Yamaha AX-9 User Manual

Natural Sound Stereo Integrated Amplifier
Préampli/ampli de puissance stéréo de la série “Natural Sound”
Natural Sound Stereo-Verstärker
Natural Sound Integrerad Stereo Förstärkare
Amplificatore integrato stereo a Suono Naturale
Amplificador integrado estéreo de Sonido Natural
Natural Sound Geïntegreerde Stereo Versterker
OWNER’S MANUAL
MODE D’EMPLOI
BEDIENUNGSANLEITUNG
BRUKSANVISNING
MANUALE DI ISTRUZIONI
MANUAL DE INSTRUCCIONES
GEBRUIKSAANWIJZING
B G R
2
Remote Control Transmitter
Emetteur de télécommande
Fernbedienung
Fjärrkontroll
Telecomando
Transmisor del control remoto
Afstandbediening
Batteries (size AA, R6, UM-3)
Piles (taille AA, R6, UM-3)
Batterien (Größe AA, R6, UM-3)
Batterier (storlek AA, R6, UM-3)
Batterie (dimensioni AA, R6, UM-3)
Pilas (tamaño AA, R6, UM-3)
Batterijen (maat AA, R6, UM-3)

SUPPLIED ACCESSORIES

After unpacking, check that the following parts are contained.
ACCESSOIRES FOURNIS
Après le déballage, vérifier que les pièces suivantes sont incluses.
MITGELIEFERTES ZUBEHÖR
Nach dem Auspacken überprüfen, ob die folgenden Teile vorhanden sind.
MEDFÖLJANDE TILLBEHÖR
Kontrollera efter det apparaten packats upp att följande delar finns med.
ACCESSORI IN DOTAZIONE
Verificare che tutte le parti seguenti siano contenute nell’imballaggio dell’apparecchio.
ACCESORIOS INCLUIDOS
Desembale el aparato y verificar que los siguientes accesorios están en la caja.
BIJGELEVERDE ACCESSOIRES
Controleer na het uitpakken of de volgende onderdelen voorhanden zijn.
YAMAHA HIFI SYSTEM
REMOTE CONTROL TRANSMITTER
MD
REC/PAUSE
DIR BDIR A
PLAY
DISC
POWER VOLUME
PLAY
AUX
PRESET
A/B/C/D/E
–+
SLEEP
TAPE
A/B
TUNER
CD
PHONO
3

