Xoceco TK1337D, TS1337 Schematic

COLOR TELEVISION

TK1337D

(TS1337)

CONTENTS

Safety Precautions………………………………………………………………………..……

Alignment instruction. ………………………………….…………………………….…….

Debugging instruction …………………………………………….………………………….

IC Block diagram ……………………………..…..…..…..…..…..…….………….………….

Function introduction to pin……………………..……………………….…………………..

Wiring diagram……………………………………………………………………………..…

Exploded view………..…..…..…..…..…..…..…..…..…..…..…..…..…..…..…..…..…..…...

Part list ………………………………………………………..……………............................

Schematic diagram …………………………………………………………………….……..

1

2

3

9

10

15

16

18

34

AUTION: THIS SERVICE MANUAL IS ONLY FOR PROFESSIONAL SERVICE PERSONNEL’S

REFERENCE. BEFORE SERVICING THIS CHASSIS, PLEASE READ THE

FOLLOWING NOTICE ITEMS.

1. SAFETY I NSTRUCTION AND GENERAL INSTRUCTION
Before servicing and aligning this equipment, please read the following “X-RAY RADIATION
PRECAUTION” ,”SAFETY PRECAUTION” and “PRODUCT SAFETY NOTICE”.

1.1 X-RAY RADIATION PRECAUTION

1） Excessive high voltage can produce potentially hazardous X-RAY RADIATION. To avoid such

hazards, the high voltage must not be above the specified limit. The normal value of the high voltage

of this receiver is under 24.5kV(21”) and 22.5KV(14”) at zero beam current (minimum brightness),

the high voltage must not, under any circumstances, exceed 30kV.

2） Each time a receiver requires servicing, the high voltage should be checked following the HIGH

VOLTAGE CHECK procedure in this manual. It is recommended the reading of the high voltage be

recorded as a part of service record. It is important to use an accurate and reliable high voltage

meter.

3） The primary source of X-RAY RADIATION in this TV receiver is the picture tube. For continuous

X-RAY RADIATION protection, the replacement tube must be exactly the same type tube as

specified in the parts list.

4） Some parts in this receiver have special safety-related characteristics for X-RAY RADIATION

protection. For continuous safety, parts replacement should be undertaken only after referring to the

PRODUCT SAFETY NOTICE below.

1.2 SAFETY PRECAUTION WARNING:

Service should not be attempted by anyone unfamiliar with the necessary precaution on this receiver.

The following are the necessary precautions to be observed before servicing this chassis.

1) Since the power supply circuit of this receiver is directly connected to the AC power line, an isolation

transformer should be used during any dynamic service to avoid possible shock hazard.

2) Always discharge the picture tube anode to the CRT conductive coating before handling the picture

tube. The picture tube is highly evacuated and if broken, glass fragments will be violently expelled.

Use shatter proof goggles and keep picture tube away from the unprotected body while handling.

3) When replacing a chassis in the cabinet, always be certain that all the protective devices are put

back in place, such as: non-metallic control knobs, insulating covers, shields, isolation

resistor-capacitor network etc.

4) When replacing parts or circuit boards, disconnect the power cord.

5) When replacing a high wattage resistor (oxiode metal film resistor) on the circuit board, keep the

resistor 10mm (1/2in) away from circuit board.

6) Connection wires must be kept away from components with high voltage or high temperature.

7) If any fuse in this TV receiver is blown, replace it with the FUSE specified in the chassis parts list.

1

1.3 PRODUCT SAFETY NOTICE

Many electrical and mechanical parts in the chassis have special safety-related characteristics. These

characteristics are often passed unnoticed by a visual inspection and the X-RAY RADIATION protection

afforded by them cannot necessarily be obtained by using replacement components rated for higher

wattage, etc. Replacement parts which have these special safety characteristics are identified in this

manual and its supplement electrical components having such features are shaded on the schematic

diagram and the parts list.
Before replacing any of these components, read the parts list in this manual carefully. The use of

substitute replacement parts which do not have the same characteristics as specified in the parts list

may create shock, fire, X-RAY RADIATION or other hazards.

2 Alignment items and procedur e

The alignment flow chart (see below figure).

EEPROM copy

B+ check

Focus adjust and aging

High-handed

Field breadth

and field line

White balance and sub-bright

RF AGC adjust

Audio check

VG2 adjust

H-field and center

field and field breadth

Filament voltage

X-radial protect

Picture and audio

Sub-brightness

White balance

OSD center position

Color pure and assemble

Foucs fine adjust

AV (S.DVD)

The button check

Leave factory state setup

Remote control check

check

Assemble check

Safety check

2

3 TEST EQUIPMENT

3.1 AUDIO VOLTAMETER

3.2 OSCILLOGRAPH

3.3 HIGH-VOLTAMETER

3.4 DIGITAL MULTIMETER

3.5 AC ATTACK PULL TEST EQUIPMENT

3.6 SCAN frequency signal generator BT-3

4 Debugging instruction

4.1 enter into the factory debugging m enu

use to the remote control(RC-A23),follow to the blow model enter into the factory:

DISPLAY → MUTE → MUTE → MUTE → enter into the factory

press “sleep” button for pages upward, press “return” button for pages downward, press “CH+/-” to

select alignment items and “VOL+/-” to adjust volume, press “MUTE” to exit.

If the remote sensor designed for alignment is unavailable, press the following buttons to enter by

using user remote sensor

4.2 B+ voltage adj ustment

Check B+ voltage ( negative pole of VD509) by using DC voltmeter DC 200V

14”110 V±1 V CRT 21”PF 100 V CRT A15QDX992X002(H)

21”110 V±1 V CRT 54SX503Y22-CD01 A51LVV898X12

4.3 AGC adjustment

Measure the voltage of RF AGC by connecting digital DC voltmeter with TP1, receive weak signal

(40dBu) and the static AGC voltage of TP1 AGC should be V1=4V±0.2V; the receive medium signal

(60dBu), adjust the value of PAGE8 RF. AGC of factory menu and the start-control voltage of TP1 AGC

should be V2=3.5V±0.2.if V2>3.5V, then the voltage is -1 or -2,if V2<3.5V, then the voltage is+1 or+2.

after adjustment the picture should not appear no-sync , distortion and moire.

White balance and screen-grid voltage VG2 adjustment

After enter PAGE3 of factory menu, use remote sensor directly to adjust white balance by pressing the

following digital buttons:

“1”=R.BIAS(+) “2”=G.BIAS(+) “3”=B.BIAS(+)

“4”=R.BIAS(-) “5”=G.BIAS(-) “6”=B.BIAS(-)

press “pp” button to select picture mode→T1→T2→bright→soft→nature→user→ the current picture

mode will be display on the screen.

The T1 mode has the maximum value of brightness and contrast with all the other items min. Value of all

the analog are minimum while in T2 mode.

Before adjustment you should set the following items :SUB-BRIGHT=50, R.B=100, G.B=100,

B.B=100, R.D=100, G.D=15, B.D=100

Adjustment method: 1. press PP button to select T2 picture mode, press CH+/- to select V.K, press vol+

to let the field scanning fail to oscillate, adjust the screen-grid potentiometer on FBT clockwise to let

horizontal bright line just appear on the screen; let the value of G.B unchanged, adjust R-BIAS and

B-BIAS to let the horizontal bright line appear white. If the green horizontal line don’t appear firstly,

fine-turn the screen-grid voltage, the adjust R.B and B.B until red , green and blue just appear. After

adjustment press VOL- to obtain normal field scanning mode.

4.4 Receive grey-scale signal (D8), enter PAGE4 of factory menu, press PP to select T2 picture mode,

3

adjustment SUB-BRIGHT to let picture on the screen microbright.

4.5 receive white balance adjustment signal

enter PAGE3 of factory menu, press PP to select T1 picture mode, let the value of GD unchange, adjust

RD and B.D to let the white part of the picture appear “white”.

4.6 Use white balancer to rectify the white balance under following conditions

colour temperature:12000K+8MPCD

x =0.270± 0.008 Y=0.283±0.008 dark space : 4.5nit, bright space: 60nit

Note:1. Check the white balance of bright field and dark field by receiving monochrome signal or

adjusting the degree of saturation to minimum under maintenance condition, adjust RGB BIAS in dark

field and RGB DRIVE in bright area, adjust bright/dark balance repeatedly until the bright and dark

field have no colour drift.

2. While the colour saturation changed from maximum to minimum, if the dark balance appears

changeable, adjust RY.DC.LVL and BY.DC.LVL (page3) to let it coincide with white balance.

3. If the dark balance appears changeable while connected with DVD, adjust YUV.BY.DC and

YUV.RY.DC (PAGE4) to let it conincide with white balance.

4.7 High voltage and filament voltage check

Connect a high-voltage meter between anode cap of picture tube and the ground, measure the filament

voltage using rms voltmeter, set the picture mode to “standard”, the high-voltage: 24.5KV±1KV of 21”,

22.5KV±1KV of 14”,filament voltage: 6.3±0.1Vrms.

4.8 x -ray protection check

Receive local TV signal, set the picture mode to “standard”, shorten the circuit and measure the

value of TP1-TP2, restart the TV 30 seconds after turn off the power source and it should return to

normal.

4.9 AV function check

according to the owner’s manual require, connect to the AV equipment and the AV interface:

VIDEO IN: 1 Vp-p 75OHM AUDIO IN: (-8±3)dBm>47 kOHM

S interface Y IN: 1 Vp-p 75OHM C IN: 0.3 Vp-p 75OHM

DVD Y IN: 1 Vp-p 75OHM Cr IN: 0.7 Vp-p 75OHM

Cb IN: 0.7 Vp-p 75OHM

4.10 AV parts check

incept to standard the TV signal:

a） AV and crossfire and allophone and shake ;
b） The user control function ana picture model
c） The remote control function check;
d） Color pure and converge check.

