Yamaha YDP-S30 User Manual
DIGITAL PIANO
YDP-S30
Owner's Manual
Bedienungsanleitung
Mode d'emploi
Manual de instrucciones
ENGLISHDEUTSCHFRANÇAISESPAÑOL
For information on assembling the keyboard stand, refer to the
instructions on pages 34-36 of this manual.
Weitere Informationen über die Montage des Keyboard-Ständers erhalten
Sie in den Anweisungen auf den Seiten 34-36 dieses Handbuchs.
Pour obtenir les détails sur l'assemblage du pupitre du clavier,
reportez-vous aux instructions figurant aux pages 34-36 de ce manuel.
Para información sobre el montaje del soporte del teclado, consulte
las instrucciones en las páginas 34-36 de este manual.
EN
DE
FR
ES
SPECIAL MESSAGE SECTION
This product utilizes batteries or an external power supply (adapter). DO
NOT connect this product to any power supply or adapter other than one
described in the manual, on the name plate, or specifically recommended by Yamaha.
WARNING: Do not place this product in a position where anyone could
walk on, trip over, or roll anything over power or connecting cords of any
kind. The use of an extension cord is not recommended! If you must use
an extension cord, the minimum wire size for a 25’ cord (or less) is 18
AWG. NOTE: The smaller the AWG number, the larger the current handling capacity. For longer extension cords, consult a local electrician.
This product should be used only with the components supplied or; a
cart, rack, or stand that is recommended by Yamaha. If a cart, etc., is
used, please observe all safety markings and instructions that accompany the accessory product.
SPECIFICATIONS SUBJECT TO CHANGE:
The information contained in this manual is believed to be correct at the
time of printing. However, Yamaha reserves the right to change or modify
any of the specifications without notice or obligation to update existing
units.
This product, either alone or in combination with an amplifier and headphones or speaker/s, may be capable of producing sound levels that
could cause permanent hearing loss. DO NOT operate for long periods
of time at a high volume level or at a level that is uncomfortable. If you
experience any hearing loss or ringing in the ears, you should consult an
audiologist.
IMPORTANT: The louder the sound, the shorter the time period before
damage occurs.
Some Yamaha products may have benches and / or accessory mounting
fixtures that are either supplied with the product or as optional accessories. Some of these items are designed to be dealer assembled or
installed. Please make sure that benches are stable and any optional fixtures (where applicable) are well secured BEFORE using.
Benches supplied by Yamaha are designed for seating only. No other
uses are recommended.
NOTICE:
Service charges incurred due to a lack of knowledge relating to how a
function or effect works (when the unit is operating as designed) are not
covered by the manufacturer’s warranty, and are therefore the owners
responsibility. Please study this manual carefully and consult your dealer
before requesting service.
ENVIRONMENTAL ISSUES:
Yamaha strives to produce products that are both user safe and environmentally friendly. We sincerely believe that our products and the production methods used to produce them, meet these goals. In keeping with
both the letter and the spirit of the law, we want you to be aware of the
following:
Battery Notice:
This product MAY contain a small non-rechargeable battery which (if
applicable) is soldered in place. The average life span of this type of battery is approximately five years. When replacement becomes necessary,
contact a qualified service representative to perform the replacement.
This product may also use “household” type batteries. Some of these
may be rechargeable. Make sure that the battery being charged is a
rechargeable type and that the charger is intended for the battery being
charged.
When installing batteries, do not mix batteries with new, or with batteries
of a different type. Batteries MUST be installed correctly. Mismatches or
incorrect installation may result in overheating and battery case rupture.
Warning:
Do not attempt to disassemble, or incinerate any battery. Keep all batteries away from children. Dispose of used batteries promptly and as regulated by the laws in your area. Note: Check with any retailer of
household type batteries in your area for battery disposal information.
Disposal Notice:
Should this product become damaged beyond repair, or for some reason
its useful life is considered to be at an end, please observe all local,
state, and federal regulations that relate to the disposal of products that
contain lead, batteries, plastics, etc. If your dealer is unable to assist
you, please contact Yamaha directly.
NAME PLATE LOCATION:
The name plate is located on the bottom of the product. The model number, serial number, power requirements, etc., are located on this plate.
