Xerox Fiery XJ+ 525 Administrator Guide

Fiery XJ+ 525 Color Server

ADMINISTRATOR GUIDE

This publication is protected by copyright, and all rights are reserved. No part of it may be reproduced or transmitted in any form or by any means for any purpose without express prior written consent from Electronics for Imaging, Inc., except as expressly permitted herein. I nformation in this document is subject to change without notice and does not represent a commitment on the part of Electronics for Imaging, Inc.

The software described in this publication is furnished under license and may only be used or copied in accordance with the terms of such license.

Trademarks

EFI, the EFI logo, Fiery, the Fiery logo, EFICOLOR and the EFICOLOR logo are trademarks registered with the U.S. Patent and Trademark Ofﬁce. Fiery XJ, Fiery XJe, Fiery XJ+, Fiery Driven, the Fiery Driven logo, XJ RipChips, Rip-While-Print, Continuous Print, Command WorkStation, AutoCal, Starr Compression, and Memory Multiplier are trademarks of Electronics for Imaging, Inc.

DocuColor 40 and all Xerox product names mentioned in this publication are trademarks of the XEROX CORPORATION. Adobe, the Adobe logo, Adobe Illustrator , P ostScript, Adobe P hotoshop, Adobe S eparator , and A dobe P ageMaker ar e trademarks of Adobe Systems I ncorporated,

registered in certain jurisdictions. EPS (Encapsulated PostScript) is a trademark of Altsys Corporation. Apple, the A pple logo, A ppleShar e, A ppleTalk, E therTalk, LaserWriter, and Macintosh are registered trademarks, and MultiFinder is a trademark of Apple Computer, Inc. Microsoft, MS, and MS-DOS are registered trademarks, and Windows is a trademark of Microsoft Corporation in the US and other countries. QuarkXPress is a registered trademark of Quark, Inc. Times, Helvetica, and Palatino are trademarks of Linotype AG and/or its subsidiaries. ITC Avant Garde, ITC Bookman, ITC Zapf Chancery, and ITC Zapf Dingbats are registered trademarks of International Typeface Corporation. Ethernet is a registered trademark of Xerox Corporation. Farallon, PhoneNET PC, and PhoneNET Talk are trademarks of Farallon Computing, Inc. COPS and COPSTalk are trademarks of CoOperative Printing Solutions, Inc. NetWare and Novell are registered trademarks and Internetwork Packet Exchange (IPX) is a trademark of Novell, Inc. UNIX is a registered trademark of UNIX System Laboratories, a wholly owned subsidiary of Novell, Inc. Sun, Sun Microsystems and SunOS are trademarks or registered trademarks of Sun Microsystems, Inc. PANTONE is a registered trademark of Pantone, Inc. X-Rite

All other terms and product names may be trademarks or registered trademarks of their respective owners, and are hereby acknowledged.

Legal Notices APPLE COMPUTER, INC. (“APPLE”) MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION THE

IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, REGARDING THE APPLE SOFTWARE. APPLE DOES NOT WARRANT, GUARANTEE, OR MAKE ANY REPRESENTATIONS REGARDING THE USE OR THE RESULTS OF THE USE OF THE APPLE SOFTWARE IN TERMS OF ITS CORRECTNESS, ACCURA CY, RELIABILITY, CURRENTNESS, OR OTHERWISE. THE ENTIRE RISK AS TO THE RESULTS AND PERFORMANCE OF THE APPLE SOFTWARE IS ASSUMED BY YOU. THE EXCLUSION OF IMPLIED WARRANTIES IS NOT PERMITTED BY SOME STATES. THE ABOVE EXCLUSION MAY NOT APPLY TO YOU.

IN NO EVENT WILL APPLE, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE TO YOU FOR ANY CONSEQUENTIAL, INCIDENTAL OR INDIRECT DAMA GES (INCLUDING DAMA GES FOR LOSS OF BUSINESS PR OFITS, BUSINESS INTERRUPTION, L OSS OF BUSINESS INFORMATION, AND THE LIKE) ARISING OUT OF THE USE OR INABILITY TO USE THE APPLE SOFTWARE EVEN IF APPLE HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. BECAUSE SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE LIMITATIONS MAY NOT APPLY TO YOU.

Apple’s liability to you for actual damages from any cause whatsoever, and regardless of the form of the action (whether in contract, tort [including negligence], product liability or otherwise), will be limited to $50.

Restricted Rights Legends

For defense agencies: Restricted Rights Legend. Use, reproduction, or disclosure is subject to restrictions set forth in subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause at 252.227.7013.

For civilian agencies: Restricted Rights Legend. Use, reproduction, or disclosure is subject to restrictions set forth in subparagraph (a) through (d) of the commercial Computer Software Restricted Rights clause at 52.227-19 and the limitations set forth in Electronics for Imaging, Inc.’s standard commercial agreement for this software. Unpublished rights reserved under the copyright laws of the United States.

Printed in the United States of America on recycled paper. Part Number:

10012576

is a registered trademark of X-Rite, Incorporated.

FCC Information

WARNING: FCC Regulations state that any unauthorized changes or modiﬁcations to this equipment not expressly approved by the manufacturer could void the user’s authority to operate this equipment.

NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, and uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause interference in which case the user will be required to correct the interference at his own expense.

Industry Canada Class A Notice

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus as set out in the interference-causing equipment standard entitled, “Digital Apparatus” ICES-003 from Industry Canada.

Avis de Conformation Classe A d l’Industrie Canada

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la Classe A prescrites dans la norme sur le matériel brouilleur, “Appareils Numériques” NMB-003 édictée par l’Industrie Canada.

Certiﬁcate by Manufacturer/Importer

This is to certify that the FC07 is shielded against radio interference in accordance with the provisions of VFG 243/1991. The German Postal Services have been advised that this device is being put on the market and that they have been given the right to inspect the series for compliance with the regulations. Electronics for Imaging, Inc.

Bescheinigung des Herstellers/Importeurs

Heirmit wird bescheinigt, daß der FC07 im Übereinstimmung mit den Bestimmungen der VFG 243/1991 Funk-Entstort ist. Der D eutschen Bundespost wur de das Inverkehrbringen dieses Gerätes angezeigt und die Berechtigung zur Überprüfung der Serie auf Einhaltung der Bestimmungen eingeraumt. Electronics for Imaging, Inc.

RFI Compliance Notice

This equipment has been tested concerning compliance with the relevant RFI protection requirements both individually and on system level (to simulate normal operation conditions). However, it is possible that these RFI Requirements are not met under certain unfavorable conditions in other installations. It is the user who is responsible for compliance of his particular installation.

Dieses Gerät wurde sowohl einzeln als auch in einer Anlage, die einen normalen Anwendungsfall nachbildet, auf die Einhaltung der Funkentstörbestimmungen geprüft. Es ist jedoch möglich, daß die Funkenstörbestimmungen unter ungünstigen Umständen bei anderen Gerätekombinationen nicht eingehalten werden. Für die Einhaltung der Funkentstörbestimmungen einer gesamten Anlage, in der dieses Gerät betrieben wird, ist der Betreiber verantwortlich.

Compliance with applicable regulations depends on the use of shielded cables. It is the user who is responsible for procuring the appropriate cables. Die Einhaltung betreffender Bestimmungen hängt davon ab, daß geschirmte Ausführungen benützt werden. Für die Beschaffung richtiger Ausführungen ist der

Betreiber verantwortlich.

Software License Agreement

Electronics for Imaging, Inc. grants to you a non-exclusive, non-transferable license to use the software and accompanying documentation (“Software”) included with the Fiery XJ Color Server you have purchased, including without limitation the PostScript

software provided by Adobe Systems Incorporated.

You may: a. use the Software solely for your own customary business purposes and solely with Fiery XJ; b. use the digitally-encoded machine-readable outline and bitmap programs (“Font P rograms”) pr ovided with F iery XJ in a special encrypted format (“Coded Font

Programs”) to reproduce and display designs, styles, w eights, and versions of letters, numerals, characters and symbols (“Typefaces”) solely for your own customary business purposes on the screen of the Fiery XJ or Macintosh monitor used with Fiery XJ;

c. use the trademarks used by Electronics for Imaging to identify the Coded Font Programs and Typefaces reproduced therefrom (“Trademarks”); and d. assign your rights under this Agreement to a transferee of all of your right, title and interest in and to Fiery XJ provided the transferee agr ees to be bound by all

of the terms and conditions of this Agreement.

You may not: a. make use of the Software, directly or indirectly, to print bitmap images with print resolutions of 600 dots per inch or greater, or to generate fonts or typefaces

for use other than with Fiery XJ; b. make or have made, or permit to be made, any copies of the Software, Coded Font Programs, accompanying documentation or portions thereof, except as

necessary for use with the Fiery XJ unit purchased by you; provided, however, that under no circumstances may you make or have made, or permit to be made, any copies of that certain portion of the Software which has been included on the Fiery XJ hard disk drive. You may not copy the documentation;

c. attempt to alter, disassemble, decrypt or reverse engineer the Software, Coded Font Programs or accompanying documentation. d. rent or lease the Software.

Proprietary Rights

You acknowledge that the Software, Coded Font Programs, Typefaces, Trademarks and accompanying documentation are proprietary to Electronics for Imaging and its suppliers and that title and other intellectual property rights therein remain with Electronics for Imaging and its suppliers. Except as stated above, this Agreement does not grant you any right to patents, copyrights, trade secrets, trademarks (whether registered or unregistered), or any other rights, franchises or licenses in respect of the Software, Coded Font Programs, Typefaces, Trademarks or accompanying documentation. You may not adapt or use any trademark or trade name which is likely to be similar to or confusing with that of Electronics for Imaging or any of its suppliers or take any other action which impairs or reduces the trademark rights of Electronics for Imaging or its suppliers. The trademarks may only be used to identify printed output produced b y the Coded Font P rograms. At the reasonable request of Electronics for Imaging, you must supply samples of any Typeface identiﬁed with a trademark.

The MacApp software is proprietary to Apple Computer, Inc. and is licensed to Electronics for Imaging, Inc. for distribution only for use in combination with Fiery XJ software utilities.

Conﬁdentiality

You agr ee to hold the Software and Coded F ont P rograms in conﬁdence, disclosing the Software and Coded F ont P rograms only to authorized users having a need to use the Software and Coded Font Programs as permitted by this Agreement and to take all reasonable precautions to prevent disclosure to other parties.

Remedies

Unauthorized use, copying or disclosure of the Software, Coded F ont Programs, Typefaces, Trademarks or accompanying documentation will result in automatic termination of this license and will make available to Electronics for Imaging other legal remedies.

Limited Warranty And Disclaimer

Electronics for Imaging warrants that, for a period of ninety (90) days from the date of delivery to you, the Software under normal use will perform without signiﬁcant errors that make it unusable. Electronics for Imaging’s entire liability and your exclusive remedy under this warranty (which is subject to you returning Fiery XJ to Electronics for Imaging or an authorized dealer) will be, at Electronics for Imaging’s option, to use reasonable commercial efforts to attempt to correct or work around errors, to replace the Software with functionally equivalent software, or to refund the purchase price and terminate this Agreement. Some states do not allow limitations on duration of implied warranty, so the above limitation may not apply to you.

Except for the above express limited warranty, Electronics for Imaging makes and you receive no warranties or conditions on the Products, express, implied, or statutory, and Electronics for Imaging speciﬁcally disclaims any implied warranty or condition of merchantability or ﬁtness for a particular purpose.

For warranty service, please contact your authorized service/support center. EXCEPT FOR THE ABOVE EXPRESS LIMITED WARRANTY, ELECTRONICS FOR IMAGING MAKES AND YOU RECEIVE NO WARRANTIES

OR CONDITIONS ON THE SOFTWARE OR CODED FONT PROGRAMS, EXPRESS, IMPLIED, STATUTORY, OR IN ANY OTHER PR O VISION OF THIS AGREEMENT OR COMMUNICATION WITH YOU, AND ELECTRONICS FOR IMAGING SPECIFICALL Y DISCLAIMS ANY IMPLIED WARRANTY OR CONDITION OF MER CHANT ABILITY OR FITNESS FOR A P AR TICULAR PURPOSE. Electronics for Imaging does not warrant that the operation of the software will be uninterrupted or error free or that the Software will meet your speciﬁc requirements.

Limitation Of Liability

IN NO EVENT WILL ELECTRONICS FOR IMAGING OR ITS SUPPLIERS BE LIABLE FOR ANY DAMA GES, INCLUDING LOSS OF DATA, LOST

PROFITS, COST OF COVER OR O THER SPECIAL, INCIDENT AL, CONSEQ UENTIAL OR INDIRECT DAMAGES ARISING FR OM THE USE OF THE SOFTWARE, CODED FONT PROGRAMS OR ACCOMPANYING DOCUMENTATION, HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY. THIS LIMITATION WILL APPLY EVEN IF ELECTRONICS FOR IMAGING OR ANY AUTHORIZED DEALER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. YOU ACKNOWLEDGE THAT THE PRICE OF FIERY XJ REFLECTS THIS ALLOCATION OF RISK. BECAUSE SOME STATES/JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE LIMITATION MAY NOT APPLY TO YOU.

Export Controls

You agr ee that you will not export or re-export the Softwar e or Coded Font Programs in any form without the appropriate United States and foreign government

licenses. Your failure to comply with this provision is a material breach of this Agreement.

Government Use

Use, duplication or disclosure of the Software by the United States Government is subject to restrictions as set forth in subdivision (c) (1) (ii) of the Rights in

Technical Data and Computer Software clause at DFARS 252.227-7013 or in subparagraphs (c) (1) and (2) of the Commercial Computer Software—Restricted

Right Clause at 48 CFR 52.227-19, as applicable.

Third Party Beneﬁciary

You ar e hereby notiﬁed that A dobe Systems I ncorporated, a California corporation located at 303 Almaden Blvd., S an J ose, California 95110 (“Adobe”) is a third-

party beneﬁciary to this Agreement to the extent that this Agreement contains provisions which relate to your use of the Fonts, the Coded Font Programs, the

Typefaces and the Trademarks licensed her eby. Such provisions are made expressly for the beneﬁt of Adobe and are enforceable by Adobe in addition to Electronics

for Imaging.

General

This Agreement will be governed by the laws of the State of California.

This Agreement is the entire agreement held between us and supersedes any other communications or advertising with respect to the Software, Coded Font

Programs and accompanying documentation.

If any provision of this Agreement is held invalid, the remainder of this Agreement shall continue in full force and effect.

If you have any questions concerning this Agreement, please write to Electronics for Imaging, Inc., Attn: Licensing Dept. or see Electr onics for Imaging ’s web site

at www.eﬁ.com.

Electronics for Imaging, Inc.

