COLOR TELEVISION
TK2716
CONTENTS
Safety instruction………………………………………………………………………1
General instruction……………………………… ……………………………………… .1
Alignment instruction……………………………………………………………………2
Alignment flow ..……………………………………………………………………..2
Alignment method…………………………………………………………………..3
BLOCK DIAGRAM………………………………………………………………………... 8
MAIN IC……………………………………………………………………………….. 9
Schematic diagram………………………………………………………………….60
APPENDIX:Exploded view
Parts list
Note: This service manual is only for professional service personnel’s reference. Before
servicing the unit, please read the following items carefully.
1 safety instruction
1.1 X-RAY radiation precaution
1.1.1 Excessive voltage will cause harmful X-ray. To avoid this radiation hazard, the high voltage should
fall within the limitation. The appliance works at AC 120V, 60Hz. The high voltage of zero beam current
should be within 29.0kV on condition that the main power (B+) voltage is AC135V. And it should not
exceed 30kV in any condition.
* Keep the main power voltage at 135V when checking the high voltage.
1.1.2 The primary source of X-RAY RADIATION is the CRT. The CRT of this TV set have gotten the
approval of safety authentication inspection. The replacement CRT should be exactly the same type and
specification CRT which has gotten a similar safety approval, and check the high voltage according to
the HIGH VOLTAGE CHECK procedure.
1.2 safety precaution
a. Since the power supply circuit of this receiver is directly connected to the AC power line, an isolation
transformer is necessary during dynamic service to avoid possible shock hazard.
b. Always discharge the graphite layer conductor when moving the CRT.
c. Disconnect the power cord before replacing parts.
d. When replacing high-power resistor, keep the resistor 10 mm away from the circuit board.
1.3 Component safety precaution
Many electrical and mechanical parts in the chassis have special safety-related characteristics. These
characteristics are often passed unnoticed by a visual inspection. Replacement parts which have these
special safety characteristics are identified in this manual and its supplement electrical components
having such features are shaded or marked by on the schematic diagram and the parts list. Before
replacing any of these components, read the parts list in this manual carefully. The use of substitute
replacement parts which do not have the same characteristic as specified in the parts list may create
shock, fire, X-RAY RADIATION or other hazards.
2.General instruction
2.1 Copy the standard model data to let EEPROM of the chassis have those data before placing it on the
unit, do “factory adjustment” if necessary. If use a blank EEPROM directly, you should preset IIC data
and then do other common adjustment. Refer to TABLE1 to preset EEPROM.
2.2 the adjustment should be done under following circumstances without additional instruction
a) Alternating current 120V/60Hz
b) Preheat at least 30 min
2.3The unit has auto degaussing circuit, the auto degaussing process can be finished within 1s when the
main power. only when turn on the unit at least 30min after last time turn off TV does the auto
degaussing circuit work.
2.4 If the CRT with magnetism affects color purity and convergence, when the auto degaussing
eraser. if the color purity and convergence are still not very good, then corresponding adjustment
should be done. Refer to picture tube adjustment method for adjustment.
3
Alignment instruction
1
3.1 Debugging item
N
a)adjust mode instruction
b)B+ voltage adjustment
c)RFAGC voltage adjustment
d)focus adjustment
e)Screen-grid voltage white balance, sub brightness adjustment
f)filed scan center, line , amplitude adjustment
g)H-scan center adjustment
3.2 Alignment flow
+B adjustment
ormal
temperature aging
Focus adjustment
AGC adjustment
White balance
adjustment
Picture adjustment
Fig-1 alignment flow
3.3 Enter/exit factory adjustment method
Use remote control, press “MENU” button, then press 6483,”M”will appear on screen to show that you
have entered the factory adjustment method, press “STANDBY” to exit it.
3.4 Select adjustment item and adjust data
After entering factory adjustment mode, press 1-4 number buttons to select menu1- menu4; To enter into
MENU0~MENU5, press “CHILD LOCK” button and then the number button (5~0) to enter into relative
menus. Press “P+” and “P-” to select and “V+” and “V-”to adjust.
4 Alignment method
4.1 B+ voltage adjustment
a) connect B+ point with a digital voltmeter to measure the negative pole of VD524
b) receive PHILIPS test pattern signal and set the picture to standard.
c) Adjust VR501 to let the value of B+ voltage be 135 V ±0.5 V (yongxin super pure flat)
4.2 AGC adjustment
a) receive VHF-H band,60 dB RF signal.
b) Select factory menu2 of “AGC”.
c) Press “V+”,”V-”to let voltage value of tuner pin AGC be 3.8 V ± 0.1 V(DC).(if the selected tuner
is changed, then the voltage of AGC should be measured again: receive VHF-H band and 60
dB RF signal, adjust AGC-TOP to let the picture just without noisy, then the voltage of tuner
AGC is the required value for adjustment.)
d) exit factory menu
4.3 Normal temperature aging
a) do not receive signals.
2
b) under ”M” condition, set the accelerator to an appropriate point for aging.
4.4 Accelerator adjustment
a) do not receive signals;
b) select “SC” of factory menu3 to let the field scanning stop working.
c) adjust acceleration potentiometer to let bright lines just appears on screen.
d) exit SC menu.
4.5 High voltage check
Note: the main power voltage (B+=135 V)can affect the high voltage directly, so be sure to let the B+
power voltage accurate. Under any state, the high voltage should not exceed 30 kV.
a) connect an accurate high voltage meter between the second anode cap of picture tube and
ground.
b) turn on TV and receive testing card signal.
c) set picture to standard, the high voltage should be 27 kV± 1 kV.
d) the high voltage should not exceed 30KV with minimum brightness and contrast.
4.6 Focus adjustment
a) receive PHILIPS signal
b) adjust focus electrode potentiometer on FBT to optimize B area focus of screen.
4.7 White balance adjustment (color temperature 12000°K± 8MPCD,X=0.270± 0.008,Y=0.283± 0.008)
a) receive full white signal
b) select factory menu3
c) on the basis of blue, adjustment RD,GD of M3, let to white balance coincide with standard.
4.8 Filed scanning adjustment (fig-2)
a) receive PAL of PHILIPS test pattern signal.
b) select factory menu1
c) adjust V-SLOPE menu to let the horizontal center line of test pattern above blanking.
d) select V-SHIFT menu and adjust to let the vertical center of picture coincide with
vertical center of picture tube.
e) Select V-SIZE menu and adjust to let the vertical reproduction ratio of picture acceptable.
f) Adjust V.SC to optimise the vertical S correction of picture.
g) Receive NTSC PHILIPS test pattern and readjust the above items.
4.9 Horizontal scanning adjustment (Fig-3)
a) Receive PAL PHILIPS signal
b) Select factory menu1
c) Select H.SHIFT menu and adjust to let the scanning horizontal center coincide with mechanical
center of picture tube
d) Exit M3 menu
e) Adjust VR433 to let horizontal reproduction ration of picture acceptable
f) Adjust VR432 to minimize left-right edge pincushion distortion of picture
Horizontal line
Under part banking
Fig-2 field scan adjustment
3
g) Adjust VR431 to minimize trapezoidal distortion
h) Exit factory menu
a
4.10 Sub-brightness adjustment
a) Receive PAL-D/K PHILIPS signal
b) Select “SB” of factory menu3
c) Adjust “SB” to let things between the sixth and seventh grey scale clear
4.11 OSD adjustment
a) Receive PAL-D/K PHILIPS signal
b) Select OSD H and OSD V of factory menu4. Adjust OSD H and OSD V to let OSD at a specified
place.
