1 GENERAL INFORMATION
The Vertex Standard GX1000S ECLIPSE DCS is a VHF/FM transceiver designed for use in the
frequency range of 156.025 to 163.275 MHz. The GX1000S ECLIPSE DCS can be operated from 1 1
to 16 VDC and has a switchable RF output power of 1 watt or 25 watts.
The GX1000S ECLIPSE DCS is capable of RTCM SC101 DSC (Digital Selective Calling) operation.
The GX1000S ECLIPSE DCS operates on all currently-allocated marine channels which are
switchable for use with either USA, International, or Canadian regulations. It has an emergency
channel 16 which can be immediately selected from any channel by pressing the red [16/9] key.
NOAA Weather channels can also be accessed immediately by pressing the [WX] key.
Other features of the transceiver include: scanning, priority scanning, submersible mic, high and low
voltage warning, and GPS repeatability.
2 PACKING LIST
When the package containing the transceiver is first opened, please check it for the following
contents:
GX1000S ECLIPSE DCS Transceiver
Mounting Bracket and attaching hardware
Panel Cover
Owner’s Manual
Power Cord
3 OPTIONS
MMB-84 Flush-Mount Bracket
MLS-310 Amplified External Speaker
MLS-300 External Loudspeaker
101W White External Speaker
4 SAFETY / WARNING INFORMATION
This radio is restricted to occupational use, work related operations only where the radio operator
must have the knowledge to control the exposure conditions of its passengers and bystanders by
maintaining the minimum separation distance of 0.6 m (2 feet).
Failure to observe these restrictions will result in exceeding the FCC RF exposure limits.
Antenna Installation:
The antenna must be located at least 0.6 m (2 feet) away from passengers in order to comply with
the FCC RF exposure requirements.
ON-LINE WARRANTY REGISTRATION
Please visit www.standardhorizon.com to register the GX1000S Marine VHF. It should be noted that
visiting the Web site from time to time may be beneficial to you, as new products are released they
will appear on the Marine Division of Vertex Standard Web site.
FCC ID: K6630303X3S
IC ID: 511B-30303X3S
GX1000S Operating Manual
PRODUCT SUPPORT INQUIRIES
If you have any questions or comments regarding the use of the GX1000S, you can visit the Marine
Division of Vertex Standard Web site to send an E-Mail or contact the Product Support team at
800-767-2450 M-F 7:00-5:00PST.
5 FCC RADIO LICENSE INFORMATION
Vertex Standard radios comply with the Federal Communication Commission (FCC) requirements
that regulate the Maritime Radio Service.
STATION LICENSE
An FCC ship station license is no longer required for any vessel traveling in U.S. waters (except
Hawaii) which is under 20 meters in length. However, any vessel required to carry a marine radio on
an international voyage, carrying a HF single side band radiotelephone or marine satellite terminal is
required to have a ship station license. FCC license forms, including applications for ship (506) and
land station licenses can be downloaded via the Internet at www .fcc.gov/forms. To obtain a form from
the FCC, call (888) 225-5322.
RADIO CALL SIGN
Currently the FCC does not require recreational boaters to have a Ship Radio Station License. The
USCG recommends the boats registration number and the state to be used.
CANADIAN SHIP STATION LICENSING
You may need a license when traveling in Canada. If you do need a license contact their nearest
field office or regional office or write:
Industry Canada
Radio Regulatory Branch
Attn: DOSP
300 Slater Street
Ottawa, Ontario
Canada, KIA 0C8
FCC / INDUSTRY CANADA INFORMATION
The following data pertaining to the transceiver is necessary to fill out the license application.
Type Acceptance FCC Part 80
Output Power 1 Watt (low) and 25 Watts (high)
Emission 16K0G3E, 16K0G2B
Frequency Range 156.025 to 163.275 MHz
FCC Type Number K6630303X3S
Industry Canada Type Approval 511B-30303X3S
FCC ID: K6630303X3S
IC ID: 511B-30303X3S
GX1000S Operating Manual
6 FCC NOTICE
NOTICE
Unauthorized changes or modifications to this equipment may void compliance with FCC
Rules. Any change or modification must be approved in writing by Marine Division of Vertex
Standard.
