Xtant Technologies 604-X Owners manual

4

C

h

a

n

n

e

l

4

x

7

5

W

.

P

.

C

.

@

4

Ω

•

4

x

1

5

0

W

.

P

.

C

.

@

2

Ω

•

N

o

i

s

e

G

a

t

e

&

1

2

/

2

4

d

B

X

-

o

v

e

r

x•tant (ikst`ænt, e`kstent) 1. adj.
still in existence, especially. of

enduring excellence.||e.g. of xtant
quality that stands the test of time
and the passing of fads. 2. adj.

Standing out or above, as in out­standing, the quality or state of

being original. [from. L. xstans
(xstantis) n present participle of
xstare, to stand forth. ||Second
origin; Prescott AZ. U.S.A. Ntl.
Frst. Cmp. 1994 v. to xtantify = to
stand up and be heard] 3. noun
/X

TANT applied creativity esp. a

company of people united to apply
original thinking to continually
advance the spectrum of extraordi­narily vivid sound reproduction,

to apply innovative thought and
action to questions previously
considered resolved.||

Xtant Technologies

7676 South 46th Street Phoenix, Arizona 85040

[phone] FAX [phone]

x•tant

WELCOME

We would like to personally thank you for choosing Xtant Technologies equip­ment. Our mission is to continually provide you with the best mobile audio – any­where. Our goal is to exceed your expectations. Our driving concepts are superior­ity through simplicity, flexibility, compatibility, reliability, efficiency, and ease of
system expansion. We began with a clean slate. We challenged all the assumptions.
We enlisted a dream team of audio specialists; manufacturers, installers, designers
and audiophiles. We all became excited about the possibilities. We listened. We are
still listening.

We Listen to your recommendations, opinions, and needs .

We Listen to our fellow supporting manufacturers to ensure that our products

interface well with a wide variety of products.

We Listento our equipment with sensitive and critical ears to provide the finest
mobile audio components on the planet.

We have created Xtant because we respect the music, and the people who want
to really listen. The result has expanded the expectations of extraordinarily vivid
mobile audio. Vivid mobile audio, a continuing evolution of the art of listing and
hearing, well. We believe that music deserves the maximum accuracy in reproduc­tion. We have united art of the technology and the technology of the art to create the
magic. Xtant is only available through the finest specialized mobile audio retailers.
Your Xtant Select Dealer was chosen by us because of their passion for excellence
and their commitment to expanding their expertise. Please remember, exceptional
audio requires professional installation. Your Xtant Dealer will will optimize your
system and your level of satisfaction.

Whether you are a professional competitor in auto sound or a privately passion­ate connoisseur of fine music, we salute you, and appreciate your investment in
quality mobile audio. If you have a problem or a suggestion please give us a call or
write us. Thanks for having the faith in the music and the faith in us.

We look forward to a long and enduring relationship!

Welcome to Xtant!

TABLE OF CONTENTS

Safeguards 4

Xtant 604X 5

Specifications 6

Electronic Crossover 7

Optional Accessory Modules 8

Maintenance 9

Customer Relations / Technical Services 10

Warranty 11

Owner’s Installation Log 12

Installer’s Reference Insert

4

SAFEGUARDS

Please take the time to read this Owners Manual.

The following guidelines are designed to assure a safe and

properly installed Xtant Mobile Audio System.

All Xtant amplifiers and accessories are intended to be installed by a certified
professional mobile audio installation specialist. It is the recommendation of
Xtant Technologies that your new Xtant product(s) and all of your mobile
audio products be installed by your Authorized Xtant Select Dealer.

Installer’s Reference (insert )

The Installer’s Reference is an insert included in this manual. It is designed to
assist your Authorized Xtant Select Dealer’s professional installer.
Installation techniques critical to the creation of a high-performance mobile
audio sound system, (procedures for running wires, basic safety rules, and
system layout concepts) are not presented in this owners manual. All
Authorized Xtant Select Dealers have been chosen for their expertise in sys­tem design and advanced installation capabilities and Xtant highly recom­mends that you have all of your mobile audio products professionally
installed. If, however, you choose to install your Xtant amplifier yourself,
please refer to the Installer’s Reference prior to installation.

