User Manual
32 pgs4.58 Mb0

Xdp recreation 86150 User Manual

Download
Page 1
DO NOT RETURN TO RETAILER WHERE PURCHASED.
CONTACT XDP FOR PARTS AND SUPPORT AT 1.866.884.0535 or [email protected]
MODEL #: 86150
“
Assembled dimensions are 180” x 104” x 74” Allow 6 - 12 ft of clearance around the perimeter of the swing set area when fully
assembled.
OWNER'S MANUAL, ASSEMBLY INSTRUCTIONS, CARE, MAINTENANCE AND USER'S
GUIDE
WA RN ING !
Please read this entire instruction and assembly manual completely before proceeding. Yo u m us t f o ll ow al l sa fe ty
instructions while using this equipment. The surface area where this swing set is set up must be level and free of all debris. This
set is designed to be anchored into the ground and is not to be set up on any hard surfaces such as concrete, hardened soil, or
asphalt. Proper surfacing under and surrounding the set adds to the safety level such as sand or mulch. Read all cautionary
statements on the following pages before using this equipment and save this instruction manual. DO NOT ALLOW
CHILDREN TO PLAY ON THIS GYM SET UNSUPERVISED! CONSTANT ADULT SUPERVISION IS REQUIRED.
Do not use when raining or during any inclement weather (i.e. rain, sleet, snow, ice, high winds, thunderstorms, or lightening).
DO NOT ALLOW CHILDREN TO JUMP ON OR CLIMB UP ON THIS SET'S TOP BAR.
For warranty details and registration see the back page of this manual.
FOLLOW ALL ASSEMBLY INSTRUCTIONS AS WRITTEN IN THIS MANUAL
! ! ! ! ! ! !
Please retain sales receipt for warranty purposes. DO NOT
RETURN THE SET TO THE STORE. If replacement parts or customer
service is needed please contact XDP Recreation by email at
[email protected] or by calling 1-866-884-0535
between 8:00am and 5:00pm (Eastern Standard Time), Monday - Friday. This gym is designed to be used safely by
up to seven (7) children, ages 3 years to 8 years, with weight capacity of 100 lbs per child or total combined weight
limit of 700 lbs for all seven (7) children (318kgs). This play gym is designed for backyard use only and is NOT
intended for playgrounds, schools, day care facilities, nurseries or other public places. Follow all assembly
instructions carefully and as directed in this manual. This gym conforms to all safety requirements by ASTM for
Home Playground equipment when properly assembled using the instructions enclosed. Adult assembly is required.
