Yamaha Audio R-V98 User Manual
R-V98
Natural Sound Stereo Receiver
5 Speaker Configuration
80W + 80W (8Ω) RMS Output Power, 0.09% THD, 1 kHz (Front)
80W (8Ω) RMS Output Power, 0.1% THD, 1 kHz (Center)
15W + 15W (8Ω) RMS Output Power, 0.7% THD, 1 kHz (Rear)
Digital Sound Field Processor
4 Programs for Digital Sound Field Processing and
2 Programs Dolby Surround (DOLBY PRO LOGIC and DOLBY PRO LOGIC ENHANCED)
Automatic Input Balance Control for Dolby Surround
Test Tone Generator for Easier Speaker Output Balance Adjustment
3 Center Channel Modes (NORMAL/WIDE/PHANTOM)
40-Station Random Preset Tuning
Automatic Preset Tuning
Preset Station Shifting Capability
IF Count Direct PLL Synthesizer Tuning System
Video Signal Input/Output Capability
SLEEP Timer
Remote Control Capability
Thank you for selecting this YAMAHA stereo receiver.
OWNER’S MANUAL
CONTENTS
Safety Instructions........................2
Supplied Accessories ...................4
Profile of This Unit .......................5
Speaker Setting-up for This Unit
....6
Connections .................................7
Adjustment Before Operation .....10
Operations .................................13
Tuning Operations ......................16
Preset Tuning ...................................
17
Using Digital Sound Field Processor
(DSP) ...............................................2
0
Setting the SLEEP Timer ...........24
Remote Control Transmitter .......25
Notes about the Remote Control
Transmitter .......................................26
Troubleshooting .........................27
Specifications .............................28
IMPORTANT!
Please record the serial number of this
unit in the space below.
Model:
Serial No.:
The serial number is located on the rear
of the unit.
Retain this Owner’s Manual in a safe
place for future reference.
WARNING
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE
THIS UNIT TO RAIN OR MOISTURE.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK), NO USER-SERVICEABLE
PARTS INSIDE, REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
Explanation of Graphical Symbols
•
The lightning flash with arrowhead
symbol, within an equilateral triangle,
is intended to alert you to the
presence of uninsulated “dangerous
voltage” within the product’s
enclosure that may be of sufficient
magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an
equilateral triangle is intended to alert
you to the presence of important
operating and maintenance
(servicing) instructions in the
literature accompanying the
appliance.
SAFETY INSTRUCTIONS (U.S.A.)
1 Read Instructions – All the safety and operating
instructions should be read before the unit is operated.
2 Retain Instructions – The safety and operating instructions
should be retained for future reference.
3 Heed Warnings – All warnings on the unit and in the
operating instructions should be adhered to.
4 Follow Instructions – All operating and other instructions
should be followed.
5 Water and Moisture – The unit should not be used near
water – for example, near a bathtub, washbowl, kitchen
sink, laundry tub, in a wet basement, or near a swimming
pool, etc.
6 Carts and Stands – The unit should be used only with a
cart or stand that is recommended by the manufacturer.
6A A unit and cart combination should
be moved with care. Quick stops,
excessive force, and uneven
surfaces may cause the unit and
cart combination to overturn.
7 Wall or Ceiling Mounting – The unit
should be mounted to a wall or ceiling only as
recommended by the manufacturer.
8 Ventilation – The unit should be situated so that its location
or position does not interfere with its proper ventilation.
For example, the unit should not be situated on a bed,
sofa, rug, or similar surface, that may block the ventilation
openings; or placed in a built-in installation, such as a
bookcase or cabinet that may impede the flow of air
through the ventilation openings.
9 Heat – The unit should be situated away from heat sources
such as radiators, stoves, or other appliances that produce
heat.
10 Power Sources – The unit should be connected to a power
supply only of the type described in the operating
instructions or as marked on the unit.
11 Power-Cord Protection – Power-supply cords should be
routed so that they are not likely to be walked on or
pinched by items placed upon or against them, paying
particular attention to cords at plugs, convenience
receptacles, and the point where they exit from the unit.
12 Cleaning – The unit should be cleaned only as
recommended by the manufacturer.
13 Nonuse Periods – The power cord of the unit should be
unplugged from the outlet when left unused for a long
period of time.
14 Object and Liquid Entry – Care should be taken so that
objects do not fall into and liquids are not spilled into the
inside of the unit.