Wiring Requirements

All Xtant amplifiers have minimum wire gauge requirements for Power,
Ground, Remote Turn-On, and Speaker cables. Please refer to the Installer ’s
Reference for recommended wire gauges.

Fusing Requirements

The 604X is not fuse protected! For safety, an outboard 120 amp fuse may be
added close to the amplifier. A 120 amp fuse must

be installed in-line with the
power wire at the battery. In the case of a multi-amp system, use a fuse value
equal to the combined total demand of all amplifiers in the system.

Water and Moisture

Install all Xtant amplifiers and accessories in a location free of

moisture or exposure to water.

The 604X is a four channel amplifier which combines unique

performance features with outstanding design flexibility to pro-

vide a single chassis “system solution” for most mobile audio

applications. With its on-board crossover, a high performance bi-

amplified system is easily configured.
By utilizing the on-board crossover’s four (4) RCA line outputs, you can steer

specific frequency ranges to additional amplifiers, thus eliminating the need for
external, active crossover components.

As with all Xtant “X” Series amplifiers, the 604X incorporates an on-board noise
gate, forced convection thermal management system, and a Pulse Width
Modulated power supply for high efficiency and unsurpassed reliability. All these
features are encased in Xtant’s exclusive finish of stainless steel and copper!

Standard Features

Forced Convection Cooling:All Xtant “X” Series ampli-

fiers employ forced convection cooling for thermal management.

An on-board thermal sensing circuit regulates fan speed to main­tain optimum operating temperature.

PWM Power Supply: All Xtant “X” Series amplifiers feature a

fully regulated, Pulse Width Modulated power supply. This sup-

ply technology provides high efficiency and consistent output per-

formance even when battery voltage is less than optimum.

Crossover:Selectable 12/24 dB per octave “Butterworth” filter network with selec­table Bypass (Full Range), High Pass, Low Pass and Bandpass modes of operation.
Frequency selection is via a 12 pin Frequency Module (SIP). The amplifier is shipped
with a 90 Hz SIP installed, 13 other frequencies are available from your Xtant Dealer.
Refer to page 7 of this manual for a list of the available frequencies.

Noise Gate: Provides deep muting when no musical signal is present. Features
include adjustable threshold and bypass switch.

Balanced / Floating Input: When enabled, this circuitry helps to eliminate
“system noise” associated with “ground-loops”.

Modular Expansion Port: All Xtant amplifiers are supplied with a modular
port used for docking any of Xtant’s signal processing modules.

Protection Circuitry: Both Thermal and Overcurrent protection has been
incorporated into all Xtant amplifiers. In the event of a problem, the amplifier will
reduce its power to maintain operation.

Sta tus LEDs:Four LEDs, visible through the cover, indicate operational status of all
Xtant amplifiers. The red LED illuminates when the amplifier is “ON”, the green LED
indicates when the noise gate is open, the yellow LED indicates that overcurrent pro­tection is employed and the orange LED indicates that the thermal protection circuit
is operational.

PASSIVE Outputs: The RM8 Resistor Module is designed to activate the “passive
speaker terminals.” It provides 8dB of attenuation for speakers connected to these ter­minals. RM4, RM12 and RM16 also available.

