Xplore DT4100 Quick Start Manual
WiFi PDA
DT4100
Quick Start Guide
1
Contents
Copyright ................................................................................................ 2
Disclaimer
............................................................................................... 2
Regulatory Information
.......................................................................... 2
Safety Information
.................................................................................. 4
Getting Started
........................................................................................ 5
Device Overview
................................................................................ 5
Installing and Removing the Battery
................................................... 7
Battery Charging
................................................................................ 8
LED Status Description
.................................................................... 10
Powering the Device On and Off
...................................................... 11
Suspending the Device
.................................................................... 11
Using the Device................................................................................... 12
Viewing System Information
............................................................. 12
Using Wi-Fi
....................................................................................... 12
Using Bluetooth
................................................................................ 12
Using NFC
........................................................................................ 13
Adjusting Date & Time
...................................................................... 13
Adjusting Volume
.............................................................................. 13
Adjusting Display Settings
................................................................ 13
Dening Keys
................................................................................... 14
Changing Battery Charging Policy
................................................... 14
Changing Language
......................................................................... 15
Performing System Backup
.............................................................. 15
Performing System Restore
............................................................. 15
Resetting the Device
........................................................................ 16
Contents
2
Copyright
Copyright© 2015 Group Sense Mobile-Tech Limited. All rights reserved.
No part of this document may be reproduced, distributed, translated, or
stored in any form without the prior written permission of Group Sense
Mobile-Tech Limited. All brands and product names mentioned herein
may be trademarks or registered trademarks of their respective owners.
Product specications are subject to change without prior notice.
Disclaimer
The contents of this document are provided as is. Group Sense MobileTech Limited makes no representations or warranties with respect to
the contents herein and specifically disclaims any express or implied
warranties of merchantability or tness for any particular purpose. Group
Sense Mobile-Tech Limited reserves the right to revise this document at
any time without prior notice.
Regulatory Information
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. Changes
or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
FCC Radiation Exposure Statement
This device should be installed and operated with a minimum separation
distance of 20cm between the radiator and all persons. This transmitter
must not be co-located or operated in conjunction with any other antenna
or transmitter.
CE Statement
This device has been tested and found to comply with the following EU
Directives:
Copyright
3
• R&TTE Directive (1999/5/EC)
• EMC Directive (2004/108/EC)
• Low Voltage Directive (2006/95/EC)
The assessment of compliance of the device was performed according to
the following European standards:
• EMC: EN 301 489-1 V1.9.2, EN 301 489-3 V1.4.1, EN 301 489-17
V2.2.1
• Health: EN 62311:2008, EN 62209-2:2008, EN 62479:2010
• Safety: EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011
• Radio: EN 300 328 V1.7.1, EN 300 330-1 V1.7.1, EN 300 330-2
V1.5.1, EN 50360:2001
Use Restrictions: This device is restricted to indoor use when
operating in the 5150 to 5250 MHz frequency range.
Radiation Exposure Statement
This devise is designed, tested, and manufactured to comply with the
limits for exposure to RF energy set by international regulatory agencies.
“Specic Absorption Rate,” or SAR, refers to the rate at which the body
absorbs RF energy. The SAR limits for Wi-Fi and Bluetooth are 1.6
watts per kilogram (W/kg) for the FCC, and 2.0 W/kg for the Council of
the European Union. This device has been tested, and meets the FCC
and European Union RF exposure guidelines for Wi-Fi and Bluetooth
operation.
Regulatory Information
4
Safety Information
Please read the following information carefully before using the device for
the rst time, and keep this Quick Start Guide in a safe place for future
reference.
■
Always treat the device with care and keep it in a clean and dustfree environment.
■
Do not expose the device to extremely hot, cold or humid
environment. The operation temperature is from –10°C to 50°C.
■
Do not use the device in wet or rainy conditions.
■
Do not charge the device in extremely hot (over 38°C) or cold
conditions (below 0°C).
■
Do not attempt to disassemble or modify the device including the
charger.
■
Do not operate the device when your hands are wet.
■
Do not insert foreign objects into the openings of the device.
■
Use only the charger and battery approved for the device.
■
Install the cradle on a at and stable surface.
■
Do not cascade over 3 cradles in series.
■
Do not use the charger if the power cord or plug is damaged.
■
Do not disassemble, crush or puncture the battery.
■
Do not expose the battery to high temperatures.
■
Do not let battery terminals touch other metal objects that could
lead to short-circuit of the battery.
■
Do not dispose of the battery in re or water.
■
Dispose of used battery properly according to local laws and
regulations.
Safety Information
5
Getting Started
Device Overview
1
2
3
4
5
6
7
8
9
10
11
12
13
16
15
14
17
No. Item Description
1
MicroSD card
cover
Open the cover to access the MicroSD card
slot
2 Left side key
Congurable shortcut key. Default as Menu
key
3 Power key
Press and hold to turn the device on or off.
If the device is on, press to suspend.
4 /12 Strap eyelet Attach the anti-drop string
5 Congurable LED Software congurable LED
6 Device LED Power and Wi-Fi connection status indicator
7 Light sensor Auto screen brightness control
Getting Started
