Yamaha Audio RX-V2095 User Manual

OWNER’S MANUAL

MODE D’EMPLOI

OWNER’S MANUAL

MODE D’EMPLOI

NATURAL SOUND AV RECEIVER

AMPLI-TUNER AUDIO-VIDEO

U C A

NATURAL SOUND AV RECEIVER RX V209S

CINEMA DSP

7ch

VOLUME

INPUT SELECTOR

INPUT MODE

–dB

BASS TREBLE BALANCE

VCR 2

VIDEO AUX

REC OUT/ZONE 2

VCR 1

TV/DBS

PHONO

TUNER

DVD/LD

SOURCE/REMOTE

TAPE/MD

VIDEO AUX

EFFECT

A/B/C/D/E

PRESET STATIONS

TUNING

EXT. DECODER

l0l

STANDBY/ON

PHONES

BASS

EXTENSION

TONE

BYPASS

SPEAKERS

PROGRAM

EDIT

FM/AM

MEMORY

PRESET/TUNING

TUNING MODE

MAN’L/AUTO FM AUTO/MAN’L MONO

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF

ELECTRIC SHOCK, DO NOT REMOVE

COVER (OR BACK). NO USER-SERVICEABLE

PARTS INSIDE. REFER SERVICING TO

QUALIFIED SERVICE PERSONNEL.

IMPORTANT

Please record the serial number of your unit in the space below.

Model: Serial No.:

The serial number is located on the rear of the unit. Retain this Owner’s Manual in a safe place for future reference.

SAFETY INSTRUCTIONS

Explanation of Graphical Symbols

•

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert you to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert you to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.

1 Read Instructions – All the safety and operating

instructions should be read before the unit is operated.

2 Retain Instructions – The safety and operating instructions

should be retained for future reference.

3 Heed Warnings – All warnings on the unit and in the

operating instructions should be adhered to.

4 Follow Instructions – All operating and other instructions

should be followed.

5 Water and Moisture – The unit should not be used near

water – for example, near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool, etc.

6 Carts and Stands – The unit should be used only with a

cart or stand that is recommended by the manufacturer.

6A A unit and cart combination should be

moved with care. Quick stops, excessive force, and uneven surfaces may cause the unit and cart combination to overturn.

7 Wall or Ceiling Mounting – The unit

should be mounted to a wall or ceiling only as recommended by the manufacturer.

8 Ventilation – The unit should be situated so that its

location or position does not interfere with its proper ventilation. For example, the unit should not be situated on a bed, sofa, rug, or similar surface, that may block the ventilation openings; or placed in a built-in installation, such as a bookcase or cabinet that may impede the flow of air through the ventilation openings.

9 Heat – The unit should be situated away from heat

sources such as radiators, stoves, or other appliances that produce heat.

10 Power Sources – The unit should be connected to a power

supply only of the type described in the operating instructions or as marked on the unit.

11 Power-Cord Protection – Power-supply cords should be

routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the unit.

12 Cleaning – The unit should be cleaned only as

recommended by the manufacturer.

13 Nonuse Periods – The power cord of the unit should be

unplugged from the outlet when left unused for a long period of time.

14 Object and Liquid Entry – Care should be taken so that

objects do not fall into and liquids are not spilled into the inside of the unit.

15 Damage Requiring Service – The unit should be serviced

by qualified service personnel when:

A. The power-supply cord or the plug has been

damaged; or

B. Objects have fallen, or liquid has been spilled into the

unit; or

C. The unit has been exposed to rain; or D. The unit does not appear to operate normally or

exhibits a marked change in performance; or

E. The unit has been dropped, or the cabinet damaged.

16 Servicing – The user should not attempt to service the unit

beyond those means described in the operating instructions. All other servicing should be referred to qualified service personnel.

17 Power Lines – An outdoor antenna should be located away

from power lines.

18 Grounding or Polarization – Precautions should be taken

so that the grounding or polarization is not defeated.

19 For US customers only:

EXAMPLE OF ANTENNA GROUNDING

MAST

GROUND CLAMP

ANTENNA LEAD IN WIRE

ANTENNA DISCHARGE UNIT (NEC SECTION 810–20)

GROUNDING CONDUCTORS (NEC SECTION 810–21)

GROUND CLAMPS

POWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ART 250. PART H)

ELECTRIC SERVICE EQUIPMENT

NEC – NATIONAL ELECTRICAL CODE

Outdoor Antenna Grounding – If an outside antenna is connected to this unit, be sure the antenna system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA 70, provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.

Note to CATV system installer:

This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.

FCC INFORMATION (for US customers only)

English

1. IMPORTANT NOTICE : DO NOT MODIFY THIS UNIT!

This product, when installed as indicated in the instructions contained in this manual, meets FCC requirements. Modifications not expressly approved by Yamaha may void your authority, granted by the FCC, to use the product.

2. IMPORTANT : When connecting this product to accessories and/or another product use only high quality shielded cables. Cable/s supplied with this product MUST be used. Follow all installation instructions. Failure to follow instructions could void your FCC authorization to use this product in the USA.

3. NOTE : This product has been tested and found to comply with the requirements listed in FCC Regulations, Part 15 for Class “B” digital devices. Compliance with these requirements provides a reasonable level of assurance that your use of this product in a residential environment will not result in harmful interference with other electronic devices.

This equipment generates/uses radio frequencies and, if not installed and used according to the instructions found in the users manual, may cause interference harmful to the operation of other electronic devices.

Compliance with FCC regulations does not guarantee that interference will not occur in all installations. If this product is found to be the source of interference, which can be determined by turning the unit “OFF” and “ON”, please try to eliminate the problem by using one of the following measures:

Relocate either this product or the device that is being affected by the interference.

Utilize power outlets that are on different branch (circuit breaker or fuse) circuits or install AC line filter/s.

In the case of radio or TV interference, relocate/reorient the antenna. If the antenna lead-in is 300 ohm ribbon lead, change the lead-in to coaxial type cable.

If these corrective measures do not produce satisfactory results, please contact the local retailer authorized to distribute this type of product. If you can not locate the appropriate retailer, please contact Yamaha Electronics Corp., U.S.A. 6660 Orangethorpe Ave, Buena Park, CA

90620. The above statements apply ONLY to those products

distributed by Yamaha Corporation of America or its subsidiaries.

We Want You Listening For A Lifetime

YAMAHA and the Electronic Industries Association’s Consumer Electronics Group want you to get the most out of your equipment by playing it at a safe level. One that lets the sound come through loud and clear without annoying blaring or distortion – and, most importantly, without affecting your sensitive hearing.

Since hearing damage from loud sounds is often undetectable until it is too late, YAMAHA and the Electronic Industries Association’s Consumer Electronics Group recommend you to avoid prolonged exposure from excessive volume levels.

Congratulations!

You are the proud owner of a Yamaha Digital Sound Field Processing (DSP) System—an extremely sophisticated audio component. The DSP system takes full advantage of Yamaha’s undisputed leadership in the field of digital audio processing to bring you a whole new world of listening experiences. Follow the instructions in this manual carefully when setting up your system, and the DSP system will sonically transform your room into a wide range of listening environments—anything from a famous concert hall to a cozy jazz club. In addition, you get incredible realism from most of surround-sound encoded video sources available in the market using the builtin Dolby Pro Logic Surround Decoder, Dolby Digital Decoder and DTS Decoder.

Seven built-in channels of amplification on this model mean that no additional amplifiers are required to enjoy advanced digital sound field processing.

Rather than tell you about the wonders of digital sound field processing, however, let’s get right down to the business of setting up the system and trying out its many capabilities. Please read this operation manual carefully and store it in a safe place for later reference.

