Xoopar XP62002 User Manual

www.xoopar.com

PunchBox

Bluetooth Speaker

User Manual

WELCOME

Thank you for purchasing Xoopar PunchBox speaker and speakerphone.

This innovative product uses intelligent Bluetooth wireless technology matching with an exciting design. You can easily pair PunchBox with any Bluetooth digital devices to share music and movies. It is also a Speakerphone for your mobile. PunchBox is designed for home and oce use. It delivers you amazing sound quality. Built-in rechargeable battery provides you up to 15 hours play time ! It is a great companion to your smartphones and tablets. Enjoy your PunchBox and having fun, NON-STOP !

OVERVIEW

Can connect PunchBox wirelessly with any Bluetooth device

Spin

Press

LaptopsTabletsPhones Music Players

Micro-USB charging cable

3.5mm stereo cable

3.5mm Stereo

OVERVIEW CHARGE CONNECT LISTEN SPEAKER PHONE SPECIFICATIONS TROUBLE SHOOTING SAFETY INFORMATION

High quality monomer

2000 mAh battery

Bass diaphragm

Via PC

Via A/C Adapter

1. Please connect it with your wall charger or computer via Micro USB cable.

2. It takes about 4 hours to fully charge.

3. PunchBox supports 15-hour play time.

4. Battery Status indicated by LED light.

Charging

Full

LED light Micro USB

CONTENTS

OVERVIEW

Power ON/OFFAUX-IN

CHARGE

Micro USB

01-03

04 05 06 07 08 09 10

1. For Bluetooth Pairing, follow one-time setting processes below:

- Turn on Bluetooth function of your device.

- Switch on your PunchBox.

- Press and Hold the Volume button for 3 seconds until you hear "it is ready to pair" .

- Go to Bluetooth setting of your device and Select "Xoopar PunchBox" .

- Enter "0000" if a passcode is requested (normally not required). * To Pair another devices, repeat the above processes.

2. Pairing is required for the rst time use only.

3. If your device does not support Bluetooth, you can play wired audio by connecting PunchBox via 3.5mm stereo input.

4. 3.5mm stereo cable is included in package.

Make sure your Bluetooth device is within 10M eective range of Bluetooth connection

Power ON/OFF

Press

Press to answer End a call

Hands-free Speaker Phone

TROUBLE SHOOTING

Make sure you have turned on Bluetooth of your device

Turn o other device that has paired and connected with PunchBox

It might be too loud, slightly lower the volume on your PunchBox

CONNECT

SPEAKER PHONE

1. Speaker phone only works on Bluetooth connection.

2. To pick up and end a call, simply press the volume button.

Check if battery is empty and recharge it

Hearing Distortion

Check for low battery and recharge it

Volume Button

Cannot Connect

LISTEN

1. To get the best sound, make sure Punch Box is resting on a at base.

2. If the song is too loud creating hearing distortion, it is recommend to lower the volume.

3. Bluetooth connection range is up to 10 meters, make sure your device is within this eective range from your PunchBox.

4. For Bluetooth, incoming and outgoing calls will always take connection priority over audio playback.

SPECIFICATIONS

Bluetooth Version：

Language (voice instructions)：

Respond frequency：

Accessories included：

Bluetooth Range：

V3.0 + EDR Class 2 Up to 10m (33ft) A2DP/HST/HFP/AVRCP

Protocol：

English/ Mandarin/ French/ German/ Spanish

2.5W x 2

Output power：

40Hz ~ 20KHz 85db

Resolution：

90db

SNR：

Yes

Microphone：

Li-ion 2000mAh, Rechargeable

Battery type：

Up to15-hour play time

Battery life：

DC 5V +/- 5% 500mAh

Power input：

500mAh

Input current：

Bluetooth/3.5mm Stereo/Micro USB

Interface：

3.5mm cable, Micro USB cable

SAFETY INFORMATION

1. Do not expose the speaker to water, liquid, or humidity. Electric shock could be resulted.

2. Keep the speaker in a ventilate place and away from any heat source to prevent a risk of re.

3. Do not attempt to disassemble the speaker and replace the built-in rechargeable battery by yourself. Electric shock could be resulted.

4. Always unplug the charger rst and clean the speaker with a dry cloth.

5. Do not place the speaker on high surface. Strong music may cause the speaker to move and fall o from the shelf.

Spin

FCC warning statements:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful interference

to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void

your authority to operate this equipment.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Patent Information

EU Design: 002148601-0001 PRC Design: 201230484688.70

HK Design: 1202080.4M001 Others Patent Pending

PATENTED PRODUCT

www.xoopar.com Made in China

All products are protected by Patent and Copyright. To protect our Intellectual Property (IP) ,

we would enforce the IP rights in court against infringers.