c) Exit factory menu
4.12 Degaussing
a) The unit has and auto degaussing circuit, the degaussing circuit works several seconds after turning
on TV
b) If you want to move TV or change the direction, turn off TV and ten minutes later the degaussing
circuit will work
c) For better degaussing effect, you can use magnetic eraser
d) Move the magnetic eraser clockwise before your TV, when it is 2m away from your TV, turn off the
magnetic eraser. If the effect is still not very good, you can adjust “color purity” and “convergence”
4.13 Color purity correction
a) Turn on your TV
b) At least 15 minutes later, use anti-magnetized coil for degaussing
c) Obtain maximum brightness and contrast
d) Select factory menu3 and adjust to let R and B be zero, then let only green raster appear on the
screen at the moment
e) Loosen screws of deflection yoke frame to let vertical green belt appear on screen only
f) Move the rubber wedge
g) Rotate along neck of picture tube and slide color-purity magnets until the green belt at the middle of
screen and is vertical at the same time
h) Slowly move the deflection yoke backward of forward until the whole green raster appears on screen,
tighten the screws of the deflection yoke
i) Check the color purity of red raster and blue raster
j) Adjust white balance again to obtain white raster
4.14 Convergence correction
4.14.1 Central convergence correction
a) Turn on your TV
Fig-3 line scan adjustment
4
b) At least 15 minutes later, receive square test pattern signal
c) Adjust brightness and contrast to get the best picture
d) Adjust the angle of two tetrode magnetic rings to let the red vertical line coincide with the blue
vertical line at middle of screen
e) Keep the angle unchanged, move the two tetrode magnetic rings at the same time to let the red and
blue horizontal lines coincide at middle of screen
f) Adjust two hexode magnetic rings to let the green line coincide with the mixed line of red and blue.
Adjust the angle between them will affect the vertical line, move them together will affect the
horizontal line.
g) Repeat d), e), f) and observe the movement of red, green and blue.
4.14.2 Ambient convergence correction
a) Turn on your TV
b) At least 15 minutes later, loosen the screws of the deflection yoke
c) Fixate the rubber wedge temporarily under the deflection yoke
d) Move the deflection yoke upward or downward to get best convergence, push the rubber wedge into
space between picture tube and deflection yoke to fixate the deflection yoke temporarily
e) Place the rubber wedge whose overlay paper has been removed at the bottom space
f) Move the deflection yoke left and right to get best convergence
g) Keep the condition unchanged, place another rubber wedge whose overlay paper has been
removed also at the upper space at the same time
h) Remove the interim rubber wedge, adhere it to picture tube and deflection yoke
i) After placing three rubber wedges, check all the convergence again
j) Stick three transparent viscous belts to the rubber wedge
Chart 1 I
2
I
C standard UOC for export bus control adjustment item default setting
2
C TDA (NOM)8377-B-6NA E
2
PROM pre-set data
MI Items Variable Preset
M0 SUBCON 56(sub-contrast)
SUBCOL 56(sub-chroma)
SUBSHP 48(sub-acutance)
SUBTINT 31(sub-hue)
M1 V.SLOPE 34(field center adjustment)
V.SHIFT 27(field point adjustment)
V.SIZE 36(field amplitude adjustment)
V.SC 32(field line )
HSHIFT 32(line point adjustment)
PROGRAMA.NO 2(channel)
M2 AGCTAKEOVER 24(AGC adjustment)
SHIPPING 0(leave factory set)
M3 BT 75(adjust white balance of brightness)
5
CT 75(adjust white balance of brightness contrast)
SC OFF
RB 32(red cut off level adjustment)
GB 32(green cut off level adjustment)
RD 32(red cut off level adjustment)
GD 32(green cut off level adjustment)
BD 32(blue cut off level adjustment)
SB 40(sub brightness adjustment)
M4 OSD.V.POSITION 10(OSD position)
OSD.H.POSITION 5(OSD H-position)
BTSC-MODE MONO(STEORO,SAP )
BTSC-ST 13
BTSC-SP 12
BTSC-L1 1
BTSC-A1 15
BTSC-A2 0
BTSC-TC 0
BTSC-STS
BTSC-ADJ
MI Items Variable Preset
M5 MODE STANADARD(standard, soft, floweriness)
BRIGHT 75
COLOR 50
SCBRIGHT 20
YDELAYTV 12
YDELAYAV 1 2
M6 OSO 1(field over-scan switch)
AGCSPEED 1(AGC of speed)
FFI 0(IF PLL SPEED)
FMWS 1(frequency range of sound OFF=225KHZ,ON=450KHZ)
RP0 0(pre-shock and over-shock scale)
NTSCMATRIX USA
VOLPIN 0(1:push-pull output; 0: OC gate output.)
SOFT CLIP 3(white level limit)
PEAK WHITE 15(peak white limit)
CORING 0(coring noise reduction)
M7 AV2 1
SVHS 1
YUV 1
CONTRAST
0
75
6
VOLADJPOING 1(volume value have:1,25,50,75)
VOLVALUE 20(volume curve value:20,60,75,90)
M8 CATHOOELEVEL 7(cathode level)
UOCVOLUME 0(0:PWM terminal control; 1:UOC sound amplitude control of
inside)
FMATT 45(UOC sound output of amplitude) BTSC : 38
COMBFILTRE 0(N comb filter)
HEADPHONE 0(earphone function selection)
VM OPTION 0(VM function selection)
FRANCE 1 French
SPANISH 1 Spaish
POTUGUES 1 Portuguese
M9 NOM8377-B-6NA
STARTON 2(turn on)
STARTTIME 8(turn on time)
IF OFFSET 32(IF compensate)
TUNER OPTION 0(BXATB011F---X/ BXATB108F---K) 1 (BXATB017F---K) 2(XXX)
7
Block diagram
rCb
L
DY
S
F
S
TUNER
POWER
UNIT
SAW
135V
24V
16V
8V
5V
3.3V
S
TRAP
24C08
video
bus
TDA8377
IF IN Y IN
RF AGC V IN
U IN
CVBSINT
CHROMA
IFVO OUT
CVBS/Y IN
SDA
SCL
AUDIO OUT IK
RGB OUT
V OUT H OUT
V IN
TDA8177
V OUT
H IN
H OUT
H OUT
video
200V
+15V
-15V
Y
C
CRT PCB
CREEN
OCU
audio
video
CRT
video
4052
audio
N801
video
audio
Y
C
BU4052
V1i
ARo
ALo
ARi2
ARi1
A
ALi1
AN7522
Vi1
OUT1-
OUT1+
Vi2
OUT2-
OUT2+
Vo
V2i
S-VHS
i2
8
MAIN IC 8377:
ICs functional description
UOC TDA8377
SYMBOL PIN DESCRIPTION
STAND BY output. 1 In STAND BY mode, high level (Power OFF).
For Power ON this pin will be reduced to low.
SCL 2 I2C-bus clock line
SDA 3 I2C-bus data line
TUNING 4 tuning Voltage (Vt) PWM output
P3.0/NTSC SW 5 Port 3.0 or NTSC output/SCART SW input, Forced NTSC selection,
Low-level output, otherwise High output.