CONTENTS

English

SAFETY INSTRUCTIONS

........................................... Inside of the Front Cover

CAUTION .................................................................. 2

INTRODUCTION ....................................................... 3

Features .................................................................... 3

What’s DSP?............................................................. 4

GETTING STARTED ................................................ 7

Getting started.......................................................... 7

Unpacking.............................................................. 7

Opening and closing the front cover ...................... 7

Installing batteries in the remote controller ........... 8

Notes about the remote controller.......................... 8

Controls and their functions................................... 9

Front panel............................................................. 9

Display panel........................................................ 11

BASIC OPERATION ............................................... 35

Playing a source .................................................... 35

Recording a source to tape (or MD) or dubbing

from tape (or MD) to tape (or MD)......................... 40

Sound control......................................................... 42

Tuning ..................................................................... 43

Basic operation ................................................... 43

Preset tuning........................................................ 44

Using digital sound field processor (DSP) ......... 48

Playing a source with an effect of the digital

sound field processor (DSP)................................ 48

Adjusting output level of the center, right rear,

left rear, front effect speakers and subwoofer...... 51

Brief overview of digital sound field programs...... 53

ADVANCED FEATURES ....................................... 58

SET MENU mode ................................................... 58

Creating your own sound fields .......................... 62

Setting the SLEEP timer ....................................... 67

PREPARATION ...................................................... 12

Speaker setup......................................................... 12

Connections ........................................................... 14

Audio/video source equipment ............................ 14

Speakers ............................................................. 22

Antennas ............................................................. 25

Plugging in this unit ............................................. 27

On screen display.................................................. 28

Selecting the output modes

(“SET MENU” mode) ............................................. 29

Speaker balance adjustment ................................ 32

REMOTE CONTROLLER ....................................... 68

Basic operation (Cover is open) .......................... 68

Using the “learning-capable” keys

(Cover is open)....................................................... 70

Using OPERATION CONTROL keys

(Cover is closed) ................................................... 72

Macro operations (Cover is closed) .................... 74

Methods of learning and clearing functions ....... 76

CUSTOM INSTALLATION GUIDE ......................... 79

Connections .......................................................... 79

ZONE 2 remote controller...................................... 80

TROUBLESHOOTING ............................................ 81

SPECIFICATIONS .................................................. 84

REAR

SWITCHED

AC OUTLETS

IMPEDANCE SELECTOR

I00W MAX. TOTAL

I20V 80Hz

CENTER : 4ΩMIN. / SPEAKER FRONT :6Ω

MIN. / SPEAKER

REAR:4Ω

MIN. / SPEAKER

MAIN A OR B:4Ω

MIN. / SPEAKER

A B :8Ω

MIN. / SPEAKER

CENTER : 8ΩMIN. / SPEAKER FRONT :8Ω

MIN. / SPEAKER

REAR:8Ω

MIN. / SPEAKER

MAIN A OR B:8Ω

MIN. / SPEAKER

A B :I 6Ω

MIN. / SPEAKER

( SURROUND )

SET BEFORE POWER ON

MAIN

CAUTION : Read this before operating your unit.

1. To assure the finest performance, please read this manual

carefully. Keep it in a safe place for future reference.

2. Install this unit in a cool, dry, clean place – away from

windows, heat sources, sources of excessive vibration, dust, moisture and cold. Avoid sources of humming (transformers, motors). To prevent fire or electrical shock, do not expose the unit to rain or water.

3. Never remove the unit cover. Contact your dealer if an

object falls inside the unit.

4. Do not use force on switches, controls or connection wires.

When moving the unit, first disconnect the power plug and the wires connected to other equipment. Never pull on the wires themselves.

5. The openings on the unit cover assure proper ventilation of

the unit. If these openings are obstructed, the temperature inside the unit will rise rapidly. Therefore, avoid placing objects against these openings, and install the unit in a well-ventilated area to prevent fire and damage.

Be sure to allow a space of at least 10 cm behind, 20 cm on the both sides and 30 cm above the top panel of the unit to prevent fire and damage.

6. The voltage used must be the same as that specified on

this unit. Using this unit with a higher voltage than specified is dangerous and may result in fire or other accidents. YAMAHA will not be held responsible for any damage resulting from use of this unit with a voltage other than specified.

7. Digital signals generated by this unit may interfere with

other equipment such as tuners, receivers or TVs. Move this unit farther away from such equipment if interference is observed.

8. Always set the VOLUME control to “–

the audio source play. Increase the volume gradually to an appropriate level after playback has been started.

9. Do not attempt to clean the unit with chemical solvents;

this might damage the finish. Use a clean, dry cloth.

10.Be sure to read the “TROUBLESHOOTING” section

regarding common operating errors before concluding that the unit is faulty.

11.When not planning to use this unit for long periods of time,

disconnect the AC power plug from the wall outlet.

12.To prevent lightning damage, disconnect the AC power

plug and antenna cable when there is an electrical storm.

13.Grounding or polarization – Precautions should be taken

so that the grounding or polarization of an appliance is not defeated.

14.Do not connect an audio unit to the AC outlet on the rear

panel if the equipment requires more power than the outlet is rated to provide.

15.Voltage Selector (China and General Models only)

The voltage selector on the rear panel of this unit must be set for your local main voltage BEFORE plugging into the AC main supply. Voltages are 110/120/220/240 V AC, 50/60 Hz.

” before starting

∞

This unit is not disconnected from the AC power source as long as it is connected to the wall outlet, even if this unit itself is turned off. This state is called the standby mode. In this mode, this unit is designed to consume a small amount of power.

FREQUENCY STEP switch (China and General Models only)

Because the interstation frequency spacing differs in different areas, set the FREQUENCY STEP switch (located at the rear) according to the frequency spacing in your area. Before setting this switch, disconnect the AC power plug of this unit from the AC outlet.

For Canadian Customers

To prevent electric shock, match wide blade of plug to wide slot and fully insert.

This Class B digital apparatus complies with Canadian ICES–003.

WARNING Do not change the IMPEDANCE SELECTOR switch setting while the power to this unit is on, otherwise this unit may be damaged.

IF THIS UNIT FAILS TO TURN ON WHEN THE STANDBY/ON SWITCH IS PRESSED:

The IMPEDANCE SELECTOR switch may not be set to either end. If so, set the switch to either end when this unit is in the standby mode.

(U.S.A. model)

IMPEDANCE SELECTOR

Features

INTRODUCTION

English

7 Channel Power Amplification

Main: 100W + 100W (8Ω) RMS Output

Power, 0.02% THD, 20–20,000 Hz

Center: 100W (8Ω) RMS Output Power,

0.02% THD, 20–20,000 Hz

Rear: 100W + 100W (8Ω) RMS Output

Power, 0.02% THD, 20–20,000 Hz

Front effect:

25W + 25W (8Ω) RMS Output Power, 0.05% THD, 1 kHz

Multi-Mode Digital Sound Field Processing

●

Digital Sound Field Processor (DSP)

●

Dolby Digital Decoder

●

Dolby Pro Logic Surround Decoder

●

DTS Decoder

●

CINEMA DSP: Theater-like Sound Experience by the Combination of YAMAHA DSP Technology and Dolby Digital, Dolby Pro Logic or DTS

●

Automatic Input Balance Control for Dolby Pro Logic Surround

●

Test Tone Generator for Easier Speaker Balance Adjustment

●

Speaker Output Mode Selection Capability for the Most Suitable Use of Your Speaker System

Sophisticated FM/AM Tuner

● 40-Station Random Access Preset Tuning

● Automatic Preset Tuning

● Preset Station Shifting Capability (Preset

Editing)

● IF Count Direct PLL Synthesizer Tuning

System

Others

●

“SET MENU” Mode which Provides You with 8 Titles of Setting Changes and Adjustments for Optimizing This Unit for Your Audio/Video System

● BASS EXTENSION Button for Reinforcing

Bass Response

● On Screen Display Function Helpful in

Controlling This Unit

●

REC OUT Selector which is Independent of Input Source Selection

● SLEEP Timer

●

OPTICAL and COAXIAL Digital Audio Signal Terminals

6 Channel External Decoder Input for Other

●

Future Formats

● Video Signal Input/Output Capability

(Including S Video Connections)

●

Multi-Functional “Learning” Capability

●

Dual-Room Audio/Video System Setup Capability (Custom Installation)

remote controller

with

INTRODUCTION

What’s DSP?

