK DUMP]

1) Native System bulk dump

2) Bulk Control bulk dump

3) Native Multi bulk dump

4) Normal Voice bulk dump

5) Drum Voice bulk dump

2.2.1 XG bulk dump

This message sets XG-related parameters. Unlike parameter change messages, a single message can modify multiple parameters. The message format is as follows.

11110000 F0H Exclusive status 01000011 43H YAMAHA ID 0000nnnn 0NH N:Device Number 01001100 4CH Model ID 0sssssss SSH ByteCountMSB 0ttttttt TTH ByteCountLSB 0ggggggg GGH Address High 0mmmmmmm MMH Address Mid 0lllllll LLH Address Low 0vvvvvvv VVH Data : : 0kkkkkkk KKH Check-sum 11110111 F7H End of Exclusive

Address and Byte Count are given in tables 1-n. Byte Count is indicated by the total size of the Data in tables 1-n. Bulk dump and dump request messages are received when the beginning of the block is specified as the 'Address'. 'Block' indicates the unit of the data string that is indicated in tables 1-n as 'Total size'. Check sum is the value that produces a lower 7 bits of 0 when the Start Address, Byte Count, Data, and the Check-sum itself are added.

2.2.1.1 XG System bulk dump

This message sets the XG SYSTEM block (refer to tables <1-1>, <1-2>).

2.2.1.2 System Information bulk dump

This message indicates the contents of the SYSTEM INFORMATION block (refer to tables <1-1>, <1-3>). This message is transmitted in response to a Dump Request, but this message will be ignored if it is received.

2.2.1.3 Multi Effect1 bulk dump

This message sets the MULTI EFFECT1 block (refer to tables <1-1>, <1-4>).

2.2.1.4 Multi Part bulk dump

This message sets the MULTI PART block (refer to tables <1-1>, <1-5>).

2.2.1.5 Drums Setup bulk dump

This message sets the DRUMS SETUP block (refer to tables <1-1>, <1-6>).

2.2.2 S03 native bulk dump

This message modifies parameters unique to the S03.Unlike parameter change messages, a single message will modify multiple parameters. The message format is as follows.

11110000 F0H Exclusive status 01000011 43H YAMAHA ID 0000nnnn 0NH N:Device Number 01101100 6CH Model ID 0sssssss SSH ByteCountMSB 0ttttttt TTH ByteCountLSB 0ggggggg GGH Address High 0mmmmmmm MMH Address Mid 0lllllll LLH Address Low 0vvvvvvv VVH Data : : 0kkkkkkk KKH Check-sum 11110111 F7H End of Exclusive

Address and Byte Count are given in tables x-n. Byte Count is indicated by the total size of the Data in tables x-n. Bulk dump and dump request messages are received when the beginning of the block is specified as the 'Address'. Block indicates the unit of the data string that is indicated in tables x-n as 'Total size'. Check sum is the value that produces a lower 7 bits of 0 when the Start Address, Byte Count, Data, and the Check-sum itself are added.

2.2.2.1 Native System bulk dump

This message sets the NATIVE SYSTEM block (refer to tables <2-1>, <2-2>, <2-3>).

2.2.2.2 Bulk Control bulk dump

Bulk Control bulk dump This message sets the parameters such as Multi Number, Memory Bank and Voice Number when the Native Multi bulk dump, Normal Voice bulk dump or Drum Voice Bulk dump is received (refer to tables <2-1>, <2-2>, <2-4>).

2.2.2.3 Native Multi bulk dump

This message sets the NATIVE MULTI block (refer to tables <2-1>, <2-2>, <2-6>, <2-7>, <2-8>). To receive this message, the Bulk Header and Bulk Footer of Bulk Control must be received before and after reception, respectively. The Bulk Header determines the Multi number to which the data is stored.

2.2.2.4 Normal Voice bulk dump

This message sets the NORMAL VOICE block (refer to tables <2-1>, <2-2>, <2-9>, <210>). To receive this message, the Bulk Header and Bulk Footer of Bulk Control must be received before and after reception, respectively. The Bulk Header determines the Memory Bank/Voice number to which the data is stored.

2.2.2.5 Drum Voice bulk dump

This message sets the NORMAL VOICE block (refer to tables <2-1>, <2-2>, <2-11>, <212>). To receive this message, the Bulk Header and Bulk Footer of Bulk Control must be received before and after reception, respectively. The Bulk Header determines the Memory Bank/Voice number to which the data is stored.

2.3 Parameter request

This message requests transmission of a parameter value. The output is transmitted in the Parameter Change message format (refer to 2.1.x).

2.3.1 XG parameter request

This message requests transmission of XG parameter settings. Settings are transmitted in the format of an XG parameter change (refer to 2.1.3).

11110000 F0H Exclusive status 01000011 43H YAMAHA ID 0001nnnn 3NH N:device Number 01001100 4CH Model ID 0ggggggg GGH Address High 0mmmmmmm MMH Address Mid 0lllllll LLH Address Low 11110111 F7H End of Exclusive

2.3.2 S03 native parameter request

This message requests transmission of a parameter value unique to the S03. The output is transmitted in the format of a S03 native parameter change (refer to 2.1.4).

11110000 F0H Exclusive status 01000011 43H YAMAHA ID 0001nnnn 3NH N:device Number 01101100 6CH Model ID 0ggggggg GGH Address High 0mmmmmmm MMH Address Mid 0lllllll LLH Address Low 11110111 F7H End of Exclusive

2.4 Dump request

This message requests transmission of a specific block of parameter values. The output is the same as the bulk dump format.

2.4.1 XG dump request

This message requests transmission of all parameters of the specified block of XG parameters. The output is the same as the format of XG bulk dump (refer to 2.2.1).

11110000 F0H Exclusive status 01000011 43H YAMAHA ID 0001nnnn 2NH N:device Number 01001100 4CH Model ID 0ggggggg GGH Address High 0mmmmmmm MMH Address Mid 0lllllll LLH Address Low 11110111 F7H End of Exclusive

Address is valid only when the beginning of the block has been specified.

2.4.2 S03 native dump request

This message requests transmission of all parameters of the specified block of S03 native parameters. The output is in the same format as an S03 native bulk dump (refer to 2.2.2).

11110000 F0H Exclusive status 01000011 43H YAMAHA ID 0001nnnn 2NH N:device Number 01101100 6CH Model ID 0ggggggg GGH Address High 0mmmmmmm MMH Address Mid 0lllllll LLH Address Low 11110111 F7H End of Exclusive

Address is valid only when the beginning of the block has been specified. No System Exclusive Message is received when the Compare function is active.

3. Realtime messages

3.1 Active sensing

a) Transmission

Transmitted at every 270 msec.

b) Receive

Once FE has been received, failure to receive any MIDI message for an interval longer than approximately 300 msec will cause processing to be performed as if ALL SOUND OFF, ALL NOTE OFF, and RESET ALL CONTROLLERS messages were received, and the unit will reset to a condition in which FE was never received.

MIDI Data Table

Bank Select

Available Bank Select/Program Change

MSB (HEX) LSB (HEX) Program No. Type Memory Description

0 00 *1 0 - 127

64 40 0 00 *1 126 7E 0 00 0 - 1 127 7F 0 00 *1

63 3F 0 00 0 - 127

63 3F 8 08 0 - 127 User

63 3F 40 28 0 - 1 Drum Voice User

63 3F 64 40 0 - 127 Multi User

*1 Refer to Voice List

XG Parameter Base Address

MODEL ID = 4C

Parameter Description Remarks

Address

(H) (M) (L)

00 00 00 XG System

XG SYSTEM

INFORMATION 01 00 00 System Information Receives dump request only EFFECT 1 02 01 00 Effect1 (Reverb, Chorus, Variation )

MULTI PART

DRUM

The S03 responds to the message “MODEL ID = 4C” only when in the Multi mode.