You should record the model number, serial number, and the date of purchase in the spaces provided below and retain this manual as a permanent record of your purchase.
92-BP (bottom)
Model
Serial No.
Purchase Date
PLEASE KEEP THIS MANUAL
PRECAUTIONS
PLEASE READ CAREFULLY BEFORE PROCEEDING
* Please keep this manual in a safe place for future reference.
WARNING
Always follow the basic precautions listed below to avoid the possibility of serious injury or even death from electrical
shock, short-circuiting, damages, fire or other hazards. These precautions include, but are not limited to, the following:
Power supply/AC power adaptor
• Only use the voltage specified as correct for the instrument. The required
voltage is printed on the name plate of the instrument.
• Use the specified adaptor (PA-5D, PA-150 or an equivalent recommended by
Yamaha) only. Using the wrong adaptor can result in damage to the instrument
or overheating.
• Check the electric plug periodically and remove any dirt or dust which may have
accumulated on it.
• Do not place the AC adaptor cord near heat sources such as heaters or radiators,
and do not excessively bend or otherwise damage the cord, place heavy objects
on it, or place it in a position where anyone could walk on, trip over, or roll
anything over it.
Do not open
• Do not open the instrument or attempt to disassemble the internal parts or
modify them in any way. The instrument contains no user-serviceable parts. If it
should appear to be malfunctioning, discontinue use immediately and have it
inspected by qualified Yamaha service personnel.
Water warning
• Do not expose the instrument to rain, use it near water or in damp or wet
conditions, or place containers on it containing liquids which might spill into
any openings.
• Never insert or remove an electric plug with wet hands.
Fire warning
• Do not put burning items, such as candles, on the unit.
A burning item may fall over and cause a fire.
If you notice any abnormality
• If the AC adaptor cord or plug becomes frayed or damaged, or if there is a
sudden loss of sound during use of the instrument, or if any unusual smells or
smoke should appear to be caused by it, immediately turn off the power switch,
disconnect the adaptor plug from the outlet, and have the instrument inspected
by qualified Yamaha service personnel.
CAUTION
Always follow the basic precautions listed below to avoid the possibility of physical injury to you or others, or damage
to the instrument or other property. These precautions include, but are not limited to, the following:
Power supply/AC power adaptor
• When removing the electric plug from the instrument or an outlet, always hold
the plug itself and not the cord.
• Unplug the AC power adaptor when not using the instrument, or during
electrical storms.
• Do not connect the instrument to an electrical outlet using a multiple-connector.
Doing so can result in lower sound quality, or possibly cause overheating in the
outlet.
Location
• Do not expose the instrument to excessive dust or vibrations, or extreme cold or
heat (such as in direct sunlight, near a heater, or in a car during the day) to
prevent the possibility of panel disfiguration or damage to the internal
components.
• Do not use the instrument in the vicinity of a TV, radio, stereo equipment,
mobile phone, or other electric devices. Otherwise, the instrument, TV, or radio
may generate noise.
• Do not place the instrument in an unstable position where it might accidentally
fall over.
• Before moving the instrument, remove all connected adaptor and other cables.
• When setting up the product, make sure that the AC outlet you are using is
easily accessible. If some trouble or malfunction occurs, immediately turn off
the power switch and disconnect the plug from the outlet. Even when the power
switch is turned off, electricity is still flowing to the product at the minimum
level. When you are not using the product for a long time, make sure to unplug
the power cord from the wall AC outlet.
• Use only the stand specified for the instrument. When attaching the stand or
rack, use the provided screws only. Failure to do so could cause damage to the
internal components or result in the instrument falling over.
ENGLISH
(3)-10
1
YDP-S30 Owner’s Manual
3
Connections
• Before connecting the instrument to other electronic components, turn off the
power for all components. Before turning the power on or off for all
components, set all volume levels to minimum. Also, be sure to set the volumes
of all components at their minimum levels and gradually raise the volume
controls while playing the instrument to set the desired listening level.
Maintenance
• When cleaning the instrument, use a soft, dry cloth. Do not use paint thinners,
solvents, cleaning fluids, or chemical-impregnated wiping cloths.
Handling caution
•Take care that the key cover does not pinch your fingers, and do not insert a
finger or hand in any gaps on the key cover or instrument.