Introduction

Welcome to the exciting world of digital home entertainment. This unit is one of the most complete and advanced AV receiver available. Some of the more advanced features may not be familiar to you, but they are easy to use. State-of-the-art technologies such as Dolby Digital and Digital Theater Systems (DTS) may be new to your home, but you have probably experienced the amazing realism they bring to feature films in theaters around the world.

Digital Sound Field Processing

Technological advances in sound reproduction over the last 30 years have enhanced the listening experience with improved clarity, precision and power. However, something has still been missing: The atmosphere and acoustic ambiance of the public venue. Our Yamaha engineers have extensively researched the nature of sound acoustics and the way sound reflects inside a room. We sent these engineers to famous theaters and concert halls around the world to measure the acoustics of those venues with sophisticated microphones. The data they collected is used to recreate these environments in digital sound fields. Some of these digital sound fields are created using data measured directly at the original venue; others are created from combinations of data to form unique environments for specific purposes.

To make the listening experience even more enjoyable, this unit includes a number of exclusive, digitally created listening environments known as digital sound fields. Choosing a sound field program is like transporting yourself to such venues as an outdoor arena, a European church, or a cozy jazz club. Take some time now to read more about these features and enjoy the new experiences this unit brings to your home theater.

Of course, that only solves half of the problem. These engineers have no way of knowing the acoustics of your listening room, so we’ve made it possible for you to adjust the various parameters of this data to tailor each virtual venue to your taste. You can use these sound fields to enhance any source and in combination with any of the following surround sound technologies. Some are designed especially for music, and some especially for movies.

Dolby Pro Logic Surround

Dolby Pro Logic Surround has been used in movie theaters since the mid-seventies. It has also been available in home entertainment systems since the late eighties and continues to be a popular format for home theater systems. It uses four discrete channels and five speakers to reproduce realistic and dynamic sound effects: two main channels (left and right), a center channel for dialog, and a rear channel for special sound effects. The rear channel reproduces sound within a narrow frequency range.

Most video tapes and laser discs include Dolby Pro Logic Surround encoding as do many TV and cable broadcasts. The Dolby Pro Logic Surround decoder built into this unit employs a digital signal processing system that stabilizes each channel for even more accurate sound positioning than is available with standard analog processors.

Dolby Digital

INTRODUCTION

English

Dolby Digital is the next level of Dolby Surround sound system developed for 35 mm film-movies by employing low bit-rate audio coding.

Dolby Digital is a digital surround sound system that provides completely independent multi-channel audio to you. Dolby Digital provides five full range channels in what is sometimes referred to as a “3/2” configuration: three front channels (left, center and right), and two surround channels. A sixth bass-only effect channel is also provided for output of LFE (low frequency effect), or low bass effects that are independent of other channels. (This is called the “subwoofer channel” or “LFE channel”.) This channel is counted as 0.1, thus giving rise to the term 5.1 channels in total.

Compared to Dolby Pro Logic that is referred to a “3/1” system (left front, center, right front and just one surround channel), Dolby Digital features two surround channels, called stereo or split surrounds, each offering the same full range fidelity as the three front channels.

By using the built-in Dolby Digital decoder, you can experience the dramatic realism and impact of Dolby Stereo Digital theater sound in your home. Wide dynamic range of sound reproduced by the five full range channels and precise sound orientation by the digital sound processing presents listeners much excitement and realism that has never been experienced before.

Dolby Digital forms 5.1 channels as mentioned left, and moreover, it can also form fewer channels, for example 2 channel stereo and monaural. You may be able to find some 2 channel stereo and/or monaural sources encoded with Dolby Digital in the market.

Laserdisc and DVD are home audio formats that could benefit from Dolby Digital. In the near future, Dolby Digital will also be applied to DBS, CATV and HDTV. The ongoing release of Dolby Stereo Digital theatrical films now underway will provide an immediate source of Dolby Digital encoded video software.

Manufactured under license from Dolby Laboratories Licensing Corporation. “DOLBY”, “AC-3”, “Pro Logic”, and the double-D symbol are trademarks of Dolby Laboratories Licensing Corporation. Copyright 1992 Dolby Laboratories, Inc. All rights reserved.

DTS Digital Surround

DTS (Digital Theater Systems) system was developed to replace analog soundtracks of movies with six discrete channels of digital soundtracks, and now, it is installed in many theaters around the world. The DTS digital playback system changed the way we experienced movies in theaters with six discrete channels of superb digital audio.

The DTS technology, through intense research and development, made it possible to deliver a similar encode/decode discrete technology to home audio surroundsound entertainment. The DTS Digital Surround is an encode/decode system which delivers six channels of master-quality, 20-bit audio; technically

5.1 channels, which means 5 full-range (left, center, right and two surround) channels, plus a subwoofer (LFE) channel (as “0.1”). It is compatible with the 5.1 speaker configurations that are currently available for home theater systems

The DTS Digital Surround algorithm is designed to encode the six channels of 20-bit audio onto some laserdiscs, compact discs and DVDs with considerably less data-compression.

By using the DTS decoder built into this unit, you can experience the dramatic realism and impact of the DTS installed theater’s high quality sound in your home.

Laserdisc, compact disc and DVD are home audio format within which DTS can represent its high quality multi-channel audio. (In addition to movies on laserdiscs, many exciting new multi-channel music recordings will also become available in the form of DTS-encoded compact discs.)

Manufactured under license from Digital Theater Systems, Inc. US Pat. No. 5,451,942 and other world-wide patents issued and pending. “DTS”, “DTS Digital Surround”, are trademarks of Digital Theater Systems, Inc. Copyright 1996 Digital Theater Systems, Inc. All Rights Reserved.

CINEMA DSP

INTRODUCTION

CINEMA DSP: Dolby Surround + DSP / DTS + DSP

The Dolby Surround sound and DTS systems show their full ability in a large movie theater, because movie sounds are originally designed to be reproduced in a large movie theater that uses a multitude of speakers. Trying to create a sound environment similar to that of a movie theater in your home is difficult because of the room size, material inside the walls, the number of speakers, and so on. In other words, your listening room is very different from a movie theater.

Dolby Pro Logic + 2 Digital Sound Fields

Digital sound fields are created on the presence side and the rear surround side of the Dolby Pro Logic Surrounddecoded sound field respectively. They create a wide acoustic environment and emphasize surround-effect in the room, letting you feel much presence as if you were watching a movie in a popular Dolby Stereo theater.

This combination is available when the digital sound field program No. 8, 9, 10, 11 or “PRO LOGIC/Enhanced” of No. 12 is selected, and the input signal of the source is analog, PCM audio or encoded with the Dolby Digital in 2-channels.

However, Yamaha DSP technology allows you to create nearly the same sound experience as that of a large movie theater in your home by compensating for the lack of presence and dynamics in the listening room with original digital sound fields combined with Dolby Surround or DTS Digital Surround sounds.

The YAMAHA “CINEMA DSP” logo indicates those programs that are created by the combination of YAMAHA DSP technology and Dolby Surround or DTS.

Dolby Digital or DTS + 3 Digital Sound Fields

Digital sound fields are created on the presence side and the independent left and right surround sides of the Dolby Digital-decoded or the DTS-decoded sound field respectively. They create a wide acoustic environment and much surround effect in the room without losing high channel separation. With wide dynamic range of Dolby Digital or DTS sound, this sound field combination lets you feel as if you were watching a movie in the newest Dolby Stereo Digital theater or DTS installed theater. This is the most ideal home theater sound at the present time.

This combination is available when the digital sound field program No. 8, 9, 10, 11 or “DOLBY DIGITAL (or DTS DIGITAL SUR.)/Enhanced” of No. 12 is selected, and the input signal of the source is encoded with the Dolby Digital (except in 2-channels) or encoded with the DTS.

