FreeFlow Accxes Customer Release Notes

Version 13.0 b 141 (for 6279 only)

Contents

2 Introduction 2 Feature Keys 3 Release Deliverables 4 Recommended Configurations 5 Release Installation 6 New Features 7 Release Notes 15 Customer Issues Resolved

December, 2008

FreeFlow Accxes Customer Release Notes

Version 13.0 b 141

Introduction

The FreeFlow® Accxes® Controller Firmware Release 13.0 b 141 provides multinational software for the Xerox 6279 and for the Xerox Wide Format Scan System. The languages supported are English, Deutsch, Espanol, Francais, Italiano, Portugues, and Russian.

This document presents the following information about the FreeFlow® Accxes® Controller Release 13.0 build 141. The document applies to FRX, and LVX controllers and for simplicity they will simply be referred to as YKE.

Release deliverables

Recommended configurations

Installation procedures

Present supplemental information and known issues that are not mentioned in the published customer user documentation.

New Features

Feature Keys

Print and Copy Feature Keys are enabled on the YKE controller by loading the “OS Enablement” feature key. Additionally, the following functions will be unavailable until the appropriate feature key is loaded.

• DGN printing is enabled with an “Other CAD” feature key beginning in 12.5.

• JPEG 2000, PNG, BMP, and GIF printing is enabled with a Raster feature key beginning in 12.1.

• DWF printing is enabled with the “AutoCAD” feature key beginning in version 12.0.

• Job Accounting Enables tracking media usage data for print, scan, and copy jobs. Account Management

Tool, or some other external accounting tool, is used to assign User Id, Account Id, Printer Id associations, and then collects and tallies the stored data from the printers).

• PostScript – Enables the interpretation of Adobe Postscript 3 and PDF 1.6 files.

• Disk Image Overwrite – Enables the security options for overwriting image data on the hard drive.

Xerox6279 Wide Format System added in 13.0:

• 9-D Speed key for printing on 6279.

• Scanner Speed key for faster scanning on 6279.

• Color Enablement specific to the 6279 scanner.

• Scan to Net Enablement specific to 6279.

Xerox Wide Format Scanner Features:

• Color Enablement –Accxes - Allows color scanning when scan to net license is present.

• Speed Enhancement Turbo II – Accxes - Enables 4 ips scan speed for 36” wide.

• Speed Enhancement Turbo III – Accxes – Enables 7.33 ips Scans on YKE/YKE-N/FRX Controllers

For more information on Feature Keys, see the Feature Key Instructions and Coupon Exchange screens on the

https://www.xeroxlicensing.xerox.com/coupon/

Release Deliverables

Xerox 6279 Wide Format Solution

The following executable is provided for the Xerox 6279 Wide Format Solution and supports the Xerox Wide Format Scan System and GFI finisher.

FRX & LVX Controller: FRX_LVX_6279_13_0b141.disk.bin (file size = 54,615,971 bytes)

Recommended Configurations

The following table specifies the RAM requirements for the various systems and configurations supported by the FreeFlow Accxes controller.

System Min

Any System with the following feature keys:

• AutoCAD

• OtherCAD

• RASTER

6279 2GB 2GB 2GB 2GB

FRX Controller LVX Controller

Recommend Min Recommend

2GB 2GB 2GB 2GB

Release Installation

This version of Accxes (13.0 b 141) requires OS Install CD version 4.1 or higher. BSP Kernel revision 2.6.22.9-

61.fc6 or later is also required. Service is required to upgrade from earlier Accxes® revisions.

Regarding scanner firmware revisions: If you are upgrading the firmware of a system containing a Xerox Wide Format Scanner, you must also ensure that the scanner firmware is upgraded, prior to upgrading the controller, to the following version:

IMPORTANT NOTE: The controller will only accept the installation when there are no active jobs being processed.

Accxes Client Tools

Download the file named “<Controller>_<Printer>_<Accxes_version>.disk.bin”. A status sheet will be printed and indicate that the download was successful.

Web Printer Management Tool

Select Utilities > Upload > Upload File. Use the Browse button to select the “<Controller>_<Printer>_<Accxes_version>.disk.bin”. Click on the “Upload” button. A printed status sheet will indicate that the download was successful.

Unix

Download the software using LPR with the following command line:

lpr –P printername “<Controller>_<Printer>_<Accxes_version>.disk.bin”

A status sheet will be printed and indicate that the download was successful.