KEY 6 Control keys input *3
9
VOL 7 Sound Volume control PWM output
MUTE 8 Sound mute output
VSSC/P 9 Digit ground for µ-controller core and periphery
BAND1 10 Tuner Band selection output
BAND2 11 Tuner Band selection output
VSSA 12 Analog ground of teletext decoder and digital ground of TV-processor
SECPLL 13 SECAM PLL decoupling
VP2 14 2nd supply voltage TV-processor(+8V)
DECDIG 15 decoupling digital supply of TV-processor
PH2LF 16 Phase-2 filter
PH1LF 17 Phase-1 filter
GND3 18 Ground 3 for TV-processor
DECBG 19 Band gap decoupling
AVL/EWD 20 Automatic volume leveling /EAST-WEST drive output
VDRB 21 Vertical drive B output
VDRA 22 Vertical drive A output
IFIN1 23 IF input 1
IFIN2 24 IF input 2
IREF 25 Reference current input
VSC 26 Vertical sawtooth capacitor
TUNER AGC 27 Tuner AGC output
AUDEEM/SIFIN1 *1 28 Audio deemphasis or SIF input
DECSDEM/SIFIN2 29 decoupling sound demodulator or SIF input 2
GND2 30 ground 2 for TV processor
SNDPLL/SIFAGC *1 31 narrow band PLL filter or AGC sound IF
AVL/SNDIF/REF0/
AMOUT *1
HOUT 33 horizontal output
FBISO 34 flyback input/sandcastle output
AUDEXT/QSSO/
AMOUT *1
EHTO 36 EHT/overvoltage protection input
PLL IF 37 IF-PLL loop filter
IFVO/SVO 38 IF video output / selected CVBS output
VP1 39 supply voltage TV processor
CVBS INT 40 internal CVBS input
GND1 41 ground for TV processor
CVBS/Y 42 CVBS/Y input
CHROMA 43 C input
AUDOUT/AMOUT
*1
INSSW2 45 2nd RGB / YUV insertion input
32 Automatic Volume Levelling / sound IF input / subcarrier reference output
/ audio
deemphasis
35 external audio output / QSS intercarrier out
44 audio output /AM audio output (volume controlled)
10
R2/VIN 46 2nd R input / V (R-Y) input / PR input
G2/YIN 47 2nd G input / Y input
B2/UIN 48 2nd B input / U (B-Y) input / PB input
BCLIN 49 beam current limiter input
BLKIN 50 black current input / V-guard input
RO 51 Red output
GO 52 Green output
BO 53 Blue output
VDDA 54 analog supply of Closed Caption decoder and digital supply of
TV-processor (3.3 V)
VPE 55 OTP Programming Voltage
VDDC 56 digital supply to core (3.3 V)
OSCGND 57 oscillator ground supply
XTALIN 58 crystal oscillator input
XTALOUT 59 crystal oscillator output
RESET 60 reset
VDDP 61 digital supply to periphery (+3.3 V)
P1.0/INT1 62 TV/AV (AV1) / AV2 /S-VHS mode Output.
P1.1/T0 63 TV/AV (AV1) / AV2 /S-VHS mode Output.
P1.2/INT0 64 Remote control signal input.
AN7522 Function : audio output
Symbol PIN Function Symbol PIN Function
Vcc 1 Power supply GND 7 ground
Out 1 (+) 2 Ch 1 output (+) In 2 8 Ch 2 input
GND(out 1) 3 Ch 1Ground VOL 9 Volume Control
Out 1 (-) 4 Ch 1 output (-) Out 2 (-) 10 Ch 2 output (-)
Standby 5 Mute input GND(out 2) 11 Ch 2 Ground
In 1 6 Ch 1 input Out 2 (+) 12 Ch 2 output (+)
TDA8177 Function : vertical output
Symbol PIN Function Symbol PIN Function
INV IN 1 Input V OUT 5 Vertical output
VCC1 2 Power VCC2 6 Output power supply
PUMP UP 3 Pump up power NON INV IN 7 Negative feedback
GND 4 Ground
11
Test point Waveforms
2.6Vpp
H
TDA8377
95Vpp
H
1Vpp
TDA8377
V
H H
1.2Vpp
H
TDA8377
95Vpp
H H
CRT KG CRT KR
0.8Vpp
V
TDA8377
300Vpp 22Vpp
T511 PIN7
3.8Vpp
H
TDA8377
95Vpp
CRT KB
TDA8377
2.5Vpp
H H
TDA8377
0.9Vpp
H
TDA8377
2.7Vpp
H
V451 B
2.5Vpp
TDA8377 PIN51
5Vpp
H
TDA8377 PIN34
1000Vpp
H
V451 C
IC voltages
TDA8377
PIN 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
V 2.8 3.8 3.6 3.3 3.5 3.5 0.1 0.1 0 5.4 0.1 0 2.3 8 5 3
PIN 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
V 4 0 4 0.9 0.7 0.8 1.9 1.9 3.9 3.8 1.6 3.2 3.4 0 2.4 0.1
PIN 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
V 0.6 0.5 3.7 1.7 2.4 3.1 8 3.8 0 3.4 1.5 3.6 2.3 2.6 2.6 2.6
PIN 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64
V 2.3 7.2 2.7 2.7 2.7 3.5 0 3.5 0.1 1.7 1.8 0 3.5 0.1 0.1 5
TDA8177
PIN 1 2 3 4 5 6 7
V 0.7 15 -12 -15 0.3 15.9 -0.07
AN 7522
PIN 1 2 3 4 5 6 7 8 9 10 11 12
V 12 7 0 7 3.3 1.4 0 1.4 0 7 0 7
12
SCHEMATIC DIAGRAM
CAUTION:all the parts in the schematic diagram marked with shodows and the signs of
are extremely
important for safety. In case of replacement of any part of components. Be sure to consult the service manual
carefully.
1. the schematic diagram is characteristic. The various valus in the electric circuits are basic data, which are
changeable according to the various basic circuits.
2. testing waves are abtained by inputing the standard color bar of the signed.
3. resistance unit is in Ohm, namely: K=1000; M=1000K; Capacitance unit is in µF; P=µµF(µ=10
6
)
4. Unless othervise noted inside, all resistors are 1/6W, the withstand voltage of all capacitor are 50V.
5. Inductance unit is in µH.
6. The mark
in the diagram means Ferrite ring
7. The symbols of various types of resistors and capacitors are listed as follows:
Carbon film resistor
Metal film resistor
M
Potentiometer resistor
1/2w resistor
1w resistor
2w resistor
3w resistor
Ceramic capacitor
AC Ceramic capacitor
Terylene capacitor
Polypropylene capacitor
Metal Terylene capacitor
Aluminium electrolyse capacitor
Tantalum electrolyse capacitor
AC
1
2
3
T
24
15
16
17
18
19
20
21
22
23
14
13
12
11
10
9
8
24
25
7
26
6
5
27
4
28
29
3
30
31
2
1
32
PART LIST OF EXPLODED VIEW
No. DESCRIPTION PART NO.
1 SCREW 851-24016-14
2 SCREW 851-23012-14
3 REAR CABINET 780-10641-02A
4 BRAIDED WIRE 123-30001-04
5 LINE CLASP 742-30032-00
6 DEGAUSSING COIL
7 BRAIDED PULLING SPRING 838-10012-00
8 SCREW 851-24030-11
9 LINE CLASP 742-30038-00
10 REAR PANEL 808-10760-020
11 MAIN BOARD ASSY 667-TKE16-01B
12 FRONT CABINET 611-E16Y1J0H1B
13 BUTTON BOARD ASSY 667-TK2916-05B
14 BUTTON 877-50316-0H0B
15 SCREW 851-23008-31
16 FRONT NAMEPLATE 880-10633-A1
17 LED COLUMN 700-60099-00
18 POWER INDICATOR LIGHT 700-60100-00
19 POWER BUTTON
20 SPEAKER BRACKET 870-20664-00
21 SPEAKER 384-40908-B0
22 SCREW 855-85020-31
23 CRT BRACKET 870-20666-00
24 POWER SWITCH
25 SCREW 851-53012-11
26 SCREW 851-53016-11
27 CRT 335-2942Q-60
28 CRT FIXER 868-20337-00A
29 CUSHION 868-10089-00
30 NUT 893-10600-11
31 CRT BOARD
32 REAR NAMEPLATE 880-10205-799A
PART LIST
PART# DESCRIPTION LOCA.NO.
