XMODS 6000939 User Manual

STARTER KIT USER’S GUIDE

The 6000939 XMODS Starter Kit revs
up your XMODS experience.

Please read this user’s guide before
building and using your new car.

PRECISION
CONTROL!

Page 8.

1:24 SCALE
AGE 8+

2

Contents

XMODS Custom RC Starter Kit ................................................................................................................. 3

Install the Car Batteries............................................................................................................................... 4

Install the Controller Battery .................................................................................................................... 4

Assembling Your XMODS Custom RC ................................................................................................... 5

Assembling the Car Chassis .................................................................................................................. 5

Pairing Your Controller and the Car ................................................................................................... 6

Mounting the Car Body on the Chassis ............................................................................................ 7

Driving Your Car and Adjusting Trim ..................................................................................................... 8

When You Finish Driving ........................................................................................................................ 8

XMODS Upgrades ........................................................................................................................................ 9

FCC Information ..........................................................................................................................................10

Limited Warranty ........................................................................................................................................10

3

XMODS Custom RC Starter Kit

Thank you for purchasing your XMODS Custom RC Start Kit! Your starter kit features:

• Four-wheel spring suspension to provide improved handling over uneven surfaces.

• Decals to customize the body exterior.

• Multiple frequency bands that allow up to eight people to race.

• Digitally proportional steering for optimal speed, acceleration, and maneuverability.

To really get your motor running, customize your XMODS with optional upgrades for both
performance and looks, available at your local RadioShack store. Check out the line-up of XMODS
upgrades available online at www.RadioShack.com.

Your Starter Kit Includes

Screws (4)

Decal Sheet

User’s Guide

Battery Unit

Controller Car Body

Rear Unit

Front Unit

4

Install the Car Batteries

1. Make sure the power switch on the chassis is OFF.

2. Remove the screw on the battery compartment cover. Then

carefully unlatch the battery compartment cover and remove
the cover.

3. Insert four AA batteries (not included) in the compartment,
matching the polarity symbols (+ and –) marked inside.

4. Replace the battery compartment cover and screw.

Install the Controller Battery

Your controller needs a 9V battery (not included). We
recommend 9V alkaline batteries for best performance. If
the LED is off or the range of your car decreases, replace
the battery.

1. Make sure the power switch is OFF, and remove the
screw on the battery compartment.

2. Place the 9V battery in the compartment, matching
the polarity symbols (+ and –) marked inside.

3. Snap the cover back in place and replace the screw.