5

Xtant 604X SPECIFICATIONS

Frequency Response: 5 Hz to 50 kHz +/– 1 dB
Number of Channels: 4
Watts per Channel @ 4Ω: 4 x 75
Watts per Channel @ 2Ω: 4 x 150
Bridged Mono @ 4Ω: 2 x 300
Recommended Load: >2Ω Stereo / >4Ω Bridged
Distortion (THD): < .04%

Measured: 20 Hz to 20 kHz at rated power, all channels driven 4Ω

Signal to Noise Ratio: > 100 dB

Measured: A-weighted in 20 kHz noise bandwidth @ 1 volt sensitivity

Damping Factor: > 200 @ 100 Hz with 4Ω load
Input Sensitivity: 100 mV to 8.5 V RMS Unbalanced Source

100 mV to 17 V RMS Balanced Source

Input to Line Output Gain: 0 dB +/– 20 dB,

Selectable in 10 dB steps

On-Board Crossover: 12/24 dB/Octave Butterworth
Module Port(s): 4 – Accessory
Balanced Line: 2 – On Board
Passive Outputs: 2 Channels; RM8 provided
Power Supply: Fully Regulated, PWM
Operational Voltage: 11 to 15 Volts
Fusing Requirement: 120 Amp
Size (L xW x H): 23.63 x 8.875 x 2.145”
Warranty: Limited 4 Year Parts and Labor

SEE PAGE ELEVEN OF THIS MANUAL FOR COMPLETE DETAILS

6

ON-BOARD ELECTRONIC CROSSOVER

All Xtant “X” series amplifiers have on-board, two-way elec-

tronic crossovers. Xtant 3 and 4 channel models feature two inde­pendent two-way crossovers. Each crossover is tied to a set of inputs and con­trols the frequency range of the associated amplifier. Independent frequency
selection is provided for both the High and Low Pass sections. Aset of selec­table RCA line outputs (to feed additional components) are included with
each crossover. In addition, each crossover features four on-board header
jumpers (two for the amplifier and two for the RCA line outputs) which
allow you to select Bypass (Full Range), High Pass, and/or Low Pass modes.
The “X” Series models offer an additional Band Pass selection. When chosen,
the Band Pass selection is

available via the Low Pass jumper position for the

RCA line outputs.

The following Frequency Modules (SIPs)* are available from your Xtant

Dealer: 50 Hz, 70 Hz, 80 Hz, 90 Hz, 120 Hz, 150 Hz, 300 Hz, 500 Hz, 700 Hz,

1 kHz, 3 kHz, 4 kHz, and 5 kHz.

Please refer to the Installer’s Refer ence (insert) for the Frequency Module recep­tacle location and chart of frequency/SIP value code numbers

* SIP: an acronym referring to multiple resistors in a Single In-Line Package

7

OPTIONAL ACCESSORY MODULES

Xtant optional accessory modules are easily and quickly

installable by your Authorized Xtant Dealer. The upgrade

modules snap into place on the amplifiers PC board when the top
of the unit is removed. These accessories enhance your entire system, expand­ing and customizing performance for your unique applications.

PARAMETRIC EQUALIZATION MODULE – PQM 1

The PQM-1 is a precision tuning instrument, designed to be
adjusted with the use of a Real-Time-Analyzer. This true,
fully adjustable, one band parametric equalizer provides
individual frequency, Q/bandwidth, and +/- 18dB gain adjust­ment controls. By utilizing one of three (3) frequency modules included, any
frequency from 20 Hz to 20kHz can be chosen. The “Q” ranges from 1 to 10
in value, allowing a wide variety of bandwidth adjustment to address the
subtle tuning requirements common to mobile audio systems.

LOW FREQUENC

Y EQUALIZER – LFQ45

The LFQ45 will add Bass impact to any system. It provides
+4, +8 OR 12dB of Boost at a center frequency of 45Hz. A

MAX performance tweak.

Remote gain MODULE – RGM 1

The RGM 1 adds remote gain control for either subwoofer
or stereo channels. Add more bass or add more mids and
highs with the RGM 1. Remote mounted control adjusts up
to 15dB of gain. With a mounting depth of 1-3/4” and 20
foot RJ11 modular cord included, installation remains flexible.