GETTING STARTED

Getting started

Unpacking

Carefully remove this unit and accessories from the box. You should find the unit itself and the following accessories.

English

Remote controller (for the main room)

ZONE 2 Remote controller

Indoor FM Antenna

AM Loop Antenna

Antenna adapter (U.S.A. and Canada models only)

User function stickers

Batteries (size AA, LR6, UM-3)

Opening and closing the front cover

Close the front cover whenever the controls inside the panel are not used.

To open the front cover

To close the front cover

30°

GETTING STARTED

Installing batteries in the remote controller

Since the remote controller will be used for many of this unit’s control operations, you should begin by installing the supplied batteries.

1. Turn the remote controller over and slide the battery

compartment cover in the direction of the arrow.

2. Insert the batteries (AA, LR6, UM-3 type) according to the

polarity markings on the inside of the battery compartment.

3. Close the battery compartment cover.

Remote controller for the main room

Notes about the remote controller

Battery replacement

If you find that the remote controller must be used closer to the main unit, the batteries are weak. Replace both batteries with new ones.

Notes

●

Use only AA, R6, UM-3 batteries. (It is recommended to use an LR6 type to use the remote controller for a long period of time.)

●

Be sure the polarities are correct. (See the illustration inside the battery compartment.)

●

Remove the batteries if the remote controller is not used for an extended period of time.

●

If batteries leak, dispose of them immediately. Avoid touching the leaked material and contact with clothing, etc. Clean the battery compartment thoroughly before installing new batteries.

Remote controller operation range

ZONE 2 remote controller

Note on the remote controller for the main room

After the batteries are inserted, press the RESET button before using the remote controller.

RESET button

Remote control sensor

Within approximately 6 m (19.7 feet)

Notes

●

The area between the remote controller and the main unit must be clear of large obstacles.

●

Do not expose the remote control sensor to strong lighting, in particular, an inverter type fluorescent lamp. Otherwise, the remote controller may not work properly. If necessary, position the main unit away from direct lighting.

Controls and their functions

NATURAL SOUND AV RECEIVER RX V2095

CINEMA DSP

7ch

VOLUME

INPUT SELECTOR

INPUT MODE

–dB

PHONES

BASS

EXTENSION

BASS TREBLE BALANCE

TONE

BYPASS

VCR 2

VIDEO AUX

REC OUT/ZONE 2

VCR 1

TV/DBS

PHONO

TUNER

DVD/LD

SOURCE/REMOTE

TAPE/MD

VIDEO AUX

EFFECT

A/B/C/D/EA

SPEAKERS

PROGRAM

PRESET STATIONS

TUNING

EXT. DECODER

STANDBY/ON

l0l

EDIT

FM/AM

MEMORY

PRESET/TUNING TUNING MODE

MAN’L/AUTO FM AUTO/MAN’L MONO

G ICJ

23 4

87 0 A9 D FH

EDIT

FM/AM

MEMORY

PRESET/TUNING TUNING MODE

MAN’L/AUTO FM AUTO/MAN’L MONO

K LNM

Front panel

GETTING STARTED

English

For the remote controller, refer to pages 68 to 69.

1 STANDBY/ON switch

Press this switch to turn on the power. Press this switch again to set this unit in the standby mode. * A click from the switch and the initial rotation of the built-in

fan will be heard when the power is turned on. Standby mode

This unit is still using a small amount of power in this mode in order to be ready to receive infrared-signals from the remote controller.

2 Remote control sensor

Receives signals from the remote controller.

3 Display panel

Displays a variety of information. (Refer to page 11 for details.)

4 INPUT MODE button

Press this button to select how input signals are received from sources that output two or more types of signals. The “AUTO”, “DTS” and “ANALOG” modes are available. Refer to page 38 for details.

<Australia, China, Singapore and General models only>

The “AUTO”, “D.D.RF”, “DTS”, “DGTL” and “ANALOG” modes are available for DVD/LD sources.

5 INPUT SELECTOR

Turn this knob to select the input source. The selected source will be shown on the display.

6 Master VOLUME control

Simultaneously controls volume for all output sounds; front effect, main, rear, center and subwoofer. (The REC OUT level is not affected.) * The indicator on the master VOLUME control will flash when

7 SPEAKERS switches

Press the switch A or B (or both) for the main speakers you will use to select them. Press the switch for the main speakers you will not use again to cancel them. On the display panel, “SPEAKERS A” and/or “SPEAKERS B” will be illuminated, depending on which main speakers are being selected.

the volume is decreased by pressing the MUTE key on the remote controller.

PHONES

GETTING STARTED

8 PHONES jack

Headphones can be plugged into this jack for private listening. You can listen to the sound to be output from the main speakers through headphones. When listening with headphones privately, press both SPEAKERS A and B switches to cancel both of the main speakers A and B, and turn off the digital sound field processor by pressing the EFFECT button so that no DSP program name is illuminated on the display panel.

9 PROGRAM selector button

Press this button in the or direction to select a digital sound field processing program.

0 BASS EXTENSION button

Press this button inward (ON) to boost the bass frequency response at the main left and right channels while maintaining overall tonal balance. This function is effective for reinforcing the bass frequencies when a subwoofer is not used.

A TONE BYPASS button

Press this button inward (ON) to bypass the tone (BASS and TREBLE) control circuitry. This function is used for outputting

pure sound and checking the tone control settings. The tone control circuitry can be used when this button is released outward (OFF).

B EFFECT button

Press this button to turn on and off the output from the center, rear and front effect speakers. The sound becomes normal 2channel when this function is turned off. However, this does not apply to Dolby Digital or DTS. The signals at all channels will be distributed to the main channels and output from the main speakers, even if the output from the center, rear and front effect speakers are turned off, when Dolby Digital or DTS is decoded.

C BASS and TREBLE controls

Rotate these knobs to adjust the low and high frequency response for the left and right main channels only.

D EXT. DECODER button

Press this button to select the input signals from the EXTERNAL DECODER INPUT terminals as the input source. This function takes priority over the INPUT SELECTOR setting. “EXT. DECODER IN” will be illuminated on the display panel. The source selected with the INPUT SELECTOR knob becomes the current input source when “EXT. DECODER IN” is not illuminated on the display panel.

G REC OUT/ZONE 2 selector

Rotate this knob to select the source for recording to an MD recorder (or tape deck) or VCR. This setting is independent of the INPUT SELECTOR setting, except when the REC OUT/ZONE 2 selector is set to the SOURCE/REMOTE position. Then the INPUT SELECTOR is used to select the source for recording to the MD recorder (or tape deck) or VCR.

For a user who made up a dual-room audio/video system with this unit:

The setting of the REC OUT/ZONE 2 selector controls the input source for the second room. However, when this selector is set to the SOURCE/REMOTE position, the ZONE 2 remote controller is used to select the input source for the second room. Refer to page 80.

H PRESET STATIONS/TUNING button

This button is used for the PRESET STATIONS function when “ : ” is illuminated on the display, and the TUNING function when “ : ” is not illuminated. The following explains these functions in detail.

PRESET STATIONS :

Selects a preset station number (from 1 to 8). Press the side to select a higher preset station number. Press the side to select a lower preset station number.

TUNING :

Used for tuning. Press the side to tune in to a higher frequency, and press the side to tune in to a lower frequency.

I VIDEO AUX terminals

Connect an auxiliary video or audio input source unit such as a camcorder to these terminals. A video unit with a S video output terminal can be connected to the S VIDEO terminal to obtain a high resolution picture. The source can be selected with the INPUT SELECTOR and REC OUT/ZONE 2 selector.

J Front cover

Refer to page 7 on how to open and close the front cover.

K PRESET/TUNING (EDIT) button

Press this button to alternately illuminate and turn off “PRESET” on the display panel function of the PRESET STATIONS/TUNING button. This button is also used to exchange the places of two preset stations with each other.

. This button switches the

L FM/AM button

Press this button to switch the reception band between FM and AM.