NOTICE
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
7 GETTING STARTED
FCC ID: K6630303X3S
IC ID: 511B-30303X3S
GX1000S Operating Manual
7.1 ABOUT VHF RADIO
The radio frequencies used in the VHF marine band lie between 156 and 158 MHz with some shore
stations available between 161 and 163 MHz. The marine VHF band provides communications over
distances that are essentially “line of sight” (VHF signals do not travel well through objects such as
buildings, hills or trees). Actual transmission range depends much more on antenna type, gain and
height than on the power output of the transmitter. On a fixed mount 25W radio transmission
expected distances can be greater than 15 miles.
7.2 SELECTING AN ANTENNA
Marine antennas are made to radiate signals equally in all horizontal directions, but not straight up.
The objective of a marine antenna is to enhance the signal toward the horizon. The degree to which
this is accomplished is called the antenna’s gain. It is measured in decibels (dB) and is one of the
major factors in choosing an antenna. In terms of effective radiated power (ERP), antennas are rated
on the basis of how much gain they have over a theoretical antenna with zero gain. A 3 foot, 3dB
gain antenna represents twice as much gain over the imaginary antenna.
Typically a 3 foot 3dB gain stainless steel whip is used on a sailboat mast. The longer 8 foot 6dB
fiberglass whip is primarily used on power boats that require the additional gain.
7.3 COAXIAL CABLE
VHF antennas are connected to the transceiver by means of a coaxial cable – a shielded
transmission line. Coaxial cable is specified by it’s diameter and construction.
For runs less than 20 feet, RG-58/U, about 1/4 inch in diameter is a good choice. For runs over 20
feet but less than 50 feet, the larger RG-8X should be used for cable runs over 50 feet RG213 should
be used. For installation of the connector onto the coaxial cable refer to the figure below.
To get your coax cable through a fitting and into your boat’s interior, you may have to cut off the end
plug and reattach it later . You can do this if you follow the directions that come with the connector . Be
sure to make good soldered connections.
8 INSTALLATION
8.1 LOCATION
The radio can be mounted at any angle. Choose a mounting location that:
is far enough from any compass to avoid any deviation in compass reading due to the speaker
magnet
provides accessibility to the front panel controls
allows connection to a power source and an antenna
FCC ID: K6630303X3S
IC ID: 511B-30303X3S
GX1000S Operating Manual
has nearby space for installation of a microphone hanger
the antenna must be mounted at least 3 feet from radio
Note: To insure the radio does not affect the compass or radios performance is not affected by the
antenna location, temporarily connect the radio in the desired location and:
a. Examine the compass to see if the radio causes any deviation
b. Connect the antenna and key the radio. Check to ensure the radio is operating correctly by
requesting a radio check.
8.2 ELECTRICAL CONNECTIONS
CAUTION
Reverse polarity connections will damage the radio!
Connect the power cord and antenna to the radio. Antenna and Power Supply connections are as
follows (see Figure 1):
1. Mount the antenna at least 3 feet away from the radio. At the rear of the radio, connect the
antenna cable.
2. Connect the red power wire to a 13.8 VDC ±20% power source. Connect the black power wire
to a negative ground.
3. If an optional remote extension speaker is to be used, refer to next section for connections.
4. It is advisable to have a Certified Marine Technician check the power output and the standing
wave ratio of the antenna after installation.
8.3 ACCESSORY CABLE
When connecting the external speaker or GPS navigation receiver, strip off about 1 inch (2.5 cm) of
the specified wire’s insulation, then splice the ends together using proper waterproofing techniques.
The GPS must have the NMEA Output turned on and set to 4800 Baud in the setup menu. If
there is a selection for parity select none.
For further information on interfacing /setting up your GPS. Please contact the manufacturer of
the GPS receiver.
GX1000S can read NMEA-0183 version 2.0 or higher.
The NMEA supported sentences are:
Input: GLL, GGA, RMC and GNS (RMC sentence is recommended)
Output: DSC and DSE
(DSC sentences to Standard Horizon Plotter for Position Polling)
If you have further inquires, please feel free to contact Product Support at:
Phone: (800) 767-2450
Email: marinetech@vxstdusa.com
FCC ID: K6630303X3S
IC ID: 511B-30303X3S
GX1000S Operating Manual
8.4 CHECKING GPS CONNECTIONS
After connections have been made between the GX1000S and the GPS, a small satellite icon will
appear on the LCD display. To see the additional GPS information, press and hold the [H/L] key. The
GX1000S displays “LAT” and “LON” information alternately every two seconds.