2855 Campus Drive

San Mateo, CA 94403

Contents

Introduction

About this manual

Organization xi

About the documentation Before you proceed

Levels of access and control xiii Fiery XJ printing connections xiii Fiery WebTools and HTTP access xiv Passwords xvi Control level scenarios xvii

Chapter 1: Connecting to the Network

Fiery XJ on the network

Stages of installation on the network 1-1

Quick path to installation Before you begin Ethernet cable connection Parallel cable connection Setting up the Command WorkStation

Printing to the Fiery XJ 1-14 Setting up IPX/SPX communication 1-14 Setting up TCP/IP communication 1-14 Setting up the Fiery XJ Downloader 1-15

xii

xiii

1-1

1-3

1-9 1-10 1-13 1-14

Attaching external SCSI devices

Supported drives 1-15

1-15

vii Contents

Chapter 2: Setting up the Fiery XJ

About Fiery XJ Setup

Initial Setup on the Control Panel 2-1 Making changes to Setup 2-1 Network server setup requirements 2-1

Running Setup on the Control Panel

Accessing Setup options 2-3 About the Control Panel Setup interface 2-5 Types of Setup screens 2-6

Server Setup options Network Setup options

Ethernet Setup options 2-11 Token Ring Setup options 2-19 Parallel Port Setup options 2-20

Printer Setup options Administrative functions in the Setup menu

Fiery XJ Job Log Setup 2-26 Job Log Setup options 2-27 Change Password 2-27 Clear Server 2-29 Exit Setup 2-29 Printing the Conﬁguration page from the Control Panel 2-29

2-1

2-2

2-8 2-10

2-21 2-25

Running Setup from the Command WorkStation

General Setup options 2-33 Network Setup options 2-37 Printer Setup options 2-48 Printing the Conﬁguration page from the Command WorkStation 2-51

Setting the WebLink destination

2-30

2-52

viii Contents

Chapter 3: Command WorkStation Functions

Starting the Fiery XJ and Command WorkStation Connecting to the server

Conﬁguring the Chooser list 3-3 Editing the NET_WSCK.INI ﬁle 3-6

Rebooting the server from the Command WorkStation Shutting down the server and Command WorkStation Installing Command WorkStation software

Chapter 4: Setting up Network Servers

The Fiery XJ on an IPX network Tips for experts—IPX networks Overview of IPX printing to the Fiery XJ Conﬁguring a NetWare server for printing

Setting the NetWare 4.x bindery context 4-6 Setting up a Fiery XJ print queue 4-9

Setting up NetWare Windows clients for printing Conﬁguring Windows 95 workstations

for printing and for the Fiery XJ Downloader

Windows 95 workstations on TCP/IP networks 4-15

3-1

3-3

3-7

3-8

3-9

4-1

4-2

4-3

4-4

4-13

4-14

Fiery XJ on a network with Windows NT Tips for experts—Windows NT with TCP/IP Conﬁguring a Windows NT server to support the Fiery XJ

Loading the TCP/IP network protocol 4-17 Adding the Fiery XJ to the TCP/IP network 4-18 Installing the Fiery XJ as a PostScript printer 4-20 Setting up another printer 4-21

Conﬁguring Windows NT clients for printing Conﬁguring Windows NT workstations for

the Fiery XJ Downloader Using AppleTalk with Windows NT Fiery XJ on a network with UNIX workstations

4-15 4-15 4-16

4-22

4-23 4-24 4-24

ix Contents

Tips for experts—UNIX workstations

Important note about the remote printer name 4-25 Setting up the Fiery XJ on TCP/IP networks 4-26 Printing and managing print jobs 4-27

Chapter 5: Administering the Fiery XJ

Administrator functions Maintaining optimal server performance Troubleshooting the Fiery XJ

Troubleshooting during Setup 5-4 Runtime error messages 5-7

Appendix A: Token Ring Network Option

Fiery XJ Token Ring option

Connecting Token Ring hardware A-1

Conﬁguring the NetWare server Setting up IPX-Token Ring on the Fiery XJ Setting up NetWare Windows clients

4-25

5-1

5-2

5-3

A-1

A-3 A-3 A-3

Index

x About this manual

Introduction

This manual is intended for anyone who is responsible for integrating the Fiery XJ+ 525™ Color Server into a business environment that includes networked personal computers. After the Fiery XJ and remote workstations are set up, as described in this guide and in

Getting Started

, individual users can print to the

Fiery XJ+ 525 as a high-performance color PostScript printer.

The applications described in this manual can be used with the Fiery XJ+ 500

OTE

and Fiery XJ+ 525 systems. The software works the same way on both systems.

About this manual

This manual provides guidelines on the following topics:

• Basic conﬁguration of the Fiery XJ and Command WorkStation to support printing over AppleTalk, TCP/IP, and IPX (Novell) networks

• Setting up a parallel port connection

• Conﬁguring UNIX systems and Novell and Windows NT servers to provide Fiery XJ printing services

• Administering network printing

• Using the Fiery XJ in mixed network environments

• Setting up a Token Ring connection

The network guidelines in this book are not intended to replace the services of

OTE

an experienced network engineer.

Organization

The manual is organized as follows:

• Chapter 1 illustrates the supported network conﬁgurations and shows the network connectors on the Fiery XJ. It also describes how to install the Command WorkStation and connect SCSI devices to it.

• Chapter 2 describes Fiery XJ conﬁguration from the Control Panel and from the Command WorkStation, and explains how to set the WebLink destination.

xi Introduction

• Chapter 3 describes starting up the Command W orkS tation, logging in to the server for the ﬁrst time, and procedures for rebooting and shutting down. It also gives instructions on installing the Command WorkStation software, should that become necessary .

• Chapter 4 offers guidelines for setting up Windows network servers and UNIX systems for printing to the Fiery XJ.

• Chapter 5 summarizes some administrative features of Fiery XJ software that are available for the three major platforms and offers some troubleshooting hints.

• Appendix A describes the Token Ring option.

OTE

Administrator features described in other manuals are summarized on page 5-1.

About the documentation

This manual is part of the set of documentation that includes the following manuals for users and system administrators:

•

Getting Started

describes ﬁrst time installation of software to enable users to print to the Fiery XJ. It describes installing PostScript printer drivers, printer description ﬁles, and other user software provided on the Fiery XJ User Software CD. It also explains how to connect each user to the network.

• The

User Guide

describes the printing features of the Fiery XJ for users who send jobs via remote workstations on the network or via a direct parallel port connection. It explains how users can monitor their own jobs, or supply job information to the operator at the Command WorkStation. It also describes the Fiery WebTools and the Fiery XJ Downloader, and gives examples of the printer fonts installed on the Fiery XJ.

• The

Operator Guide

is about the Command WorkStation. It describes the basic printing model and the functions and features of the Command WorkStation as used by an operator, including calibration of the printing system.

• The

Release Notes

contain important information about the product that was not

available at the time the other manuals were produced.

xii Before you proceed

Before you proceed

No two Fiery XJ sites are identical and the Fiery XJ system can be conﬁgured to suit your site’s particular requirements for ﬂexibility or control. As the system administrator, you decide the level of network and software access that will be accessible to users.

Before you proceed with installation and setup, make sure you understand the spectrum of access and control possible with the Fiery XJ. Then decide what level is most appropriate for your site.

Levels of access and control

The level of control you implement can range from strict to moderate to minimal, or none. Strictest control might be appropriate for a high-volume printing environment where an administrator or operator controls the job ﬂow and all printing; jobs sent by users are spooled (stored) to the server disk until the operator decides it is time to print them. In addition, only the administrator and/or operator have access to certain software tools.

Least control might be appropriate for at a small site where anyone on the local network can control all printing and server functions. Although there may be an administrator or operator charged with certain duties, all users have equal access to the system and its software tools.

When you perform Setup, you (the system administrator) implement a particular level of control by enabling (or not enabling) printing connections, HTTP access, and passwords.

Fiery XJ printing connections

The Fiery XJ supports three printing connections: Hold queue, Print queue, and Direct connection. The Hold queue is always available to users on the network. The Print queue and the Direct connection can be enabled, or “published” to users on the network, when you conﬁgure the server setup. These two printing connections give remote users more access to the server, and therefore should not be enabled in environments where stricter control is desired.

xiii Introduction

Hold queue

The Hold queue is the default printing connection. Jobs sent to the Hold queue are spooled to the server’s hard disk. These jobs cannot proceed through the printing process without intervention via the Command WorkStation (see the

Operator Guide

or the WebSpooler (see page xv).

Direct connection

The Direct connection transmits jobs directly to the Fiery XJ, but only when the Fiery XJ is ready to print. If the Fiery XJ is busy, the job remains at the user workstation until the Fiery XJ is ready. It is then processed as soon as the prior job is ﬁnished and before the next queued job is processed.

Jobs sent to the Direct connection are not stor ed on the Fiery XJ hard disk and do not appear in the Command WorkStation (or WebSpooler) display of current jobs; therefore the Direct connection provides a measure of security for sensitive ﬁles. Jobs sent to the Direct connection do appear in the Job Log, for accounting purposes.

)

OTE

The Direct connection must be used to download fonts. If you plan to

download fonts to the Fiery XJ, you must publish the Direct connection.

Print queue

If you publish the Print queue, jobs sent to it are processed and printed in the order they are received. Intervention by an operator at the Command WorkStation, or jobs sent via the Direct connection, can take priority over jobs sent to the Print queue.

OTE

The Print queue must be enabled to use the WebTools.

Fiery WebTools and HTTP access

The Fiery XJ can support Internet or intranet access with the Fiery WebTools. To enable use of the WebTools, you must do the following in Setup:

Enable TCP/IP

• Set

• Set an IP address for the Fiery XJ

Enable HTTP

• Set

• Set Publish Print Queue to Yes

Yes

xiv Before you proceed

Passwords can be set to control access to WebTools features. If you do not speciﬁcally set these passwords, all users have access to all WebTools functions. (See “Passwords” on page xvi.)

The WebTools include Status, WebSpooler, Installer, and WebLink.

Status

Status gives you a quick update of Fiery XJ status by showing the jobs currently spooling, processing, and printing. You can close the active web browser window and leave the Status window open on the desktop to view current Fiery XJ information, which is dynamically updated.

Status is not affected by any password setting. For more information on Status, see the User Guide.

WebSpooler

WebSpooler allows remote users to view, manipulate, reorder, reprint, and delete jobs currently spooling, processing, or printing on the Fiery XJ. It also allows you to view, print, or delete the Job Log.

The WebSpooler interface is similar to the Command WorkStation display; however, some Command WorkStation functions (such as calibration, Thumbnails, and DocBuilder) are not available from the WebSpooler.

WebSpooler access can be controlled by setting a WebSpooler User password in Setup from the Command WorkStation. If you set a password, only users with that password can manipulate jobs from the WebSpooler. A user who does not have the password can still log in to the WebSpooler as a Guest with view-only access. (See “Passwords” on page xvi.) For more information, see the User Guide.

Installer

Installer allows users to download user software and printer ﬁles installers directly fr om the server.

The WebTools Installer is not affected by any password setting. For more information, see Getting Started.

xv Introduction

WebLink

WebLink provides a link to a Fiery WebLink destination. This destination is initially set to www.efi.com/weblink/xerox. From this page, you can link to either the Xerox home page or the Electronics for Imaging home page (www.eﬁ.com).he WebLink destination can be changed. This function requires the Administrator password, if one has been set. See “Passwords” below.

NOTE: If no Administrator password has been set, any user can set the WebLink

destination. For this reason, it is strongly recommended that y ou set an Administrator password.

For more information, see page 2-52.

Passwords

You can implement password requirements as a means of controlling access to Fiery XJ functions. The Fiery XJ allows for the following passwords to be set:

• Administrator—can be set from either the Control Panel or the Command WorkStation

• Operator—can only be set from the Command WorkStation

• WebSpooler User—can only be set from the Command WorkStation

NOTE: By default, no passwords are implemented on the Fiery XJ. If you do not

speciﬁcally set passwords, all users will have administrator privileges which include access to important functions such as Setup (including setting passwords), calibration, and job control. It is strongly recommended that you set at least an Administrator password to protect the server from random or accidental changes to Setup.

Administrator password privileges

With an Administrator password, the administrator has unlimited access to server functions, including Setup (from either the Control Panel or the Command WorkStation) and setting the WebLink destination. Administrator control, which confers control of setup, is the highest level of control, since the person who has access to setup can control the printing and job management environment by choosing which queues are enabled, and by electing to set passwords.

xvi Before you proceed

Operator password privileges

Operator control is the next level of control. It includes control of print jobs that arrive at the server (including the ability to override job settings), and the ability to perform calibration and override calibration settings.

WebSpooler User password privileges

With the WebSpooler User password, remote users can control print jobs via the WebSpooler when they log into the ColorPASS web page. WebSpooler User control is roughly equivalent to operator control from the Command WorkStation in terms of managing print jobs. However, a WebSpooler User cannot perform calibration, access archived jobs, or use the Thumbnail and DocBuilder features of the Command WorkStation.

Guest privileges (No password)

No password is needed for a user to log in as a Guest from the Command WorkStation or the WebSpooler and view the status of active jobs. A Guest cannot make changes to jobs or to the server’s state (for example, calibration).

Control level scenarios

Typical scenarios of access and control, ranging from least control to strictest control, are described below. Choose the scenario that best matches your site requirements, and then refer to the corresponding number for guidance on how to conﬁgure your system for those requirements.

NOTE: It is strongly recommended that you set at least an Administrator password to

avoid potential hazards to system operations.

1. (Least control) No designated administrator and no designated operator

All users have equal access to all system functions including Setup, WebLink destination setup, calibration, printing to all three Fiery XJ print connections, and managing all jobs from the Command WorkStation or the WebSpooler.

2. A designated administrator but no designated operator

Only an administrator can perform Setup and set the WebLink destination, but all other system functions are accessible to all users, including calibration, printing to all three Fiery XJ print connections, and managing all jobs from the Command WorkStation or the WebSpooler.

xvii Introduction

3. A designated administrator and a superuser operator

Only an administrator can perform Setup and set the WebLink destination, and only an operator or administrator can perform calibration and control jobs from the Command WorkStation, but users can print to all three Fiery XJ print connections, and all users can control jobs from the WebSpooler.

4. A designated administrator, a designated operator, limited WebTool access

Only an administrator can perform Setup and set the WebLink destination, and only an operator or administrator can perform calibration and control jobs from the Command WorkStation; users can print to all three Fiery XJ print connections, but a WebSpooler User password is required to control jobs from the WebSpooler.

5. A designated administrator, a designated operator, no WebTool access

Only an administrator can perform Setup, and only an operator or administrator can perform calibration and control jobs from the Command W or kS tation; users can print to the Hold queue and the Print queue, but not to the Direct connection; the operator controls all job ﬂow, but jobs sent to the Print queue may not require operator intervention; no access to WebTools.

6. (Strictest control) A designated administrator, a designated operator, no WebTool access, operator controls all jobs

Only an administrator can perform Setup, and only an operator or administrator can perform calibration and control jobs from the Command W or kS tation; users can print only to the Hold queue; the operator alone controls job ﬂow; no access to WebTools.

Use these settings:

Enable Direct connection in Setup √ √ √ √ Enable Print queue in Setup √ √ √ √ √ Enable HTTP in Setup √ √ √ √ Set an Administrator Password in

Setup (strongly recommended) Set an Operator password in Setup

(from Command WorkStation) Set a WebSpooler User password in

Setup (from Command WorkStation)

(Least)

2 3 4 5 6

√ √ √ √ √

√ √ √ √

√ n/a n/a

(Strictest)

1-1 Fiery XJ on the network

Chapter 1: Connecting to the Network

This chapter summarizes the stages in setting up a Fiery XJ, and includes diagrams that refer you to other chapters or other manuals for completing your installation. If you check those references, you should be able to ﬁnd the information you need quickly.