203-TK29160-12 TK2716, BRAND PRIMA,N-M,CUL SILVERY
100-TK29160-01 TK2916
123-30001-04 TWIST WIRE
615-10105-00 CRT FIXER ASS'Y
648-30001-00 COMPOSE NUTS SJ2843-87M6
700-60099-00 LED COLUMN
700-60100-00 LED COLUMN
742-30005-09 LINE TIE
742-30006-09 GRADING TIE
742-30032-00 TIE
742-30038-00 TIE
770-40151-40 IMITATEUL1672 22# 400mm BLACK
780-10641-02A BACK CABINET ( BLACK )
808-70239-00 EVA GLUE 150X50X1
838-10012-00 BRAIDED WIARE SPRING
851-23008-31 SCREW SJ2824 ST3X8FT-D.Zn
851-23012-11 SCREW SJ2824 ST3X12C-DZn
851-23012-14 SCREW SJ2824 ST3X12C-Y
851-24014-11 SCREW SJ2824 ST4X14C-D.Zn
851-24016-14 SCREW SJ2824 ST4X16C-Y
851-24016-14 SCREW SJ2824 ST4X16C-Y
851-24020-14 SCREW SJ2824 ST4X20C-Y
851-24030-11 SCREW SJ2824 ST4X30C-D.Zn
851-53008-31 SCREW SJ2825 ST3X8FT D.Zn
855-85020-31 COMPOSE SCREW ST5X20FT-D.Zn
857-10002-09 COTTON FLANNEL
857-10004-00 COTTON FLANNEL
857-10004-00 COTTON FLANNEL
862-20028-00 POWER CORD CLAMPE
863-80727-00 POLY FOAM (TOP ) ( SMALL )
863-80728-00 POLY FOAM (BOTTOM ) ( SMALL )
868-20007-00 SLEEVE
868-20175-00 SUPPORT CUSHION
868-20271-00 RUBBER WASHER
868-20271-00 RUBBER WASHER
868-20337-00A CRT FIXER
868-20548-00 CUSHION
868-20553-00 CABINET BOTTOM CUSHION
870-20666-00 CRT BRACKET
870-20913-00 RIGHT LEADING TRACK
881-60085 BLANK WARNING LABEL
887-20044-01 POWER CORD COVER
887-21114-P0 PE/PEARL COTTONPALSTIC BAG 1300X1250
887-21135-00 CLASPER PALSTIC BAG 230X330X0.1
893-10600-11 NUT GB6170-86-M6 D.Zn
335-2942Q-60 CRT NA MAGNETIC FIELD !
488-10007-00 BATTERY 5# ENGLISH
602-TK2426-01 SCHEMATIC DIAGRAM
604-TK27167-01 OWNER'S MANUAL(PRIMAMTS NEWCPU )
611-E16Y1J0H1B FRONT CABINET ASS'Y (HIPS V0 SILVER WHITE 03
742-30005-09 LINE TIE
880-10205-799A BACK PLATE (TK2716,PRIMA)
880-10633-A1 FRONT LOGO (PRIMA NEW SILVERY GREY 10C
881-61341-00 CUL LABEL
881-63016-00A POWER SYMBOL LABEL ( T2751)
881-63751-00 BAR CODE LABEL (69020712716)
881-80667-00 REGISTER CARD ( PRIMA )
881-80672-00 SERVICE CARD ( 27-32 CRT)
886-31115-22 CARTON BOX (TK2716,PRIMA)
887-20171-00 PALSTIC BAG 70-500-0.06
887-21135-00 CLASPER PALSTIC BAG 230X330X0.1
887-21135-02 CLASPER PALSTIC BAG 230X330X0.1
615-20385-00 SPEAKER ASS'Y
384-40908-B0 SPEAKER ST613-04
655-41201-322 (4-PINS) LEAD WITH HOUSING
851-53008-31 SCREW SJ2825 ST3X8FT D.Zn
868-20217-00 WASHER
870-20664-00 SPEAKER BRACKET
667-Q27351-05 Stand By KEY BOARD ASS'Y
360-10001-00 TACT SWITCH KFC-A06-4X4.5X5B S1
665-21201-16 ( 2-PINS ) LEAD WITH HOUSING X1
782-13Y90-050A BUTTON PCB
667-TKE16-01B MAIN PCB ASS'Y
364-34101-00 4-PINS CONNECTORS TJC3-04A XS701
467-8E522-H0U SOLID RESISTOR 1/2W-2.2MΩ-JL ! R501
475-25451-00 CERAMIC TRAP FILTER XT4.5MB Z351
491-752HD-02 POWER CORD UL !
535-TK2916-02W OUTSOURCING ASS'Y
569-18101-00U FUSE 51S 5A/125V !
364-32101-00 2-PINS CONNECTORS TJC3-02A XS702
364-36101-00 6-PINS CONNECTORS TJC3-06A XS895
459-2156K-00 CERAMIC CAPACITOR CT1-06-2B4-63V-561K C381
459-2310R-00 CERAMIC CAPACITOR CT1-08-2F4-63V-103Z C472
459-5239K-00 CERAMIC CAPACITOR RQC12B392K-H46CA C451
464-6D647-M0 ELECTROLYTIC CAPACITOR CD110-16V-47uF-M C804
464-6D747-M0 ELECTROLYTIC CAPACITOR CD110-16V-470uF-M C801
464-60510-M0 ELECTROLYTIC CAPACITOR CD110-50V-1uF-M C827
464-60510-M0 ELECTROLYTIC CAPACITOR CD110-50V-1uF-M C337
464-60522-M0 ELECTROLYTIC CAPACITOR CD110-50V-2.2uF-M C339
464-60547-M0 ELECTROLYTIC CAPACITOR CD110-50V-4.7uF-M C340
464-62610-M0 ELECTROLYTIC CAPACITOR CD288-160V-10uF-M C458
467-1DA82-H0 CARBON RESISTOR RT14-1/4W-8.2Ω-J R513
467-1E210-H0 CARBON RESISTOR 1/2W-1K-J R453
467-1E433-H0 CARBON RESISTOR 1/2W-330K-J R942
467-2D218-G0 METAL RESISTOR 1/4W-1.8K-G R403
467-2D218-G0 METAL RESISTOR 1/4W-1.8K-G R405
471-2001K-00 PEAKING COIL SPT0305-1R0K-5 L302
666-12301-00 FERRITE BEAD TY23X13.5X6
666-12301-00 FERRITE BEAD TY23X13.5X6
681-40003-00 OK LABEL
741-10001-02 WIRE FIXED BLADE
742-30005-09 LINE TIE
808-10760-020 BLACK PLATE ( MOLD BLACK )
808-60895-01 INTERFACE SPACE PLATE (SILK-SCREEN )
851-24012-11 SCREW SJ2824 ST4X12C-D.Zn
851-53012-11 SCREW SJ2825 ST3X12C-D.Zn
851-53012-11 SCREW SJ2825 ST3X12C-D.Zn
851-53012-14 SCREW SJ2825 ST3X12C-D.Zn
851-53016-11 SCREW SJ2825 ST3X16C-D.Zn
851-53016-11 SCREW SJ2825 ST3X16C-D.Zn
863-60172U000 MAIN BOARD FRAME (HIPS V0)
870-20357-00B WIRE FIXED HOLDER
870-30150U000 FBT BRACKET (HIPS V0)
881-60074-00 HIGH VOLTAGE WARNING LABEL
998 JUMPER WIRE W343
998 JUMPER WIRE W844A
998 JUMPER WIRE W861
998 JUMPER WIRE VD1561
742-30005-09 LINE TIE
808-60895-01 INTERFACE SPACE PLATE (SILK-SCREEN )
808-60895-02 INTERFACE SPACE PLATE (SILK-SCREEN )
851-53010-11 SCREW SJ2825 ST3X10C-D.Zn
887-20171-00 PALSTIC BAG 70-500-0.06
998 JUMPER WIRE N502
340-51240-003 ZENER DIODE HZ12A3 VD588
459-2182K-002 CERAMIC CAPACITOR RPU05B821K-H46CA C323
462-00268-H02 POLYESTER CAPACITOR CL11-100V-6800PF-J C154
462-00268-H02 POLYESTER CAPACITOR CL11-100V-6800PF-J C158
464-6D710-M02 ELECTROLYTIC CAPACITOR CD110-16V-100uF-M C536
467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J R301A
467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J R302A