8.5 CHANGING THE GPS TIME
From the Factory the GX1000S shows GPS satellite time or UTC time. A time offset is needed to
show the local time in your area.
1. Press and hold down the [CALL(SET)MENU] key until “RADIO SETUP” menu appears.
2. Press the [CALL(SET)MENU] key, then select “OFFSET TIME” with the [T]/[S] keys.
3. Press the [CALL(SET)MENU] key.
4. Press the [T]/[S] keys to select time offset from UTC. See illustration below to find your offset
time from UTC. If “0:00” is assigned, the time is the same as UTC (Universal Time Coordinated
or GMT Greenwich Mean Time).
5. Press the [CALL(SET)MENU] key to store the time offset.
6. Press the [16/9] key to exit the menu mode and return to radio operation.
8.6 CHANGING THE TIME LOCATION
Sets the radio to show UTC time or local time with the offset inputted in section 8.6 Changing the
GPS Time.
1. Press and hold down the [CALL(SET)MENU] key until “RADIO SETUP” menu appears.
2. Press the [CALL(SET)MENU] key, then select “TIME DISP” in the “Radio Setup” menu with the
[T]/[S] keys.
3. Press the [CALL(SET)MENU] key.
4. Press the [T]/[S] keys to select “UTC” or “Local.”
5. Press the [CALL(SET)MENU] key to store the selected setting.
6. Press the [16/9] key to exit the menu mode and return to radio operation.
In the local time mode, the display shows the time by the 12-hour system. Meanwhile, the display
shows the time by the 24-hour system in the UTC mode.
8.7 OPTIONAL MMB-84 FLUSH MOUNT INSTALLATION
1. To assist in flush mounting, a template has been included. Use this template to find the
mounting location.
2. Use the template to mark the location where the rectangular hole is to be cut. Confirm the space
behind the dash or panel is deep enough to accommodate the transceiver (at least 6 inches or
FCC ID: K6630303X3S
IC ID: 511B-30303X3S
GX1000S Operating Manual
15 cm deep).
There should be at least 1/2 inch (1.3 cm) between the transceiver’s heat sink and any wiring,
cables or structures.
3. Cut out the rectangular hole and insert the transceiver.
4. Fasten the brackets to the sides of the transceiver with the lock washer nut combination; so that
the mounting screw base faces the mounting surface (see Figure 2).
5. Turn the adjusting screw to adjust the tension so that the transceiver is tight against the
mounting surface.
9 CONTROLS AND INDICATORS
NOTE
This section defines each control of the transceiver. See Figure 4 for location of controls. For detailed
operating instructions refer to section “10 BASIC OPERATION.”
1. POWER SWITCH / VOLUME CONTROL (VOL)
Turns the transceiver on and off as well as adjusts the audio volume.
Turn this knob clockwise to turn the radio on and to increase the audio volume level.
Turn fully counter-clockwise to turn the radio off.
2. SQUELCH CONTROL (SQL)
Adjusting this control clockwise sets the point at which random noise on the channel does not
activate the audio circuits but a received signal does. This point is called the squelch threshold.
Further adjustment of the squelch control will degrade reception of wanted transmissions.
3. [H/L] Key
Press this key to toggle the transmit output power between 25 W (High) and 1 W (Low) power.
When the [H/L] key is pressed while the transceiver is on channel 13 or 67, the power will
temporarily switch from LO to HI power until the PTT is released.
The [H/L] key does not function on transmit inhibited and low power only channels.
NOTE: 1W low power is indicated by LO on the display, when 25W high power is selected the
display do not show an indication.
Secondary use
Press and hold this key, the LCD displays NAV GPS Time and vessel’s position (LAT/LON)
when a GPS is connected to the accessory cable of the GX1000S. See section “8.4
CONNECTION OF GPS WITH NMEA OUTPUT” for details.
4. [WX] Key
Immediately recalls the previously selected NOAA weather channel from any channel.
Secondary use
Holding down the [16/9] key while pressing the [WX] key changes from USA, International and
Loading...