8

MAINTENANCE

Recommended Cleaning Procedures

Cleaning the fan / Circuit Board – Every 90 Days

A. The internal fan in all Xtant amplifiers need periodic cleaning.

If you are in a high dust environment, every 30 days is
recommended. We recommend that your dealer remove
the cover and clean the fan blades with a soft brush.
Loose dust can be removed with a vacuum hose.

Caution: Have your dealer check the fan for obstructions if your

amplifier over heats. When the Thermal Protection
Circuit is engaged, the orange LED will be illuminated
and power may be reduced.

B. Have your dealer check the circuit board for dust. If

present, use a low pressure air source to blow-off the
dust particles. DO NOT

use a high-pressure source,

brush or any similar device to clean the circuit board!

Cleaning the Amplifier – Every 30 days

A. Clean the stainless steel cover with a light dust cloth. For

a more thorough cleaning, use window cleaner that is
ammonia free. Apply the cleaner to the cloth (not the
amplifier) and wipe the surface. T ake car e not to catch the
cloth on the copper mesh.

Caution: Do not allow liquids to touch the circuit board.

B. To polish the stainless steel cover use a commercially

available stainless steel cleaner/polish. It is important to
note that stainless steel has a (directional) grain. Please
read the directions supplied with the polish before
beginning. As a rule of thumb, always polish with the
grain. Apply the cleaner/polish to the cloth (not the
amplifier) and wipe the surface. T ake car e not to catch the
cloth on the copper mesh.

9

CUSTOMER RELATIONS

TECHNICAL SERVICES

STATEMENT OF PURPOSE

Our customer ’s satisfaction is our purpose. You repre­sent our present and our future. It is our goal to create
and nurture relationships based upon trust and respect.
This commitment is not taken lightly or just for today; it
is our way of doing business. We believe there is no
other way.

Xtant’s policies and procedures are designed, in the
event of a problem, to minimize the amount of your
“down-time” and inconvenience. It is our commitment
that the product will be at our facility for no more than
four (4) days. Please consider weekends or holidays
(which may fall within the time period) when estimat­ing the return date of serviced product.

For technical assistance and information regarding
products and/or installation, please contact Xtant’s
Customer Service Department from 8:00 am to 5:00 pm
MST– Monday thru Friday at:

Phone: [phone]
Fax: [phone]
U.S.A. toll free: [phone]

10

11

LIMITED U.S.A. WARRANTY

This warranty gives you specific legal rights, and you may also have other
rights which vary from state to state. Xtant Technologies (Xtant) warrants its

products to be free from defects in materials and workmanship under normal

use and service when the unit is installed by an Authorized Xtant Dealer as

folows: electronics (4) four years from original purchase date; speakers/sub-

woofers (3) three years from original purchase date. Non-Authorized Dealer installed
products carry a one (1) year parts and labor limited warranty. The extent and conditions of Xtant’s
Limited Warranty are as follows:

1. Authorized Xtant Dealer Installed Products: Xtant will repair at no charge, to the original pur­chaser, any unit which Xtant’s examination discloses to be defective and under warranty, provided
the defect occurs within the warranty period and the product is returned immediately to Xtant. This
warranty is not transferable.

2. Non-Authorized Xtant Dealer Installed Products: Xtant will repair at no charge, to the original
purchaser, any unit which Xtant’s examination discloses to be defective and under warranty, pro­vided the defect occurs within one (1) year from the date of purchase and the product is returned
immediately to Xtant. This warranty is not transferable.

3. The date of purchase and proof of Authorized Dealer Installation of an Xtant product must be
established by an original (or copy of the original) sales receipt which must accompany the arti­cle being returned for warranty work.

4. This warranty shall NOT apply to any Xtant unit found to have the original factory serial number
removed or defaced. All products received (by Xtant) for in warranty or out of warranty repair, with
their original serial numbers removed or defaced, will NOT be repaired and will be returned to
sender, freight collect.

