x-pointer XP300 User Manual

XP300 USER MANUAL

www.choistec.com

1. Package Contents 4

2. Features of the XP300

5

3. Setting up the XP300

6

4. Layout of the XP300

9

5. How to use the XP300

12

6. Cautions

13

7. Certifications

14

8. Support

16

9. Specifications of the XP300

17

Features of the XP300

5

XP300 User Manual

4

1. Package Contents

XP300 package contains a Transmitter,
a Receiver, a Pouch, a User Manual and two

1.5V Type AAA Batteries.

2. Features of the XP300

Superior ergonomic design allows user to
comfortably take control of the PC and
presentation. By using Radio instead of Infra­red communication, XP300 offers greater
range, reliability and freedom of movement.
XP300 Model with optical touch sensor mouse
controls offer greater functionality with finer
mouse control and intuitive presentation
controls.

●

Main functions : Page Up/Down, Start or End
Slide Show, Switch Application /Task bar, Optical
Touch Sensor Mouse(360 degree)

●

The Integrated Optical Touch Sensor provides 360
degree directional mouse controls with drag and
drop capability.

●

By using a range of communication frequencies
and unique IDs X-pointers can overcome any
interference in the RF environment from other
devices.

Content Q'ty

① Transmitter 1EA

② Receiver 1EA

③ Pouch 1EA

④ User Manual 1EA

⑤ Battery 2EA

①

②

③

④

⑤

Setting up the XP300

7

XP300 User Manual

6

●

The XP300 receiver is interoperable. One receiver
is all you need to use whichever X-pointer model
fits the occasion.

●

Use (Task Switch, Alt+Tab) button to select a
particular window that you want to use for a
smooth presentation.

●

Delivers drag and drop, as well as drawing
function in your PPT presentations.

●

The auto-off feature turns off the laser after 20
seconds to prevent accidental damage or battery
drain.

●

USB Receiver stores easily in the space provided.

●

No software installation needed. Simply plug the
receiver into the USB port, press and hold any
function button for 1 second and you are ready to
go.

●

Provides excellent Leather pouch for protection
from the elements, scratches, dirt, and shocks.

3. Setting up the XP300

1. Insert 2 x AAA batteries into XP300 Transmitter.

2. Insert the Receiver into the USB port of the PC.

3. The Receiver will be installed automatically and
will work immediately after it is inserted into the
USB port.

4. To use the mouse function, set the Mode Selector
located on the right side of the Transmitter to

Mouse( ). Control the Optical Touch Sensor to
move the mouse arrow. Press the left and right
buttons to activate the mouse left click and
mouse right click functions.

5. To use for presentations, set the Mode Selector
located on the right side of the Transmitter to
Presentation( ). The left button( ) will start
and stop the presentation. The right button( )
will switch the application programs. To move
forward, use the right mouse button( ). To
move backward, use the left mouse button( ).

Layout of the XP300

9

XP300 User Manual

8

1. Press and release “LED & RESET button” on the
Receiver for 1 second. The LED(Green) will start
blinking and blink for 10 seconds.

2. Press together Two buttons (Start or End Slide
Show, Alt+Tab) on the Transmitter and release the
buttons when the LED turns off automatically.

3. If ID paired successfully, the LED on the Receiver
and Transmitter will blink 4 times together.

4. XP300 is ready to use.

- In case of the failure in ID pairing -

Remove and reinsert the USB Receiver.
Please repeat above installation processes.

ID Pairing between

Transmitter and Receiver

6. LED Indicator
LED on the transmitter displays the mode status

7. If you see the failure in recognizing the Receiver,
please follow ID Pairing process.

Status LED
Mouse Mode Orange color
Presentation Mode Green color
Laser On Red color

4. Layout of the XP300

The Transmitter is an all in one controller- A
Remote Controller, Optical Touch Sensor
Mouse, Power On/Off Switch, Mode Selector
and Laser Pointer. The Receiver consists of a
USB plug, LED & RESET buttons.

Layout of the XP300

11

XP300 User Manual

10

No. Button Function

⑥ Page Down [Presentation Mode ] Move to next page

Mouse Right Click [Mouse Mode ] Right button of a PC Mouse

⑦ Laser Laser beam for pointing

⑧ Power On /Off Power on or off of transmitter

⑨ Mode Selector Switch between Presentation and Mouse mode

⑩ RELEASE Take out USB receiver from storage

⑪ USB Storage Compartment USB receiver storage compartment or outlet

⑫ USB plug Insert it into the USB Port

⑬ LED & RESET ID Recognition or Status indicator

No. Button Function

① Task Switch(Alt+Tab) Switching between open windows / tasks
② LED Display the mode status
③ Start or End Slide The Slide Show starts/ends from the current slide.