Fiery XJ on the network

When the Fiery XJ is connected to a network, it behaves as a networked PostScript printer. The built-in Ethernet interface on the Fiery XJ supports three network protocols: AppleTalk, the lpd protocol of TCP/IP, and IPX (Novell). These three protocols (rules that enable computers on a network to communicate with each other) are supported on the Macintosh, Windows, and UNIX platforms and can run concurrently on the same Ethernet cable. Workstations that use other protocols can print through a server that uses one of the protocols mentioned, or they can print to the Fiery XJ parallel port. A Token Ring option is also available on some systems. The Fiery XJ is auto-sensing, and can handle all of these connections simultaneously.

When you add a Fiery XJ to a network, it is assumed that a network administrator will have already installed a network cabling system and connected workstations and servers, and perhaps one or more printers.

Stages of installation on the network

Installation can be performed by a network or printing administrator. The stages of a successful installation are:

• Physically connecting the Fiery XJ and Command W orkStation to a functioning netw ork

Prepare one network node each for the Fiery XJ and the Command WorkStation— obtain cable and route it to the location where the Fiery XJ will be installed (near the copier), and attach the cable to the network interfaces of the Fiery XJ and the Command WorkStation. See pages 1-9 and 1-14 for details.

• Conﬁguring network servers

When network servers are required, you need to conﬁgure those servers to provide client access to the Fiery XJ as a color PostScript printer. See Chapter 4 for conﬁguring network servers in Windows and UNIX network environments.

• Fiery XJ Setup

1-2 Connecting to the Network

• Client setup

• System administration

Conﬁgure the Fiery XJ for your particular printing and network environment. First read carefully “Before you proceed” in the Introduction, and then see Chapter 2 for details.

Install the ﬁles needed for printing and additional user software, and connect the client to the network. These steps are described in Getting Started and Chapter 4 of this manual.

Monitor and maintain system performance and troubleshoot problems that arise. See Chapter 5 and the Operator Guide for details.

1-3 Quick path to installation

Quick path to installation

The diagrams on the following pages show typical systems that can be used for printing and using the Fiery XJ Downloader. Find the page with your preferred platform and network type, and then look up the setup procedures referenced in the “Key to setup” at the top left of each diagram.

The diagrams describe devices that use the supported networking protocols. They are logical diagrams and are not intended to describe the physical arrangement (topology) of devices on the network. A variety of physical arrangements is possible with each logical arrangement. For example, twisted pair Ethernet networks commonly use a star conﬁguration around a hub, rather than a bus arrangement. The design of physical networks is beyond the scope of this manual.

If the network uses more than one protocol or more than one type of workstation, combine the setups listed for each component of your system. Note that multiple protocols (shown in the diagrams as parallel lines) can run on the same cable. A solid connection from the Fiery XJ with an arrow indicates that other supported network types can be operational at the same time.

The protocols used in these diagrams are indicated as follows:

IPX (Novell)

AppleTalk

lpd (TCP/IP)

Parallel

Other

1-4 Connecting to the Network

Networked Macintosh computers using AppleTalk

Key to setup:

1 Macintosh Getting Started 2 Fiery XJ Setup Chapter 2

Another supported protocol

Fiery XJ connected to copier

AppleTalk

AppleTalk protocol

Macintosh

Macintosh computers can print directly and run Fiery XJ Downloader

Macintosh

1-5 Quick path to installation

PC compatibles in a Novell environment

Key to setup:

1 NetWare server page 4-4 2 Fiery XJ Setup Chapter 2 3 NetWare client Getting Started 4 Windows 95 with SPX page 4-14,

Getting Started

Another supported protocol

Fiery XJ connected to copier

PC compatible

IPX protocol

SPX protocol (TCP/IP or AppleTalk possible)

IPX

PC compatible

Novell NetWare server

PC compatible

3, 4

IPX

SPX for running Fiery XJ Downloader

Printing on this network

All PC compatibles can print through the NetWare server

For running Fiery XJ Downloader

A PC compatible running Windows 3.1x or Windows 95 with IPX/SPX protocols loaded

The functionality outlined here also applies to Token Ring networks

1-6 Connecting to the Network

Windows NT Server environment

Key to setup:

1 Windows NT Server page 4-15 2 Fiery XJ Setup Chapter 2 3 Windows NT client page 4-22,

Getting Started

Another supported protocol

Windows NT Workstation or Windows NT Server acting as print server

LAN with NETBEUI, etc.

PC compatible

NETBEUI or other protocol available on the clients and the server

Windows NT Workstation or Windows NT Server with TCP/IP loaded

Fiery XJ connected to copier

lpd (TCP/IP) for printing TCP/IP for Fiery XJ Downloader

Printing on this network

PC compatible clients can print using a protocol available on the Windows NT print server; Windows NT machines can print using TCP/IP with lpd

For running Fiery XJ Downloader

A PC compatible running Windows NT Server or Windows NT Workstation, with TCP/IP loaded

TCP/IP protocol

1-7 Quick path to installation

UNIX workstations and PC compatibles on a TCP/IP network

Key to setup:

1 UNIX server/host page 4-25 2 Fiery XJ Setup Chapter 2 3 UNIX workstation page 4-25 4 TCP/IP client Getting Started,

page 4-25

5 Windows NT page 4-15

UNIX server or workstation

1, 3

Another supported protocol

Fiery XJ connected to copier

lpd (TCP/IP) protocol

TCP/IP client PC

lpd (TCP/IP)

Windows NT computer with TCP/IP loaded

Printing on this network

UNIX workstations with lpd protocol can print directly and act as host for shared printing

TCP/IP clients can print through UNIX server or directly

For running Fiery XJ Downloader

Requires PC compatible running Windows NT with TCP/IP and lpd loaded.

Fiery XJ Downloader is not available on UNIX workstations.

1-8 Connecting to the Network

Fiery XJ parallel port connection

Key to setup:

1 Fiery XJ Setup Chapter 2 2 PC compatible User Guide

With the parallel port enabled, the Fiery XJ can accept and print jobs sent to its parallel port.

Fiery XJ connected to copier

A supported network protocol

Parallel input

Protocol not directly supported on Fiery XJ

Parallel

PC workstation, server, or laptop

The rest of this chapter and the next cover the parts of an installation that are performed on the Fiery XJ itself. This chapter describes the physical network connections; Chapter 2 summarizes Fiery XJ Setup and other administrative functions available from the Control Panel and Command WorkStation.

In addition to Ethernet and parallel cabling, described in this chapter, a Token Ring option is available for some Fiery XJ models. See Appendix A for more information.

1-9 Before you begin

Before you begin

The following steps should be completed before you conﬁgure the Fiery XJ and workstations that will print to the Fiery XJ. A service technician will have performed some initial installation.

You need two network nodes, one for the Fiery XJ and one for the Command WorkStation.

TO PREPARE FOR FIERY XJ CONFIGURATION:

1. Make a copier test page to make sure the copier is functioning normally.

2. Power down the copier and connect the interface cable from the copier to the Fiery XJ.

While the Fiery XJ is powered down, verify that the SCSI terminator is installed on the SCSI connector on the back of the Fiery XJ.

3. To conﬁrm this connection, you can turn on the copier and the Fiery XJ and print a Test Page from the Control Panel.

To print a Test Page, press the oval Menu button on the Control Panel to display the Functions menu. (See “F iery XJ Control Panel ” on page 2-3.) Choose Print Pages, and then Test Page.

4. With both the copier and the Fiery XJ switched off, connect the network cable to the Fiery XJ, as described in the next section.

An Ethernet network should already be installed and operational.

5. Turn on the copier and then the Fiery XJ.

6. Prepare network servers to enable networked users to print to the Fiery XJ, and proceed to Setup.

See Chapters 2 and 4 for details.

7. Connect network cable to the Command WorkStation.

The connections are shown on page 1-12. Thinnet cable can be attached to the BNC connector without an external transceiver. (After the initial conﬁguration you can connect cable to the Fiery XJ and the Command WorkStation at the same time.)

1-10 Connecting to the Network

8. Conﬁgure the Command WorkStation connection.

See “Setting up the Command WorkStation” on page 1-14. After the Command WorkStation is connected, you can set up the Fiery XJ using the Command WorkStation interface.

Ethernet cable connection

The Fiery XJ supports the following types of Ethernet cabling:

• Thinnet (thin coaxial Ethernet cable or 10Base2)

Uses an external transceiver (media attachment unit, or MAU) to attach to the AUI (attachment unit interface) connector on the Ethernet interface of the Fiery XJ.

• Thicknet (thick coaxial Ethernet cable or 10Base5)

Cable connects directly to the AUI connector on the Ethernet interface of the Fiery XJ.

• Unshielded Twisted Pair (UTP), deﬁned as Category 3, 2-pair or 4-pair (10BaseT)

Uses an 8-pin RJ-45 connector that plugs into the RJ-45 socket on the Fiery XJ.

• Unshielded Twisted Pair (UTP), deﬁned as Category 5, 4-pair (100BaseT)

Uses an 8-pin RJ-45 connector that plugs into the RJ-45 socket on the Fiery XJ.

The Ethernet connectors lead to the Ethernet network adapter chip built into the main logic board of the Fiery XJ.

1-11 Ethernet cable connection

Back view of the Fiery XJ

Centronics-type parallel connector

AUI connector for thinnet and thicknet

RJ-45 connector for twisted pair Ethernet

Serial connector (not used)

Copier interface connectors

Slots for options

SCSI connector for external CD-ROM drive, for installing system software

Shut down the Fiery XJ before connecting it to any network device

NOTE: Do not attach the cable to more than one Ethernet connector on the Fiery XJ or

the Command WorkS tation at one time.

TO USE THINNET CABLE:

1. With the Fiery XJ and the Command WorkStation turned off, connect the transceiver to the AUI connector on the back of the Fiery XJ. Press down on the latch to lock the transceiver connection.

2. Connect the thinnet cable to the BNC connector on the transceiver.

3. Conﬁgure network servers for printing and then proceed to Setup.

Power switch

TO USE THICKNET CABLE:

TO USE ANY UTP (UNSHIELDED TWISTED PAIR) CABLE:

SCSI connector for attaching external disk drives

1-12 Connecting to the Network

1. With the Fiery XJ and the Command WorkStation turned off, connect the thicknet cable connector to the AUI connector on the back of the Fiery XJ. Press down on the latch to lock the connector.

2. Conﬁgure network servers for printing and then proceed to Setup.

1. With the Fiery XJ and the Command WorkStation turned off, connect the RJ-45 cable connector to the RJ-45 socket on the back of the Fiery XJ.

2. Conﬁgure network servers for printing and then proceed to Setup.

Back view of the Command WorkStation

Network connectors

(from left: BNC, AUI, RJ-45)

Power

Keyboard

NOTE: You can connect network cabling to the Command WorkStation the same way

you connect it to the Fiery XJ with one exception: the thinnet cable can be connected directly to the BNC connector without using a transceiver.

Mouse

(COM1)

Densitometer

Parallel

Monitor

(COM2)

1-13 Parallel cable connection

Parallel cable connection

In addition to receiving print jobs over Ethernet, the Fiery XJ can accept print jobs from a PC-compatible computer or server through its high-speed parallel port. This connection is advantageous for portable computers and for workstations on dedicated networks using protocols other than AppleTalk, TCP/IP, or IPX.

The parallel port connection is active at the same time as the Ethernet port.

NOTE: The Command WorkStation cannot be connected to the Fiery XJ over the

parallel port.

TO USE PARALLEL CABLE:

1. With the Fiery XJ and a PC-compatible computer or server turned off, attach the Centronics-type parallel cable to the parallel port of the Fiery XJ.

The parallel port is the top connector on the back of the Fiery XJ.

2. Connect the other end of the cable to the parallel port on the PC.

3. Turn on the computer and the Fiery XJ.

4. Proceed to Setup.

To print to the parallel port, you will need to set up the parallel port connection. See “Parallel P ort S etup options ” on page 2-20. For information on setting up printing, see Getting Started; for printing to the parallel port, see the User Guide.

NOTE: If your system requires both a parallel and an AUI (Ethernet) connection,

connect the parallel cable before connecting the transceiver and the Ethernet cable.

1-14 Connecting to the Network

Setting up the Command WorkStation

The Command WorkStation for the Fiery XJ allows you to control print jobs and print PostScript ﬁles at the Command WorkStation. In addition, the Command WorkStation provides a graphical interface that allows you to track jobs, change their priority, optimize hard disk space, keep queues current, maintain logs of user activity, and print non-network jobs.

Printing to the Fiery XJ

You can send jobs to the Fiery XJ from the Command WorkS tation as you would from any remote workstation. To print from applications, install the Adobe PostScript Printer Driver for Windows 95 and the printer description ﬁle (PPD) for the Fiery XJ (as described in Getting Started). To download ﬁles, open the Utilities shortcuts slider at the Command WorkStation and click the Downloader icon.

For information on printing or downloading ﬁles, see the User Guide.

Setting up IPX/SPX communication

The Command WorkStation is set up to communicate with the IPX/SPX networking protocol by default. Make sure that all settings are correct, as described in Getting Started.

Setting up TCP/IP communication

If you prefer, you can set up the Command WorkStation to communicate over TCP/ IP, instead of IPX/SPX. This requires deleting all existing Command WorkStation ﬁles and reinstalling the Command WorkStation software from the User Software CD, selecting TCP/IP as the desired protocol.

TO SET UP THE COMMAND WORKSTATION WITH TCP/IP:

1. Install TCP/IP communication software as described in your Windows 95 documentation.

2. In the Network Control Panel, select TCP/IP communication.

3. On your hard disk drive, ﬁnd the directory named CSTATION (the directory containing the cstation.exe ﬁle) and delete it.

1-15 Attaching external SCSI devices

4. Open the \WINDOWS directory and delete the ﬁle named NET_WSCK.INI.

5. Open the \WINDOWS\SYSTEM directory and delete the ﬁle named NET_WIPX.DLL.

6. Open the \WINDOWS\Start Menu\Programs directory and delete the ﬁle named

7. Open the \WINDOWS\Start Menu\Programs\StartUp directory and delete the directory

8. Reinstall the Command WorkStation application as described in “Installing Command

9. When the installation is complete, connect to the Fiery XJ as described in “Connecting

Command WorkStation.

named Command WorkStation.

WorkStation softw ar e” on page 3-9; select TCP/IP when pr ompted to choose a netw ork type.

to the server” on page 3-3.

Setting up the Fiery XJ Downloader

The ﬁrst time you start the Fiery XJ Downloader from the Command WorkStation or from any workstation, you must conﬁgure the Chooser list. For instructions, see Getting Started.

Attaching external SCSI devices

The Command WorkStation can be thought of as an independent computer. The Command WorkStation has a dedicated monitor, keyboard, mouse, and ﬂoppy disk drive. In addition, the SCSI port on the back of the Command WorkStation allows you to connect external SCSI devices for downloading ﬁles and fonts.

