FTM-10R Operating Manual
Accessories & Options
Supplied Accessories
Mobile Mounting Bracket
DC Power Cord W/Fuse
Spare Fuse 15 A
Angle Sub Panel
Hex Wrench
Operating Manual
Warranty Card
Optional Accessories
DTMF Microphone MH-68A6J
Normal Microphone MH-68B6J
Panel Separation Kit YSK-M10
Bluetooth Head Set BH-1
Bluetooth Adapter Unit BU-1
Head Set Charger Sleeve CAB-1
Microphone Jack MEK-M10
Ear Phone for BH-1 FEP-4
High-Power External Speaker MLS-200-M10
AC Power Supply (25 A) FP-1025A
AC Power Supply (30 A) FP-1030A
Availability of accessories may vary. Some accessories are supplied as standard per local
requirements, while others may be unavailable in some regions. This product is
designed to perform optimally when used with genuine Vertex Standard accessories.
Vertex Standard shall not be liable for any damage to this product and/or accidents such
as fire, leakage or explosion of a battery pack, etc., caused by the malfunction of non-
Vertex Standard accessories. Consult your Vertex Standard dealer for details regarding
these and any newly-available options. Connection of any non-Vertex
Standard-approved accessory, should it cause damage, may void the Limited Warranty
on this apparatus.
FCC ID: K6620275X40
IC ID: 511B-20275X40
FTM-10R Operating Manual
Installation
This chapter describes the installation procedure for integrating the FTM-10R into a
typical amateur radio station. It is presumed that you possess technical knowledge and
conceptual understanding consistent with your status as a licensed radio amateur.
Please take some extra time to make certain that the important safety and technical
requirements detailed in this chapter are followed closely.
Preliminary Inspection
Inspect the transceiver visually immediately upon opening the packing carton. Confirm
that all controls and switches work freely, and inspect the cabinet for any damage.
Gently shake the transceiver to verify that no internal components have been shaken
loose due to rough handling during shipping.
If any evidence of damage is discovered, document it thoroughly and contact the
shipping company (or your local dealer, if the unit was purchased over-the-counter) so
as to get instructions regarding the prompt resolution of the damage situation. Be
certain to save the shipping carton, especially if there are any punctures or other
evidence of damage incurred during shipping; if it is necessary to return the unit for
service or replacement, use the original packing materials but put the entire package
inside another packing carton, so as to preserve the evidence of shipping damage for
insurance purposes.
Installation Tips
To ensure long life of the components, be certain to provide adequate ventilation around
the cabinet of the FTM-10R.
Do not install the transceiver on top of another heat-generating device (such as a power
supply or amplifier), and do not place equipment, books, or papers on top of the
FTM-10R. Avoid heating vents and window locations that could expose the transceiver
to excessive direct sunlight, especially in hot climates. The FTM-10R should not be used
in an environment where the ambient temperature exceeds +140 °F (+60 °C).
Safety Information
The FTM-10R is an electrical apparatus, as well as a generator of RF (Radio Frequency)
energy, and you should exercise all safety precautions as are appropriate for this type of
device. These safety tips apply to any device installed in a well-designed amateur radio
station.
(!) Never allow unsupervised children to play in the vicinity of your transceiver or
FCC ID: K6620275X40
IC ID: 511B-20275X40
FTM-10R Operating Manual
antenna installation.
(!) Be certain to wrap any wire or cable splices thoroughly with insulating electrical tape,
to prevent short circuits.
(!) Do not route cables or wires through door jambs or other locations where, through
wear and tear, they may become frayed and shorted to ground or to each other.
(!) Do not stand in front of a directional antenna while you are transmitting into that
antenna. Do not install a directional antenna in any location where humans or pets may
be walking in the main directional lobe of the antenna’s radiation pattern.
(!) In mobile installations, it is preferable to mount your antenna on top of the roof of the
vehicle, if feasible, so as to utilize the car body as a counterpoise for the antenna and
raise the radiation pattern as far away from passengers as possible.
(!) During vehicular operation when stopped (in a parking lot, for example), make it a
practice to switch to Low power if there are people walking nearby.
(!) Never wear dual-earmuff headphones while driving a vehicle.
