Xerox 4635 User Manual
Xerox 4635 Laser Printing System
Message Guide
XEROX
April 1995
721P83040
Xerox Corporation
701 S. Aviation Boulevard
El Segundo, CA 90245
© 1994, 1995 by Xerox Corporation. All rights reserved.
Copyright protection claimed includes all forms and matters of
copyrightable material and information now allowed by statutory
or judicial law or hereinafter granted, including without limitation,
material generated from the software programs which are
displayed on the screen, such as icons, screen displays, looks,
etc.
Printed in the United States of America
Xerox® and all Xerox products mentioned in this publication are
trademarks of Xerox Corporation. Products and trademarks of
other companies are also acknowledged.
WARNING: This equipment has been tested and found to
comply with the limits for a Class A digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user
will be required to correct the interference at his own expense.
Changes are periodically made to this document. Changes,
technical inaccuracies, and typographic errors will be corrected in
subsequent editions.
This document was created on the Xerox 6085 Professional
Computer System using VP software. The typeface is Optima.
Related publications
The Xerox 4635 Laser Printing System Message Guide Guide is
part of the ten-manual reference set for your laser printing
system. The entire reference set is listed in the table below.
Several other related documents are also listed for your
convenience. For a complete list and description of available
Xerox documentation, refer to the Xerox Documentation Catalog
(Publication number 610P17417) or call the Xerox
Documentation and Software Services (XDSS) at 1-800-445-5554.
Publication Number
Xerox Dynamic Document Interface
Operator Guide
Xerox Dynamic Document Interface
Command Summary
Xerox 4635 Laser Printing System
Operator Guide
Xerox 4635 Laser Printing System
Operations Reference
Xerox 4635 Laser Printing System
Sysgen Guide
Xerox 4635 Laser Printing System
Message Guide
Xerox 4635 Laser Printing System
PDL/DJDE Reference
Xerox 4635 Laser Printing System
Forms Creation Guide
Xerox 4635 Laser Printing System
Product Reference
Xerox 4635 Laser Printing System
Installation Planning Guide
720P13670
720P13680
721P83010
721P83020
721P83030
721P83040
721P83050
721P83060
721P83070
721P83080
Xerox 4635 Laser Printing System
Operator Command Summary Card
Xerox 4635 Laser Printing System
PC UI Reference
Xerox Laser Printing Systems
Tape Formats Manual
Xerox Laser Printing Systems
Standard Font Library Font User Guide
Xerox 4850 HighLight Color and 4135
Laser Printing Systems Font User Guide
Helpful Facts About Paper 721P82490
XEROX 4635 LASER PRINTING SYSTEM MESSAGE GUIDE iii
721P83090
721P83100
600P86175
600P86174
720P87340
Notice
This publication may contain descriptions of concepts and
features not currently available for your Xerox Laser Printing
System. Consult your Xerox sales representative or your
operating system software program description for additional
information.
iv XEROX 4635 LASER PRINTING SYSTEM MESSAGE GUIDE
Table of contents
Related publications iii
Notice iv
Introduction vii
About the reference set vii
4635 Laser Printing System document set vii
What the message guide contains x
How the message guide is organized xi
The conventions used in this guide xii
1. CP (COMPRESS command) messages 1-1
2. DSR (disk save and restore command) messages 2-1
3. FD (forms compilation) messages 3-1
4. HIP (host interface processor) messages 4-1
5. IFU (Interpress font utility) messages 5-1
6. OSS (operating system software) messages 6-1
OS Level 0: Confirmation 6-1
OS Level 1: Information 6-9
OS Level 2: Routine maintenance 6-41
OS Level 3: Printer problem 6-65
OS Level 4: System or tape problem 6-71
OS Level 6: Job integrity 6-75
OS Level 7: System problem 6-95
OS Level 8: Probable severe software error 6-100
OS Level 9: Probable severe hardware error 6-107
7. PDL (job source library compilation) messages 7-1
8. PG (PURGE command) messages 8-1
9. PR (HARDCOPY graphics printing command) messages 9-1
10. PSC (printer subsystem controller command) messages 10-1
11. SCALE command messages 11-1
12. SFS (status file services command) messages 12-1
13. System verification error messages 13-1
14. Summary sheet error messages 14-1
XEROX 4635 LASER PRINTING SYSTEM MESSAGE GUIDE v
TABLE OF CONTENTS
Appearance warning messages 14-4
Appearance warning 14-4
Appearance warning (page n) 14-6
Fatal error messages 14-8
Fatal error 14-8
Fatal error (page n) 14-8
Informational messages 14-11
Informational messages 14-11
Master error messages 14-13
Master error (page n) 14-13
Master warning messages 14-18
Master warning (page n) 14-18
System problem messages 14-18
System problem 14-18
System problem (page n) 14-19
15. 4635 LPS additional messages 15-1
Numbered 4635 LPS messages 15-2
Messages 7 through 36 15-2
Messages 41 and 42 15-2
Messages 44 through 48 15-2
Message 538 15-2
Messages 540 and 541 15-2
Messages 544 through 574 15-3
Messages 1538 through 1572 15-7
Messages 3538 through 3579 15-11
Messages 4037 through 4145 15-13
Messages 4500 through 4506 15-14
Messages 9038 through 9068 15-15
Messages 9537 through 9542 15-18
Unnumbered 4635 LPS messages (in alphabetical order) 15-19
Appendix
A. Xerox support services A-1
Glossary GLOSSARY-1
Index INDEX-1
vi XEROX 4635 LASER PRINTING SYSTEM MESSAGE GUIDE
About the reference set
aaaaaaaaaaaaaaaaa
a
a
a
a
aaaaaaaaaaaaaaaaa
a
a
Introduction
The Xerox4635 Laser Printing Systems Message Guide is one of
the ten manuals which make up your 4635 Laser Printing System
(LPS) Reference Set.