M MEMORY (MAN’L/AUTO FM) button

Use this button to enter a station to memory. Refer to the section “Manual preset tuning” on page 44 for details. Hold down this button for more than 3 seconds to start automatic preset tuning. Refer to page 46 for details.

E BALANCE control

This knob controls the sound from the main speakers only. The balance of the output volume to the left and right main speakers can be adjusted to compensate for sound imbalances caused by the speaker location or listening room conditions.

F A/B/C/D/E button

Press this button to select a group (A–E) of preset stations.

N TUNING MODE (AUTO/MAN’L MONO) button

Press this button to switch the tuning mode between automatic and manual. To select the automatic tuning mode, press this button so that the “AUTO” indicator is illuminated on the display. To select the manual tuning mode, press this button so that the “AUTO” indicator is not illuminated.

Display panel

DIGITAL

PRO LOGIC

DSP

SPEAKERS

TAPE/MD

TUNER

PHONO

DVD/LD

TV/DBS

VCR 1

VCR 2

V-AUX

MEMORY

STEREO AUTO

SLEEP

2 351

768 90

SPEAKERS A

TAPE/MD

TUNER

PHONO

DVD/LD

TV/DBS

VCR 1

VCR 2

V-AUX

MEMORY

STEREO AUTO

GETTING STARTED

English

1 indicators

Either of the “dts” indicators will be illuminated when the built-in DTS decoder is turned on. A red “dts” indicator will be illuminated when playing a compact disc or laserdisc encoded with DTS. An orange “dts” indicator will be illuminated when playing a DVD encoded with DTS. An orange “dts” indicator may be illuminated when playing a laserdisc encoded with DTS after a video-CD or DVD on a DVD/LD combi-player.

2 Multi-information display

This display shows the current DSP program and the status of adjustments and setting changes. Several statuses can be viewed at one time. The current station frequency and band (AM or FM) will also appear when the tuner source input mode is selected.

Indicates the signal level of the received station. If multipath interference is detected, the indication decreases.

3 MEMORY indicator

A flashing MEMORY indicator means a station can be saved, as explained in the following: Press the MEMORY button. The MEMORY indicator will flash about 5 seconds. While the indicator is flashing, program the displayed station to memory by using the A/B/C/D/E and PRESET STATIONS/TUNING buttons.

4 AUTO indicator

This indicator will be illuminated during the automatic tuning mode.

5 Input source indicators

One of the arrows for these indicators will be illuminated depending on which source is selected.

6 DIGITAL and PRO LOGIC indicators

The DIGITAL indicator will be illuminated when the built-in Dolby Digital decoder is on and the signals of the source encoded with Dolby Digital are not 2-channels. The PRO LOGIC indicator will be illuminated when the built-in Dolby Pro Logic Surround Decoder is on.

7 DSP indicator

This indicator will be illuminated when the built-in digital sound field processor is on.

8 SPEAKERS A/B indicators

One of these indicators will be illuminated depending on which main speakers are selected. Both indicators will be illuminated when both speakers A and B are selected.

9 STEREO indicator

This indicator will be illuminated when an FM stereo broadcast with sufficient signal strength is received.

0 SLEEP indicator

This indicator will be illuminated when the built-in SLEEP timer is on.

PREPARATION

Speaker setup

m Setting up your speaker system

This unit has been designed to provide the best sound field quality with a full seven-speaker system setup, using a pair of main speakers to output main source sounds, two extra pairs of effect speakers to generate the sound field plus one center speaker for dialog. We therefore recommend that you use a seven-speaker setup. A four-speaker system using only one pair of effect speakers for the sound field will still provide impressive ambience and effects, however, and may be a good way to begin with this unit. You can always upgrade to the full seven-speaker system later. In the 4 or 5 speaker system, the Digital Sound Field Processing is still performed, but the main speakers are used for both the main channels and the front effect channels.

Use of the center dialog speaker is recommended

When playing back a source with Dolby Pro Logic decoded, or playing back a source which contains center-channel signals with Dolby Digital or DTS decoded, dialog, vocals etc. are output from the center channel. Therefore, if you want to maximize the performance of your Audio/Video home theater system, it is recommended that you use a center channel speaker.

If, for some reason, it is not practical to use a center speaker, it is possible to enjoy the movie without it. Best results, however, are obtained with the full system.

Use of a subwoofer expands your sound field

It is also possible to further expand your system with the addition of a subwoofer and amplifier. The use of a subwoofer is effective not only for reinforcing bass frequencies from any or all channels, but also for reproducing signals at the subwoofer channel with high fidelity during playing back a source with Dolby Digital or DTS decoded. You may wish to choose the convenience of a Yamaha Active Servo Processing Subwoofer System, which has its own built-in power amplifier.

m Speakers and speaker placement

Your full seven-speaker system will require three speaker pairs: the MAIN SPEAKERS (your normal stereo speakers), the FRONT EFFECT SPEAKERS and the REAR SPEAKERS, plus the CENTER SPEAKER. You may also be using a SUBWOOFER.

The MAIN SPEAKERS should be high performance models and have enough power handling capacity to accept the maximum output of your audio system. Other speakers do not have to be equal to the MAIN SPEAKERS. For precise sound localization, however, it is ideal to use high performance models that can reproduce sounds in full range for the CENTER SPEAKER, the FRONT EFFECT and REAR SPEAKERS.

Place the MAIN SPEAKERS in the ordinary position. Place the FRONT EFFECT SPEAKERS further apart than the MAIN SPEAKERS, on either side of and 0.5–1m behind and above the MAIN SPEAKER pair. Place the REAR SPEAKERS behind your listening position. They should be nearly 1.8m above the floor. Place the CENTER SPEAKER precisely between the two MAIN SPEAKERS. (To avoid interference, keep the speaker above or below the television monitor, or use a magnetically shielded speaker.) If using a SUBWOOFER, such as a Yamaha Active Servo Processing Subwoofer System, the position of the speaker is not so critical because low bass tones are not highly directional.

Main speaker

Subwoofer

Front effect speaker

Rear speaker

Center speaker

m Recommended speaker system configurations

PREPARATION

English

4 Speaker System

Basic system.

You can enjoy widely diffused sound by only adding a pair of rear speakers to a basic stereo speaker system.

1E. SYS. SETUP—Set to 5ch. (See page 30.) 1A. CENTER SP—Set to NONE. (See page 29.)

5 Speaker System

Good for Audio/Video sources.

By the use of a center speaker, center sounds (dialog, vocals etc.) are precisely localized.

1E. SYS. SETUP—Set to 5ch. (See page 30.) 1A. CENTER SP—Set to LRG or SML. (See page 29.)

6 Speaker System

Good for sound fields from 2-channel stereo sources.

When a normal stereo source is played back with the sound field programs No. 1 through No. 7, a sound effect matching that of a 7-speaker system can be obtained. The addition of front left and right effect speakers produces a more effective sound field.

7 Speaker System

This is the recommended speaker system, providing the best sound effects.

The rear speakers and the front effect speakers produces a 360-degree sound field, and the center speaker provides precise center localization. You can experience the amazing YAMAHA “CINEMA DSP” sound fields completely with the 7 speaker system.

1E. SYS. SETUP—Set to 7ch. (See page 30.) 1A. CENTER SP—Set to NONE. (See page 29.)

1E. SYS. SETUP—Set to 7ch. (See page 30.) 1A. CENTER SP—Set to LRG or SML. (See page 29.)

PHONO

VIDEO

DVD/LD

TV/DBS

VCR 1

OUT

VCR 2

OUT

ZONE 2

OUT

VIDEO

S VIDEO

DVD/LD

TV/DBS

VCR 1

OUT

VCR 2

OUT

MONITOR

OUT

S VIDEO

75Ω

UNBAL.

