This Quick Start Guide provides system requirements and an overview of how to set up
your Fiery EX12/EX2000d Color Server
the initial tasks you must perform and points you to sections in the user documentation
where the procedures are described in detail. A full set of user documentation is provided
on the User Documentation CD. A brief description of the user manuals and how to print
them follows.
Media pack
Your Fiery
•User Software CD
®
media pack should contain the following:
™
so you can begin printing. The guide describes
•System Software CD(s) (for service use only)
•Back-up/Restore Utility CD (for service use only)
•User Documentation CD
•Printed Quick Start Guide
•Printed Customer Release Notes
•Kodak Gray Scale
About the documentation
Along with the printed Customer Release Notes included in the Media Pack, documentation
is provided in electronic form on the User Documentation CD. The documents are
provided as Acrobat PDF (Portable Document Format) files, which are linked and crossreferenced. A description of the documentation follows:
• The Quick Start Guide summarizes the steps for configuring the Fiery and setting up
printing. It also describes how to access the online documentation.
• The Configuration Guideexplains basic configuration and administration of the Fiery for
the supported platforms and network environments. It also includes guidelines for setting
up UNIX, Windows NT 4.0, and Novell NetWare servers to provide printing services to
users.
• The User Software Installation Guide describes installation of printer drivers and other
software from the User Software CD to enable users to print to the Fiery.
Electronics For Imaging, Inc.
• The Printing Guide describes the printing features of the Fiery for users who send jobs
from their computers.
• The Color Guide provides information on managing the color output of the Fiery.
It explains how to calibrate your copier and take advantage of the ColorWise
management system, as well as features in ColorWise Pro Tools
™
.
Part Number: 450256942002
®
color
2 Quick Start Guide
• The Fiery Color Reference addresses concepts and issues associated with managing color
output of the Fiery and outlines key workflow scenarios. In addition, it offers
information on printing from popular Microsoft Windows and Apple Mac OS
applications.
• The Job Management Guide explains the functions of the Fiery client utilities, including
EFI Command WorkStation
™
and Fiery DocBuilder Pro
™
, and how you can use them to
manage jobs and maintain color quality. This manual is intended for an operator or
administrator, or a user with the necessary access privileges, who needs to monitor and
manage job flow, perform color calibration, and troubleshoot problems that may arise.
•Customer Release Notes provide last-minute product information and workarounds for
some of the problems you may encounter.
Printing the manuals
The PDF files on the User Documentation CD include blank pages to allow for correct
pagination with duplex printing. The CD also includes an installer for the Adobe Acrobat
reader, an application that allows you to view and print the user documentation from a
Windows or Mac OS computer. If your system includes Acrobat Reader version 3.0 or later,
you can view and print these documents directly from the User Documentation CD. If not,
install the version of Acrobat Reader provided on the User Documentation CD.
T
I
O
A
NSTALL
1. Insert the User Documentation CD into the CD-ROM drive of your computer.
2. Double-click the CD icon to open the Documentation folder.
3. For Macintosh: Open the Acrobat Reader 4.0 folder, and then open the Mac folder.
Double-click Reader Installer.
For Windows 9x/Me/NT/2000/XP: Open the Acrobat Reader 4.0 folder, and then open
the Windows folder. Double-click ar405eng.exe.
CROBAT
R
EADER
M
OS
ON
A
AC
OR
W
INDOWS
COMPUTER
When installation is complete, you can view, print, and search the following files:
Configuration Guide, User Software Installation Guide, Printing Guide, Job Management
Guide, Color Guide, and Fiery Color Reference.
N
:
OTE
To access the online documentation, you must place all book files in a folder called
English on your desktop.
Part Number: 45025694
:
3System requirements
System requirements
To install the Fiery user software on a Windows or Mac OS computer, the computer must
be equipped with a built-in or external CD-ROM drive. The following table lists the
minimum system requirements.