The LPS Message Guide provides an easy to use reference tool
for quickly determining why messages appear on your system
controller display or printed summary sheet, and the appropriate
action(s), if any, to take.
This message guide does not contain detailed explanations of
tasks. Throughout the guide, you are referred to the appropriate
reference manual for detailed information.
This document is part of a reference set designed to help you
receive maximum benefit from your 4635 laser printing system.
To help you select the appropriate document for your needs, the
following section identifies the documents in the set and
describes the information contained in each.
4635 Laser Printing System document set
aaaaaaaaaaaaaaa
aaaaaaaaaaaaaaa
4635 LPS
Product
Reference
aaaaaaaaaaaaaaa
aaaaaaaaaaaaaaa
4635 LPS
Operator
Guide
• Product overview
• Hardware and software
• LPS connections
• User considerations
• LPS comparisons
• System overview
• PC UI procedures
• Paper facts and procedures
• Operating procedures
• Maintenance
• Problem solving
• Supplies
• Meter reading and reporting
XEROX 4635 LASER PRINTING SYSTEM MESSAGE GUIDE vii
INTRODUCTION
aaaaaaaaaaaaaaaaa
a
a
aaaaaaaaaaaaaaaaa
a
a
a
a
aaaaaaaaaaaaaaaaa
a
a
a
a
aaaaaaaaaaaaaaaaa
a
a
aaaaaaaaaaaaaaaaa
a
a
a
a
aaaaaaaaaaaaaaaaa
a
a
a
a
aaaaaaaaaaaaaaa
aaaaaaaaaaaaaaa
4635 LPS
PDL/DJDE
Reference
aaaaaaaaaaaaaaa
aaaaaaaaaaaaaaa
4635 LPS
System
Generation
Guide
aaaaaaaaaaaaaaa
aaaaaaaaaaaaaaa
4635 LPS
Operations
Reference
• Print Description Language components and processes
• Input processing functions
• Output processing functions
• PDL/DJDE command summary
• Page formatting guidelines
• Character code assignment tables
• PDL/DJDE programming information with step-by-step
instructions
• Configuration options
• Commands
• OSS software installation, upgrade, and modification
procedures
• Command syntax for operator and system administrator
procedures
• LPS defaults
• LPS resources
• Command summaries
• Communication and graphics on the LPS
• Command files
aaaaaaaaaaaaaaa
4635 LPS
Forms
Creation
Guide
aaaaaaaaaaaaaaa
aaaaaaaaaaaaaaa
4635 LPS
PC UI
Reference
aaaaaaaaaaaaaaa
aaaaaaaaaaaaaaa
4635 LPS
Message
Guide
• Basic concepts for creating forms
• Coding and compiling for LPS Forms Description Language
• Sample form setup command sets
• Tips for successful forms creation
• PC UI procedures
• Hierarchy of PC UI windows
• OSS and other messages
• Meaning and recovery procedures
viii XEROX 4635 LASER PRINTING SYSTEMS MESSAGE GUIDE
INTRODUCTION
aaaaaaaaaaaaaaaaa
a
a
aaaaaaaaaaaaaaaaa
a
a
a
a
aaaaaaaaaaaaaaaaa
a
a
aaaaaaaaaaaaaaaaa
a
a
a
a
aaaaaaaaaaaaaaaaa
a
a
a
a
aaaaaaaaaaaaaaaaa
a
a
aaaaaaaaaaaaaaa
aaaaaaaaaaaaaaa
4635 LPS
Operator
Command
Summary
Card
aaaaaaaaaaaaaaa
aaaaaaaaaaaaaaa
4635 LPS
Installation
Planning
Guide
aaaaaaaaaaaaaaa
aaaaaaaaaaaaaaa
Helpful Facts
About Paper
• Provides a quick reference of commonly-used operator
commands.
