x-rite DTP32HS Operator’s Manual
DTP32HS
Auto Scanning Densitometer
Operator’s Manual
CE Declaration
Manufacturer's Name: X-Rite, Incorporated
Manufacturer's Address: 3100 44th Street, S.W. • Grandville, Michigan • U.S.A.
Model Name: Densitometer
Model No.: DTP32HS
Directive(s) Conformance: EMC 89/336/EEC LVD 73/23/EEC
Federal Communications Commission Notice
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference with radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures: reorient or relocate the receiving antenna; increase the separation between the
equipment and receiver; connect the equipment into an outlet on a circuit different from that to
which the receiver is connected; and/or consult the dealer or an experienced radio/television
technician for help.
NOTE: Shielded interface cables must be used in order to maintain compliance with the desired
FCC and European emission requirements.
DTP32HS DENSITOMETER
Industry Canada Compliance Statement
This Class B digital apparatus meets all requirements of the Canadian Interference-Causing
Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel
brouilleur du Canada.
Equipment Information
Use of this equipment in a manner other than that specified by X-Rite, Incorporated may
compromise design integrity and become unsafe.
WARNING: This instrument is not for use in explosive environments.
ADVERTENCIA - NO use este aparato en los ambientes explosivos.
AVVERTIMENTO - NON usare questo apparecchio in ambienti esplosivi.
WARNUNG: Das Gerät darf in einer explosiven Umgebung NICHT verwendet werden.
AVERTISSEMENT: Cet instrument ne doit pas être utilisé dans un environnement explosif.
Proprietary Notice
The information contained in this manual is derived from patent and proprietary data of
X-Rite, Incorporated. The contents of this manual are the property of X-Rite, Incorporated and are
copyrighted. Any reproduction in whole or part is strictly prohibited. Publication of this information does
not imply any rights to reproduce or use this manual for any purpose other than installing, operating, or
maintaining this instrument. No part of this manual may be reproduced, transcribed, transmitted, stored
in a retrieval system, or translated into any language or computer language, in any form or by any means,
electronic, magnetic, mechanical, optical, manual, or otherwise, without the prior written permission of an
officer of X-Rite, Incorporated.
This product may be covered by one or more patents. Refer to the instrument for actual patent numbers.
Copyright © 2003 by X-Rite, Incorporated “ALL RIGHTS RESERVED”
X-Rite® is a registered trademark of X-Rite, Incorporated. All other logos, brand names, and product names mentioned are the
properties of their respective holders.
1
DTP32HS DENSITOMETER
Warranty Information
X-Rite, Incorporated warrants each instrument manufactured to be free of defects in material and
workmanship for a period of twelve months. If the fault has been caused by misuse or abnormal
conditions of operation, repairs will be billed at a nominal cost. In this case, an estimate will be submitted
before work is started, if requested. The unit shall be returned with transportation charges prepaid.
THERE ARE NO WARRANTIES OF MERCHANTABILITY OR FITNESS. THIS WARRANTY OBLIGATION IS
LIMITED TO SERVICING THE UNIT RETURNED TO X-RITE, INCORPORATED OR AN AUTHORIZED SERVICE
DEALER FOR THAT PURPOSE.
X-Rite, Incorporated offers a repair program for instruments out of warranty. For more information,
contact X-Rite Customer Service Department. Always include serial number in any correspondence
concerning the unit. The serial number is located on the bottom plate of the instrument.
This agreement shall be interpreted in accordance with the laws of the State of Michigan and jurisdiction
and venue shall lie with the courts of Michigan as selected by X-Rite, Incorporated.
Table of Contents
Overview and Setup 3
Instrument Description 3
Unpacking and Inspection 3
Instrument Interface 4
Instrument Location Requirements 5
Strip Feeding Requirements 5
Instrument LED Indicator 5
Strip Positioning and Patch Requirements 6
Calibration 7
Frequency of Calibration 7
Reflection Reference Handling 7
Calibration Procedure 7
Strip Measurement 8
Important Notes 8
Strip Positioning and Measurement Techniques 8
Troubleshooting, Service, and General Maintenance 9
Troubleshooting 9
Service Information 10
General Maintenance 10
Cleaning the Reflection Reference 11
Technical Information 12
Instrument Reset 12
Drive Wheels Rotation Timer 12
Technical Notes 12
Instrument Specifications - Pending 13
General 13
Performance 13
Environmental 14
Safety Compliance 14
Standard Accessories 14
Optional Accessories 14
Operational Considerations Between a DTP32R and a DTP32HS 15
Operation 15
Barcode Operation 16
2
Overview and Setup
(
r
Instrument Description
The DTP32HS densitometer is a “high speed” color measurement instrument that reports
densitometric and dot data. The instrument is designed to calibrate color output devices
including large format printers, proofers, and digitally connected color copiers. The
DTP32HS densitometer is a “drop-in” replacement for the X-Rite DTP32R instrument.
