FRU Parts List 253
FRU Parts List
Parts List Contents
Print Engine
Page
PL 1.1 Covers 256
PL 2.1 Universal Paper Tray 258
PL 3.1 Paper Feed I 260
PL 3.2 Paper Feed II 262
PL 3.3 Paper Feed III 264
PL 4.1 Housing Assembly Retard 266
PL 5.1 Chute Assembly In 268
PL 6.1 Chute Assembly Out 270
PL 7.1 Chute Assembly Exit 272
PL 8.1 Transfer Roller & Fuser Assembly (CRCs) 274
PL 9.1 Xerographics 276
PL 10.1 Holder Toner Cartridge Assembly 278
PL 11.1 Frame and Drive Assemblies 280
PL 12.1 Electrical 282
PL 13.1 Harness Assemblies 284
Optional High-Capacity Feeder
PL 14.1 High-Capacity Feeder Paper Trays 2 & 3 286
PL 14.2 High-Capacity Feeder Covers 288
PL 14.3 High-Capacity Feeder Guides and Turn Chute Assembly 290
PL 14.4 Paper Pick Assembly Trays 2 & 3 292
PL 14.5 High-Capacity Feeder Harness, Board and Motor 294
Supplies and Accessories
PL 15.1 Xerox Supplies and Accessories 296
254 Phaser 6200 Color Laser Printer - Service Manual
Changes to Xerox products are made to accommodate improved components as they
become available. It is important when ordering parts to include the following
information:
■ Component's part number
■ Product type or model number
■ Serial number of the printer
Serial numbering. Particular fields in the serial number indicate the modification
level of the printer, the date of its manufacture and the sequence number of the printer
produced on that day. The serial number is coded as follows:
■ The text “S/N” followed by the serial number in the barcode.
■ The barcode does not include a field identifier.
■ The nine digit serial number is based on the following format:
PPPRSSSSS
R - Single digit numeric revision digit. To be rolled when a major product change occurs. Initiated
with a change request.
SSSSS - Five digit numeric serial number.
Serial Number Example:
LPH453072:
LPH = Product code for the 110V Printer
4 = Revision level
53072 = Serial number
PPP = Three digit alphanumeric product code
Product Model Voltag e Product Code
6200 N 110V LPH
6200 DP 110V LPH
6200V N 220V LPK
6200V DP 220V LPK
FRU Parts List 255
Using the Parts List
1. No. = The callout number from the exploded part diagram.
2. Part Number = The material part number used to order specific parts.
3. Qty = This number represents the parts per printer, not the number of parts
supplied in the actual part order.
4. Name/Description = Details the name of the part to be ordered and the number of
parts supplied per order.
5. Parts identified throughout this manual are referenced PL#.#.#; For example,
PL3.1.10 means the part is item 10 of Parts List 3.1.
6. A black triangle preceding a number followed by a parenthetical statement in an
illustrated parts list means the item is a parent assembly, made up of the individual
parts called out in parentheses.
7. The notation “with X~Y” following a part name indicates an assembly that is
made up of components X through Y. For example, “1 (with 2~4)” means part 1
consists of part 2, part 3, and part 4.
8. An asterisk (*) following a part name indicates the page contains a note about this
part.
9. The notation (NS) next to a part indicates that pariticular part is not spared, but
contained in a kit or major assembly.
10.The notation “J1<>J2 and P2” is attached to a wire harness. It indicates that
connector Jack 1 is attached to one end of the wire harness and connector J2 is
attached to the other end that is plugged into P2.
Note: Only parts showing part numbers are available for support.
Parts not showing part numbers are available on the parent
assembly.