• LPS basic components and options
• Tasks that must be accomplished before installation
• Preinstallation requirements
• Installation process
• Postinstallation activities
• Selection and guidelines
• Storage and handling
• Specifications for different printers
aaaaaaaaaaaaaaa
aaaaaaaaaaaaaaa
Tape Formats
Manual
aaaaaaaaaaaaaaa
aaaaaaaaaaaaaaa
LPS Standard
Font Library
Font User
Guide
aaaaaaaaaaaaaaa
aaaaaaaaaaaaaaa
4850
HighLight
Color and
4135 LPS Font
User Guide
• Characteristics of different formats
• File organization
• Data formats
• Carriage control conventions
• Font naming conventions
• Listing of standard fonts
• Data sheets
• Glossary of typography terminology
• Available fonts
• Typography concepts
• Xerox Font Services
• Glossary of typography terminology
XEROX 4635 LASER PRINTING SYSTEMS MESSAGE GUIDE ix
INTRODUCTION
What the message guide contains
Chapter 1: CP (COMPRESS command) messages
Chapter 2: DSR (disk save and restore command) messages
Chapter 3: FD (forms compilation) messages
Chapter 4: HIP (host interface processor) messages
Chapter 5: IFU (Interpress font utility) messages
Chapter 6: OSS (operating system) messages
Chapter 7: PDL (job source library compilation) messages
Chapter 8: PG (PURGE command) messages
Chapter 9: PR (HARDCOPY graphics printing command) messages
The 4635 LPS Message Guide is divided into the following
chapters:
Chapter 10: PSC (printer subsystem controller command) messages
Chapter 11: SCALE command messages
Chapter 12: SFS (status file services command) messages
Chapter 13: System verification error messages
Chapter 14: Summary sheet error messages
Chapter 15: 4635 LPS additional messages
Appendix: Xerox support services
Glossary A glossary of terms and abbreviations is provide
Index An alphabetical listing of all unnumbered messages contained in
this guide
The following information is also provided:
• Information about ordering additional copies of this message
guide through the Xerox Documentation Subscription Service
(XDSS)
• An order card for the Customer Documentation Catalog,
which describes other available Xerox documentation
• A Reader Comment Form. Please take a few minutes to write
your comments about the message guide, and any
suggestions you may have for improving it, on the Reader
Comment Form
• Chapters 1 through 14 are arranged alphabetically according
to the coded messages as they appear on the system
controller (e.g., CP, DS, and FD) or by the type of uncoded
messages (i.e., scale, summary sheet, and system verification
error).
x XEROX 4635 LASER PRINTING SYSTEMS MESSAGE GUIDE
INTRODUCTION
How the message guide is organized
• Tabs separate the chapters for easy reference and are printed
• Coded messages are listed alphanumerically, with the two-
• Scale and system verification error messages are not
• The message chapters consist of a lefthand “Message”
with the code you will see on the system display. For
example, FDL messages appear as FDxxxx on your system
display, thus the tab for the FDL chapter is “FD (forms
compilation).”
letter code followed by the four-digit numeric code, such as:
OS1000, PD8510, and HP2430. The numeric codes range
from 0 to 9. Generally, the higher the numeric code, the
more serious the problem or condition being reported.
numbered and, therefore, are listed in alphabetical order by
the first word in the message.
column and a righthand “Meaning/action” column. The
message column contains each entry‘s message code
followed by the message that appears on the system
controller display, for example:
OS2002 CHECK PAPER SUPPLY IN TRAY 1.
The Meaning/action column contains the meaning of the
message and/or what caused it to be displayed. For example:
Fewer than 25 sheets of paper remain in (feeder) tray 1.
This column also lists the action(s) to take, if any, in response to
the message. For example:
1. Add paper to (feeder) tray 1.
. Press the <CON> key to resume printing.
2.
XEROX 4635 LASER PRINTING SYSTEMS MESSAGE GUIDE xi
INTRODUCTION
The conventions used in this guide
The following conventions are used throughout this guide:
• When keyed in, most commands can be shortened to three
letters. For example, RESET may be entered as RES.
Commands are shown in capital letters.