This manual covers the installation, basic operation and maintenance of the instrument.
Specific instructions for using the instrument with your third-party software program can be
found in the third-party software documentation.
As the DTP32HS is designed to be a drop-in replacement for the DTP32R Automatic Strip
Reading Densitometer, reflection versions, it will by default report itself as a DTP32R. Most
existing software packages will reference a DTP32R in their connection menu while newer
software may use DTP32HS. Select DTP32HS if it is available, otherwise select the DTP32R.
DTP32HS DENSITOMETER
3-Color LED
Indicato
Alignment Mark
Shipping Spacer
remove)
Strip Entrance
Unpacking and Inspection
After removing the instrument from the shipping carton, inspect it for damage. If any
damage has occurred during shipping, immediately contact the transportation company. Do
not proceed with installation until the carrier’s agent has inspected the damage.
Your instrument was packaged in a specially designed carton to assure against damage. If
shipment is necessary, the instrument should be packaged in the original carton along with
all the accessories. If the original carton is not available, contact X-Rite to have a
replacement shipped to you.
Interface Cable
3
DTP32HS DENSITOMETER
Instrument Interface
The DTP32HS must be interfaced directly with one of the computer’s Serial ports. For
attachment to a Mac Mini-DIN 8 Serial Port, you need to use the optional adapter (P/N
SE108-DB9PA-01).
1. Quit all programs and shut down the computer before installing interface cabling.
2. Connect the interface cable as shown.
CAUTION: Use only the 100-240VAC input, +12VDC output Switching Power Supply to
power the instrument.
3. Plug the small end of the switching power supply into the power input connector
of the interface cable.
4. Plug the detachable line cord into the power supply and then into the AC wall
receptacle. The instrument does not have an ON/OFF switch.
+12VDC Switching
Power Supply
Detachable Line Cord
AC Wall
Receptacle
Power Input
SE108-97-02
Interface Cable
PC
DB9
MAC
Mini-DIN 8
SE108-DB9PA-01
(optional)
4
DTP32HS DENSITOMETER
Instrument Location Requirements
To ensure reliable read switch activation, the instrument must sit on a reasonably flat, level,
and stable surface.
Strip Feeding Requirements
To ensure consistent strip readings, you must feed the strip into the instrument at a
continual pace (without pausing) and speed before it is taken in by the drive motor. More
specifically, a strip cannot be fed into the instrument too quickly (more than 7.2
inches/second or 183 mm/second), too slowly (less than 2.6 inches/second or 66
mm/second), or intermittently (pausing one or more times). If you are experiencing any
strip-feeding problems, observe how fast the motor is moving the strip (about 5.4
inches/second or 137 mm/second) and try to match the speed as closely as possible.
Before feeding a second strip or a second pass of a multi-pass strip into the instrument, you
must momentarily pause (approx. 3 seconds) to allow the instrument to process data from
the first measurement. The LED is not lit when the instrument is processing data.
Instrument LED Indicator
The LED indicates a variety of instrument operation conditions, such as calibration mode
and operation. Below is a complete list of conditions reported by the LED.
Operation Mode
• Solid Green—self-test passed and instrument is ready for use with defined strip.
• Slow Flashing Green—strip reading in progress (strip being read) or ready for next pass
(multi-pass strip definition).
• Fast Flashing Green—strip reading was attempted but the wrong strip was read, or strip
was skewed during reading.
• Slow Flashing Amber/Green—a configuration barcode was scanned and the instrument is
waiting for the 2
• Fast Flashing Amber/Green—there was an error in recognizing a barcode or the
configuration failed. Reread the entire barcode, starting with the first pass.
