yada BT53872, BT53328, BT53355 User Manual
TABLE OF CONTENTS
1. Introduction ................................................................................................................................................................................... 1
2. Package Contents ........................................................................................................................................................................ 2
3. Product Specications ............................................................................................................................................................... 3
4. Installation Guide ......................................................................................................................................................................... 3
5. Pairing and Connecting ............................................................................................................................................................. 7
6. Operation Guide ........................................................................................................................................................................... 7
7. Settings ............................................................................................................................................................................................ 8
8. Safety Information ....................................................................................................................................................................... 8
9. Maintenance & Warranty ......................................................................................................................................................... 11
10. General Information ...............................................................................................................................................................15
1. INTRODUCTION
Please read all of the installation instructions carefully before installing the product. Improper installation
will void manufacturer’s warranty. The installation instructions do not apply to all types of vehicles, and are
written as guidelines to assist in installing the system.
Consult an experienced technician if you are not comfor table installing the product. You can also contact
Winplus at 866.294.9244 to speak to one of our installation specialists if you have any specic questions
regarding the Digital Wireless Backup Camera.
BEFORE using the Digital Wireless Backup Camera, please read the safety information provided in
this user manual. ALWAYS use the product as outlined in this user manual.
Please make sure to read and understand all local laws and regulations regarding cameras and their
use in a vehicle. Laws vary by state.
1
2. PACKAGE CONTENTS
1. 3.5” or 4. 3” Dash Monito r
or 3.5” Mirror Monitor
2. Weatherproof Rearview Camera
3. Windshield mount for Dash
Monitor only
4. 12V/24V Power Adaptor
5. Hardwire Power Cable for Dash
Monitor or 3.5” Mirror Monitor
(Optional)
6. Hook and loop straps for Mirror
Monitor only
7. 4x Snap Lock Splice Connectors
8. 4x Zip Ties
9. Rubber Ring
10. User Manual
11. Quick Installation Guide
1.
3.5” Dash Mo nitor
4.3” Dash M onitor
3.5” Mirror Monitor
2.
3. 10.
4.
5.
6.
7.
8. 9.
11.
2
3. PRODUCT SPECIFICATIONS
Digital Wireless Backup Camera with Dash Monitor
1. 3.5” or 4.3” TFT LCD Display
2. 2.4GHz Digital Wireless
3. Image sensor: CMOS
4. Operation range: 30 Feet/10 Meters
5. Input Voltage DC12~24
6. Operation temperature: 14~122ºF
7. Storage temperature: -4~140ºF
8. Camera water resistance: IP67 Rating
Digital Wireless Backup Camera with Mirror Monitor
1. 3.5” TFT LCD Display
2. 2.4GHz Digital Wireless
3. Image sensor: CMOS
4. Operation range: 30 Feet/10 Meters
5. Input Voltage DC12~24
6. Operation temperature: 14~122ºF
7. Storage temperature: -4~140ºF
8. Camera water resistance: IP67 Rating
4. INSTALLATION GUIDE
MIRROR MONITOR INSTALLATION
1. Attach black Hook and Loop straps to the back of the Yada mirror by sliding the metal clip into the mirror
brackets. Push in all the way until the straps are secure.
2. Make sure the connection for each strap is facing the same way- rather up or down- to allow for easy
adjusting of the mirror.
3. Open the Hook and Loop straps and allow them to hang freely in the FRONT of the mirror, so there is no
obstruction between the Yada mirror and your original rearview mirror.
4. Start by matching up the mirrors at the top, with the spring clamps wrapping around the original
rearview mirror.
5. Pull the Yada mirror down to allow the spring clamps on the bottom to snap into place around the
3
original rearview mirror. Tip: Use both hands on either side of the mirror to snap into place evenly. Make
sure the mirror is centered before snapping into place.
6. Once the Yada mirror is in place, reach behind and one by one reattach the Hook and Loop straps
together to hold the Yada mirror tight in place.
7. At this time you can trim o any excess strap with a scissor.
8. Remove the Yada mirror protective overlay.
9. Now power the mirror.
a. 12V/24V Power Adapter
i. Take the 12V/24V Power Adapter and plug in adapter to top of the Yada mirror. Plug other end
into 12V Power in your car.
b. Hard wire
i. Take the Hard Wire Power Adapter and plug adapter into the top of the mirror. Run cable to fuse
box and connec t to fused accessory power source. Refer to your vehicle owner manual for location
of available accessory fuses.
10. At this time, the Yada Mirror Monitor is ready to be powered on.
DASH MONITOR INSTALLATION
1. Stick the windshield holder on the windshield and adjust to your desired position.
2. Hook the Dash Monitor on to the windshield mount.
3. Remove the Yada Dash Monitor protective overlay.
4. Now power the monitor:
a. 12V/24V Power Adapter
Take the 12V/24V Power Adapter and plug in adapter in the right side of the Yada Dash Monitor. Plug
the other end into 12V/24V power port in your car.
b. Hard wire
Take the Hard Wire Power Adapter and plug adapter in the right side of the Yada Dash Monitor. Run
cable to fuse box and connect to fused accessory power source. Refer to your vehicle owner manual
for location of available accessory fuses.
5. At this time, the Yada Dash Monitor is ready to be automatically powered on when the vehicle
engine starts.
4
