USER MANUAL
1
Thank you for choosing SPRINT
GPS cycling computer
With low power consumption
2.7 inches HD screen
More than 30 hours of battery life
Integrated accelerometer, geomagnetic
Temperature and air pressure sensors
Support all bluetooth and ANT+ sensors
2
Step 1: Charging
Take out the USB cable and connect to a standard 5V
USB adapter, SPRINT will turn on automatically. It takes
about three hours to be fully charged.
SPRINT cycling computer
2.5mm hex wrench
Rubber pad
Extended computer mount
Micro USB cable
User manual
×1
×1
×1
×1
×1
×1
ACCESSORIES LIST
QUICK SETUP
Button diagram
Micro USB
Side button+
Side button-
home button
WELCOME
Press the button below to
start the initial setup
3
Step 2: Download the application
Step 3: Initial setting
Search XOSS in Apple App Store or Google play
download the application.
Before you use SPRINT for the first time, you need to do
some initial settings. Following the instructions on your
SPRINT, use side button to select and adjust options,
and use front button to confirm.
Step 4: Start using
When you complete the initial setting it will enter the data
page(figure 1).
• When SPRINT is not recording,and not be operated for
60 seconds, it will enter the standby page(figure 4), you
can press the home button to exit this page
• At data page(figure 1)you can use side buttons to
increase or decrease the number of data fields that
shows on the screen
XOSS
• Press the home button to switch between data page
(figure 1) and map page(figure 3)
• Long press the home button a pop-up menu will
show(figure 2), you can choose
Start > start recording
Sync > APP connection
Menu > menu page
5
Strong signal
Good signal
Weak signal
No signal
GPS signal
⑤
Battery﹥90%
Battery﹥75%
Battery﹥50%
Battery﹥25%
Battery﹤5%
⑨
Time
Temperature
Other
⑧
Km per hour
Miles per hour
Unit system
Battery level
⑩
MPH
KMH
①
②
③
④
Speed
Cadence
Heart rate
Power
Electronic shifting
Sensor connection
Note: Blinking icons indicate
it's searching, constant light
indicates connected
Above AVS
Equal to AVS
Below AVS
Speed indicator
⑪
* AVS: Average speed
Recording
Pause
Recording status
⑥
4
• At data page(figure 1) you can long press the
side button + to switch backlight mode.
ICON DESCRIPTION
Data page(figure 1) Pop-up menu(figure 2)
Map page(figure 3) Standby page(figure 4)
12:00
Page layout
DIS
TIME. ACT
HRM
KMH
CAD
DIS
TIME. ACT
HRM
KMH
CAD
DIS
TIME. ACT
HRM
KMH
CAD
⑧
⑨
⑩
⑪
⑫
⑫
⑦
⑥
④
⑤
③
②
①
Sync
Menu
Start
⑦
7
INSTALL THE MOUNT
1 Put the rubber pad inside the clamp ring;
2 Clamp it on the handlebar of your bike;
3 Use the 2.5mm hex wrench to tighten the screw;
4 Align the tabs on the back of the SPRINT with the bike
mount notches, then press down slightly and turn the
SPRINT clockwise(or anti-clockwise) until it locks into
place.
①
②
③
6
SPRINT use GPS（Global Position System）to measure
speed, calibrate time, record mileage and tracks etc.
After start recording, please make sure to be outdoors
and no shelter above. You should also avoid searching
GPS signal when near high voltage wires and signal
towers.
Track record
FUNCTION DESCRIPTION
Note: It usually takes 30-120 seconds to search GPS signal and
positioning when cold boot. It tooks less than 30 seconds when
warm boot. After successful positioning it will calibrate time
automatically.
SPRINT support all the speed sensor, cadence sensor,
heart rate monitor and power meter that use ANT+ or
Bluetooth 4.0.
Select Menu in the pop-up menu, then select Device
manage to bind and manage your sensor; After switch
bike on the computer, it will automatically select its list of
sensors, supporting up to three bicycles.
Sensor connection
Note: When using speed sensor,you need to set the correct
wheel diameter, in order to get the correct speed.
You can connect SPRINT to computer and get the
standard FIT files, when connected the following icon
will appear on the screen of SPRINT, the device name is
also SPRINT on the computer.
USB connection
USB connection icon
Note: You should end the recording before making a USB connection
8
Name: SPRINT smart GPS cycling computer
Size: 55mm x95mm x22mm
Weight: 70g
Operating temperature: -10℃～50℃
Battery life: 37+ hours
Battery type: Rechargeable lithium polymer batteries
Bluetooth support: heart rate ,speed,cadence ,power
ANT+ support: heart rate,speed,cadence,power
Language: Chinese and English
Waterproof rating: IPx6
PRODUCT SPECIFICATIONS
Thank you for purchasing our product,It has a one-year
free warranty from the date of purchase,contact your
original dealer for warranty service.
The following conditions are not covered by the
warranty
1.The normal aging loss of the battery
2.Damage and loss of products due to improper
installation
3.Damage caused by abnormal use,such as high
temperature、water damage etc.
4.Damage caused by unauthorized dismantling.
WARRANTY
Visit the website www.xoss.co
You can get installed video and more product information
SUPPORT