Calibration Mode
• Slow Flashing Green—instrument calibration in progress (strip being read).
• Solid Green after Flashing Green—instrument calibration was successful and instrument
is ready for use.
• Fast Flashing Green—instrument calibration failed.
Error/Reset Mode
NOTE: When the instrument is first turned on, the motor runs, and the LED illuminates red while
performing self-tests. Self-tests are completed in approximately 2 to 3 seconds, at which time the LED
turns green and the motor stops under normal conditions.
nd
or 3rd barcode pass.
• Fast Flashing Red—incorrect power supply attached. Verify correct 12-volt power supply
is used.
• Slow Flashing Red—a factory reset is in progress.
• Flashing Red/Green— the host firmware loader program is reprogramming the
instrument.
5
DTP32HS DENSITOMETER
Strip Positioning and Patch Requirements
The strip width must extend a minimum of 0.75” (19mm) to the left of the alignment mark
(optical path) when measuring. This ensures the read switch is activated when the strip is
inserted into the instrument.
TOP VIEW
Alignment Mark
1.2" (3 0.5 mm)
min. leader
length
0.75"
(19mm)
min.
0.40" (10.2mm)
min. patch
height
4" (101.6mm) max. to paper stop
0.50" (12.7mm) min. patch width
Paper Stop
6
Calibration
Frequency of Calibration
Your DTP32HS should be calibrated weekly. Refer to the following procedure for details on
the calibration process.
Reflection Reference Handling
Handle the reflection reference by the edges. Make sure that the reflection reference is free
of dust, dirt and smudgemarks. Refer to General Maintenance Section for cleaning
procedure. Always store the reflection reference in it protective envelope away from light
and heat.
Calibration Procedure
A calibration can be performed at any time. All that is required is that you insert the
reflection reference into the instrument as you would with any other strip.
1. Center the designated end of the reflection reference under the alignment mark.
2. Insert the reference strip until it is automatically advanced by the drive motor. Refer to
“Strip Feeding Requirement” for more information.
DTP32HS DENSITOMETER
LED Indicator
Alignment Mark
3. The LED slowly flashes green while the strip is pulled through the instrument and out the
back. The LED turns solid green and a short beep sounds after a successful calibration. If
the calibration fails (fast flashing green LED and long beep), verify strip is clean and reread.
4. Place the reflection reference in its protective envelope and store away from light and
heat.
7
DTP32HS DENSITOMETER
Strip Measurement
Important Notes
• You should refer to the documentation for the software program that you are using with
your instrument. All applications that utilize this instrument must be running during
measurements.
• The strip must have at least a 1.2″ (30.5mm) leader before the leading edge of the first
step. Contact X-Rite Applications Support if additional information is required. Inspect
the strip for spots or defects on the steps. Defects may cause inaccurate measurements.
• The darkest patch of a strip must be read first unless there is at least 1.1″ (27.9mm)
unprinted trailer after the last patch.
• Some software packages define strips as “multi-pass” where all color passes must be
read before a conformation is displayed on the monitor. In these cases, a successful
reading of a color pass is shown by the instrument slowly flashing green after the
reading. This indicates that you may continue to the next color pass. Fast flashing of
green indicates a re-read is required on the pass. The instrument’s LED will stay at solid
green after all passes are successfully read.
Strip Positioning and Measurement Techniques
The following information is provided to familiarize you with reading strips, a series of
printed control patches.
1. Select strip type to measure from the host software.
2. Position the strip so that the group of patches to measure is directly under alignment
mark on the cover.
3. Insert the strip until it is automatically advanced by the drive motor. Refer to “Strip
Feeding Requirement” for more information.
For large strips (media that extends outside the left side of the cover), guide the strip
with slight pressure. This prevents skewing of the strip as it is measured. Do not “tug”
forwards or backwards on strip while the internal motor is pulling the strip through.
4. The LED slowly flashes green while the strip is pulled through the instrument and out the
back.
A successfully reading is verified by a solid green LED and a short beep on the
instrument, and a conformation message on the computer monitor.
When measuring large strips,
guide along outside edge
Insert the strip until it is
automatically advanced by
the rear drive rollers
8
DTP32HS DENSITOMETER
Troubleshooting, Service, and General Maintenance
Troubleshooting
The DTP32HS is used with a number of third party software vendors. To get the most
specialized technical assistance, you should first contact the technical service representative
for the specific third-party software that you are using.