When the external drive is installed, you can use the Fiery XJ Downloader to download fonts and ﬁles from it.

NOTE: To download fonts, the Direct connection must be enabled.

Supported drives

The Command WorkStation supports the following media:

• Command WorkStation internal hard disk (c:)

An IDE (Integrated Drive Electronics) drive used to store the Command WorkStation operating software, MS-DOS, and the Microsoft Windows 95 operating system used by the Command WorkStation.

1-16 Connecting to the Network

• Floppy disk drive (a:)

The ﬂoppy disk drive, for 3.5-inch high density 1.44MB ﬂoppy disks, is used for downloading fonts and ﬁles to the Fiery XJ.

• External SCSI devices (d:, e:, f:, and so on)

The Command WorkStation SCSI bus simultaneously supports up to seven devices connected in a chain. The Command WorkStation is furnished with Adaptec device drivers, which support the following drives, provided the media use an MS-DOS format:

Hard disk drives Removable media drives that support 44MB and 88MB SyQuest-type removable

data cartridges with MS-DOS format (To create SyQuest-type cartridges with an MS-DOS format, contact the

manufacturer of your drive for the appropriate formatting utility.) CD-ROM drives (SCSI-2)

TO ATTACH AN EXTERNAL SCSI DEVICE TO THE COMMAND WORKSTATION:

1. Turn off the Command WorkStation (see “Shutting down the server and Command WorkStation” on page 3-8). If necessary, turn off any other external SCSI device also.

You do not need to turn off the Fiery XJ.

2. Connect the large 50-pin end of the SCSI cable furnished with the Command WorkStation to the external device.

1-17 Attaching external SCSI devices

3. Connect the micro-SCSI 50-pin end to the small SCSI connector on the back of the Command WorkStation.

Squeeze the sides of the micro SCSI connector as you plug it into the back of the Command WorkStation to secure the connection.

Connect SCSI cable from external device to SCSI connector on back of Command WorkStation

4. Attach the power cord from the external SCSI device to an outlet or power strip.

5. Make sure the SCSI ID on the external device is not set to 7.

SCSI ID 7 is reserved for the Command WorkStation. Also, make sure the external device has internal termination or an external terminator.

6. Plug in the SCSI devices, and switch them on.

Your SyQuest drive or CD-ROM drive should be turned on before you turn on the Command WorkStation; however , y ou can insert a S yQ uest cartridge or CD-ROM in the drive later.

7. Turn on the Command WorkStation (see “Starting the Fiery XJ and Command WorkStation” on page 3-1).

TO ATTACH MULTIPLE SCSI DEVICES TO THE COMMAND WORKSTATION:

1. Turn off the Command WorkStation. If necessary, turn off the external devices also.

You do not need to turn off the Fiery XJ.

1-18 Connecting to the Network

2. Connect the large 50-pin end of the SCSI cable furnished with the Command

3. Using SCSI peripheral cable (usually 50 pin to 50 pin), connect the second external

WorkStation to the external device, and connect the micro-SCSI 50-pin end to the small SCSI connector on the back of the Command WorkStation.

Squeeze the sides of the micro SCSI connector as you plug it into the back of the Command WorkStation to secure the connection.

device to the ﬁrst external device, the third to the second, and so on.

You can connect up to seven devices in a SCSI chain. They can be any combination of supported devices. Make sure that:

• The last device on the chain (farthest from the Command WorkStation) is

terminated.

• No two devices have the same SCSI ID or use SCSI ID 7, which is reserved for the

Command WorkStation.

• The devices and media are formatted with MS-DOS format, including the

removable media (44MB or 88MB SyQuest cartridges) for use in removable media hard disk drives.

4. Plug in the SCSI devices, and turn them on.

The SyQuest drive or CD-ROM drive should be turned on before you turn on the Command WorkStation; however, you can insert a SyQuest cartridge or CD into the drive later.

5. Turn on the Command WorkStation (see “Starting the Fiery XJ and Command WorkStation” on page 3-1).

2-1 About Fiery XJ Setup

Chapter 2: Setting up the Fiery XJ

The Fiery XJ+ 525 Color Server ﬁts into a variety of work environments. To prepare for printing at your site, you need to do some initial conﬁguration to specify the network environment and the kind of printing you will do.

NOTE: Before you can set up the Fiery XJ, you must decide what levels of access you

will implement for your site. (See page xiii.)

About Fiery XJ Setup

Setup is required the first time the Fiery XJ is powered on after new system software is loaded. In this initial Setup, you (or the service technician who loads the software) choose the language you want to use for Control Panel screens.

Initial Setup on the Control Panel

In initial Setup, the server, network, and printer have to be set up, in that order, on the Control Panel. Default settings are adequate for getting the Fiery XJ to reach Idle, but not for full functionality. Also, during initial Setuzp you conﬁgure a network connection between the Fiery XJ and the Command WorkStation. After you become more familiar with your options you can reset them according to your network and user environment.

Making changes to Setup

After initial Setup, you can change the Setup either on the Control P anel (page 2-2), or on the Command WorkS tation (page 2-30). The options are almost identical in both cases. You may ﬁnd it easier to make changes in Setup from the Command WorkStation; setup options are grouped in a series of dialog boxes.

Network server setup requirements

On IPX networks and on some TCP/IP networks, the network servers must be conﬁgured for printing to the Fiery XJ before you enter network settings on the Fiery XJ. The diagrams on pages 1-4 through 1-8 give chapter references for network server setup.

You need a live network connection so the Fiery XJ can query the network for zones, servers, and server-based queues.

2-2 Running Setup on the Control Panel

Whenever the conﬁguration of servers, printers, or the network itself changes at your site, you can alter individual settings to correspond to the changed environment. Likewise, if printing needs or administrative requirements change, you can alter the corresponding settings.

NOTE: Changing network or port settings may require that you make changes in more

than one Setup menu or group.

Running Setup on the Control Panel

Setup, performed on the Control Panel right after powering on the Fiery XJ, conﬁgures it to communicate with other devices and manage print jobs.

There are four groups of Setup options:

Use this group of options: To specify:

Server Setup System options Network Setup All the active network systems that will transmit print

jobs to the Fiery XJ

Printer Setup The way print jobs and queues are managed on the

color Fiery XJ

Job Log Setup How the Fiery XJ handles its log of printed jobs

The Setup menus also allow you to create and change an Administrator password, and clear the jobs queued on the server.

2-3 Running Setup on the Control Panel

Accessing Setup options

The Control Panel on the front of the Fiery XJ enables you to set options and view information about jobs printed to the Fiery XJ.

It comprises the following parts:

• Display window showing status information and options for setting up the Fiery XJ

• Line selection buttons

• Up and down arrow buttons

• Menu button (escape)

• Activity light that indicates normal or problem activity

Fiery XJ Control Panel

Activity light

Fiery XJ at Idle (ready)

Up and down arrow buttons

Menu button

Server Name

Idle

2.2 GB 4.2

Server Info

NOTE: Make sure that the display says Idle before attempting to access Setup.

Line selection buttons

2-4 Running Setup on the Control Panel

For software update or setup, press any key.

Run Setup Install Software Format Disk

Start Up

Exit Setup Server Setup Network Setup Printer Setup

Setup

Job Log Setup Change Password Clear Server

Setup

TO ACCESS SETUP WHEN THE FIERY XJ IS AT IDLE:

Print Pages Suspend Printing Resume Printing Reboot Server

Functions

1. When the Fiery XJ displays the Idle screen, press the oval Menu button on the Control

Panel to go to the Functions menu.

2. Press the button to choose Reboot Server.

After automatic startup diagnostics, the Fiery XJ displays the entry screen.

3. At the startup message, press any button.

The Start Up screen is displayed.

4. Choose Run Setup to access all Setup menus.

The Install Software and Format Disk commands are for service technicians.

5. Press the line selection button to choose a Setup menu or command.

Press the down arrow to view the second screen of the main Setup menu.

6. Choose Setups in the same order as they appear in the menu: Server Setup, Network

Setup, Printer Setup, and then Job Log Setup.

The sequence is important for initial Setup. Later, just go directly to the menu you want to change. However, if you make

changes in Network Setup, y ou may need to change some settings in P rinter Setup as well.

NOTE: If you make changes in Server, Network, or Printer Setup, you’ ll need to update

the system conﬁguration by opening and saving the other Setups even if you haven’t changed any other settings.

2-5 Running Setup on the Control Panel

TO ACCESS SETUP WHEN THE FIERY XJ IS OFF:

1. Make sure the Fiery XJ is connected to the copier and connected to the network you will use.

2. Turn on the Fiery XJ.

Startup diagnostics messages appear.

3. At the startup message, press any button.

4. Continue with step 4 from the previous procedure.

About the Control Panel Setup interface

When you choose Run Setup on the Control Panel, you can select one menu after another and enter information about your Fiery XJ and your network and printing environment.

In each Setup, the last line of the display window tells you the name of the current Setup menu. The screens you see are shown on the Control Panel Map, a ﬂowchart that can be printed from the Control Panel.

TO PRINT THE CONTROL PANEL MAP:

1. At the Control Panel, press the oval Menu button to access the Functions menu.

2. Press the button for Print Pages.

The Control Panel displays the ﬁrst four types of pages you can print. (To see the remaining types of pages, press the down-arrow key.)

3. Press the button for Control Panel Map.

2-6 Running Setup on the Control Panel

Types of Setup screens

There are two types of Setup options:

Multiple choice

questions

Information entry

options

You are given choices (for example, Yes or No, or a list of options from which to choose). Only one choice is displayed at a time, in highlighted text. The currently selected (or the default) value appears ﬁrst.

Use the up and down arrow buttons to scroll through the selections, and choose OK when the correct information is displayed.

You must specify the information for your site. For example, the printer name or IP address.

In that case, use the up and down arrow buttons to scroll the alphabet and numerals to make your selection.

The cursor position is made evident, and two of the line selection buttons become left and right buttons. Arrows appear on the display window next to the corresponding buttons. Use these buttons to move between positions for entering information.

NOTE: When you enter text, enter it from left to right, as

the left-arrow button acts as a delete key as well as a cursor-moving key. This is indicated in the display by the delete symbol ( ).

Example: Multiple choice

Publish Print Queue

Yes

Printer Setup

Press the up or down arrow button to display the other option or options.

Publish Print Queue

Printer Setup

When the setting you want is displayed, press the button beside OK to continue.

2-7 Running Setup on the Control Panel

Example: Information entry with ﬁelds

Subnet Mask

255.0.0.0 >

< OK

TCP/IP Setup

From the starting position, press the right arrow button to move the cursor to the right.

Example: Information entry with individual characters

Enter Your File Server Password >

IPX (Novell) Setup

From the starting position, press the up or down arrow button to enter the ﬁrst character.

Subnet Mask

255.0.0.0 > < OK

TCP/IP Setup

The next ﬁeld is selected. Press the up or down arrow button to change the number.

Enter Your File Server Password >

IPX (Novell) Setup

When the correct character is displayed, press the right arrow button to move the cursor to the next position.

Subnet Mask

255.255.0.0 > < OK

TCP/IP Setup

When the correct number is displayed, press the right arrow button to move to the third ﬁeld. Press the left arrow to go back and edit, or press OK to accept the choice and continue.

Enter Your File Server Password > 9 OK

IPX (Novell) Setup

Press the up or down arrow to enter a character in the second position. The delete button erases the current character and moves the cursor to the left.

OTE: If you make a mistake during Setup, you can always use the Menu button to

cancel without saving changes. If you are viewing a Setup screen, pressing the Menu button cancels what you are doing in the current screen to bring you to the next higher level menu. You can start the current Setup again, or exit without making changes.

When you have entered all the settings or made all the changes you want, you need to save the changes. For most Setups, a screen prompts you to save changes. When you ﬁnish Network Setup for all the protocols you use, choose prompted to save changes. If you choose Yes, your settings overwrite previous settings. If you choose No, your previous settings are retained.

The Fiery XJ reboots after you exit from the Setup menu.

Exit Network Setup; you are

2-8 Server Setup options

Server Setup options

The Server Setup menu enables you to specify system information that pertains to the Fiery XJ itself and all users. To access the Control Panel Setup menu, see page 2-3.

Exit Setup Server Setup Network Setup Printer Setup

Setup

When you choose Server Setup, the options appear in sequence, as described below. Default values, where applicable, are shown in square brackets.

Server Name Fiery XJ

Use this option to give the F iery XJ a name (up to 10 characters long). This is the name that will appear in the Chooser on an AppleTalk network. This is also the server name that you will enter when conﬁguring the server for the Chooser list from the Command WorkStation or from the Fiery XJ Downloader with the IPX/SPX protocol.

If you have multiple color servers and give them the same name, a unique number is appended to the name that appears in the Chooser. Although this routes jobs corr ectly, it may be inconvenient for users and is not a recommended practice.

System Date

Use this option to change the system date. The date is entered in the form

MM/DD/YY (Month/Day/Year) in all languages. The date is used on the cover page and

on Job Logs.

System Time

Press button for Server Setup

Use this option to change the system time. Enter the time based on the 24-hour clock in the form HH:MM (Hours:Minutes). The time is used on the cover page and on Job Logs.

Print Start Page No/Yes [No]

Use this option to specify whether the Fiery XJ should print a start page every time it is powered on. The start page displays information about the Fiery XJ, including the server name, current date and time, amount of memory installed in the Fiery XJ, last calibration date, network protocols enabled, and connections published.

2-9 Server Setup options

When Print Start Page is set to Yes, the Fiery XJ must be connected to a copier before it can reach the Idle status screen.

Use Character Set Macintosh/DOS/Windows [Macintosh]

Use this option to specify whether the Control Panel should use the Macintosh, DOS, or Windows character set for displaying ﬁlenames. This is important if ﬁlenames include accented or composite characters (such as é, ü, or æ).

For mixed-platform networks, choose the predominant client type, or whichever option gives better overall representation of the special characters you use.

Parallel Port Disabled/Enabled [Disabled]

Select Enabled if you are planning to print from a computer connected to the parallel port on the Fiery XJ. Select Disabled if you plan to use only a network connection.

Enable Printed Queue Yes/No [Yes]

Select Yes if you want to enable the Printed queue, which creates a storage location on the Fiery XJ disk for recent jobs printed from the Print queue. Users who have access to the Command WorkStation (with Operator or Administrator privileges), or to the WebSpooler (with User privileges), can reprint jobs from the Printed queue without sending them to the Fiery XJ again. If you select disk immediately after they are printed.

Jobs Saved in Printed Queue 1-99 [20]

This option appears only if Enable Printed Queue is set to Yes. Specify the number of jobs to be stored in the Printed queue. Note that jobs in the Printed queue take up space on the Fiery XJ hard disk.

Save Changes Yes/No [Yes]

Select Yes to activate any changes made in the Server Setup; select No to return to the main Setup menu without making any changes.

No, jobs are deleted from the Fiery XJ

2-10 Network Setup options

Network Setup options

Network Setup conﬁgures the F iery XJ to receive print jobs over the networks that will be used at your site.

