TV Buddy
™
Universal TV Remote
with Bottle Opener
and Corkscrew
Model UR41A
INTRODUCTION
Direct Library Code Entry
Your TV Buddy™ Universal TV Remote controls
most all TV brands presently available. It also
includes a handy bottle opener and corkscrew so
you can enjoy a beer or a glass of wine while
watching your favorite movie.
SET UP INSTRUCTIONS
Install 2 AAA alkaline batteries in the battery
compartment on the back of the remote.
Look up the 3 digit code for your brand of TV
from the Code Table and install it into the remote
as follows:
To enter Codes directly from Library Code
Table.
1. Press and hold the Power and Mute buttons
simultaneously until the red LED remains on.
2. Release the buttons.
3. Enter the 3 digit code for your brand of TV
from the Library Code Table by using the V-,
Ch+, and V+ buttons. Use the V- button to
enter the first digit, use the Ch+ button to
enter the second digit and use the V+ button
to enter the third digit.
E.G. to enter code 013, don’t press V-, press
Ch+ once, and press V+ three times. The red
LED blinks off with each keypress.
4. Press the Mute button to save the code.
Note: for a valid code, the red LED turns off.
For an invalid code, the red LED blinks
rapidly for three seconds before going off.
5. Direct code entry is now complete.
Write your code below in case you forget it.
32
Code Search Method
Code Identification
If you cannot find a 3 digit code in the Code
Table that operates your TV, try searching for the
code as follows:
1. Manually turn on the TV to be controlled.
2. Press and hold the Power and Mute buttons
until the red LED remains on.
3. Release the buttons.
4. Press the Power button to begin code search.
5. Press the Channel Up (Ch+) button (or Power
button) repeatedly until the TV changes
channel (or turns off). You might have to
press the button 100 times or more to find
your code. If you accidentally overshoot the
code required, press the Channel Down (Ch-)
button, to backtrack through the code library
until the TV changes channel.
6. Press Mute to save the code.
7. Code Search is now complete. Write down
your code on the previous page.
Note: Code Search will start from the currently
stored three digit number. E.G. if there are 100
codes in the library and the currently stored code
is 050 then the Code Search will start from 051
continuing to 100 before looping back to 000
and finishing at 050.
To determine the code installed in the remote:
1. Press and hold Power and Mute at the same time
until the red LED remains on.
2. Release the buttons.
3. Press and release the Channel Down (Ch-)
button. The red LED blinks off once to
indicate the keypress acceptance.
4. To find the first digit, press the V- button and
count the red LED blinks. To find the second
digit, press the Ch+ button and count the red
LED blinks. To find the third digit, press the
V+ button and count the red LED blinks. The
red LED remains off after the last blink.
Note: No blink indicates a “0” digit.
5. Code Identification is now complete.
Note: If the remote accidentally gets stuck down
the back of the couch with a button pressed it
will stop transmitting after about 2 minutes so as
not to drain the battery.
When changing batteries have the new batteries
handy before removing the old ones. If the
remote has no batteries installed for more than
about a minute you will lose the installed code.
54
OPERATION
Press Power to turn your TV on and off.
Press Channel Up (Ch+) or Channel Down (Ch-)
to change channels.
Press Volume Up (V+) and Volume Down (V-) to
adjust the volume of your TV.
Press Mute to silence your TV.
Place back of bottle opener over bottle top and
lift.
Screw corkscrew clockwise into top of wine
bottle and pull.
