Yakima Q10 Installation Instructions Manual

Q1

0 A

BUICK

Skylark 4dr

85-91 Q10-A Q5-A 114,161

40 -1/4" 5" 39 -1/2" 34"

Somerset 4dr 85-91 Q10-A Q5-A 114,161

40 -1/4" 5" 39 -1/2" 34"

JAGUAR

X-Type 02 Q10-A Q5-A 54,114,161

39"

7" 39 -3/4" 32"

MAZDA

Protege'

90-94 Q10-A Q10-A 114,161

38"

5" 38 -1/8" 30"

OLDSMOBILE

Cutlass Calais 2dr Coupe 85-91 Q10-A Q10-A 101,161

40 -1/2" 6" 40" 20"

Cutlass Calais 2dr Coupe 85-91 Q10-A Q5-A 161

with Q Stretch Kit 40

-1/2" 6" 38 -7/8" 36"

Cutlass Calais 4dr (FWD) 85-91 Q10-A Q5-A 161

40

-1/4" 5" 39 -1/2" 34"

PONTIAC

Grand Am 4dr

85-91 Q10-A Q5-A 114,161

40

-1/4" 5" 39

-

5/8

" 34"

10

10

16

1

11

4

Check clips after installing. Grab each clip and
try to pull them away from vehicle. If the clip
moves, tighten the adjustment post. If the clip
still moves, recheck your measurement
between the towers and adjust if necessary.
Check again.

101

Surf/sailboard length is limited to 8'
or less on this vehicle.

54

When open, the sunroof may interfere
with accessories placed between the
bars.
