Xantech HD44CC5, HD44C User Manual

INSTALLATION INSTRUCTIONS
HD44CC5 HD44C
High Definition Video Matrix Switcher,
Coaxial and CAT5
The HD44CC5 four-source, four-zone high-definition matrix switcher has component video and S/PDIF digital audio inputs for each source. All four zone outputs have component video output and S/PDIF audio output for economical local distribution up to 250’, as well as a RJ45 output for transmission of the video and digital audio signal up to 1000’ to the HDRXSG01 receiver located in the zone. Both coaxial component video output and CAT5 output are active simultaneously, making it possible to distribute four sources to eight outputs at the same time.
The HD44C has the same great features as the HD44CC5 without the CAT5 output. The HD44C is ideal for installations requiring local switching and distribution up to 250’.
The HD44CC5 and HD44C unit is expandable up to 16 zones.
SPECIFICATIONS
Size: 17” W x 7 3/8” D x 3 15/16” H Weight: 9.25 lbs (4.2 kilos) Controllable through IR and RS232 commands Bandwidth supports resolutions of 1080p, 1080i, 720p, 480p and 480i. Optional Rack Mount kit available (RM2UKIT) Power supply (120VAC, 0.25A, 50-60Hz) Operates in temperatures up to 55 degrees Celsius.
High Definition Video Matrix Switcher,
Coaxial Only
08905071B - 1 -
DETAIL OVERVIEW
[1] SOURCE LOOP-THROUGH CONNECTION
The source inputs are buffered to provide an output at the same levels, assuming a 75-ohm termination is on the output. Use these connections for HD44 expansion systems. The buffers are an active circuit. The HD44 must be powered on for an active connection.
[2] SOURCE INPUTS
Gold-plated RCA jacks for connection from the output of the source. Color coordinated to match all HD source components.
08905071B - 2 -
[3] IR RECEIVER
The rear panel IR receiver is a 3.5mm Stereo jack that is compatible with all Xantech IR receivers, such as the 291-10. Switch 4 must be in the OFF position to use this jack.
PLUG CIRCUIT
TIP IR SIGNAL RING GROUND SLEEVE +12VDC, 25mA
[4] IR BUS, EMITTER PORT
The 3.5mm Mono jack is an emitter port. The IR signal is connected to the IR Receiver. A Xantech 283M emitter can be connected to this port.
PLUG 2-Pin WECO CIRCUIT
TIP + IR SIGNAL SLEEVE - GROUND
The 2-Pin WECO screw terminal is an IR port. The IR signal is connected to the IR Receiver. The WECO screw terminal allows easy installation to a typical Xantech IR connecting block.
[5] RS232 (SERIAL) COMMANDS
The RS232 Port is bi-directional. The communication is set to 9600 Baud 8-N-1.
DB9 CONNECTOR
CIRCUIT PIN
TX 2 RX 3
GND 5
08905071B - 3 -
Where:
RS232 COMMAND STRUCTURE
{CR#} – Carriage Return (0x0D) {z#} - Zone Number. Range is 1..4 (1..16 if expanded) {s#} - Source Input Number. Range is 1..4 {0/1} – Either 0 (zero) or 1 (one). 0 – Off, 1 – On.
NAME COMMAND RETURN
!{z#}PR01+
Zone Power
!{z#}PR00+
Zone Power Toggle
All Zones Off
All Zones On
Zone Restore All
Input (Source) Select
Ping Expansion Port
Return Ping to Xantech port
!{z#}PT+
!EO+
!EA+
!RF+
!{z#}SS{s#}+
!RP+
!SP+ +
OK{CR} ERROR{CR}
OK{CR} ERROR{CR}
OK{CR} ERROR{CR}
OK{CR} ERROR{CR}
OK{CR} ERROR{CR}
OK{CR} ERROR{CR}
OK{CR} ERROR{CR}
REMARKS
To turn on Zone 2: !2PR1+ or !02PR1+ or !2PR01+ or !02PR01+ To turn off Zone1: !1PR0+ or !01PR0+ or !1PR00+ or !01PR00+
Turns all the zones off.
