WARNING: This device should never be used
on live electrical circuits. It is not protected
against electrical shock! This tool is not to be
used for purposes other than intended. Read
carefully and understand the instructions
before using this device.
Features and Benefits
Cable Continuity Testing
The XProTec Cable Tester is a cable continuity tester for
identifying cables in multi-run installations. The cable tester
uses the Cable
Tester to place a DC current through one end
of the desired cable and identifies the cable at the other end
with the Detachable Tone Detector.
Short Circuit Testing
This device is equipped with a Short Circuit Detector LED
located on the head of the Cable
Tester. If a DC short circuit
exists in the cable being tested, the LED will illuminate. Many
high quality splitters used for multi-run installations are short
circuits to DC. If these splitters are in line with the cable being
tested, the LED will illuminate.
Precautions Before Use
Page 6
XProTec Cable Tester with Universal Connector Kit - Operation Manual
4
Equipment Supplied
The XProTec Cable Tester includes the following:
• Cable Tester with Short
Circuit Detector
•
Detachable Tone Detector
• Carrying Case
• Printed Operation Manual
• F Type Adapters (Qty 7)
• BNC Adapters (Qty 6)
• RCA Adapters (Qty 4)
• RJ-11 Adapters (Qty 2)
• RJ-45 Adapters (Qty 2)
Page 7
XProTec Cable Tester with Universal Connector Kit - Operation Manual
5
A Guided Tour of Your Equipment
Cable Tester Unit
The XProTec Cable Tester consists of the following components:
Male F Type Push-On Connector
Battery Access Cap
Detachable Tone Detector
Short Circuit Detector LED
Cable Tester
Page 8
XProTec Cable Tester with Universal Connector Kit - Operation Manual
6
BNC Adapters
The following BNC Adapters are included:
• Qty 2 - BNC Male to F Type
Female
•
Qty 2 - BNC Female to F Type
Female
• Qty 2 - BNC Female to F Type
Male
F Type Adapters
The following F Type Adapters are included:
• Qty 2 - F Female to F Male
Push-On
•
Qty 2 - F Female to F Female
• Qty 3 - F Male to F Male
Page 9
XProTec Cable Tester with Universal Connector Kit - Operation Manual
7
RJ-11 Adapters
The following RJ-11 Adapters are included:
• Qty 2 - RJ-11 Male
to F Male Push-On
RJ-45 Adapters
The following RJ-45 Adapters are included:
• Qty 2 - RJ-45 Male
to F Male Push-On
RCA Adapters
The following RCA Adapters are included:
• Qty 2 - RCA Male to F Female
•
Qty 2 - RCA Female to F Male
Page 10
XProTec Cable Tester with Universal Connector Kit - Operation Manual
8
Battery Installation
The XProTec Cable Tester includes one (1) 1.5 V AAA sized
battery. To install the battery, perform the following steps:
1. Remove the battery access cap at the bottom of the
Cable
Tester by turning it counter-clockwise.
2. Insert the included battery positive (+) side first into the
body of the Cable Tester.
3. Replace the battery access cap.
Operation
To test a cable run, perform the following steps:
1. Remove the Detachable Tone Detector
from the bottom of the Cable
Tester by
turning it counter-clockwise.
2. Attach the Cable Tester to the destination
end of the cable run.
3. Attach the Detachable Tone Detector to
each one of the cables at the home run
cable location. Once the proper cable is
found, a tone will sound.
Page 11
XProTec Cable Tester with Universal Connector Kit - Operation Manual
9
Testing Cables
RG-59/U & RG-6 Coaxial Cables
The following example illustrates the configuration of adapters
needed when testing coaxial cables with two (2) male ends.
This configuration uses the following adapters:
• Qty 1 - F Female to F Female
Tone Detector Cable End
Cable Tester Cable End
Page 12
XProTec Cable Tester with Universal Connector Kit - Operation Manual
10
BNC Cables (Male to Male)
The following example illustrates the configuration of adapters
needed when testing BNC cables with two (2) male ends. This
configuration uses the following adapters:
• Qty 1 - BNC Female to F Type Female
•
Qty 1 - BNC Female to F Type Male
Tone Detector Cable End
Cable Tester Cable End
Page 13
XProTec Cable Tester with Universal Connector Kit - Operation Manual
11
BNC Cables (Female to Female)
The following example illustrates the configuration of adapters
needed when testing BNC cables with two (2) female ends.
This configuration uses the following adapters:
• Qty 2 - BNC Male to F Type Female
•
Qty 1 - F Male to F Male
Tone Detector Cable End
Cable Tester Cable End
Page 14
XProTec Cable Tester with Universal Connector Kit - Operation Manual
12
RCA Cables (Male to Male)
The following example illustrates the configuration of adapters
needed when testing RCA cables with two (2) male ends. This
configuration uses the following adapters:
• Qty 2 - RCA Female to F Male
•
Qty 1 - F Female to F Female
Tone Detector Cable End
Cable Tester Cable End
Page 15
XProTec Cable Tester with Universal Connector Kit - Operation Manual
13
RCA Cables (Female to Female)
The following example illustrates the configuration of adapters
needed when testing RCA cables with two (2) female ends.
This configuration uses the following adapters:
• Qty 2 - RCA Male to F Female
•
Qty 1 - F Male to F Male
Tone Detector Cable End
Cable Tester Cable End
Page 16
XProTec Cable Tester with Universal Connector Kit - Operation Manual
14
Telephone Cables (RJ-11)
The following example illustrates the configuration of adapters
needed when testing wired telephone plugs. This configuration
uses the following adapters:
• Qty 2 - RJ-11 Male to F Male Push-On
•
Qty 1 - F Female to F Female
Tone Detector Cable End
Cable Tester Cable End
Page 17
XProTec Cable Tester with Universal Connector Kit - Operation Manual
15
Network Cables (RJ-45)
The following example illustrates the configuration of adapters
needed when testing wired network plugs. This configuration
uses the following adapters:
• Qty 2 - RJ-45 Male to F Male Push-On
•
Qty 1 - F Female to F Female
Tone Detector Cable End
Cable Tester Cable End
Page 18
XProTec Cable Tester with Universal Connector Kit - Operation Manual
16
Warranty Information