• Variable numbers, letters, and words appear as lowercase
italicized characters. These variables represent the actual
characters you will see in system controller display messages
or will enter in commands. For example, the command FEED
cluster-name and the message
OS1010 STARTING JOB xxxx
contain variable elements.
• There are four symbols used for variables in this guide:
n = Any permitted number. Decimal numbers appear as
nn.nn
x = Any applicable letter. Variable words appear as strings
of x’s, such as xxxx
y = A second variable number or letter appearing when n or
x has already been used in the message
z = A third variable number or letter appearing when n
and/or x and y have already been used in the message
• The names of keys are indicated in capital letters and
enclosed in delimiters, such as the <CON> and <ENTER>
keys.
• If a printer display message appears in conjunction with a
system display message, it is shown in the Meaning/action
column of the message guide in capital italicized letters, for
example:
• The terms “feeder tray,” “paper tray,” and “tray” are used
EMPTY SAMPLE TRAY.
interchangeably.
• Other terms used include the following:
enter = Key in a command or response, then press the
<ENTER> or <RETURN> key.
restart job = Send or transmit a job again (online) or
rewind a tape and start job again (offline).
recode job = Rewrite the JSL entry or DJDE, making
necessary changes.
xii XEROX 4635 LASER PRINTING SYSTEMS MESSAGE GUIDE
1. CP (COMPRESS command)
These messages may appear during the process of compressing
the system disk. (Refer to your 4635 LPS Operations Reference
chapter on managing LPS resources for additional information.)
CP1010 Compress now restoring the print file
The COMPRESS command was entered. The process has moved
the print file to different area of the system disk.
CP1020 Now processing DP0
CP1030 Now processing DP1
CP1040 Now processing DP2
CP1050 Now processing DP3
The COMPRESS command was entered. The system is currently
compressing the indicated disk pack unit.
messages
Action None.
CP1800 Compress processor aborting
The ABORT command was entered during the compress process.
The system disk remains partially compressed.
CP1900 Insufficient working memory for compress
Not enough dynamic memory exists for the compress process.
Action Contact your systems specialist or Xerox representative regarding
obtaining additional memory capacity.
CP2010 Enter ‘A’ to abort or ‘C’ to compress other disks
Multiple disks IDs were specified in the COMPRESS command.
One of the system disks contains so many files that there is not
enough internal memory to load the COMPRESS task.
Action Enter A to abort compression.
or
Enter C to skip over the full disk and compress others specified
in COMPRESS command.
CP2700 Invalid keyin
The compress command was entered incorrectly.
Action Reenter command correctly
XEROX 4635 LASER PRINTING SYSTEM MESSAGE GUIDE 1-1
CP (COMPRESS COMMAND) MESSAGES
CP2710 Keyins are not allowed at this time
Compress process has begun. System cannot process any other
commands entered at this time.
Action 1. Wait for entire compress process to complete.
2. Reenter command.
CP2720 Invalid start command
The COMPRESS start command was entered incorrectly.
Action Reenter COMPRESS.
CP7010 Unable to compress this disk. Use DSR - COMPRESS MODE
The COMPRESS command was entered, but disk contains so
many files that there is not enough internal memory to load
COMPRESS task.
Action Perform DSR, selecting compressed object mode, to compress
the disk. (Refer to your 4635 LPS Operations Reference chapter
on managing LPS resources for additional information.)
CP9100 File integrity error. Edit and print CPR000.TMP
The system has discovered a multi-allocated sector and is listing
it in a special file (CPR000.TMP). The compress function is
terminated.
Action 1. Print CPR000.TMP error log to locate the problem.
2. Call Xerox Customer Service with the information above.
1-2 XEROX 4635 LASER PRINTING SYSTEM MESSAGE GUIDE
2. DSR (disk save and restore
These messages may appear during the process of saving all disk
files on tape or restoring all files to system disk from tape. (Refer
to your 4635 LPS Operations Reference chapter on managing
LPS resources for additional information.)
DS1010 Save process complete
The DSR command was entered. The system has completed
backing-up system disk data on tape.
DS1020 DSR is saving disk drive 0.
DS1030 DSR is saving disk drive 1.
DS1040 DSR is saving disk drive 2.
DS1050 DSR is saving disk drive 3.
Action None.
command) messages
DS2010 Mount and ready DSR tape
The DSR command was entered when no save tape had been
mounted.
Action Mount the save tape.
DS2020 Mount and ready DSR volume nnnn
The DSR process requires more than one save tape. The system
has encountered the EOV label.
Action Mount the indicated tape volume.
DS3010 Invalid parameter...DSR aborted
An incorrect density parameter was entered with the DSR
command. The DSR task has terminated.
