User’s manual
Wireless Fishfinder
WIRELESS
FC60X
FC60X
ENT
MENU
EXIT
www.goyachting.cn
FREECAST
www.goyachting.cn
All right reserved! Except as expressly provided herein,
no part of this manual may be copied, reproduced, repub-
lished, transmitted or distributed for any purpose, without
prior written consent of Yachting Electronic Co., Ltd.
Yachting Electronic may find it necessary to change or end
our policies, regulations, and special offers at any time.
We reserve the right to change or improve its products and
to make changes in the content without obligation to notify
any person or organization.
For current updates or other information, please visit our
website:
www.goyachting.cn
Yachting Electronic Co., Ltd
Building107, No.508, Heyan Road,
Nanjing, 210038, China
Printed in China
Copyright 2008 Yachting Electronic Co., Ltd.
All rights reserved.
i
Content
Introduction .................................................................1
Packing list...................................................................2
General attention..........................................................2
Installing battery...........................................................3
Using the product.........................................................4
Operational modes.......................................................6
Instruction of Freecast sensor.......................................7
Power supply...........................................................7
Electronic switch.....................................................7
Using the Freecast sensor............................................10
Operational Panel Basic..............................................12
Display.........................................................................13
Understanding the display.......................................13
Content
Depth range.............................................................14
Water surface line....................................................15
Operation.....................................................................17
ii
Menu Operation Instruction....................................17
Sensitivity................................................................19
Channel....................................................................20
Shallow....................................................................21
Depth Range............................................................22
Fish ID.....................................................................23
Units........................................................................24
Backlight.................................................................25
Contrast...................................................................26
Load DFT................................................................27
Trouble Shooting.........................................................28
Maintenance................................................................33
Guarantee Conditions..................................................34
Specfications and Feature...........................................35
Specfications...............................................................35
Features.......................................................................36
iii
Introduction
Introduction
Thank you for choosing FC60X Fish Finder. and welcome
to the innovations of Yachting Electronic Co., Ltd! We has
been committed to fish finder R&D activities all the way
and its products have been reputed for their cutting-edge
technologies and reliable performance.
FC60X is designed to facilitate fishing on the bank, along
the seashore,and on-board in a variety of water areas.
We offer six months charge-free main-tenance against any
damages induced by non-human factors; and damages
beyond the six months are handled with reasonable charges
based on concrete situations. For details regarding maint-
enance
To familiarize yourself better with the product’s operation
and maximize the utilization, we invite you to read the
User’s Guide carefully.
For any possible problems you may encounter during the
operation, please switch to the Trouble shooting section
service,
please refer to the warranty explanations.
for reference.
1
Packing list
General attention
War
ning
Warning:
Warning:
Packing list
The following items are included in FC60X:
1) A FREECAST wireless remote sonar sensor
2) A handheld with 3” Dot matrix LCD
3) A copy of FC60X User’s Guide
In the event that any of the items listed is found missing,
call us immediately or log on to our website at
www.goyachting.cn. Clients located in other parts of the
world may also refer to their respective local distributors.
General attention
War
ning
performed by professionals designated by the Company.
Any of the following situations can void the remainder of
your warranty: unauthorized disassembly or maintenance,
: Disassembly and maintenance are only to be
damage or alteration to the production serial number, etc.
Warning:
an adult’s watch.
Warning:
it
is strongly warned not
may cause damage of inner electronic part.
Children under six may not use the sensor without
Although FC60X is designed IPX7 waterproof,
immerge it into in water, whcih
2
Warning:
Installing the battery
Installing the battery
Warning:
with strength in the vertical directiion!
do not split the battery cover
To take off the battery
cover, press it and
slide in the indicated
direction
1. Turn the screw anti-clockwise with a screw driver.
Then slide the battery cover towards the bottom of the
unit and remove it from the main housing.
2. Install 4 “AAA” batteries. Be certain that the batteries
are aligned as per the diagram within the battery
compartment.
