Page 1
X – 6 SQUARED
K 021 KIT
INSTRUCTION MANUAL
Version 1.0
X – 6 SQUARED KIT
K021 Instructions v1.0 First Things Page 1
Page 2
CONTENTS
First Things…………………………………….. 3
A Front Arms & Hubs………………………… 5
B Complete The Front End…………………. 12
C Differential…………………………………. 20
D Transmission………………………………. 25
E Transmission Installation…………………. 32
F Build the C-CVDs…………………………. 38
G Rear Control Arms……………………….. 43
Build The Shocks …………………………….. 48
H Rear Tower, Shocks,Turnbuckles………. 55
I Finish It Up………………………………….. 62
Final Set-Up & Prep…………………………… 70
Tuning Section…………………………………. 73
Parts List……………………………………….. 83
K021 Instructions v1.0 First Things Page 2
Page 3
X – 6 SQUARED ASSEMBLY INSTRUCTIONS
FIRST THINGS FIRST
A) ASSUMPTIONS These instructions assume several things:
1. You have at least some experience building R/C cars. These
instructions are not written for a first-timer.
2. You have the usual assortment of R/C tools.
If you do not meet both assumptions above, please contact us.
Contact information is on Page 4.
B) We suggest you have a clean, well-lighted work area.
C) Before threading screws or ball studs into plastic parts, tap the hole with a
4-40 tap.
D) All references to right and left are from the viewpoint of the driver sitting in
the car facing forward.
E) This Kit contains many parts; most are supplied by X Factory, others are
genuine Team Associated parts. A complete parts list is at the end of this
manual.
F) Many AE parts are supplied on “trees.” When you remove those parts from
the trees, we suggest you do so with a twisting motion to reduce flashing
on the parts, then dress the parts with a file prior to assembly.
G) To photograph this manual, we assembled the car several times. In some
photos, parts you have already assembled are “missing.” This was done
deliberately so you may clearly see this particular step. Follow the steps in
order and you’ll get to the end quickly.
K021 Instructions v1.0 First Things Page 3
Page 4
SOME IMPORTANT INFORMATION
WELCOME TO THE
This is the first time we have made the entire Kit – always before we have made
Conversion Kits. We know we are not perfect. If you experience the slightest
difficulty assembling your X – 6 Squared – if you have trouble with an instruction
or if something does not fit properly – please contact us immediately. Even if you
figure out what needs to be done or modify the part to fit, we will make changes
to help the next person.
Here at X Factory we do not have customers. You have become a member of a
world-wide Family of R/C racing enthusiasts who love working on their cars,
trying new things, helping each other at the track, and winning races. The Family
constantly gives us ideas for new products or improvements to existing products.
We welcome and encourage this input. Thanks in advance for your help!
These instructions are available on our
Web site, www.xfactoryrc.com in the
Tech section. Many of the color photos
on the web are better than the black
and white versions here. You are
welcome to download all or any part
of the website manual.
THANK YOU FOR YOUR
CONFIDENCE IN
THE NEW MATH!
Chief Engineer and designer
Of the X – 6 Squared
Paul Sinclair (large arrow)
His X – 6 Squared (small arrow)
Snail mail
X Factory R/C Racing Products
P.O. Box 2361
Whitehouse, Ohio 43571 U.S.A.
K021 Instructions v1.0 First Things Page 4