Exit Setup Server Setup Network Setup Printer Setup

Setup

Exit Network Setup Ethernet Setup Token Ring Setup Parallel Port Setup

Network Setup

TO ACCESS NETWORK SETUP OPTIONS:

In the Setup menu, you choose Network Setup. The Network Setup menu lets you choose the communication types: Ethernet,

Token Ring, and Parallel Port. Each type has its own Setup, and in the case of Ethernet, its own menu with three protocols that can be used with Ethernet cabling.

For each enabled protocol, you are prompted to enter settings pertaining to that protocol. This is the place to specify network addresses and names to be used by workstations, servers, and the Fiery XJ when they communicate with each other.

You need display and select options only for the network systems that are currently used at your site. If your network requirements change, you can change the Network Setup at any time.

Parallel port Setup is included under Network Setup. If you plan to print to the Fiery XJ parallel port, you must ﬁrst enable the parallel port in Server Setup.

If the Fiery XJ is conﬁgured to enable more than one protocol, it automatically switches to the correct protocol when it receives a print job. When the parallel port and one or two network ports are enabled, print jobs can be received over all of those ports at the same time. Default values, where applicable, are shown in square brackets.

1. Conﬁrm that the network cable is connected to the Fiery XJ.

During Network Setup , the Fiery XJ queries the network for zones, servers, and serverbased queues. If you perform Network Setup without a connected and functioning network, default settings are used that may not fulﬁll your needs.

2. Choose Network Setup from the main Setup menu.

3. To use Ethernet, choose Ethernet Setup, choose the pr otocol, and enter the appropriate settings.

2-11 Network Setup options

4. When you have ﬁnished entering settings for one protocol, select another protocol, or

5. To use Token Ring, choose Token Ring Setup, and then choose the appropriate Token

6. To use the parallel port, choose Parallel Port Setup and enter the appropriate settings.

7. When you have ﬁnished entering network settings, choose Exit Network Setup.

8. Choose Yes when prompted to save changes.

9. From the main Setup menu, choose another Setup or choose Exit Setup.

choose Exit Ethernet Setup.

Ring and IPX settings.

For initial Setup, or if you have conﬁgured a new connection, choose Printer Setup after you ﬁnish Network Setup.

Ethernet Setup options

Exit Ethernet Setup AppleTalk Setup TCP/IP Setup IPX (Novell) Setup

Ethernet Setup

Network Setup

Ethernet Setup

You can enable AppleTalk, TCP/IP, and IPX (Novell) communication simultaneously over Ethernet cabling. To conﬁgure the Fiery XJ, choose each protocol and enter the settings for that protocol. Since network setups are nested, the names of higher-level menus are shown in this chapter to the left of each menu heading.

AppleTalk Setup

Enable AppleTalk Yes/No [Yes]

Select Yes if you have an AppleTalk network connected to the Fiery XJ. This setting enables the Fiery XJ to communicate over AppleTalk networks.

AppleTalk Zone [List of zones]

The Fiery XJ searches the network for A ppleTalk zones. Scroll through the list to select the AppleTalk zone in which you want the Fiery XJ to appear. If you do not enter a zone, the Fiery XJ is assigned to the default AppleTalk zone.

The alert No AppleTalk zone found may mean your network has no zones, or the network cable is not connected (see page 5-4). Choose OK.

Network Setup

Ethernet Setup

2-12 Network Setup options

Choose another protocol, or choose Exit Ethernet Setup.

TCP/IP Setup

Enable TCP/IP Yes/No [No]

Select Yes if you have a TCP/IP network connected to the Fiery XJ.

NOTE: If you are using TCP/IP for printing from Windows NT workstations,

enabling TCP/IP here also enables you to use the Fiery XJ Downloader from Windows NT workstations using TCP/IP protocols. At the same time, enabling TCP/IP lets you use the Fiery XJ Downloader from Windows 95 computers using IPX/SPX protocols.

IP Address [127.0.0.1]

Enter the Fiery XJ IP address for printing with TCP/IP or accessing the Fiery XJ with the Fiery WebTools. The Fiery XJ is shipped with an invalid IP address. If you plan to print with TCP/IP, you must ﬁrst assign the Fiery XJ a unique, valid IP address. This IP address is all that is required to identify the Fiery XJ on your network; you do not need to give the Fiery XJ a host name. For information about setting up printing with TCP/IP, see Chapter 4.

Subnet Mask [255.255.255.0]

This option lets you modify the subnet mask for printing with TCP/IP. If you notice that some, but not all, users can print to the Fiery XJ using TCP/IP, you may need to set the subnet mask. If you did not set the IP address for the Fiery XJ, the subnet mask is set to 255.255.255.0 by default. If you set the IP address and you need to set the subnet mask, enter one of the following values:

255.0.0.0 if the IP address starts with a number less than 128

255.255.0.0 if the IP address starts with a number between 128 and 191

255.255.255.0 if the IP address starts with a number that is greater than 191

Network Setup

Ethernet Setup

2-13 Network Setup options

Gateway Address [127.0.0.1]

Use this option to set the gateway address for printing with TCP/IP. By default, no gateway address is set. If your TCP/IP network has a gateway and users outside the gateway plan to print to the Fiery XJ using TCP/IP, you must enter the gateway address here.

Enable HTTP Yes/No [No]

Select Yes to enable Internet or intranet access to the Fiery XJ via the WebTools.

Choose another protocol, or choose Exit Ethernet Setup.

IPX (Novell) Setup

Before entering IPX (Novell) settings, be sure the Fiery XJ is connected to the network and you have already conﬁgured one or more NetWare ﬁle servers with a Print Server and a Print Queue for F iery XJ jobs (see page 4-4). The NetWare server must be running. You need a login name, and if access to the ﬁle server or print server is restricted, you need a login password.

NOTE: The terms NetWare server, Novell server, and IPX ﬁle server are used here

interchangeably to mean the server on an IPX network running Novell NetWare networking software.

Enable IPX (Novell) No/Yes [No]

Select Yes if you have an IPX (Novell) network connected to the Fiery XJ over Ethernet.

You may select Yes if you are using an IPX/SPX network between one or more Windows 95 workstations and the Fiery XJ to run the Fiery XJ Downloader. If you don ’t have a Novell server, you can still use the Fiery XJ Downloader by enabling TCP/IP. Note that additional conﬁguration is needed after you have enabled network communication here (see page 4-14).

NOTE: If your IPX network uses Token Ring to communicate with the Fiery XJ, use the

separate Token Ring Setup from the Network Setup menu (see page 2-19).

2-14 Network Setup options

Select Frame Type Ethernet 802.3/Ethernet 802.2/Ethernet II

Select the frame type used between the NetWare server(s) and the Fiery XJ. Although some models support additional frame types, only one frame type can be used.

If the IPX/SPX network does not include a NetWare server, select the frame type that is used on the workstation or workstations that will print to the Fiery XJ. For those networks press OK after selecting the frame type, and then press the menu button, since the remaining IPX (Novell) Setup options do not apply.

IPX (Novell) Setup menu

Because you can set up more than one Novell server to handle Fiery XJ print jobs, an additional menu is displayed for this purpose. The options are:

Exit IPX Setup Add File Server View Server List Edit Connection

IPX (Novell) Setup

Remove File Server

IPX (Novell) Setup

• Add File Server creates a new file server connection to the Fiery XJ. You can set up

as many as eight file server connections to handle Fiery XJ print jobs over Ethernet, and eight over Token Ring. (It is possible for both Ethernet and Token Ring hardware to be active on the same ﬁle server.) After you have ﬁnished adding a new server, you return to the IPX (Novell) Setup menu, and you can set up another if you wish.

Remember that after adding a ﬁle server, you hav e to ﬁnish Setup in P rinter Setup (see page 2-23).

View Server List displays the list of file servers that have already been selected to

•

communicate with the Fiery XJ.

• Edit Connection lets you change the NetWare Print Server that will print to the

Fiery XJ, and change the poll interval.

• Remove File Server lets you disconnect the Fiery XJ from a file server to which it

is currently connected. Remove a ﬁle server when you want to reduce the number of connections to the Fiery XJ or re-assign the connection to a different NetWare ﬁle server.

• Exit IPX Setup after you have viewed a list of file servers or removed a file server

from the list.

NOTE: If you change your mind about any of the menus you have selected, you can

use the Menu button to escape and return to the main IPX (Novell) Setup menu.

2-15 Network Setup options

Network Setup

Ethernet Setup

IPX (Novell) Setup

Add File Server

This option gives you two ways to add a Novell NetWare ﬁle server. Select File Server

From List/Search Name

You can select the ﬁle server from a scrollable list or search by name. Choose

From List if your network doesn’t have a large number of file servers. Select Search Name

if the number of file servers is so large that scrolling through the list would take

a long time. If you selected From List: If you selected Search Name:

Add Server [list of all servers]

The Fiery XJ obtains a list of NetWare ﬁle servers by querying the IPX network. Use the up and down arrows to select a NetWare ﬁle server from the list. Choose the server on which you have conﬁgured a print server and print queue to handle Fiery XJ print jobs.

Enter First Letters of Server Name

Use the up and down arrows to enter the ﬁrst letters of the name of the ﬁle server you want to use, and choose OK.

Add Server [list of servers matching the search]

This option is displayed if you entered letters to search. Scroll to select the server you want from the list.

Once you have chosen a ﬁle server, the Fiery XJ immediately tries to log in as guest without a password. If it succeeds, it skips to the NetWare Print Server option.

If you try to add a ﬁle server but all Fiery XJ connections are already being used, you are prompted to remove a ﬁle server (see page 2-18).

File Server Login administrator/supervisor/Enter Login Name [supervisor]

This option appears only if a password is required for login. Choose Enter Login Name to enter your own login name and password or to log in as a guest. Choose

administrator or supervisor if you have those privileges.

2-16 Network Setup options

Enter Your Login Name [guest]

This option and the next only appear if you selected Enter Login Name for the File

Server Login

Enter Your File Server Password

Enter the password for logging in to your NetWare ﬁle server. If you enter the password incorrectly, you are prompted to re-enter it.

NetWare Print Server [list of print servers on selected file server]

This option appears only if there is more than one print server deﬁned on the selected Novell ﬁle server. From the list of print server names, select the name of the print server that you have conﬁgured in the NetWare utility PCONSOLE. This is the print server that will route print jobs to the Fiery XJ from computers on IPX networks.

Enter Your Print Server Password

This option appears only if your NetWare print server is set up to require you to log in with a password. Enter your print server password.

. Enter your login name or select guest.

NetWare Server Poll Interval in Seconds 0-3600 [15]

Specify the interval, in seconds, at which the Fiery XJ communicates with the Novell server to see if there are print jobs waiting. If you specify as frequently as possible for your network conﬁguration.

NOTE: If you select a short interval, the amount of network trafﬁc increases. This may

slow down other network jobs.

0, the Fiery XJ polls the server

Network Setup

Ethernet Setup

IPX (Novell) Setup

Network Setup

Ethernet Setup

IPX (Novell) Setup

2-17 Network Setup options

View Server List

Supported Servers

This option lets you view the file server(s) currently connected to the Fiery XJ, that is, servers you have added in IPX (Novell) Setup. You are notiﬁed if there are none. When you choose OK, you return to the IPX (Novell) Setup menu.

Edit Connection

On each connected NetWare ﬁle server, you have deﬁned a print server to handle Fiery XJ print jobs. Use this option to change the print server assigned to the Fiery XJ or to change the poll interval.

Choose File Server [File server name]

From the list of connected NetWare ﬁle servers, choose the ﬁle server whose print server you wish to change.

NetWare Print Server [List of print servers on selected file server]

Choose the name of the print server that you now wish to use. This is the print server that will route print jobs to the Fiery XJ from computers on IPX networks.

If you change your mind, press the Menu button to return to the IPX (Novell) Setup menu without making a change.

Enter Your Print Server Password

This option appears only if your NetWare print server is set up to require you to log in with a password. Enter your print server password.

Network Setup

Ethernet Setup

IPX (Novell) Setup

2-18 Network Setup options

NetWare Server Poll Interval in Seconds 0-3600 [15]

Specify the interval, in seconds, at which the Fiery XJ communicates with the Novell server to see if there are print jobs waiting. If you specify 0, the Fiery XJ polls the server as frequently as possible for your network conﬁguration.

NOTE: If you select a short interval, the amount of network trafﬁc increases. This may

slow down other network jobs.

After you select the poll interval, the IPX (Novell) Setup menu is displayed again. Choose Add Server again until you have connected each NetWare ﬁle server you have conﬁgured for printing to the Fiery XJ. When you have added all the IPX ﬁle servers for your site, choose Exit IPX Setup.

Remove File Server

Network Setup

Ethernet Setup

IPX (Novell) Setup

Remove support for [File server name]

Allows you to select a NetWare ﬁle server from a list of connected ﬁle servers and remove the connection to it. You are notiﬁed that you have removed the connection, and returned to the IPX (Novell) Setup menu. If you change your mind and don’t want to remove any of the ﬁle servers, press the Menu button.

You can choose another IPX (Novell) Setup option (such as adding another ﬁle server) or choose Exit IPX Setup.

Exit IPX Setup

Choose Exit IPX Setup after you have viewed a list of IPX ﬁle servers, after you have removed a ﬁle server from the list, or after you have connected all the conﬁgured NetWare ﬁle servers. After you select Exit IPX Setup, you return to Ethernet Setup.

Network Setup

Token Ring Setup

2-19 Network Setup options

Token Ring Setup options

This Setup can be used only if your system has the Token Ring option installed. Token Ring networks used with the Fiery XJ use IPX protocols. After enabling Token Ring and selecting the maximum frame size, you continue with IPX (Novell) S etup. You can set up a maximum of eight Token Ring connections, but you have to conﬁgure a different NetWare ﬁle server for each Token Ring connection.

Enable Token Ring Yes/No [No]

Select Yes if you use Token Ring. When you select Yes, the Fiery XJ veriﬁes the Token Ring hardware conﬁguration.

Maximum Frame Size (bytes) 632/4216/17690 [4216]

Select the maximum size (in bytes) of the data frame for the Token Ring network. In general, you should leave this at the default 4216. If your network requir es it, you can change the value.

The Fiery XJ conﬁgures the Token Ring hardware, and then displays the IPX (Novell) menu (page 2-14). The options are the same as for IPX on Ethernet networks, except that the networks.

From the IPX (Novell) menu, choose Add File Server. See page 2-15 for details.

When you have connected all the servers you have conﬁgured for the Token Ring network, choose another IPX (Novell) Setup option or choose

NetWare Server Poll Interval does not apply to Token Ring

Exit IPX Setup.

Network Setup

Parallel Port Setup

2-20 Network Setup options

Parallel Port Setup options

Parallel port printing is enabled in Server Setup; port setup is completed in Network Setup. You must have set the Server Setup Parallel Port option to Enabled in order to print to the parallel port and enter the Parallel Port Setup options.

Enable Parallel Port No/Yes [No]

OTE: Select Yes if you want to print through the parallel port. You can connect a

single PC compatible to the parallel port and print directly to the Fiery XJ.

Port Timeout in Seconds 5-60 [5]

This option appears only if Enable Parallel Port is set to Yes. Your setting determines how long the Fiery XJ waits without receiving data from the parallel port before deciding that the current job is complete. Until the timeout, the Fiery XJ cannot receive new jobs through the parallel port, but it can continue to receive network print jobs.