Turns all the zones on.
Restore all the Zone-to-Source routing to the current selection: !RF+
To set Zone 1 to Source Input 4: !1SS4+
Request that any unit connected to the expansion port respond with a ping.
Returns a +. Meant for inter-expansion box communications.
08905071B - 4 -
RS232 QUERIES
Where:
{CR#} – Carriage Return (0x0D) {z#} - Zone Number. Range is 1..4 (1..16 if expanded) {s#} - Source Input Number. Range is 1..4 {0/1} – Either 0 (zero) or 1 (one). 0 – Off, 1 – On.
NAME QUERY RETURN
Zone Power ?{z#}PR+ ?{z#}PR{0/1}+ ?4PR0+{CR} Power in zone 4 is OFF. Input Select ?{z#}SS+ ?{z#}SS{s#}+
?SI {Device: HD44, Device Cde: 000C,
System Info ?SI+
Hardware Cde: 0000, Reserved Cde: 0000, Firmware Ver: X.Y.Z}+
EXAMPLE
RETURN
?4SS3+{CR} Zone 4 currently has source 3 selected.
?SI Device: HD44, Device Cde: 000C, Hardware Cde: 0000, Reserved Cde: 0000, Firmware Ver:
1.1.0
This command is used only with single unit systems. Note this is command does not trickle down to the expansion port.
X = Major Y = Minor Z = Release
EXPLANATION
08905071B - 5 -
[6] AC POWER INPUT
Standard IEC 3-Conductor AC Line Cord Receptacle for plug-in of a 3-conducator power line cord. Be sure to note if the power receptacle is domestic (120VAC type) or international (240VAC type).
[7] RS232 EXPANSION
The HD44C and HD44CC5 can be expanded into a larger system. By using any combination of the HD44C and HD44CC5 (up to 4 units), a larger High-Definition distribution system can be created.
For instance, two HD44C units can be combined to create a much larger 4 source input to 8 zone output. The two HD44C units must have their own unique address (see ADDRESS (DIP SWITCH) section). The top unit (master controller) must always be addressed as UNIT 1. See Section 8 for setting the unit address. The included RS232 expansion cable allows a single RS232 control port to be used to command the entire system. The expansion cable is connected between the DB9 (5) and
3.5mm stereo mini jack (7).
IMPORTANT NOTICE
The top unit (master controller) must always be addressed as UNIT 1.
DB9 MALE 3.5MM PLUG
CIRCUIT PIN
TX 2 TIP TX RX 3 RING RX GND 5 SLEEVE GND
[8] ADDRESS (DIP SWITCH)
Switch 1 & 2: Unit Address (for Expansion mode)
ADDR SW 1 SW 2
UNIT 1 OFF OFF UNIT 2 OFF ON UNIT 3 ON OFF UNIT 4 ON ON
Switch 3: ON for firmware write protect Switch 4: ON for front panel IR receiver / OFF for rear panel IR receiver
PLUG CIRCUIT
08905071B - 6 -
[9] CAT5 ZONE OUTPUT
Output connection to the HDRXSG01 receiver module. Uses standard CAT5 cable. Be sure to verify CAT5 wiring connection is correct before installation.
[10] COAXIAL ZONE OUTPUT
Gold-plated RCA jacks for connection to an HD monitor. Color coordinated to match all HD type products. The CAT5 and coaxial output can be used at the same time.
IMPORTANT NOTICE
After connecting the CAT5 cable to the receiver (HDRXSG01), the power supply to the receiver should be unplugged for a few seconds and then reconnected. This allows the receiver to go through the full process of line length and line quality self-calibration.
Do not connect the power supply to the receiver until after the CAT5 connection. The HD44CC5 must be powered on before the HDRXSG01.
As an alternate process to this procedure, the power may be cycled off for a few seconds and reapplied to accomplish the same full self­calibration process.
If for some reason the system losses power at the receiving end (HDRXSG01), the transmitting end (HD44CC5), or both ends, the full self-calibration process will automatically occur.