4.11 leave factory state setup

Picture model (PP) STENDARD

language All the country language

Color system AUTO

C.CAPTION C1

CCD ON MUTE OFF

RECEPTION AIR

AFT ON

4

MTS AUTO

PASSWORD CLEAR

volume 30

4.12 the factory menu adjustment model pre-set

OSD item Pre-set model

P1-60

V SIZE 60HZ field amplitude 50 4.5.1

V SHIFT 60HZ field center 0 4.5.1

H-PHASE 60HZ H-center 9 4.5.1

V LINE 60HZ V-line 15 4.5.1

V SC 60HZ field S-correct 10 4.5.1

V COMP field amplitude compensate 7 fixed

L.BLK Left blanking 3 fixed

R.BLK Right blanking 3 fixed

P3-50

V SIZE 50HZ field amplitude 50 4.5.2

V SHIFT 50HZ field center 0 4.5.2

H-PHASE 50HZ H-center 6 4.5.2

V LINE 50HZ V-line 13 4.5.2

V SC 50HZ field S-correct 10 4.5.2

P5

LINE Level bright line 0 0=normal 1= Level bright line

RB Red cut off 100 4.4
GB Green cut off 100 4.4
BB Blue cut off 100 4.4
RD Red driver 100 4.4
GD Green driver 15 4.4
BD Blue driver 100 4.4

P6

RF AGC RF AGC 30 4.3

SUB-BRI Sub-brightness 127 4.4

SUB-CNT Sub-contrast 31 fixed

SUB-COL Sub-colour 15 fixed

SUB-SHP Sub-definition 15 fixed

SUB-TINT Sub-tint 28 fixed

P7

VOL.FIL Volume control ADC filter 0 fixed

OSD.COT OSD contrast 2 fixed

OSD.HPOS OSD center 6 fixed

AFT

VIF SW IF3=45.75MHZ 3 fixed

Line AFC loop gain and sync

gate switch

1

fixed

5

SIF SW Sound IF0=4.5MHZ 0 fixed

VIDEO LEVEL VIDEO LEVEL 3 fixed

P8

GY ANGLE G-Y demodulation angle 0 fixed

V.R TM Filed scan strting time 0 fixed

R/B ANG R-Y/B-Y demodulation angle 8 Fixed

R/B BAL R-Y/B-Ydemodulation balance 8 fixed

C TRAP Color trap filter 6 fixed

H FREQ H-frequency 16 fixed

C.BPF TEST

Color band filter center

frequency

0 fixed

P9

OVER.MOD.SW

OVER.MOD.LVL

BLK.STR

Selection over-modulation

function

Adjustment over-modulation

working point

Dark level expand starting

control point

0 Fixed,0=nothing 1=have

0 fixed

0 Fixed,0=40IRE 2=60IRE 3-OFF

BLK.GAIN Dark level expand gain 0 Fixed,0=MIN 2=MAX

Y.APF Selection color trap filter 0 0=trap filter,1= direct pass(YcbCr&Y/C)

PRE.ADJ Pre-shoot 3 fixed, 0=narrow 3=width

OVER ADJ overshoot 3 Fixed,a 0=narrow 3=width

C.VCO.ADJ

Color VCO frequency

adjustment

4

fixed,0－4－7=-120KHZ-0-90KHZ

P10

BRT.ABL.DEF Brightness ABL 0 fixed,0=ABL ON 1=ABL OFF

MID.STP.DEF ABL start control point 0 fixed

BRT.ABL.THR ABL threshold 7 fixed

WPL.OPE White peak limit 2 fixed

V BLK.SW Field blanking switch 0 fixed ,0=nomarl;1=width model

FBP BLK SW Horizontal blanking switch 1

fixed,0=inside produce;1=FBP and

inside logic “and”

DC REST DC recover rate 1 fixed,0=100% 1=107%

CD.MODE Field frequency division model 0 fixed,0=auto

P11

CORE GAIN Noise reduction 2 fixed,0=OFF 1=MIN 3=MAX

γ.GAMA

RGB TEMP.SW

RGB DC output

temperature speciality

A.MONI SW Selection pin5 output 1

SVO OR FSC Selection pin5 output 0

r-correct 0 fixed,0=OFF

1 fixed

fixed，1=SAO

fixed,0=VIDEO 1=FSC(color sub-carrier wave)

CROSS B/W Selection test signal 0 fixed,0=TV

6

CRAY.MODE Test signal 0 fixed,0=white(75%)1=grey(15%)

P12

BY TV Blue chromatism DC level 8

RY TV Red chromatism DC level 8

BY YUV

RY YUV

S.TRAP.TEST Sound trap filter adjustment 6 fixed

LOW.BRI Min-brightness 28 fixed

LOW.CONT Min-contrast 30 fixed

P13

COL.KILL Achromatic level 5 fixed,0=-30dB 3=-40dB

VCO.FREQ VCO frequency 32 fixed

P14

Y GAIN 0 fixed

Y TH 0 fixed

B OFFSET 0 fixed

B WIDTH 0 fixed

C OFFSET 0 fixed

C WIDTH 0 fixed

CAN.V CHIP V-CHIP 0/1 1=CAN.V-CHIP

OPTION

AV AV selec t i on 3 AV input select(3=AV1/AV2/S/DVD)

MTS MTS IC selection 1/0 0=nothing,1=72700 2=AN5832

V.OFF.MOTE Turn off model 1 0=discharge,1=close

PWR.MEM Turn on model 0/2 0=standby,1=auto turn on,2=memory

1115 select LV1115 0 fixed,0=nothing;1=have

BLCK GROND

N/PN

1115(the unit no use)

VOL.OFFSET

GAIN

PWM LOGIC

AVL M OD E

AVL DET LEVEL

AVL SLOPE

PWM SET

DVD input Blue chromatism

DC level

DVD input Red chromatism

DC level

No signal background

selection

South America and North

America selection

8

8

1

1/0 0=south america;1=north america

4.4 adjustment dark white balance (DVD

4.4 adjustment dark white balance(DVD

0=nothing 1/3=blue background;2=black

4.4 adjustment dark white

balance(TV/AV model)

4.4 adjustment dark white

balance(TV/AV model)

input)

input)

background

7

VOL 1 1% volume control speciality 30 fixed

VOL 25 25%volume control speciality 32 fixed

VOL 50 50%volume control speciality 68 fixed

VOL 75 75%volume control speciality 82 fixed

72700

ALC ALC 1 fixed ,1=ALC ON

VOL

SAP LEVEL SAP level 1 fixed

SIF.M/BB.M SIF and baseband model 0 fixed,0=SIF MODE 1=BB MODE

5832

AGC 1 fixed

Note:above “/” are the adjustment data for north america, below it are for south america.

Baseband model ,input level

adjustment

0 The unit no use

8

IC BLOCK DIA GRAM

LA76931

9

Function introduction to pin

pin function Reference

voltage

(V)

1 SIF output 2.28 64 PIF input1 2.86

2 PIF AGC 2.61 63 PIF input 2 2.86

3 SIF input 3.11 62 IF GND 0

4 FM filter 2.64 61 RF AGC output 4.55

5 FM filter/sound output 2.25 60 Video output 2.30

6 Sound output 2.24 59 AFT filter 2.50

7 SIF APC filter 2.24 58 APC filter 2.60

8 IF VCC(5V) 4.92 57 Black level detection

9 Expanded sound input 2.25 56 Internal video input and

10 ABL 3.21 55 Video, colour and

11 RGB VCC(8V/18Ma) 8.00 54 Expanded video input

12 R ouput 2.65 53 Colour APC filter 3.40

13 G ouput 2.65 52 Selection video output

14 B ouput 2.67 51 Cr input 2.50

15 AKB (undo) 2.31 50 4.43 MHZ crystal 2.73

16 Field sawtooth filter to

capacitance

17 Field output 2.34 48 Y(DVD) input

18 VCO Reference voltage 1.65 47 DDS filter 1.89

19 H/BUS VCC(5V/27mA) 6.81 46 Y(Y/C) input

20 H/APC filter 2.54 45 C(Y/C) input

21 H-output 0.28 44 Retrace impulse input 1.20

22 Video, colour and

deflexion ground

23

x -ray protection,

2.16 49 Cb input 2.50

0 43 CCD VCC 4.50

5.00 42 CPU GND 0

pin function Reference

voltage

(V)

2.50

filter

2.70

S-C input

4.90

deflexion power VCC

2.50

and Y input

2.40

and FSC output

low level availability

24 41 PLL 3.50

25 40 reset 4.00

26 IR control input 4.90 39 Button input 0.32

27 38 TV/AV H=TV L=AV 0

28 POWER H=OFF

0 37 AV1/AV2 5.00

L=ON

29 STAND-BY 5 36 MUTE high level 5.00

10

30 Mute, high

0 35 VDD 5.00

Level availability

31 I2C DATA 5.00 34 x T2 4.50

32 I2C CLOCK 5.00 33 x T1 2.70

KA5Q0565RT

Function introduction to pin

pin name function Reference

1 Drain drain output of MOSFET, current-limiting checking point of

internal drain current.

2 GND source of MOSFET,common ground and reference of circit

controlled by source.

3 Vcc Control cicuit power input, provide starting and stabling

Operating current.

4 Vfb Connect it with inverting input terminal of PWM comparator

,the collector of optical coupler can be connected to

it. To work stably , connect a capacitor between it and

the ground. If the voltage upon it reaches to 7.5V, the

overvoltage protection will work.

5 Sync Connect it with sync detector for quasi-resonance vonversion.

Normal quasi-resonance work, threshold voltage upon sync

comparator is 4.6V/2.6V. while expanding quasi-resonance

operating mode, the threshold voltage will change to

3.0V/1.8V.

