Chapter 1
1.1 Features
1. Microprocessor based with OSD (On Screen Display) control.
2. Compatible with standard IBM VGA, extended VGA, super VGA, IBM XGA modes, as well as VESA resolution standards.
3. Universal power supply15", 17", 19"(100-240 Vac, 50/60Hz, 1.0A).
14"(100-240 Vac, 50/60Hz, 1.5A).
4. Microsoft Windows 95/98/2000/ME/XP compatible & VESA Display Data
channel
5. Safety Model No.: 14"(468P), 15"(500P), 17"(700P), 19"(900P).
1.2 Checking List
Please make sure the following items are included with your LCD monitor:
Your monitor
User manual
If any of these items are missing, please contact with your dealer for Technical support and customer service.
(DDC)1/2B compatible.
AC power cord
Signal cable
Introduction
Note:
Be sure to save original box and all packing material for transport in future if the Monitor need .
1