(!) Do not attempt to drive your vehicle while making a telephone call on an autopatch
using the optional DTMF microphone. Pull over to the side of the road, whether dialing
manually or using the auto-dial feature.
Warning!: The 70.7 V RF voltage (@50 W/50 Ohms) is applied to the TX RF section of the
transceiver while transmitting. Do not touch the TX RF section absolutely while
transmitting.
Antenna Considerations
The FTM-10R is designed for use with antennas presenting an impedance of near 50
Ohms at all operating frequencies. The antenna (or a 50 Ohm dummy load) should be
connected whenever the transceiver is turned on, to avoid damage that could otherwise
result if transmission occurs accidentally without an antenna.
Ensure that your antenna is designed to handle 50 Watts of transmitter power. Some
magnetic-mount mobile antennas, designed for use with hand-held transceivers, may
not be capable of withstanding this power level. Consult the antenna manufacturer’s
specification sheet for details.
Most all FM work is performed using vertical polarization. When installing a directional
antenna such as a Yagi or Cubical Quad, be certain to orient it so as to produce vertical
polarization, unless you are engaged in a special operating situation where horizontal
polarization is used. In the case of a Yagi antenna, orient the elements vertically for
vertical polarization; for a Cubical Quad, the feedpoint should be at the center of one of
FCC ID: K6620275X40
IC ID: 511B-20275X40
FTM-10R Operating Manual
the vertical sides of the driven element (or at a side corner, in the case of a
diamond-shaped Cubical Quad).
Note that this transceiver is designed with wide frequency coverage in the VHF/UHF
spectrum. For general listening, you may wish to have a broadband antenna such as a
discone available, as a directional antenna such as a Yagi will have degraded
performance outside the Amateur band for which it is designed.
Excellent reference texts and computer software are available for the design and
optimization of VHF and UHF antennas. Your dealer should be able to assist you with
all aspects of your antenna installation requirements.
Use high-quality 50 Ohm coaxial cable for the lead-in to your FTM-10R transceiver. All
efforts at providing an efficient antenna system will be wasted if poor quality, lossy
coaxial cable is used. Losses in coaxial lines increase as the frequency increases, so an
8-meter-long (25’) coaxial line with under 1 dB of loss at 144 MHz may have a loss of 3
dB or more at 446 MHz; choose your coaxial cable carefully based on the installation
location (mobile vs. base) and the overall length of the cable required (for very short
runs of cable in a mobile installation, the smaller, more flexible cable types may be
acceptable).
For reference, the chart below shows approximate loss figures for typically-available
coaxial cables frequently used in VHF/UHF installations.
In outdoor installations, be certain to weatherproof all connectors thoroughly, as water
entering a coaxial cable will cause losses to escalate rapidly, thus diminishing your
communications effectiveness. The use of the shortest possible length of the highest
quality coaxial cable that fits within your budget will ensure the best performance from
your FTM-10R.
Mobile Installation
The FTM-10R must only be installed in vehicles having a 13.8 Volt negative ground
electrical system. Mount the transceiver where the display, controls, and microphone
are easily accessible, using the supplied MMB-?? Mobile Mounting Bracket.
The transceiver may be installed in almost any location, but should not be positioned
near a heating vent nor anywhere where it might interfere with driving (either visually
or mechanically). Make sure to provide plenty of space on all sides of the transceiver so
that air can flow freely around the radio’s case. Refer to the diagrams showing proper
installation procedures.
FCC ID: K6620275X40
IC ID: 511B-20275X40
FTM-10R Operating Manual
How to use the supplied Angle Sub Panel
FTM-10R can tilt the front panel by using supplied Angle Sub Panel.
Remove the four screws affixing the Front Panel, then remove the Front Panel from
the transceiver’s body.
Disconnect the 8-pin modular plug from the transceiver’s body.
Remove a screw affixing the Straight Sub Panel, then remove the Straight Sub
Panel from the Front Panel.
Affix the supplied Angle Sub Panel to the Front Panel, using the previously
removed screw. You may set up to “look-up” or “look-down” direction by a direction
to install.
Connect the 8-pin modular plug from the transceiver’s body.
Affix the Front Panel (with Angle Sub Panel) to the transceiver’s body, using the
previously removed four screws.