Legend:
Identifier Meaning
C C-ring
E E-ring
KL K-clip
S Screw
256 Phaser 6200 Color Laser Printer - Service Manual
PL 1.1 Covers
S6200-228
FRU Parts List 257
PL 1.1 - Covers - FRU Parts List Table
No. Part Number Qty Name/Description
1 333-4382-00 1 Control Panel (Front Panel Display)
2 116-0003-00 1 Cover Assembly, Front (with 3-7)
3 1 Cover, Front (NS, part of PL 1.1.2)
4 1 Holder, Lever Out (NS)
5 1 Lever Out (NS)
6 1 Con. Amp 175694-3 (NS)
7 116-0004-00 1 Fan, Fuser
8 116-0005-00 1 Cover Assembly, Top
9 116-0006-00 1 Cover, Top Main
10 116-0007-00 1 Cover Assembly, Top Image Unit (with11-19) (Door C)
11 1 CAM I/R (NS)
12 1 Cover, CAM (NS)
13 116-0010-00 1 Spring, CAM I/R
14 116-0011-00 1 Latch, Top Right
15 1 Handle, Top (NS)
16 1 Shaft Latch, Top (NS)
17 1 Spring, Handle (NS)
18 116-0014-00 1 Latch, Top Left
20 116-0016-00 1 Cover, Rear
21 116-0492-00 2 Stud, Top (1 per order)
22 116-0586-00 2 Spring, Link (1 per order)
23 116-0963-00 2 Link (1 per order)
24 116-0974-00 1 Cover, Side, Right
25 116-1322-00 1 Cover Assembly, Front Right
26 1 Cover, Multi-Purpose Tray (NS, part of Multi-Purpose Tray
99)
27 1 Multi-Purpose Tray Slide (NS, part of Multi-Purpose Tray
99)
28 116-1325-00 1 Assembly, MPT ,Base
29 116-1326-00 1 Cover Assembly, Front Left
30 116-1327-00 1 Cover, Side, Left
31 1 Cover, Top Stopper (NS)
99 116-1329-00 1 Tray, MPT(with 26 and 27)
258 Phaser 6200 Color Laser Printer - Service Manual
PL 2.1 Universal Paper Tray
S6200-229
5
4
2
3
6
FRU Parts List 259
PL 2.1 Tray, Univeral Paper - FRU Parts List Table
ID No. Part Number Qty Name/Description
1 116-1330-00 1 Universal Paper Tray (with 2~6)
2 116-1331-00 2 Paper Feed Roller Kit*
*(2 interchangeable rollers per order)
3 116-1332-00 1 Assembly, Friction Clutch
4 1 Holder, Retard (NS)
5 116-1334-00 1 Spring, Retard
6 1 Cover, Front Tray (NS)
260 Phaser 6200 Color Laser Printer - Service Manual
PL 3.1 Paper Feed I
S6200-230
1
2
4
4
4
5
5
5
5
3
FRU Parts List 261
PL 3.1 Paper Feed - FRU Parts List Table
ID No. Part Number Qty Name/Description
1 116-1335-00 1 Cover, Feeder, Front
2 116-1336-00 1 Assembly, Turn Chute
3 116-1337-00 1 Cover, Paper Tray, Rear
4 116-1338-00 3 Block (1 per order)
5 212-0237-00 4 Long Screw (M3 x 85) Kit (2 per order)
262 Phaser 6200 Color Laser Printer - Service Manual
PL 3.2 Paper Feed II
S6200-231
FRU Parts List 263
PL 3.2 Paper Feed II - FRU Parts List Table
ID No. Part Number Qty Name/Description
1 116-1340-00 1 Assembly, Harness, Temperature/Humidity
(J231~J2361)
2 116-1341-00 1 Sensor, Temperature/Humidity
3 116-1342-00 1 Asssembly, Harness, LTA (HCF) (J210~P810)
4 116-1343-00 1 Assembly, Paper Size Switch
5 116-1344-00 4 Printer Feet (4 per order)
7 116-1345-00 1 Lever, Low Paper
8 116-1346-00 1 Indicator, Paper Level
9 116-1347-00 1 Indicator, Holder, Shaft
10 116-1348-00 1 Indicator, Guide
11 116-1349-00 1 Indicator, Spring
12 116-1350-00 1 Indicator, Shaft
13 116-1351-00 1 Paper Tray Stopper
264 Phaser 6200 Color Laser Printer - Service Manual
PL 3.3 Paper Feed III
S6200-247
FRU Parts List 265
PL 3.3 Paper Feeder III - FRU Parts List Table
ID No. Part Number Qty Name/Description
1 116-1352-00 1 Assembly, Paper Pick (with 2~24)
2 1 Shaft, Feed 1 (NS)
3 116-1353-01 2 Paper Pick Roller Kit (2 per order)
4 116-1354-00 1 Sensor, (No Paper, Low Paper)
