Xiaomi ZMI 10, QB820! User Manual

ZMi 10 power bank
Read the instructions carefully before using the device.
Safety label instructions
also forbidden to place it in water, in a re or expose it to a temperature
above 60 ° C (140 ° F).
Each genuine portable battery has a protective label on the outside of the
package. Please erase a special cover and enter your code at o󰀩cial
website.
The company-manufacturer: LLC «ZMI Electronic Technology» Address: Jiangsu Province, 159 Cheng Jiang Central Road, A913.
Before using the battery for the rst time, fully charge it.
• When the battery is used, a display of a digital device should light up, this indicates a correct operation of the device.
You can select the cable yourself to charge this battery or to charge other devices.
• If the LED indicators do not light up while charging the digital device, the battery is completely discharged. Please charge it right away.
• When the digital device is connected to the battery, the charge of this portable charger is being charged.
After fully charging the battery, immediately unplug it from a power supply.
• If a short-circuit on the battery output or for other reasons the protection mode activates (after the LED button is pressed, the indicators do not light), charge it with external power supplies, and then it will return to normal operation.
Attention
This device is equipped with a lithium-ion battery. It is strictly forbidden to disassemble a case of the device, in order to prevent the battery from breaking.
USB port input
Mode indicator:
Double-click the charge check button to turn on the HUB mode. The blue indicator indicates a successful activation of the HUB mode, absence of a blue indicator indicates
that the HUB mode is turned o󰀨.
Caution: «Charge level check» button is
not designed to turn the device on / o󰀨. This
device has a function of automatic detection of charging and discharging, so there is no need to constantly press the charge level check button. Two minutes before the discharge, the charge level indicators turn
o󰀨.
USB port output
Charge level indicators
Charge level check
Mode indicators
Strictly prohibited any dismantling, squeezing, puncturing the device; It is
Features of the device
Specications
Safety: Portable ZMI power bank has a reliable protection system. If the battery is charged, discharged or in standby mode, it can easily cope with overcharging, excessive battery discharge, high temperature, short circuit and many other non-standard situations. ZMI power bank provides reliable protection for your digital portable equipment.
High performance: ZMI power bank is equipped with fast charging technology, supports a wide two-way range of input and output voltage USB-C PD 5V / 20A, maximum power is 45W.
Compatibility: ZMI power bank is equipped with the built-in technology of Smart USB Control Charge, it is compatible with many smartphones, other digital devices and many portable power supplies, it is possible to increase the voltage to 9V / 12V.
Quality: A choice of LG and other lithium-ion batteries *, Intersil and other manufacturers of charge-discharge microcircuits.
Overview of the device
Thank you for choosing our products. This device is a high-quality portable battery, which uses a lithium-ion battery from LG and charge-discharge chip from the best international company-manufacturer of integrated circuits
Intersil. Special performance indicators: security, e󰀩ciency, compatibility
with other devices, etc.
Model: QB820; Battery type: Li-ion battery; Battery Capacity: 9750mAh / 10 000mAh 7.2V 70.2Wh / 72Wh (MIN / TYP); Limiting voltage: 8.4V; Operating temperature range 0 ° C - 45 ° C; Size: 160 x 81.8 x 21 mm; Input voltage: 5-20V / MAX 45W; Output voltage: MAX 45W; USB-C 5-20V / MAX 40W; 2 USB-A x 5.0V / 2.4A, 9-0V / 2.0A,
12.0V / 1.5A / MAX 18W.
Charging time: about 3.8 hours (5-20V / 45W USB PD charger); About 5.5 hours (9V / 2A 12V / 1.5A with charging cable); About 8.7 hours (5V-2A charger with charging cable).
Charging
Connect the power adapter to charge the battery. During charging, the status indicators display a charge level as follows:
Note: * Zimi reserves the right to supply products of similar quality and technical
specications.