Mobile Power Connections
To minimize voltage drop and avoid blowing the vehicle’s fuses, connect the supplied DC
power cable directly to the battery terminals. Do not attempt to defeat or bypass the DC
cable’s fuse - it is there to protect you, your transceiver, and your vehicle’s electrical
system.
Warning!
Never apply AC power to the power cable of the FTM-10R, nor DC voltage greater than
15.8 Volts. When replacing the fuse, only use a 15-A fuse. Failure to observe these safety
precautions will void the Limited Warranty on this product.
Before connecting the transceiver, check the voltage at the battery terminals while
revving the engine. If the voltage exceeds 15 Volts, adjust the vehicle’s voltage
regulator before proceeding with installation.
Connect the RED power cable lead to the POSITIVE (+) battery terminal, and the
BLACK power cable lead to the NEGATIVE (–) terminal. If you need to extend the
power cable, use #12 AWG or larger insulated, stranded copper wire. Solder the
splice connections carefully, and wrap the connections thoroughly with insulating
electrical tape.
Before connecting the cable to the transceiver, verify the voltage and polarity of the
voltage at the transceiver end of the DC cable using a DC voltmeter. Now connect
the transceiver to the DC cable.
Mobile Speakers
FCC ID: K6620275X40
IC ID: 511B-20275X40
FTM-10R Operating Manual
The optional MLS-200-M10 High-Power External Speaker includes its own swivel-type
mounting bracket, and is available from your Yaesu dealer.
Other external speakers may be used with the FTM-10R, if they present the specified
8-Ohm impedance and are capable of handling the 8 Watts of audio output supplied by
the FTM-10R.
Base Station Installation
The FTM-10R is ideal for base station use as well as in mobile installations. The
FTM-10R is specifically designed to integrate into your station easily, using the
information to follow as a reference.
AC Power Supplies
Operation of the FTM-10R from an AC line requires a power source capable of providing
at least 9 Amps continuously at 13.8 Volts DC. The FP-1025A and FP-1030A AC Power
Supplies are available from your Yaesu dealer to satisfy these requirements. Other
well-regulated power supplies may be used, as well, if they meet the above voltage and
current specifications.
Use the DC power cable supplied with your transceiver for making power connections to
the power supply. Connect the RED power cable lead to the POSITIVE (+) power supply
terminal, and connect the BLACK power cable lead to the NEGATIVE (–) power supply
terminal.
Front Panel Controls & Switches
1. MIC
The internal microphone is located here.
The internal microphone is only activated when the top panel’s [PTT] key is pressed.
2. SELECT Key
Press this key momentarily to select the functions of the front panel’s [X] key and DIAL
knob.
The available selections are:
Transceiver/Frequency mode Transceiver/Volume mode Clock/Timer mode*
Transceiver/Frequency mode …
*: The Clock/Timer mode is disabled at the factory default. To enable this mode, see
page ??.
FCC ID: K6620275X40
IC ID: 511B-20275X40
FTM-10R Operating Manual
3. LCD Display
The main digits on the display may show the operating frequency, memory name, or any
of many parameters during Menu setup.
4. [BANDS] Key
Press this key to switch the operating band as follows:
2 m Amateur Band 430 MHz Amateur Band FM BC Band AM BC Band WX
Band Audio Line Home Channel 2 m Amateur Band …
5. [X] Key
This key function is different by setting of [SELECT] key.
Transceiver/Frequency mode Switch the frequency control between the VFO and
Memory System.
Transceiver/Volume mode Switch the frequency control between the VFO and
Memory System.
Clock/Timer mode* Press this key momentarily to Start/Stop the Stop
Watch timer.
Press and hold this key for two seconds to reset the
Stop Watch timer
*: The Clock/Timer mode is disabled at the factory default. To enable this mode, see
page ??.
6. [BANDT] Key
Press this key to switch the operating band as follows:
2 m Amateur Band Home Channel Audio Line WX Band AM BC Band FM
BC Band 430 MHz Amateur Band 2 m Amateur Band …
7. DIAL Knob
This knob function is different by setting of [SELECT] key.
Transceiver/Frequency mode Select the operating frequency, and also select the
memory channel.
Transceiver/Volume mode Adjust the audio volume level. Clockwise rotation
increases the volume level.