MIDI Parameter Change table (XG SYSTEM)

Address Size Data Parameter Description Default value

(H) (H) (H) (H)

00 00 00 4 00 - 0F MASTER TUNE -102.4...0...+102.3[cent] 00 04 00 00

01 00 - 0F 1st bit3-0→bit15-12 02 00 - 0F 2nd bit3-0→bit11-8 03 00 - 0F 3rd bit3-0→bit7-4

04 1 00 - 7F MASTER VOLUME 0...127 7F 05 1 not used 06 1 28 - 58 TRANSPOSE -24...0...+24 [semitones] 40 7D 1 N DRUM SETUP RESET N: Drum setup number (0,1) --

7E 1 00 XG SYSTEM ON 7F 1 00 ALL PARAMETER RESET 00=ON (receive only) --

TOTAL SIZE 07

MIDI Parameter Change table (SYSTEM INFORMATION)

Address Size Data Parameter Description

(H) (H) (H)

01 00 00 E 20 - 7F Model Name 1 32...127(ASCII CHARACTER)

0D 20 - 7F Model Name 14 32...127 (ASCII CHARACTER) 0E 1 00 - 7F XG Level 1 0F 1 00 - 7F XG Level 2

TOTAL SIZE 10 Transmitted in response to Dump Request. Not received.

MIDI Parameter Change table (EFFECT)

Address Size Data Parameter Description Default value

(H) (H) (H) (H)

02 01 00 2 00 - 7F REVERB TYPE MSB Refer to Effect Type List 01(=HALL1)

02 1 00 - 7F REVERB PARAMETER 1 “ 12(depends on reverb type) 03 1 00 - 7F REVERB PARAMETER 2 “ 0A(“) 04 1 00 - 7F REVERB PARAMETER 3 “ 08(“) 05 1 00 - 7F REVERB PARAMETER 4 “ 0D(“) 06 1 00 - 7F REVERB PARAMETER 5 “ 31(“) 07 1 00 - 7F REVERB PARAMETER 6 “ 00(“) 08 1 00 - 7F REVERB PARAMETER 7 “ 00(“) 09 1 00 - 7F REVERB PARAMETER 8 “ 00(“) 0A 1 00 - 7F REVERB PARAMETER 9 “ 00(“) 0B 1 00 - 7F REVERB PARAMETER 10 “ 00(")

00 00 7D Drum Setup Reset Receives parameter change only 00 00 7E XG System On Receives parameter change only 00 00 7F All Parameter Reset Receives parameter change only

08 00 00 Multi Part 1

: 08 0F 00 Multi Part 16 30 0D 00 Drum Setup 1 31 0D 00 Drum Setup 2

00 - 7F REVERB TYPE LSB “ 00

Normal Voice

Drum Voice

Normal Voice

4th bit3-0→bit3-0

00=XG system ON (receive only)

GM/XG

Preset

Address Parameter

3n 0D 00 note number 13 3n 0E 00 note number 14

3n 5B 00 note number 91

Effective only when in the Multi mode

Address Size Data Parameter Description Default value

(H) (H) (H) (H)

0C 1 00 - 7F REVERB RETURN -∞dB...0dB...+6dB(0...96...127) 40 0D 1 01 - 7F REVERB PAN L63...C...R63 40

TOTAL SIZE 0E

02 01 10 1 00 - 7F REVERB PARAMETER 11 Refer to Effect Parameter List 00(depends on reverb type)

11 1 00 - 7F REVERB PARAMETER 12 “ 04(“) 12 1 00 - 7F REVERB PARAMETER 13 “ 32(“) 13 1 00 - 7F REVERB PARAMETER 14 “ 08(“) 14 1 00 - 7F REVERB PARAMETER 15 “ 40(“) 15 1 00 - 7F REVERB PARAMETER 16 “ 00(“)

TOTAL SIZE 6

02 01 20 2 00 - 7F CHORUS TYPE MSB Refer to Effect Type List 41(=CHORUS1)

00 - 7F CHORUS TYPE LSB “ 00 22 1 00 - 7F CHORUS PARAMETER 1 “ 06(depends on chorus type) 23 1 00 - 7F CHORUS PARAMETER 2 “ 36(“) 24 1 00 - 7F CHORUS PARAMETER 3 “ 4D(“) 25 1 00 - 7F CHORUS PARAMETER 4 “ 6A(“) 26 1 00 - 7F CHORUS PARAMETER 5 “ 00(“) 27 1 00 - 7F CHORUS PARAMETER 6 “ 1C(“) 28 1 00 - 7F CHORUS PARAMETER 7 “ 40(“) 29 1 00 - 7F CHORUS PARAMETER 8 “ 2E(“) 2A 1 00 - 7F CHORUS PARAMETER 9 “ 40(“) 2B 1 00 - 7F CHORUS PARAMETER 10 “ 40(“)

2C 1 00 - 7F CHORUS RETURN -∞dB...0dB...+6dB(0...96...127) 40 2D 1 01 - 7F CHORUS PAN L63...C...R63(1...64...127) 40

2E 1 00 - 7F

SEND CHORUS TO REVERB

-∞dB...0dB...+6dB(0...96...127) 00

TOTAL SIZE 0F

02 01 30 1 00 - 7F CHORUS PARAMETER 11 Refer to Effect Type List 2E(depends on chorus type)

31 1 00 - 7F CHORUS PARAMETER 12 “ 40(“) 32 1 00 - 7F CHORUS PARAMETER 13 “ 0A(“) 33 1 00 - 7F CHORUS PARAMETER 14 “ 00(“) 34 1 00 - 7F CHORUS PARAMETER 15 “ 00(“) 35 1 00 - 7F CHORUS PARAMETER 16 “ 00(“)

TOTAL SIZE 6

02 01 40 2 00 - 7F VARIATION TYPE MSB Refer to Effect Type List 05(=DELAY L, C, R)

00 - 7F VARIATION TYPE LSB “ 00 42 2 00 - 7F

44 2 00 - 7F

46 2 00 - 7F

48 2 00 - 7F

4A 2 00 - 7F

4C 2 00 - 7F

4E 2 00 - 7F

50 2 00 - 7F

52 2 00 - 7F

54 2 00 - 7F

56 1 00 - 7F VARIATION RETURN -∞dB...0dB...+6dB(0...96...127) 40 57 1 01 - 7F VARIATION PAN L63...C...R63(1...64...127) 40 58 1 00 - 7F 59 1 00 - 7F 5A 1 00 - 01 VARIATION CONNECTION INSERTION, SYSTEM 00 5B 1 00 - 7F VARIATION PART NUMBER Part1 7F

5C 1 00 - 7F

5D 1 00 - 7F

5E 1 00 - 7F

5F 1 00 - 7F

60 1 00 - 7F

VARIATION PARAMETER 1 MSB

00 - 7F

VARIATION PARAMETER 1 LSB VARIATION PARAMETER 2 MSB

00 - 7F

VARIATION PARAMETER 2 LSB VARIATION PARAMETER 3 MSB

00 - 7F

VARIATION PARAMETER 3 LSB VARIATION PARAMETER 4 MSB

00 - 7F

VARIATION PARAMETER 4 LSB VARIATION PARAMETER 5 MSB

00 - 7F

VARIATION PARAMETER 5 LSB VARIATION PARAMETER 6 MSB

00 - 7F

VARIATION PARAMETER 6 LSB VARIATION PARAMETER 7 MSB

00 - 7F

VARIATION PARAMETER 7 LSB VARIATION PARAMETER 8 MSB

00 - 7F

VARIATION PARAMETER 8 LSB VARIATION PARAMETER 9 MSB

00 - 7F

VARIATION PARAMETER 9 LSB VARIATION PARAMETER 10 MSB

00 - 7F

VARIATION PARAMETER 10 LSB

SEND VARIATION TO REVERB SEND VARIATION TO CHORUS

MW VARIATION CONTROL DEPTH

BEND VARIATION CONTROL DEPTH

CAT VARIATION CONTROL DEPTH

AC1 VARIATION CONTROL DEPTH

AC2 VARIATION CONTROL DEPTH

“ “ 05(“) “ 0D(“) “ 03(“) “ 27(“) “ 08(“) “ 27(“) “ 08(“) “ 00(“) “ 4A(“) “ 00(“) “ 64(“) “ 00(“) “ 0A(“) “ 00(“) “ 00(“) “ 00(“) “ 00(“) “ 00(“) “ 20(“)

-∞dB...0dB...+6dB(0...96...127) 00

OFF(127)

