HOW TO USE
L
T9
R
T9
折线
折线
折线
折线
折线
In-Ear Monitors
Dual balanced-armature drivers
Clear and
articulate sound
Dual balanced-
armature drivers
English Manual
Impedance:
59 ohms
Xvive’s T9 In-Ear Monitors have been designed by top IEM engineers in the
USA to offer customers pro-level audio quality—previously only available
from custom in-ears—at a much more accessible price.
The T9 is endowed with two balanced-armature Knowles drivers: one of the
industry’s largest and most powerful mid-bass drivers, and a custom-tuned,
custom-ported micro tweeter. Along with a custom unified crossover, these
cutting-edge components have the headroom to accommodate whatever
EQ adjustments any user may desire. Nonetheless, T9 comes perfectly
balanced, with a responsive and detailed sound signature that is not overly
hyped or colored—so audiophiles will enjoy a fulfilling listening experience
right out of the box.
T9 is an invaluable tool for performing live musicians, and also perfectly
suited to in-studio tracking and mixing—but perhaps most importantly,
these hi-tech earbuds make the experience of listening to music fun and
rewarding for absolutely anyone!
T9 IEMs pair perfectly with Xvive’s U4 In-Ear Monitor Wireless System,
providing musicians with unbeatable monitoring value for live performance
and studio applications.
T9
PRODUCT
Memory foam
ear tips
Ear tips
S
X 2
M
X 2
L
X 2
1/8 TRS to 1/4 TRS
adapter
S
X 4
M
X 4
L
X 4
FEATURES
●
Dual balanced-armature drivers
●
Hand-assembled
●
Sound-isolating earphones
●
3.5 mm earphone jack, compatible
with all systems
●
Carrying case and cleaning tool
included
●
Durable, replaceable cables
●
Custom-designed, unified crossover
Cable
ensures that each driver is only
sent frequencies they were
designed to reproduce
Cleaning tool
Carrying case
SAFETY PRECAUTIONS
This device is able to produce audio volumes higher than 85 dB SPL. Please
check the maximum allowed continuous noise-exposure levels based on
your national employment protection requirements.
LISTENING TO AUDIO AT EXCESSIVE VOLUMES CAN CAUSE PERMANENT
HEARING DAMAGE. USE AT AS LOW A VOLUME AS POSSIBLE.
To avoid hearing damage, follow the U.S. occupational safety and health
administration (OSHA) guidelines for maximum time exposure to sound
pressure levels.
90 dB SPL: max 8 hours 95 dB SPL: max 4 hours
100 dB SPL: max 2 hours 105 dB SPL: max 1 hour
110 dB SPL: max 30 minutes 115 dB SPL: max 15 minutes
120 dB SPL: avoid or damage may occur
To prevent possible hearing damage, do not listen at high volume levels
for long periods.
●
Before using the earphones, first turn down the volume of the wireless
receiver or sound source to prevent hearing damage due to sudden
excessive volume.
●
When using the earphones, turn down the volume so you can hear sounds
around you.
●
Do not use earphones while riding a bicycle or motorcycle, or driving any
vehicle.
●
Do not submerge earphones in water.
●
Keep earplugs and accessories out of reach of children to prevent
accidental ingestion.
●
Do not remove or reinstall any components of the earphones. If there is a
problem with the earphones, please contact Xvive for repair or replacement.
●
Do not put the earphones under heavy pressure or close to a heat source
or a strong magnetic field. Otherwise, the earphones may become
damaged and/or deformed.
Installing the ear tips
L
M
S
Press
Small, medium, and large ear tips made
of pliable rubber are included. Select the
suitable size for your ears and press the
ear tips firmly onto the earphone output
tubes.
Wearing the earphones
Important: A good acoustic seal provides
maximum bass. If there seems to be a lack of
low-frequency response, this means that the
ear tips are not forming a tight seal in your
ears. Gently push the earphone deeper into
the ear canal or try a different ear tip size.
Warning: Do not push the ear tip sleeve
beyond the ear canal opening. Wearing the
cable over the ear and securing it behind
the head can help keep the earphones in
place during physical activity.
Cable routing
The best way to use T9s with a wireless
in-ear monitor system is to run the wire
down your back and wear the beltpack
transmitter on your back side. When
listening to music, the wire can be
positioned on your front side.
Maintenance and cleaning
• Keep the earphones and ear tips as clean and
dry as possible.
• Use the cleaning tool to clean the earphone
output tubes.
• Wipe the ear tips with water to avoid infections.
Earphones should be cleaned with a dry cloth.
Do not use alcohol-based disinfectants.
Carrying case for earphone storage
Loosely coil the cable around your 4 fingers
and protect your T9 in the carrying case.
SPECIFICATIONS
Frequency response
Impedance
Sensitivity
Total harmonic distortion (THD)
Transducer principle
Input
Cable Length
Weight with cable
20 Hz - 16.5 kHz +/- 3 dB
59 ohms @ 1 kHz
120 dB @ 1 kHz
< 0.2% @ 1 kHz
Dual Balanced Armature
1/8" headphone jack, or with 1/4" adapter
120 cm (47”)
18.6 g
Connecting the cables
T9
L
L
R
T9
R
Match the "L" and "R" markings when
connecting cables. The cable direction is
upward. The red cable adapter is Right.
1
1
2
2
6
6
5
5
3
3
4
4
CERTIFICATIONS
This product meets the essential requirements of all relevant European
directives and is eligible for CE marking.
SHENZHEN FZONE TECHNOLOGY CO., LTD.
2nd floor, Building 12, Xicheng Industrial Area, Xixiang
Made in China
料号：111081357 T9说明书 展开尺寸: 100*360mm 折后尺寸:100*60mm 材质：80G书纸正反双面印刷
Town, Baoan District, Shenzhen Guangdong, China.
www.xvive.com
www.xvive.com