467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J R723A
467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J R724A
467-1C210-H03 CARBON RESISTOR 1/6W-1K-J R380
467-1C233-H03 CARBON RESISTOR 1/6W-3.3K-J R702
340-00001-003 DIODE 1N4148 VD171
340-00001-003 DIODE 1N4148 VD431
340-00001-003 DIODE 1N4148 VD461
340-00001-003 DIODE 1N4148 VD462
340-00001-003 DIODE 1N4148 VD511
340-00001-003 DIODE 1N4148 VD544
340-00001-003 DIODE 1N4148 VD561
340-00001-003 DIODE 1N4148 VD562
340-00001-003 DIODE 1N4148 VD734
340-00001-003 DIODE 1N4148 VD911
340-00001-003 DIODE 1N4148 VD921
340-00001-003 DIODE 1N4148 VD931
340-00001-003 DIODE 1N4148 VD491
459-2210K-002 CERAMIC CAPACITOR CK45-B1H102KYR C308
459-2210K-002 CERAMIC CAPACITOR CK45-B1H102KYR C311
459-2210K-002 CERAMIC CAPACITOR CK45-B1H102KYR C401
459-2210K-002 CERAMIC CAPACITOR CK45-B1H102KYR C402
459-2210K-002 CERAMIC CAPACITOR CK45-B1H102KYR C721
459-2210K-002 CERAMIC CAPACITOR CK45-B1H102KYR C861
459-2222K-002 CERAMIC CAPACITOR CT1-08-2B4-63V-222K C335
459-2310R-002 CERAMIC CAPACITOR CK45-F1H103ZYR C162
459-2310R-002 CERAMIC CAPACITOR CK45-F1H103ZYR C302
459-2310R-002 CERAMIC CAPACITOR CK45-F1H103ZYR C309
459-2310R-002 CERAMIC CAPACITOR CK45-F1H103ZYR C313
459-2310R-002 CERAMIC CAPACITOR CK45-F1H103ZYR C332
459-2310R-002 CERAMIC CAPACITOR CK45-F1H103ZYR C362
459-2310R-002 CERAMIC CAPACITOR CK45-F1H103ZYR C475
459-2310R-002 CERAMIC CAPACITOR CK45-F1H103ZYR C535
459-2310R-002 CERAMIC CAPACITOR CK45-F1H103ZYR C703A
459-2310R-002 CERAMIC CAPACITOR CK45-F1H103ZYR C723
459-2310R-002 CERAMIC CAPACITOR CK45-F1H103ZYR C744
459-2310R-002 CERAMIC CAPACITOR CK45-F1H103ZYR C752
459-2310R-002 CERAMIC CAPACITOR CK45-F1H103ZYR C756
459-2310R-002 CERAMIC CAPACITOR CK45-F1H103ZYR C399
459-5122K-002 CERAMIC CAPACITOR RQC05B221K-6H46UA C405
459-5210K-002 CERAMIC CAPACITOR CK45-B2H102KYR C452
462-00333-K02 POLYESTER CAPACITOR CL11-100V-0.033uF-K C403
462-00333-K02 POLYESTER CAPACITOR CL11-100V-0.033uF-K C510
462-00333-K02 POLYESTER CAPACITOR CL11-100V-0.033uF-K C544
462-00347-K02 POLYESTER CAPACITOR CL11-100V-0.047uF-K C427
462-00410-K02 POLYESTER CAPACITOR CL11-100V-0.1uF-K C460
464-6C710-M02 ELECTROLYTIC CAPACITOR CD110-10V-100uF-M C548
464-6D610-M02 ELECTROLYTIC CAPACITOR CD110-16V-10uF-M C163A
464-6D610-M02 ELECTROLYTIC CAPACITOR CD110-16V-10uF-M C172
464-6D610-M02 ELECTROLYTIC CAPACITOR CD110-16V-10uF-M C301
464-6D610-M02 ELECTROLYTIC CAPACITOR CD110-16V-10uF-M C307
464-6D610-M02 ELECTROLYTIC CAPACITOR CD110-16V-10uF-M C322
464-6D610-M02 ELECTROLYTIC CAPACITOR CD110-16V-10uF-M C363
464-6D610-M02 ELECTROLYTIC CAPACITOR CD110-16V-10uF-M C364
464-6D610-M02 ELECTROLYTIC CAPACITOR CD110-16V-10uF-M C367
464-6D610-M02 ELECTROLYTIC CAPACITOR CD110-16V-10uF-M C751
464-6D610-M02 ELECTROLYTIC CAPACITOR CD110-16V-10uF-M C807
464-6D610-M02 ELECTROLYTIC CAPACITOR CD110-16V-10uF-M C871
464-6D622-M02 ELECTROLYTIC CAPACITOR CD110-16V-22uF-M C745
464-6D647-M02 ELECTROLYTIC CAPACITOR CD110-16V-47uF-M C116
464-6D647-M02 ELECTROLYTIC CAPACITOR CD110-16V-47uF-M C171
464-6D647-M02 ELECTROLYTIC CAPACITOR CD110-16V-47uF-M C333
464-6D647-M02 ELECTROLYTIC CAPACITOR CD110-16V-47uF-M C352
464-6D647-M02 ELECTROLYTIC CAPACITOR CD110-16V-47uF-M C561
464-6D647-M02 ELECTROLYTIC CAPACITOR CD110-16V-47uF-M C723A
464-6D647-M02 ELECTROLYTIC CAPACITOR CD110-16V-47uF-M C811
464-6D647-M02 ELECTROLYTIC CAPACITOR CD110-16V-47uF-M C823
464-6D647-M02 ELECTROLYTIC CAPACITOR CD110-16V-47uF-M C121
464-6D647-M02 ELECTROLYTIC CAPACITOR CD110-16V-47uF-M C123
464-6D647-M02 ELECTROLYTIC CAPACITOR CD110-16V-47uF-M C806
464-6D710-M02 ELECTROLYTIC CAPACITOR CD110-16V-100uF-M C361
464-6D710-M02 ELECTROLYTIC CAPACITOR CD110-16V-100uF-M C743
464-6D747-M02 ELECTROLYTIC CAPACITOR CD110-16V-470uF-M C525
464-6D747-M02 ELECTROLYTIC CAPACITOR CD110-16V-470uF-M C532
464-60447-M02 ELECTROLYTIC CAPACITOR CD110-50V-0.47uF-M C372
464-60447-M02 ELECTROLYTIC CAPACITOR CD110-50V-0.47uF-M C374
464-60510-M02 ELECTROLYTIC CAPACITOR CD110-50V-1uF-M C153
464-60510-M02 ELECTROLYTIC CAPACITOR CD110-50V-1uF-M C157
464-60510-M02 ELECTROLYTIC CAPACITOR CD110-50V-1uF-M C163
464-60510-M02 ELECTROLYTIC CAPACITOR CD110-50V-1uF-M C813
464-60510-M02 ELECTROLYTIC CAPACITOR CD110-50V-1uF-M C815
464-60510-M02 ELECTROLYTIC CAPACITOR CD110-50V-1uF-M C825
464-60510-M02 ELECTROLYTIC CAPACITOR CD110-50V-1uF-M C862
464-60510-M02 ELECTROLYTIC CAPACITOR CD110-50V-1uF-M C841
464-60522-M02 ELECTROLYTIC CAPACITOR CD110-50V-2.2uF-M C755
464-60547-M02 ELECTROLYTIC CAPACITOR CD110-50V-4.7uF-M C325
464-60547-M02 ELECTROLYTIC CAPACITOR CD110-50V-4.7uF-M C464
464-60547-M02 ELECTROLYTIC CAPACITOR CD110-50V-4.7uF-M C481
464-60622-M02 ELECTROLYTIC CAPACITOR CD110-50V-22uF-M C703
464-60647-M02 ELECTROLYTIC CAPACITOR CD110-50V-47uF-M C462
464-60647-M02 ELECTROLYTIC CAPACITOR CD110-50V-47uF-M C517
467-1C010-H03 CARBON RESISTOR 1/6W-10Ω-J R312
467-1C010-H03 CARBON RESISTOR 1/6W-10Ω-J R871
467-1C022-H03 CARBON RESISTOR 1/6W-22Ω-J R914