08905071B - 7 -
QUICK INSTALLATION: HD44CC5 and HDRXSG01 [1] Connect the High-Definition Source to the HD44CC5 or HDTXSG01. Figure 1 below shows a
HD44CC5 (video matrix transmitter) connected to the HDRXSG01 (receiver). [2] Using CAT5 cable, connect the HD44CC5 zone output or the output from the HDTXSG01 to the HDRXSG01. Connect power to the HD44CC5 first. Then connect power to the HDRXSG01. [3] On the HD44CC5, set the source to zone to enable the HDRXSG01 from the connected High- Definition source. See HD44CC5 manual on how to use RS232 and IR RC68+ controls. [4] Installation Complete! No adjustments needed!
08905071B - 8 -
RC68+ (IR) COMMANDS The RC68+ should be set to Group Code “C0”.
1
2
3 4 5 6 7
Zone Power Toggle 80 48 10 90
Zone 1 Source Select 00 C0 50 D0 Zone 2 Source Select 40 A0 30 B0 Zone 3 Source Select 20 E0 70 F0 Zone 4 Source Select 60 88 18 98
Zone Power On 08 A8 38 B8 Zone Power Off 28 E8 78 F8 Zone Power All Off 68 Zone Restore All C8 Zone Power All On 58
ZONE 1 ZONE 2 ZONE 3 ZONE 4
SRC 1 SRC 2 SRC 3 SRC 4
ZONE 1 ZONE 2 ZONE 3 ZONE 4
Note: For expanded systems, the ‘Primary’
HD44 should remain on the default group code of “C0” but each additional HD44 will need to be changed to a different discrete Code Group so the units can be individually controlled. To change the Group Code of the additional HD44’s please see the RC68X instruction manual (section labeled CHANGING THE INTERNAL CODE GROUP NUMBER OF A XANTECH MODEL) or the Application Advisory AA-09 on the Xantech Web Site
[URL:
http://www.xantech.com/products/a_folder/a_aa
09.pdf
08905071B - 9 -
ADVANCE INSTALLATION FIGURE 2: Below shows a diagram for a sports bar application. With the equipment rack located near
or behind the bar area, the coaxial outputs can be used for local HD monitors. The CAT5 outputs can be used to deliver HD content to areas such as outdoor patios and pool table recreational areas.
FIGURE 2
FIGURE 3: The figure in the next page shows an expanded HD44CC5 system. With two HD44CC5
devices, HD content can be distributed to 16 displays (8 with CAT5 outputs, 8 with coaxial outputs). The included RS232 expansion cable allows a single RS232 control port to be used to command the entire system.
08905071B - 10 -
FIGURE 3 (Note: The top unit (master unit) must be addressed as UNIT #1)
08905071B - 11 -
COMMON PROBLEMS AND TROUBLESHOOTING Poor video quality (picture is washed out): Several manufacturers of cable and satellite box may
have higher than normal DC offset on the video signals. When connected to an HD44C, HD44CC5, and HDTXSG01, this may result in a washed out picture. To remedy this problem, a DC blocker should be used between the source component and the HD44C, HD44CC5, and HDTXSG01.
Picture appears to be blooming: A blooming picture is usually caused by a video signal that is too high. One reason for this problem is the HDRXSG01 was not synchronized to the HD44CC5. To correct this, be sure the CAT5 cables is connected between the HD44CC5 and HDRXSG01. Remove power from both devices. Simultaneously apply power to both units. This will synchronize the correct signal strength.
Xantech Corporation
13100 Telfair Avenue, 2/F
Sylmar, CA 91342 www.xantech.com
Phone: (818) 362-0353, Fax: (818) 362-9506
Installation Instructions, HD44CC5, HD44C © 2007 Xantech Corporation
This document is copyright protected. No part of this manual may be copied or reproduced in any form without prior
written consent from Xantech Corporation.
Xantech Corporation shall not be liable for operational, technical, or editorial errors/omissions made in this document.
Document Number 08905071B
08905071B - 12 -