AM ANT

ANT

GND

AUDIO SIGNAL VIDEO SIGNAL

OPTICAL

TV/DBSCDCD DVD/LD TAPE/MD

(PLAY)

OUT

(REC)

DVD/LD

DIGITAL SIGNAL

EXTERNAL DECODER INPUT

TAPE/MD

( PLAY )

OUT

( REC)

MAIN

SUB WOOFER

CENTER

SURROUND

COAXIAL

AUDIO SIGNAL

OUTPUT

GND

OUTPUT

LINE OUT LINE IN

PREPARATION

Connections

Caution: Plug in this unit and other components after all connections are completed.

All connections must be correct, that is to say L (left) to L, R (right) to R, “+” to “+” and “–” to “–”. Also refer to the owner’s manual for each of your components.

Audio/video source equipment

●

Use RCA type pin plug cables for audio/video units with the exception described later.

●

The output (or input) terminals of YAMAHA audio/video units numbered as 1, 3, 4, etc. on the rear panel must be connected to the same-numbered terminals of this unit.

m Basic connections of audio units

Turntable

CD player

MD recorder, Tape deck, etc.

(*1): GND terminal (For turntable use)

Connecting the ground wire of the turntable to the GND terminal will normally minimize hum, but in some cases better results may be obtained with the ground wire disconnected.

(*1)

(U.S.A. model)

: Indicates the direction of signals.

PHONO

VIDEO

DVD/LD

TV/DBS

VCR 1

OUT

VCR 2

OUT

ZONE 2

OUT

VIDEO

S VIDEO

DVD/LD

TV/DBS

VCR 1

OUT

VCR 2

OUT

MONITOR

OUT

S VIDEO

75Ω

UNBAL.

ANT

FM ANT

GND

AUDIO SIGNAL

GND

AUDIO SIGNAL VIDEO SIGNAL

OPTICAL

TV/DBSCDCD DVD/LD TAPE/MD

(PLAY)

OUT

(REC)

DVD/LD

DIGITAL SIGNAL

EXTERNAL DECODER INPUT

TAPE/MD

( PLAY )

OUT

( REC)

MAIN

SUB WOOFER

CENTER

SURROUND

COAXIAL

VIDEO IN

VIDEO OUT

AUDIO OUT

VIDEO OUT

AUDIO OUT

VIDEO OUT

AUDIO IN

VIDEO IN

AUDIO IN

VIDEO IN

AUDIO OUT VIDEO OUT

PREPARATION

VIDEO AUX

S VIDEO

VIDEO

VIDEO OUT

S VIDEO OUT

AUDIO OUT L

AUDIO OUT R

VCR 1

OUT

VCR 2

PAL

NTSC

OUT

REMOTE

CONTROL

English

m Basic connections of video units

(U.S.A. model)

LD player or DVD player

TV/Satellite tuner

Video cassette recorder 1

Video cassette recorder 2

VIDEO AUX terminals (on the front panel)

These terminals are used to connect a video input source such as a camcorder.

: S-video cable

(Refer to page 20 for details about the S VIDEO terminal.)

Camcorder

TV monitor

PAL/NTSC switch (China and General models only)

This unit is designed for use with the NTSC and PAL television formats. Set this switch to the position for the format your TV monitor employs.

PAL/NTSC switch

PAL: Set to this position if your TV monitor employs the

PAL format. Outputs signals in the PAL format no matter which format (PAL or NTSC) of video signal is sent from an external video unit to this unit.

NTSC: Set to this position if your TV monitor employs the

NTSC format. Outputs signals in the NTSC format no matter which format (PAL or NTSC) of video signal is sent from an external video unit to this unit.

Note

Be sure to input a video signal which employs the same format that your TV monitor employs, otherwise a picture will not be played back normally.

PHONO

VIDEO

DVD/LD

TV/DBS

VCR 1

OUT

VCR 2

OUT

ZONE 2

OUT

VIDEO

S VIDEO

DVD/LD

TV/DBS

VCR 1

OUT

VCR 2

OUT

MONITOR

OUT

S VIDEO

75Ω

UNBAL.

ANT

GND

AUDIO SIGNAL

GND

AUDIO SIGNAL VIDEO SIGNAL

OPTICAL

TV/DBSCDCD DVD/LD TAPE/MD

(PLAY)

OUT

(REC)

DVD/LD

DIGITAL SIGNAL

EXTERNAL DECODER INPUT

TAPE/MD

( PLAY )

OUT

( REC)

MAIN

SUB WOOFER

CENTER

SURROUND

COAXIAL

OPTICAL DIGITAL OUT

COAXIAL DIGITAL OUT

OPTICAL DIGITAL OUT

OPTICAL DIGITAL IN

OPTICAL DIGITAL OUT

PREPARATION

m Connecting to digital (OPTICAL and COAXIAL) terminals

If your CD player, MD recorder, LD player, DVD player, TV/satellite tuner, etc. are equipped with coaxial or optical digital audio signal output terminals, they can be connected to this unit’s COAXIAL or OPTICAL, or both terminals.

Digital audio signals are transmitted with less loss than analog audio signals. In addition, digital audio signal connections are necessary, especially for an LD player, a DVD player or a CD player to send signals encoded with Dolby Digital or DTS to this unit.

To make an optical digital connection between this unit and an external unit, remove the cover from each optical terminal, and then connect them by using a commercially available optical fiber cable that conforms to EIAJ standards. Other cables might not function correctly.

<U.S.A. and Canada models>

Even if you connect an audio/video unit to the OPTICAL (or COAXIAL) terminal of this unit, you must keep the unit connected with the same named analog audio signal terminals of this unit, because digital signal cannot be recorded by a tape deck or VCR connected to only analog audio signal terminals of this unit. You can switch the selection of input signals between “digital” and “analog” easily. (See page 38 for details.) * However, if you connect an MD recorder or DAT to this

unit’s OPTICAL TAPE/MD IN and OUT terminals, it can record input sources connected to this unit’s OPTICAL digital signal input terminals.

(U.S.A. model)

CD player

MD recorder, DAT, etc.

TV/Satellite tunerLD player or DVD player

: Optical fiber cable

: Coaxial cable

PREPARATION

DVD/LD

PHONO

VIDEO

DVD/LD

TV/DBS

VCR 1

OUT

VCR 2

OUT

ZONE 2

OUT

VIDEO

S VIDEO

DVD/LD

TV/DBS

VCR 1

OUT

VCR 2

OUT

MONITOR

OUT

S VIDEO

75Ω

UNBAL.

ANT

GND

AUDIO SIGNAL

GND

AUDIO SIGNAL VIDEO SIGNAL

OPTICAL

TV/DBSCD TAPE/MD

(PLAY)

OUT

(REC)

DVD/LD

DIGITAL SIGNAL

EXTERNAL DECODER INPUT

TAPE/MD

( PLAY )

OUT

( REC)

MAIN

SUB WOOFER

CENTER

SURROUND

DIGITAL

RF SIGNAL

COAXIAL

OPTICAL DIGITAL OUT

COAXIAL DIGITAL OUT

OPTICAL DIGITAL OUT

OPTICAL DIGITAL IN

OPTICAL DIGITAL OUT

English

Notes

●

When you connect an audio/video unit to both of the digital

●

and analog terminals of this unit, make sure to connect to both terminals of the same name.

●

Be sure to attach the covers when the OPTICAL terminals

●

are not being used, in order to protect the terminals from dust.

●

In order to make this unit perform successful DTS-decoding, the DTS bitstream must not be altered, manipulated or corrupted in the process of sending the DTS bitstream from the DIGITAL OUT terminal of an external unit to a digital signal input terminal of this unit.

<Australia, China, Singapore and General models>

Digital audio signals will not be output from the ZONE 2 OUT AUDIO SIGNAL terminals of this unit. All digital audio signal input terminals are applicable to the sampling frequency of 32 kHz, 44.1 kHz and 48 kHz.

(Australia model)

CD player

MD recorder, DAT, etc.

TV/Satellite tunerLD player or DVD player

: Optical fiber cable

: Coaxial cable

PHONO

DVD/LD

TV/DBS

VCR 1

OUT

VCR 2

OUT

ZONE 2

OUT

75Ω

UNBAL.