467-1C022-H03 CARBON RESISTOR 1/6W-22Ω-J R924
467-1C022-H03 CARBON RESISTOR 1/6W-22Ω-J R934
467-1C033-H03 CARBON RESISTOR 1/6W-33Ω-J R806
467-1C047-H03 CARBON RESISTOR 1/6W-47Ω-J R368
467-1C047-H03 CARBON RESISTOR 1/6W-47Ω-J R708
467-1C047-H03 CARBON RESISTOR 1/6W-47Ω-J R911
467-1C047-H03 CARBON RESISTOR 1/6W-47Ω-J R921
467-1C047-H03 CARBON RESISTOR 1/6W-47Ω-J R931
467-1C056-H03 CARBON RESISTOR 1/6W-56Ω-J R355
467-1C068-H03 CARBON RESISTOR 1/6W-68Ω-J R304
467-1C068-H03 CARBON RESISTOR 1/6W-68Ω-J R801
467-1C082-H03 CARBON RESISTOR 1/6W-82Ω-J R313
467-1C082-H03 CARBON RESISTOR 1/6W-82Ω-J R815
467-1C082-H03 CARBON RESISTOR 1/6W-82Ω-J R824
467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J R363
467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J R365
467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J R381
467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J R382
467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J R383
467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J R401
467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J R402
467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J R452
467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J R463
467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J R723
467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J R724
467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J R743
467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J R861
467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J R862
467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J R366
467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J R354
467-1C115-H03 CARBON RESISTOR 1/6W-150Ω-J R815A
467-1C115-H03 CARBON RESISTOR 1/6W-150Ω-J R848
467-1C115-H03 CARBON RESISTOR 1/6W-150Ω-J R852
467-1C118-H03 CARBON RESISTOR 1/6W-180Ω-J R353
467-1C118-H03 CARBON RESISTOR 1/6W-180Ω-J R805
467-1C122-H03 CARBON RESISTOR 1/6W-220Ω-J R311
467-1C122-H03 CARBON RESISTOR 1/6W-220Ω-J R442
467-1C122-H03 CARBON RESISTOR 1/6W-220Ω-J R917
467-1C122-H03 CARBON RESISTOR 1/6W-220Ω-J R927
467-1C122-H03 CARBON RESISTOR 1/6W-220Ω-J R937
467-1C130-H03 CARBON RESISTOR 1/6W-300Ω-J R913
467-1C130-H03 CARBON RESISTOR 1/6W-300Ω-J R923
467-1C130-H03 CARBON RESISTOR 1/6W-300Ω-J R933
467-1C133-H03 CARBON RESISTOR 1/6W-330Ω-J R916
467-1C133-H03 CARBON RESISTOR 1/6W-330Ω-J R926
467-1C133-H03 CARBON RESISTOR 1/6W-330Ω-J R936
467-1C139-H03 CARBON RESISTOR 1/6W-390Ω-J R322
467-1C147-H03 CARBON RESISTOR 1/6W-470Ω-J R308
467-1C168-H03 CARBON RESISTOR 1/6W-680Ω-J R316
467-1C210-H03 CARBON RESISTOR 1/6W-1K-J R351
467-1C210-H03 CARBON RESISTOR 1/6W-1K-J R481
467-1C210-H03 CARBON RESISTOR 1/6W-1K-J R128
467-1C210-H03 CARBON RESISTOR 1/6W-1K-J R129
467-1C210-H03 CARBON RESISTOR 1/6W-1K-J R369
467-1C210-H03 CARBON RESISTOR 1/6W-1K-J R460
467-1C210-H03 CARBON RESISTOR 1/6W-1K-J R464
467-1C210-H03 CARBON RESISTOR 1/6W-1K-J R531
467-1C210-H03 CARBON RESISTOR 1/6W-1K-J R541
467-1C210-H03 CARBON RESISTOR 1/6W-1K-J R544
467-1C210-H03 CARBON RESISTOR 1/6W-1K-J R734
467-1C210-H03 CARBON RESISTOR 1/6W-1K-J R802
467-1C210-H03 CARBON RESISTOR 1/6W-1K-J R803
467-1C210-H03 CARBON RESISTOR 1/6W-1K-J R816
467-1C210-H03 CARBON RESISTOR 1/6W-1K-J R818
467-1C210-H03 CARBON RESISTOR 1/6W-1K-J R825
467-1C210-H03 CARBON RESISTOR 1/6W-1K-J R827
467-1C212-H03 CARBON RESISTOR 1/6W-1.2K-J R305
467-1C212-H03 CARBON RESISTOR 1/6W-1.2K-J R560
467-1C215-H03 CARBON RESISTOR 1/6W-1.5K-J R732
467-1C222-H03 CARBON RESISTOR 1/6W-2.2K-J R371
467-1C222-H03 CARBON RESISTOR 1/6W-2.2K-J R451
467-1C222-H03 CARBON RESISTOR 1/6W-2.2K-J R540
467-1C224-H03 CARBON RESISTOR 1/6W-2.4K-J R515
467-1C233-H03 CARBON RESISTOR 1/6W-3.3K-J R721
467-1C233-H03 CARBON RESISTOR 1/6W-3.3K-J R722
467-1C233-H03 CARBON RESISTOR 1/6W-3.3K-J R728
467-1C233-H03 CARBON RESISTOR 1/6W-3.3K-J R735
467-1C233-H03 CARBON RESISTOR 1/6W-3.3K-J R736
467-1C233-H03 CARBON RESISTOR 1/6W-3.3K-J R737
467-1C233-H03 CARBON RESISTOR 1/6W-3.3K-J R741
467-1C233-H03 CARBON RESISTOR 1/6W-3.3K-J R742
467-1C239-H03 CARBON RESISTOR 1/6W-3.9K-J R321
467-1C247-H03 CARBON RESISTOR 1/6W-4.7K-J R131
467-1C247-H03 CARBON RESISTOR 1/6W-4.7K-J R133
467-1C247-H03 CARBON RESISTOR 1/6W-4.7K-J R154
467-1C247-H03 CARBON RESISTOR 1/6W-4.7K-J R158
467-1C247-H03 CARBON RESISTOR 1/6W-4.7K-J R306
467-1C247-H03 CARBON RESISTOR 1/6W-4.7K-J R462
467-1C247-H03 CARBON RESISTOR 1/6W-4.7K-J R733
467-1C256-H03 CARBON RESISTOR 1/6W-5.6K-J R370
467-1C268-H03 CARBON RESISTOR 1/6W-6.8K-J R426
467-1C282-H03 CARBON RESISTOR 1/6W-8.2K-J R153A
467-1C282-H03 CARBON RESISTOR 1/6W-8.2K-J R157A
467-1C282-H03 CARBON RESISTOR 1/6W-8.2K-J R562
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R126
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R127
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R163
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R427
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R461
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R543