Clock/Timer mode* Select the display
FCC ID: K6620275X40
IC ID: 511B-20275X40
FTM-10R Operating Manual
Clock Stop Watch Timer Stop Watch Timer
(Sum) Current temperature inside the
transceiver’s body Clock …
*: The Clock/Timer mode is disabled at the factory default. To enable this mode, see
page ??.
Top Panel Controls & Switches
1. PTT Key
Press this key activate the internal microphone.
2. [TOPT] Key
Press this key momentarily to select the functions of the top panel’s [F].
The available selections are:
PA HORN 4 HORN 3 HORN 2 HORN 1 SCAN INTERCOM PA …
3. [TOPS] Key
Press this key momentarily to select the functions of the top panel’s [F].
The available selections are:
PA INTERCOM SCAN HORN 1 HORN 2 HORN 3 HORN 4 PA …
4. [F] Key
This key decide/activate the function that is selected by the [TOPT]/[TOPS] keys.
5. [POWER] Switch
Press and hold this key for two seconds to toggle the transceiver’s power on and off.
Press this key momentarily to toggle the key lockout feature on and off while the
transceiver is turned on.
6. Bluetooth Antenna Slit
The Bluetooth Antenna is located here. Do not cover this slit by the metal object.
7. Internal Speaker
The internal speaker is located here.
FCC ID: K6620275X40
IC ID: 511B-20275X40
FTM-10R Operating Manual
Rear Panel Connectors
1. ANT Jack
Connect your antenna hear, using a type-M (PL-259) plug and coaxial cable.
2. DC 13.8 V Cable Pigtail w/Fuse
This is the power supply connection for the transceiver. Use the supplied DC cable to
connect this pigtail to the car battery or other DC power supply capable of at least 10
Amperes (continuous duty). Make certain that the red lead connects to the positive side
of the supply. The fuse is 15-A.
3. MIC Jack
Connect the optional MH-68A6J Hand Microphone to this jack.
4. LINE IN Jack
This 2-contact 3.5-mm mini phone jack
5. EXT SPK Jack
This 2-contact 3.5-mm mini phone jack provides receiver audio output for an optional
external speaker. The audio impedance is 4 Ohms, and the level varies according to the
setting of the front panel’s VOL control. Inserting a plug into this jack disables audio
from the transceiver’s internal speaker.
MH-68A6J Microphone Switches (Option)
1. PTT Key
Press this key activate the MH-68A6J’s microphone.
2. [DWN]/[UP] key
Press (or hold in) either of these keys to tune (or scan up or down) the operating
frequency or through the memory channels.
3. [PGM] key
This key is used programmable, allowing quick access to features used often.
In the USA version, pressing this key recalls the “Weather” broadcast channel bank. In
the EXP version, pressing this key activates T.CALL (1750 Hz) for repeater access.
You can reprogram this key for other functions, if desired. See page for details.
FCC ID: K6620275X40
IC ID: 511B-20275X40
FTM-10R Operating Manual
4. Keypad
These 16 keys generate DTMF tones during transmission.
In the receive mode, these 16 keys can be used for direct frequency entry.
The [A], [B], [C], and [D] keys replicate the functions of the front panel keys ([BANDS],
[X], [BANDT], and [SELECT]), and also the [*] and [#] keys replicate the functions of
the top panel keys ([TOPT] and [F]).
Basic Operation
Turning the Transceiver On and Off
1. To turn the transceiver on, press and hold in the top panel’s [POWER] key for two
seconds.
When you turn on the transceiver, the current date is indicated on the LCD for 2
seconds. After this interval, the display will switch its normal indication of the
operating frequency.
2. To turn the transceiver off, again press and hold in the [POWER] key for two
seconds.
Adjusting the Audio Volume Level
1. Press the [SELECT] key until the red lamp to the left of the DIAL knob will be
illuminates. Now, the DIAL knob becomes volume knob.
2. Rotate the DIAL knob to adjust the receiver volume. Clockwise rotation increases
the audio output level. The volume level displays on the LCD while rotating the
DIAL knob.
3. Press the [SELECT] key again, the DIAL knob returns dial knob.
Note: 1) The FTM-10R includes an automatic volume level controller to allow the most
comfortable and/or effective reception in noisy environments. See page ?? for details.