3. Slide the battery cover towards the top of the unit until
it is completely closed. Then turn the screw clockwise
with a screw driver until snug before continuing. Be
Usin
g the pro
duct
certain not to over-tighten it.
Usin
g the pro
This product is designed with user-friendliness in mind.
Attach the sensor to the fishing thread’s extreme and
duct
throw them into water as you do with float and lure.
After switching on the main unit’s power,you are ready
to fish. With sonar technologies employed, the FC60X
sensor transmits ultrasonic waves to water, and the
microprocessor inside the principal machine applies
Warning:
Warning
:
wireless technologies, filtering the signals fed-back. As
the filtered signals have been analyzed and processed, they
are illustrated on the display. Newly-detected information
is displayed at the very right of the screen and disappears
at the very left. Showed between precisely are sea bottom
contours, water depth, fish size, and location etc.
Warning:
bottom; otherwise, deformations may occur to the product
and damage to internal structures and elements can ensue.
To pick up the sensor working in water, take hold of the
antenna post at the sensor’s top.
Warning
s
ervice. However, in water areas where there are significant
water level fluctuations, the sensor may be subject to
collision with rocks, which will result in damages to the
d
evice. Therefore, for water areas with depth less than
1 foot (0.3m), we recommend that you avoid using this sensor.
While the sensor is working, do not hold it at the
FC60X is designed to work durably in normal
Operational modes
Operational modes
FC60X features two operational modes:
1) Sonar Graphic Mode
FC60X renders real
sonar graphic. Cast the sensor into water, drag it slowly and
at stable speed, and you can view accurate information
displayed on the screen, including sea bottom contour,
structure, depth, fish location, size, etc.
2) Stationary Float Mode
Cast the sensor into water and let it undisturbed. It will float
on the water surface, monitoring submarine developments
in a real-time manner. Information will be automatically
updated on the screen once fish approach your bait.
-time conditions at the sea bottom with
Instruction of Freecast sensor
Instruction of Freecast sensor
1. Power
supply
2.
Electronic switch
1. Power
The FC60X sensor is provided with a separate, built-in, and
irremovable lithium battery that has a continuous service
time of 550 hours in normal operation. When the battery’s
service life ends and becomes out of service, it should be
handled in a way compliant with local provisions regarding
discarding used batteries and relevant electronic products.
2.
Electronic switch
There are three pins on the bottom of cover, which is used
to switch between power on / power off.
At the moment the sensor is put in water, the sonar trans-
mitter/receiver is automatically turned on and transmits
ultrasonic signals. As the principal machine receives the
signals, related information about the sea bottom will be
showed on the screen. After a few seconds elapse since the
supply
sensor is taken out of water, the built-in power will be switch
off automatically and transmission of sonar signals termi-
nated
Warning:
1)
When the sensor is casted into water, with the three pins
touching water, the sensor begin working.
2) When the sensor is droped out from water, after wiping
off the remained water on pin surface, the sensor stop
working automatically.
Three pins for electronic switch
Warning:
when not using,
on the built-in power automatically, thus shortening its
useful life. Likewise, avoid placing it on board or on a metal
surface for the same reason.
do not place your Freecast sensor in a wet area
the dampness may cause the sensor to turn
Note:
Note:
Note:
U
sing the Freecast sensor
store it in a dry, nonmetal container! A toolbox, for
example, may be used for storage and placed
room far away from any metal equipment.
Note:
Rinse its surface with fresh water after
worked in salt water for some time.
sing the Freecast sensor
The two holes at the FC60X front end is for tying fishing
thread. If you desire to use it in the Stationary float Mode,
bind the fishing hook with light threads to the second hole.
However, be informed that if the sensor encounters barriers
when being dragged, the fishing thread can easily break.
Hence, for this practice, we advise you not to pull the thread
if unnecessary, for fear that you may be unable to regain
your sensor due to the broken thread.
Alternatively, in case you wish to drag the sensor as you
see fit, you may tie the f
irst hole with another light thread,
in a separate
the sensor has
therefore preventing the
See the following instruction:
failure of retrieving your sensor.