Ignore EOF Character Yes/No [Yes]

This option appears only if Enable Parallel Port is set to Yes. This option speciﬁes that the Fiery XJ should ignore end-of-ﬁle (EOF) messages in a ﬁle. This option must be set

Yes to print PostScript ﬁles in binary format (not ASCII); under normal

to circumstances, it should be set to No. When this option is set to Yes, the Fiery XJ uses the parallel port timeout value to determine when the end of the ﬁle has been reached.

When you have conﬁgured the parallel port options, choose another network type and protocol, or choose Exit Network Setup and proceed to Printer Setup.

2-21 Printer Setup options

Printer Setup options

Printer Setup conﬁgures the connections and printing behavior associated with a particular printing device.

Exit Setup Server Setup Network Setup Printer Setup

Setup

1. In the main Setup menu, choose Printer Setup.

2. Enter the options appropriate to the printing requirements at the site and the netw ork

protocol or protocols you use.

3. When you have ﬁnished, save changes.

Printer Setup includes the following general steps:

• Publish the Direct connection and Print queue

• Specify the printer’s defaults. Setting these defaults is particularly important for

systems that don ’t transmit printer options or overrides from applications to printers (for example UNIX, the DOS command line, and systems that use PostScript Level 1 printer drivers).

• For IPX (Novell) networks, specify a connection (Direct, Print queue, or Hold

queue) for each Novell ﬁle server that is supported

• Specify the Fiery XJ connection for parallel jobs when a parallel connection is

enabled

Default values, where applicable, appear in square brackets.

Publish Direct Connection Yes/No [Yes]

This option enables users to print (or download) jobs to the Fiery XJ without spooling. Note that jobs printed to the Direct connection are not saved in the Printed queue.

If you plan to download fonts from any system to the Fiery XJ, you must publish the Direct connection. If you do not want users to print to Direct, choose No.

Publish Print Queue Yes/No [Yes]

This option enables users to print (or download) jobs to the Print queue. J obs that are printed to the Print queue are spooled on the Fiery XJ disk. Only connections published in the Printer Setup are available to remote users. If no connections are published, all jobs are sent to the Hold queue.

2-22 Printer Setup options

If you set Enable HTTP to Yes, in order to make the WebTools available, you must publish the Print queue.

IPX (Novell) options in Printer Setup

The following options are displayed only if in Network Setup you selected Yes for

Enable IPX (Novell) and you configured E thernet or Token Ring servers. You attach an

IPX (Novell) ﬁle server to the DocuColor 40 and to a Fiery XJ connection (Direct, Print queue, or Hold queue).

Repeat for each Novell ﬁle server you have conﬁgured to print to the Fiery XJ. If you change your mind about an option you have selected, press the M enu button to

escape. You are prompted to Save Changes, and you return to the main Setup menu.

IPX File Servers View List/Attach [View List]

Choose Attach to attach an IPX ﬁle server to one of the published connections. Choose

View List if you want to see a list of the file servers already attached.

If you selected View List: If you selected Attach:

Attached IPX File Servers

Use the up and down buttons to scroll through the list of ﬁle servers that have been attached to the Fiery XJ in Printer Setup (not in Network Setup).

There are two possible situations:

• If all the previously conﬁgured ﬁle servers are attached to a Fiery XJ connection, pressing OK skips the remaining IPX options.

• If one or more ﬁle servers are not attached you see a partial list of servers. If no ﬁle servers have been attached, the only item in the list is None attached. When you press OK,

Unattached file server detected appears

brieﬂy, followed by a prompt to attach a ﬁle server.

Attach a File Server? Yes/No

Choose Yes to attach a ﬁle server.

Attach Novell File Server

[File Server 1]

See below for explanation.

2-23 Printer Setup options

Attach Novell File Server [File Server 1]

Use the up and down buttons to scroll through a list of all IPX ﬁle servers that were added (with Add File Server) in the IPX (Novell) part of Network Setup . An asterisk (*) beside the name indicates that the ﬁle server is already connected.

Cable to Novell File Server Ethernet/Token Ring [Ethernet]

This option appears only if both IPX (Novell) and Token Ring were enabled in Network Setup, and if the selected N o vell ﬁle server has both Ethernet and T oken Ring cabling. Specify the network cabling that will be used between the selected ﬁle server and the Fiery XJ.

Connection for [File Server 1] Print queue/Hold queue/Direct connection

Select the Fiery XJ connection that should be used for jobs originating from the named ﬁle server. Only the Hold queue and any connections you published earlier in Printer Setup are displayed as choices. If only one connection is enabled (the Hold queue), you will not see this question.

NOTE: You must select a connection here for each ﬁle server you added in Network

Setup if you want all NetWare clients to be able to connect or print to the Fiery XJ.

Attach another File Server? Yes/No [Yes]

This option is displayed only if there is still an unattached server. I f you select Yes, the

Attach Novell File Server screen is displayed again. After you select another file server,

you are prompted to select the connection for it from among the published connections.

You can attach a maximum of 16 NetW ar e ﬁle servers to F iery XJ queues (a maximum of 8 over Ethernet and 8 over Token Ring).

Parallel Connection Print Queue/Hold Queue

Use this option to determine whether jobs printed to the parallel port are sent to the Print queue or Hold queue. Only the currently enabled queues are displayed.

This option appears only if you selected Enabled for the Parallel Port option in Server Setup.

2-24 Printer Setup options

NOTE: If only one of the queues is enabled (the Hold queue), this option does not

appear and parallel port jobs are automatically printed to that queue.

Compression On/Off [On]

Select On to enable compression, so that jobs are printed at high quality with up to 1/200 of the memory normally required. Select Off if you prefer to disable this feature.

Default Paper Sizes US/Metric [default depends on language]

Specify whether to print on US paper sizes (for example, letter, legal, tabloid), or Metric paper sizes (for example, A4, A3) by default. When no page size is deﬁned within a PostScript ﬁle, jobs are printed on Letter paper if you selected US, or A4 paper if you selected Metric.

Convert Paper Sizes No Letter/11x17->A4/A3 A4/A3->Letter/11x17 [No]

Specify whether to convert paper sizes in documents automatically to the default paper sizes speciﬁed. For example, if you selected Letter/11x17->A4/A3, a letter size document would automatically be printed on A4 paper. If you select No, the server only prints the document if it ﬁnds a media source in the size speciﬁed by the ﬁle.

Print Cover Page No/Yes [No]

Use this option to specify whether the Fiery XJ prints a cover (job summary) page at the end of each print job. If you select Yes, each print job is followed by a page containing the name of the user who sent the job, the document name, the color server name, the time the job was printed, the number of pages printed, and the status of the job. If a P ostScript err or occurs and the Print to PS Error option is set to Yes, the status entry will be the PostScript error message.

Allow Courier Substitution Yes/No [Yes]

Specify whether to substitute Courier for fonts that are unavailable when you download P ostScript ﬁles to the F iery XJ. If this option is set to No, jobs with fonts that are not available on the Fiery XJ hard drive will not print, and you will get a P ostScript error.

2-25 Administrative functions in the Setup menu

Print to PS Error No/Yes [No]

Use this option to specify whether the Fiery XJ should print the available portion of a print job when it encounters a PostScript error. Select Yes to print the portion of the job that was processed before the error occurred; select No to cancel the print job entirely when a PostScript error is encountered. We recommend leaving this option at

No unless you encounter printing problems.

Enable Bypass Tray as default No/Yes [No]

Select Yes to specify that jobs should be printed from the bypass tray. Use this option to enable printing from the bypass tray when tray selection is not otherwise available in the interface, such as when printing from the command line (lpr or DOS). In general, select No when the interface permits tray selection on a job-by-job basis.

Detect Black as default No/Yes [Yes]

Select Yes to specify that jobs should be scanned before being printed to detect blackonly pages. Black detection allows for accurate billing of black-and-white pages and increases the printing speed of jobs containing multiple black-only pages.

Save Changes Yes/No [Yes]

Select Yes to activate any changes made in the Printer Setup; select No to return to the main Setup menu without making any changes.

Administrative functions in the Setup menu

The remaining options in the Setup menu are intended to help you manage print jobs and color output, but are not required for printing:

Use this option: To do this:

Job Log Setup Specify whether you want the Fiery XJ to print and clear its

log of printed jobs automatically. See the next section for details.

2-26 Administrative functions in the Setup menu

Use this option: To do this:

Change Password Enable you to create an Administrator password on the

Fiery XJ so that casual users cannot enter the Setup menus and change Fiery XJ settings without permission.

Clear Server Clear all queued print jobs from the server—jobs in the

Fiery XJ Print, Hold and Printed queues. The Job Log is cleared at the same time. If you have set an Administrator password (created with the Change Password option), unauthorized users will not see this option (or any of the administrative or Setup options).

Fiery XJ Job Log Setup

The Fiery XJ Job Log is a running record of all jobs processed or printed on the Fiery XJ, whether they originate from a user workstation, a networked server, the Fiery XJ, or a computer attached to the parallel port. The Job Log can be printed at any time from the server or from the Command WorkStation.

Job Log Setup Change Password Clear Server

Setup

The printed Job Log lists accounting information about each job including user name, document name, time and date printed, number of pages, and some job settings. If users print with the latest Adobe printer driver, they can also enter job-speciﬁc notes that will appear in the Job Log. See the User Guide for details.

By default, the Job Log is not printed or cleared automatically. You can change these defaults in Job Log Setup.

Scroll the main Setup menu to choose Job Log Setup. Enter the options as described below. When you have ﬁnished, save changes.

2-27 Administrative functions in the Setup menu

Job Log Setup options

Default values, where applicable, appear in square brackets.

Auto Print Job Log Every 55 Jobs Yes/No [No]

Use this option to specify whether you want the Fiery XJ to print the Job Log after every 55 jobs. If accounting for each printed page is important at your site, and an administrator checks the printed output, set the Job Log for automatic printing.

If this option is set to Yes, the Fiery XJ will also print the Job Log after restarting if it ﬁnds 55 jobs are listed in the Job Log (even if the Job Log was printed prior to restarting).

Auto Clear Job Log Every 55 Jobs Yes/No [No]

Use this option to specify whether to clear the Job Log after ev ery 55 jobs. This option is only available if you selected Yes for the option to print the Job Log automatically.

If you do not enable this option, and do not clear the Job Log from the Fiery XJ, the Fiery XJ saves a record of all jobs.

NOTE: The Job Log (together with all queued jobs) is cleared when you choose Clear

Server from the main Setup menu. It is also cleared when system software is r einstalled or a new version of system software is installed on the Fiery XJ.

Job Log Page Size Tabloid/A3 Letter/A4 [Tabloid/A3]

Select the paper size for printing the Job Log. Regar dless of paper size, 55 jobs are listed on a page. The paper size used depends on the Default Paper Sizes setting in the P rinter Setup. If the Default Paper Sizes setting is US, the J ob Log is printed on tabloid or letter size paper, with tabloid the default.

Save Changes Yes/No [Yes]

Select Yes to activate any changes made in the Job Log S etup; select No to r eturn to the main Setup menu without making any changes.

Change Password

Change Password enables you to set or change the Administrator password for the

Fiery XJ. This password determines whether a user can modify the Setup options.

2-28 Administrative functions in the Setup menu

The Fiery XJ system administrator can move, delete, and conﬁgure jobs for all users, and can re-order jobs within a queue. The administrator can also change the WebLink destination.

The Administrator password also controls access to the Administrator menu in the Command WorkStation. With access to that menu, you can specify or change the passwords for the Administrator, Operator and WebS pooler User. (See “Passwor ds” on page 2-34.)

When the Fiery XJ is installed, there is no password. If you do not create an Administrator password, users are not required to enter a password to modify the Setup.

If an Administrator password has been set previously, you are required to enter it right after Start Up, when you choose the characters and the left and right arrows to move between them (see page 2-6).

Run Setup. Use the up and down arrow keys to select

Job Log Setup Change Password Clear Server

Setup

Scroll the main Setup menu to choose Enter and conﬁrm the password as described below.

New Password

Use the up and down arrow keys to select the characters and the left and right arrows to move between them. Enter characters from left to right, since the left arrow line selection key is a delete key. The password can be any combination of letters and numbers up to 19 characters. Choose OK when you are done. Be sure to write down the password. The only way to remove a password that you can’t remember is to reinstall system software.

Verify New Password

Enter the new password again exactly as before to verify that you have entered it correctly. If you make a mistake, you are prompted to enter the password again. The new password is effective until you change it again.

Change Password.

2-29 Administrative functions in the Setup menu

Clear Server

Clear Server enables you to clear all queued print jobs from the server—jobs in the

Fiery XJ Print, Hold and Printed queues. The Job Log is cleared at the same time. If you keep Job Logs, be sure to print or export the Job Log before you choose Clear

Server

Jobs can also be deleted, individually or as a group, from the Command WorkStation. Note that jobs printed to the Direct connection are not stored on the Fiery XJ at all.

Job Log Setup Change Password Clear Server

Setup

Exit Setup Server Setup Network Setup Printer Setup

Setup

TO PRINT THE CONFIGURATION PAGE:

Scroll the main Setup menu to choose Choose Clear Server if you want to clear all queued print jobs and the Job Log from

the server. You are asked to conﬁrm your selection.

Clear Server.

Exit Setup

Choose Setup changes.

The Fiery XJ reboots and any changes you saved during the Setup take effect.

Exit Setup from the main Setup menu when you have ﬁnished making

Printing the Conﬁguration page from the Control Panel

The Conﬁguration page lists all the settings in effect from the current Setup. After you have ﬁnished running Setup, print a Conﬁguration page to conﬁrm your settings.

There are other pages you can print from the Control Panel of the Fiery XJ, including Test Page, Job Log, Control Panel Map , color charts, and font list. For information on these pages, see the Operator Guide.

1. At the Control Panel, press the oval Menu button to access the Functions menu.

2. Choose for Print Pages.

The Control Panel displays the ﬁrst four types of pages you can print. (To see the remaining types of pages, scroll down using the down arrow button.)

2-30 Running Setup from the Command WorkStation

3. Select Conﬁguration.

You may want to post the current Conﬁguration page near the server for quick reference. Some of the information on this page should be conveyed to remote users; for example, users sending print jobs will need to know the current printer default settings.

You can also print Fiery XJ pages from the Command WorkStation. For details, see page 2-51.

Running Setup from the Command WorkStation

Once you have performed an initial Setup on the Control P anel, you can change Setup options from either the Command WorkStation or the Control Panel.

To run Setup from the Command WorkStation, the Command WorkStation must be installed and conﬁgured for communication with the Fiery XJ. The Fiery XJ must be turned on and displaying the WorkStation and connecting to the Fiery XJ, see Chapter 3 of this manual or the Operator Guide.

Idle screen. For information on starting the Command

TO CHANGE SETUP OPTIONS FROM THE COMMAND WORKSTATION:

Click to select a Setup menu

1. Start the Command WorkStation application.

2. Log in as Administrator.

3. From the Administrator menu, select Run Setup.

The Run Setup dialog box appears, displaying the three selection options.