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R548
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R551
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R704
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R709
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R816A
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R818A
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R825A
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R827A
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R851A
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R852A
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R912
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R922
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R932
467-1C312-H03 CARBON RESISTOR 1/6W-12K-J R425
467-1C315-H03 CARBON RESISTOR 1/6W-15K-J R331
467-1C315-H03 CARBON RESISTOR 1/6W-15K-J R491
467-1C315-H03 CARBON RESISTOR 1/6W-15K-J R453A
467-1C318-H03 CARBON RESISTOR 1/6W-18K-J R804
467-1C322-H03 CARBON RESISTOR 1/6W-22K-J R162
467-1C322-H03 CARBON RESISTOR 1/6W-22K-J R384
467-1C322-H03 CARBON RESISTOR 1/6W-22K-J R422
467-1C322-H03 CARBON RESISTOR 1/6W-22K-J R455
467-1C322-H03 CARBON RESISTOR 1/6W-22K-J R482
467-1C327-H03 CARBON RESISTOR 1/6W-27K-J R484
467-1C327-H03 CARBON RESISTOR 1/6W-27K-J R487
467-1C333-H03 CARBON RESISTOR 1/6W-33K-J R171
467-1C333-H03 CARBON RESISTOR 1/6W-33K-J R175
467-1C333-H03 CARBON RESISTOR 1/6W-33K-J R317
467-1C333-H03 CARBON RESISTOR 1/6W-33K-J R385
467-1C333-H03 CARBON RESISTOR 1/6W-33K-J R431
467-1C333-H03 CARBON RESISTOR 1/6W-33K-J R434
467-1C347-H03 CARBON RESISTOR 1/6W-47K-J R172
467-1C347-H03 CARBON RESISTOR 1/6W-47K-J R732A
467-1C347-H03 CARBON RESISTOR 1/6W-47K-J R745
467-1C347-H03 CARBON RESISTOR 1/6W-47K-J R807
467-1C356-H03 CARBON RESISTOR 1/6W-56K-J R424
467-1C368-H03 CARBON RESISTOR 1/6W-68K-J R173
467-1C410-H03 CARBON RESISTOR 1/6W-100K-J R429
467-1C410-H03 CARBON RESISTOR 1/6W-100K-J R483
467-1C410-H03 CARBON RESISTOR 1/6W-100K-J R802A
467-1C410-H03 CARBON RESISTOR 1/6W-100K-J R803A
467-1C415-H03 CARBON RESISTOR 1/6W-150K-J R318
467-1C422-H03 CARBON RESISTOR 1/6W-220K-J R429A
467-1C427-H03 CARBON RESISTOR 1/6W-270K-J R174
467-1C456-H03 CARBON RESISTOR 1/6W-560K-J R465
467-1DA27-H03 CARBON RESISTOR RT14-1/4W-2.7Ω-J R468
467-1D001-H03 CARBON RESISTOR RT14-1/4W-1Ω-J R404
467-1D027-H03 CARBON RESISTOR RT14-1/4W-27Ω-J R561
467-1D110-H03 CARBON RESISTOR RT14-1/4W-100Ω-J R486
467-1D222-H03 CARBON RESISTOR RT14-1/4W-2.2K-J R161
467-1D227-H03 CARBON RESISTOR RT14-1/4W-2.7K-J R512
467-1D310-H03 CARBON RESISTOR RT14-1/4W-10K-J R485
467-1D351-H03 CARBON RESISTOR RT14-1/4M-51K-J R539
467-1D351-H03 CARBON RESISTOR RT14-1/4M-51K-J R539A
471-2010K-003 PEAKING COIL SPT0305-100K-5 L331
471-2010K-003 PEAKING COIL SPT0305-100K-5 L361
471-2010K-003 PEAKING COIL SPT0305-100K-5 L751
471-2010K-003 PEAKING COIL SPT0305-100K-5 L752
471-2010K-003 PEAKING COIL SPT0305-100K-5 L753
895-6016030-50 RIVET GB876-86 1.6X3 COPPER L501
895-6016030-50 RIVET GB876-86 1.6X3 COPPER PS501
895-6016030-50 RIVET GB876-86 1.6X3 COPPER T501
895-6016030-50 RIVET GB876-86 1.6X3 COPPER T451
895-6016030-50 RIVET GB876-86 1.6X3 COPPER L452
895-6016030-50 RIVET GB876-86 1.6X3 COPPER C467
895-6025030-50 RIVET GB876-86-2.5X3 COPPER C507
895-6025030-50 RIVET GB876-86-2.5X3 COPPER VD451
895-6025030-50 RIVET GB876-86-2.5X3 COPPER VD452
895-6025030-50 RIVET GB876-86-2.5X3 COPPER V451
895-6025030-50 RIVET GB876-86-2.5X3 COPPER V432
998 JUMPER WIRE W930
998 JUMPER WIRE W011
998 JUMPER WIRE W391
998 JUMPER WIRE W486
998 JUMPER WIRE W791
998 JUMPER WIRE W901
998 JUMPER WIRE W852
998 JUMPER WIRE W851A
998 JUMPER WIRE W582
998 JUMPER WIRE W684
998 JUMPER WIRE W021
998 JUMPER WIRE W051
998 JUMPER WIRE W131
998 JUMPER WIRE W168
998 JUMPER WIRE W311
998 JUMPER WIRE W356
998 JUMPER WIRE W368
998 JUMPER WIRE W373
998 JUMPER WIRE W381
998 JUMPER WIRE W385
998 JUMPER WIRE W442
998 JUMPER WIRE W443
998 JUMPER WIRE W466
998 JUMPER WIRE W467
998 JUMPER WIRE W471
998 JUMPER WIRE W493
998 JUMPER WIRE W531
998 JUMPER WIRE W532
998 JUMPER WIRE W554
998 JUMPER WIRE W555
998 JUMPER WIRE W562
998 JUMPER WIRE W563
998 JUMPER WIRE W564
998 JUMPER WIRE W581
998 JUMPER WIRE W652
998 JUMPER WIRE W721
998 JUMPER WIRE W763
998 JUMPER WIRE W764
998 JUMPER WIRE W771
998 JUMPER WIRE W773
998 JUMPER WIRE W774
998 JUMPER WIRE W841
998 JUMPER WIRE W862
998 JUMPER WIRE W863
998 JUMPER WIRE W881
998 JUMPER WIRE W843
998 JUMPER WIRE W844
998 JUMPER WIRE W231
998 JUMPER WIRE W243
998 JUMPER WIRE W358
998 JUMPER WIRE W762
998 JUMPER WIRE W875
998 JUMPER WIRE W876
998 JUMPER WIRE W401
998 JUMPER WIRE W786
998 JUMPER WIRE W675
998 JUMPER WIRE W242
998 JUMPER WIRE W552
998 JUMPER WIRE W553
998 JUMPER WIRE W662
998 JUMPER WIRE W663
998 JUMPER WIRE W244
998 JUMPER WIRE W245
998 JUMPER WIRE W148
998 JUMPER WIRE W152
998 JUMPER WIRE W154
998 JUMPER WIRE W166
998 JUMPER WIRE W171
998 JUMPER WIRE W241
998 JUMPER WIRE W263
998 JUMPER WIRE W421
998 JUMPER WIRE W435