ANT

GND

AUDIO SIGNAL

GND

AUDIO SIGNAL

EXTERNAL DECODER INPUT

TAPE/MD

( PLAY )

OUT

( REC)

MAIN

SUB WOOFER

CENTER

SURROUND

DIGITAL OUT

ANALOG OUT

DOLBY DIGITAL

RF OUT

DVD/LD

OPTICAL

TV/DBSCD TAPE/MD

(PLAY)

OUT

(REC)

DVD/LD

DIGITAL SIGNAL

DIGITAL

RF SIGNAL

COAXIAL

PREPARATION

m Connecting to DOLBY DIGITAL RF output of the DVD/LD/CD combi-player

If your DVD/LD/CD combi-player has a DOLBY DIGITAL RF signal output terminal, connect it to this unit’s DIGITAL RF SIGNAL input terminal. Audio signals of an LD source encoded with the Dolby Digital are input to this unit by this connection. * To play back an LD source with the Dolby Digital decoded,

set the input mode of DVD/LD to “AUTO” or “D.D.RF”. (Refer to page 38 for details.)

It is also necessary to connect the DVD/LD/CD combi-player to this unit’s analog audio signal input terminals regardless of the DOLBY DIGITAL RF signal connection. This is for playing back a source with Dolby Pro Logic Surround decoded or in normal stereo (or monaural).

DVD/LD/CD combi-player

You must also connect the optical digital signal output terminal of the DVD/LD/CD combi-player to the OPTICAL DVD/LD digital signal input terminal of this unit. This connection is necessary for playing back a DVD source with Dolby Digital or DTS decoded, and playing back an LD source with DTS decoded.

Note

DOLBY DIGITAL RF audio input signal cannot be recorded by a tape deck, MD recorder or VCR. To record a source played back on the DVD/LD/CD combi-player, it must be connected to the OPTICAL digital audio signal input terminal and analog audio signal input terminals of this unit.

(Australia model)

PHONO

DVD/LD

TV/DBS

VCR 1

OUT

VCR 2

OUT

ZONE 2

OUT

75Ω

UNBAL.

ANT

GND

AUDIO SIGNAL

GND

AUDIO SIGNAL

OPTICAL

TV/DBSCDCD DVD/LD TAPE/MD

(PLAY)

OUT

(REC)

DVD/LD

DIGITAL SIGNAL

EXTERNAL DECODER INPUT

TAPE/MD

( PLAY )

OUT

( REC)

MAIN

SUB WOOFER

CENTER

SURROUND

COAXIAL

COAXIAL DIGITAL OUT

DOLBY DIGITAL

RF IN

OPTICAL DIGITAL OUT

ANALOG OUT

DOLBY DIGITAL

RF OUT

PREPARATION

English

If your DVD/LD/CD combi-player has a DOLBY DIGITAL RF signal output terminal, it can be connected to this unit by using an RF demodulator (separate purchase). First, connect the DOLBY DIGITAL RF signal output terminal of the DVD/LD/CD combi-player to the DOLBY DIGITAL RF signal input terminal of the RF demodulator. Next, connect the coaxial digital signal output terminal of the RF demodulator to the COAXIAL digital signal input terminal of this unit. This connection is necessary for sending audio signals of an LD source encoded with Dolby Digital to this unit.

When these connections are completed, set the input mode of the DVD/LD source to “AUTO”, and you will hear sounds decoded with Dolby Digital even if signals are input to both COAXIAL and OPTICAL digital signal input terminals of this unit. This is because signals input to the COAXIAL terminal take priority over signals input to the OPTICAL terminal. Refer to page 38 for details about switching the input mode.

Notes

●

If, for example, you play a CD on the DVD/LD/CD combiplayer, there is no input to the COAXIAL terminal, so the signals input to the OPTICAL terminal take priority. In this case, switch off the RF demodulator to listen to CD sound without interference. However, if your RF demodulator is the Yamaha model APD-1, you do not have to switch it off.

●

When you want to play an LD source encoded with Dolby Digital without decoding Dolby Digital, you must switch off the power of the RF demodulator.

DVD/LD/CD combi-player, etc.

RF demodulator

(U.S.A. model)

VIDEO

DVD/LD

TV/DBS

VCR 1

OUT

VCR 2

OUT

VIDEO

S VIDEO

DVD/LD

VCR 1

OUT

VCR 2

MONITOR

OUT

S VIDEO

AUDIO SIGNAL VIDEO SIGNAL

TV/DBS

OUT

VIDEO IN

S-VIDEO OUT

VIDEO OUT

S-VIDEO

S-VIDEO OUT

VIDEO IN

S-VIDEO IN

VIDEO OUT

S-VIDEO OUT

VIDEO OUT

VIDEO IN

S-VIDEO IN

PREPARATION

m Connecting to S VIDEO terminals

If your video cassette recorder, LD player, etc. and your monitor are equipped with “S” video terminals, connect them to this unit’s S VIDEO terminals, and connect this unit’s S VIDEO MONITOR OUT terminal to the “S” video input of your monitor. With this connection, you can play back and record high quality pictures. Otherwise, connect the “composite” video terminals from your video cassette recorder, LD player, etc. to the VIDEO terminals of this unit, and connect this unit’s VIDEO MONITOR OUT terminal to the “composite” video input of your monitor.

Note

If video signals are sent to both S VIDEO input and VIDEO input terminals, the signals will be sent to their respective output terminals.

LD player or DVD player

Notes about the Video superimpose

●

If you watch a video source that is connected to both S VIDEO and VIDEO input terminals of this unit, signals of screen display information are output from only the S VIDEO MONITOR OUT terminal.

●

When no video signal is input to either S VIDEO or VIDEO input terminals of this unit, signals of screen display information are output from both S VIDEO MONITOR OUT and VIDEO MONITOR OUT terminals with a color background. * For China and General models, if the PAL/NTSC switch

on the rear panel is set to “PAL”, nothing will be output from either S VIDEO MONITOR OUT or VIDEO MONITOR OUT terminal in this case.

S VIDEO terminals

This unit provides you with S VIDEO terminals in addition to standard type VIDEO terminals. S VIDEO terminals transmit video signals separated into luminance (Y) signals and color (C) signals. In comparison with S VIDEO terminals, standard type VIDEO terminals transmit “composite” video signals.

Video cassette recorder 1

TV/Satellite tuner

Video cassette recorder 2

TV monitor

: S-video cable

Connecting an external decoder of a future format to this unit

PHONO

VIDEO

DVD/LD

TV/DBS

VCR 1

OUT

VCR 2

OUT

ZONE 2

OUT

VIDEO

S VIDEO

DVD/LD

TV/DBS

VCR 1

OUT

VCR 2

OUT

MONITOR

OUT

S VIDEO

75Ω

UNBAL.

AM ANT

ANT

GND

AUDIO SIGNAL VIDEO SIGNAL

OPTICAL

TV/DBSCDCD DVD/LD TAPE/MD

(PLAY)

OUT

(REC)

DVD/LD

DIGITAL SIGNAL

TAPE/MD

( PLAY )

OUT

( REC)

MAIN

SUB WOOFER

CENTER

SURROUND

COAXIAL

AUDIO SIGNAL

EXTERNAL DECODER INPUT

SUBWOOFER OUT

SURROUND OUT

CENTER

OUT

MAIN OUT

PREPARATION

English

This unit is equipped with additional 6-channel audio signal input terminals (for left main, right main, center, left rear surround, right rear surround and subwoofer channels) for inputting signals from an external decoder of a future format to this unit. To listen to a sound by reproducing signals input to these terminals, press the EXT. DECODER button on the front panel so that “EXT. DECODER IN” appears on the display. By doing so, the signals input to these terminals are sent to the corresponding SPEAKERS terminals and OUTPUT terminals of this unit.

Notes

●

When signals input to these terminals are selected, the digital sound field processor cannot be used.