2) If you select the VFO-VOL feature to “AUTO” mode via the Menu Item “F45
VFO-VOL,” the DIAL knob returns to the “dial” function automatically after adjusting
the volume level.
Adjusting the Squelch Setting
1. Press and hold the [SELECT] key for one second to activate the Menu (SET) mode.
2. Rotate the DIAL knob to select Menu Item “F34 SQL.LEVEL.”
3. Press the [X] key to enable adjustment of the squelch threshold level. The current
FCC ID: K6620275X40
IC ID: 511B-20275X40
FTM-10R Operating Manual
squelch threshold level is appeared on the LCD.
4. Rotate the DIAL knob just to the point where the noise is silenced and the front
panel’s green “BUSY” indicator turns off. If the SQL control is set further clockwise,
sensitivity to weak signals is reduced.
5. Press the [SELECT] key momentarily to save your new setting and resume normal
operation.
Selecting the Operating Band
Press the front panel’s [BANDS]/[BANDT] keys to switch the operating band as
follows:
[BANDS] Key
2 m Amateur Band 430 MHz Amateur Band FM BC Band AM BC Band WX
Band Audio Line Home Channel 2 m Amateur Band …
[BANDT] Key
2 m Amateur Band Home Channel Audio Line WX Band AM BC Band FM
BC Band 430 MHz Amateur Band 2 m Amateur Band …
Note: The FTM-10R provides for automatic receiving mode changing when the radio is
tuned to different operating frequencies. However, you may change other receiving
mode via Menu Item “F28 RX MODE” (Except the FM BC Band and AM BC Band). See
page ?? for details.
Band Expansion
The FTM-10R can be received the following frequency bands via the Menu Item.
1. Press and hold the [SELECT] key for one second to activate the Menu (SET) mode.
2. Rotate the DIAL knob to select Menu Item “F4 BAND.”
3. Press the [X] key to enable selection of this Menu Item.
4. Rotate the DIAL knob to change the setting to “EXPAND.”
5. Press the [SELECT] key momentarily to save your new setting and resume normal
operation.
When the band is expanded, you can see the “AIR,” “GR1,” and “GR2” additional
frequency bands between the “WX Band” and “Audio Line.”
Frequency Navigation
1) Tuning Dial
1. Press the [SELECT] key until the red lamp to the left of the DIAL knob will be
FCC ID: K6620275X40
IC ID: 511B-20275X40
FTM-10R Operating Manual
turned off. Now, the DIAL knob becomes dial knob.
2. Rotating the DIAL knob allows tuning in the pre-programmed steps. Clockwise
rotation of the DIAL knob causes the transceiver to be tuned toward a higher
frequency, while counter-clockwise rotation will lower the operating frequency.
3. Press and hold the one of the front panel’s [BANDS]/[BANDT] key for one second
(blink the MHz digits), then rotate the DIAL knob, to change the frequency steps to
1 MHz per step. This feature is extremely useful for making rapid frequency
excursions over the wide tuning range of the FTM-10R.
2) Direct Keypad Frequency Entry (Requires the optional MH68A6J Microphone)
The keypad of the optional MH-68A6J DTMF Microphone may be used for direct entry
of the operating frequency.
To enter a frequency from the MH-68A6J keypad, just press the numbered digits in the
proper sequence. There is no “decimal point” key on the MH-68A6J keypad.
Examples: To enter 146.520 MHz, press [1] [4] [6] [5] [2] [0]
To enter 146.5375 MHz, you do not need to press final “5” in the frequency: [1] [4]
[6] [5] [3] [7]
3) Scanning
You may scan the VFO frequency by simple operation.
1. Press the [TOPT]/[TOPS] key repetitively, until the “SCAN” notation appears on
the display.
2. Press the [F] key momentarily to initiate upward scanning. The FTM-10R will stop
when it receives a signal strong enough to break through the squelch threshold.
The FTM-10R will then hold on that frequency according to the setting of the
“Resume” mode (Menu Item “F25 RESUME”; see page ??).
3. If you want to change direction of the scan while it is underway, rotate the DIAL
knob one click in the opposite direction (in this case, one click counter-clockwise).
You will see the scanner turn around and change frequency down.