5. The provisions of this warranty shall not apply to any Xtant unit used for a purpose for which it
is not designed, which has been repaired or altered in any way, or which has been connected,
installed, or adjusted other than in accordance with the instructions furnished in Xtant’s owner’s
manual. Nor shall this warranty apply to any part which has been subject to misuse, neglect, or
accident.

6. Xtant does not authorize any other persons to assume any other liability in connection with its
products. THIS WARRANTY IS THE ONLY EXPRESS WARRANTY MADE BY XTANT APPLICABLE
TO ITS PRODUCTS. ANY IMPLIED WARRANTY OR MERCHANTABILITY OR FITNESS FOR A PAR­TICULAR PURPOSE APPLICABLE TO XTANT’S AMPLIFIERS AND OR ACCESSORIES IS LIMITED
IN DURATION TO THE DURATION OF THIS LIMITED WARRANTY. XTANT SHALL NOT BE LIABLE
FOR THE INCIDENTAL, CONSEQUENTIAL, OR COMMERCIAL DAMAGES RESULTING FROM THE
BREACH OF THIS WRITTEN WARRANTY. Some states or provinces do not allow the exclusion or
limitation of incidental or consequential damages or limitations on how long an implied warranty
lasts; so the above limitations or exclusions may not apply to you.

7. Your unit will be serviced on an in-warranty basis within the warranty period for the correction
of warranted defects. If improper operation of your Xtant product should occur, contact your
Authorized Xtant Dealer for assistance with the return and factory repair of your Xtant product. If
an Authorized Xtant Dealer is not available, please contact Xtant’s Customer Service Department

for assistance.

ELECTRONICS SPEAKERS
Xtant Technologies Xtant Technologies
7676 South 46th Street 805 Woodman Ave.
Phoenix, Arizona 85040 Winslow, Il 61089
888-449-8268 800-556-2888

TO RETURN XTANT PRODUCTS OUT OF WARRANTY: Contact Xtant’s Warranty Department at

[phone] from 8:00 am to 5:00 pm (MST) for a Return Authorization Number. Return the unit,
postage prepaid, in the original protective carton. Please include a description of the problem and,
if desired, a request for an estimate of repair costs. Unless a request for an estimate is included, the
unit will be repaired as necessary. Repaired unit will be returned with an itemized statement,
C.O.D. certified or Visa/MC. Xtant provides a 90 day warranty on all repairs serviced as non-war­ranty units.

OWNER’S INSTALLATION LOG

Upon installation of your mobile audio sound system, your

Authorized Xtant Select Dealer will complete this log. Keep this

owner’s manual with your vehicle as a reference for all amplifier set-

tings.

owner’s name:
Vehicle: year:
xtant amplifier serial no.
input sensitivity

(CIRCLE SETTING)

Front Inputs Rear Inputs

–20 dB –10 dB 0 dB +10 dB +20 dB –20 dB –10 dB 0 dB +10 dB +20 dB

Front Crossover Rear crossover

CIRCLE JUMPER SETTING

: CIRCLE JUMPER SETTING:

Amplifier: byp high low BND Amplifier: byp high low BND
rca outputs: byp high low BND rca outputs: byp high low BND

frequency value frequency v alue

SIP High Pass FQ SIP High Pass FQ
sip low pass FQ sip low pass FQ

output gain adjustment noise gate adjustment

switch: on off

threshold position

(DRAW ARROW POSITION)(DRAW ARROW POSITION)

Accessory modules (CIRCLE SETTING)
LFQ45 front rear pqm-1 (FRONT) yes no

yes no yes no

pqm-1 chip frequency

RGM 1

front rear pqm-1 (REAR) yes no

yes no yes no

pqm-1 chip frequency

Balanced Line Input Passive Outputs

front rear RM4 RM8 RM12 RM16

yes no yes no yes no yes no yes no yes no

Xtant Select Dealer
phone: date installed:
installation specialist:

RIGHTLEFT RIGHTLEFT

12

front rear