Voltage(V)

283

0

23

1.35

5.65

11

AN7522

Pins function

pin function pin function

1
2
3
4
5
6

power

CH1+ output

GND

CH1- output

Stand-by

CH1 input

7
8

9
10
11
12

GND input

CH2 input

volume

CH1+ output

GND (CH2 output)

CH1+ output

LA78040

12

Pins function

pin function pin function

1 Inverting input 5 Ver. output

2 VCC 6 Output stage vcc

3 Pump up output 7 NON inverting input

4 GND

LA72700

pin function pin function

1 AC coupling input 19 dbx RMS detection

2 AC coupling output 20 Dbx main signal V/I charge filter

3 Stereo VCO PLL filter 21 Decoupling filter

4 Pilot level check 22 AC coupling output

5 Signal input 23 AC coupling input

6 GND 24 ALC filter

7 SAP carrier level check 25 R output

8 26 L output

9 SIF decoupling filter 27 Reference voltage(DC3.8V)

10 mute(5V) 28 AC coupling input

11 Serial data input(SDA) 29 AC coupling output

12 Serial clock input (SCL) 30 Voltage regulation filter

13 Decoupling filter 31 VCC(9V)

13

14 Stereo detection sensitivity 32 Model output: MONO=0.9V SAP=2.0V

STEREO=3.0V STEREO+SAP=3.8V

15 SAP detection sensitivity 33 Sub-carrier input(3.579545MHZ 200Mv)

16 dbx RMS detection 34 Filter adjustment check

17 Dbx broad band detection 35 Pilot dispel reference signal1

18 Dbx spectrum detection 36 Pilot dispel reference signal2

14

CRT

A

A

WIRING DIAGRAM

220V/50HZ

POWER SWITCH

XS602

AV P OR T

XS302

A2

S501

BOARDP667-TSC30-01

MAIN

XS301

XS502

XS202

XS701

A1

XS501

DEGASSINGP COIL

XS901

BOARDP667-TS2130-05

S PORT

XS604

N201

XS601

XS201

XS203

KEY

XS902

XS401

CRT PCB

TUNER

XS402

XS606

V BOARD

667-TS2130-29

M108

SPE

-

SCREEN

FOCUS

KER

+

-

+

15

16

24

23

22

21

20

19

18

17

11

15

14

13

12

10

5

6

9

8

7

1

4

3

2

TS1337

PART LIST OF EXPLODED VIEW

NO. DESCRIPTION PART#

1 BRAIDED LINE 123-30001-04
2 LINE CLASP 742-30030-00
3 DEGAUSSING COIL 477-11401-00
4 BRAIDED PULLING SPRING 838-10164-00
5 SPEAKER 384-40508-N1
6 SCREW 851-23008-31
7 SCREW 851-23012-14
8 SCREW 851-23008-31

9 SIDE AV BOARD ASSY 667-TS1337-29
10 SCREW 851-24020-14
11 REAR CABINET 780-B37RH-040
12 SCREW 851-25035-11
13 CRT 335-14216-00
14 CUSHION 868-10108-00
15 TAPER CUSHION 868-10172-00
16 MAIN BOARD ASSY 667-TSB37-01
17 BUTTON BOARD ASSY 667-TS1337-05
18 INDICATOR LIGHT LED COLUMN 700-60269-00
19 LED COLUMN 700-60270-00
20 BUTTON BOARD FRAME 870-30218-0T0
21 FRONT CABINET 780-B37R0-0H1
22 MAIN BOARD FIXED BLOCK 868-20796-00
23 STANDBY BUTTON 877-60697-0T0
24 FRONT NAMEPLATE 880-10752-A2

PART LIST

PART# DESCRIPTION LOCA.NO.

100-TS13370-10 TK1337D
100-TS13370-01 TS1337

123-30001-04 TWIST WIRE
335-14216-00 CRT A34KQW42X01 THIN !

384-40508-N1 SPEAKER ST47-02

477-11401-00 DEGAUSS COIL DGC-CJ-37cm !
488-10012-00 BATTERY 7#( made in china

491-702K0-02 POWER CORD UL !

604-TS13377-00 OWNER'S MANUAL(DIGISTAR, MTS)

655-2E301-01 (2-PINS) LEAD WITH HOUSING XS701

655-62101-01 (6-PINS) LEAD WITH HOUSING
700-60269-00 INDICATOR LIGHT LED COLUMN
700-60270-00 LED COLUMN
741-10001-02 WIRE FIXED BLADE
742-30005-09 LINE TIE
742-30006-09 GRADING TIE
742-30032-00 TIE

770-28112-40 RV105 12X0.15 280mm BLACK
780-B37R1J0H1
780-B37RHJ040 BACK CABINET (HIPS V0 MOLD GREY )

785-30002-09A RUBBER BAND
785-30002-09A RUBBER BAND

808-6A930-01 INTERFACE SPACE PLATE (SILK-SCREEN )

838-10164-00 BRAIDED WIARE SPRING

838-10332-00 SPRING

851-23008-31 SCREW SJ2824 ST3X8FT-D.Zn

851-23008-31 SCREW SJ2824 ST3X8FT-D.Zn

851-23008-31 SCREW SJ2824 ST3X8FT-D.Zn

851-23008-31 SCREW SJ2824 ST3X8FT-D.Zn

851-23010-31 SCREW SJ2824 ST3X10FT-D.Zn

851-23010-31 SCREW SJ2824 ST3X10FT-D.Zn

851-23010-31 SCREW SJ2824 ST3X10FT-D.Zn

851-23010-31 SCREW SJ2824 ST3X10FT-D.Zn

851-23012-14 SCREW SJ2824 ST3X12C-Y

851-24020-14 SCREW SJ2824 ST4X20C-Y

851-24020-14 SCREW SJ2824 ST4X20C-Y

851-25035-11 SCREW SJ2824 ST5X35C-D.Zn

851-25035-11 SCREW SJ2824 ST5X35C-D.Zn

851-53008-31 SCREW SJ2825 ST3X8FT D.Zn

857-10002-09 COTTON FLANNEL

862-20042-00 THREAD CLIP

863-81251-01 POLY FOAM (TOP )

863-81252-01 POLY FOAM (BOTTOM )

FRONT CABINET (HIPS V0 SILVERY WHITE 03SILK-SCREEN

868-10109-00 CUSHION

868-10109-00 CUSHION

868-10172-00 TAPER CUSHION CRT

868-10172-00 TAPER CUSHION

868-20007-00 SLEEVE

868-20796-00 MAIN BOARD FIXER

877-60679-0T0 STANDBY BUTTON (PLATE SILVERY WHITE )

880-10752-A2 FRONT LOGO (DIGISTAR GREY 10C14

881-60085 BLANK WARNING LABEL
881-61341-00 CUL LABEL
881-63329-00 LABEL (FPE2000,AUDIOVOX)
881-63840-00 POWER SYMBOL LABEL
881-63841-01 BACK PLATE LABEL (TK1337D,GIDISTAR)
881-80782-00 OPERATION CARD (TS1337,DIGISTAR)
881-80788-00 REGISTER CARD (DIGISTAR)
881-80789-00 EXTENDED CARD (DIGISTAR,13-20CRT)

886-31833-010W CARTON BOX WHITE TK1337D,DIGISTAR

887-20044-01 POWER CORD COVER
887-20171-00 PALSTIC BAG 70-500-0.06
887-21135-00 CLASPER PALSTIC BAG 230X330X0.1
887-21185-00 PALSTIC BAG (850X800)

667-TSB37-01A MAIN PCB ASS'Y

998 JUMPER WIRE J001
998 JUMPER WIRE J003
998 JUMPER WIRE J005
998 JUMPER WIRE J006
998 JUMPER WIRE J007
998 JUMPER WIRE J008
998 JUMPER WIRE J009
998 JUMPER WIRE J010
998 JUMPER WIRE J011
998 JUMPER WIRE J012
998 JUMPER WIRE J013
998 JUMPER WIRE J014
998 JUMPER WIRE J015
998 JUMPER WIRE J016
998 JUMPER WIRE J017
998 JUMPER WIRE J018
998 JUMPER WIRE J019
998 JUMPER WIRE J020
998 JUMPER WIRE J021
998 JUMPER WIRE J022
998 JUMPER WIRE J023
998 JUMPER WIRE J025

998 JUMPER WIRE J026
998 JUMPER WIRE J027
998 JUMPER WIRE J028
998 JUMPER WIRE J029
998 JUMPER WIRE J030
998 JUMPER WIRE J032
998 JUMPER WIRE J033
998 JUMPER WIRE J034
998 JUMPER WIRE J035
998 JUMPER WIRE J036
998 JUMPER WIRE J037
998 JUMPER WIRE J038
998 JUMPER WIRE J039
998 JUMPER WIRE J040
998 JUMPER WIRE J041
998 JUMPER WIRE J042
998 JUMPER WIRE J043
998 JUMPER WIRE J044
998 JUMPER WIRE J045
998 JUMPER WIRE J047
998 JUMPER WIRE J048
998 JUMPER WIRE J049
998 JUMPER WIRE J050
998 JUMPER WIRE J051
998 JUMPER WIRE J052
998 JUMPER WIRE J053
998 JUMPER WIRE J054
998 JUMPER WIRE J055
998 JUMPER WIRE J056
998 JUMPER WIRE J057
998 JUMPER WIRE J058
998 JUMPER WIRE J059
998 JUMPER WIRE J060
998 JUMPER WIRE J061
998 JUMPER WIRE J063
998 JUMPER WIRE J064
998 JUMPER WIRE J065
998 JUMPER WIRE J066
998 JUMPER WIRE J067
998 JUMPER WIRE J068
998 JUMPER WIRE J069
998 JUMPER WIRE J070
998 JUMPER WIRE J071
998 JUMPER WIRE J072
998 JUMPER WIRE J073

998 JUMPER WIRE J074
998 JUMPER WIRE J075
998 JUMPER WIRE J076
998 JUMPER WIRE J078
998 JUMPER WIRE J079
998 JUMPER WIRE J080
998 JUMPER WIRE J081
998 JUMPER WIRE J082
998 JUMPER WIRE J083
998 JUMPER WIRE J084
998 JUMPER WIRE J085
998 JUMPER WIRE J086
998 JUMPER WIRE J087
998 JUMPER WIRE J088
998 JUMPER WIRE J089
998 JUMPER WIRE J090
998 JUMPER WIRE J091
998 JUMPER WIRE J092
998 JUMPER WIRE J093
998 JUMPER WIRE J094
998 JUMPER WIRE J095
998 JUMPER WIRE J096
998 JUMPER WIRE J097
998 JUMPER WIRE J098
998 JUMPER WIRE J099
998 JUMPER WIRE J100
998 JUMPER WIRE J101
998 JUMPER WIRE J102
998 JUMPER WIRE J103
998 JUMPER WIRE J104
998 JUMPER WIRE J106
998 JUMPER WIRE J401
998 JUMPER WIRE R316
998 JUMPER WIRE R420
998 JUMPER WIRE R421
998 JUMPER WIRE R422