Action Reenter the command as DSR or DSR 6250. No other
parameters are accepted.
DS3020 DSR Version 2.0 unable to run on this configuration
DSR version 2.0 is incompatible with the current printer
configuration.
Action None.
XEROX 4635 LASER PRINTING SYSTEM MESSAGE GUIDE 2-1
DSR (DISK SAVE AND RESTORE COMMAND) MESSAGES
DS8010 Tape error xxxx...DSR aborted
Action 1. Clean the tape drive and retry the task. (Refer to the
DS8020 Tape is read only...DSR aborted
Action Use a different tape.
DS8030 Tape is write protected
Action 1. Add a write enable ring to tape.
The system has encountered a device error from which it was
unable to recover after several attempts. DSR task is aborted.
maintenance chapter in your 4635 LPS operator guide.)
2. If the problem continues, replace the save tape.
The tape is designed to be read but not written. Data cannot be
copied onto it. The DSR task is aborting.
The save tape does not have a write enable ring. Data cannot be
copied onto it. The DSR task will abort.
2. Reenter the DSR command.
DS8040 6250 not supported, defaulting to 1600
The DSR 6250 command was entered, but your system does not
support a recording density of 6250 bpi. The system will record
at 1600 bpi.
Action None.
DS9010 Disk error xxxx...DSR aborted
The system has encountered an error on disk from which it was
unable to recover after several attempts. The DSR task is
aborted.
Action Contact your systems specialist or Xerox Customer Service.
DS9020 DSR aborted
The DSR task has aborted due to a hardware error.
Action 1. Retry the DSR task.
2. If the problem continues, contact your systems specialist or
Xerox Customer Service.
DS9030 File structure integrity error...DSR aborted
This message occurs during the DSR process of saving disk files
to tape. Either multiple-allocated or nonallocated blocks have
been encountered. The DSR process has been cancelled.
Action 1. Enter the COMPRESS command.
2. If the compress procedure fails, reformat the disk. (Refer to
your 4635 LPS Operations Reference.)
2-2 XEROX 4635 LASER PRINTING SYSTEM MESSAGE GUIDE
DSR (DISK SAVE AND RESTORE COMMAND) MESSAGES
DS9040 System error...DSR aborted
An unspecified hardware error has caused DSR task to abort.
Action 1. Retry the DSR task.
2. If the problem continues, contact your systems specialist or
Xerox Customer Service.
DS9050 File structure integrity error on xx...DSR aborted
The specified disk drive has a corrupt file structure. A format will
be required.
Action Reformat the system disk. (Refer to your 4635 LPS Operations
Reference.)
DS9060 Invalid DSR.SAF detected
DSR.SAF is corrupt or incompatible with DSR.
Action Perform system generation, if authorized to do so, or contact
your systems specialist.
XEROX 4635 LASER PRINTING SYSTEM MESSAGE GUIDE 2-3
3. FD (forms compilation) messages
These messages may appear while forms are being compiled
using Forms Description Language (FDL). (Refer to your 4635
LPS Forms Creation Guide for additional information.)
FD0900 Operator-requested abort
The ABORT command was entered. Compiling is stopped.
Action None.
FD1000 All forms compiled. Forms compiler exiting
The FDL file-name command was entered. Form(s) have been
successfully compiled and the FDL compiling session is
terminated.
Action None.
FD1050 Forms compiler resuming
The system is beginning to compile another form after having
completed one previously sent.
Action None.
FD1800 Forms compiler aborting
The FDL task is being cancelled. The ABORT command was
entered, a system disk error has occurred, or a specified file was
not found. This message appears with all fatal error messages.
Action None.
FD2700 Unrecognized key-in, key-in ignored. May be reentered
A command was entered incorrectly or placed incorrectly in a
line. The system is ignoring the entry.
Action Reenter the command correctly. (Refer to your 4635 LPS Forms
Creation Guide.)
FD2710 Invalid character, reenter
The symbol or word entered was incorrect for its location in the
command line.
Action None.
XEROX 4635 LASER PRINTING SYSTEM MESSAGE GUIDE 3-1
FD (FORMS COMPILATION) MESSAGES
FD2720 Key-in too long. Reenter
The name or word entered exceeds the permitted number of
characters.
Action Enter a different word within the permitted range. (Refer to your
4635 LPS Forms Creation Guide.)
FD2730 Parameter too long. Reenter
The command parameter entered contained more characters than
permitted.
Action Reenter the command with an allowable number of characters.
(Refer to your 4635 LPS Forms Creation Guide.)