• Never insert or drop paper, metallic, or other objects into the gaps on the key
cover, panel or keyboard. If this happens, turn off the power immediately and
unplug the power cord from the AC outlet. Then have the instrument inspected
by qualified Yamaha service personnel.
• Do not place vinyl, plastic or rubber objects on the instrument, since this might
ENGLISH
discolor the panel or keyboard.
• Do not rest your weight on, or place heavy objects on the instrument, and do not
use excessive force on the buttons, switches or connectors.
• Do not use the instrument/device or headphones for a long period of time at a
high or uncomfortable volume level, since this can cause permanent hearing
loss. If you experience any hearing loss or ringing in the ears, consult a
physician.
Saving data
Saving and backing up your data
• Data in the instrument’s internal memory can be lost due to operational errors or
malfunction. Be sure to save any important data to external media via a
computer connected to the instrument. (page 31)
Yamaha cannot be held responsible for damage caused by improper use or modifications to the instrument, or data that is lost or destroyed.
Always turn the power off when the instrument is not in use.
Even when the power switch is in the “STANDBY” position, electricity is still flowing to the instrument at the minimum level. When you are not using the instrument for a long
time, make sure you unplug the AC power adaptor from the wall AC outlet.
YDP-S30 Owner’s Manual
4
(3)-10
2
We l come
Thank you for purchasing the Yamaha Digital Piano! We recommend that you read this manual carefully so that you can
take full advantage of the advanced and convenient functions of your new digital piano.
We also recommend that you keep this manual in a safe, convenient place for future reference.
About this Owner’s Manual
This manual consists of three main sections: “Introduction,” “Reference” and “Appendix.”
Introduction (page 2):
Please read this section first.
Reference (page 13):
This section explains how to make detailed settings for the instrument’s various functions.
Appendix (page 39):
This section introduces reference material.
*The illustrations as shown in this owner’s manual are for instructional purposes only, and may be different from the
ones on your instrument.
COPYRIGHT NOTICE
This product incorporates and bundles computer programs and contents in which Yamaha owns copyrights or with
respect to which it has license to use others’ copyrights. Such copyrighted materials include, without limitation, all
computer software, MIDI files and WAVE data. Any unauthorized use of such programs and contents outside of personal use is not permitted under relevant laws. Any violation of copyright has legal consequences. DON’T MAKE,
DISTRIBUTE OR USE ILLEGAL COPIES.
Copying of the commercially available software is strictly prohibited except for your personal use.
Trademarks:
•Windows is a registered trademark of Microsoft® Corporation.
•All other trademarks are the property of their respective holders.
ENGLISH
3
YDP-S30 Owner’s Manual
5
Ta b le of Contents
Introduction
SPECIAL MESSAGE SECTION ...................... 2
Welcome...............................................................5
About this Owner’s Manual........................ 5
Table of Contents ....................................... 6
Application Index........................................ 7
Accessories .................................................. 8
Maintenance ............................................... 8
Features....................................................... 9
Before Using the Digital Piano ................. 10
ENGLISH
Turning the Power On.......................................10
Key cover and music rest ...................................11
Setting the Volume.............................................12
Using Headphones.............................................12
Reference
Part Names................................................ 14
Listening to the Demo Songs ................... 15
Listening to 50 Piano Preset Songs .......... 16
Listening to Songs Loaded from
the Computer......................................... 17
Selecting & Playing Voices........................ 18
Selecting Voices..................................................18
Using the Pedals .................................................19
Adding Variations to the Sound – Reverb........20
Layering Two Voices (Dual mode) ...................21
Transposition .....................................................22
Fine-tuning the Pitch .........................................22
Using the Metronome........................................23
Adjusting the Keyboard Touch
(Touch Sensitivity) ........................................24
Recording your Performance.................... 25
Playing Back Recorded Performance Data .......26
Song Clear...........................................................26
Connecting MIDI Instruments.................. 27
About MIDI........................................................27
MIDI’s Capability...............................................27
Connecting the Digital Piano to
a Computer ............................................ 28
MIDI Functions.......................................... 29
MIDI Transmit/Receive Channel Selection......29
Local Control ON/OFF......................................29
Program Change ON/OFF.................................30
Control Change ON/OFF ..................................30
Transmitting Song Data between
the Computer and the Digital Piano...... 31
Loading Song Data from a Computer to the
Digital Piano .................................................. 31
Transmitting Song Data from the Digital
Piano to a Computer..................................... 31
Backing up Data and Initializing the Settings .. 32
Troubleshooting........................................ 33
Options...................................................... 33
Keyboard Stand Assembly ........................34
Index.......................................................... 37
Appendix
MIDI Data Format .....................................40
MIDI Implementation Chart .....................44
Specifications ............................................46
YDP-S30 Owner’s Manual
6
4
Application Index
Use this index to find reference pages that may be helpful for your particular application and situation.
