Page 1
Instruction Manual
V 1.0
Page 2
Please read the manual carefully before using.
Please do not shine it directly into eyes to avoid causing
blindness.
Please put the product where children can not reach.
Please use Wuben battery or Wuben recommended
batteries.
Please do not disassemble and repair the flashlight by
yourself, or it will not be guaranteed any longer.
This product will generate heat while being used, please
be cautious with it to avoid accident.
Before using this product, please check whether the
contents of the package are complete.
Waterproof Ring x 2 （Manual/Warranty Card
/Certificate） x 1
WARNINGS
Product List
Wuben E01 is a tiny portable EDC flashlight. Utilized
1* Cree XPG3 LED, E01 emits 100 lumens max output,
powered by AAA battery, more convenient to get.
Product Features
E01 x 1
1
AAA Battery x 1
2
Key Chain x 1
3
4
5
Page 3
Utilized Cree XPG3 LED, lifespan of as long as 100,000 hours
Max output 100 lumens
Max beam distance 40 meters
Hard military III anodizing aircraft grade aluminium alloy housing
Double side anti scratch coating optical lens
Aluminium alloy vacuum electroplated reflector
Reverse battery installation protection circuit
Product Operation
1. Product Structure
Intelligent temperature control design
IP68 waterproof level(2 meters underneath water for 1 hour)
1 meter impact resistance
2. Installation
① Please screw off the tail switch ② Please Insert the battery with
positive pole pointing
Multi-function
tail switch
Head
Aluminum Alloy Shell
Stainless
Steel Clip
Battery
AAA
Page 4
Turn on: Single click on the tail switch to turn on the light
Outputs selection: When the light is on, tap on tail switch
to cycle through Low-Med-High, and click to turn it off.
Flash mode: When the light is off, double click on the
switch to get into SOS, click again to get out.
3. Operation
When battery in low status, flashlight will shift down the
brightness automatically until battery totally die.
3. Low battery status indication
FL1 Standard
Size
100 Lm
40 m
395 cd
1 m
IP68
20 Lm 1 Lm
1 h
5 h
20 h
20 Lm
/
High Med Low SOS
82.5mm x 15mm ( L x D )
We recommend only a WUBEN brand battery.
Charge or replace the battery when the power is low.
Clean the battery contact points with alcohol and wipe
clean as necessary.
When not in use we recommend removing the battery
for safe storage.
O ring may lose its effectiveness over time and need
to be replaced with the spare O ring to ensure the
flashlights water resistance.
Maintenance
Parameters
The above data tested in WUBEN laboratory, may fluctuate due to
a variation in the testing instruments.
Page 5
Store the flashlight only in a well ventilated and dry place.
5 years warranty: WUBEN offers free repair for any
manufacturing defects if problem arose during normal
use, as long as the end user has registered the product
on WUBEN’s official website.
Limited lifetime warranty : After 5 years, WUBEN will
repair the light but the user will be responsible to pay for
parts and shipping.
Warranty
1. Category
1 year warranty :Since the date purchased, within one
year if product fails to work because of quality problem,
Wuben will offer free repair service.
Free replacement : WUBEN will replace a new product
within 15 days of purchase for any manufacturing defects
if problems arise during normal use.
Troubleshooting
Problem
Abnormal
flashing or
no bright
Noise
Reason
Check whether the switch is
opened properly
Open the switch
Tighten the assembly
parts
Charger the battery
Remove the battery
re-assembly
Use alcohol to clean
Pour foreign body
Return to the local
dealer
Checked whether the
assembly is in the right place
Check whether the battery
is charged
Check whether the battery
is anti-loading
Check if the battery contact
points are dirty
Check whether there is a
foreign body fall
Parts damage
Solution
Page 6
Misuse or abuse.
Damage caused by long term storage with the battery
not removed.
Normal wear and tear.
Wuben is not responsible for the shipping charges.
2.Warranty does not cover :
Any modifications to the light.
SHENZHEN SHENGQI LIGHTING TECHNOLOGY., LTD
Add: 209 Building C, 1970 Industrial Zone, Minzhi, Longhua
District, Shenzhen, China
Web: www.wubenlight.comE-mail: [email protected]
Zip Code: 518131
wubenlight.com