FD2740 FSL not found or invalid option, check and retry
The Forms Source Library (FSL) file specified does not exist on
system disk. The compiler will abort.
Action 1. Check FSL for the correct file name.
2. Create the FSL file on disk if necessary. (Refer to your 4635
LPS Forms Creation Guide.)
3. Retry the FDL task.
FD2750 Unsupported tape device specified
You have entered the SUBDEV command, and referenced a tape
device that is currently not supported by this system.
Action Correct the reference parameter in the SUBDEV command. Refer
to your system administrator guide.
FD2915 Security violation
The requested file has been protected by the ABNORMAL
SECURITY = YES PDL statement. An attempt was made to
access it at an incorrect logon level.
Action To access the file, obtain correct password and logon at Level 5.
(Refer to your 4635 LPS Operations Reference chapter on setting
LPS parameters for additional information.)
FD4500 Error in reading magnetic tape
The system is unable to read the input tape containing FDL. The
compiler will abort. (Refer to the maintenance chapter in your
4635 LPS Operator Guide.)
Action 1. Clean the magnetic tape drive. (Refer to the maintenance
chapter in your 4635 LPS Operator Guide.)
2. If the problem recurs, recreate the FDL tape.
3-2 XEROX 4635 LASER PRINTING SYSTEM MESSAGE GUIDE
FD9400-FD9540 Disk/file error messages
The system is unable to access (read, write, open, or close) the
indicated file due to a problem with the disk. Forms Compiler
will abort.
FD9400 Error in closing the source-input file.
FD9410 Error in closing the source-output file.
FD9420 Error in closing the listing/summary file.
FD9430 Error in opening the source/output file.
FD9440 Error in opening the listing/summary file.
FD9450 Error in reading the source-input file.
FD9460 Error in reading the source-output file.
FD9470 Error in writing the source-output file.
FD9475 Error in back-spacing the source-output file.
FD9480 Error in writing the listing/summary file.
FD9485 Error in reading the listing/summary file.
FD9490 Error in back-spacing the listing/summary file.
FD9510 Error in closing context file.
FD9520 Error in opening context file.
FD9530 Error in reading context file.
Action 1. Retry the entry. The message should not reappear if the
failure was an intermittent memory error.
2. If the problem continues, contact your systems specialist or
Xerox Customer Service.
FD (FORMS COMPILATION) MESSAGES
XEROX 4635 LASER PRINTING SYSTEM MESSAGE GUIDE 3-3
4. HIP (host interface processor)
These messages may appear on your system controller display if
printer communications have been established through the host
interface processor (HIP). The HIP chapters in your 4635 LPS
Operator Guide and 4635 LPS Operations Reference provide
detailed information on HIP.
HP0010 Host interface processor unloaded
The HIP command was entered. HIP task is activated and ready
to receive jobs.
Action None.
HP0020 Host interface processor unloaded
messages
The HIP END command was entered. HIP task is deactivated.
Action Wait for the system to print any files stored in the HIP buffer.
HP0030 Logging enabled
You have entered the HIP LOG [START] command. The system
has enabled the logging of selected XNS operations.
Action None.
HP0031 Logging disabled
You have entered the HIP LOG [STOP] command. The system is
telling you that it has disabled the logging of selected XNS
operations. You can disable selected XNS operations for the
purpose of record capturing.
Action None.
HP0080 Concatenated job operator display mode is ‘ON’
In response to an operator command, HIP will display internal
job status while in a concatenated job mode.
Action None.
HP0085 Concatenated job operator display mode is ‘OFF’
In response to an operator command, HIP will not display
internal job status while in a concatenated job mode.
Action None.
XEROX 4635 LASER PRINTING SYSTEM MESSAGE GUIDE 4-1
HIP (HOST INTERFACE PROCESSOR) MESSAGES
HP0090 Job concatenation mode is ‘ON’
Action None.
HP0095 Job concatenation mode is ‘OFF’
Action None.
HP0100 Stopped online
Action 1. Wait for message HP2100 to appear on the printer display.
In response to an operator command, HIP is now in a
concatenated job mode.
In response to an operator command, HIP is not in a
concatenated job mode.
The HIP STOP command was entered while the system was
online. Jobs will be accepted until the HIP buffer is full. No
further jobs will be accepted.
2. Enter the HIP START command to print only jobs in the HIP
buffer.
HP0110 Stopped offline
The HIP STOP command was entered while HIP was offline from
the host. No processes were interrupted.
Action None.
HP0120 Job aborted: JOB ID xxxx
The HIP ABORT job command was entered. The job indicated
has been cancelled.
Action None.
HP0130 Log file reset
You have entered HIP LOG [RESET]. The system is informing you
that the log file has been cleared and all information had been
deleted.