Listening
Listening to demo songs with different voices...................................................... “Listening to the Demo Songs” on page 15
Listening to songs from “50 Greats for the Piano” ...................................... “Listening to 50 Piano Preset Songs” on page 16
Listening to recorded performances................................................. “Playing Back Recorded Performance Data” on page 26
Listening to songs loaded from the computer......................... “Listening to Songs Loaded from the Computer” on page 17
Playing
Using three pedals ....................................................................................................................... “Using the Pedals” on page 19
Shifting the pitch of the keyboard up or down in semitone steps................................................ “Transposition” on page 22
Fine-tuning the pitch of the entire instrument when you play this instrument
along with other instruments or CD music....................................................................... “Fine-tuning the Pitch” on page 22
Adjusting the key touch response (sensitivity) for changing the volume
.............................................................................................. “Adjusting the Keyboard Touch (Touch Sensitivity)” on page 24
Changing voices
Viewing the list of voices............................................................................................................. “Selecting Voices” on page 18
Simulating a concert hall ....................................................................“Adding Variations to the Sound – Reverb” on page 20
Combining two voices....................................................................................“Layering Two Voices (Dual mode)” on page 21
Practicing
Practicing with an accurate and steady tempo .................................................................“Using the Metronome” on page 23
ENGLISH
Recording
Recording your performances ............................................................................... “Recording your Performance” on page 25
Erasing recorded song.......................................................................................................................... “Song Clear” on page 26
Connecting this instrument to other devices
What is MIDI? ..................................................................................................... “Connecting MIDI Instruments” on page 27
Connecting the computer............................................................ “Connecting the Digital Piano to a Computer” on page 28
Tr ansmitting the recording of your performance to a computer
..........................................................................“Transmitting Song Data from the Digital Piano to a Computer” on page 31
Tr ansmitting song data from a computer to the instrument
..................................................................................“Loading Song Data from a Computer to the Digital Piano” on page 31
Assembling
Assembling and disassembling this instrument..................................................“Keyboard Stand Assembly” on pages 34–36
5
YDP-S30 Owner’s Manual
7
Accessories
• “50 Greats for the Piano” (Music Book)
• Owner’s Manual
This manual contains complete instructions for operating your digital piano.
• Quick Operation Guide
• AC Power Adaptor (Yamaha PA-5D, PA-150 or an equivalent)*
* May not be included depending on your particular area. Check with your Yamaha dealer for details.
Maintenance
ENGLISH
Clean the instrument using a dry or slightly damp soft cloth (wring well).
CAUTION
Do not use benzene, thinner, detergent, or chemically-treated cloth for cleaning. Do not place vinyl, plastic or rubber
products on the instrument.
Otherwise, the panel or keys may become discolored or degraded.
CAUTION
Before using this instrument, be sure to read “Precautions” on pages 3 – 4.
Tuning
Unlike an acoustic piano, this instrument does not need to be tuned. It always stays perfectly in tune.
Transporting
If you move to another location, you can transport this instrument along with your other belongings. You can move
the unit as it is (assembled) or you can disassemble the unit before moving.
Tr ansport the keyboard horizontally. Do not lean it up against a wall or stand it up on its side. Do not subject the
instrument to excessive vibration or shock.
YDP-S30 Owner’s Manual
8
6
Features
The Yamaha YDP-S30 digital piano features a special “GHS (Graded Hammer Standard)” keyboard that offers natural
grand-piano type playability.
The GHS keyboard simulates the touch of a fine piano keyboard that changes key weight over the range of the entire keyboard from low to high, providing a luxurious and natural playability.
The sound source of the YDP-S30 uses Yamaha’s original “AWM Stereo Sampling” tone-generation technology for rich
and musical voices.