15 Damage Requiring Service – The unit should be serviced
by qualified service personnel when:
A. The power-supply cord or the plug has been damaged;
or
B. Objects have fallen, or liquid has been spilled into the unit;
or
C. The unit has been exposed to rain; or
D. The unit does not appear to operate normally or exhibits a
marked change in performance; or
E. The unit has been dropped, or the cabinet damaged.
16 Servicing – The user should not attempt to service the unit
beyond those means described in the operating
instructions. All other servicing should be referred to
qualified service personnel.
17 Power Lines – An outdoor antenna should be located away
from power lines.
18 Grounding or Polarization – Precautions should be taken
so that the grounding or polarization is not defeated.
19 Outdoor Antenna Grounding – If an outside antenna is
connected to this unit, be sure the antenna system is
grounded so as to provide some protection against voltage
surges and built-up static charges. Article 810 of the
National Electrical Code, ANSI/NFPA 70, provides
information with regard to proper grounding of the mast
and supporting structure, grounding of the lead-in wire to
an antenna discharge unit, size of grounding conductors,
location of antenna discharge unit, connection to
grounding electrodes, and requirements for the grounding
electrode.
EXAMPLE OF ANTENNA GROUNDING
MAST
GROUND
CLAMP
ELECTRIC
SERVICE
EQUIPMENT
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250. PART H)
NEC – NATIONAL ELECTRICAL CODE
Note to CATV system installer (U.S.A.):
This reminder is provided to call the CATV system
installer's attention to Article 820-40 of the NEC that
provides guidelines for proper grounding and, in
particular, specifies that the cable ground shall be
connected to the grounding system of the building, as close
to the point of cable entry as practical.
ANTENNA
LEAD IN
WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810–20)
GROUNDING CONDUCTORS
(NEC SECTION 810–21)
GROUND CLAMPS
2
CAUTION: READ THIS BEFORE OPERATING YOUR UNIT
1 To assure the finest performance, please read this
manual carefully. Keep it in a safe place for future
reference.
2 Install this unit in a cool, dry, clean place – away from
windows, heat sources, sources of excessive vibration,
dust, moisture and cold. Avoid sources of humming
(transformers, motors). To prevent fire or electrical
shock, do not expose the unit to rain or water.
3 Never open the cabinet. If something drops into the set,
contact your dealer.
4 Do not use force on switches, controls or connection
wires. When moving the unit, first disconnect the power
plug and the wires connected to other equipment. Never
pull the wires themselves.
5 The openings on the cabinet assure proper ventilation of
the unit. If these openings are obstructed, the
temperature inside the cabinet will rise rapidly and
eventually damage the circuits. Therefore, avoid placing
objects against these openings and do not install the unit
where the flow of air through the ventilation openings
could be impeded.
FCC INFORMATION (U.S.A.)
1. IMPORTANT NOTICE : DO NOT MODIFY THIS UNIT!
This product, when installed as indicated in the
instructions contained in this manual, meets FCC
requirements. Modifications not expressly approved by
Yamaha may void your authority, granted by the FCC, to
use the product.
2. IMPORTANT : When connecting this product to
accessories and/or another product use only high quality
shielded cables. Cable/s supplied with this product
MUST be used. Follow all installation instructions.
Failure to follow instructions could void your FCC
authorization to use this product in the USA.
3. NOTE : This product has been tested and found to
comply with the requirements listed in FCC Regulations,
Part 15 for Class “B” digital devices. Compliance with
these requirements provides a reasonable level of
assurance that your use of this product in a residential
environment will not result in harmful interference with
other electronic devices.
This equipment generates/uses radio frequencies and, if
not installed and used according to the instructions
found in the users manual, may cause interference
harmful to the operation of other electronic devices.
6 Always set the VOLUME control to “–
the audio source play. Increase the volume gradually to
an appropriate level after playback has been started.
” before starting
∞
7 Do not attempt to clean the unit with chemical solvents;
this might damage the finish. Use a clean, dry cloth.
8 Be sure to read the “TROUBLESHOOTING” section
regarding common operating errors before concluding
that the unit is faulty.
9 When not planning to use this unit for long periods of
time (ie., vacation, etc.), disconnect the AC power plug
from the wall outlet.
10 To prevent lightning damage, disconnect the AC power
plug and disconnect the antenna cable when there is an
electrical storm.
11 Grounding or polarization – Precautions should be taken
so that the grounding or polarization of an appliance is
not defeated.
12 AC outlet
Do not connect audio equipment to the AC outlet on the
rear panel if that equipment requires more power than the
outlet is rated to provide.
