Xtrons HD116HD User Manual

HD116HD

USER MANUAL

Thank you for buying this XTRONS product. Please read through these instructions so you will

know how to operate this product properly. After you have finished reading the instructions,

keep this document in a safe place for future reference.

NOTICES

NOTICE OF INTENDED USE

Our products are designed to enable viewing of video
ONLY for rear-seat occupants, and are not intended for
viewing by the driver when the vehicle is in motion.
Such use might distract the driver or interfere with the
driver’s safe operation of the vehicle, and thus result in
serious injury or death. Such use might also violate
state or local laws.

Manufacturer disclaims any liability for any bodily
injury or property damage that might result from any
improper or unintended use.

NOTE: Features and specifications listed in this manual are subject to
change without notice.

Contents

1

Precaution .........................................................................................................

Checking part names and functions .......................................................

Remote control ...............................................................................................

Playing a disc ...................................................................................................

USB/SD ...............................................................................................................

Using AV input and AV output ..................................................................

Listening over the vehicle’s speakers .....................................................

Using the external wireless IR headset ..................................................

Using an HDMI source ..................................................................................

Appendix ...........................................................................................................

2

4

6

10

10

10

10

11

11

12

Precaution

2

Certain country and government laws may prohibit or restrict the placement and
use of this product in your vehicle. Please comply with all applicable laws and
regulations regarding the use, installation and operation of this product.

If you want to dispose this product, do not mix it with general household waste.
There is a separate collection system for used electronic products in accordance
with legislation that requires proper treatment, recovery and recycling.

Before installing this product

- Use this unit with a 12-volt battery and negative grounding only. Failure to do so
may result in a fire or malfunction.

- To avoid shorts in the electrical system, be sure to disconnect the (-) battery cable

before installation.

Important safety information

WARNING

- Do not attempt to install or service this product by yourself. Installation or
servicing of this product by persons without training and experience in
electronic equipment and automotive accessories may be dangerous and could
expose you to the risk of electric shock, injury or other hazards.

- Do not allow this product to come into contact with liquids. Electrical shock could

3

result. Also, damage to the product, smoke and overheating could result from
contact with liquids.

- If liquid or foreign matter should get inside this product, park your vehicle in a safe
place, turn the ignition switch off (ACC OFF) immediately and consult your dealer.
Do not use this product in this condition because doing so may result in a fire,
electric shock, or other failure.

- If you notice smoke, a strange noise or odor from this product, or any other
abnormal signs on the screen, turn off the power immediately and consult your
dealer. Using this product in this condition may result in permanent damage to the
system.

- Do not disassemble or modify this product, as there are high-voltage components

inside which may cause an electric shock. Be sure to consult your dealer for internal
inspection, adjustments or repairs.

To avoid battery exhaustion

Be sure to run the vehicle engine while using this product. Using this product without
running the engine can drain the battery.

WARNING

Do not install this product in a vehicle that does not have an ACC wire or circuitry
available.