Prior to contacting X-Rite, Inc. Customer Service for instrument problems try the applicable
solution(s) described below. If the condition persists, contact a Customer Service
Representative toll-free by phone at:
1-888-826-3059; or by fax at: 1-888-826-3061. You can also contact X-Rite’s support staff
through our Support page at www.xrite.com
LED not lit:
• Ensure that the power supply is plugged in and connected to the Interface Cable.
• Reset the instrument (see Instrument Reset).
Fast flashing green LED:
• If error persists, clean instrument and calibration strip (see General Cleaning).
• Reset the instrument (see Instrument Reset).
Solid red LED:
• Remove power from the instrument, reapply power and see if the condition is corrected.
• Reset the instrument (see Instrument Reset) and calibrate.
• This could indicate that the unit may not be programmed properly, which could happen
if power was removed during reprogramming. Try reprogramming the instrument again
(refer to the programming instructions that came with your update).
Densitometer and software not communicating:
• Verify that the instruments LED indicates normal operation (see Instrument LED
Indicator). If normal, close and restart the software application. If this does not work
reboot the computer.
• Remove power from the instrument, reapply power and see if the condition is corrected.
• Check for proper configuration setting from the software provider.
• Reset the instrument (see Instrument Reset) and calibrate.
Repeated strip measurement failures:
• Ensure that the strip is being read in accordance with your software’s documentation.
• Close and restart the software application.
• Perform a calibration on the instrument (see Calibration section).
• Reset the instrument (see Instrument Reset).
Repeated calibration failures:
• Clean instrument and reference (see General Maintenance).
• Strip definition set below five steps.
• Reset the instrument (see Instrument Reset) and calibrate.
.
Reading lamp not working:
• When the temperature in the optics area reaches or exceeds 45°C (or 113°F), the
instrument will keep the reading lamp from turning on. This is to prevent any damage
from occurring to the optics components. Allow the instrument to cool before measuring.
• Reset the instrument (see Instrument Reset).
9
DTP32HS DENSITOMETER
Service Information
The DTP32HS Densitometer is covered by a one-year limited warranty and should be
referred to an authorized service center for repairs within the warranty period.
X-Rite provides repair service to their customers. Because of the complexity of the circuitry,
all repairs should be referred to an authorized service center.
X-Rite will repair any instrument past warranty. The customer shall pay shipping and repair
cost to the authorized service center, and the instrument shall be submitted in the original
carton, as a complete unaltered unit along with all the supplied accessories.
General Maintenance
Your instrument requires very little maintenance to achieve years of reliable operation.
However, to protect your investment and maintain reading accuracy, a few simple-cleaning
procedures should be performed from time to time.
General Cleaning
Whenever required, the exterior of the instrument may be wiped clean with a cloth
dampened in water or mild cleaner.
NOTE: DO NOT use any solvents to the clean the instrument, this will cause damage to the cover.
Cleaning the Strip Reading Mechanism
The reading mechanism should be cleaned once a week in normal environments, and more
often in dirty or dusty environments.
1. Disconnect the power supply from the instrument.
2. Turn instrument upside-down.
3. Using your index finger and thumb, pinch the two tabs on the bottom of the base
assembly towards each other.
10
Base Tabs
4. Holding the tabs, lift base assembly upward.
5. Clean base surface, bottom plate surface, idler rollers, and drive wheels with a lint-free
cloth.
Idler Roller(s)
Drive Wheel(s)
Serial Number Plate
DTP32HS DENSITOMETER
Idler Roller(s)
Base Surface
Idler Roller(s)
Bottom Plate Surface
6. Position Base Assembly over Bottom Plate and insert tabs into openings. The Base is
positioned properly when it snaps into place
Cleaning the Reflection Reference
The reflection reference can be cleaned with a lint free cloth whenever required. Make sure
to return the reference to its protective case when finished. Always handle the
calibration reference by the edges.
If required, a new calibration reference can be ordered from X-Rite. Order calibration
reference part number DTP32HS-100-KIT.
11
DTP32HS DENSITOMETER
Technical Information
Instrument Reset
Note: When performing an Instrument Reset, which restores the X-Rite Factory Defaults, you will have to
ensure the correct configuration for your software is then restored.