Compliance with FCC regulations does not guarantee that
interference will not occur in all installations. If this product
is found to be the source of interference, which can be
determined by turning the unit “OFF” and “ON”, please try
to eliminate the problem by using one of the following
measures:
Relocate either this product or the device that is being
affected by the interference.
Utilize power outlets that are on different branch (circuit
breaker or fuse) circuits or install AC line filter/s.
In the case of radio or TV interference, relocate/reorient the
antenna. If the antenna lead-in is 300 ohm ribbon lead,
change the lead-in to coaxial type cable.
If these corrective measures do not produce satisfactory
results, please contact the local retailer authorized to
distribute this type of product. If you can not locate the
appropriate retailer, please contact Yamaha Electronics
Corp., U.S.A. 6660 Orangethorpe Ave, Buena Park, CA
90620.
The above statements apply ONLY to those products
distributed by Yamaha Corporation of America or its
subsidiaries.
We Want You Listening For A Lifetime (U.S.A.)
YAMAHA and the Electronic Industries Association’s
Consumer Electronics Group want you to get the most out of
your equipment by playing it at a safe level. One that lets the
sound come through loud and clear without annoying blaring or
distortion – and, most importantly, without affecting your
sensitive hearing. Since hearing damage from loud sounds is
often undetectable until it is too late, YAMAHA
and the Electronic Industries Association’s
Consumer Electronics Group recommend you to
avoid prolonged exposure from excessive
volume levels.
3
This product complies with the radio frequency interference requirements of the Council Directive 82/499/EEC and/or
POWER SLEEP PLAY PHONO
PAUSE/STOP
CD
TUNER
A/B/C/D/E
LD/TV
DECK A/B
TAPE MON
VCR MON
CENTER
MODE
PRO LOGIC
ENHANCED CNCT VIDEO
+
MONO MOVIE
VOLUME
HALL
—
+
PRESET
SKIP
PLAY
—
+
DISC SKIP
STOP
REC/PAUSE
DELAY
TIME
EFFECT
ON/OFF
ROCK
SUR.
—
DIR A DIR B
87/308/EEC.
The apparatus is not disconnected from the AC power source as long as it is connected to the wall outlet, even if the apparatus
itself is turned off.
For U.K. customers
If the socket outlets in the home are not suitable for the plug supplied with this appliance, it should be cut off and an appropriate 3
pin plug fitted. For details, refer to the instructions described below.
Note: The plug severed from the mains lead must be destroyed, as a plug with bared flexible cord is hazardous if engaged in a live
socket outlet.
SPECIAL INSTRUCTIONS FOR U.K. MODEL
IMPORTANT:
The wire in the mains lead are coloured in accordance with the following code:
Blue: NEUTRAL
Brown: LIVE
The colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the
terminals in your plug. Proceed as follows: the wire which is coloured BLUE must be connected to the terminal which is marked
with the letter N or coloured BLACK. The wire which is coloured BROWN must be connected to the terminal which is marked
with the letter L or coloured RED. Making sure that neither core is connected to the earth terminal of the three pin plug.
SUPPLIED ACCESSORIES
After unpacking, check that the following parts are contained.
Indoor FM Antenna
AM Loop Antenna
Remote Control Transmitter
Batteries (size AA, R6, UM-3)
4
PROFILE OF THIS UNIT
You are the proud owner of a Yamaha stereo receiver –an extremely sophisticated audio component. The Digital Sound Field
Processor (DSP) built into this unit takes full advantage of Yamaha’s undisputed leadership in the field of digital audio processing to
bring you a whole new world of listening experiences. Follow the instructions in this manual carefully when setting up your system,
and this unit will sonically transform your room into a wide range of listening environments –movie theater, concert hall, and so on.
In addition, you get incredible realism from Dolby-encoded video sources using the built-in Dolby Pro Logic Surround Decoder.
Rather than tell you about the wonders of digital sound field processing, however, let’s get right down to the business of setting up
the system and trying out its many capabilities. Please read this operation manual carefully and store it in a safe place for later
reference.
Digital Sound Field Processing
What is it that makes live music so good? Today’s advanced
sound reproduction technology lets you get extremely close to
the sound of a live performance, but chances are you’ll still
notice something missing: the acoustic environment of the live
concert hall. Extensive research into the exact nature of the
sonic reflections that create the ambience of a large hall has
made it possible for Yamaha engineers to bring you this same
sound in your own listening room, so you’ll feel all the sound of
a live concert.
