CWTC10
10.4” Wireless Touch Controller
User’s Manual
REGULATORY NOTICES
Federal Communications Commission Notice
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses,
and radiates radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation.
CAUTION!
CAUTION! Danger of explosion if an improper battery is
substituted. If a replacement is needed, only replace with a
manufacturer issued battery pack.
Do not dispose of the battery pack in a fire. They may explode.
Check with local authorities for proper disposal instructions.
TABLE OF CONTENTS
1. GETTING STARTED..................................................................................1
1.1. WELCOME ....................................................................................1
1.2. SAFETY INSTRUCTIONS AND CARE OF YOUR CWTC10 ............... 1
1.3. CHECKLIST ................................................................................... 3
2. GETTING TO KNOW YOUR CWTC10 .............................................5
2.1. P
2.2. T
ARTS NAMES ..............................................................................5
HE CRADLE ................................................................................8
2.3. THE BATTERY AND AC ADAPTER ................................................ 9
2.4. THE STYLUS ...............................................................................10
2.5. TOUCH-SCREEN DISPLAY ...........................................................11
2.6. DISPLAY PROPERTIES .................................................................11
2.7. THE CRADLE ..............................................................................11
3. PANEL CONFIGURATION ................................................................. 12
3.1. DATA INPUT ...............................................................................12
3.2. BASIC SETTINGS……………………………………………12
SYNCHRONIZATION CONNECTING OTHER DEVICES ............................15
4. GETTING ONLINE................................................................................... 16
5. TROUBLESHOOTING ........................................................................... 17
6. SPECIFICATIONS .................................................................................... 19
1. Getting Started
1.1. Welcome
Congratulations! With your new CWTC10 you will be able to
control your WIC1200 Web Intelligent Controller or just about any
web server based system. The CWTC10 has a unique firmware build
of Window’s CE which secures the device for the specific intent of
displaying your control web page while preventing access to critical
setup and files. When the CWTC10 is turned on it will do only one
thing; display your control web page, allowing you to control your
custom system without worries of it controlling you. Your CWTC10
also gives you freedom with easy access to the Internet, and the
800X600 SVGA screen offers high resolution for all your control
system uses.
This manual will guide you through the unit’s simple set-up,
introduce you to its range of features and help you source extra
information.
1.2. Safety Instructions and Care of your CWTC10
CAUTION!
Danger of explosion if an improper battery is substituted. If a
replacement is needed, only replace with a manufacturer issued
battery pack.
• During normal usage and charging, the battery pack heats up.
This is caused by energy that has been generated and a chemical
- 1 -
charge that has occurred inside the battery pack. This is not a
cause for concern.
• You should charge batteries at temperatures from 10°C to 30°C
(from 50°F to 85°F). Lower temperatures require a longer
charging time.
• Do not carry a battery in your pocket, purse, or other container
where metal objects could short-circuit the battery pack. The
resulted excessive current flow can cause extremely high
temperatures and may result in damage from burns.
• Do not use your CWTC10 in a wet environment, for instance,
near a bathtub, sink, or any other place where there is risk of
moisture.
• To help prevent electric shock, plug the AC adapter into a three
prong, grounded power source. If a two-prong extension plug is
absolutely needed, use a 3-wire cable with properly grounded
plugs.
Do not dispose of the battery pack in a fire. They may explode.
Check with local authorities for-proper disposal instructions.
• When traveling, never check your CWTC10 as baggage. You can
put your CWTC10 through an X-ray security machine, but never
put your CWTC10 through a metal detector. Have a charged
battery with you in case you are asked to turn on the Tablet.
• When traveling, do not place the CWTC10 in an overhead
compartment where it can slide around. Do not drop your
CWTC10 or subject it to mechanical shocks.
• Protect your CWTC10 from environmental hazards such as dirt,
dust, food, liquids, temperature extremes, and over exposure to
sunlight.
- 2 -
• When you change environments rapidly, in respect to
temperature and humidity, with your CWTC10, condensation
may form on or within the Tablet. To avoid potential damage to
your CWTC10, allow sufficient time for the moisture to
evaporate before using.
• When disconnecting cables from your CWTC10, be sure to pull
on the connector or the strain relief loop, not on the cable itself.
As you pull, keep it evenly aligned to avoid bending the
connector pins. Never force a connector into a port. Make sure
the connector and port are aligned correctly.
• Before you clean your CWTC10, turn it off, remove the battery,
and unplug the power source.
• Clean your computer with a soft cloth dampened with water
rather than with liquid or aerosol cleaners.
• Clean the screen with a soft, clean cloth and commercial window
cleaner that does not contain wax or abrasives. Always apply the
cleaner to the cloth, not the screen. If the display contains grease
or some other contaminant, use isopropyl alcohol instead of
commercial cleaner.
1.3. Checklist
Check to see that the package your CWTC10 came in includes these
items:
• CWTC10
• Cradle
• AC Adapter
- 3 -
• Power Cord
• Battery Pack
• Stylus
• User Manual
- 4 -
2. Getting to Know Your CWTC10
2.1. Parts Names
Your CWTC10 features powerful functions and connectivity for you
to control your system via a touch panel interface.
This section outlines your CWTC10’s components.
Top Side
1. Power On/Off (Suspend/Resume) Switch
2. Future Expansion
3. SD Card Slot
4. Stylus Storage
12 3
4
- 5 -
Right Side
5. External Microphone jack
6. External Headphone jack
7. VGA-Out Connector
8. RS-232 Connector
5 67 8
Left Side
9. RJ-45 LAN Port
10. USB 2.0 Type A Port x2
11. DC IN Jack
9 10
- 6 -
11