5 116-1355-00 1 Actuator, No Paper
6 116-1356-00 1 Actuator, Link
7 3 Bearing - Metal (NS)
8 1 Gear, Feed 1 (NS)
9 1 Spring, Feed 1 (NS)
10 1 Spring, Feed H (NS)
11 1 Gear, Feed H2 (NS part of 99)
12 1 Gear, Feed H1 (NS part of 99)
13 1 Gear, Feed 2 (NS part of 99)
14 1 Gear, Idler Feed (NS part of 99)
15 1 Gear, Idler (NS part of 99)
16 1 Clutch Stopper (NS)
17 116-1361-00 1 Feed Solenoid
18 116-1362-00 1 Assembly, Clutch Turn
19 1 Gear, Idler In (NS part of 99)
20 116-1363-00 1 Assembly, Roll Turn
21 3 Bearing - Black (NS)
22 1 Shaft, Feed 2 (NS)
23 116-1331-00 2 Paper Feed Roller Kit*
*(2 interchangeable rollers per order)
24 116-1366-00 1 Assembly, Harness, Feeder
(J47-J471/J472/J473/P474/P475)
99 116-1367-00 1 Paper Feed Gear Kit (with 8, 11~15 and 19)
266 Phaser 6200 Color Laser Printer - Service Manual
PL 4.1 Housing Assembly Retard
S6200-232
FRU Parts List 267
PL 4.1 Assembly, Housing Retard - FRU Parts List Table
ID No. Part Number Qty Name/Description
1 116-1368-00 1 Assembly, Housing Retard (with 2~13)
2 1 Roll, Turn (NS)
3 1 Shaft, Retard (NS)
4 116-1370-00 1 Assembly, Friction Clutch
5 116-1371-00 1 Assembly, RetardRoll
6 1 Holder, Retard (NS)
7 1 Housing, Retard (NS)
8 1 Bearing (NS)
9 116-1374-00 1 Turn Clutch
10 1 Stud, Retard (NS)
11 1 Spring, Retard 370 (NS)
12 1 Cap, Retard (NS)
13 1 Bearing, Ground (NS)
268 Phaser 6200 Color Laser Printer - Service Manual
PL 5.1 Chute Assembly In
S6200-233
FRU Parts List 269
PL 5.1 Chute Assembly, In - FRU Parts List Table
ID No. Part Number Qty Name/Description
1
1a
1b
116-1379-00
116-1380-00
1
1
Chute Assembly, In (with 2~30)
120 V
220 V
2 116-1381-00 1 Assembly, Wiring 2nd BTR (J5020)(Transfer Roller)
3 116-1382-00 1 Spring, 2nd BTR
4 116-1383-00 1 Shaft, BTR IN
5 116-1384-00 1 Assembly, Wire Disk (J5030)
6 116-1385-00 1 Spring, DTC
7 116-1386-00 1 Stud, 2nd BTR
8 116-1387-00 1 Spring, Holder BTR
99a9b116-1388-00
116-1389-00
1
1
Assembly, Harness Fuser 100 V / 120 V (FSR 2)
Assembly, Harness Fuser 220 V (FSR 22)
10 116-1390-00 1 Assembly, Harness CTD (ADC)
11 116-1391-00 1 Assembly, Sensor CTD (ADC)
12 116-1392-00 1 Spring, ADC
13 116-1393-00 1 Sensor, Toner Full
14 116-1394-00 1 Assembly, Harness Toner Full SNS
15 116-1395-00 1 Spring, IDT
16 116-1396-00 1 Stud, IDT
17 116-1397-00 1 Holder, IDT
18 116-1398-00 1 Assembly, Drive Fuser
19 116-1399-00 1 Spring, BTR
20 116-1400-00 1 Wire Assembly, FSR Earth GRND
21 116-1401-00 1 Right Latch
22 116-1402-00 1 Spring, Latch
23 1 Shaft, Latch (NS)
24 116-1403-00 1 Plate, In T/R
25 116-1404-00 2 Roll, Pinch Turn (1 per order)
26 116-1405-00 2 Spring, Pinch Turn (1 per order)
27 116-1406-00 2 Roll, Pinch Dup (Duplex) (1 per order)
28 116-1407-00 1 Spring, Pinch Dup (Duplex)
29 116-1408-00 1 Chute, In (Duplex)
30 116-1409-00 1 Left Latch
270 Phaser 6200 Color Laser Printer - Service Manual
PL 6.1 Chute Assembly Out
PL 6.1 Chute Assembly, Out - FRU Parts List Table
ID No Part Number Qty Name/Description
1 116-1410-00 1 Assembly, Chute Out (with 2~43)
2 116-1411-00 1 Assembly, Harness, Front 2
S6200-234
FRU Parts List 271
3 116-1412-00 1 Assembly, Harness, Front Panel
4 116-1413-00 3 Sensor, (Full Stack, Paper Present) (1 per order)
5 116-1414-00 1 Actuator, Output Tray Full (Full Stack)
6 116-1415-00 4 Spring, Pinch Exit (1 per order)
