1
XT-1010 User Guide
Model: XT-1010
FCC ID: GKM-XT1000
IC: 10281A-XT1000
Version 1.1
2
Table of Contents
Document Change History .......................................................................................... 3
1. Introduction ........................................................................................................... 4
1.1 Feature Matrix................................................................................................................................................................................. 4
2. Hardware Description ............................................................................................. 5
2.1 Hardware Specifications ............................................................................................................................................................. 6
2.2 Cable Harness Description......................................................................................................................................................... 6
2.3 LED Description.............................................................................................................................................................................. 7
3. Device Mounting Options: ...................................................................................... 7
3.1 Screw Mounting.............................................................................................................................................................................. 7
3.2 Magnetic Mounting........................................................................................................................................................................ 8
3.3 VHB Tape Mounting...................................................................................................................................................................... 8
4. Quick Start Guide.................................................................................................... 9
4.1 Device Installation......................................................................................................................................................................... 9
4.2 Pairing the XT1010Z and the XT4860G5 ...........................................................................................................................10
4.3 Unpairing Devices........................................................................................................................................................................10
3
Document Change History
Revision
Date
Author
Changes
1.0
8/28/2014
Johnny Chen
Document Creation
1.1
9/2/2014
Johnny Chen
Revision Based on Nader’s Feedback
4
1. Introduction
The XT-1010 is a wireless ZigBee sensor that pairs with the XT-4860G5 generally known as the Base
Unit to provide inclination data based on a 3-axis digital accelerometer readout with an accuracy of
±1 degree. Additional general purpose digital IO sensors can also be queried and transmitted to the
XT-4860G5. The XT-1010 leverages a high efficiency solar energy harvesting platform to support long
term, remote deployments without the burden of frequent battery replacement. This installation
guide describes the physical hardware, associated parts, mounting options, and a quick start-up
procedure.
1.1 Feature Matrix
Feature Description
XT-1010
High Efficiency Solar Panel
6600mAh Rechargeable Li-Ion Battery
Diagnostic LEDs
Optional Digital IO Sensors and 1-Wire Serial Bus
ZigBee pairing with XT-4860G5
Inclinometer Data based on 3-axis Dig Accel. with 1 deg. accuracy
Over-the-air FW upgrade via XT-4860G5