4. If and when the scanner encounters a signal strong enough to open the squelch, the
scanner will halt temporarily; the decimal pint of the frequency display will blink
during this “Pause” condition.
5. The scanner will then resume according to the Scan Resume mode selected in the
previous section.
6. To cancel scanning, press the [F] key momentarily again.
FCC ID: K6620275X40
IC ID: 511B-20275X40
FTM-10R Operating Manual
Transmission
To transmit, simply close the PTT (Push To Talk) key on the microphone when the
frequency is clear. Hold the microphone approximately 1” (25 mm) from your mouth,
and speak into the microphone in a normal voice level. When your transmission is
complete, release the PTT switch; the transceiver will revert to the receive mode.
During transmission, the red “TX” indicator at front panel will appear.
Note: 1) The FTM-10R has the “Time-Out Timer” (TOT) feature which is designed to
force the transceiver into the “receive” mode after a preset time period of continuous
transmission (the default is 6 minutes). This feature prevents your transceiver from
transmitting a “dead carrier” for a long period of time in the event that the microphone
PTT switch is accidentally locked in the “TX” condition. The Time-Out Timer’s
“switch-to-receive” time may be adjusted to 1 ~ 30 minutes, or Off via Menu Item “F43
TOT.” See page ?? for details.
2) You may set the microphone gain (level) via Menu Item “F16 MIC GAIN.” See page ??
for details.
Changing the Transmitter Power Level
You can select from among a total of three transmit power levels on your FTM-10R.
To change the power level:
1. Press and hold the [SELECT] key for one second to activate the Menu (SET) mode.
2. Rotate the DIAL knob to select Menu Item “F44 TX POWER.”
3. Press the [X] key to enable selection of the transmit power level. The current
transmit power level is appeared on the LCD.
4. Rotate the DIAL knob just to desired transmit power level.
5. Press the [SELECT] key momentarily to save your new setting and resume normal
operation.
During transmission, the Bar Graph will deflect in the display, according to the power
output selected.
LOCK feature
To prevent accidental frequency change, various aspects of the FTM-10R’s keys and
knob may be locked out.
Press the [POWER] key momentarily to toggle the key lockout feature on and off while
the transceiver is turned on.
In the LOCK mode, the display will show “LOCK” when you rotate the DIAL knob or
touch the keys.
FCC ID: K6620275X40
IC ID: 511B-20275X40
FTM-10R Operating Manual
Advanced Feature: You may also lock out the PTT key when the LOCK mode is
activated via the Menu Item “F24 PTT LOCK.” See page ??.
Advanced Operation
Display Brightness
The FTM-10R display illumination has been specially engineered to provide high
visibility with minimal disruption of your “night vision” while you are driving. The
brightness of the display is manually adjustable, using the following procedure:
1. Press and hold the [SELECT] key for one second to activate the Menu (SET) mode.
2. Rotate the DIAL knob to select Menu Item “F14 DIMMER.”
3. Press the [X] key to enable selection of this Menu Item.
4. Rotate the DIAL knob to select a comfortable brightness level
(MIN/LOW/NOR/HIGH/MAX).
5. Press the [SELECT] key momentarily to save the new setting and exit to normal
operation.
Key Beeper
A key beeper provides useful audible feedback whenever a key is pressed. If you want to
turn the beeper off (or back on again):
1. Press and hold the [SELECT] key for one second to activate the Menu (SET) mode.
2. Rotate the DIAL knob to select Menu Item “F5 BEEP.”
3. Press the [X] key to enable selection of this Menu Item.
4. Rotate the DIAL knob to change the setting to “OFF.”
5. Press the [SELECT] key momentarily to save the new setting and exit to normal
operation.
6. To return the beep back on again, select “KEY” or “KEY+SC (factory default)” in
step 4 above.
KEY: The beeper sounds when you press the key.
KEY+SC: The beeper sounds when you press the key, or when the scanner stops.