7 116-1416-00 2 Roll, Pinch Exit (1 per order)
8 116-1417-00 2 Roll, Pinch (1 per order)
9 116-1418-00 1 Eliminator Assembly
10 116-1419-00 1 Gear 30
11 1 Bearing Ground (NS)
12 116-1420-00 1 Roll, Dup (Duplex)
13 116-1421-00 1 Actuator, Duplex
14 116-1422-00 1 Actuator, Cover
15 116-1423-00 1 Spring, Sensor Dup (Duplex)
16 1 Bearing (NS)
17 1 Latch, Plate (NS)
18 1 Latch, Out (NS)
19 1 Latch, Holder (NS)
20 116-1425-00 1 Latch, Spring Out
21 116-1426-00 2 Spring, N/F MPT 250GF (1 per order)
22 116-1427-00 1 Gear, MPT
23 116-1428-00 1 Assembly, Harness Duplex
24 2 Bearing, MPT (NS)
25 116-1430-00 2 CAM, MPT (1 per order)
26 116-1431-00 2 Core, Roll, MPT (1 per order)
27 116-1432-00 1 Assembly, Feed Roll
28 1 Shaft MPT (NS)
35 116-1433-00 1 Plate, Out MPT
36 116-1434-00 1 Sensor, Spring MPT
37 116-1435-00 1 Actuator, MPT
38 116-1436-00 1 Solenoid Stopper
39 116-1437-00 1 Solenoid, Spring
40 116-1438-00 1 Feed Solenoid, MPT
41 1 Chute, Out (NS)
42 116-1439-00 1 Assembly, Bottom Plate, MPT
43 116-1440-00 1 Assembly, Wire, Earth GRND
PL 6.1 Chute Assembly, Out - FRU Parts List Table
ID No Part Number Qty Name/Description
272 Phaser 6200 Color Laser Printer - Service Manual
PL 7.1 Chute Assembly Exit
S6200-235
FRU Parts List 273
PL 7.1 Chute Assembly, Exit - FRU Parts List Table
ID No. Part Number Qty Name/Description
1 116-1441-00 1 Chute Assembly, Exit (with 2~11)
2 2 Gear Roll (NS, part of PL 7.1.99)
3 2 Bearing Earth (NS)
4 116-1442-00 1 Roll, Exit
5 116-1443-00 1 Roll, Mid
6 116-1444-00 1 Chute, Exit Lower
7 2 Bearing (NS)
8 116-1445-00 1 Assembly, Duplex Motor
9 1 Gear, 42 (NS, part of PL 7.1.99)
10 2 Gear, 40/42 (NS, part of PL 7.1.99)
11 2 Gear, 48 (NS, part of PL 7.1.99)
99 116-1446-00 1 Chute Assembly, Exit Gear Kit (with 2,9~11)
274 Phaser 6200 Color Laser Printer - Service Manual
PL 8.1 Transfer Roller & Fuser Assembly (CRCs)
S6200-236
FRU Parts List 275
PL 8.1 Transfer Roller and Fuser - FRU Parts List Table
ID No. Part Number Qty Name/Description
1
1a
1b
016-2014-00
016-2015-00
1
1
110 V Fuser, Phaser 6200 (with 7 and 8)
220 V Fuser, Phaser 6200 (with 7 and 8)
7 116-1447-00 1 Actuator, Exit
8 116-1448-00 1 Actuator, Spring
12 016-2013-00 1 Transfer Roller, (BTR)
13 116-1449-00 1 Strap
14 116-1528-00 2 E-Ring (part of E-Ring Kit )
15 116-1450-00 2 Shaft, Pivot (1 per order)
276 Phaser 6200 Color Laser Printer - Service Manual
PL 9.1 Xerographics
S6200-237
FRU Parts List 277
PL 9.1 Xerographics - FRU Parts List Table
ID No. Part Number Qty Name/Description
1 116-1451-00 1 Laser Unit
2 116-1452-00 2 Spring, ROS (1 per order)
3 016-2012-00 1 Imaging Unit
4 116-1453-00 1 Bias Housing Assembly
5 116-1454-00 8 Plunger, Stud (1 per order)
6 116-1455-00 1 Assembly, Chute Registration (with 7~10 and 12)
7 1 Registration Clutch (NS)
8 116-1413-00 1 Sensor, Registration
9 116-1456-00 1 Actuator, Registration
10 116-1457-00 1 Actuator Spring, Registration
11 116-1458-00 1 Assembly, Housing, Electric
12 116-1459-00 1 OHP Sensor (with Harness) Kit
278 Phaser 6200 Color Laser Printer - Service Manual
PL 10.1 Holder Toner Cartridge Assembly
S6200-238
FRU Parts List 279
* When a new EEPROM Board is installed in the printer, the CRUM data written to
the EEPROM makes it unique to that printer. The EEPROM board cannot be
re-used in another printer.
