XIAOKOA
®
2.4G Wireless Microphone
User Manual
(N-80 Headset)
Page 2
Features
The wireless microphone uses 2.4g technology,
which features signal stability, plug and play, long
distance amplification etc. It is compatible with a
variety of loudspeakers, amplifier equipment,
outdoor audio equipment, etc.
Product Overview
3.5 mm Microphone
audio output jack
Charging status
indicator
Charging jack
Figure1
(Wireless Transmitter)
Working status indicator
Charging jack
Power switch
Charging status
Power
switch
Volume
indicator
Working status
indicator
Mic
Page 3
1.
How to set up on amplifier
Headset and receiver connection method
1 2
.
Mic-in jac k for 3 .5mm
3
Mic-in jac k for 6 .35mm
Page 4
How to dissemble
Step 2: Use 2 thumb to press down
the Headset holder at the
same time.
Step 1
How to Assem ble
Step 3
:
After remove it, the
headphone will
separate out.
Step 4
:
When wan to assemble,
there will be a joint and
allign it by using 2 thumb
to push it up.
Page 5
1.
Product Parameler
1. Why does t he microph one whistle when
working ?
Keep the microphone away from loudspeaker,
and do not block the transmitter and receiver.
2. Why can' t the microp hone be connected to
the louds peaker?
Make sure the power of the receiver and
transmitter is sufficient, and the pairing is
successful.
3. How long d oes the micr ophone charge and
work?
Fully charged for 2-3 hours, it can usually be
used for about 4-5 hours. When the blue light
flashes rapidly during use, it indicates that the
battery is low. please charge immediately.
Page 6
Introduction
Thank you for purchasing this wireless
microphone, please read this user manual
carefully.
Tips
The product must be set up on windows first and
secondly turning on the recording software.
Specification
Sampling Frequency
Modulation Method
The Speaker size
RF Transmission power
Transmission Distance
RX Sensitivity
S/N Ratio
16KS/s
GFSK
3 inch
10dbm
40m
-88dbm
≥65db
Page 7
Einführung
Vielen Dank für den Kauf dieses drahtlosen
Mikrofons. Bitte lesen Sie diese
Bedienungsanleitung sorgfältig.
Tipps
Das Produkt muss zuerst auf Windows und
zweitens auf die Aufnahmesoftware eingestellt
werden.
Specification
Abtastfrequenz
Modulationsmethode
Die Lautsprechergröße
RF Sendeleistung
Übertragungsdistanz
Empfangsempfindlichkeit
S/N-Verhältnis
16KS/s
GFSK
3 Zoll
10dbm
40m
-88dbm
≥65db
Page 8
Introduction
Merci d'avoir acheté ce microphone sans fil,
veuillez lire attentivement ce manuel
d'utilisation.
Conseils
Le produit doit être installé sur Windows d'abord
et ensuite sur le logiciel d'enregistrement.
Specification
Fréquence d'échantillonnage
Méthode de modulation
La taille du haut-parleur
RF Puissance de transmission
Distance de transmission
Sensibilité RX
Rapport S/N
16KS / s
GFSK
3 pouces
10 dBm
40m
-88dbm
≥65db
Page 9
Introduzione
Grazie per aver acquistato questo microfono
wireless, leggere attentamente questo manuale
utente.
Suggerimenti
Il prodotto deve essere prima installato su
Windows e successivamente acceso il software
di registrazione.
Specification
Frequenza di campionamento
Metodo di modulazione
Dimensione dell'altoparlante
Potenza di trasmissione RF
Distanza di trasmissione
Sensibilità RX
Rapporto S/N
16KS / s
GFSK
3 pollici
10dBm
40m
-88dBm
≥65dB
Page 10
Introducción
Grazie per aver acquistato questo microfono
wireless, leggere attentamente questo manuale
utente.
Consejos
El producto debe configurarse en Windows
primero y luego encender el software de
grabación.
Specification
Frecuencia de muestreo
Método de Modulación
El tamaño del altavoz
Potencia de transmisión de RF
Distancia de transmisión
Sensibilidad RX
Relación S/N
16KS/s
GFSK
3 pulgadas
10dbm
40 m
-88dbm
≥65db