998 JUMPER WIRE W472
998 JUMPER WIRE W342
998 JUMPER WIRE W484
998 JUMPER WIRE W485
998 JUMPER WIRE W643
998 JUMPER WIRE W653
998 JUMPER WIRE W655
998 JUMPER WIRE W741
998 JUMPER WIRE W921
998 JUMPER WIRE W922
998 JUMPER WIRE W650
998 JUMPER WIRE W900
998 JUMPER WIRE W341
998 JUMPER WIRE W752
998 JUMPER WIRE W420
998 JUMPER WIRE W651
998 JUMPER WIRE W411A
998 JUMPER WIRE W153
998 JUMPER WIRE W251
998 JUMPER WIRE W159
998 JUMPER WIRE W571
998 JUMPER WIRE W432
998 JUMPER WIRE W454
998 JUMPER WIRE W551
998 JUMPER WIRE W665
998 JUMPER WIRE W621
998 JUMPER WIRE W674
998 JUMPER WIRE W681
998 JUMPER WIRE W682
998 JUMPER WIRE W673
998 JUMPER WIRE W731
998 JUMPER WIRE W873
998 JUMPER WIRE W872
998 JUMPER WIRE W142
998 JUMPER WIRE W253
998 JUMPER WIRE W162
998 JUMPER WIRE W355
998 JUMPER WIRE W451
998 JUMPER WIRE W331
998 JUMPER WIRE W163
998 JUMPER WIRE W164
998 JUMPER WIRE W369
998 JUMPER WIRE W412
998 JUMPER WIRE W434
998 JUMPER WIRE W452
998 JUMPER WIRE W453
998 JUMPER WIRE W463
998 JUMPER WIRE W464
998 JUMPER WIRE W465
998 JUMPER WIRE W641
998 JUMPER WIRE W642
998 JUMPER WIRE W644
998 JUMPER WIRE W656
998 JUMPER WIRE W672
998 JUMPER WIRE W840
998 JUMPER WIRE R520
998 JUMPER WIRE W221
998 JUMPER WIRE W362
998 JUMPER WIRE W363
998 JUMPER WIRE W364
998 JUMPER WIRE W365
998 JUMPER WIRE W366
998 JUMPER WIRE W367
998 JUMPER WIRE W461
998 JUMPER WIRE W462
998 JUMPER WIRE W671
998 JUMPER WIRE W761
998 JUMPER WIRE W156
998 JUMPER WIRE W561
998 JUMPER WIRE W661
998 JUMPER WIRE W664
998 JUMPER WIRE W494
998 JUMPER WIRE L401
998 JUMPER WIRE W903
998 JUMPER WIRE W904
895-6016030-50 RIVET GB876-86 1.6X3 COPPER L502
998 JUMPER WIRE W371
998 JUMPER WIRE W261
998 JUMPER WIRE W262
998 JUMPER WIRE W252
998 JUMPER WIRE W441
998 JUMPER WIRE W271
998 JUMPER WIRE W272
998 JUMPER WIRE W122A
998 JUMPER WIRE W882
998 JUMPER WIRE W883
998 JUMPER WIRE W884
998 JUMPER WIRE R737A
667-TK2916-05B KEY BOARD ASS'Y
340-10039-20 LED HFR205 (RED ) VD901
352-03810-50 IC AT138A (M) RC901
360-10001-00 TACT SWITCH KFC-A06-4X4.5X5B S901
360-10001-00 TACT SWITCH KFC-A06-4X4.5X5B S902
360-10001-00 TACT SWITCH KFC-A06-4X4.5X5B S903
360-10001-00 TACT SWITCH KFC-A06-4X4.5X5B S904
360-10001-00 TACT SWITCH KFC-A06-4X4.5X5B S905
360-10001-00 TACT SWITCH KFC-A06-4X4.5X5B S906
467-1C139-H0 CARBON RESISTOR 1/6W-390Ω-J R906
467-1C215-H0 CARBON RESISTOR 1/6W-1.5K-J J902
467-1C218-H0 CARBON RESISTOR 1/6W-1.8K-J R901
467-1C230-H0 CARBON RESISTOR 1/6W-3K-J R902
467-1C230-H0 CARBON RESISTOR 1/6W-3K-J R903
467-1C262-H0 CARBON RESISTOR 1/6W-6.2K-J R904
467-1C318-H0 CARBON RESISTOR 1/6W-18K-J R905
655-41201-181 (4-PINS) LEAD WITH HOUSING X901
782-Q2716-0500 BUTTON PCB
870-20374-00 IR RECEIVER HOLDER
877-50316-0H0B KEY ( SILVERY WHITE 03)
998 JUMPER WIRE J903
998 JUMPER WIRE R908
998 JUMPER WIRE J901
667-TK2916-29 SIDE AV BOARD ASS'Y
364-93202-00 AV JACK AV306-2 XAA5
655-6E301-23 (6-PINS) LEAD WITH HOUSING XAA3
782-Q2735-2900 SIDE AV PCB
851-53012-11 SCREW SJ2825 ST3X12C-D.Zn
868-10089-00 CUSHION
870-20707-023 SIDE AV BRACKET ( MOLD BLACK SILK-SCREEN )
998 JUMPER WIRE JAA1
998 JUMPER WIRE LAA2
998 JUMPER WIRE LAA1
667-TK2950-17 RELAY BOARD ASS'Y
340-00001-00 DIODE 1N4148 VD2003
464-6F710-M0 ELECTROLYTIC CAPACITOR CD110-35V-100uF-M C2002
467-1C247-H0 CARBON RESISTOR 1/6W-4.7K-J R2002
467-1C310-H0 CARBON RESISTOR 1/6W-10K-J R2001
667-TK2953-31 MTS BOARD ASS'Y
462-00322-K02 POLYESTER CAPACITOR CL11-100V-0.022uF-K C05
462-00333-K02 POLYESTER CAPACITOR CL11-100V-0.033uF-K C07
462-00410-K02 POLYESTER CAPACITOR CL11-100V-0.1uF-K C04
462-00410-K02 POLYESTER CAPACITOR CL11-100V-0.1uF-K C06
462-00410-K02 POLYESTER CAPACITOR CL11-100V-0.1uF-K C09
462-00422-K0 POLYESTER CAPACITOR CL11-100V-0.22uF-K C10
464-6D610-M0 ELECTROLYTIC CAPACITOR CD110-16V-10uF-M C01
464-6D710-M0 ELECTROLYTIC CAPACITOR CD110-16V-100uF-M C15
464-60433-M0 ELECTROLYTIC CAPACITOR CD110-50V-0.33uF-M C02
464-60433-M0 ELECTROLYTIC CAPACITOR CD110-50V-0.33uF-M C08
464-60510-M0 ELECTROLYTIC CAPACITOR CD110-50V-1uF-M C16
464-60510-M0 ELECTROLYTIC CAPACITOR CD110-50V-1uF-M C17
464-60510-M0 ELECTROLYTIC CAPACITOR CD110-50V-1uF-M C18
464-60510-M0 ELECTROLYTIC CAPACITOR CD110-50V-1uF-M C19
464-60522-M0 ELECTROLYTIC CAPACITOR CD110-50V-2.2uF-M C11
464-60522-M0 ELECTROLYTIC CAPACITOR CD110-50V-2.2uF-M C12
464-60522-M0 ELECTROLYTIC CAPACITOR CD110-50V-2.2uF-M C13
464-60522-M0 ELECTROLYTIC CAPACITOR CD110-50V-2.2uF-M C14
464-60533-M0 ELECTROLYTIC CAPACITOR CD110-50V-3.3uF-M C03
467-1C115-H0 CARBON RESISTOR 1/6W-150Ω-J R07
467-1C115-H0 CARBON RESISTOR 1/6W-150Ω-J R11
467-1C147-H0 CARBON RESISTOR 1/6W-470Ω-J R06
467-1C147-H0 CARBON RESISTOR 1/6W-470Ω-J R10
467-1C233-H0 CARBON RESISTOR 1/6W-3.3K-J R02
467-1C247-H0 CARBON RESISTOR 1/6W-4.7K-J R05
467-1C247-H0 CARBON RESISTOR 1/6W-4.7K-J R09
467-1C310-H0 CARBON RESISTOR 1/6W-10K-J R04
467-1C310-H0 CARBON RESISTOR 1/6W-10K-J R08
467-1C327-H0 CARBON RESISTOR 1/6W-27K-J R03
467-1C418-H0 CARBON RESISTOR 1/6W-180K-J R01
998 JUMPER WIRE W01
998 JUMPER WIRE W02
Loading...