Tw o of the piano voices, “Grand Piano 1” and “Grand Piano 2,” feature totally new samples recorded from a full-size concert grand piano. The “Electric Piano” voice features multiple samples for different velocities (Dynamic Sampling); that
is, different samples are used depending on how fast or strong you strike the keys.
This digital piano sounds much closer to a true acoustic piano.
[DEMO/SONG]
Listen to the playback of a demo song
for each voice and 50 piano preset
songs (page 15).
[PIANO/VOICE]
Select one of 6 internal sounds, including Grand Piano 1 and 2 (page 18).
You can also layer two voices together
(page 21) or select various reverb
effects (page 20).
[REC]
Record your performance (page 25).
[PLAY]
Play back your recorded performance
(page 26).
........
........
[MASTER VOLUME]
Adjust the volume level using this control
(page 12).
........
........
[METRONOME]
Control the metronome functions (page 23).
[SELECT –/+]
........
Select a demo song for each voice, or one
of the 50 piano preset songs (page 15 and
16). You can also select a different voice
while the song playback is stopped.
ENGLISH
[DC-IN 12V]
Connect the included power
adaptor here (page 10).
IN OUT
Front
7
MIDI [IN/OUT]
Connect a MIDI device to this jack to
........
MIDI
use various MIDI functions (pages 27–
28). (Connecting MIDI Instruments—
page 27)
........
[PHONES]
PHONES
A set of standard stereo headphones
can be plugged in here for private practice (page 12).
TO PEDAL
....
[PEDAL]
Connect the pedal cord
(page 34).
Shows the [DC-IN 12V] and [PEDAL]
jacks as seen when viewed from the
rear of the instrument.
..
DC IN 12V
Owner’s Manual
YDP-S30
9
Before Using the Digital Piano
Tu rning the Power On
1. Connect the power adaptor.
1-1 Make sure that the
1-2 Insert the DC plug on the power adaptor into the [DC IN 12V] jack.
1-3 Insert the AC plug on the power adaptor into a wall AC outlet.
[DC IN 12V] jack
1-2
ENGLISH
[STANDBY/ON] button is set to STANDBY.
1-3
adaptor
WARNING
Use the specified adaptor (PA-5D, PA-150, or an equivalent recommended by yamaha) only. The use of other adaptors may result in
irreparable damage to both the adaptor and the instrument.
WARNING
Unplug the AC Power Adaptor when not using the instrument, or during electrical storms.
2. Turn the power on.
Press the [STANDBY/ON] button.
•The power indicator located below the left end of the keyboard lights up.
[STANDBY/ON]
Power indicator
AC outlet
To turn the power off, press the
•The power indicator turns off.
CAUTION
Even when the switch is in the “STANDBY” position, electricity is still flowing to the instrument at a minimum level. When not using the
instrument for an extended period of time, be sure to unplug the AC power adaptor from the wall AC outlet.
YDP-S30 Owner’s Manual
10
[STANDBY/ON] button again.
8
Key cover and music rest
Opening the key cover
1. Hold the ledge of the key cover top with both hands, then open the key cover slowly.
2. Fold the front panel strip.
3. Unfold the music rest.
ENGLISH
Closing the key cover
1. Fold the music rest.
2. Unfold the front panel strip.
3. Hold the key cover with both hands and close it slowly.
CAUTION
Before closing the key cover, be sure to fold the music rest and unfold the front panel strip.
9
YDP-S30 Owner’s Manual
11
Setting the Volume
When you start playing, adjust the [MASTER VOLUME] control to the most comfortable listening level.
The level decreases. The level increases.
CAUTION
Do not use this instrument at a high volume level for a long period of time, or your hearing may be damaged.
ENGLISH
Using Headphones
Connect a pair of headphones to one of the [PHONES] jacks.
Tw o [PHONES] jacks are provided.
You can connect two sets of standard stereo headphones. (If you are
using only one pair of headphones, you can plug them into either
jack.)
bottom surface
PHONES
standard stereo
phone plug
YDP-S30 Owner’s Manual
12
10
This section explains how to make detailed settings for this
Reference
instrument’s various functions.