Enjoy ☺
Channel Up
Volume Down
Mute
Power
Volume Up
Channel
Down
Bottle
Opener
Corkscrew
76
Code Table
Abex 185
Acme 001
Ada 017
Adc 006 098
Admiral 014 186
Adventura 187
Aiko 029
Alleron 059
Amtron 051
Akai 015
Amstrad 202
Anam national 016 051 055 205 206 207
AOC 017 018 020 022 027 188
Audiovox 051
Belcor 017
Bell & Howell 014 062 096
Bradford 051
Brokwood 017
Candle 017 021 022 187
Capehart 188
Celebrity 015
Centurion 022
Cetronic 055
Citizen 017 021 022 029 051 055
Clairtone 027
Classic 055
Colortyme 017 022 023 213
Concerto 017 022
Contec/Cony 024 026 027 051 055 184
Craig 051 055
Crown 051 055 184
Curtis Mathes 013 017 022 028 062 084
208
084 118 184 187 190
118 184
CXC 051 055
Daewoo 017 018 022 029 030 031
Daytron 017 022 184
Dimensia 013
Dumont 017 134
Dynasty 055
Dynatech 191
Electroband 015 027
Electrohome 016 017 018 022 035
Emerson 017 022 027 036 037 038
Envision 017 022
Fisher 026 062 064 193
Fujitso 059
Funai 051 055 059
Futuretec 051 055
GE 013 016 017 022 035 065
Gibralter 017 134
Goldstar 017 018 022 069 070 071
Grundy 051 059 184
Hallmark 017 022
Harvard 051
Hitachi 017 022 024 026 072 073
055 098 139 140 184
039 040 043 044 045 046
047 048 049 050 051 052
053 054 055 056 057 058
059 062 136 137 176 184
190 192 210
067 068 100 176 177 179
180 194
168 169 184 185
074 100 150 151 152 153
154 155 156 157 158 159
160 161 163 184 192 211
212
98
Ima 051
Infinity 075
Janeil 187
JBL 075
JCB 015
JC Penny 013 017 018 021 022 035
Jensen 017 022
JVC 024 026 067 073 078 079
Kawasho 015 017 022
Kaypani 188
KEC 055
Kenwood 017 022
Kloss Novabeam 081 082 187
KTV 027 051 055 083 184 190
Lodgenet 096
Loewe 075
Logik 096
Luxman 017 022
LXI 013 022 062 075 084 194
Megatron 022 072
Magnavox 017 021 022 075 081 082
Majestic 096
Marants 075
Marantz 017 022 075 091
Matsui 075
MEI 027
Memorex 014 018 022 062 096
MGA 017 018 022 035 059 064
Midland 067 134 184 185 194
065 067 071 076 077 084
100 118 141 184 185 194
214
080 102 171 172 184 195
087 088 089 090 101 102
143 145 146 197
092
Minutz 065
Mitsubishi 017 018 022 035 059 064
Montgomery ward 096
Motorola 016 186
MTC 017 018 022 027 084 118
Multitech 051 191
Multivision 097
NAD 022 084 198
NEC 016 017 018 022 098 102
Nikei 055
Nikko 022 029
Ntc 029
Onking 055
Onwa 051 055
Optimus 183 198
Optonica 108 186
Orion 048
Panasonic 016 067 075 183
Philco 016 017 018 021 022 075
Philips 016 017 019 021 022 075
Pilot 017 184
Pioneer 017 022 103 104 105 192
Portland 017 018 022 029 184
Price Club 118
Prism 067
Proscan 013 194
Proton 017 022 106 184 188 199
Pulsar 134
Pulser 017
092 094 102 138
191
108 213
081 082 087 088 090 184
197
081 082 087 088 089 099
100 101 102 184
198
1110
Quasar 016 067 083 107
Radio Shack/ 013 017 022 024 051 054
Realistic 055 062 108 168
RCA 013 016 017 018 020 022
Rhapsody 027
Runco 134
Sampo 017 022 184 185 188
Samsung 017 018 022 024 028 084
Samsux 184
Sanyo 017 026 062 064 120 121
Scotch 022
Scott 017 022 037 048 051 055
Sears 013 017 022 026 059 062