The following procedure resets DTP32HS to the factory default settings.
1. Disconnect power from the instrument.
2. Insert a piece of paper or a strip into the instrument past the front idler rollers.
3. Reapply power to the instrument.
4. After the LED begins to flash red slowly, remove the paper The factory defaults are now
reinstated.
Drive Wheels Rotation Timer
The instruments rubber drive wheels may develop temporary flat spots if the instrument sits
idle for and extended period of time. These “flat spots” could cause the first few moments of
a reading to contain unwanted noise. To prevent this condition, the instrument incorporates
an automatic timer that rotates the drive wheels for 10 seconds after a 12 hour, non-use
period. A reading or computer command that occurs during a wheel rotation timer cycle will
override the cycle and the clock resets.
Technical Notes
Firmware Update
After updating the instrument firmware you must power down the instrument and then
power it back up. This ensures that the instrument functions properly and user-configurable
settings are restored to the factory defaults.
Calibration Strip
The number of steps in the strip definition must be set to a minimum of five to achieve a
successful calibration using the X-Rite calibration reference strip.
12
Instrument Specifications - Pending
General
Measurement Geometry: ........ Reflection 0°/45° per ANSI PH2.17/ISO 5/4
Multi-sensor array
Measurement Area: ............... 2 mm x 4 mm, 2mm in the direction of travel
Light Source: ........................ Gas pressure filament lamp with approx. @ 2850°K
color temp.
Receiver: ............................. Blue enhanced silicon photodiode
System Response: ................. ANSI/ISO Status T
Calibration............................ Automatic with QuickCal®
Measuring Location ................ 4.0” (101 mm) from the alignment mark to the
rightmost edge
Sample Characteristics:.......... Thickness: 0.003” (0.076 mm) to 0.015” (0.381 mm)
Size: unit is open at one end and can accept any size
sheet as long as it can be pulled evenly through the
unit.
Patch Size: .400” (10.16 mm) min. in direction of
travel by 0.5” (13 mm) min. wide, 1 mm wide 1.0D
contrast space between patches, or 0.5D min.
difference between patches.
Communication Interface/
Protocol (as described in X-Rite
DTP RCI manual):.................. I/O port: patented bi-directional RS-232 at <=19.2K
baud rate
Communication Protocol: X-Rite DTP series RCI
commands
Data format: transmitted in Density, +Dot, -Dot, or
Reflectance
Output has x10 capability
Dimension:........................... L: 7.3” (185 mm), W: 4.5” (114 mm), H: 2.7” (69 mm)
Weight:................................ Approx. 1.8 lbs (0.8 kg)
Power Requirements:............. +12VDC @ 700 mA maximum
DTP32HS DENSITOMETER
Performance
Measurement Rate: ............... Approx. 5.4” (137 mm)/sec
Measurement Range: ............. Reflection: 0.00D to 2.20D
Linearity: ............................. ±0.02D or ±2%, 0.00D to 2.20D, whichever is greater
Repeatability: ....................... ±0.01D, 0.00D to 1.9D
±1%, 1.91D to 2.20D
Inter-Instrument Agreement: .. ±0.02D or 2%, 0.00D to 2.20D, whichever is greater
Zero Stability:....................... ±0.01D max
Lamp Life: ............................ Approx. 1,000,000 scans @ 11” (279 mm)
13
DTP32HS DENSITOMETER
Environmental
Operating Temp: ................... 10° to 35°C
Storage Temp:...................... -40° to 45°C
Humidity Range: ................... 0 - 85% RH
Usage:................................. Indoor Only
Altitude:............................... 2000m
Pollution Degree:................... 2
Transient Overvoltage:........... Category II
Safety Compliance
Underwriters Laboratories:...... UL 61010-1
Canadian Standards Association: CSA 22.2 No. 1010.1-92
CENELEC.............................. IEC (EN) 61010-1
Design and specifications subject to change without notice.
Standard Accessories
Calibration Reference
DTP Series CD
Serial Communication Cable (integrated with the instrument)
+12VDC Switching Power Supply
Line Cord (North America)
Line Cord (Europe)
Optional Accessories
Mac Serial Adapter ............ P/N SE108-DB9PA-01
25-pin Serial Adapter......... P/N SE108-231-01
14
Loading...