Optical Touch Sensor has the same functionality as the touchpad of a laptop
computer and the left button of a mouse.

④ Optical TouchSensor ※ Drag & Drop ※

Has the same functionality as the left button of a Mouse. Press the Optical Touch
Sensor for 0.5 sec to activate "Drag". Push again to release it.

⑤ Page Up/ [ Presentation Mode] Move to previous page

Mouse Left Click [Mouse Mode ] Left button of a PC Mouse

Caution in Usage

13

XP300 User Manual

12

5. How to use the XP300

■ Presentation mode( )

1.

Open the file for your presentation using PowerPoint.

2. Set the power switch on the transmitter to ON.(The
RED LED will blink.)

3. Set the Mode Selector on the transmitter to
presentation(P/T) Mode.

4. Press the Start or End Slide Show ( ) button on
the transmitter. The slide show starts from the
current slide. Press the Start or End Slide Show
button again to end a slide show.

5. To display the next slide, press the DOWN( )

button. To display the previous slide, press the
UP( ) button.

■ Mouse mode( )

1. Set the power switch on the transmitter to ON.
(The RED LED will blink.)

2.

Set the Mode Selector on the transmitter to Mouse Mode.

3. Sliding your finger across the touch sensor moves
the mouse pointer on the screen in the same
direction. Pushing once performs a left click,
pushing twice performs a double click. Press the
Optical Touch Sensor for 1 sec to activate "Drag" and
push again to release it.

4. " " button has the same functionality as the left
click, " " button has the same functionality as
the right click.

6. Cautions

Use of controls adjustments, or performance of
procedures other than those specified herein
may result in hazardous radiation exposure.

1. Do not stare into laser beam.

2. Do not aim the laser at people.

3. Keep out of reach of children.

4. Any changes or modifications to the controller
could void your authority to operate the
equipment.

5. Do not place the controller in a location where it
is subject to direct sunlight or extreme heat.

6. If any solid object or liquid falls onto the
controller, disconnect it and have it checked by
qualified personnel.

7. When not using the controller, set the power
switch to OFF.

XP300 User Manual

14

Certifications(FCC, CE, TELEC, FDA, PSC)

15

7. Certifications

(FCC, CE, TELEC, FDA, PSC)

1. Model Name
Transmitter : XP300T
Receiver : XP300R

2. Certification

FCC ID : RVBXP300T

This Device complies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
(1)This device may not cause harmful
interference, and (2)This device must accept any
interference received, including interference that
may cause undesired operation.

This equipment has been tested and found to
comply with the limits for Class B digital device,
pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation.
This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this

equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference by one
or more of the following measures:

●

Reorient or relocate the receiving antenna.

●

Increase the separation between the equipment
and receiver.

●

Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.

Specifications of the XP300

17

XP300 User Manual

16

●

Consult the dealer or an experienced radio/TV
technician for help.

“Caution : you are cautioned that any changes or
modifications to the equipment not expressly
approved by the party responsible for compliance
could void your authority to operate the equipment.”

“Note : This unit was tested with shielded cables on
the peripheral devices. Shielded cables must be
used with the unit to ensure compliance.”

3. Manufacturer : Chois Technology Co., Ltd/ Made

in KOREA

If you have problems while using the XP300 or
if you have any suggestions, don’t hesitate to
contact us.

Tel : [phone], Fax : [phone]
Homepage : www.choistec.com,
E-mail : [e-mail]

9. Specifications of the XP3008. Support

1. Transmitter

Bandwidth 2.4GHz ISM (2,405~2,480MHz)

Channel 76

RF Range 30m (Open Field )
RF Power <3mW

Modulation GFSK

RF Type Half Duplex

RF Data Rate 2Mbps

ID Code 65,536

Mouse 800CPI
Operating
Temperature

-10~ 50°C

Laser ClassII( <1mW)
Laser
Wavelength

650nm

8EA (Input button 4, Optical Touch

Buttons Sensor 1, Laser 1, Power ON/OFF

switch 1, Mode Selecter 1)

Battery DC 1.5V Type AAA x 2EA
Dimension 120 x 36.5 x 19mm
Weight 30g
Certificate CE, FCC, TELEC, FDA, PSC

XP300 User Manual

18

2. Receiver

Input Power 5V( USB Power)

Operating
Temperature

-10~ 50°C

RF Power < 2mW

OS Windows 2000, XP, Vista

System IBM PC / AT & Laptop PC

Interface USB1.1 / 2.0

Dimension 47.5 x 16 x 7.5mm

Weight 5g