-64...0...+63 40

1A(depends on variation type)

TOTAL SIZE 21

02 01 70 1 00 - 7F VARIATION PARAMETER 11 Refer to Effect Parameter List

71 1 00 - 7F VARIATION PARAMETER 12 “ 3C(“) 72 1 00 - 7F VARIATION PARAMETER 13 “ 1C(“) 73 1 00 - 7F VARIATION PARAMETER 14 “ 40(“) 74 1 00 - 7F VARIATION PARAMETER 15 “ 2E(“) 75 1 00 - 7F VARIATION PARAMETER 16 “ 40(“)

00(depends on variation type)

TOTAL SIZE 6

MIDI Parameter Change table (MULTI PART)

Address Size Data Parameter Description Default value

(H) (H) (H) (H)

08 nn 00 1 00 - 20 ELEMENT RESERVE 0...64 part10 = 0

01 1 00 - 7F BANK SELECT MSB 0...127 part10 = 7F

02 1 00 - 7F BANK SELECT LSB 0...127 00 03 1 00 - 7F PROGRAM NUMBER 1...128 00 04 1

00-0F, 7F 05 1 00 - 01 MONO/POLY MODE MONO, POLY 01 06 1 00 - 02 SAME NOTE NUMBER

07 1 00 - 03 PART MODE NORMAL, DRUM, DRUMS1 Part10=2

08 1 28 - 58 NOTE SHIFT -24...0...+24[semitones] 40 09 2 00 - 0F DETUNE -12.8...0...+12.7[Hz] 08 00 0A 00 - 0F 1st bit3-0→bit7-4

0B 1 00 - 7F VOLUME 0...127 64 0C 1 00 - 7F VELOCITY SENSE DEPTH 0...127 40 0D 1 00 - 7F 0E 1 00 - 7F PAN RND, L63...C...R63 40 0F 1 00 - 7F NOTE LIMIT LOW C-2...G8 00 10 1 00 - 7F NOTE LIMIT HIGH C-2...G8 7F 11 1 00 - 7F DRY LEVEL 0...127 7F 12 1 00 - 7F CHORUS SEND 0...127 00 13 1 00 - 7F REVERB SEND 0...127 28 14 1 00 - 7F VARIATION SEND 0...127 00 15 1 00 - 7F VIBRATO RATE -64...0...+63 40 16 1 00 - 7F VIBRATO DEPTH -64...0...+63 40(drum part ignores) 17 1 00 - 7F VIBRATO DELAY -64...0...+63 40(drum part ignores)

18 1 00 - 7F

19 1 00 - 7F 1A 1 00 - 7F EG ATTACK TIME -64...0...+63 40

1B 1 00 - 7F EG DECAY TIME -64...0...+63 40 1C 1 00 - 7F EG RELEASE TIME -64...0...+63 40 1D 1 28 - 58 MW PITCH CONTROL -24...0...+24[semitones] 40

1E 1 00 - 7F 1F 1 00 - 7F

20 1 00 - 7F MW LFO PMOD DEPTH 0...127 0A 21 1 00 - 7F MW LFO FMOD DEPTH 0...127 00 22 1 00 - 7F MW LFO AMOD DEPTH 0...127 00 23 1 28 - 58 BEND PITCH CONTROL -24...0...+24[semitones] 42

24 1 00 - 7F 25 1 00 - 7F

26 1 00 - 7F BEND LFO PMOD DEPTH 0...127 00 27 1 00 - 7F BEND LFO FMOD DEPTH 0...127 00 28 1 00 - 7F BEND LFO AMOD DEPTH 0...127 00

TOTAL SIZE 29

08 nn 30 1 00 - 01 Rcv PITCH BEND OFF, ON 01

31 1 00 - 01 32 1 00 - 01 Rcv PROGRAM CHANGE OFF, ON 01 33 1 00 - 01 Rcv CONTROL CHANGE OFF, ON 01 34 1 00 - 01 35 1 00 - 01 Rcv NOTE MESSAGE OFF, ON 01 36 1 00 - 01 Rcv RPN OFF, ON 01 37 1 00 - 01 Rcv NRPN OFF, ON XGmode=01, GMmode=00 38 1 00 - 01 Rcv MODURATION OFF, ON 01 39 1 00 - 01 Rcv VOLUME OFF, ON 01 3A 1 00 - 01 Rcv PAN OFF, ON 01 3B 1 00 - 01 Rcv EXPRESSION OFF, ON 01 3C 1 00 - 01 Rcv HOLD1 OFF, ON 01 3D 1 00 - 01 Rcv PORTAMENTO OFF, ON 01 3E 1 00 - 01 Rcv SOSTENUTO OFF, ON 01 3F 1 00 - 01 Rcv SOFT PEDAL OFF, ON 01 40 1 00 - 01 Rcv BANK SELECT OFF, ON XGmode=01, GMmode=00 41 1 00 - 7F SCALE TUNING C -64...0...+63[cent] 40 42 1 00 - 7F SCALE TUNING C# -64...0...+63[cent] 40 43 1 00 - 7F SCALE TUNING D -64...0...+63[cent] 40 44 1 00 - 7F SCALE TUNING D# -64...0...+63[cent] 40 45 1 00 - 7F SCALE TUNING E -64...0...+63[cent] 40 46 1 00 - 7F SCALE TUNING F -64...0...+63[cent] 40 47 1 00 - 7F SCALE TUNING F# -64...0...+63[cent] 40 48 1 00 - 7F SCALE TUNING G -64...0...+63[cent] 40 49 1 00 - 7F SCALE TUNING G# -64...0...+63[cent] 40 4A 1 00 - 7F SCALE TUNING A -64...0...+63[cent] 40 4B 1 00 - 7F SCALE TUNING A# -64...0...+63[cent] 40 4C 1 00 - 7F SCALE TUNING B -64...0...+63[cent] 40 4D 1 28 - 58 CAT PITCH CONTROL -24...0...+24[semitones] 40

4E 1 00 - 7F 4F 1 00 - 7F

50 1 00 - 7F CAT LFO PMOD DEPTH 0...127 00 51 1 00 - 7F CAT LFO FMOD DEPTH 0...127 00 52 1 00 - 7F CAT LFO AMOD DEPTH 0...127 00 53 1 28 - 58 PAT PITCH CONTROL -24...0...+24[semitones] 40

54 1 00 - 7F 55 1 00 - 7F

56 1 00 - 7F PAT LFO PMOD DEPTH 0...127 00 57 1 00 - 7F PAT LFO FMOD DEPTH 0...127 00 58 1 00 - 7F PAT LFO AMOD DEPTH 0...127 00 59 1 00 - 5F 5A 1 28 - 58 AC1 PITCH CONTROL -24...0...+24[semitones] 40

5B 1 00 - 7F 5C 1 00 - 7F

Rcv CHANNEL A1...A16, OFF Part No.

KEY ON ASSIGN

VELOCITY SENSE OFFSET

LOW PASS FILTER CUTOFF FREQUENCY

LOW PASS FILTER RESONANCE

MW LOW PASS FILTER CONTROL

MW AMPLITUDE CONTROL

BEND LOWPASS FILTER CONTROL

BEND AMPLITUDE CONTROL

Rcv CH AFTER TOUCH(CAT)

Rcv POLY AFTER TOUCH(PAT)

CAT LOW PASS FILTER CONTROL

CAT AMPLITUDE CONTROL

PAT LOW PASS FILTER CONTROL

PAT AMPLITUDE CONTROL

AC1 CONTROLLER NUMBER

AC1 LOW PASS FILTER CONTROL

AC1 AMPLITUDE CONTROL

SINGLE, MULTI, INST (for DRUM)

2nd bit3-0→bit3-0

0...127 40

-64...0...+63 40

-9600...0...+9450[cent] 40

-100...0...+100[%] 40

-9600...0...+9450[cent] 40

-100...0...+100[%] 40

OFF, ON 01

-9600...0...+9450[cent] 40

-100...0...+100[%] 40

-9600...0...+9450[cent] 40

-100...0...+100[%] 40

0...95 10

-9600...0...+9450[cent] 40

-100...0...+100[%] 40

other parts = 2

other parts =0

other parts=0

5D 1 00 - 7F AC1 LFO PMOD DEPTH 0...127 00

5E 1 00 - 7F AC1 LFO FMOD DEPTH 0...127 00 5F 1 00 - 7F AC1 LFO AMOD DEPTH 0...127 00 60 1 00 - 5F 61 1 28 - 58 AC2 PITCH CONTROL -24...0...+24[semitones] 40