PL 10.1 Toner Cartridge Holder Unit Assemblies - FRU Parts List
ID No. Part Number Qty Name/Description
1 016-2003-00
016-2007-00
1
1
Yellow Toner Cartridge, Standard-Capacity
Yellow Toner Cartridge, High-Capacity
2 016-2002-00
016-2006-00
1
1
Magenta Toner Cartridge, Standard-Capacity
Magenta Toner Cartridge, High-Capacity
3 016-2001-00
016-2005-00
1
1
Cyan Toner Cartridge, Standard-Capacity
Cyan Toner Cartridge, High-Capacity
4 016-2004-00
016-2008-00
1
1
Black Toner Cartridge, Standard-Capacity
Black Toner Cartridge, High-Capacity
8 116-1464-00 1 Sensor, Toner Low
9 116-1465-00 1 Assembly, Plate Dispenser, Left
10 116-1460-00 1 Holder, Toner Cartridge Assembly, Yellow
11 116-1461-00 1 Holder, Toner Cartridge Assembly, Magenta
12 116-1462-00 1 Holder, Toner Cartridge Assembly, Cyan
13 116-1463-00 1 Holder, Toner Cartridge Assembly, Black
14 116-1466-00 1 Assembly, Harness Toner
(J51-J431/J432/J433/J434/J441/J442/J443/J444/
J511/J512/J13/J514)
15 116-1467-00 1 Assembly , Harness CRUM (J71-J710)
16 116-1468-00 1 *Circuit Board, EEPROM
17 116-1469-00 1 Sub-High-Voltage Power Supply
18 116-1470-00 1 Switch, Toner CTG-IN (Present)
280 Phaser 6200 Color Laser Printer - Service Manual
PL 11.1 Frame and Drive Assemblies
S6200-239
FRU Parts List 281
PL 11.1 Frame and Drive Assemblies - FRU Parts List Table
ID No. Part Number Qty Name/Description
1 1 Lever, Plate Left (NS)
2 116-1471-00 2 Lever, Bracket (1 per order)
3 116-1472-00 1 Lever, Link , Left
4 116-1473-00 8 Lever, Drum (1 per order)
5 116-1474-00 8 Lever, Spring (1 per order)
6 116-1475-00 1 Link Lever, Right
7 1 Lever, Plate Right (NS)
8 116-1476-00 1 Actuator, I/L
9 116-1477-00 1 Spring, I/L
10 116-1478-00 2 Press, Gear IDL (1 per order)
11 116-1479-00 1 Press, Gear Right
12 116-1480-00 1 Spring, IDT Right
13 116-1481-00 1 Assembly, Developer Drive
14 116-1482-00 1 Assembly, Main Drive
15 116-1483-00 1 Registration, Film
16 116-1484-00 1 Circuit Board, Earth GRND (Ground)
17 116-1485-00 1 Spring, IDT Left
18 116-1486-00 1 Press, Gear, Left
282 Phaser 6200 Color Laser Printer - Service Manual
PL 12.1 Electrical
S6200-240
FRU Parts List 283
PL 12.1 Electrical - FRU Parts List Table
ID No. Part Number Qty Name/Description
1 116-1487-00 1 Circuit Board, Engine Control
2 116-1488-00 1 Rear Fan
3 116-1489-00 2 Harness, Clamp Guide (1 per order)
4
4a
4b
4c
4d
671-5290-81
163-1459-00
163-1458-00
163-1474-00
163-1475-00
650-4237-00
156-4838-00
156-4837-00
156-4663-00
1 Image Processor Board, no configuration chip, no
memory, no NVRAM, no Hard Drive
IC, Memory NVRAM
Configuration Chip = “i” button
IC, Base Configuration Chip
IC, Network Configuration Upgrade Chip
IC, DP/DX Configuration Upgrade Chip
Internal Hard Drive, FRU
Memory
64 MB, 8M x 64, PC133; Memory DIMM
128 MB, 16M x 64, PC133; Memory DIMM
256 MB, 32M x 64, PC133; Memory DIMM
5 1 Plate, Rear, Image Processor Board (NS)
6 2 Spring, Ground, Image Processor Board (NS)