998 JUMPER WIRE R503
340-00001-003 DIODE 1N4148 VD401
340-00001-003 DIODE 1N4148 VD402
340-00001-003 DIODE 1N4148 VD403
340-00001-003 DIODE 1N4148 VD502
340-00001-003 DIODE 1N4148 VD506
340-00001-003 DIODE 1N4148 VD510
340-00001-003 DIODE 1N4148 VD512
340-00005-003 DIODE S5295J VD301

340-00010-003 DIODE S5295G VD313
340-00011-003 DIODE 1N4002 VD308
340-00079-003 DIODE FR103 VD304
340-00079-003 DIODE FR103 VD305
340-00079-003 DIODE FR103 VD306
340-50240-003 ZENER DIODE HZ2C2 VD514
340-50470-003 ZENER DIODE HZ5B1 VD503
340-50520-003 ZENER DIODE HZ5C3 VD201
340-50520-003 ZENER DIODE HZ5C3 VD309
340-50560-003 ZENER DIODE HZ6B1 VD202
340-50560-003 ZENER DIODE HZ6B1 VD203
340-50560-003 ZENER DIODE HZ6B1 VD204
340-50560-003 ZENER DIODE HZ6B1 VD513
340-50750-003 ZENER DIODE HZ7C2 VD307
340-51260-003 ZENER DIODE HZ12B1 VD515
343-10150-104 TRANSISTOR 2SA1015Y Pr2.5 V202
343-10150-104 TRANSISTOR 2SA1015Y Pr2.5 V501
343-18150-104 TRANSISTOR 2SC1815-Y V201
343-18150-104 TRANSISTOR 2SC1815-Y V303
343-18150-104 TRANSISTOR 2SC1815-Y V503
343-18150-104 TRANSISTOR 2SC1815-Y V504
343-18150-104 TRANSISTOR 2SC1815-Y V505
343-18150-104 TRANSISTOR 2SC1815-Y V507
343-23830-604 *TRANSISTOR 2SC2383-0 V301
343-27170-004 TRANSISTOR 2SC2717 V101

459-2015H-102 CERAMIC CAPACITOR CC45-CH1H150JYR C220
459-2015H-102 CERAMIC CAPACITOR CC45-CH1H150JYR C221
459-2020H-102 CERAMIC CAPACITOR CC45-CH1H200JYR C201
459-2022H-102 CERAMIC CAPACITOR CC45-CH1H220JYR C229
459-2047H-102 CERAMIC CAPACITOR CC45-CH1H470JYR C226
459-2110H-102 CERAMIC CAPACITOR CC45-CH1H101JYR C713
459-2110H-102 CERAMIC CAPACITOR CC45-CH1H101JYR C714
459-2120H-902 CERAMIC CAPACITOR RBU06SL201J-H46CA C252
459-2127H-902 CERAMIC CAPACITOR CC45-SL1H271JYR C404
459-2127H-902 CERAMIC CAPACITOR CC45-SL1H271JYR C405
459-2127H-902 CERAMIC CAPACITOR CC45-SL1H271JYR C406
459-2210K-002 CERAMIC CAPACITOR CK45-B1H102KYR C333
459-2215K-002 CERAMIC CAPACITOR CT1-06-2B4-63V-152K C208
459-2233K-002 CERAMIC CAPACITOR CT1-08-2B4-63V-332K C511

459-2310R-002 CERAMIC CAPACITOR CK45-F1H103ZYR C103
459-2310R-002 CERAMIC CAPACITOR CK45-F1H103ZYR C105
459-2310R-002 CERAMIC CAPACITOR CK45-F1H103ZYR C106
459-2310R-002 CERAMIC CAPACITOR CK45-F1H103ZYR C107
459-2310R-002 CERAMIC CAPACITOR CK45-F1H103ZYR C108
459-2310R-002 CERAMIC CAPACITOR CK45-F1H103ZYR C207

459-2310R-002 CERAMIC CAPACITOR CK45-F1H103ZYR C210
459-2310R-002 CERAMIC CAPACITOR CK45-F1H103ZYR C219
459-2310R-002 CERAMIC CAPACITOR CK45-F1H103ZYR C224
459-2310R-002 CERAMIC CAPACITOR CK45-F1H103ZYR C232
459-2310R-002 CERAMIC CAPACITOR CK45-F1H103ZYR C237
459-2310R-002 CERAMIC CAPACITOR CK45-F1H103ZYR C241
459-2310R-002 CERAMIC CAPACITOR CK45-F1H103ZYR C244
459-2310R-002 CERAMIC CAPACITOR CK45-F1H103ZYR C707
459-2322R-002 CERAMIC CAPACITOR CT1-10-2F4-63V-223Z C202
459-2322R-002 CERAMIC CAPACITOR CT1-10-2F4-63V-223Z C205
459-2347R-002 CERAMIC CAPACITOR CT1-14b-2E-63V-473Z C231
459-2410R-002 CERAMIC CAPACITOR DD308-63F104Z50 C228
459-2410R-002 CERAMIC CAPACITOR DD308-63F104Z50 C230
459-2410R-002 CERAMIC CAPACITOR DD308-63F104Z50 C240

459-5122K-002 CERAMIC CAPACITOR RQC05B221K-6H46UA C302
459-5139K-002 CERAMIC CAPACITOR CK45-B2H391KYR C306
459-5168K-002 CERAMIC CAPACITOR RQC06B681K-6H46UA C315
459-5168K-002 CERAMIC CAPACITOR RQC06B681K-6H46UA C318
459-5168K-002 CERAMIC CAPACITOR RQC06B681K-6H46UA C323
459-5168K-002 CERAMIC CAPACITOR RQC06B681K-6H46UA C513
459-5168K-002 CERAMIC CAPACITOR RQC06B681K-6H46UA C515
459-5182K-002 CERAMIC CAPACITOR DD06-999B812K500 C305
462-00315-H02 POLYESTER CAPACITOR CL11-100V-0.015uF-J C216
462-00322-H02 POLYESTER CAPACITOR CL11-100V-0.022uF-J C510
462-00333-H02 POLYESTER CAPACITOR CL11-100V-0.033uF-J C222

462-00347-K02 POLYESTER CAPACITOR CL11-100V-0.047uF-K C512
462-B0410-H02 POLYESTER CAPACITOR CL21X-50V-0.1uF-J C245
462-B0410-H02 POLYESTER CAPACITOR CL21X-50V-0.1uF-J C520
462-B0447-H02 POLYESTER CAPACITOR CL21X-50V-0.47uF-J C214
462-B0510-H02 POLYESTER CAPACITOR CL21X-50V-1uF-J C217
464-30447-M02 ELECTROLYTIC CAPACITOR CD11W-50V-0.47uF-M C235
464-60433-M02 ELECTROLYTIC CAPACITOR CD110-50V-0.33uF-M C227
464-60447-M02 ELECTROLYTIC CAPACITOR CD110-50V-0.47uF-M C236
464-60510-M02 ELECTROLYTIC CAPACITOR CD110-50V-1uF-M C204
464-60510-M02 ELECTROLYTIC CAPACITOR CD110-50V-1uF-M C239
464-60510-M02 ELECTROLYTIC CAPACITOR CD110-50V-1uF-M C242
464-60510-M02 ELECTROLYTIC CAPACITOR CD110-50V-1uF-M C243
464-60510-M02 ELECTROLYTIC CAPACITOR CD110-50V-1uF-M C247
464-60510-M02 ELECTROLYTIC CAPACITOR CD110-50V-1uF-M C248
464-60510-M02 ELECTROLYTIC CAPACITOR CD110-50V-1uF-M C249
464-60510-M02 ELECTROLYTIC CAPACITOR CD110-50V-1uF-M C706
464-60522-M02 ELECTROLYTIC CAPACITOR CD110-50V-2.2uF-M C223
464-60522-M02 ELECTROLYTIC CAPACITOR CD110-50V-2.2uF-M C238
464-60547-M02 ELECTROLYTIC CAPACITOR CD110-50V-4.7uF-M C101
464-60547-M02 ELECTROLYTIC CAPACITOR CD110-50V-4.7uF-M C330

464-60610-M02 ELECTROLYTIC CAPACITOR CD110-50V-10uF-M C324
464-60647-M02 ELECTROLYTIC CAPACITOR CD110-50V-47uF-M C509
464-62547-M02 ELECTROLYTIC CAPACITOR CD288-160V-4.7uF-M C307

464-6C710-M02 ELECTROLYTIC CAPACITOR CD110-10V-100uF-M C209
464-6C710-M02 ELECTROLYTIC CAPACITOR CD110-10V-100uF-M C218
464-6C710-M02 ELECTROLYTIC CAPACITOR CD110-10V-100uF-M C225
464-6C747-M02 ELECTROLYTIC CAPACITOR CD110-10V-470uF-M C250
464-6D522-M02 #ELECTROLYTIC CAPACITOR CD110-16V-2.2uF-M C704
464-6D610-M02 ELECTROLYTIC CAPACITOR CD110-16V-10uF-M C213
464-6D610-M02 ELECTROLYTIC CAPACITOR CD110-16V-10uF-M C325
464-6D610-M02 ELECTROLYTIC CAPACITOR CD110-16V-10uF-M C327
464-6D610-M02 ELECTROLYTIC CAPACITOR CD110-16V-10uF-M C407
464-6D610-M02 ELECTROLYTIC CAPACITOR CD110-16V-10uF-M C601
464-6D610-M02 ELECTROLYTIC CAPACITOR CD110-16V-10uF-M C605
464-6D610-M02 ELECTROLYTIC CAPACITOR CD110-16V-10uF-M C608
464-6D610-M02 ELECTROLYTIC CAPACITOR CD110-16V-10uF-M C705
464-6D610-M02 ELECTROLYTIC CAPACITOR CD110-16V-10uF-M C710
464-6D622-M02 *ELECTROLYTIC CAPACITOR CD110-16V-22uF-M C211
464-6D647-M02 ELECTROLYTIC CAPACITOR CD110-16V-47uF-M C255
464-6D710-M02 ELECTROLYTIC CAPACITOR CD110-16V-100uF-M C212
464-6D710-M02 ELECTROLYTIC CAPACITOR CD110-16V-100uF-M C322
464-6D710-M02 ELECTROLYTIC CAPACITOR CD110-16V-100uF-M C529
464-6D722-M02 ELECTROLYTIC CAPACITOR CD110-16V-220uF-M C606
464-6D733-M02 ELECTROLYTIC CAPACITOR CD110-16V-330uF-M C233
464-6D747-M02 ELECTROLYTIC CAPACITOR CD110-16V-470uF-M C319