Action None.
HP0210 Transmission aborted: JOB ID xxxx
The HIP ABORT command was entered. The job being sent has
been cancelled.
Action None.
HP1010 Input starting report - jid xx
This is displayed while in a concatenated job mode if the
concatenated job operator display mode is ON when input starts
a HIP job.
Action None.
4-2 XEROX 4635 LASER PRINTING SYSTEM MESSAGE GUIDE
HIP (HOST INTERFACE PROCESSOR) MESSAGES
HP1020 Input report complete - jid xx
This is displayed while in a concatenated job mode if the
concatenated job operator display mode is ON when input
finishes a HIP job.
Action None.
HP1030 Output starting report - jid xx
This is displayed while in concatenated job mode if the
concatenated job operator display mode is ON when output
starts a HIP job.
Action None.
HP1040 Output report complete - jid xx
This is displayed while in a concatenated job mode if the
concatenated job operator display mode is ON when output
finishes a HIP job.
Action None.
HP1100 No jobs to abort
The HIP ABORT command was entered, but the host has not
sent any jobs to the printer.
Action None.
HP1110 End of job display
All job information appears on the system (controller) display.
No more related information will appear at this time.
Action None.
HP1120 HIP job queue cleared
No data remains in the HIP buffer; jobs have printed or have
been aborted.
Action None.
HP1130 Buffer file allocation less than specified
The HIP buffer has less space than specified in the HIP.CMD file
at installation. There may not be enough space to hold the
entire job being sent.
Action 1. Delete unneeded files from system disk to create more
space.
2. Compress the disk. (Refer to your 4635 LPS Operations
Reference chapter on managing LPS resources for additional
information.)
3. Enter SETUP mode to change the HIP buffer file size. (Refer
to your 4635 LPS Operations Reference chapter on HIPaccessed communicating modes for additional information.)
4. Resend the job.
XEROX 4635 LASER PRINTING SYSTEM MESSAGE GUIDE 4-3
HIP (HOST INTERFACE PROCESSOR) MESSAGES
HP1140 Cannot abort job(s): xxxx (, yyyy, etc.)
Action 1. Verify that the job numbers were entered correctly.
HP1150 Cannot start job(s): xxxx
Action 1. Verify that the job numbers were entered correctly.
HP1160 Logging already enabled
The HIP ABORT jobs command was entered. The system is
unable to process the command because job(s) entered were
not received by printer.
2. Reenter the command.
The HIP START jobs command was entered, but the system is
unable to process the jobs indicated because they are either not
in the pending or receive state, or they have already been
started.
2. Reenter the command.
You have entered the HIP LOG [START] command. The system is
informing you that the log is already enabled.
Action None.
HP1170 Log file allocation less than specified
The system is informing you that there is insufficient disk space in
the file system for the number of log entries specified in the
LOG ENTRIES command. The system allocates the largest
possible number of entries available for the disk space.
Action None.
HP1171 New log file created
A new log file has been created.
Action None.
HP1172 Log file empty, nothing to print.
You have entered the HIP SHOW LOG [PRN] command and
there are no entries in the log file.
Action None.
HP1180 No echo servers on list
There are no echo servers on list.
Action None.
HP1181 Echo test started. Results available in nnn seconds
The echo test has been started.
Action None.
4-4 XEROX 4635 LASER PRINTING SYSTEM MESSAGE GUIDE
HIP (HOST INTERFACE PROCESSOR) MESSAGES
HP1182 Echo test already running
The echo test is running.
Action None.
HP1183 Invalid echo server specification
You have entered an invalid echo server specification.
Action None.
HP1184 Echo test was not in progress
The echo test is not in progress.
Action None.
HP1185 Echo test terminated. echo server: nn
The echo test has been terminated.
Action None.
HP1190 HIP version n, n
This is an informational message stating the HIP version(s) being
used.
Action None.
HP1200 Offline pending end of transmission
The HIP OFFLINE command was entered. The printer will go
offline when the current file being received is complete.
Action None.
HP1207 Offline pending end of current active xns session
The HIP OFFLINE command was entered. The printer will
disconnect from Ethernet when the current session is terminated.
Action None.
HP1210 Host online. Accepting all jobs
The HIP ONLINE ALL command was entered. The printer and
remote host are communicating, and the host is sending jobs to
the HIP buffer. All print and nonprint files (fonts, forms, or JSLs)
will be accepted.
Action Enter the HIP START command at the system controller keyboard
to initiate printing.