Menu tabs

Change settings as needed

2-31 Running Setup from the Command WorkStation

4. Select General Setup, Network Setup, or Printer Setup.

Use the callouts in the illustration below as a guide to the Setup dialog boxes.

Click to discard all changes and return to the Setup dialog box

Click to apply all changes Click to discard changes and restore the

5. Make changes as needed in the Setup menus. Press Tab to navigate the options.

You can select the following Setup menus by clicking the appropriate tab at the top of the dialog box:

General Setup

• Server Setup • Passwords • Job Log Setup

Network Setup

• AppleTalk • TCP/IP • Parallel Port • Token Ring and Novell

Printer Setup

• Printer Options • Network Usage • Color and Paper Setup

Each of these dialog boxes is described in the following sections.

current Setup (in the current menu only)

2-32 Running Setup from the Command WorkStation

6. Click Save to apply changes, click Cancel to discard your changes and dismiss the

7. If you clicked Save in step 6, then click Save in the Run Setup dialog box.

8. Click OK for conﬁrmation.

You can review all your changes before applying them. If at any point you want to restore the Setup options currently in effect on the F iery XJ, click Revert at the bottom of the dialog box. Note that this restores Setup options only in the current Setup menu.

current Setup menu, or click Revert to restore settings in the current menu.

When you click Save, a dialog box asks you to conﬁrm that you want to save changes and reboot the Fiery XJ.

The Fiery XJ reboots and your changes take effect.

2-33 Running Setup from the Command WorkStation

General Setup options

A dialog box with graphical tabs gives you these choices: Server Setup, Passwords, and Job Log Setup.

Server Setup options

Server Name Enter a name for the Fiery XJ (up to ten characters long). This is also the server

name you should enter when you conﬁgure the server for the Chooser list over IPX/SPX. (See Getting Started.) Each time you change the Server Name, you will need to modify the Chooser list conﬁguration on the Command W orkS tation and on other workstations that are using the Fiery XJ Downloader.

Time Enter the correct system time, based on a 24-hour clock, in the form

(Hours:Minutes). The time is used on the cover page and on Job Logs.

Date Enter the correct system date, in the form Month, Day, and Year. The date is used

on the cover page and on Job Logs.

NOTE: If you enter a number that is out of range in either the Time or the Date

ﬁeld, 17 in the month ﬁeld, for example, you are prompted, when you dismiss the Server Setup menu, to enter a number that is in range.

HH:MM

2-34 Running Setup from the Command WorkStation

Print Start Page Specify whether the Fiery XJ should print a start page every time it restarts. The

start page displays information about the Fiery XJ including the server name, current date and time, Color Mode, Printer Mode, amount of memory installed in the Fiery XJ, last calibration date, network protocols enabled, and connections enabled.

Use Character Set Specify whether the Command WorkStation should use the

Windows character set for displaying filenames. This is important if a filename

includes accented or composite characters (such as é, ü, or æ). For mixed-platform networks, select the predominant client type, or whichever

option gives better overall representation of the special characters you use.

Parallel Port Select Disabled if you plan to use only a network connection to the Fiery XJ. Select

Enabled if you are planning to print from a computer connected to the parallel

port on the Fiery XJ.

Jobs Saved in Printed Queue

Specify the number of jobs (from 1 to 99) to be saved in the Printed queue. Note that jobs in the Printed queue take up space on the Fiery XJ hard disk.

Macintosh, DOS, or

Passwords

The Passwords dialog box enables you to set, change, and remove passwords for the Fiery XJ.

NOTE: You can also set or change the Administrator password (but not the Operator or

User passwords) with Setup on the Control Panel.

2-35 Running Setup from the Command WorkStation

For more information on the various passwor ds and the access privileges they allow, see page xvi of the Introduction.

NOTE: By default, no passwords are set on the Fiery XJ. If you do not speciﬁcally set

passwords, all users will have access to important functions such as Setup (including setting passwords), calibration, and job control. It is strongly recommended that you set at least an Administrator password to protect the server from accidental or incorrect changes to Setup.

If you forget the Administrator password, contact your authorized service representative to reinstall Fiery XJ system software. This will clear the Administrator password and allow you to set a new one.

TO ENTER OR CHANGE A PASSWORD:

• Enter the new password in both ﬁelds of the Password setup.

If there is no current password, you create one. If there is a password, you change it to a new password; you need to ﬁrst select (and delete) the asterisks (*) in both ﬁelds.

Passwords are case-sensitive and can be any combination of letters and numbers up to nineteen characters. You must enter the password exactly the same way both times. If you make a mistake, you are prompted to enter the password again either when you dismiss the Password dialog box or click OK to apply Setup changes. The new password remains in effect until you change it again.

TO REMOVE A PASSWORD:

• Delete the asterisks (*) in both ﬁelds of the Password setup.

2-36 Running Setup from the Command WorkStation

Job Log Setup options

Auto Print Job Log every 55 Jobs

Auto Clear Job Log every 55 Jobs

Job Log Page Size Select the size of paper you want to print the Job Log on.

Specify whether you want the Fiery XJ to print the Job Log after every 55 jobs. The Job Log displays a list of the last 55 jobs processed on the Fiery XJ, with accounting information about each one, including user name, document name, time and date printed, number of pages, and other job information.

Specify whether you want to clear the Fiery XJ Job Log after every 55 jobs. If you do not turn on this option, the Fiery XJ saves a file containing a record of all jobs ever printed. Since this file takes up space on the Fiery XJ hard disk, clearing the Job Log frees up additional disk space.

Note that you can clear the Job Log manually at any time from the Command WorkStation’s Job Log window (by clicking the trash can icon), or from the WebSpooler (by selecting cleared when you select Clear Server from the Command WorkStation’s Administrator menu.

Delete Job Log from the File menu). The Job Log is also

2-37 Running Setup from the Command WorkStation

Network Setup options

A dialog box with graphical tabs for available network options gives you these choices: AppleTalk, TCP/IP, Parallel Port, and Token Ring and Novell Setup.

NOTE: You can enable AppleTalk, TCP/IP, and IPX (Novell) communication

simultaneously.

AppleTalk options

Enable AppleTalk Check if you have an AppleTalk network connected to the Fiery XJ. This enables

AppleTalk communication.

AppleTalk Zones Choose the AppleTalk zone in which you want the Fiery XJ to appear from the

pop-up menu. (The list of zones is active only if AppleTalk is enabled). If your network does not have zones, no options are available.

2-38 Running Setup from the Command WorkStation

TCP/IP options

Enable TCP/IP Check if you have a TCP/IP network connected to the Fiery XJ. This enables

TCP/IP communication.

IP Address For TCP/IP networking, enter the IP address for the Fiery XJ. The Fiery XJ is

shipped with an invalid IP address, so you must assign the Fiery XJ a unique and valid IP address. This IP address is all that is required to identify the Fiery XJ on your network.

Subnet Mask Enter the subnet mask for printing with TCP/IP. Check with your network

administrator if you are unsure whether your network uses subnets. Set the subnet mask to be one of the following values:

255.0.0.0

•

If the IP address starts with a number less than 128.

• 255.255.0.0

If the IP address starts with a number between 128 and 191.

• 255.255.255.0

If the IP address starts with a number greater than 191.

2-39 Running Setup from the Command WorkStation

Gateway Address Enter the gateway address for printing with TCP/IP. By default, no gateway

address is set. If your TCP/IP network has a gateway and users outside the gateway plan to print to the Fiery XJ using TCP/IP, you must enter the gateway address here.

NOTE: You need to enter only one gateway address; if you have multiple gateways

on your network, you must specify the appropriate gateway to communicate with the Fiery XJ.

Enable HTTP Check to allow Internet or intranet access to the Fiery XJ via the WebTools.

2-40 Running Setup from the Command WorkStation

Parallel Port options

In order to print to the parallel port and enter the Parallel Port Setup options, you must set the Parallel Port option to Enabled in the Server Setup menu in General Setup.

Enable Parallel Port

Port Timeout in seconds

Ignore EOF Character

Specify that you want to print through the Fiery XJ parallel port. You can connect a single PC compatible to the Fiery XJ parallel port and print directly to the Fiery XJ.

Specify how long (between data from the parallel port before deciding that the current job is complete. Until the timeout, the Fiery XJ cannot receive new jobs through the parallel port, but it can continue to receive network print jobs.

Specify if the Fiery XJ should ignore end-of-file (EOF) messages in a file. This option must be selected to print PostScript files in binary format (not ASCII); under normal circumstances, it should be turned off.

When you select this option, the Fiery XJ uses the value you entered for the parallel port timeout to determine when the end of the file has been reached.

1 and 60 seconds) the Fiery XJ waits without receiving

2-41 Running Setup from the Command WorkStation

Token Ring and Novell options

Token Ring Setup options

Token Ring Setup Click to access the Token Ring Setup dialog box from which you enable a Token

Ring network connection to the Fiery XJ.

NOTE: The Token Ring Setup dialog box is only available if your system has the

Token Ring option installed.

Maximum Frame Size (bytes)

IPX (Novell) Setup Click to access the Novell Setup dialog box from which you enable an IPX (Novell)

Select the maximum size of the data frame for the Token Ring network. In general, you should leave this at the default (4216). If your network requires it, you can change the value.

NOTE: After selecting the maximum frame size, continue by clicking IPX (Novell)

Setup, since Token Ring networks supported by the Fiery XJ use IPX protocols. The options are the same as for IPX on Ethernet networks, except that the NetWare

Server Poll Interval

Novell Setup options

network connection to the Fiery XJ. Before entering IPX (Novell) settings, be sure the Fiery XJ is connected to the network and you have already configured one or more NetWare file servers with a Print Server and a Print Queue for Fiery XJ jobs. The NetWare server must be running.

does not apply to Token Ring networks.

2-42 Running Setup from the Command WorkStation

Enable IPX Novell Specify if you have an IPX (Novell) network connected by Ethernet to the

Fiery XJ.

Frame Type Specify the frame type used between the NetWare server and the Fiery XJ.

2-43 Running Setup from the Command WorkStation

NOVELL SETUP: ADD CONNECTIONS

Use this option to create a new ﬁle server connection to the Fiery XJ. You can set up as many as eight ﬁle servers to handle Fiery XJ print jobs over Ethernet and eight over Token Ring.

NOTE: In order to correctly complete the Novell login procedure, you should use the

tab key to move through the options in this window. Do not use the mouse or the Enter key to move between options.

Select File Server You can select the Novell ﬁle server from a scrollable list or by a name search.

If you specify NetWare ﬁle server on the IPX (Novell) network.

If you specify Search Name, enter the ﬁrst letters of the ﬁle server name, and scroll to select the server you want from the Add Server list.

File Server Login Displays guest by default. Enter your login name, or select administrator or

supervisor if you have those privileges.

File Server Password

Enter the password for logging into your NetWare ﬁle server. If you enter the incorrect password, you are prompted to re-enter it.

From List, use the up/down arrow in the Add Server list to select a

2-44 Running Setup from the Command WorkStation

NetWare Print

Server

Print Server Password

Server Poll Interval (in Seconds)

Add Click

This option appears only if there is more than one print server deﬁned on the selected Novell ﬁle server. From the list of NetWare print server names, select one that you have conﬁgured in the NetWare utility PCONSOLE. This is the print server that will route print jobs to the Fiery XJ from computers on IPX networks.

This option appears only if your NetWare print server is set up to require a password for login. Enter your password.

Specify the interval (between 0 and 3600 seconds) at which the Fiery XJ communicates with the Novell server to see if there are print jobs waiting. If you specify 0 (zero), the Fiery XJ polls the server as frequently as possible for your network conﬁguration.

NOTE: If you select a short interval, the amount of network trafﬁc increases. This

may slow down other network jobs.

NOTE: If you click Save without clicking Add, the server connection will not be

added to the list of available servers.

Add to connect additional Novell servers.

2-45 Running Setup from the Command WorkStation

NOVELL SETUP: VIEW CONNECTIONS

Use this option to view the list of ﬁle servers that have already been speciﬁed for communication with the Fiery XJ.

View Connections View the list of ﬁle server(s) connected to the Fiery XJ. The window displays

information about the ﬁle server you select.

2-46 Running Setup from the Command WorkStation

NOVELL SETUP: EDIT CONNECTIONS

Use this option to change the NetWare print server assigned to the Fiery XJ, and to change the poll interval.

File Servers Specify the ﬁle server whose print server or poll interval you want to change. NetWare Print

Server Print Server

Password Server Poll Interval

(in Seconds)

Update Click Update to edit additional Novell server connections and to accept your

Specify the print server you now want to use. This is the print server that will route print jobs to the Fiery XJ from computers on IPX networks.

This option appears only if your NetWare print server is set up to require a password for login. Enter your password.

Specify the interval (between communicates with the Novell server to see if there are print jobs waiting.

If you specify 0 (zero), the F iery XJ polls the server as frequently as possible for your network conﬁguration.

NOTE: If you select a short interval, the amount of network trafﬁc increases. This

may slow down other network jobs.

previous changes.

0 and 3600 seconds) at which the Fiery XJ

2-47 Running Setup from the Command WorkStation

NOVELL SETUP: REMOVE CONNECTIONS

Use this option when you want to disconnect the Fiery XJ from a ﬁle server to which it is currently connected.

Remove File Server

Remove Click

Specify a NetWare ﬁle server whose connection you want to remove. You are notiﬁed that you have removed the connection.

Remove to remove additional Novell servers.

2-48 Running Setup from the Command WorkStation

Printer Setup options

A dialog box with graphical tabs gives you these choices: Printer Setup, Network Usage, and Color and Paper Setup.

Printer Setup options

Select Printer Specify the device name whose connections and protocols you want to conﬁgure. Printer Type Specify the model of the copier connected to the Fiery XJ. Enable Direct

Connection

Enable Print Queue

Click to enable users to print (or download) jobs to the Fiery XJ without spooling. When a direct connection is enabled, users can print jobs to the direct connection and download and delete printer fonts. Note that jobs printed to the direct connection are not available to be reprinted from the Printed queue.

NOTE: The direct connection must be enabled to download fonts.

Click to enable users to print jobs to the Print queue. Jobs that are printed to the Print queue are spooled on the Fiery XJ disk.

If Enable HTTP is set to Yes, you must enable the Print queue.

2-49 Running Setup from the Command WorkStation

Network Usage options

Use this tab to assign a Fiery XJ queue to each Novell server that you have connected in Network Setup. Checkmarks beside other options indicate that the protocol was enabled in Network Setup.

Use AppleTalk This option is checked if you enabled AppleTalk in Network Setup. Use TCP/IP This option is checked if you enabled TCP/IP in Network Setup. Use Parallel Input This option is checked if you enabled parallel communication in S erver Setup and

Network Setup.

Use IPX This option is checked if you enabled IPX Novell in Network Setup. Select File Server Specify a ﬁle server connection. Use Server With This option only applies if you have installed the Token Ring Option. Specify the

network cabling that will be used between the selected ﬁle server and the Fiery XJ. You need to select an option only if you have enabled both Token Ring and Ethernet networking for the same Novell ﬁle server.