464-6F710-M02 ELECTROLYTIC CAPACITOR CD110-35V-100uF-M C332
467-1C010-H03 CARBON RESISTOR 1/6W-10Ω-J R309
467-1C010-H03 CARBON RESISTOR 1/6W-10Ω-J R507
467-1C027-H03 CARBON RESISTOR 1/6W-27Ω-J R109
467-1C033-H03 CARBON RESISTOR 1/6W-33Ω-J R303
467-1C051-H03 CARBON RESISTOR 1/6W-51Ω-J R208
467-1C075-H03 CARBON RESISTOR 1/6W-75Ω-J R601
467-1C075-H03 CARBON RESISTOR 1/6W-75Ω-J R602
467-1C075-H03 CARBON RESISTOR 1/6W-75Ω-J R603
467-1C075-H03 CARBON RESISTOR 1/6W-75Ω-J R604
467-1C075-H03 CARBON RESISTOR 1/6W-75Ω-J R609
467-1C075-H03 CARBON RESISTOR 1/6W-75Ω-J R621
467-1C075-H03 CARBON RESISTOR 1/6W-75Ω-J R622
467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J J031
467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J R102
467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J R103
467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J R108
467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J R110
467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J R218
467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J R219

467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J R224
467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J R228
467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J R232
467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J R235
467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J R401
467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J R404
467-1C110-H03 CARBON RESISTOR 1/6W-100Ω-J R407
467-1C115-H03 CARBON RESISTOR 1/6W-150Ω-J R107
467-1C118-H03 CARBON RESISTOR 1/6W-180Ω-J R211
467-1C133-H03 CARBON RESISTOR 1/6W-330Ω-J R203
467-1C133-H03 CARBON RESISTOR 1/6W-330Ω-J R326
467-1C139-H03 CARBON RESISTOR 1/6W-390Ω-J R403
467-1C139-H03 CARBON RESISTOR 1/6W-390Ω-J R406
467-1C139-H03 CARBON RESISTOR 1/6W-390Ω-J R409
467-1C147-H03 CARBON RESISTOR 1/6W-470Ω-J R505
467-1C147-H03 CARBON RESISTOR 1/6W-470Ω-J R519
467-1C156-H03 CARBON RESISTOR 1/6W-560Ω-J R231
467-1C156-H03 CARBON RESISTOR 1/6W-560Ω-J R234
467-1C156-H03 CARBON RESISTOR 1/6W-560Ω-J R240
467-1C168-H03 CARBON RESISTOR 1/6W-680Ω-J R506
467-1C175-H03 CARBON RESISTOR 1/6W-750Ω-J R209
467-1C175-H03 CARBON RESISTOR 1/6W-750Ω-J R239
467-1C210-H03 CARBON RESISTOR 1/6W-1K-J R202
467-1C210-H03 CARBON RESISTOR 1/6W-1K-J R305
467-1C210-H03 CARBON RESISTOR 1/6W-1K-J R508
467-1C210-H03 CARBON RESISTOR 1/6W-1K-J R605
467-1C210-H03 CARBON RESISTOR 1/6W-1K-J R606
467-1C210-H03 CARBON RESISTOR 1/6W-1K-J R608
467-1C210-H03 CARBON RESISTOR 1/6W-1K-J R709
467-1C212-H03 CARBON RESISTOR 1/6W-1.2K-J R106
467-1C212-H03 CARBON RESISTOR 1/6W-1.2K-J R410
467-1C215-H03 CARBON RESISTOR 1/6W-1.5K-J R318
467-1C218-H03 CARBON RESISTOR 1/6W-1.8K-J R708
467-1C222-H03 CARBON RESISTOR 1/6W-2.2K-J R205
467-1C230-H03 CARBON RESISTOR 1/6W-3K-J R212
467-1C230-H03 CARBON RESISTOR 1/6W-3K-J R517
467-1C239-H03 CARBON RESISTOR 1/6W-3.9K-J R522
467-1C243-H03 CARBON RESISTOR 1/6W-4.3K-J R611
467-1C247-H03 CARBON RESISTOR 1/6W-4.7K-J R210
467-1C247-H03 CARBON RESISTOR 1/6W-4.7K-J R313
467-1C247-H03 CARBON RESISTOR 1/6W-4.7K-J R402
467-1C247-H03 CARBON RESISTOR 1/6W-4.7K-J R405
467-1C247-H03 CARBON RESISTOR 1/6W-4.7K-J R408
467-1C256-H03 CARBON RESISTOR 1/6W-5.6K-J R105
467-1C268-H03 CARBON RESISTOR 1/6W-6.8K-J R524

467-1C268-H03 CARBON RESISTOR 1/6W-6.8K-J R525
467-1C268-H03 CARBON RESISTOR 1/6W-6.8K-J R528
467-1C268-H03 CARBON RESISTOR 1/6W-6.8K-J R711
467-1C275-H03 CARBON RESISTOR 1/6W-7.5K-J R330
467-1C282-H03 CARBON RESISTOR 1/6W-8.2K-J R716
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R204
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R206
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R226
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R236
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R325
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R514
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R515
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R516
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R518
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R521
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R523
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R707
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R710
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R713
467-1C310-H03 CARBON RESISTOR 1/6W-10K-J R714
467-1C312-H03 CARBON RESISTOR 1/6W-12K-J R310
467-1C312-H03 CARBON RESISTOR 1/6W-12K-J R327
467-1C315-H03 CARBON RESISTOR 1/6W-15K-J R241
467-1C318-H03 CARBON RESISTOR 1/6W-18K-J R320
467-1C320-H03 CARBON RESISTOR 1/6W-20K-J R227
467-1C322-H03 CARBON RESISTOR 1/6W-22K-J R214
467-1C322-H03 CARBON RESISTOR 1/6W-22K-J R215
467-1C322-H03 CARBON RESISTOR 1/6W-22K-J R216
467-1C322-H03 CARBON RESISTOR 1/6W-22K-J R217
467-1C322-H03 CARBON RESISTOR 1/6W-22K-J R220
467-1C322-H03 CARBON RESISTOR 1/6W-22K-J R243
467-1C322-H03 CARBON RESISTOR 1/6W-22K-J R319
467-1C324-H03 CARBON RESISTOR 1/6W-24K-J R229
467-1C324-H03 CARBON RESISTOR 1/6W-24K-J R230
467-1C324-H03 CARBON RESISTOR 1/6W-24K-J R510
467-1C333-H03 CARBON RESISTOR 1/6W-33K-J R328
467-1C339-H03 CARBON RESISTOR 1/6W-39K-J R201
467-1C347-H03 CARBON RESISTOR 1/6W-47K-J R237
467-1C347-H03 CARBON RESISTOR 1/6W-47K-J R238
467-1C368-H03 CARBON RESISTOR 1/6W-68K-J R242
467-1C410-H03 CARBON RESISTOR 1/6W-100K-J R101
467-1C410-H03 CARBON RESISTOR 1/6W-100K-J R527
467-1C415-H03 CARBON RESISTOR 1/6W-150K-J R225
467-1C415-H03 CARBON RESISTOR 1/6W-150K-J R343
467-1C424-H03 CARBON RESISTOR 1/6W-240K-J R344

467-1C439-H03 CARBON RESISTOR 1/6W-390K-J R207
467-1C439-H03 CARBON RESISTOR 1/6W-390K-J R222
467-1C468-H03 CARBON RESISTOR 1/6W-680K-J R233
467-1C510-H03 CARBON RESISTOR 1/6W-1M-J R223
467-1D227-H03 CARBON RESISTOR RT14-1/4W-2.7K-J R302
467-2D247-G03 METAL RESISTOR 1/4W-4.7K-G R511

467-2D251-F03 METAL RESISTOR 1/4W-5.1K-F R213
467-2D330-G03 METAL RESISTOR 1/4W-30K-G R512
467-2D418-H03 METAL RESISTOR 1/4W-180K-J R513

471-2022K-003 PEAKING COIL SPT0305-220K-5 L202

471-2027K-003 PEAKING COIL SPT0305-270K-5 L203

471-2027K-003 PEAKING COIL SPT0305-270K-5 L204
471-2B56K-003 PEAKING COIL SPT0305-R56K-5 L101

667-TSP30-01U* MAIN PCB ASS'Y (AUTOMATIC INSERTION )

782-TS2030-010B MAIN PCB

895-6020025-50 RIVET GB876-86-2X2.5-COPPER M103
895-6020025-50 RIVET GB876-86-2X2.5-COPPER M104
895-6020025-50 RIVET GB876-86-2X2.5-COPPER M105
895-6020025-50 RIVET GB876-86-2X2.5-COPPER M106
895-6020025-50 RIVET GB876-86-2X2.5-COPPER M107
895-6020025-50 RIVET GB876-86-2X2.5-COPPER M108
895-6020025-50 RIVET GB876-86-2X2.5-COPPER M109
895-6020025-50 RIVET GB876-86-2X2.5-COPPER M111
895-6020025-50 RIVET GB876-86-2X2.5-COPPER M112
895-6020025-50 RIVET GB876-86-2X2.5-COPPER M113
895-6020025-50 RIVET GB876-86-2X2.5-COPPER M114
895-6020025-50 RIVET GB876-86-2X2.5-COPPER M115
895-6020025-50 RIVET GB876-86-2X2.5-COPPER M116
895-6020025-50 RIVET GB876-86-2X2.5-COPPER M117
895-6020025-50 RIVET GB876-86-2X2.5-COPPER M118
895-6020025-50 RIVET GB876-86-2X2.5-COPPER M119
895-6020025-50 RIVET GB876-86-2X2.5-COPPER M119A
895-6020025-50 RIVET GB876-86-2X2.5-COPPER M122
895-6020025-50 RIVET GB876-86-2X2.5-COPPER M125
895-6020025-50 RIVET GB876-86-2X2.5-COPPER M126
895-6020025-50 RIVET GB876-86-2X2.5-COPPER M127
895-6020025-50 RIVET GB876-86-2X2.5-COPPER M128
895-6020025-50 RIVET GB876-86-2X2.5-COPPER M129
895-6020025-50 RIVET GB876-86-2X2.5-COPPER M132
895-6020025-50 RIVET GB876-86-2X2.5-COPPER M133
895-6025030-50 RIVET GB876-86-2.5X3 COPPER M201
895-6025030-50 RIVET GB876-86-2.5X3 COPPER M202
895-6025030-50 RIVET GB876-86-2.5X3 COPPER M203
895-6025030-50 RIVET GB876-86-2.5X3 COPPER M204
895-6025030-50 RIVET GB876-86-2.5X3 COPPER M205

