Xmark ILR Users Manual

are

and Hugs

MyCall

FindIt,

DRAFT

.

Part Number 806A5301

Local Area Receiver Guide

• Pulled network and power cable?

• Resolved power supply requirements?

• Selected the location for the LAR?

LAR Orientation

• Main antenna should be pointing downward into

35 ft. (11 m) stand-alone LARs

Storage: -22° to 158° F (-30° to 70°C)

Certifi ed to the ISO 9001 Quality Standard

an area free of metal obstructions.

metal objects, such as framing or air ducts.

806U5301 Rev 01

• Ensure that the LAR is at least 2 ft. (60 cm) from

All other company and product names may be trademarks of their respective compa-

Printed in Canada. February 2005.

nies.

© 2005 Xmark, a division of Instantel Inc. All Rights Reserved.

registered trademarks of Instantel Inc. in North America. Xmark and the Xmark logo are trademarks of

Instantel Inc.

808 Commerce Park Drive, Ogdensburg, NY 13669 USA or

309 Legget Drive, Ottawa, ON K2K 3A3, Canada

you:

Have

Read these instructions thoroughly

If you answered, “No,” to any of these questions, refer to the

MyCall/FindIt Installation Manual before installing.

before installing the Local Area Receiver.

Faulty installation can lead to system failure.

clip and mounting hardware.

path.

network. Two provided with each Controller (p/n 805A2201).

Frequency 433.42 to 434.42 MHz

Supply Voltage 10-30 VDC

Current Draw 60 mA @ 12 / 24 VDC, 100 mA max.

Detection Radius 50 ft. (15 m) overlapping LARs

Communications LonWorks two wire

Temperature Operating: 32°F to 120°F (0°C to 49°C)

Humidity 0-85% RH @ 70°F (21°C), non-condensing

Dimensions Approximately 5.2 x 3.3 x 1.5 in. (133 x 84 x 38 mm)

Materials Required

Materials Required

• Local Area Receiver (p/n 806A5301); includes antennas, Caddy

• Facility fl oor plan indicating LAR position and network wiring

• 105 Ω network terminator (p/n 805A2401) required to terminate

Important Reference Documents

Important Reference Documents

• Hugs Installation Manual (p/n 805I0301)

• MyCall/FindIt Installation Manual (p/n 805I0401)

Specifi cations

Weight Approximately 9.2 oz. (260 g)

Telephone: 1-866-55-XMARK International: [phone] Facsimile: 1-613-592-4296

E-mail: [e-mail] Web Site: www.xmarksystems.com

plied by Instantel during the warranty period as set out in the

Product documentation; or, at the option of Instantel,

tel.

installation or maintenance of Instantel’s Product or products or the

system in which they are incorporated, or alleged to have resulted

from an act or omission of Instantel or any person, negligent or

otherwise, shall be limited to:

A) The repair or replacement of defective Product or materials sup-

B) Refund of the purchase price of the Product supplied by Instan-

Unconfi gured LAR. Run Auto Confi gure in the LonWorks

Device Installation dialog box.

In no event shall Instantel be liable for general, specifi c, indirect,

consequential, incidental, exemplary or punitive damages or any

losses or expenses suffered by you or anyone else, whether or not

Instantel, or its employees, offi cers, agents, resellers or installers has

been informed of the risk of such loss or expense and whether or not

such losses or expenses were foreseeable.

Statements

United States—Federal Communication Commission (FCC)

the LonWorks Device Installation dialog box.

This device complies with Part 15 of the FCC Rules. Operation

is subject to the following two conditions: (1) this device may not

cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause unde-

sired operation.

NOTE: This equipment has been tested and found to comply with

the limits for a Class A digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable protection

against harmful interference when the equipment is operated in a

commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accor-

dance with the instruction manual, may cause harmful interference to

radio communications. Operation of this equipment in a residential

area is likely to cause harmful interference in which case the user will

be required to correct the interference at his own expense.

Warning: Changes or modifi cations not expressly approved by Xmark

could void the user’s authority to operate the equipment.

Canada—Industry Canada

The term “IC:” before the certifi cation/registration number only

signifi es that Industry Canada technical specifi cations were met.

European Union—CE declaration

Xmark hereby declares that this radio frequency receiver is in compli-

ance with the essential requirements and other relevant provisions

of Directive 1999/5/EC.

LED state Meaning

Service Light

The service light is located beside the secondary antenna, and indi-

cates the current status of the LAR, as shown in the table below.

Off Normal operation.

Flashing every

0.5 sec.

On Hardware failure. Download fi rmware to the LAR from

Warranty

Xmark’s products are warranted against defects in materials and

workmanship and shall perform in accordance with published speci-

fi cations for a period of one year. Instantel Inc. reserves the right to

change specifi cations without notice.

Limitation of Liability

This Product has been designed for use to assist personnel in sum-

moning help when they are under personal duress and/or locate

assets.

The range, accuracy, function and performance of this Product

may vary from the published specifi cations due to many factors,

including, without limitation, site impairments from structural

effects, metal objects in the vicinity, placement of the receiver and

transmitter, interference from other electrical devices, atmospheric

effects, installation, and maintenance. There may be other factors,

which also affect performance of this Product.