Dolby Pro Logic Surround
The Dolby Pro Logic Surround Decoder program lets you
experience the dramatic realism and impact of Dolby Surround
movie theater sound in your own home. Dolby Pro Logic gets
its name from its professional-grade steering logic circuitry,
which provides greater effective channel separation for a much
higher degree of realism than the “passive” Dolby Surround
circuits found in today’s typical home audio/video equipment.
Dolby Pro Logic Surround provides a true center channel, so
that there are four independent channels, unlike passive Dolby
Surround which has in effect only three channels: left, right,
and rear. This center channel allows listeners seated in even
less-than-ideal positions to hear the dialog originating from
action on the screen while getting a stereo effect as well.
What’s more, our technicians, armed with sophisticated
measuring equipment, have even made it possible to capture
the acoustics of a variety of venues such as an actual concert
hall, theater, etc. to allow you to accurately recreate one of
several actual live performance environments, all in your own
home.
This Dolby Pro Logic Surround Decoder employs a digital
signal processing system. This system increases sound
stability at each channel and minimizes crosstalk between
channels compared to conventional analog Dolby signal
processing.
In addition, this unit features a built-in automatic input balance
control. This circuit always presents you the best surround
conditions without performing manual adjustments.
Dolby Pro Logic Surround + DSP
You can also enjoy a combination of Dolby Pro Logic Surround
and DSP in the sound field program “ PRO LOGIC
ENHANCED”.
It recreates the surround effect of a movie theater, effectively
duplicating its multiple surround loudspeaker system,
completely surrounding the listener with the sounds of the
action taking place on the screen.
5
SPEAKER SETTING-UP FOR THIS UNIT
SPEAKERS TO BE USED
This unit is designed to provide the best sound-field quality with a 5 speaker configuration. The speakers to be used with this unit
will be mainly front speakers, rear speakers, and a center speaker. (You can omit the center speaker. Refer to the “4-Speaker
Configuration” shown below.)
The front speakers are used for the output of the main source sound and the effect sound. They will probably be the speakers of
your present stereo speaker system. The rear speakers are used for the output of the effect sound. And the center speaker is
used for the output of the center sound (dialog etc.) encoded with the Dolby Surround. The rear and center speakers do not need
to be equal in power to the front speakers. However, all the speakers should have high enough power handling to accept the
maximum output of this unit.
SPEAKER CONFIGURATION
5-Speaker Configuration
This configuration is the most effective and is the one that is
recommended. In this configuration, the center speaker is
necessary as well as the rear speakers. If the digital sound
field program is in DOLBY PRO LOGICor DOLBY PRO
LOGICENHANCEDmode conversations will be output from
the center speaker and the ambience will be excellent.
●
Set the center mode to the “NORMAL” or “WIDE” position.
(For details, refer to page 11.)
Front L Center Front R
Dialogue
Dialogue
Surround sound
Surround sound
Rear L
Rear R
SPEAKER PLACEMENT
4-Speaker Configuration
The center speaker is not used in this configuration. If the
digital sound field program is in the DOLBY PRO LOGICor
DOLBY PRO LOGICENHANCEDmode, the center sound is
output from the left and the right front speakers. However, the
sound effect of other programs can be the same as that of the
5-speaker configuration.
●
Be sure to set the center mode to the “PHANTOM” position.
(For details, refer to page 11.)
Front L Front R
Dialogue
Dialogue
Surround sound
Surround sound
Rear L Rear R
The recommanded speaker configuration, the 5-speaker configuration, will require two speaker pairs: front speakers(your normal
stereo speakers), and rear speakers, plus a center speaker. When you place these speakers, refer to the following.
Front R
Center
Front L
TV set
Rear R
Rear L
6
Front: In normal position. (The position of your present
stereo speaker system.)
Rear: Behind your listening position, facing slightly inward.
Nearly six feet (approx. 1.8 m) up from the floor.
Center:Precisely between the front speakers. (To avoid
interference with TV sets, use a magnetically shielded
speaker. If, however, it is not effective, keep the
speaker away from TV sets.)
CONNECTIONS
R L
A
B
75Ω
UNBAL
PHONO CD LD/TV IN OUT
LD
/
TV
IN
OUT
MONITOR
OUT
VCR
REAR
CENTER
REAR
A
B
SWITCHED
FM
ANT
GND
AM
ANT
SPEAKERS
TAPEPBREC
OUT
TAPE VCR
R
L
AUDIO SIGNAL
SPEAKERS
AC OUTLETS
LD player Video cassette recorder
Turntable Compact disc
player
Tape deck Monitor TV
To AC outlet
AUDIO OUT
VIDEO OUT
AUDIO OUT
AUDIO IN
VIDEO OUT
VIDEO IN
GND
OUTPUT
OUTPUT
LINE OUT
LINE IN
VIDEO IN
GND
120V 50Hz
100W MAX TOTAL
VIDEO
SIGNAL
Before attempting to make any connections to or from this unit, be sure to first switch OFF the power to this unit and to any other
components to which connections are being made.