62 1 00 - 7F 63 1 00 - 7F

64 1 00 - 7F AC2 LFO PMOD DEPTH 0...127 00 65 1 00 - 7F AC2 LFO FMOD DEPTH 0...127 00 66 1 00 - 7F AC2 LFO AMOD DEPTH 0...127 00 67 1 00 - 01 PORTAMENTO SWITCH OFF, ON 00 68 1 00 - 7F PORTAMENTO TIME 0...127 00 69 1 00 - 7F PITCH EG INITIAL LEVEL -64...0...+63 40 6A 1 00 - 7F PITCH EG ATTACK TIME -64...0...+63 40

6B 1 00 - 7F PITCH EG RELEASE LEVEL -64...0...+63 40 6C 1 00 - 7F PITCH EG RELEASE TIME -64...0...+63 40 6D 1 01 - 7F VELOCITY LIMIT LOW 1...127 01

6E 1 01 - 7F VELOCITY LIMIT HIGH 1...127 7F

TOTAL SIZE 3F

nn = PART NUMBER(00 - 0F)

In the case of DRUM PART, the following parameters will have no effect.

• BANK SELECT LSB

• MONO/POLY MODE

• SCALE TUNING

• PORTAMENTO

AC2 CONTROLLER NUMBER

AC2 LOW PASS FILTER CONTROL

AC2 AMPLITUDE CONTROL

0...95 11

-9600...0...+9450[cent] 40

-100...0...+100[%] 40

MIDI Parameter Change table (DRUM SETUP)

Address Size Data Parameter Description Default value

(H) (H) (H) (H)

3n rr 00 1 00 - 7F PITCH COARSE -64...0...+63 40

01 1 00 - 7F PITCH FINE -64...0...+63[cent] 40

02 1 00 - 7F LEVEL 0...127 depend on the note

03 1 00 - 7F ALTERNATE GROUP OFF, 1...127 “

04 1 00 - 7F PAN RND, L63...C...R63 “

05 1 00 - 7F REVERB SEND 0...127 “

06 1 00 - 7F CHORUS SEND 0...127 “

07 1 00 - 7F VARIATION SEND 0...127 7F

08 1 00 - 01 KEY ASSIGN SINGLE, MULTI 00

09 1 00 - 01 Rcv NOTE OFF OFF, ON depend on the note

0A 1 00 - 01 Rcv NOTE ON OFF, ON 01

0B 1 00 - 7F

0C 1 00 - 7F 0D 1 00 - 7F EG ATTACK RATE -64...0...63 40

0E 1 00 - 7F EG DECAY1 RATE -64...0...63 40

0F 1 00 - 7F EG DECAY2 RATE -64...0...63 40

TOTAL SIZE 10

n = DRUM SETUP NUMBER(0 - 1) rr = NOTE NUMBER(0D - 5B)

In the following cases, the S03 will initialize all Drum Setups.

XG SYSTEM ON received GM SYSTEM ON received DRUM SETUP RESET received (the designated Drum Setup only when in XG mode)

[Note]

When a part to which a Drum Setup is assigned receives a program change, the assigned Drum Setup will be initialized.

If the same Drum Setup is assigned to two or more parts, changes in Drum Setup parameters (including program changes) will apply to all parts to which it is assigned.

LOW PASS FILTER CUTOFF FREQUENCY

LOW PASS FILTER RESONANCE

-64...0...63 40

Native Parameter Base Address

MODEL ID = 6C

Parameter Description Remarks

Address

NATIVE SYSTEM 00 00 00 Native System REMOTE SWITCH 0A 00 00 Remote Switch Receives parameter change only BULK CONTROL 0E 00 00 Header Bulk dump only

MULTI COMMON 30 00 00 Multi Common MULTI EFFECT 30 01 00 Multi Effect Bulk dump only MULTI PART 31 00 00 Multi Part 1 Bulk dump only

NORMAL VOICE COMMON NORMAL VOICE ELEMENT

DRUM VOICE COMMON 46 00 00 Drum Voice Common DRUM VOICE KEY 47 0D 00 Drum Voice Key

(H) (M) (L)

0F 00 00 Footer

: 31 0F 00 Multi Part 16 40 00 00 Normal Voice Common 41 00 00 Normal Voice Element 1

: 41 03 00 Normal Voice Element 4

Address Parameter

47 0D 00 note number 13 47 0E 00 note number 14

47 5B 00 note number 91

Bulk Dump Block

Parameter Block Description Byte Count Top Address

NATIVE SYSTEM Native System 22 16 00 00 00

NATIVE MULTI Bulk Header 0 00 0E mm nn

NATIVE NORMAL VOICE Bulk Header 0 00 0E mm nn

NATIVE DRUM VOICE Bulk Header 0 00 0E mm nn

COMMON Common 13 0B 30 00 00

EFFECT Reverb Parameter 20 14 30 01 00

Chorus Parameter 53 35 30 01 20 Variation Parameter 103 67 30 01 40

PART Multi Part1 43 2B 31 00 00

: 16 Blocks : : : : Multi Part16 43 2B 31 0F 00 Bulk Footer 0 00 0F mm nn

COMMON Common1 12 0C 40 00 00

Common2 33 21 40 00 10

ELEMENT Element1 106 6A 41 00 00

Element2 106 6A 41 01 00 Element3 106 6A 41 02 00

ELEMENT OPTION Element Option1 52 34 42 00 00

Element4 106 6A 41 03 00

Element Option2 52 34 42 01 00 Element Option3 52 34 42 02 00 Element Option4 52 34 42 03 00 Bulk Footer 0 00 0F mm nn

COMMON Common 10 0A 46 00 00

KEY Key C#-1 16 10 47 0D 00

: 79 Blocks : : : : Key G5 16 10 47 5B 00 Bulk Footer 0 00 0F mm nn

Dec Hex H M L

MIDI Parameter Change table (NATIVE SYSTEM)

Address Size Data Parameter Description Default value

(H) (H) (H) (H)

00 00 00 1 00 - 60 MW Transmit Control Number 0...95(0,32=off), AT(96) 01

01 1 00 - 60 FC Transmit Control Number 0...95(0,32=off), AT(96) 10 02 1 00 - 61 FS Transmit Control Number 03 1 00 - 01 Voice Mode Controller Reset Hold, Reset 01

04 1 00 - 01 Local Switch off, on 01 05 1 00 - 10 Receive Channel 1...16, omni 10 06 1 00 - 0F Transmit Channel 1...16 00 07 1 00 - 01 Receive Program Change off, on 01 08 1 00 - 01 Receive Bank Select off, on 01 09 1 00 - 01 0A 1 00 - 01 Transmit Bank Select off, on 01 0B 1 3D - 43 Octave Shift -3 ...+3 40 0C 1 35 - 4B Keyboard Transpose -11... +11 40

0D 1 00 - 05 Velocity Curve 0E 1 00 - 7F Fixed Velocity off,1...127 00

0F 1 00 - 01 Voice Effect Bypass off, on 00 10 1 00 - 5F 11 1 00 - 07 Thru Port 1...8 00

12 4 00 MASTER TUNE -102.4...0...+102.3[cent] 00 04 00 00 13 00 - 07 1st bit3-0→bit15-12 14 00 - 0F 2nd bit3-0→bit11-8 15 00 - 0F 3rd bit3-0→bit7-4

Transmit Program Change

Voice Mode AC1 Control Number

TOTAL SIZE 16

MIDI Parameter Change table (BULK CONTROL)

Address Size Data Parameter Description

(H) (H) (H)

0E 00 nn 0 - Bulk Header Normal Voice PRESET (nn = 0 - 127)

