User Manual v1.0
Page 2
WARNINGS
Please read user manual carefully before using the light.
Product will generate heat while working, please be cautious
with that to avoid any possible harm.
Please don’t shine into eyes directly to avoid harm to eyes.
Please keep the light away from children.
Please use WUBEN or WUBEN recommended batteries.
Please don’t disassemble the light or it will not be covered
by WUBEN warranty policy.
Please don't throw the product into fire.
This is not a diving product, please don't use it underwater
for a long time.
Product List
Before using this product, please check whether the
contents of the package are complete.
1
E10 x 1
2
Lanyard x 1
3
Spare O-ring x 2
4
Holster x 1
5
(Manual, warranty card,
quality certificate) x 1
Page 3
Product Features
E10 is an EDC flashlight. E10 utilizes 1 pcs OSRAM P9 LED,
powered by 1 pcs 18650 Li-ion battery(compatible with
2 pcs CR123A batteries), it emits 1200 Lumens max output.
Tail switch design, suitable for one hand operation, offers
users a better use experience.
Product Operation
1. Product Structure
Lanyard hole
Tail cap
Clip
2. Installation
Tail switch
Body
① Unscrew the tail cap ② Load the battery as instructed
Battery is not included, recommend to use WUBEN battery.
Page 4
3. Operation
1
ON/OFF: Click on the tail switch to turn on the flashlight,
click again to turn it off. This light has memory function,
every time it will be turned on the memorized output
level on which it was turned off.
2
Output selections: When the light is on, click on tail
switch to cycle through Low-Mid-High-Turbo.
3
Flash mode
Strobe: When the light is on, double tap on the tail
switch to activate Strobe and click to exit.
SOS: When the light is on, triple tap on the tail switch
to activate SOS and click to exit.
4. Power source
Powered by 1*18650 Li-ion battery, compatible with
2*CR123A batteries.
Battery
18650
18650
CR123A
RCR123A
16340
Description
3.7V with over-charging and
over-discharging protection
3.7V without over-charging and
over-discharging protection
3V disposable battery
3.7V rechargeable battery
3.7V rechargeable battery
Recommended Cautious Banned
√
√
√
√
√
18350
3.7V rechargeable battery
5. Battery status indication
When the battery power is low, flashlight will dim till
battery totally runs out of power.
√
Page 5
Parameters
FL1 Standard
Weight
Dimension
Turbo
1200 700
LM
1+110
mins
215m
11556cd
76g/2.68oz(
124.2mm x 25.4mm | 4.89in x 1in (L x D)
High
LM
300
6.5h 21h 514h /
without battery
Mid Low SOS
1
100
LM
) | 123g/4.34oz
LM
1.5m
IP68
(2m underwater for 1h)
Strobe
LM
1200
/
(with battery)
All data from experiments of WUBEN lab, may vary because of
different experiment equipment, experiment environment or
other factors.
Optional accessories
WUBEN ABE2600C battery,
200
LM
WUBEN ABE3100C battery,
WUBEN ABE3400 battery.
FAQs
Problem
Abnormal
flashing or
no bright
Check whether the switch is
opened properly
Checked whether the
assembly is in the right place
Check whether the battery
is charged
Check whether the battery
is anti-loading
Check if the battery contact
points are dirty
Reason
Solution
Open the switch
Tighten the assembly
parts
Charger the battery
Remove the battery
re-assembly
Use alcohol to clean
Check whether there is a
foreign body fall
Noise
Parts damage
Pour foreign body
Return to the local
dealer
If your problems still not solved yet, please contact seller
for after-sales service.
Page 6
Maintenance
The O-Ring may be damaged for a long time use, please
replace the O-Ring in time to ensure the waterproofness
of the product.
Please use WUBEN battery or WUBEN recommended
batteries.
When the flashlight indicates low power, please charge
or replace the battery in time to avoid affecting the
durability of the battery.
Please use alcohol and rag to clean the conductive parts
of the flashlight in time.
When not in use for a long time, please remove the
battery to prevent the battery from leaking or exploding,
store the flashlight in a dry and ventilated place.
Warranty policy
1. Warranty coverage
15 days replacement: Within 15 days from the date of
purchase, if the product has quality problems, customers
can request free replacement.
1 year warranty: Within 1 year from the date of purchase,
if the product has quality problems, WUBEN will offer
free repair.
5 years warranty: Within 5 years from the date of
purchase, if the product (accessories excluded) has
quality problems, WUBEN will offer free repair for
WUBEN registered customers.
Lifetime maintenance: From the date of purchase,
if the product has problem after 5 years, WUBEN will
offer paid repair for WUBEN registered customers .
Page 7
If proof of purchase cannot be provided, it will be
counted on the date of manufacture.
If there is any dispute, the two parties will coordinate
to solve.
2. Beyond warranty
Man-made damage.
Damage caused by not following the instructions.
Damage caused by improper use of the battery.
Abnormal wear and tear.
Damage caused by irresistible factors.
Gifts.
The final interpretation right is reserved by WUBEN.
SHENZHEN SHENGQI LIGHTING
TECHNOLOGY CO., LTD.
E-mail: [email protected]
Web: www.wubenlight.com
Add: 202#, Building A, Jihe E-Business Park,
No. 33 Yangmei Road, Bantian Street,
Longgang District, Shenzhen, China