Channel Step Selection
Tuning steps are factory preset to default increments which are appropriate for the
country to which this radio is exported. You may have a reason to use a different step
size, however, and here is the procedure for changing the channel steps:
1. Press and hold the [SELECT] key for one second to activate the Menu (SET) mode.
FCC ID: K6620275X40
IC ID: 511B-20275X40
FTM-10R Operating Manual
2. Rotate the DIAL knob to select Menu Item “F39 STEP.”
3. Press the [X] key to enable selection of this Menu Item.
4. Rotate the DIAL knob to select desired step size
(5.00/6.25/8.33/10.00/12.50/15.00/20.00/25.00/50.00/100.00/200.00 kHz or AUTO).
5. Press the [SELECT] key momentarily to save the new setting and exit to normal
operation.
Note: 1) AM BC band only choose 9 kHz and 10 kHz.
2) FM BC band only choose 50 kHz, 100 kHz, and 200 kHz.
3) Can not choose 5 kHz, 6.25 kHz, 8.33kHz, and 9 kHz selection at frequency above 470
MHz.
Audio Pitch Control
1. Press and hold the [SELECT] key for one second to activate the Menu (SET) mode.
2. Rotate the DIAL knob to select Menu Item “F2 AF PITCH.”
3. Press the [X] key to enable selection of this Menu Item.
4. Rotate the DIAL knob to select desired receiver audio response. Available selections
are BASS-3, BASS-2, BASS-1, NORMAL, TREBLE-1, and TREBLE-2.
5. Press the [SELECT] key momentarily to save the new setting and exit to normal
operation.
Public Address/Horn Alert Operation
The FTM-10R includes a unique feature which allows the transceiver to be used as a 10
W Public Address/Horn Alert when an optional MLS-200-M10 External Speaker is
connected.
1. Press the top panel’s [TOPT]/[TOPS] key to select the one of the five function
descried below:
PA: Outputs your amplified voice.
HORN 1: Sounds a Gong Bell.
HORN 2: Sounds a flight sound of a UFO.
HORN 3: Sounds a klaxon.
HORN 4: Sounds an ambulance siren.
Note: The “INTERCOM” and “SCAN” functions are not the function of the Public
Address/Horn Alert Operation. Describes detail later.
2. Press the [F] key to set the function which selected by above step.
3. Press the [F] key again to activate the function which selected by above step, then
FCC ID: K6620275X40
IC ID: 511B-20275X40
FTM-10R Operating Manual
press the PTT key to sound the voice/sound from the external speaker.
4. On the PA mode, when speak into the microphone while pressing the PTT key,
outputs your amplified voice from the external speaker.
5. Rotate the DIAL knob control the AF output level.
Note: You may exclude the five functions which is listed above from a list which is by a
Menu Item “F17 FNC KEY” individually.
Clock/Timer Operation
The FTM-10R also includes a Clock and Stop Watch Timer.
To activates the Clock and Stop Watch Timer:
1. Press and hold the [SELECT] key for one second to activate the Menu (SET) mode.
2. Rotate the DIAL knob to select Menu Item “F9 CLOCK.”
3. Press the [X] key to enable selection of this Menu Item.
4. Rotate the DIAL knob to select “ON.”
5. Press the [SELECT] key momentarily to save the new setting and exit to normal
operation.
When the Clock and Stop Watch Timer is activated, you can see the Clock/Timer mode
between the “Transceiver/Volume mode” and “Transceiver/Frequency mode” while
selecting the operation mode by pressing the front panel’s [SELECT] key.
Transceiver/Frequency mode Transceiver/Volume mode Clock/Timer mode
Transceiver/Frequency mode …
In the Clock/Timer mode, rotate the DIAL knob to select you may select the operation:
Clock Stop Watch Timer Stop Watch Timer (Sum) Current temperature inside
the transceiver’s body Clock …
Adjusting the Calendar
1. Press the [SELECT] key repeatedly to recall the Clock/Timer mode.
2. Press and hold the [SELECT] key for one second to activate the Clock/Timer
Customization mode.
3. Rotate the DIAL knob to select Menu Item “T1 CALENDER.”
4. Press the [X] key to enable selection of this Menu Item.
5. Press and hold the [X] key. You will notice the “YEAR” column blinking. Rotate the
DIAL knob to select the current year.
6. Press the [BANDS] key to move the blinking column to “MONTH.” Rotate the
DIAL knob to select the current month.
FCC ID: K6620275X40
IC ID: 511B-20275X40
FTM-10R Operating Manual
7. Repeat above step regarding the “DAY,” “DAY OF WEEK,” “CLOCK,” “MINUTE,”
and “SECOND.”