895-6025030-50 RIVET GB876-86-2.5X3 COPPER M206
895-6025030-50 RIVET GB876-86-2.5X3 COPPER M207
895-6025030-50 RIVET GB876-86-2.5X3 COPPER M208
895-6025030-50 RIVET GB876-86-2.5X3 COPPER M209
895-6025030-50 RIVET GB876-86-2.5X3 COPPER M210
895-6025030-50 RIVET GB876-86-2.5X3 COPPER M211
895-6025030-50 RIVET GB876-86-2.5X3 COPPER M212
895-6025030-50 RIVET GB876-86-2.5X3 COPPER M213
895-6025030-50 RIVET GB876-86-2.5X3 COPPER M214

998 JUMPER WIRE C203
998 JUMPER WIRE C602
998 JUMPER WIRE C603
998 JUMPER WIRE N601
998 JUMPER WIRE R314
998 JUMPER WIRE XS601
998 JUMPER WIRE XS603

998 JUMPER WIRE XS606
329-33204-00 CRYSTAL 32.768K G201
329-54401-00 CRYSTAL JA18 4.433619MHZ G202
340-00079-00 DIODE FR103 VD504
340-00079-00 DIODE FR103 VD505
340-00079-00 DIODE FR103 VD507
340-00257-00 DIODE BYT56J VD509
340-00291-00 DIODE TEU2YX VD508
340-80022-00 RECTIFIER T2SB60 VD501
343-01800-00 TRANSISTOR KSE180 TO-126 V502
343-21400-00 TRANSISTOR TT2140 V302
343-26880-20 TRANSISTOR 2SC2688L V401
343-26880-20 TRANSISTOR 2SC2688L V402
343-26880-20 TRANSISTOR 2SC2688L V403
352-04310-00 IC LM431A (M) N504
352-05740-00 IC uPC574 (D) VD101
352-06210-70 IC TLP621-GB(UL) (O)! N502
352-07400-10 *IC KA5Q0740RTYDTU N501
352-24080-50 IC M24C08BN6 N202
352-75230-90 IC AN7523N (M) N701
352-76931-00 *IC LA769317F N201
352-78040-70 *IC LA78040N (D) N301
352-78050-00 IC KA7805 (M) N503
364-32101-00 2-PINS CONNECTORS TJC3-02A XS204
364-32101-00 2-PINS CONNECTORS TJC3-02A XS701
364-32108-00 2-PINS CONNECTORS TJC1-2A XS502
364-33101-00 3-PINS CONNECTORS TJC3-03A XS203
364-33102-00 3-PINS CONNECTORS TJC2-3A XS501

364-34101-00 4-PINS CONNECTORS TJC3-04A XS202
364-34101-00 4-PINS CONNECTORS TJC3-04A XS205
364-36102-00 6-PINS CONNECTORS TJC2-6A XS301
364-58204-00 CRT SOCKET GZS8-17(UL) ! XS403
364-77511-00 FUSE HOLDER FU501
364-77511-00 FUSE HOLDER
364-91206-00 S-VIDEO TERMINAL S-402 XS602
364-96207-00 AV JACK AV6-8416 XS601

457-12003-90U RELAY JQX-115F-012-1H1 ! RL01

458-07009-00 SAW FILTER M1859M Z201

459-6147K-00 CERAMIC CAPACITOR DE0705B471K1k C514
459-6215K-00 CERAMIC CAPACITOR DE0905B152K1K C508
459-6247K-00 CERAMIC CAPACITOR DE1205B472K1K C503
459-6247K-00 CERAMIC CAPACITOR DE1205B472K1K C504
459-6247K-00 CERAMIC CAPACITOR DE1205B472K1K C505
459-6247K-00 CERAMIC CAPACITOR DE1205B472K1K C506
459-8147K-00 CERAMIC CAPACITOR DE0707B471K2K C312

459-8210K-00 CERAMIC CAPACITOR DE0907B102K2K C410
459-B147M-20U CERAMIC CAPACITOR CD11-B2GA471M-MYAS ! C524
459-B147M-20U CERAMIC CAPACITOR CD11-B2GA471M-MYAS ! C525

459-B222M-20 CERAMIC CAPACITOR ECK-DNS222MEX ! C523

462-00410-K0 POLYESTER CAPACITOR CL11-100V-0.1uF-K C326

462-00410-K0 POLYESTER CAPACITOR CL11-100V-0.1uF-K C328
462-2B410-M0U POLYESTER CAPACITOR MKP-300VAC-0.1UF-M ! C502
462-2B422-M0U POLYESTER CAPACITOR 250VAC-0.22uF-M ! C501

462-83356-H0 POLYESTER CAPACITOR CBB21-200V-0.056uF-J C304

462-83439-H0 POLYESTER CAPACITOR CBB21-200V-0.39uF-J C339

462-88233-H0 POLYESTER CAPACITOR CBB81-1600V-3300PF-J C310

462-8E227-H4 POLYESTER CAPACITOR CBB81A-2KV-2700PF-J C311
462-B0410-H0 POLYESTER CAPACITOR CL21X-50V-0.1uF-J C527

464-04747-M0R ELECTROLYTIC CAPACITOR 200USP470MA35 C507

464-60610-M0 ELECTROLYTIC CAPACITOR CD110-50V-10uF-M C104
464-62710-M0 ELECTROLYTIC CAPACITOR CD288-160V-100uF-M C301
464-62710-M0 ELECTROLYTIC CAPACITOR CD288-160V-100uF-M C517
464-65547-M0 ELECTROLYTIC CAPACITOR CD288-250V-4.7uF-M C338

464-65633-M0 ELECTROLYTIC CAPACITOR CD288-250V-33uF-M C303
464-6C710-M0 ELECTROLYTIC CAPACITOR CD110-10V-100uF-M C102
464-6C722-M0 ELECTROLYTIC CAPACITOR CD110-10V-220uF-M C234
464-6D810-M0 ELECTROLYTIC CAPACITOR CD110-16V-1000uF-M C519
464-6D810-M0 ELECTROLYTIC CAPACITOR CD110-16V-1000uF-M C703
464-6E822-M0 ELECTROLYTIC CAPACITOR CD110-25V-2200uF-M C329

464-6F747-M0 ELECTROLYTIC CAPACITOR CD110-35V-470uF-M C335

464-6F747-M0 ELECTROLYTIC CAPACITOR CD110-35V-470uF-M C521

464-6F810-M0 ELECTROLYTIC CAPACITOR CD110-35V-1000uF-M C317

467-1D251-H0 CARBON RESISTOR RT14-1/4W-5.1K-J R526

467-2D239-G0 METAL RESISTOR 1/4W-3.9K-G R312

467-2D282-G0 METAL RESISTOR 1/4W-8.2K-G R311

467-2E001-H0 METAL RESISTOR 1/2W-1Ω-JL R321

467-2E133-H0 METAL RESISTOR 1/2W-330Ω-JL R317

467-2F210-H0 METAL RESISTOR 1W-1KΩ-JL R315
467-2G015-H0 METAL RESISTOR 2W-15Ω-JL R520
467-2G291-H0 METAL RESISTOR 2W-9.1kΩ-JL R301
467-2G312-H0 METAL RESISTOR 2W-12kΩ-JL R104
467-2G315-H0 METAL RESISTOR 2W-15kΩ-JL R413
467-2G315-H0 METAL RESISTOR 2W-15kΩ-JL R414
467-2G315-H0 METAL RESISTOR 2W-15kΩ-JL R415

467-2H239-H0D METAL RESISTOR 3W-3.9kΩ-JL R332

467-4F001-H0 FUSIBLE RESISTOR 1W-1Ω-JL R307

467-4F010-H0 FUSIBLE RESISTOR 1W-10Ω-JL R304

467-4FA24-H0 FUSIBLE RESISTOR 1W-2.4Ω-JL R306
467-4FA33-H0 FUSIBLE RESISTOR 1W-3.3Ω-JL R419

467-4FB33-H0 FUSIBLE RESISTOR 1W-0.33Ω-JL J046
467-4FB33-H0 FUSIBLE RESISTOR 1W-0.33Ω-JL R308

467-6FA15-H0 WIRE ROUND RESISTOR RX21-1-1.5Ω-J R324
467-8E227-H0A SOLID RESISTOR 1/2W-2.7KΩ-J ! R416
467-8E227-H0A SOLID RESISTOR 1/2W-2.7KΩ-J ! R417
467-8E227-H0A SOLID RESISTOR 1/2W-2.7KΩ-J ! R418

467-8E422-H0 SOLID RESISTOR 1/2W-220KΩ-JL ! R504
467-8E522-H0A SOLID RESISTOR 1/2W-2.2M-J ! R501
467-8E582-H0A SOLID RESISTOR 1/2W-8.2MΩ-J ! R509

468-32107-00 POTENTIOMETER EVND8A-A03-B13 RP501
469-10023-00 THERMISTOR 96708 (9Ω) RT501
469-40004-00 THERMISTOR 5D2-14LC R502

470-00361-00U SWITCHING TRANSFORMERSR4039C ! T501

471-2068K-10 PEAKING COIL LGA0410-68uH-K L102

472-10001-00 HORIZONTAL DRIVE TRANSFORMER XR0961 T302
472-21122-00 FBTBSC24-01N4085D ! T301
477-00077-00 LINERITY COIL HL1830H-X14 L302

477-20028-00U POWER FILTER LF21065 L501

477-40031-00 FIXED COIL LG750 L301
477-40031-00 FIXED COIL LG750 L503
569-13141-90 FUSE 50T T3.15A/250V UL ! FU501

590-40707-00 TUNER 115-B-8035AZ T101
655-41201-135 ( 4-PINS ) LEAD WITH HOUSING XS302
655-61201-117 * ( 6-PINS ) LEAD WITH HOUSING XS201