Instantel does not guarantee that this Product will detect 100% of

the calls for personal assistance and locate all assets 100% of the time.

Instantel does not guarantee that this Product will not return false

reports of calls for personal assistance and/or location of assets.

Monthly testing and maintenance of this Product, as described in the

Product documentation, is essential to verify the system is operating

correctly and to ensure that the probability of detecting an alarm

and/or locating the transmitter are maximized.

The failure to undertake regular testing and maintenance will increase

the risk of system failure and failure to report personal duress calls

and/or failure to locate assets. The failure to undertake regular test-

ing and maintenance will increase the risk of false reports of calls for

personal assistance and/or location of assets.

Instantel hereby disclaims all warranties, express or implied, arising

out of or in connection with any of its Products of the use or perfor-

mance thereof, including but not limited to, where allowable by law,

all other implied warranties or conditions of merchantable quality

and fi tness for a particular purpose and those arising by statute or

otherwise in law or from a course of dealing or usage of trade.

Instantel’s liability to you or anyone claiming through or on behalf of

you with respect to any claim or loss arising out of the use or misuse

of Instantel’s Product, defective products or materials, improper

OR

Figure 1: Physical connections for the LAR.

OR

Install the mounting plate using one of the following methods.

A Fasten to a suspended ceiling guy wire, using:

• 1 multi-function Caddy clip

• 2 machine screws

• 2 hex nuts

• 2 lock washers

B Install directly to a ceiling or a wall using:

• 2 wood screws

• 2 hollow wall anchors

C Install to a receptacle box, using:

Do not supply power to the LAR or any other network

device until all connections are complete.

• 2 machine screws

5 Install the LAR to the Mounting Plate.

Plug the wired terminal block into the LAR and install the LAR

onto the Mounting Plate, using the screw removed in Step 2.

DO NOT place excess network and power supply wires inside

the LAR case.

touching metal. For best coverage, ensure that they are at least 2

ft. (60 cm) from metal objects. Do not encase, wrap, or otherwise

cover the antennas.

6 Attach the two antennas.

The antennas have a protective covering to prevent them from

Final Steps

Installation is complete. Proceed to Final Steps below.

Final Steps

off to prevent electrical shock or damage to equip-

ment.

• Ensure that the power supply and network are turned

Once all devices are installed, power up the LAR and other devices.

In the Xmark™ software, run Auto Confi gure to install the new

devices, and then confi gure them for operation.

static charge before handling the LAR.

• Touch your hand to ground to discharge any electro-

The coverage area of the LAR must also be checked.

Refer to the Hugs Installation Manual (p/n 805I0301) or MyCall/

FindIt Installation Manual (p/n 805I0401) for detailed informa-

tion on how to complete these steps.

mounting above drop ceilings, mount the LAR below metal duct

work, pipes and foil-backed ceiling tiles.

not in conduit, keep it at least 1 ft. (30 cm) from the LAR.

ings should be secure enough that the LAR can be permanently

mounted without disturbing its orientation.

metal objects—The main antenna always points downwards,

but the orientation of the secondary antenna is adjusted to suit

site conditions. Point it away from metal objects, and make sure

Installation Considerations

• Position the LAR beneath ceiling obstructions—When

Installation Considerations

• Route cables up and away from the LAR—When the cable is

• Install the LAR temporarily until testing is complete—Fasten-

• Point the secondary antenna into a clear area, away from

it is not running parallel to cabling in the ceiling.

Specifi cations table.

the communication and power cable to allow for adjustments in

the location of the LAR.

cause component or system failure, or both, and will void the

warranty.

Installing the LAR

• Observe temperature and humidity restrictions—Refer to the

• Leave slack in the cable—Leave at least 10 ft. (3 m) of slack in

• No user adjustments to internal circuitry—Tampering may

Installing the Exciter

the facility fl oor plan indicating the LAR’s position and network

wiring path. Use the tear-away sticker on the LAR’s Neuron ID

label.

The steps below correspond to the numbers in Figure 1.

1 Record the LonWorks ID number.

Locate and record the LonWorks identifi cation number onto

2 Remove the Mounting Plate from the LAR.

and power supply wires through the hole in the Mounting Plate.

(For other installations, the wires are passed through the slot on

If the LAR is to be installed to a receptacle box, pass the network

the side of the LAR case in Step 5.)

Power Supply to the terminals. If the LAR is at the end of the

3 Wire the terminal block.

Connect the LonWorks Network IN, Network OUT, and

network, then terminate the network segment with Item A

(105 Ω terminator). Ensure there is at least 10 ft. (3 m) of slack

in the cable to allow the possible repositioning of the LAR.

4 Install the Mounting Plate.

Do not place near metal objects and structural frames. Ensure

that the service light will be visible and that space is allowed for

the antennas. Unless there is a conduit tray, run the cables at least

Referring to the facility fl oor plan, decide the position of the LAR.

1 ft. (30 cm) up and away from the LAR.