Minimum requirements forWindows 9x/MeWindows NTWindows 2000/XPMac OS
ComputerWindows-based computer with an 80486, AMD, or Pentium
Mac OS computer
processor
Operating SystemWindows 9x/MeWindows NT with
Windows 2000/XPMac OS 8.6 to 9.1
NT Service Pack 6
Memory for printing and Fiery
utilities (Fiery Downloader
and
ColorWise Pro Tools)
™
8MB of RAM for printing
32MB of RAM for utilities
32MB of RAM for
printing
64MB of RAM for
utilities
Networking protocolIPX/SPX or TCP/IPIPX/SPX, TCP/IP, or AppleTalkAppleTalk
PostScript printer driverAdobe PostScript
Printer Driver for
Windows (included
with user software)
Adobe PostScript
Printer Driver for
Windows NT
(included with user
software)
Microsoft PostScript
Printer Driver for
Windows 2000/XP
(included with
Windows 2000/XP
Adobe PostScript
Printer Driver
(included with user
software)
operating system)
Fiery Scan
™
Fiery WebTools
™
Adobe Photoshop version 4.0 or later
•Java-enabled web browser: Either Netscape Communicator v4.5 or Internet Explorer
v4.0.1
N
Netscape and Microsoft release frequent updates to their browsers. As support cannot
OTE
be guaranteed for all versions, use the versions specified above for best results.
•A monitor and video memory that supports 16-bit color at a minimum resolution of
800
600
x
•A TCP/IP-enabled network and the IP address or DNS name of the Fiery
•Web Services enabled on the Fiery
Command WorkStation
(Windows only)
Doc Builder Pro on
Command WorkStation
(Windows only)
•Windows-based computer with a 200MHz Pentium processor
• 60MB of available hard disk drive
•2
CD-ROM drive
x
• 17" monitor that supports 16-bit color at a minimum resolution of
1024
768
x
• 64MB of RAM
•Video adapter card with 2MB of video memory
•TCP/IP networking protocol installed
In addition to requirements for Command WorkStation:
•Windows-based computer with 333MHz Pentium processor
• 90MB of available hard disk space
—
—
Part Number: 45025694
4 Quick Start Guide
Other Network Requirements
UNIX (TCP/IP) workstation• Standard TCP/IP connectivity (for example, Sun SPARCStation or Silicon Graphics
workstation with Solaris version 2.5 or later or SunOS version 4.1.x software)
•TCP/IP printing software that conforms to RFC1179 (Berkeley lpd protocol)
IPX (Novell) network• Novell server
•Novell NetWare software version 3.x, 4.x, or 5.x
•Support for Ethernet SNAP, Ethernet II, Ethernet 802.3, and Ethernet 802.2 frame types
Preparing to print
To set up your Fiery, you must perform the following tasks:
• Connect the Fiery physically to a functioning network.
• Configure the network server.
•Set up the Fiery from the Control Panel.
T
O
•Prepare client workstations for printing.
A brief explanation of each task follows.
Connecting the Fiery to a functioning network
OTE
When you add the Fiery to a network, it is assumed that a network administrator has
N
:
already installed a network cabling system and has connected workstations and servers. For
examples of different networks, see the Configuration Guide.
•Prepare a network node for the Fiery.
•Route the cable to a location near the copier where the Fiery will be installed and attach
the cable to the network interface of the Fiery.
For more information, see Chapter 1 of the Configuration Guide.
• Connect the Fiery to the copier and print a test page.
For detailed instructions, see the Configuration Guide.
F
PREPARE
FOR
1. Print a copier test page to verify the copier is functioning normally.
2. Turn off the copier and connect the interface cable from the copier to the Fiery.
IERY
CONFIGURATION
3. To confirm this connection, turn on the copier and the Fiery and print a Test Page from the
Fiery Control Panel.
To print a Test Page, press the Menu button on the Control Panel to access the Functions
menu. Choose Print Pages, and then choose Test Page.
4. With both the copier and the Fiery turned off, connect the network cable to the Fiery.
The network should already be installed and operational.
5. Turn on the copier and then the Fiery.
Part Number: 45025694
5Preparing to print
Configuring the network server
If you require a network server, you must configure that server to provide client access to
the Fiery as a color printer. To configure a network server in a Windows or UNIX network
environment, see the Configuration Guide. For Token Ring, Novell, and Windows NT
(using TCP/IP) networks, the network servers must be configured for printing to the Fiery
before you configure Fiery network settings in Setup. For more information, see the
Configuration Guide.