7 1 Guide Right - Engine Control Board (NS)
8 1 Guide Left - Engine Control Board (NS)
10
10a
10b
116-1494-00
116-1495-00
1
1
Low-Voltage Power Supply 110 V
Low-Voltage Power Supply 220 V
11 116-1496-00 1 Assembly, Harness, AC Switch
12 116-1497-00 1 Circuit Board, Motor Driver
14 116-1498-00 1 Housing Assembly Contact
284 Phaser 6200 Color Laser Printer - Service Manual
PL 13.1 Harness Assemblies
S6200-241
FRU Parts List 285
PL 13.1 - Harness Assemblies - FRU Parts List Table
ID No. Part Number Qty Name/Description
1 116-1499-00 1 Assembly, Harness, LVNC (J165-61)
2 116-1500-00 1 Assembly, Harness, DRV 1 (J11-J41)
3 116-1501-00 1 Assembly, Harness, DRV 2 (J12-J42)
4 116-1502-00 1 Assembly, Harness, LVRPG (J164-311)
5 116-1503-00 1 Assembly, Harness, ROSKA (J15-J151)
6 116-1504-00 1 Assembly, Harness, 24 V (J60-J163)
7 116-1505-00 1 Assembly, Harness, FRONT 1A
(J13-P139/P1361/P1381/P5011)
8 116-1506-00 1 Assembly, Harness, OPF MAIN (J121-P210)
9 116-1507-00 1 Assembly, Harness, OPEPANE OPA (J22-P221)
10 116-1508-00 1 Assembly, Harness, EEPROM (J140-P71/J144/P141)
12 116-1509-00 1 Assembly, Harness, TMPB (J24-2361)
286 Phaser 6200 Color Laser Printer - Service Manual
High Capacity Feeder FRU Parts List
PL 14.1 High-Capacity Feeder Paper Trays 2 & 3
S6200-246
5
4
2
3
6
FRU Parts List 287
PL 14.1 Tray 2 & 3, Univeral Paper - FRU Parts List Table
ID No. Part Number Qty Name/Description
1 116-1330-00 1 Universal Paper Tray (with 2~5)
2 116-1331-00 2 Paper Feed Roller Kit*
*(2 interchangeable rollers per order)
3 116-1332-00 1 Assembly, Friction Clutch
4 1 Holder, Retard (NS)
5 116-1334-00 1 Spring, Retard
6 1 Cover, Front Tray(NS)
288 Phaser 6200 Color Laser Printer - Service Manual
PL 14.2 High-Capacity Feeder Covers
S6200-242
FRU Parts List 289
PL 14.2 High-Capacity Feeder Covers- FRU Parts List Table
ID No. Part Number Qty Name/Description
1 116-1510-00 1 Cover, Left
2 116-1337-00 2 Cover, Rear (1 per order)
3 116-1511-00 1 Cover, Right
4 116-1512-00 3 Cover, Front (1 per order)
5 116-0009-00 2 Casters, Locking (1 per order)
6 116-0008-00 2 Casters, Non-Locking (1 per order)
7 116-1514-00 2 Indicator, Paper (1per order)
290 Phaser 6200 Color Laser Printer - Service Manual
PL 14.3 High-Capacity Feeder Guides and Turn
Chute Assembly
S6200-243
FRU Parts List 291
PL 14.3 High-Capacity Feeder Guides and Chute - FRU Parts List Table
ID No. Part Number Qty Name/Description
1 Guide Assembly (with 3 and 8) (NS)
2 Guide Assembly (with 5 and 6) (NS)
3 116-1515-00 2 Guide, Tray Left (1 per Tray)
5 116-1516-00 2 Guide, Tray Right (1 per Tray)
6 116-1343-00 2 Assembly, Paper Size Switch (1 per Tray)
7 116-1336-00 2 Assembly, Turn Chute (1 per Tray)
8 116-1351-00 2 Paper Tray Stopper(1 per Tray)
292 Phaser 6200 Color Laser Printer - Service Manual
PL 14.4 Paper Pick Assembly Trays 2 & 3
S6200-244
FRU Parts List 293
PL 14.4 Paper Pick Assembly Trays 2 & 3 - FRU Parts List Table