666-13511-00 FERRITE BEAD 3.5X1X4.5 J024

666-16002-00 FERRITE BEAD TY6X2X3 VD509

667-TSP30-01U\ MAIN PCB ASS'Y (MANUAL INSERTION )

681-40003-00 OK LABEL

706-20173-00 HEAT SINK N503

706-20173-00 HEAT SINK V502

706-20249-00 HEAT SINK V302

706-46006-01 HEAT SINK N301

706-64002-01 HEAT SINK N501

706-T3008-01 HEAT SINK N701

742-30005-09 LINE TIE

770-15102-70 RV0.2 12X0.15 150mm BLACK N601

775-60044-00 SOCKET PIN RT-01T-1.3B TP1

775-60044-00 SOCKET PIN RT-01T-1.3B TP2

775-60137-00 HOLLOW PILLAR φ2.36×14B R104

775-60137-00 HOLLOW PILLAR φ2.36×14B R332

775-60137-00 HOLLOW PILLAR φ2.36×14B R520

775-60137-00 HOLLOW PILLAR φ2.36×14B VD507

775-60137-00 HOLLOW PILLAR φ2.36×14B VD508

775-60137-00 HOLLOW PILLAR φ2.36×14B VD509

775-60137-00 HOLLOW PILLAR φ2.36×14B

851-13008-56 SCREW P(+) T3X8S-R N301

851-13008-56 SCREW P(+) T3X8S-R N501

851-13008-56 SCREW P(+) T3X8S-R N701

851-13008-56 SCREW P(+) T3X8S-R N701

852-13008-81 SCREW P(+) M3X8-D.Zn N503

852-13008-81 SCREW P(+) M3X8-D.Zn V302

852-13008-81 SCREW P(+) M3X8-D.Zn V502

881-60074-00 HIGH VOLTAGE WARNING LABEL

893-10300-11 NUT GB6170-86-M3-D.Zn N503

893-10300-11 NUT GB6170-86-M3-D.Zn V302

893-10300-11 NUT GB6170-86-M3-D.Zn V502

894-40030-11 WASHER GB859-87,3-DZn N503

894-40030-11 WASHER GB859-87,3-DZn V302

894-40030-11 WASHER GB859-87,3-DZn V502

301-ATS2030-26B RC-A26-0B REMOTE CONTROL DIGISTAR

667-TS1337-05 KEY BOARD ASS'Y

340-00001-00 DIODE 1N4148 VD902

782-TS1337-0500 BUTTON PCB

352-60380-90 IC FM-6038LM (M) N901

360-10001-00 TACT SWITCH KFC-A06-4X4.5X5B SW901

360-10001-00 TACT SWITCH KFC-A06-4X4.5X5B SW902

360-10001-00 TACT SWITCH KFC-A06-4X4.5X5B SW903

360-10001-00 TACT SWITCH KFC-A06-4X4.5X5B SW904

360-10001-00 TACT SWITCH KFC-A06-4X4.5X5B SW905

360-10001-00 TACT SWITCH KFC-A06-4X4.5X5B SW906
464-6D647-M0 ELECTROLYTIC CAPACITOR CD110-16V-47uF-M C901

467-1C047-H0 CARBON RESISTOR 1/6W-47Ω-J R913
467-1C210-H0 CARBON RESISTOR 1/6W-1K-J R902

467-1C222-H0 CARBON RESISTOR 1/6W-2.2K-J R903
467-1C233-H0 CARBON RESISTOR 1/6W-3.3K-J R904
467-1C247-H0 CARBON RESISTOR 1/6W-4.7K-J R905
467-1C282-H0 CARBON RESISTOR 1/6W-8.2K-J R906
467-1C312-H0 CARBON RESISTOR 1/6W-12K-J R907
467-1C420-H0 CARBON RESISTOR 1/6W-200K-J R908

655-31201-03 (3-PINS) LEAD WITH HOUSING XS903
655-41201-238 ( 4-PINS ) LEAD WITH HOUSING XS902

998 JUMPER WIRE R912

467-1C147-H0 CARBON RESISTOR 1/6W-470Ω-J R911

870-30218-0T0 KEY BOARD FRAME (PLATE SILVERY WHITE )

851-23008-31 SCREW SJ2824 ST3X8FT-D.Zn

868-20037-00 FIBRE WASHER φ8Xφ3.2X0.5

667-TS13371-05 STANDBY KEY BOARD ASS'Y

360-10001-00 TACT SWITCH KFC-A06-4X4.5X5B XS904

655-2E301-56 ( 2-PINS ) LEAD WITH HOUSING SW907

782-TSB371-0500 STANDBYBUTTON PCB

667-TS1337-14 INDICATOR LIGHT BOARD ASS'Y

782-TS1337-1400 INDICATOR LIGHT PCB

340-10126-20 *LED HFR205P VD601
655-21201-122 (2-PINS) LEAD WITH HOUSING X601

D

C

B

A

6

9V

R-O

L-O

GND

XS01

8

54321

RS18

10K

GS01

RS19

5.1K

27pF

CS27

BVS04

2SC1815

RS20

2.2K

CS28

150pF

RS21

4.7K

E C

CS29

1200pF

RS09

1K

B

VS02

2SC1815

EC

RS08

2K

SCL

564

7

SDA

321

SIF

GND

VS02

2SC1815

ZS01

2.2uF

CS18

2.2uF

B

RS07

CS17

VS01

E C

E C

2SC1815

B

680

RS05

680

4.5MHz

ZS02

4.5MHz

CS30 10uF

RS16

36K

JS01

RS15

1.5K

RS17

VS05

2SC1815

E C

18K

RS14

1K

B

Number Revisi onSize

B

Title

Date: 6-Dec-2004 Sheet of

File : E: \PROTEL\LH L.Ddb Drawn By:

LS01

10uH

CS22

47uF

CS21

CS25

4.7uF

CS26

1uF

0.1uF

CS23

CS24

0.01uF

22uF

CS19

2.2uF

CS20

1uF

RS04

1K

RS05

1K

CS16

10uF

CS

4n7

CS14

4.7uF

CS15

1uF

CS12

3.3uF

CS13

4.7uF

36

FIL

FSC I

PLT LVL

PLT DET

MODE O

31

VCC9V

30

REG

29

ST.O

28

L+R I

27

VREF

NS01

26

L OUT

25

R OUT

24

ALC

23

L-R/SAP

22

DBX O

21

OF.CNL

LA72700

20

SPE I

19

S.R.DET

NS01

LA72700

32

33

34

35

DET.1
1

ST.PLL

BB.O
2

PLT DET

3

4

GND

BB/SIF
5

SAP DET

NC

6

7

8

SIF DEM
9

MUTE(H)

10

SDA

11

SAP SEN

15

W.R.DET

16

WIDE DET

17

SPE.DET

18

SCL

OFFSET

13

ST.SEN

14

12

CS02

1uF

CS01

1uF

CS04

1uF

RS01

4.7K

1uF

CS05

CS06

0.1uF

CS07

0.1uF

RS02

100

RS03

100

0.1uF

CS08

CS09

22uF

CS11

4.7uF

CS10

4.7uF

1 2 3 4 56

0.1uF

CS03

D

C

33

B

A

2W

15K

R413

8

7654321

C714

100p

C713

100p

C712

100p

100p

C711

N701

AN7522

LRV

LV

R

IN OUT

CbYCr

14

XS601

1

XS602

3

3

T101

*

16

2

12

4

IF1

BP

OUT2(+)

GND

OUT2(-)

VOL

IN2

GND

IN1

STB

OUT1(-)

GND

OUT1(+)

VCC

TO MTS BOARD

13

221

4

SDA

SCL

AS

AGC

R416

2.7K

IN4148

VD401

R403

390

V401

2SC2688

E C

1

B

390p

C404

R401

100

R420

4K7

R402

12

R CRT

C401

100p

L+R-R+

L-

XS701

241

3

9V

10K

12

R714

C710

11

10

C709

10n

R713

9

R712

C708

1u/16V

8

10n

C707

7

R711

6

C706

1u/16V

5

C705

4

1K2

R710

3

R709

1K

C704

2

R708

1K8

1N4148

VD704

1

V702

1

5V-1

R707

10K

B

C703

2200u/16V

10K

R705

C702

16V 100u

1

A1015

560K

V701

R703

R702

10K

IN4148

1K

VD701

R701

1

L

R

XS606

21

JUMPERA

C606

220u

75

R609

20

19

C605

10u

R608

1K

C607

18

17

10u

C604

R607

1K

15

5

10u

C603

R606

1K

4

3

C602

10u

R605

1K

1

9

R604

75

8

11

R603

75

10

14

75

R602

13

12

7

5

4

3

C601

10u

75

R601

6

2

1

R621

75

R622

75

11

9V

150

R107

L101

56uH

100

9

R108

BT/LOCK

5K6

R105

L102

7

6

5

4

100

3

R101

1

C101

D

R414

330

TO SPEAKER

10uf/16V

10K

10K

R716 10K

10K

10u/16V

2.2u 16V

C1815

E C

10K

R706

VD703

1N4148

VD702

R704

10K

C701

16V 47u

SCL

GND

56478

4.3K

10u

R611

C608

R610

4.3K

10u

L1

GV1 R1

XS603

G

C107

V101

C2717

B

C106

0.01

2W 12K

R104

2W

C103

R103

10K
R102

100K

4u7 50V

D

15K

2W

VD402

B

V402

2SC2688

100

R404

13

C402

100p

G CRT

1234567

N601

TC4053

VD601

IN4148

1

9V

R715

10K

1N4148
1

POWER OFF MUTE

9V

SIF

SDA

GND

321

9V

SDA1
SCL1

0.01

0.01

C108

E C

R109

27

R106

1K2

100

R110

RD30E

VD101

0.01u

C105

4u7

C104

0.01

100u

C102

IN4148

FM

JUMPERB

V OUT

LO

RO

L1

R1

Y-DVD

V1
S-Y

S-C

SDA1

SCL1

A

*

XS302

241

SCREEN

R304

10 1W

B

33

1

2n2

XR0961

3

390p

820

6

V301

2SC2383

3

7

C304

56n 200V

200V

1k

R305

6

1

L301

L2

1

VD301

C339

400V 0.33

1W

(390)