XEROX 4635 LASER PRINTING SYSTEM MESSAGE GUIDE 4-5
HIP (HOST INTERFACE PROCESSOR) MESSAGES
HP1220 Host online. Accepting print jobs only
Action Enter the HIP START command at the system controller keyboard
HP1230 Host offline
Action None.
HP1240 Host not responding
Action 1. If using Ethernet, verify that the connection is good and that
The HIP ONLINE command was entered. The printer and the
remote host are communicating, and the host is sending jobs to
the HIP buffer. Only files to be printed will be accepted.
to initiate printing.
The HIP OFFLINE or RESET command was entered. The printer
and remote host are no longer communicating.
The HIP START command was entered but the host is not online
and communicating with printer. (This message is displayed
every 30 seconds until the host comes online or the interface is
terminated.)
the printer network address and network number are correct.
2. If using XPAF, contact your systems specialist or Xerox
Customer Service.
. If the failure recurs, call for service.
3
HP1242 Online interface waiting for communications
HIP is online to the XPAF host and waiting for communications.
Action None.
HP1246 Receiving communications from host
The host has established the data communications link.
Action None.
HP1250 Transmission complete: job id xxxx
The host has completed sending the indicated job to the printer.
The job will now begin printing.
Action None.
HP1260 Interface busy - cannot send file(s)
The HIP SEND command was entered. The interface is busy and
is unable to send files from the host at this time.
Action Wait for current transmission to complete.
HP1265 Online interface already in use
The XPAF host was already online when the HIP HOST XPF
command was entered.
Action None.
4-6 XEROX 4635 LASER PRINTING SYSTEM MESSAGE GUIDE
HIP (HOST INTERFACE PROCESSOR) MESSAGES
HP1270 Change of job nn to file xxxxxx completed successfully
The CHANGE command successfully created the file.
Action None.
HP1280 HIP reset not allowed. Invalid task state
HIP is online and/or jobs in the HIP queue are not completed.
HIP must be offline and all jobs must be completed before the
HIP RESET command can be invoked (these restrictions do not
apply at logon level 4).
HP1290 Host suspended pending pass-through job initiation
A pass-through job was received and the HIP online interface was
suspended.
Action None.
HP1291 HIP resuming following pass-through job
The pass-through job has completed and HIP is ready to receive
data
Action None.
HP1298 XPS communications recovered
HIP can now receive data via the XPS communication mode.
Data received but not yet written to system disk will be copied
from memory (saved at system error restart) and written to
system disk. The system then reestablishes the communications
link and continues to receive the next block of data.
Action None.
HP1299 XPAF communications recovered
HIP can now receive data via the XPAF communication mode.
Data received but not yet written to system disk will be copied
from memory (saved at system error restart) and written to
system disk. The system then reestablishes the communications
link and continues to receive the next block of data.
Action None.
HP1300 Assuming negative confirmation
A confirmation prompt requiring a YES or NO response was
displayed. No response was entered within the system’s time
limit. The system is responding as if N were entered.
Action If the Y response was intended, reenter the command,
responding to the confirmation prompt within the system time
frame of 30 seconds.
XEROX 4635 LASER PRINTING SYSTEM MESSAGE GUIDE 4-7
HIP (HOST INTERFACE PROCESSOR) MESSAGES
HP1320 Function is not supported by current host
Action None.
HP1325 Command not permitted by current host
Action 1. Log off and then log on at level 2.
HP1330 Buffersize=xxx, utilization=yy% zzzz blocks used, uuuu
Action None.
The requested function cannot be carried out by the current
host.
You are currently logged on to the system at a level less than 2.
The command you attempted to enter cannot be accepted at
your present level.
2. Refer to the appropriate 4635 LPS Operator Guide.
blocks available.
This messsage provides the number of blocks available and the
amount of the buffer already used.
HP1340 Known and current hip hosts:
This message lists the available and currently-used HIP hosts for
your system.
Action None.
HP1410 End of HIP diagnostic
The HIP command was entered during an interactive diagnostic
test, or the system failed Test 2 or 3. The diagnostic test has
been terminated.
Action None.
HP1420 End of test 3 analysis
The system failed Diagnostic Test 3. HIP has completed analysis
of Test 3 results and has identified the data line that has failed.
This message follows message HP9431 or HP9432.
Action None.
HP2010 No host selected
A host has not been selected for HIP.
Action Enter the appropriate HIPHOST command. (Refer to your 4635
LPS Operations Reference chapter on HIP-accessed
communicating modes for additional information.)
HP2020 Selected host not present on system
The host selected is not available on your system.
Action Contact your systems specialist or Xerox representative.
4-8 XEROX 4635 LASER PRINTING SYSTEM MESSAGE GUIDE