ID No. Part Number Qty Name/Description
1 116-1517-00 1 Paper Pick Assembly, LTA (with 2~24)
2 1 Shaft, Feed 1 (NS)
3 116-1353-01 2 Paper Pick Roller Kit (2 per order)
4 116-1354-00 1 Sensor, No Paper, Low Paper
5 116-1355-00 1 Actuator, No Paper
6 116-1356-00 1 Actuator, Link
7 3 Bearing - Metal (NS)
8 1 Gear, Feed 1 (NS)
9 1 Spring, Feed 1 (NS)
10 1 Spring, Feed H (NS)
11 1 Gear, Feed H2 (NS part of 99)
12 1 Gear, Feed H1 (NS part of 99)
13 1 Gear, Feed 2 (NS part of 99)
14 1 Gear, Idler Feed (NS part of 99)
15 1 Gear, Idler (NS part of 99)
16 1 Clutch Stopper (NS)
17 116-1361-00 1 Feed Solenoid,
18 116-1362-00 1 Assembly, Turn Clutch
19 1 Gear, Idler In (NS part of 99)
20 116-1363-00 1 Assembly, Roll Turn
21 2 Bearing, Black (NS)
22 1 Shaft, Feed 2 (NS)
23 116-1331-00 2 Paper Feed Roller Kit*
*( 2 interchangeable rollers per order)
99 116-1367-00 1 Paper Feed Gear Kit (with 8, 11~15 and 19)
294 Phaser 6200 Color Laser Printer - Service Manual
PL 14.5 High-Capacity Feeder Harness, Board and
Motor
S6200-245
FRU Parts List 295
PL 14.5 High-Capacity Feeder Harness, Board, Motor - FRU Parts List Table
ID No. Part Number Qty Name/Description
1 116-1518-00 1 Circuit Board, Lower Feeder
2 116-1519-00 1 Assembly, OPT Feeder Plug
3 116-1520-00 1 Assembly, Harness, Tray 2
4 116-1521-00 1 Assembly, Harness, Tray 3
5 116-1522-00 1 Assembly, Drive, Feeder
6 1 Gear, Idler (NS, part of PL 3.3.99)
7 116-1354-00 2 Sensor, No Paper, Low Paper (1 per order)
8 116-1524-00 2 Lever, Low Paper (1 per order)
9 116-1525-00 Assembly, Indicator
10 116-1526-00 Assemlby, Harness, NPRSJ
296 Phaser 6200 Color Laser Printer - Service Manual
PL 15.1 Xerox Supplies and Accessories
Repair Kits, World Kits and Repacking Kits
Description Part Number
Kit, Gear, Paper Feed 116-1367-00
Kit, Gear, Exit Chute 116-1446-00
Kit, OHP Sensor with Harness 116-1459-00
Printer Feet 116-1344-00
Kit Screw, Assorted 116-1527-00
Kit, Long Screw (M3 x 85) (2 each) 212-0237-00
Kit, E-Rings, Assorted 116-1528-00
Kit, Sensor Actuator, Assorted Actuators 116-1529-00
Kit, Paper Feed Rollers
(2 interchangeable Rollers per)
116-1331-00
Paper Pick Rollers
(2 interchangeable Rollers per)
116-1353-01
Main Shipping Box 004-5258-00
Lower Tray Deck Shipping Box 004-5278-00
Phaser 6200, World Kit Plus Standard
Media Sample Pack
061-4462-00
Phaser 6200, World Kit Plus Metric Media
Sample Pack
061-4463-00
Repackaging Kit, Phaser 6200 065-0610-00
Repackaging Kit, High-Capacity Feeder,
Phaser 6200
065-0620-00
Cleaning Kit, 5 Texwipes 016-1845-00
Power Cords
Description Part Number
Cable Assy, 3,18AWG, 115 V, 98, 0L 161-0066-00
Cable PWR EURO 220V , 99L 161-0066-09
Cable PWR U.K. 240 V, 96L 161-0066-10
Cable PWR AUST 240 V, 96L 161-0066-11
Cable Assy SWISS 220/240 V, 50Hz 161-0154-00
Cable Assy PWR. DANISH, 250 V 161-0240-00
Cable Assy PWR, PRC 161-0304-00
Power, 240V , ARGENTINA 161-0307-00
FRU Parts List 297