08 nn 0 - Normal Voice USER (nn = 0 - 127) 0F nn 0 - Normal Voice Edit Buffer (nn = 0) 28 nn 0 - Drum Voice USER (nn = 0 - 1) 2F nn 0 - Drum Voice Edit Buffer (nn = 0) 40 nn 0 - Multi USER (nn = 0 - 31) 41 nn 0 - Multi Edit Buffer (nn=0) 7F nn 0 - Drum Voice S03 Kit (nn = 120 - 127)

0F 00 nn 0 - Bulk Footer Normal Voice PRESET (nn = 0 - 127)

0...95(0,32=off), PC INC(96), PC DEC(97)

off, on 01

normal, soft1, soft2, easy, wide, hard

0...95 00

4th bit3-0→bit3-0

MIDI Parameter Change table (REMOTE SWITCH)

Address Size Data Parameter Description

(H) (H) (H)

0A 00 00 1 01 MULTI on

01 1 01 VOICE on 02 1 01 DEMO on 03 1 01 UTILITY on 04 1 01 MIDI on 05 1 01 EDIT on 06 1 01 JOB on 07 1 01 STORE on 08 1 01 PART PLUS on 09 1 01 PART MINUS on 0A 1 01 PART PLUS + MINUS on

0B 1 01 INC/YES on 0C 1 01 DEC/NO on 0D 1 01 PAGE UP on

0E 1 01 PAGE DOWN on

0F 1 01 LEFT on

10 1 01 RIGHT on

11 1 01 OCT DOWN on

12 1 01 OCT UP on

13 1 01 OCT DOWN + UP on

14 1 01 ENTER on

15 1 01 EXIT on

16 1 01 CATEGORY SEARCH on

17 1 01 PRESET on

18 1 01 USER on

19 1 01 GM/XG on

1A 1 01 DRUM + USER on

1B 1 01 DRUM + GM/XG on 1C 1 01 0 on 1D 1 01 1 on

1E 1 01 2 on

1F 1 01 3 on

20 1 01 4 on

21 1 01 5 on

22 1 01 6 on

23 1 01 7 on

24 1 01 8 on

25 1 01 9 on

26 1 01 MINUS on

27 1 01 MUTE on

MIDI Parameter Change table (NATIVE MULTI COMMON)

Address Size Data Parameter Description Default value

(H) (H) (H) (H)

30 00 00 1 20 - 7F Multi Name 1 32...127(ASCII) 49 ('I')

01 1 20 - 7F Multi Name 2 32...127(ASCII) 6E ('n')

02 1 20 - 7F Multi Name 3 32...127(ASCII) 69 ('i')

03 1 20 - 7F Multi Name 4 32...127(ASCII) 74 ('t')

04 1 20 - 7F Multi Name 5 32...127(ASCII) 20 (' ')

05 1 20 - 7F Multi Name 6 32...127(ASCII) 4D ('M')

06 1 20 - 7F Multi Name 7 32...127(ASCII) 6C ('l')

07 1 20 - 7F Multi Name 8 32...127(ASCII) 74 ('t')

08 1 00 - 10 Multi Category

09 1 00 - 7F Multi Volume 0...127 7F

0A 1 28 - 58 Multi Transpose -24...+24 40

TOTAL SIZE 0B

0, 2...16(--, PF, OR, GT, BA, ST, BR, RP, LD, PD, SC, CP, DR, SE, ME, CO)

00 ('--')

MIDI Parameter Change table (NATIVE MULTI EFFECT)

Address Size Data Parameter Description Default value

(H) (H) (H) (H)

30 01 00 2 00 - 7F REVERB TYPE MSB Refer to Effect Program List 01(=HALL1)

TOTAL SIZE 14

00 - 7F REVERB TYPE LSB “ 00 02 1 00 - 7F REVERB PARAMETER 1 “ 12(depends on reverb type) 03 1 00 - 7F REVERB PARAMETER 2 “ 0A(“) 04 1 00 - 7F REVERB PARAMETER 3 “ 08(“) 05 1 00 - 7F REVERB PARAMETER 4 “ 0D(“) 06 1 00 - 7F REVERB PARAMETER 5 “ 31(“) 07 1 00 - 7F REVERB PARAMETER 6 “ 00(“) 08 1 00 - 7F REVERB PARAMETER 7 “ 00(“) 09 1 00 - 7F REVERB PARAMETER 8 “ 00(“) 0A 1 00 - 7F REVERB PARAMETER 9 “ 00(“) 0B 1 00 - 7F REVERB PARAMETER 10 “ 00(“)

0C 1 00 - 7F REVERB RETURN -∞dB...0dB...+6dB(0...96...127) 40 0D 1 01 - 7F REVERB PAN L63...C...R63 40

0E 1 00 - 7F REVERB PARAMETER 11 Refer to Effect Parameter List 00(depends on reverb type) 0F 1 00 - 7F REVERB PARAMETER 12 “ 04(“) 10 1 00 - 7F REVERB PARAMETER 13 “ 32(“) 11 1 00 - 7F REVERB PARAMETER 14 “ 08(“) 12 1 00 - 7F REVERB PARAMETER 15 “ 40(“) 13 1 00 - 7F REVERB PARAMETER 16 “ 00(“)

30 01 20 2 00 - 7F CHORUS TYPE MSB Refer to Effect Program List 41(=CHORUS1)

26 1 00 - 7F CHORUS PARAMETER 5 “ 00(“) 27 1 00 - 7F CHORUS PARAMETER 6 “ 1C(“) 28 1 00 - 7F CHORUS PARAMETER 7 “ 40(“) 29 1 00 - 7F CHORUS PARAMETER 8 “ 2E(“) 2A 1 00 - 7F CHORUS PARAMETER 9 “ 40(“) 2B 1 00 - 7F CHORUS PARAMETER 10 “ 40(“) 2C 1 00 - 7F CHORUS RETURN -∞dB...0dB...+6dB(0...96...127) 40 2D 1 01 - 7F CHORUS PAN L63...C...R63(1...64...127) 40 2E 1 00 - 7F 2F 1 00 - 7F CHORUS PARAMETER 11 Refer to Effect Parameter List 2E(depends on chorus type) 30 1 00 - 7F CHORUS PARAMETER 12 “ 40(“) 31 1 00 - 7F CHORUS PARAMETER 13 “ 0A(“) 32 1 00 - 7F CHORUS PARAMETER 14 “ 00(“) 33 1 00 - 7F CHORUS PARAMETER 15 “ 00(“) 34 1 00 - 7F CHORUS PARAMETER 16 “ 00(“)

TOTAL SIZE 35

30 01 40 2 00 - 7F VARIATION TYPE MSB Refer to Effect Program List 05(=DELAY L, C, R)

42 2 00 - 7F

44 2 00 - 7F

46 2 00 - 7F

48 2 00 - 7F

4A 2 00 - 7F

4C 2 00 - 7F

4E 2 00 - 7F

50 2 00 - 7F

52 2 00 - 7F

54 2 00 - 7F

5C 1 00 - 7F 5D 1 40 not used 40

5E 1 40 not used 40 5F 1 00 - 7F 60 1 40 not used 40

61 1 00 - 7F VARIATION PARAMETER 11 Refer to Effect Parameter List 62 1 00 - 7F VARIATION PARAMETER 12 “ 3C(“) 63 1 00 - 7F VARIATION PARAMETER 13 “ 1C(“) 64 1 00 - 7F VARIATION PARAMETER 14 “ 40(“) 65 1 00 - 7F VARIATION PARAMETER 15 “ 2E(“) 66 1 00 - 7F VARIATION PARAMETER 16 “ 40(“)

SEND CHORUS TO REVERB

00 - 7F VARIATION TYPE LSB “ 00

VARIATION PARAMETER 1 MSB

00 - 7F

VARIATION PARAMETER 1 LSB VARIATION PARAMETER 2 MSB

00 - 7F

VARIATION PARAMETER 2 LSB VARIATION PARAMETER 3 MSB

00 - 7F

VARIATION PARAMETER 3 LSB VARIATION PARAMETER 4 MSB

00 - 7F

VARIATION PARAMETER 4 LSB VARIATION PARAMETER 5 MSB

00 - 7F

VARIATION PARAMETER 5 LSB VARIATION PARAMETER 6 MSB

00 - 7F

VARIATION PARAMETER 6 LSB VARIATION PARAMETER 7 MSB

00 - 7F

VARIATION PARAMETER 7 LSB VARIATION PARAMETER 8 MSB

00 - 7F

VARIATION PARAMETER 8 LSB VARIATION PARAMETER 9 MSB

00 - 7F

VARIATION PARAMETER 9 LSB VARIATION PARAMETER 10 MSB

00 - 7F

VARIATION PARAMETER 10 LSB

SEND VARIATION TO REVERB SEND VARIATION TO CHORUS

MW VARIATION CONTROL DEPTH

AC1 VARIATION CONTROL DEPTH

-∞dB...0dB...+6dB(0...96...127) 00

OFF(127)