●

The settings of “1A” to “1E” in the SET MENU mode have no effect on the signals input to these terminals. The setting of “1F. MAIN LEVEL” is effective. (Refer to pages 29 to 30 for details.)

●

The adjustments of the output level of the center speaker, rear speakers and subwoofer are effective when the signals input to these terminals are selected as the input source. (Refer to pages 51 to 52 for details.)

(U.S.A. model)

External decoder

SEE INSTRUCTION MANUAL FOR CORRECT SETTING.

CENTER

FRONT

CAUTION

MAIN

CENTER

FRONT REAR

( SURROUND )

PRE

OUT

MAIN

SPEAKERS

COUPLER OUTPUT

REAR

MAIN

IMPEDANCE SELECTOR

CENTER : 4ΩMIN. / SPEAKER FRONT :6Ω

MIN. / SPEAKER

REAR:4Ω

MIN. / SPEAKER

MAIN A OR B:4Ω

MIN. / SPEAKER

A B :8Ω

MIN. / SPEAKER

CENTER : 8ΩMIN. / SPEAKER FRONT :8Ω

MIN. / SPEAKER

REAR:8Ω

MIN. / SPEAKER

MAIN A OR B:8Ω

MIN. / SPEAKER

A B :I 6Ω

MIN. / SPEAKER

OUT

SUB

WOOFER

REMOTE

CONTROL

( SURROUND )

SET BEFORE POWER ON

PREPARATION

Speakers

Use speakers with the specified impedance shown on the rear of this unit.

Right

Center speaker

Front effect speakers

Left

Right

Rear speakers

Left

Subwoofer system

How to Connect:

Right

Main speakers B

Left

Right

Left

Main speakers A

Connect the SPEAKERS terminals to your speakers with the wire of the proper gauge (keep as short as possible). If the connections are faulty, no sound will be heard from the speakers. Make sure that the polarity of the speaker wires is correct. That is the + and – markings are observed. If these wires are reversed, the sound will be unnatural and lack bass.

Caution Do not let the bare speaker wires touch each other or any metal part of this unit. This could damage this unit or the speakers, or both.

Red: positive (+) Black: negative (–)

Loosen the knob.

➀

Insert the bare wire.

➁

<U.S.A., Canada, China, Australia and General models

only>

Banana Plug connections are also possible. Simply insert the Banana Plug connector into the corresponding terminal.

[Remove approx. 5mm (1/4”) insulation from the speaker wires.] Tighten the knob and

➂

secure the wire.

REAR

SWITCHED

AC OUTLETS

IMPEDANCE SELECTOR

I00W MAX. TOTAL

I20V 80Hz

CENTER : 4ΩMIN. / SPEAKER FRONT :6Ω

MIN. / SPEAKER

REAR:4Ω

MIN. / SPEAKER

MAIN A OR B:4Ω

MIN. / SPEAKER

A B :8Ω

MIN. / SPEAKER

CENTER : 8ΩMIN. / SPEAKER FRONT :8Ω

MIN. / SPEAKER

REAR:8Ω

MIN. / SPEAKER

MAIN A OR B:8Ω

MIN. / SPEAKER

A B :I 6Ω

MIN. / SPEAKER

( SURROUND )

SET BEFORE POWER ON

MAIN

PREPARATION

English

Note on main speaker connections:

One or two speaker systems can be connected to this unit. If you use only one speaker system, connect it to either the SPEAKERS A or B terminals.

m IMPEDANCE SELECTOR switch

WARNING Do not change the IMPEDANCE SELECTOR switch setting while the power to this unit is on, otherwise this unit may be damaged.

IF THIS UNIT FAILS TO TURN ON WHEN THE STANDBY/ON SWITCH IS PRESSED:

The IMPEDANCE SELECTOR switch may not be set to either end. If so, set the switch to either end when this unit is in the standby mode.

(U.S.A. model)

Note on a subwoofer connection:

You may wish to add a subwoofer to reinforce low frequencies or to output low bass sound from the subwoofer channel when reproducing discrete signals. When using a subwoofer, connect the SUBWOOFER terminal of this unit to the INPUT terminal of the subwoofer amplifier, and connect the speaker terminals of the subwoofer amplifier to the subwoofer. With some subwoofers, including the Yamaha Active Servo Processing Subwoofer System, the amplifier and subwoofer are in the same unit. Such a subwoofer needs only the connection between the SUBWOOFER terminal of this unit and the INPUT terminal of the subwoofer. (Refer to page 24 for details about the SUBWOOFER terminal.)

Select the position whose requirements your speaker system meets.

(Upper position)

Center: The impedance of the speaker must be 4Ω or higher. Rear: The impedance of each speaker must be 4Ω or

higher.

Main: If you use one pair of main speakers, the impedance

of each speaker must be 4Ω or higher. If you use two pairs of main speakers, the impedance of each speaker must be 8Ω or higher.

IMPEDANCE SELECTOR

Front effect:

The impedance of each speaker must be 6Ω or higher.

(Lower position)

Center: The impedance of the speaker must be 8Ω or higher. Rear: The impedance of each speaker must be 8Ω or

higher.

Main:

If you use one pair of main speakers, the impedance of each speaker must be 8Ω or higher. If you use two pairs of main speakers, the impedance of each speaker must be 16Ω or higher.

The impedance of each speaker must be 8Ω or higher.

Front effect:

The impedance of each speaker must be 8Ω or higher.

MAIN

CENTER

FRONT REAR

( SURROUND )

PRE OUT

MAIN

COUPLER OUTPUT

SUB

WOOFER

1 4 523

PREPARATION

m To drive main, center, front effect and/or rear speakers with external

amplifiers

The speaker connections described on page 22 are fine for most applications. If for some reason, however, you wish to drive main, center, front effect and/or rear speakers with your existing amplifier, etc., the following terminals are available for connecting external amplifier(s) to this unit.

1 MAIN PRE OUT/MAIN IN terminals

The PRE OUT terminals are for main channel line output, and the MAIN IN terminals are for line input to the built-in main channel amplifier. The PRE OUT and MAIN IN terminals must be connected with jumper bars when the built-in amplifier is used. However, if you drive main speakers with an external stereo power amplifier, first remove the jumper bars, and then connect the input terminals of the external amplifier (MAIN IN or AUX terminals of an amplifier or a receiver) to the PRE OUT terminals. No connection is needed to the MAIN IN terminals. * Output signals from the PRE OUT terminals are

affected by the use of BASS, TREBLE, BALANCE controls and BASS EXTENSION button and the TONE BYPASS button.

3 CENTER terminal

This terminal is for center channel line output. If you drive a center speaker with an external power amplifier, connect the input terminal of the external amplifier to this terminal. There is no connection to this terminal when you use the built-in amplifier.

4 FRONT terminals

These terminals are for front effect channel line output. If you drive front effect speakers with an external stereo power amplifier, connect the input terminals of the external amplifier (MAIN IN or AUX terminals of an amplifier or a receiver) to these terminals. There is no connection to these terminals when you use the built-in amplifier.

5 REAR (SURROUND) terminals

These terminals are for rear channel line output. If you drive rear speakers with an external stereo power amplifier, connect the input terminals of the external amplifier (MAIN IN or AUX terminals of an amplifier or a receiver) to these terminals. There is no connection to these terminals when you use the built-in amplifier.

Notes

Output level of signals from all of these terminals are

• adjusted by the use of VOLUME control on the front panel or MASTER VOLUME keys on the remote controller. If an external power amplifier is connected to the

• CENTER, FRONT or REAR output terminals, do not use the corresponding SPEAKERS terminals (CENTER, FRONT or REAR).

2 SUBWOOFER terminal

When using a subwoofer, connect its amplifier input to this terminal. Low frequencies distributed from the main, center and/or rear channels are output from this terminal. (The cut-off frequency of this terminal is 90 Hz.) Signals of LFE (low frequency effect) generated when Dolby Digital or DTS is decoded are also output if they are assigned to this terminal.