Upgrade Kits and Options
Description Part Number
Internal Hard Drive, FRU 650-4237-00
Memory
64 MB, 8M x 64, PC133; Memory DIMM
128 MB, 16M x 64, PC133; Memory DIMM
256 MB, 32M x 64, PC133; Memory DIMM
156-4838-00
156-4837-00
156-4663-00
High-Capacity Feeder w/ Trays 119-6415-00
Casters Non-Locking 116-0008-00
Casters Locking 116-0009-00
IC, Base Configuration Chip 163-1458-00
IC, Network Configuration Upgrade Chip 163-1474-00
IC, DP/DX Configuration Upgrade Chip 163-1475-00
IC, Memory NVRAM 163-1459-00
Customer-Replaceable Consumables (CRCs)
Description Part Number
Toner Cartridges - Phaser 6200 all
Yellow Toner Cartridge, Standard-Capacity
Yellow Toner Cartridge, High-Capacity
016-2003-00
016-2007-00
Magenta Toner Cartridge, Standard-Capacity
Magenta Toner Cartridge, High-Capacity
016-2002-00
016-2006-00
Cyan Toner Cartridge, Standard-Capacity
Cyan Toner Cartridge, High-Capacity
016-2001-00
016-2005-00
Black Toner Cartridge, Standard-Capacity
Black Toner Cartridge, High-Capacity
016-2004-00
016-2008-00
Imaging Unit 016-2012-00
Fuser
110 V
220 V
016-2014-00
016-2015-00
Transfer Roller 016-2013-00
Customer-Replaceable Units (CRUs)
Description Part Number
Universal Paper Tray (1, 2, 3) 016-1330-00
Paper Feed Roller Kit 116-1331-00
298 Phaser 6200 Color Laser Printer - Service Manual
Software and Documentation
Description Part Number
Product CD 063-3414-00
Printer Management CD 063-3415-00
Interactive Documentation CD 063-3419-01
Service Manual 071-0784-00
Print Media
Description Part Number
Premium Paper, A, 500 Sheets 016-1368-00
Premium Paper, A4, 500 Sheets 016-1369-00
Glossy Coated Paper, A, 100 Sheets 016-1704-00
Glossy Coated Paper, A4 100 Sheets 016-1705-00
Color Printing Labels, A, 30 per, 100 Sheets 016-1812-00
Color Printing Labels, A, 6 per, 100 Sheets 016-1813-00
Color Printing Labels, A4, 14 per, 100 Sheets 016-1814-00
Color Printing Labels, A4, 8 per, 100 Sheets 016-1815-00
Premium Cover Paper, A, 100 Sheets 016-1823-00
Premium Cover Paper, A4, 100 Sheets 016-1824-00
CD/DVD Label and Applicator; contains 1
Applicator & 1 Jewel Case
016-1885-00
CD/DVD Labels and Inserts, 1 Insert/Sheet,
Letter (8.5 x 11 in.), 20 Sheets, 2 Labels per
Sheet, 10 Sheets
016-2011-00
CD/DVD Labels and Inserts, A4,
(210 x 297mm) 1 Insert/Sheet, 20 Sheets, 2
Labels per Sheet, 10 Sheets
016-2026-00
Premium Business Card Media, A, 10 per
25 Sheets
016-1898-00
Premium Business Card Media, A4, 10 per
25 Sheets
016-1899-00
Phaser 6200 Premium Transparency, Letter
(8.5 x 11 in.), 50 Sheets
016-1948-00
Phaser 6200 Premium Transparency, A4
(210 x 297mm), 50 Sheets
016-1949-00
Premium Greeting Card Media w/ Envelopes,
A, 50 sheets
016-1987-00
FRU Parts List 299
Premium Greeting Card Media w/ Envelopes,
A4, 50 sheets
016-1988-00
Digital Photo Paper, A, 50 Sheets 016-2009-00
Digital Photo Paper, A4, 50 Sheets 016-2010-00
Print Media (cont'd.)
Description Part Number
Loading...