-64...0...+63 40

1A(depends on variation type)

00(depends on variation type)

TOTAL SIZE 67

MIDI Parameter Change table (NATIVE MULTI PART)

Address Size Data Parameter Description Default value

(H) (H) (H) (H)

31 nn 00 1 00 - 7F BANK SELECT MSB 0...127 part10 = 7F

01 1 00 - 7F BANK SELECT LSB 0...127 00 02 1 00 - 7F PROGRAM NUMBER 1...128 00 03 1

00-0F, 7F 04 1 00 - 01 MONO/POLY MODE MONO , POLY 01 05 1 00 - 03 PART MODE

06 1 28 - 58 NOTE SHIFT -24...0...+24[semitones] 40 07 2 00 - 0F DETUNE -12.8...0...+12.7[Hz] 08 00 08 00 - 0F 1st bit3-0→bit7-4

09 1 00 - 7F VOLUME 0...127 64 0A 1 00 - 7F VELOCITY SENSE DEPTH 0...127 40 0B 1 00 - 7F 0C 1 00 - 7F PAN RND, L63...C...R63 40 0D 1 00 - 7F NOTE LIMIT LOW C-2...G8 00 0E 1 00 - 7F NOTE LIMIT HIGH C-2...G8 7F 0F 1 00 - 7F CHORUS SEND 0...127 00 10 1 00 - 7F REVERB SEND 0...127 28 11 1 00 - 7F VARIATION SEND 0...127 00 12 1 00 - 7F VIBRATO RATE -64...0...+63 40 13 1 00 - 7F VIBRATO DEPTH -64...0...+63 40(drum part ignores) 14 1 00 - 7F VIBRATO DELAY -64...0...+63 40(drum part ignores)

15 1 00 - 7F

16 1 00 - 7F 17 1 00 - 7F EG ATTACK TIME -64...0...+63 40

18 1 00 - 7F EG DECAY TIME -64...0...+63 40 19 1 00 - 7F EG RELEASE TIME -64...0...+63 40

1A 1 00 - 7F 1B 1 00 - 7F MW LFO PMOD DEPTH 0...127 0A

1C 1 00 - 7F MW LFO FMOD DEPTH 0...127 00 1D 1 00 - 7F MW LFO AMOD DEPTH 0...127 00 1E 1 28 - 58 BEND PITCH CONTROL -24...0...+24[semitones] 42

Rcv CHANNEL A1...A16, OFF Part No.

NORMAL, DRUM, DRUMS1...2

2nd bit3-0→bit3-0

VELOCITY SENSE OFFSET

LOW PASS FILTER CUTOFF FREQUENCY

LOW PASS FILTER RESONANCE

MW LOW PASS FILTER CONTROL

0...127 40

-64...0...+63 40

-9600...0...+9450[cent] 40

other parts=0

Part10=2 other parts=0

Address Size Data Parameter Description Default value

(H) (H) (H) (H)

1F 1 00 - 5F 20 1 00 - 7F 21 1 00 - 7F AC1 LFO FMOD DEPTH 0...127 00

22 1 00 - 7F AC1 LFO AMOD DEPTH 0...127 00 23 1 00 - 01 PORTAMENTO SWITCH OFF, ON 00 24 1 00 - 7F PORTAMENTO TIME 0...127 00 25 1 00 - 7F PITCH EG INITIAL LEVEL -64...0...+63 40 26 1 00 - 7F PITCH EG ATTACK TIME -64...0...+63 40 27 1 00 - 7F PITCH EG RELEASE LEVEL -64...0...+63 40 28 1 00 - 7F PITCH EG RELEASE TIME -64...0...+63 40 29 1 01 - 7F VELOCITY LIMIT LOW 1...127 01 2A 1 01 - 7F VELOCITY LIMIT HIGH 1...127 7F

TOTAL SIZE 2B

AC1 CONTROLLER NUMBER AC1 LOW PASS FILTER

CONTROL

0...95 10

-9600...0...+9450[cent] 40

nn = PART NUMBER(00 - 0F)

MIDI Parameter Change table (NATIVE NORMAL VOICE COMMON)

Address Size Data Parameter Description Default value

(H) (H) (H) (H)

40 00 00 2 00 - 01 Total Level 01 7F(0:Min)...00 00(127:Max) 00 00

01 00 - 7F 02 1 00 - 0F Element Switch 03 1 20 - 7F Voice Name 1 32...127(ASCII) 49 ('I')

04 1 20 - 7F Voice Name 2 32...127(ASCII) 6E ('n') 05 1 20 - 7F Voice Name 3 32...127(ASCII) 69 ('i') 06 1 20 - 7F Voice Name 4 32...127(ASCII) 74 ('t') 07 1 20 - 7F Voice Name 5 32...127(ASCII) 20 (' ') 08 1 20 - 7F Voice Name 6 32...127(ASCII) 56 ('V') 09 1 20 - 7F Voice Name 7 32...127(ASCII) 63 ('c') 0A 1 20 - 7F Voice Name 8 32...127(ASCII) 65 ('e')

0B 1 00 - 10 Voice Category

TOTAL SIZE 0C

40 00 10 2 00 - 7F Variation Type MSB Refer to Effect Program List 05(=DELAY L, C, R)

00 - 7F Variation Type LSB “ 00

12 2 00 - 7F Variation Param 1 MSB “

00 - 7F Variation Param 1 LSB “ 05(“)

14 2 00 - 7F Variation Param 2 MSB “ 0D(“)

00 - 7F Variation Param 2 LSB “ 03(“)

16 2 00 - 7F Variation Param 3 MSB “ 27(“)

00 - 7F Variation Param 3 LSB “ 08(“)

18 2 00 - 7F Variation Param 4 MSB “ 27(“)

00 - 7F Variation Param 4 LSB “ 08(“)

1a 2 00 - 7F Variation Param 5 MSB “ 00(“)

00 - 7F Variation Param 5 LSB “ 4A(“)

1c 2 00 - 7F Variation Param 10 MSB “ 00(“)

00 - 7F Variation Param 10 LSB “ 20(“)

1e 1 00 - 7F MW Variation Control -64...0...+63 40

1f 1 00 - 7F AC1 Variation Control -64...0...+63 40 20 1 00 - 7F Send Chorus To Reverb 0...127 00 21 1 00 - 01 Mono/Poly MONO, POLY 01 22 1 00 - 7F Total Volume 0...127 7F 23 1 00 - 7F Velocity Sense Depth 0...127 40 24 1 00 - 7F Velocity Sense Offset 0...127 40 25 1 00 - 7F Chorus Send 0...127 00 26 1 00 - 7F Reverb Send 0...127 28 27 1 00 - 7F MW Filter Control -64...0...+63 40 28 1 00 - 7F MW PMod Depth 0...127 0A 29 1 00 - 7F MW FMod Depth 0...127 00 2a 1 00 - 7F MW AMod Depth 0...127 00 2b 1 28 - 58 Pitch Bend Range -24...0...+24 42 2c 1 00 - 7F AC1 Filter Control -64...0...+63 40 2d 1 00 - 7F AC1 FMod Depth 0...127 00 2e 1 00 - 7F AC1 AMod Depth 0...127 00

2f 1 00 - 01 Portament Switch OFF, ON 00 30 1 00 - 7F Portamento Time 0...127 00

bit0: element1... bit3: element4 (0:off, 1:on)

0, 2...16(--, PF, OR, GT, BA, ST, BR, RP, LD, PD, SC, CP, DR, SE, ME, CO)

00 ('--')

1A(depends on variation type)

