Mi Laser Projector 150" User Manual
Table of Contents
To users FCC Statement WEEE FDA IC CE Laser Safety Information Important Safety Information List of Items Introduction to the Product's Exterior Connectors and Ports Power Indicator Projection Range and Projection Screen Dimensions Remote Quick Start Introduction Safety and Protection Audio Mainboard Upgrades Smart Temperature Control Daily Maintenance Technical Specifications FAQ s Product Certification
Note:
- This manual is applicable to the following model: MJJGYY02FM.
- There may be a slight difference between the actual menu and the menu display featured in this manual. Please refer to the menu as it appears to you.
Manual Version: Rev01
4 4 4 5 5 5 6 7
9 10 11 12 13 14 15 17 18 19 19 20 21 23 24
3
To users:
Thanks for choosing the Mi Laser Projector 150". Read this manual carefully before use, and retain it for future reference.
FCC Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement.The device can be used in portable exposure condition without restriction. FCC ID:
WEEE
WEEE Disposal and Recycling Information Correct Disposal of this product. This marking indicates that this product should not be disposal with other household wastes through out the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsible to promote the sustainable reuse of materials resources. To return your used device, please use the return and collection systems or contact the retailer where the product was purchased. They can take this product for environmental safe recycling.
4
FDA
Complies with 21 CFR1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007.
IC
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le present appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisee aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et. (2) l'utilisateur de l'appareil doit accepter tout brouillage radioelectrique subi, meme si le brouillage est susceptible d'en compromettre le fonctionnement.
CE
We Xiaomi Communications Co.,Ltd, Hereby, declares that this equipment is in compliance with the applicable Directives and European Norms, and amendments. For MJJGYY02FM Bluetooth Frequency range: 2400MHz-2483.5 MHz
Maximum Output Power:
Wi-Fi 2.4G Frequency range: 2400MHz-2483.5 MHz
Maximum Output Power:
Wi-Fi 5G Frequency range: 5150MHz-5350MHz
Maximum Output Power:
Frequency range: 5470MHz-5725MHz
Maximum Output Power:
The WLAN function for this device is restricted to indoor use only when operating in the 5150 to 5350 MHz frequency range.
Note:
- The distance required between a person and the projector must be ≥ 20cm.
5
Laser Safety Information
Mi Laser Projector 150"
Product Name: Mi Ultra-Short Range Laser Projector Model: MJJGYY02FM Rated Voltage: 100-240V~ Rated Frequency: 50/60Hz
Rated Current: 2A Product Weight: 6.9kg
Dimensions: 410x291x88mm
Manufactured by: Fengmi(Beijing)Technology Co., Ltd Address: 301,3F,Building3,No.10,Shunyi District Renhe Town Barracks South Stree,China
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation. FCC ID: CAN ICES-3 (B)/NMB-3(B) ICID:
Complies with 21 CFR1040.10 and 1040.11 except for deviations pursuant to Laser
Mi Laser Projector 150"
Product Name: Mi Ultra-Short Range Laser Projector Model: MJJGYY02FM
Rated Voltage: 100-240V~
Rated Frequency: 50/60Hz
Rated Current: 2A Product Weight: 6.9kg
Dimensions: 410x291x88mm
Manufactured by: Fengmi(Beijing)Technology Co., Ltd Address: 301,3F,Building3,No.10,Shunyi District Renhe Town Barracks South Stree,China
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation. FCC ID: CAN ICES-3 (B)/NMB-3(B) ICID:
Complies with 21 CFR1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007
Notice No. 50, dated June 24, 2007
CLASS 1
LASER PRODUCT
Made in China
LASER PRODUCT
Made in China
CLASS 1
Warning:
- A failure to follow the following safety advice may result in damage to the eyes and skin.
- You must never directly look at the laser projector lens or output. Its extreme level of brightness can cause irreversible eye damage. Ensure that the laser projector's casing remains intact while the projector is in use to avoid ultraviolet radiation. We recommend the use of protective safety equipment and safety goggles whenever undertaking repairs or maintenance.
- You must not, under any circumstances, open the laser's protective casing when it is operating.
- You cannot allow any reflective objects to go near the path of the laser beam.
Mi Laser Projector 150" Nameplate
Class 1 Laser Information Label Radiation output and standards information Max output of laser radiation: Pulse duration: Emitted wavelength(s): Name and publication date of the standard:
RG1 Label RG1 IEC 62471-5:2015
6
Important Safety Information
Ensure that you carefully read the following important safety information and all product labels before using this product.
Safety Label Description
This label warns users that this product contains non-insulated voltage sources which can cause electric shock. Hence, there is a danger of electric shock should you come into any kind of contact with any component within.
This label alerts users to critical handling and maintenance related information. Please ensure that you read this information carefully to avoid any errors.
This alerts users to be aware of high temperatures.
This label alerts users to keep their hands or other body parts away.
Grounding Warning This product must be grounded when used.
Transport Instructions
You are advised to transport this product in its original packaging or equivalent, identical packaging.
7
Guarding Against Electric Shocks and Fire Hazards
- Use of improper electric cables may result in decreased product performance and even electric shock or fire, and so forth. Ensure that you use the product's original electric cabling or an identical equivalent when using this product to preserve performance and safety.
- Should you use a cable extension cord, then you must ensure that it does not have a lower current rating than the product's original cable. If you do not, then the cable may overheat and cause an accident such as an electric shock, fire, and so on.
- Ensure that you disconnect the cable from the power socket during a lightning storm or if you have not used this product for an extended length of time to avoid damage from a lightning or power line surge.
- Ensure that you do not place any flammable items near this product to guard against fire hazards.
-
Do not allow any object to come into contact with the lens while the device is operating or it may result in the object becoming very hot or
deformed, which may result in a fire.
- Do not allow any items to be placed near vents or the heat dissipation vent to avoid a buildup of heat within the product, which may result in a fire.
Safe Operating Instructions
- Do not allow this product to be used while on an unstable platform, frame, or table to protect against serious damage to the device or injury to those nearby should the product fall.
- Never look directly at the lens or heat dissipation vent while the device is operating to avoid eye damage.
- Do not attempt to take this product apart as there are dangerous high voltage components inside that can cause injury. This product must be maintained and repaired by highly experienced or authorized repair personnel should repairs be necessary.
- Do not place this product upright or it may easily fall over and cause injury or suffer damage.
- Do not allow this product to come into contact with water droplets or moisture (this product must operate in an environment with 20-80% humidity).
- Do not immerse this product in, nor expose it to, water or any other liquid. Immediately unplug this device should any liquids or hard objects enter into its casing, and immediately request for a professional technician to conduct an inspection before continuing to use the device.
- Do not allow the device to be placed in the following kinds of environments:
● In an area with poor ventilation or a narrow space.
● Near any device with a strong magnetic field.
● Where it is directly exposed to the sun.
● Near a fire alarm.
● In a very hot, cold, or moist environment.
8