English

Thank you for selecting this YAMAHA stereo amplifier.
50W + 50W (8) RMS Output Power, 0.03% THD, 20–20,000 Hz
High Dynamic Power, Low Impedance Drive Capability
PURE DIRECT Switch to Reproduce the Purest Source Sound
Remote Control Capability
Supplied Accessories .........................................................................................2
Caution ...............................................................................................................4
Notes about the Remote Control Transmitter .....................................................5
Connections .......................................................................................................6
Controls and Their Functions .............................................................................8
Operations .......................................................................................................10
Troubleshooting ................................................................................................13
Specifications ...................................................................................................14
FEATURES
CONTENTS
4
1. To assure the finest performance, please read this manual
carefully. Keep it in a safe place for future reference.
2. Install this unit in a cool, dry, clean place – away from windows,
heat sources, sources of excessive vibration, dust, moisture and cold. Avoid sources of humming (transformers, motors). To prevent fire or electrical shock, do not expose the unit to rain or water.
3. Never open the cabinet. If something drops into the set, contact
your dealer.
4. Do not use force on switches, controls or connection wires. When
moving the unit, first disconnect the power plug and the wires connected to other equipment. Never pull the wires themselves.
5. The openings on the cabinet assure proper ventilation of the unit.
If these openings are obstructed, the temperature inside the cabinet will rise rapidly and eventually damage the circuits. Therefore, avoid placing objects against these openings and do not install the unit where the flow of air through the ventilation openings could be impeded.
6. Always set the VOLUME control to “0” before starting the audio
source play: increase the volume gradually to an appropriate level after the play has been started.
7. Do not attempt to clean the unit with chemical solvents; this might
damage the finish. Use a clean, dry cloth.
8. Be sure to read the “TROUBLESHOOTING” section regarding
common operating errors before concluding that the unit is faulty.
9. When not planning to use this unit for long periods of time
(ie., vacation, etc.), disconnect the AC power plug from the wall outlet.
10.To prevent lightning damage, disconnect the AC power plug and
disconnect the antenna cable when there is an electrical storm.
11.Grounding or polarization – Precautions should be taken so that
the grounding or polarization of an appliance is not defeated.
12.AC outlet
Do not connect audio equipment to the AC outlet on the rear panel if that equipment requires more power than the outlet is rated to provide.
13.Voltage Selector (General Model only)
The voltage selector on the rear panel of this unit must be set for your local main voltage BEFORE plugging into the AC main supply. Voltages are 110/120/220/240V AC, 50/60 Hz.
IMPORTANT
Please record the serial number of this unit in the space below. Serial No.: The serial number is located on the rear of the unit.
Retain this Owner’s Manual in a safe place for future reference.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
For U.K. customers
If the socket outlets in the home are not suitable for the plug supplied with this appliance, it should be cut off and an appropriate 3 pin plug fitted. For details, refer to the instructions described below. Note: The plug severed from the mains lead must be destroyed, as a plug with bared flexible cord is hazardous if engaged in a live socket outlet.
SPECIAL INSTRUCTIONS FOR U.K. MODEL
IMPORTANT:
The wire in the mains lead are coloured in accordance with the following code:
Blue: NEUTRAL Brown: LIVE
The colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the terminals in your plug. Proceed as follows: the wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or coloured BLACK. The wire which is coloured BROWN must be connected to the terminal which is marked with the letter L or coloured RED. Making sure that neither core is connected to the earth terminal of the three pin plug.
CAUTION: READ THIS BEFORE OPERATING YOUR UNIT.
This unit is not disconnected from the AC power source as long as it is connected to the wall outlet, even if this unit itself is turned off. In this state, this unit is designed to consume a very small quantity of power.
WARNING Do not change the IMPEDANCE SELECTOR switch setting while the power to this unit is on, otherwise this unit may be damaged.
IF THIS UNIT FAILS TO TURN ON WHEN THE STANDBY/ON SWITCH IS PRESSED
The IMPEDANCE SELECTOR switch may not be set to either end closely. If so, set the switch to either end closely.
L
A
B
+
SWITCHED l00W MAX. TOTAL
VOLTAGE SELECTOR
IMPEDANCE SELECTOR SET BEFORE POWER ON
AC OUTLETS
SPEAKERS
A OR B:4MIN./SPEAKER
A + B:8MIN./SPEAKER
A OR B:8MIN./SPEAKER
A + B:l6MIN./SPEAKER
IMPEDANCE SELECTOR
(General model)
5
English

NOTES ABOUT THE REMOTE CONTROL TRANSMITTER

Battery installation
Battery replacement
If you find that the remote control transmitter must be used closer to the main unit, the batteries are weak. Replace both batteries with new ones.
Notes
Use only AA, R6, UM-3 batteries for replacement.
Be sure the polarities are correct. (See the illustration inside the battery compartment.)
Remove the batteries if the remote control transmitter will not be used for an extended period of time.
If batteries leak, dispose of them immediately. Avoid touching the leaked material or letting it come in contact with clothing, etc. Clean the battery compartment thoroughly before installing new batteries.
Remote control transmitter operation range
Notes
There should be no large obstacles between the remote control transmitter and the main unit.
If the remote control sensor is directly illuminated by strong lighting (especially an inverter type of fluorescent lamp etc.), it might cause the remote control transmitter not to work correctly. In this case, reposition the main unit to avoid direct lighting.
1
3
2
30°
30°
Remote control sensor
Within approximately 6 m (19.7 feet)