TOTAL SIZE 21

MIDI Parameter Change table (NATIVE NORMAL VOICE ELEMENT)

Address Size Data Parameter Description Default value

(H) (H) (H) (H)

41 ee 00 2 00 - 01 Element Level 0...255 00

01 00 - 7F 7F 02 2 00 - 02 Wave Number 1...453 00 03 00 - 7F 1D 04 1 00 - 7F Pan Scale, L63...C...R63 40 05 1 00 - 01 Level Scaling Flag Brk.p, Table 00 06 1 00 - 7F Level Scaling BP1 C-2...G8 18 07 1 00 - 7F Level Scaling BP2 C-2...G8 30 08 1 00 - 7F Level Scaling BP3 C-2...G8 60 09 1 00 - 7F Level Scaling BP4 C-2...G8 6C 0A 2 00 - 01 Level Scaling Offset1 -128...+0...+127 00 0B 00 - 7F 00

0C 2 00 - 01 Level Scaling Offset2 -128...+0...+127 00 0D 00 - 7F 00

0E 2 00 - 01 Level Scaling Offset3 -128...+0...+127 00 0F 00 - 7F 00

Address Size Data Parameter Description Default value

(H) (H) (H) (H)

10 2 00 - 01 Level Scaling Offset4 -128...+0...+127 00 11 00 - 7F 00 12 1 00 - 7F Note Limit Low C-2...G8 00 13 1 00 - 7F Note Limit High C-2...G8 7F 14 1 01 - 7F Velocity Limit Low 1...127 01 15 1 01 - 7F Velocity Limit High 1...127 7F 16 1 01 - 7F Note Shift -63...0...+63 40 17 1 01 - 7F Detune -63...0...+63 40 18 1 00 - 05 Pitch Scaling Sensitivity 19 1 00 - 7F Pitch Scaling Center C-2...G8 3C 1A 1 00 - 02 LFO Wave Saw, Tri, S&H 01 1B 1 00 - 01 LFO Phase Init OFF, ON 01 1C 1 00 - 3F LFO Speed 0...63 1F 1D 1 00 - 7F PLFO Delay 0...127 00 1E 1 00 - 7F PLFO Fade Time 0...127 00 1F 1 00 - 7F LFO Pmod Depth 0...127 00 20 1 00 - 7F LFO Fmod Depth 0...127 00 21 1 00 - 7F LFO Amod Depth 0...127 00 22 1 39 - 47 PEG Level Velocity Sensitivity -7...+0...+7 40 23 1 39 - 47 PEG Rate Velocity Sensitivity -7...+0...+7 40 24 1 39 - 47 PEG Rate Scaling Sensitivity -7...+0...+7 40

25 1 00 - 7F 26 1 00 - 3F PEG Attack Rate 0...63 00

27 1 00 - 3F PEG Decay1 Rate 0...63 00 28 1 00 - 3F PEG Decay2 Rate 0...63 00 29 1 00 - 3F PEG Release Rate 0...63 00 2A 2 2D - 52 PEG Initial Level -2400...+0...+2400 40 2B 00 - 7F 00 2C 2 2D - 52 PEG Attack Level -2400...+0...+2400 40 2D 00 - 7F 00 2E 2 2D - 52 PEG Decay1 Level -2400...+0...+2400 40 2F 00 - 7F 00 30 2 2D - 52 PEG Decay2 Level -2400...+0...+2400 40 31 00 - 7F 00 32 2 2D - 52 PEG Release Level -2400...+0...+2400 40 33 00 - 7F 00 34 2 00 - 0F Filter Cutoff Frequency 0...2047 0F 35 00 - 7F 7F 36 1 00 - 3F Filter Resonance 0...63 06 37 1 00 - 01 Filter Cutoff Scaling Flag Brk.p, Table 00 38 1 00 - 7F Filter Cutoff Scaling BP1 C-2...G8 18 39 1 00 - 7F Filter utoff Scaling BP2 C-2...G8 30 3A 1 00 - 7F Filter Cutoff Scaling BP3 C-2...G8 60 3B 1 00 - 7F Filter Cutoff Scaling BP4 C-2...G8 6C 3C 2 00 - 01 Filter Cutoff Scaling Offset1 -128...+0...+127 00 3D 00 - 7F 00 3E 2 00 - 01 Filter Cutoff Scaling Offset2 -128...+0...+127 00 3F 00 - 7F 00 40 2 00 - 01 Filter Cutoff Scaling Offset3 -128...+0...+127 00 41 00 - 7F 00 42 2 00 - 01 Filter Cutoff Scaling Offset4 -128...+0...+127 00 43 00 - 7F 00

44 1 00 - 0f 45 1 00 - 0f Cutoff Velocity Sensitivity 0...15 00

46 1 00 - 7F FEG Hold Rate 0...127 00 47 1 00 - 7F FEG Attack Rate 0...127 00 48 1 00 - 7F FEG Decay1 Rate 0...127 00 49 1 00 - 7F FEG Decay2 Rate 0...127 00 4A 1 00 - 7F FEG Release Rate 0...127 00 4B 2 30 - 4F FEG Initial Level -2047...+0...+2047 40 4C 00 - 7F 00 4D 2 30 - 4F FEG Attack Level -2047...+0...+2047 40 4E 00 - 7F 00 4F 2 30 - 4F FEG Decay1 Level -2047...+0...+2047 40 50 00 - 7F 00 51 2 30 - 4F FEG Decay2 Level -2047...+0...+2047 40 52 00 - 7F 00 53 2 30 - 4F FEG Release Level -2047...+0...+2047 40 54 00 - 7F 00 55 1 00 - 0F FEG Rate Scaling Sensitivity 0...15 00 56 1 00 - 0F 57 1 00 - 0F

58 1 39 - 47

59 1 39 - 47 5A 1 00 - 0f Keyon Delay 0...15 00

5B 1 00 - 7F AEG Attack Rate 0...127 7F 5C 1 00 - 7F AEG Decay1 Rate 0...127 00 5D 1 00 - 7F AEG Decay2 Rate 0...127 00 5E 1 - not used - 5F 1 00 - 7F AEG Release Rate 0...127 50 60 2 00 - 01 AEG Initial Level 01 7F(0:Min)...00 00(255:Max) 00 61 00 - 7F 00 62 2 00 - 01 AEG Decay Level 01 7F(0:Min)...00 00(255:Max) 00 63 00 - 7F 00 64 2 00 - 01 AEG Sustain Level 01 7F(0:Min)...00 00(255:Max) 00 65 00 - 7F 00 66 1 00 - 0F Level Scaling Sensitivity 0...15 00 67 1 00 - 0F AEG Rate Scaling Sensitivity 0...15 00 68 1 00 - 0F AEG Level Velocity Sensitivity 0...15 00

69 1 00 - 0F

TOTAL SIZE 6A

42 ee 00 4 00 - 0F Level Scaling Table Number 0...65535, 1st bit3-0→bit15-12 00

01 00 - 0F 2nd bit3-0→bit11-8 00 02 00 - 0F 3rd bit3-0→bit7-4 06 03 00 - 0F 4th bit3-0→bit3-0 00

PEG Rate Scaling Center Note

Filter Cutoff Scaling Sensitivity

Filter Scaling Velocity Sensitivity Resonance Velocity Sensitivity FEG Attack Rate Velocity

Sensitivity FEG Other Rate Velocity

Sensitivity

AEG Attack Rate Velocity Sensitivity

100%, 50%, 20%, 10%, 5%, 0%

C-2...G8 3C

0...15 00

-7...+0...+7 40

0...15 00

04 4 00 - 0F Scaling Pan Table Number 0...65535, 1st bit3-0→bit15-12 00 05 00 - 0F 2nd bit3-0→bit11-8 00 06 00 - 0F 3rd bit3-0→bit7-4 00 07 00 - 0F 4th bit3-0→bit3-0 05 08 4 00 - 0F Tuning Curve Table Number 0...65535, 1st bit3-0→bit15-12 0f 09 00 - 0F 2nd bit3-0→bit11-8 0f 0A 00 - 0F 3rd bit3-0→bit7-4 0f 0B 00 - 0F 4th bit3-0→bit3-0 0f