R301

9K1 2W

C313

C312

(390)

*

C311

5n6

C310

3n3

C309

470 2KV

E C

2

4

C307

160V 4u7

3W

R332

3K3 3W

2K7

R302

E C

B

Number RevisionSize

D

Title

Date: 6-Dec -2004 Sheet of

File: E:\PROTEL\LHL.Ddb D rawn By:

C301

33u 160V

C302

220p

S5295J

C303

33u 250V

1

C338

S5295G

250V 4u7

VD313

B+

ABL

68K

R344

150K

R343

B+

R516

5K1 1/4W

R526

5K1 1/4W

B

R510

24K

E C

1

V505

C1815

TBY56J

VD510

R513

180K

R512

14V

HZ6B1

VD514

1000u 25V

C519

C517

C514

1n 1KV

C518

103p

FR103

1

VD508

VD509

*

16

12

*

1

5

IN4148

R507

10

VD505

1

1

VD504

FR103

1 2

5

4

3

2

N501 KA5Q0565RT

341

1

4n7

C506

4n7

C505

4.5

C525

470pF 250V~

R502

4

2

2

L501

C524

1

470pF 250V~

C526

0.1

1K

30K

R511

RP501

R527

100K

4K7 1/4W

2

C527

10n

N504

TL431

3 1

100u 160V

1K

R508

TBY56J

R517

5K6

*

2

15

1

R509

8M2

3

C523

N502

4

3

1

680

R506

HZ5B1

VD503

R529

1W-1K

1W

0.1

C501

3

1

XS501

A

2n2 400V~

*

C511

3300

VD502

IN4148

330

R505

0.022

C510

VD515

HZ12B1

0.047

C512

47u 50V

C509

C508

HZ2C2

VD511

1500pF 1KV

C516

47u 50V

2.2M

R501

FU501

T2.5A 250V~

1 2 3 4 5 6 7 8

1

2

5

100n

C326

R316

R315

1 2

R317

0.1

C328

C329

2200u 25V1WR324

330

R326

C330

4u7 25V

33K

R328

12K

R327

1000

C333

123

VCC

TEST

100

R218

4K7

R216

VD201

HZ5C2

220

C218

10V 100u

0.47u

C215

C212

10V 100u

9V

C211

22u 16V

0.01

5V-2

0.022

C206

B

330

R203

1K

R202

22uH

33K

R908

SW907

AV/TV

POWER

B

*

1

3

1W 1K

1W

L303

1W 1K

1W

L302

330 1/2W

10

R309

1

680p

C323

0.68 1W

15K

TP1

TP1

R310

TP1

TP2

TP2

TP2

HZ7C2

VD307

B

V303

C1815Y

45

A2A1A0

N202

24C08

SCL

SDA GND

678

X-RAY

100

R219

SCL1

SDA1

10K

4K7

R243

R217

REM

5V-2

5V-1

R207

390K

JUMPERC

A OUT A IN

V201

2SA1815

E C

FM

R523

12V

150K

R909

RL01

B

VD306

C324

8K2

R311

10K

4

321 5

*

HV

*

T301

5

3

R308

1 1/2W

1W 3.6

S5295G

R307

680p

C318

10u 50V

C319

470u 16V

4K3

R312

C325

12V

100u 16V

31

4K7

R313

E C

N302

*

FOCUS

9

428

10

R306

1W 2.4

1

FR103

680p

VD304

C315

1

10n

C316

FR103

VD305

27V

C317

1000u 35V

7

C320

10n

24V

TT2140

V302

R303

2

7809

C322

9V

C308

T302

470u 16V

C306

C305

TP9

TP6

POWER OFF MUTE

1

2

3

4

C522

R522

1015

V501

C529

10u/16V

C1815

V503

VD506

1N4148

1

ON

OFF

POWER

BUS DEBUG

XS205

R524

6K8

R525

6K8

B

V504

C1815

E C

R528

6K8

*

R514

10K

R515

5K6

B

V507

C1815

E C

680

R519

75uH

L503

EC

V502

KSE180

3K9

N503

1

10K

R521

POWER OFF MUTE

680

C515

T501

T501

10K

R518

B

E C

NPN2

HZ6B1

VD513

2

B

7805

10u

R520

15 1W

C520

1W

VD512

IN4148

1

C521

470u 16V

680

1

C513

1

FR103

VD507

*

13

9

10

*

*

8

7

6

R504

R503

1/2W 110K

1/2W 110K

1 2

C507

150uF 400V

2

L502

L502

4n7

C504

134

VD501

VD501

2

4n7

GND

C503

0.1

C502

t

3

RT501

PTC

XS502

XS502

C

HV

*

C410

1n 2KV

4

2W

15K

R415

R418

2.7K

2.7K

R417

R406

390

E C
1

390p

C405

330

R421

4K7

R405

R613

1K

C610

10u

R612

C609

10u

1K

R614 100K

100K
R615

L1

RO

C613

LO

16V 10u

C612

16V 10u

CRT B

CRT G

CRT R

IN4148

R409

390

VD403

E C

1

B

C406

390p

V403

2SC2688

330

R422

100

R407

4K7

R408

14

R410

1K2

B CRT

100p

C403

G

G

R2GL2

V2

XS604

43521

6

75

R616

C611

10u

V1

89

10111213141516

R619

15K

R620

7.5K

9V

AV1/AV2

R618

100K

C614

16V 1u

100K

R617

R1

C221

15p

15p

C220

5V-1

0.1

C245

10K

R246

15K

KEY

S-C

S-Y

V OUT

9V

R241

1u

C227

1M

R223

C223

50V 2.2

FBP

0.01

C224

100

R228

5V-2

47pF

C226

C248

Y-DVD

C242

10V 220u

C229

18p

C228

0.47
C235

R229

24K

V202

A1015

560

R231

C239

50V 1u

50V 1u
C243

R230

24K

C232

50V 2.2u
C238
1K
R234

47K
R238

47K
R237

10K

R236

R239

680

15

2

3

Z201

C409

250V 10u

V404

R412

C407

10u 16V

R CRT

G CRT

XS401

XS201

5C1

VD202

*****************

G201

*

R222

390K

34

35

C253

68uH

L204

10V 100u

36

10k

R221

37

C244

0.01

39

40

47K

R225

41

100

R224

42

0.033

C222

43

C225

10V 100u

44

20K

R227

45

0.01uF
C219

46

50V 1u

C249

47

50V 1u

750

R209

48

50V 1u

C247

49

C230

0.1
*

50

G202

51

0.1

100

R232

52

0.047

C231

53

R247

2M2

54

0.01

22uH

55

L202

C233

10V 470u

56

R233

680K

57

58

0.47

C236

59

60

560

R240

61

0.01
C237

62

63

4

64

*

2

6

358

G

R

CRT G

CRT R

C1815

1K8

R411

E C

B

12K

0.01

C408

B CRT

43521

6

*

43521

6

VD705

IN4148

1

VD204

HZ5C1

BGR

5C1

VD203

XT1

33

34

XT2

VDD

35

36

37

PO6/AN6

38

TV/AV

PO7/AN7

39

KEY

RESET

40

41

PLL

CPU GND

42

CCD VCC

43

FBP INH OUT

44

C(Y/C)

45

46

Y(Y/C)

N201

DDS FIL

47

Y(DVD)

48

CB

49

4.43M

50

CR

51

52

C APC

53

AV IN

54

55

V IN

56

B L D FIL

57

APC FIL

58

AFT FIL

59

60

V OUT

61

RF AGC

62

IF GND

63

PIF IN 2

64

PIF IN 1

B

CRT B

CRT

XS403

PO4/MUTE

PO5/AV1\AV2

LA76931

N201

LA76931

V OUT/FSC

V/C/D VCC

7

R419

N301 LA78040

4

3

3.3 1W

2

1

1K5

R318

HZ5B3

VD309

22K

R319

NON IN

OUT VCC

OUTPUT

GND

PUMP

VCC

INV IN

R226

P13/SCL1

32

31

P12/SDA1

VOLUME

30

P16 PWM3

29

P17 STB

28

P15 POW

P14

27

REM

26

PO3/INT3

PO2 BUS DET

25

PO1/INT1

24

P00 X-RAY

23

GND

22

21

H AFC

20

H VCC

19

VCO IREF

18

V OUT

17

V RAMPOSC

16

AKB

15

B OUT

14

G OUT

13

R OUT

12

RGB VCC

11

10

ABL

9

A IN

8

IF VCC

7

SIF APC FIL

6

A OUT

5

FM/A OUT

FM FIL

4

3

SIF IN

2

PIF AGC

1

SIF OUT

XS301

6

XS402

PIN4

10

22K

R320

7

C327

10u 16V

6

1 1/2W

R321

5

10p

C331

4

10K

R325

3

C332

100U 35V

2

1

IN4002

VD308

1

5K6

R330

C335

35V 100u

1

10K

R235

100

2

XS204

PIN2

C252

200pf

C250

10V 100u

32 33

SCL1

0.01

C240

31

SDA1

30

29

28

27 38

R245

10K

26

25

4K7

4K7

4K7

R214

R215

R220

24

23

22

1u

0.01

C217

R212

3K

C241

21

20

R211

19

0.015

C216

R242 68K

18

R213

1/4W 5K1

17

R2104K7

16

C214

0.47

15

0.1

C246

14

B

13

G

12

R

51

R208

11

10

10K

R206

9

C210

10u

2K2

68uH

R205

C213

L203

8

C209

100u

1500

C208

7

R204

10K

C207

0.01

6

5

C205

0.022

4

1u

39K

C204

R201

3

39pF

C203

2

0.022

C202

1

C201

39pF

L201

REM

KEY

5V-2

5V-1

241

3

XS202

*

PIN4

XS901

241

3

C901

22u 16V

2K

R912

123

47

IN4148

R913

1

VD902

LED

VD901

N901

HRM3806B

1k

R911

312

XS203

*

PIN3

312

XS902

1K

33u

R902

C902

SW901

SW902

VOL-

C

8K2

4K7

3K3

2K2

R904

R903

SW903

CH-

VOL+

12K

R906

R905

R907

SW906

SW904

SW905

CH+

MENU