8. When adjust of “SECOND” is finish, press the [BANDS] key. If you want to alarm
which sound every “00” minute, rotate the DIAL knob to change “OF” into “ON.”
9. Now, press the [BANDS] key to save the new setting and exit to Clock/Timer mode.
Note: 1) You may adjust the “CLOCK” and “MINUTE” via Menu Item “T2 TIME ADJ”
as well.
2) You may set the alarm function via Menu Item “F10 CLOCK BP” as well.
3) You may set the clock to “XX:00:00” by press and holding the [X] key for one second
when the FTM-10R is in Clock/Timer mode.
Calendar Customization
The FTM-10R enables to select the calendar format and clock format.
1. Press the [SELECT] key repeatedly to recall the Clock/Timer mode.
2. Press and hold the [SELECT] key for one second to activate the Clock/Timer
Customization mode.
3. Rotate the DIAL knob to select Menu Item “T7 APO.”
4. Press the [X] key to enable selection of this Menu Item.
Rotate the DIAL knob to select desired time period after which the radio will
automatically shout down.
5. Now, press the [SELECT] key to save the new setting and exit to Clock/Timer mode.
Using the Stop Watch Timer
1. Press the [SELECT] key repeatedly to recall the Clock/Timer mode.
2. Rotate the DIAL knob to select the Stop Watch Timer.
3. The Stop Watch Timer is designed to Start and Stop repeatedly whenever you press
the [X] key. The LED at the left of the DIAL knob blinks green while count the Stop
Watch Timer.
4. Press and hold the [X] key for one second to resets the Stop Watch Timer.
5. Rotate the DIAL knob one click clockwise to appear the sum time of a Stop Watch
Timer.
6. If you reset the sum time of a Stop Watch Timer, press and hold the [X] key for one
second.
Interval Timer
The FTM-10R’s Stop Watch Timer allows inform the progress of time which you
FCC ID: K6620275X40
IC ID: 511B-20275X40
FTM-10R Operating Manual
programmed by the beep sound and (white) flushing the LED.
1. Press the [SELECT] key repeatedly to recall the Clock/Timer mode.
2. Press and hold the [SELECT] key for one second to activate the Clock/Timer
Customization mode.
3. Rotate the DIAL knob to select Menu Item “T6 UP TIMER.”
4. Press the [X] key momentarily to enable selection of this Menu Item.
5. Rotate the DIAL knob to select desired interval.
6. Now, press the [SELECT] key to save the new setting and exit to Clock/Timer mode.
Automatic Power-Off feature
The “Automatic Power-Off” (APO) feature will turn the radio completely off after a
user-defined period of PTT or key/button inactivity. If you do not press any front panel
keys or buttons, rotate the DIAL knob, use the microphone’s keys and buttons, or
transmit, and so long as the transceiver is not scanning or engaged in priority
monitoring, the radio will shut itself off after the specified time period.
The FTM-10R can operate the Automatic Power-Off” feature by the Clock/Timer
feature.
The available selections for the time before power-off are 0.5 - 12.0 hours (0.5 hours
increments), as well as APO Off. This feature is useful in minimizing battery drain in a
mobile installation if you forget to turn the transceiver off when you leave your vehicle.
To activate the APO feature:
1. Press the [SELECT] key repeatedly to recall the Clock/Timer mode.
2. Press and hold the [SELECT] key for one second to activate the Clock/Timer
Customization mode.
3. Rotate the DIAL knob to select Menu Item to be configured.
T3 CALE DSP: calendar format
T4 TIME DSP: clock format
T5 12H/24H: time system
4. Press the [X] key momentarily, then rotate the DIAL knob to select desired format
or system. Available selections are:
T3 CALE DSP: YY/MM/DD, YY/DD/MM, or DD/MM/YY
T4 TIME DSP: HH:MM:SS, HH:MM, or MM:SS
T5 12H/24H: 12H or 24 H
5. Now, press the [SELECT] key to save the new setting and exit to Clock/Timer mode.
If there is no action by you within the time interval programmed, a ringer sounds 3
minutes before the APO shut-down time; three minutes thereafter, the microprocessor
Loading...