Sharp 017 022 108 124 125 126
Shogun 017
Signature 014 096 128
Simpson 021
Sonic 027
Sony 015 019
Soundesign 017 021 022 051 055 059
Squareview 202
SSS 017 051 055
Starlite 051
Supremacy 187
Supreme 015
183 184 185 210
109 111 112 113 114 115
116 142 192 194 200 201
117 118 119 184 185 214
217
193
059 184
064 079 084 118 122 123
193 194 202 210
127 135 184 186
Sylvania 017 021 022 075 081 082
Symphonic 046 051 202
Tandy 186
Tatung 016 191
Technics 067
Techwood 017 022 067
Teknika 017 018 021 022 026 029
Telecaption 130
Telerent 096
Tera 199
TMK 017 022
Toshiba 026 062 084 102 118 122
Totevision 184
Universal 065 100
Victor 079 195
Vidtech 017 018 022
Viking 187
Wards 013 014 017 018 022 037
Yamaha 017 018 022
Yupiteru 055
Zenith 096 134 166
087 088 089 090 101 174
197
051 055 059 084 089 096
118 183 184 187
130 131 214
046 059 065 075 081 082
087 088 089 096 100 101
108 132 133 197
1312
NOTES
ONE YEAR LIMITED WARRANTY
X10.COM A DIV. OF X10 WIRELESS TECHNOLOGY, INC. (X10)
WARRANTS ITS PRODUCTS TO BE FREE FROM DEFECTIVE
MATERIAL AND WORKMANSHIP FOR A PERIOD OF ONE (1) YEAR
FROM THE ORIGINAL DATE OF PURCHASE AT RETAIL. X10 AGREES
TO REPAIR OR REPLACE, AT ITS SOLE DISCRETION, A DEFECTIVE
X10 PRODUCT IF RETURNED TO X10 WITHIN THE WARRANTY
PERIOD AND WITH PROOF OF PURCHASE.
IF SERVICE IS REQUIRED UNDER THIS WARRANTY:
1. CALL 1-800-675-3044, OR VISIT WWW.X10.COM, OR E-MAIL
SALES@X10.COM TO OBTAIN A RETURN MERCHANDISE
AUTHORIZATION (RMA) NUMBER.
2. RETURN THE DEFECTIVE UNIT POSTAGE PREPAID TO THE
ADDRESS ON BACK.
3. ENCLOSE A CHECK FOR $4.00 TO COVER HANDLING AND
RETURN POSTAGE.
4. ENCLOSE A DATED PROOF OF PURCHASE.
5. X10 IS NOT RESPONSIBLE FOR SHIPPING DAMAGE. UNITS TO BE
RETURNED SHOULD BE PACKED CAREFULLY.
THIS WARRANTY DOES NOT EXTEND TO ANY X10 PRODUCTS
WHICH HAVE BEEN SUBJECT TO MISUSE, NEGLECT, ACCIDENT,
INCORRECT WIRING OR TO USE IN VIOLATION OF OPERATING
INSTRUCTIONS FURNISHED BY US, NOR EXTEND TO ANY UNITS
ALTERED OR REPAIRED FOR WARRANTY DEFECT BY ANYONE
OTHER THAN X10. THIS WARRANTY DOES NOT COVER ANY
INCIDENTAL OR CONSEQUENTIAL DAMAGES AND IS IN LIEU OF
ALL OTHER WARRANTIES EXPRESSED OR IMPLIED AND NO
REPRESENTATIVE OR PERSON IS AUTHORIZED TO ASSUME FOR US
ANY OTHER LIABILITY IN CONNECTION WITH THE SALE OF OUR
PRODUCTS.
SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN
IMPLIED WARRANTY LASTS, AND/OR THE EXCLUSION OR
LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES SO
THE ABOVE LIMITATIONS AND EXCLUSIONS MAY NOT APPLY TO
THE ORIGINAL CUSTOMER. THIS WARRANTY GIVES YOU SPECIFIC
RIGHTS AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY
FROM STATE TO STATE.
If you have any questions concerning warranty or installation, please call 1-800675-3044, e-mail sales@x10.com, or visit www.x10.com/warranty for on-line
warranty registration.
1514
X10.com, a division of
X10 Wireless Technology, Inc.
(Returns Depot),
3824 North 5th St., Suite C,
North Las Vegas, NV 89030
www.x10.com/support
BBR-9/01