0C 4 00 - 0F Cutoff Scaling Table Number 0...65535, 1st bit3-0→bit15-12 0f 0D 00 - 0F 2nd bit3-0→bit11-8 0f

0E 00 - 0F 3rd bit3-0→bit7-4 0f 0F 00 - 0F 4th bit3-0→bit3-0 0f

10 4 00 - 0F 11 00 - 0F 2nd bit3-0→bit11-8 00

12 00 - 0F 3rd bit3-0→bit7-4 00 13 00 - 0F 4th bit3-0→bit3-0 01 14 4 00 - 0F 15 00 - 0F 2nd bit3-0→bit11-8 00 16 00 - 0F 3rd bit3-0→bit7-4 00 17 00 - 0F 4th bit3-0→bit3-0 07

18 4 00 - 0F 19 00 - 0F 2nd bit3-0→bit11-8 00

1A 00 - 0F 3rd bit3-0→bit7-4 00 1B 00 - 0F 4th bit3-0→bit3-0 01

1C 4 00 - 0F 1D 00 - 0F 2nd bit3-0→bit11-8 00

1E 00 - 0F 3rd bit3-0→bit7-4 00 1F 00 - 0F 4th bit3-0→bit3-0 02 20 4 00 - 0F 21 00 - 0F 2nd bit3-0→bit11-8 00 22 00 - 0F 3rd bit3-0→bit7-4 00 23 00 - 0F 4th bit3-0→bit3-0 03 24 4 00 - 0F 25 00 - 0F 2nd bit3-0→bit11-8 00 26 00 - 0F 3rd bit3-0→bit7-4 06 27 00 - 0F 4th bit3-0→bit3-0 00 28 4 00 - 0F 29 00 - 0F 2nd bit3-0→bit11-8 00 2A 00 - 0F 3rd bit3-0→bit7-4 00 2B 00 - 0F 4th bit3-0→bit3-0 07

2C 4 00 - 0F 2D 00 - 0F 2nd bit3-0→bit11-8 00

2E 00 - 0F 3rd bit3-0→bit7-4 00 2F 00 - 0F 4th bit3-0→bit3-0 01 30 4 00 - 0F 31 00 - 0F 2nd bit3-0→bit11-8 00 32 00 - 0F 3rd bit3-0→bit7-4 00 33 00 - 0F 4th bit3-0→bit3-0 01

TOTAL SIZE 34

Cutoff Velocity Curve Tab le Number

FEG Rate Scaling Table Number

FEG Depth Velocity Curve Table Number

Resonance Velocity Curve Table Number

FEG Rate Velocity Table Number

AEG Level Scaling Table Number

AEG Rate Scaling Table Number

AEG Level Velocity Table Number

AEG Rate Velocity Table Number

0...65535, 1st bit3-0→bit15-12 00

ee = ELEMENT NUMBER(00 - 03)

MIDI Parameter Change table (NATIVE DRUM VOICE COMMON)

Address Size Data Parameter Description Default value

(H) (H) (H) (H)

46 00 00 1 20 - 7F Voice Name 1 32...127(ASCII) 49 ('I')

01 1 20 - 7F Voice Name 2 32...127(ASCII) 6E ('n') 02 1 20 - 7F Voice Name 3 32...127(ASCII) 69 ('i') 03 1 20 - 7F Voice Name 4 32...127(ASCII) 74 ('t') 04 1 20 - 7F Voice Name 5 32...127(ASCII) 20 (' ') 05 1 20 - 7F Voice Name 6 32...127(ASCII) 4B ('K') 06 1 20 - 7F Voice Name 7 32...127(ASCII) 69 ('i') 07 1 20 - 7F Voice Name 8 32...127(ASCII) 74 ('t')

08 1 00 - 10 Voice Category

09 1 00 - 13 Original Kit 01(StandKit) ...20(SFX Kit2) 00

TOTAL SIZE 0A

0, 2...16(--, PF, OR, GT, BA, ST, BR, RP, LD, PD, SC, CP, DR, SE, ME, CO)

00 ('--')

MIDI Parameter Change table (NATIVE DRUM VOICE KEY)

Address Size Data Parameter Description Default value

(H) (H) (H) (H)

47 rr 00 1 00 - 7F Pitch Coarse -64...0...+63(semitones) 40

01 1 00 - 7F Pitch Fine -64...0...+63(cent) 40 02 1 00 - 7F Level 0...127 depend on the note 03 1 00 - 7F Alternate Group 0ff, 1..127 depend on the note 04 1 00 - 7F Pan Random, L63..C..R63 depend on the note 05 1 00 - 7F Reverb Send 0...127 depend on the note 06 1 00 - 7F Chorus Send 0...127 depend on the note 07 1 - not used - -08 1 00 - 01 Key Assign Single, Multi 00 09 1 00 - 01 Receve Note Off OFF, ON depend on the note 0a 1 00 - 01 Receive Note On OFF, ON 01 0b 1 00 - 7F Filter Cutoff Frequency 0...127 7F 0c 1 00 - 7F Filter Resonance 0...63 10 0d 1 00 - 7F EG Attack Rate 0...127 7F 0e 1 00 - 7F EG Decay1 Rate 0...127 40

0f 1 00 - 7F EG Decay2 Rate 0...127 40

TOTAL SIZE 10 rr = NOTE NUMBER(0D - 5B)

YAMAHA [ Music Synthesizer ] Date :27-DEC-2000

Model S03 MIDI Implementation Chart Version : 1.0

TransmittedFunction... Recognized Remarks

Basic Channel

Mode

Default Changed

Default Messages Altered

Note Number : True voice

Velocity

Note ON Note OFF

After Touch

Key's Ch's

Pitch Bend

Control Change

1,5,7,10,11

0,32

6,38 64-67 71-74

91,93,94

96-97 98-99

100-101

1-31,33-95

1 - 16 1 - 16

**************

0 - 127 **************

Ø 9nH,v=1-127 ˛ 9nH,v=0

˛ Ø *3

Ø ˛ ˛ ˛ ˛ ˛ ˛ ˛ ˛ ˛ Ø

1 - 16

Memorized

1 - 16

Memorized

1 - 4(m=1) *2

0 - 127 0 - 127

Ø 9nH,v=1-127

Ø *1 Ø *1

Ø 0-24 semi *1

Ø *1 Ø *1 Ø *1 Ø *1 Ø *1 Ø *1 Ø *1 Ø *1 Ø *1 Ø *1 Ø *1

Bank Select Data Entry Sound Controller

Portamento Cntrl Effect Depth RPN Inc,Dec NRPN LSB,MSB RPN LSB,MSB Assignable Cntrl

Prog Change : True #

System Exclusive

Common : Song Pos. : Song Sel. : Tune

System : Clock Real Time : Commands

: All Sound Off Aux :

Reset All Cntrls : Local ON/OFF Mes- : All Notes OFF sages: Active Sense : Reset

Notes:

*1 receive if switch is on.

0 - 127

**************

˛ ˛

˛ ˛ ˛ ˛ Ø ˛

Ø 0 - 127

0 - 127

˛ ˛

Ø (120,126,127) Ø (121)

Ø (123-125)

Ø ˛

*2 m is always treated as "1" regardless of its value. *3 though the keyboard itself has no after touch, after touch data can be transmitted from MW and FC when after touch is assigned to the controllers.

Mode 1 : OMNI ON , POLY Mode 2 : OMNI ON ,MONO Mode 3 : OMNI OFF, POLY Mode 4 : OMNI OFF,MONO

Ø : Yes ˛ : No

documentation manual, user maintenance, brochure, user reference, pdf manual

This file has been downloaded from:

User Manual and User Guide for many equipments like mobile phones, photo cameras, monther board, monitors, software, tv, dvd, and othes..

Manual users, user manuals, user guide manual, owners manual, instruction manual, manual owner, manual owner's, manual guide,

manual operation, operating manual, user's manual, operating instructions, manual operators, manual operator, manual product,

Yamaha Audio S03 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

S03 Normal Voice List

XG Normal Voice List

Drum Voice List

Wave List

Original Kit List

Multi List

Control List

Effect Type List

Effect Parameter List

Effect Data Assign Table

MIDI Data Format

MIDI Data Table