2-50 Running Setup from the Command WorkStation

Attach File Server ToSpecify the Fiery XJ connection that should be used for jobs originating from the

selected ﬁle server.

NOTE: If you are conﬁguring the Fiery XJ for multiple Novell ﬁle servers, you must

attach each ﬁle server to a connection. Select each ﬁle server and attach it to a queue, one by one, for all assigned ﬁle servers, before saving and exiting Network Usage.

Color and Paper Setup options

Compression Select

to 1/200 of the memory normally required. Select Off if you prefer to disable this feature.

Default Paper Sizes

Convert Paper Sizes

Specify whether to print on US paper sizes (for example, letter, legal, tabloid), or

Metric paper sizes (for example, A4, B4, A3) by default. When no page size is

deﬁned within a PostScript ﬁle, jobs are printed on letter paper if you select US, or A4 paper if you select Metric.

Specify whether to convert paper sizes in documents automatically to the default paper sizes specified. For example, if you select document is automatically printed on A4 paper. If you select No, the server will only print the document if it ﬁnds a media source in the size speciﬁed by the ﬁle.

On to enable Compression, so that color jobs print at high quality with up

Letter/11x17->A4/A3, a letter size

2-51 Running Setup from the Command WorkStation

Print Cover Page Specify whether the Fiery XJ prints a cover (job summary) page at the end of each

print job. If you select Yes, each print job is followed by a page containing the name of the user who sent the job, the document name, the server name, the time the job was printed, the number of pages printed, and the status of the job. If a PostScript error occurs, and the Print to PS Error option is set to Yes, an error message takes the place of the job status.

Allow Courier Substitution

Print to PS Error Specify whether the Fiery XJ should print the available portion of a print job

Enable Bypass Tray as default

Detect Black as default

Specify whether to substitute Courier for unavailable fonts. If this option is set to

No, jobs with fonts that are not available on the Fiery XJ hard disk will not print

due to a PostScript error.

when it encounters a PostScript error. Select Yes to print the portion of the job that was processed before the error occurred; select whenever a PostScript error is encountered.

Select Yes to specify that jobs should be scanned before being printed to detect black-only pages. Black detection allows for accurate billing of black-and-white pages and increases the printing speed of jobs containing multiple black-only pages.

No to cancel the job entirely

Printing the Conﬁguration page from the Command WorkStation

The Conﬁguration page lists all the settings in effect from the current Setup. After you have ﬁnished running Setup, print a Conﬁguration page to conﬁrm your settings.

There are other test and status pages you can print from the Command WorkStation, including the test page, Job Log, Control Panel map, color charts, and font list. For information on these Fiery XJ pages, see the Operator Guide.

TO PRINT THE CONFIGURATION PAGE:

1. At the Command WorkStation, pr ess the F4 function k ey; or, click to open the Function Keys slider and then click the F4 icon.

2-52 Setting the WebLink destination

2. Click Conﬁguration.

3. Click Close.

You can also print Fiery XJ pages from the Control Panel. For details, see page 2-29.

Setting the WebLink destination

The WebLink destination is initially set to a www.efi.com/weblink/xerox. From this page, you can link to either the Xerox home page or the Electronics for Imaging home page (www.eﬁ.com).

The WebLink destination can be changed; this function requires the Administrator password, if one has been set.

TO CHANGE THE WEBLINK DESTINATION:

1. Start your Internet browser application.

2. Enter the IP address or the DNS name of the Fiery XJ.

The Fiery XJ home page appears.

3. Press the Control key (Macintosh) or Ctrl key (Windows) while you click the WebLink button.

2-53 Setting the WebLink destination

4. Enter the Administrator password (if required) and click OK.

5. Enter the new WebLink address (URL) and click OK.

The Update WebLink dialog box appears.

3-1 Starting the Fiery XJ and Command WorkStation

Chapter 3: Command WorkStation Functions

Power switch in the Off position

This chapter provides information on administrator-related Command WorkStation functions. It describes starting up and shutting down the Command WorkStation, conﬁguring the Chooser list to connect to the Fiery XJ, and rebooting the Fiery XJ. It also includes instructions on how to reinstall the Command WorkStation software from the User Software CD if you should need to.

For information on operator-related functions of the Command WorkStation, see the Operator Guide.

Starting the Fiery XJ and Command WorkStation

Before turning on the Command WorkStation, turn on the Fiery XJ by moving the power switch on the back to the On (|) position.

When the Fiery XJ Control Panel reads Idle, turn on the Command WorkStation by pressing the button on the front of the computer. If necessary, turn on the Command WorkStation monitor, using the switch at the bottom right of the monitor.

Monitor switch

Command WorkStation power switch

3-2 Command WorkStation Functions

The Command WorkStation application starts automatically once Window 95 has started.

3-3 Connecting to the server

Connecting to the server

The ﬁrst time you start up the Command WorkStation after initial Setup, or after you change the server name or IP address, you must conﬁgure the Chooser list to connect to the server. Once you have conﬁgured the Chooser list, you connect to the server automatically whenever you launch the Command WorkStation.

Conﬁguring the Chooser list

The Chooser list is created by a ﬁle named NET_WSCK.INI which resides in the Windows directory on the Command WorkStation. The NET_WSCK.INI ﬁle tells the Command WorkStation how to connect to the Fiery XJ. The procedure described below is simply an automated way of editing the NET_WSCK.INI ﬁle. If you prefer, you can edit the NET_WSCK.INI ﬁle directly with WordPad or any other text editor. For instructions on how to manually edit the NET_WSCK.INI ﬁle, see page 3-6.

NOTE: A NET_WSCK.INI ﬁle is also used by the Fiery XJ Downloader on remote

workstations to connect to the server over IPX/SPX or TCP/IP networks. The procedure described below is identical to that described in Getting Started for conﬁguring the Chooser list for the Fiery XJ Downloader.

TO CONFIGURE THE CHOOSER LIST:

1. Print the Conﬁguration page from the Control Panel and note the IPX address or IP address of the Fiery XJ in the Network Setup section.

If you like, you can set up a Domain Name Server (DNS) for the IP address of the Fiery XJ in the printcap ﬁle. The Chooser list can support either an IP address or a DNS name.

2. Start the Command WorkStation application.

If the server has not been connected before (i.e., you are using the default NET_WSCK.INI ﬁle), the following message is displayed.

3-4 Command WorkStation Functions

3. Click OK to conﬁgure now.

4. In the Add New Server dialog box, enter the Server Name, network address, and device name of the Fiery XJ.

Server Name—If you are using TCP/IP, enter the IP address (or DNS name) of the Fiery XJ. If you are using IPX/SPX, enter the Server Name as it was deﬁned during Setup.

IPX Address—Enter the IPX Address from the Conﬁguration page. This is only necessary for IPX/SPX networks.

New Device—Enter the device name: DocuColor. This device name appears in the Printer Setup section of the Conﬁguration page.

IPX/SPX

TCP/IP

3-5 Connecting to the server

5. When you have entered all the information, click Add.

The device name now appears in the Devices list.

3-6 Command WorkStation Functions

6. Click OK.

7. With the Fiery XJ selected in the Chooser list, click OK to begin using the Command

The server appears in the Chooser list.

WorkStation.

You can click the Conﬁgure button to modify the conﬁguration of the Fiery XJ, or to add another server to the Chooser list.

8. From the Command WorkStation display, select your login choice, enter a password if necessary, and click Log in.

The slider retracts, and the Command WorkStation connects to the selected server.

Editing the NET_WSCK.INI ﬁle

You can examine and edit the NET_WSCK.INI ﬁle with a text editor. The bottom portion of the ﬁle should appear as follows:

[ConfigServers] Server1=ServerName (DNS name or IP address)

[ServerName] DEFAULT_QUEUE=PRINT Device1=DocuColor

[ChosenServer1] ChosenServer=ServerName ChosenDevice=DocuColor ChosenQueue=ActiveQueue

where ServerName is the DNS name or IP address

3-7 Rebooting the server from the Command WorkStation

If you are having trouble connecting to the Fiery XJ, delete the NET_WSCK.INI ﬁle from the \WINDOWS directory and start over with the process of conﬁguring the Chooser list as described on page 3-3.

Rebooting the server from the Command WorkStation

When you reboot the Fiery XJ from the Command WorkStation, all current job data on the server is maintained except the data stored in RAM. The only job data stor ed in RAM is the raster data of jobs that have been printed; these appear in the Printed area of the Command WorkStation display.

TO REBOOT THE FIERY XJ FROM THE COMMAND WORKSTATION:

1. Make sure that the Fiery XJ is not receiving, processing, or printing a document.

In the Command WorkStation display, the Spool, RIP and Print Status bars should all show no activity.

2. From the Command WorkStation’s Administrator menu, select Reboot Server.

3. Click OK in the dialog box that appears.

As the Fiery XJ reboots, a dialog box displays its progress.

4. When the Fiery XJ has completed rebooting, log in again to the Command WorkStation.

3-8 Command WorkStation Functions

Shutting down the server and Command WorkStation

Generally, you can leave the Fiery XJ and the Command WorkStation running all the time. This section describes how to shut down when necessary.

NOTE: You should shut down the Command WorkStation before connecting or

disconnecting SCSI drives. You also should shut down the Command W orkS tation for service or troubleshooting.

When you shut down the Fiery XJ, all current job data on the server is maintained except the data stored in RAM. The only job data stored in RAM is the raster data of jobs that have been printed; these appear in the Printed area of the Command WorkStation display.

TO SHUT DOWN THE FIERY XJ AND COMMAND WORKSTATION:

1. Make sure that the Fiery XJ is not receiving, processing, or printing a document.

In the Command WorkStation display, the Spool, RIP and Print Status bars should all show no activity.

2. From the Command WorkStation’s File menu, choose Exit.

The Command WorkStation application shuts down.

3. Click the Windows 95 Start button and choose Shut Down.

4. In the Shut Down Windows dialog box, select Shut down the computer? and click Yes.

5. When the message “It’s now safe to turn off your computer” appears on the monitor, turn off the Command WorkStation using the power switch on the front, and turn off the Fiery XJ using the power switch on the back (press 0).

To restart the Command WorkStation and the Fiery XJ, see page 3-1.

3-9 Installing Command WorkStation software

Installing Command WorkStation software

In the event that you have to reinstall the Command WorkStation application, a backup copy of the software is provided on the User Software CD. The Command WorkStation software installer automatically installs the Fiery XJ Downloader and Fiery XJ Print Calibrator also.

TO INSTALL THE COMMAND WORKSTATION SOFTWARE:

1. Insert the User Software CD and open the \CWS\INSTALLR\DISK1 directory.

2. Double-click on the Setup.exe ﬁle.

The Installer’s Welcome dialog box appears.

3. Click Next.

4. In the Choose Destination Location dialog box, click Next to accept the default destination, or click Browse to select a different location and then click Next.

5. In the Select Program Folder dialog box, click Next to accept the default program folder, or specify a different program folder name and then click Next.

3-10 Command WorkStation Functions

6. In the Network dialog box, select the networking protocol y ou w ant to use (IPX/SPX or

7. In the Install conﬁguration ﬁle dialog box, click Next to install the default

8. When the Information dialog box displays “Installation complete,” click OK.

TCP/IP), and then click Next.

Depending on the selection you make here, one of two ﬁles will be installed in your \WINDOWS\SYSTEM directory: NET_WIPX.DLL for IPX/SPX, or NET_WSCK.DLL for TCP/IP. Only one of these two ﬁles should reside in the \WINDOWS\SYSTEM directory; if both reside there you may experience problems connecting to the Fiery XJ.

A Setup progress bar displays the status of the software copying process.

NETWSCK.INI ﬁle, or click Browse to select an existing NETWSCK.INI ﬁle that you have already conﬁgured for your server and then click Next.

The Command WorkStation application, the Fiery XJ Downloader, and the Fiery XJ Print Calibrator have been added to your Start menu programs.

9. To start the Command WorkStation, click the Start button and choose the Command WorkStation application from the Programs menu.

4-1 The Fiery XJ on an IPX network

Chapter 4: Setting up Network Servers

This chapter describes environments that typically include one or more network servers—Novell NetWare and Windows NT servers—that will share printing to the Fiery XJ. It describes setting up servers that use IPX/SPX or TCP/IP protocols for communicating with the Fiery XJ. In addition, it includes some guidelines for setting up direct communication from Windows NT and UNIX workstations, where a network server is optional.

It also outlines the requirements for network clients to print to the servers and run the Fiery XJ Downloader. Where appropriate, you are referred to other manuals for details.

If your network is based on Windows NT, go to page 4-15. If your network includes UNIX workstations, go to page 4-24.

The Fiery XJ on an IPX network

Novell NetWare, the IPX networking operating system, includes NetWare’s Queue Management Services, which handle printing. The F iery XJ supports NetW ar e versions

3.11 and 3.12 directly; and it supports version 4.x in bindery emulation mode (see “Setting the NetWare 4.x bindery context” on page 4-6).

IPX/SPX (Internetwork Packet Exchange/Sequenced Packet Exchange) is one of the protocols the Fiery XJ supports directly; and it is provided with Windows 95.

NetWare clients print to the Fiery XJ through the network server. Server setup and client network setup are outlined here. Client printing setup is described in Getting Started, and printing is described in the User Guide.

The Fiery XJ can accept IPX print jobs concurrently with jobs sent through AppleTalk and T CP/IP protocols. M acintosh computers on the same network as a NetWare server can use AppleTalk to communicate with the NetWare server if NetW are for Macintosh is installed, or they can print directly to the color server.

4-2 Tips for experts—IPX networks

In addition to printing, the Fiery XJ Downloader is available to Windows 95 users with IPX/SPX protocols loaded. The Fiery XJ Downloader can be loaded and conﬁgured on each workstation that uses it, as described in Getting S tarted. In this case, Windows 95 workstations are communicating with the Fiery XJ directly, not through the NetWare server.

The Fiery XJ can receive print jobs from N etWare servers over Ethernet or Token Ring network architecture and cabling. Appendix A describes the Token Ring option. When Ethernet is used, you select a single frame type to use between the NetWare server and the Fiery XJ. Frame type describes the format of a communications packet; it is speciﬁed in a startup ﬁle when the NetWare server (or any other workstation using Ethernet) loads its network drivers.

Tips for experts—IPX networks

Setting up the Fiery XJ is similar to setting up another PostScript printer on the network. The following information is all that experienced network administrators need.

A Fiery XJ+ 525 with IPX connections has these characteristics:

• The Fiery XJ supports NetWare 4.x in bindery emulation mode.

• A basic connection to the Fiery XJ consists of a NetWare ﬁle server, a NetWare print server, and a NetWare queue.

After conﬁguring these items for printing to the Fiery XJ, you enter IPX (Novell) Setup on the Fiery XJ and enter the name of the NetWare ﬁle server and print server. In Printer Setup you select the NetWare ﬁle server and attach it to one of the Fiery XJ connections (Direct, Print queue, or Hold queue).

• One Fiery XJ connection is available for each NetWare ﬁle server, and one NetWare print server is serviced per ﬁle server.

All NetWare print queues on that print server are polled for print jobs. Up to eight IPX connections (that is, eight ﬁle servers) can be conﬁgured over Ethernet, and eight over Token Ring.
