10/07/2006
COVERT PIR CAMERAS
INSTRUCTION
M A N U A L
CONTENTS
Page Page
1. Description ............................... 1
4. Specifications ........................... 4
19
2. Installation ................................2
3. Wiring instructions ................... 3
5. PIR Detector board installation
and descriptions........................ 5
1. Description
Thank you very much for purchasing our product.
This B/W (COLOR) HIDDEN CCD Camera uses high sensitive 1/3” (1/4”)
interline transfer CCD Image Sensor (CCD = Charge Coupled Device), and all
state circuitry which provides extremely long life and high reliability. This
Camera offers excellent image quality with low lag and high burn resistance,
and is not subject to distortions from magnetic fields. Highly resistance to
shock and vibration, and easy to install this Camera is a very good choice for
your B/W (COLOR) CCTV system.
P. 1
2. Installation
STEP 1: Secure the bracket to the wall with screws. ( included as shown in
Figure 1 )
STEP 2: Attach the Camera Case to the bracket as shown in Figure 2.
P. 2
STEP 3: Adjust the vertical and horizontal angles by loosening screws
(A&B) as in Figure 3 and by turning the bracket vertically and
horizontally.
A
B
3. Wiring instructions
STEP 1:Connect the coaxial cable between the camera and the monitor
using a 75Ohm coaxial cable.
STEP 2: Insert the AC plug into the AC power socket and the DC plug to the DC
Jack.
Note: AC Adapter Sold separately.
P. 3
4. Specifications
Model
Image Pick-up
Device
Elements (HxV)
Horizontal
Resolution
Minimum
Illumination
Scanning
System
Auto Electronic
Shutter
S / N Ratio
Gamma
Characteristic
Sync System
Vide o Output
Audio(Optional)
Power Supply
Power
Consumption
(PIR Sensor not included)
Lens Furnished
Operating
Te mp .
Built-in
PIR Sensor
B/W – PC810/PC810D Colour – PC811/PC811D
SONY 1/3” Super HAD CCD
0.3 LUX / F2.0 0.5 LUX / F2.0
(for model “Audio” & “including PIR working sensor” only)
For model including PIR working sensor only.
sensor
EIA/NTSC: 510x492
CCIR/PAL: 500x582
480
TV lines
EIA/NTSC: 1/60s~1/100,000s,
CCIR/PAL: 1/50s~1/110,000s.
More than 48 dB
GAMMA = 0.45
Internal, Negative sync.
1 Vp-p / 75 Ohms. BNC or F connector.
2 Vp-p / 50 Ohms. RCA connector.
DC 12V ±10％
1.32W 1.44W
Corn Lens f 3.7mm / F2.0
-10 to 50℃ ( 14 to 122℉)
SONY 1/4” Super HAD CCD
sensor
420
TV lines
Interlace 2 : 1
Note: Design and specifications are subject to change without prior notice.
P. 4
N
N
5. PIR Detector board installation and
descriptions (for PCC810 & PC811 models
only)
Pulse Count
Light Control
Recording Control
Time Adjustment
5
4
PULSE
1
2
J2
3
VR2
Options Description
1.LED Selector:
(3PINS: Top, Center, Bottom)
2.Sensitivity Adjustment:
High Low
3.Dwell Time Adjustment:
“VR1”
Min. Max.
“VR2”
Adjustable from 2 to 40 sec.
A. Top + Center w/black cap: Upon Walk-testing: Light
J1
B. Center + Low w/black cap: No light blinking while
A. To raise sensitivity: Turn clockwise to detect longer
B. To lower sensitivity: Turn counter clockwise for detection
For closure period of N.C/N.O relay connected to an alarm
panel, light control or recording control of time lapse VCR,
etc.
A. Max. time: Turn counter clockwise.
B. Min. time: Turn clockwise.
Top + Center pins of “J4” must be selected to adjust the time
setting.
6 Output Terminals
.C.
.O.-+
JP2
J4
blinking (Disadvantages: Easy to identify as a security
system.)
detecting. (Advantages: less obvious)
distance and wider pattern.
in narrow areas.
VR1
P. 5
1
Led Selector
J1
2
Sensitivity
Adjustment
Options Description
4.Alarm control, Light control or
Recording control
(N.O or N.C)
(3PINS: Top, Center, Bottom)
5.Pulse Control:
Once or twice
4PINS: 2PAIRS w/jumper connector
6.Output Terminals:
24 Hour/Anti-Tamper
7.Power: 12V DC
Standby Current: 3mA,
Working Current: 28mA
1
2
N.C. N.O.
JP2
-
A. Top + Center w/black cap: Operate with “VR2” to adjust
time. (To set the relay output of the Light control or
Recording control, the time is selected by individual
preference or application.
B. Center + Bottom w/black jumper: Relay output can be set
J4
J2
for Security control panel for only 2 seconds.
Note: N.C./N.O. relay output current: 1A 125 VAC, 2A 30 VDC.
Position 1: Set to “ONCE” for instant reaction when PIR
Position 2: Set to “Twice” when PIR detects someone 2 times
N.C.: Normally Closed
A. For connection to: Security panel or Light control CCTV
+
B. With anti-tamper function for 24 hours.
N.O.: Normally Open Contacts
※P.S.: Relay output cur rent: 1A 125VAC, 2A 30V DC
Caution:
The PIR is triggered by body movement, excluding fixed
objects, however, do not place in direct sunlight or reflected
sunlight.
detects someone: and either the “alarm or
Security control panel” or “Recording control”
will be triggered immediately.
within 15 seconds.
…etc.
100¢X TOP VIEW
SIDE VIEW
10 20 30
● Wide angle lens up to 100°, coverage areas to 30x30 feet.
● Provide 64 beams in 3 layers.
feet feet
302010
P. 6