ENGLISH
Part Names................................................................ 14
Listening to the Demo Songs................................... 15
Listening to 50 Piano Preset Songs.......................... 16
Listening to Songs Loaded from the Computer .....17
Selecting & Playing Voices ....................................... 18
Selecting Voices ........................................................... 18
Using the Pedals .......................................................... 19
Adding Variations to the Sound – Reverb.................. 20
Layering Two Voices (Dual mode) ............................. 21
Tr ansposition............................................................... 22
Fine-tuning the Pitch.................................................. 22
Using the Metronome................................................. 23
Adjusting the Keyboard Touch (Touch Sensitivity) .. 24
Recording your Performance................................... 25
Playing Back Recorded Performance Data ................ 26
Song Clear ................................................................... 26
Connecting MIDI Instruments ............................... 27
About MIDI................................................................. 27
MIDI’s Capability........................................................ 27
Connecting the Digital Piano to a Computer ................28
MIDI Functions........................................................ 29
MIDI Transmit/Receive Channel Selection ............... 29
Local Control ON/OFF............................................... 29
Program Change ON/OFF ......................................... 30
Control Change ON/OFF ........................................... 30
Tr ansmitting Song Data between the Computer and
the Digital Piano....................................................... 31
Loading Song Data from a Computer to the Digital
Piano ........................................................................ 31
Tr ansmitting Song Data from the Digital Piano to a
Computer................................................................. 31
Backing up Data and Initializing the Settings ........... 32
Tr oubleshooting ....................................................... 33
11
Keyboard Stand Assembly ....................................... 34
Index......................................................................... 37
YDP-S30 Owner’s Manual
13
Part Names
2
3
ENGLISH
4
6
7 8
IN OUT
5
MIDI
9
#
TO PEDAL
$
!
%
1
DC IN 12V
@
14
PHONES
)
1 [STANDBY/ON] ............................. P10
2 [MASTER VOLUME]....................... P12
3 [METRONOME]............................. P23
4 [DEMO/SONG] ............................. P15
5 [PIANO/VOICE]........................P18–21
6 [SELECT –/+] ..................... P15, 16, 18
7 [REC]............................................. P25
8 [PLAY] ..................................... P25, 26
Owner’s Manual
YDP-S30
9 MIDI [IN]/[OUT] ........................... P27
0 [PHONES] ..................................... P12
A [PEDAL]......................................... P34
B [DC-IN 12V].................................. P10
C Soft (Left) Pedal ............................ P19
D Sostenuto (Center) Pedal .............. P19
E Damper (Right) Pedal ................... P19
12
Listening to the Demo Songs
Demo songs are provided that effectively demonstrate each of this instrument’s voices.
Procedure
1. Turn on the power.
(In case the power is not turned ON) Press the [STANDBY/ON] button.
When you start playing, adjust the [MASTER VOLUME] control to the most
comfortable listening level.
2. Start playing back a demo song.
Press the [DEMO/SONG] button.
The demo song for the currently-selected voice starts playing.
Refer to the voice list on
page 18 for more information on
the characteristics of each preset voice.
3. Select and play a demo song.
While a demo song is playing, press the [SELECT –/+] button to select and play
the next demo song.
If you wish to select a particular demo song from 6 voice demo songs, while
holding down the [DEMO/SONG] button, press one of the C1–F1 keys.
The selected demo song starts to play. Starting with the selected song, the
playback of the demo songs will continue in the following sequence: other
voice demo songs, followed by 50 piano preset songs, and any songs
loaded from the computer. The sequence then returns to the first demo
song and repeats until you stop it.
The lowest key
Demo Songs
Each of the 6 voices features its own demo song that showcases the corresponding voice. Please refer to “Selecting Voices” on page 18.
The demo songs listed below are re-arranged excerpts from the original compositions.
The other demo songs are Yamaha’s original pieces (©2005 Yamaha Corporation).
KeyVoice Name Title Composer
C1 GrandPiano1 “Eintritt” Waldszenen Op.82 R. Schumann
D
1 Harpsichord Gavotte J.S. Bach
C1 F1
ENGLISH
The demo songs will not be
transmitted via MIDI.
Adjusting the Volume
[MASTER VOLUME] control to adjust the volume.
Use the
4. Stop the Voice demo.
Press the [DEMO/SONG] button to stop playback.
13
YDP-S30 Owner’s Manual
15
Loading...