CONNECTIONS WITH OTHER COMPONENTS
When making connections between this unit and other components, be sure all connections are made correctly, that is to say L
(left) to L, R (right) to R, “+” to “+” and “–” to “–”. Also, refer to the owner’s manual for each component to be connected to this unit.
LD player, TV tuner,
etc.
(U.S.A. model)
:Refer to “ABOUT THE ACCESSORY TERMINALS” on page 8.
7
CONNECTING SPEAKERS
R L
A
B
IN OUT
REAR
CENTER
REAR
A
B
SPEAKERS
REC
OUT
TAPE VCR
R
L
SPEAKERS
Front speakers A
Right Left
Right Left
Front speakers B
Rear speakers
Right
Left
Center speaker
➀
➁
➂
Connect the SPEAKERS terminals to your speakers with wire
of the proper gauge, cut to be as short as possible. If the
connections are faulty, no sound will be heard from the
speakers. Make sure that the polarity of the speaker wires is
correct, that is, + and – markings are observed. If these wires
are reversed, the sound will be unnatural and will lack bass.
Do not let the bare speaker wires touch each other and do
not let them touch the metal parts of this unit as this could
damage this unit and/or speakers.
●
Use speakers with the specified impedance shown on the
rear of this unit.
●
Note for front speaker connection:
One or two speaker systems can be connected to this unit.
If you connect only one speaker system, connect it to either
the SPEAKERS A or B terminals.
ABOUT THE ACCESSORY TERMINALS
AC OUTLET(S)
(U.S.A., Canada, Europe and General models)
............................................................2 SWITCHED OUTLETS
(Australia and U.K. models)
.............................................................. 1 SWITCHED OUTLET
Use these to connect the power cords from your components
to this unit.
The power to the SWITCHED outlets is controlled by this unit’s
POWER switch or the provided remote-control transmitter’s
POWER key. These outlets will supply power to any
component whenever this unit is turned on.
8
How to Connect:
Red: positive (+)
Black: negative (–)
Press up the tab.
➀
Insert the bare wire.
➁
[Remove approx. 5mm
(1/4”) insulation from
the speaker wires.]
Press down the tab and
➂
secure the wire.
The maximum power (total power consumption of
components) that can be connected to the SWITCHED AC
OUTLET(S) is 100 watts.
GND terminal (For turntable use)
Connecting the ground wire of the turntable to this terminal will
minimize hum, but in some cases better results may be
obtained with the ground wire disconnected.
ANTENNA CONNECTIONS
75Ω
UNBAL
PHONO CD LD/TV
LD
/
TV
IN
OUT
MONITOR
OUT
VCR
GND
FM
ANT
GND
AM
ANT
VIDEO
SIGNAL
TAPE
PB
AUDIO SIGNAL
300-ohm feeder
75-ohm
coaxial cable
75-ohm/300-ohm
antenna adapter
Ground
Outdoor FM antenna
Indoor FM
antenna
(included)
Outdoor AM antenna
AM loop
antenna
(included)
➀
➁
➂
●
Each antenna should be connected to the designated terminals correctly, referring to the following figure.
●
Both AM and FM indoor antennas are included with this unit. In general, these antennas will probably provide sufficient signal
strength. Nevertheless, a properly installed outdoor antenna will give clearer reception than an indoor one. If you experience
poor reception quality, an outdoor antenna may result in improvement.
Connecting the AM loop antenna
12 3
* The AM loop antenna should be placed apart from the main unit. The antenna may be hung on a wall.
* The AM loop antenna should be kept connected, even if an outdoor AM antenna is connected to this unit.
GND terminal
For maximum safety and minimum interference, connect the
GND terminal to a good earth ground. A good earth ground is
a metal stake driven into moist earth.
Notes
●
When connecting the indoor
FM antenna, make sure that
the grooved part of the
connector hole is facing
downward.
●
If you need an outdoor
FM antenna to improve
FM reception quality, either 300-ohm feeder or coaxial cable
may be used. In locations troubled by electrical
interference, coaxial cable is preferable.
Orient so that the best
reception is obtained.
9
Loading...