Setting up the Fiery from the Control Panel
Setup configures the Fiery to communicate with other devices and manage print jobs. You
must perform Setup the first time you turn on the Fiery after new system software is loaded
or any time Server software is reinstalled. Initial Setup must be performed at the Fiery
Control Panel.
Perform the following Setup options in the order listed:
T
O
Server Setup
•
•
Network Setup
—specifies system options.
—specifies all the active network systems that transmit print jobs to the
Fiery.
Printer Setup
•
N
:
OTE
This is the minimum setup required to enable your Fiery to begin printing.
—specifies how print jobs and queues are managed.
To configure network settings in Setup, you need a live network connection so the Fiery can
query the network for zones, servers, and server-based queues.
To perform Setup from the Control Panel, select one menu after another and enter
information about your Fiery and your network and printing environment. In each Setup
screen, the last line of the display shows the name of the current Setup menu. Most of the
menus you see are displayed on the Control Panel Map, a flow chart you can print from the
Control Panel.
PRINT
C
THE
1. At the Control Panel, press the Menu button to access the Functions menu.
2. Press the line selection button for Print Pages.
ONTROL
P
ANEL
M
AP
The Control Panel displays the first four types of pages you can print. To see the remaining
types of pages, press the Down arrow button.
3. Press the line selection button for Control Panel Map.
N
:
OTE
The other pages you can print from the Control Panel include the Configuration
page, Test Page, Font List, Job Log, and color charts. Print the Configuration page after you
have finished running Setup to confirm your settings.
For an introduction to Fiery Setup and detailed instructions on setting up the Fiery from
the Control Panel or a Windows computer, see the Configuration Guide.
Part Number: 45025694
6 Quick Start Guide
Preparing client workstations for printing
Before you can print to the Fiery, you must install the appropriate printer files from the
User Software CD and connect the client to the Fiery over the network. The software
provided on the User Software CD is described in the User Software Installation Guide.
OTE
The steps to set up printing vary slightly for Windows and Mac OS computers.
N
:
Windows computers
For all Windows operating systems supported (including Windows 9x/Me and Windows
NT/2000/XP), the minimum steps for setting up printing are as follows:
•Install the printer drivers and corresponding printer driver files.
• Configure installable print options.
• Configure the print connection between the client and the Fiery.
For details, see the User Software Installation Guide. It also contains instructions for the
following:
•Installing Fiery utilities
• Configuring the connection for Fiery utilities
• Copying additional files from the User Software CD as required
Mac OS computers
To set up printing on a Mac OS computer, perform the following steps:
•Install the printer driver and PPD files.
•Set up the Fiery in the Chooser.
For details, see the User Software Installation Guide. It also contains instructions for the
following:
•Installing Fiery utilities
•Installing printer and screen fonts
• Configuring the connection for Fiery utilities
• Copying additional files from the User Software CD as required
Safety warnings
The Fiery display window is a liquid crystal display (LCD) that is made of glass and can
break. Do not subject it to strong shocks.
If the display window breaks and the liquid crystal material leaks out, do not inhale, ingest,
or touch it. If the material gets on your skin or clothing, wash it off with soap and water
immediately.
Do not touch or put pressure on the panel. This will change the color of the panel.
Part Number: 45025694
7 Cleaning the Fiery display window
Cleaning the Fiery display window
Clean the Fiery with a soft cloth moistened with isopropyl alcohol or ethyl alcohol. Never
use water or ketone as these may permanently alter the display.
Summary of Fiery network installation
Connection
Server configuration
Fiery setup
Client setup
Fiery
Network server
Fiery
UNIXMac OSWindows
Prepare a network node. Connect the Fiery to the
copier and the network.
Configure UNIX, Windows NT 4.0, and IPX
(Novell) servers to specify Fiery print queues and
Fiery users.
No special configuration of AppleShare servers
is required.
On the Fiery Control Panel, configure at least the
Server Setup, Network Setup, and Printer Setup.
At each workstation that will print to the Fiery:
•Install the appropriate printer files and connect
to one or more queues.
• For computers that will use them, install Fiery
utilities and an Internet browser.
•Verify the Fiery in the list of printers and run a
test print.
Fiery available on the network
Part Number: 45025694
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
