Introduction
The W&T Web-Thermo-Hygrobarograph includes all the
functions in one box for measuring, storing and displaying
your temperature and humidity data. Numerous alarm functions
are also available which can be custom incorporated into your
own applications or into existing systems.
This manual contains all the information you need to install,
configure and operate the Web-Thermo-Hygrobarograph.
4
W&T
Content
Introduction ......................................................................... 3
1 Quick-Start/Commissioning ......................................................... 6
1.1 Connecting the power supply 57612 ................................6
1.2 PoE power supply 57613 ................................................. 6
1.3 Connecting the temperature-humidity-air pressure sensor . 7
1.5 Ethernet connection ........................................................ 8
1.5 Assigning the IP address using „WuTility“ ......................... 9
1.6 IP assignment using DHCP protocol ................................ 11
1.6.1 Activating/deactivating DHCP ................................ 11
1.6.2 System Name ........................................................ 12
1.6.3 Lease time ............................................................13
1.6.4 Reserved IP addresses ........................................... 14
1.6.5 Dynamic IP addresses ............................................ 14
1.7 Assigning the basic network parameters ......................... 15
2 Graph Display of the Measurements ........................................18
2.1 Basic functions ............................................................. 18
2.2 Config menu ................................................................ 20
2.3 Table ............................................................................22
3 Additional basic settings .............................................................23
3.1 Configuring port and device name ................................. 23
3.2 Setting local time .......................................................... 25
3.3 Automatic time setting using a network service ............... 28
3.4 Configuation of the the data logger ................................29
3.5 Configuration of the graphics settings ........................... 31
3.5.1 Basic Settings ............................................................. 31
3.5.2 Select Sensor ............................................................. 33
3.5.3 Scale Config .............................................................. 35
3.6 Calibration ................................................................... 36
3.7 Browser access ............................................................. 38
3.8 Alarm via E-Mail ............................................................. 39
3.9 SNMP incl. alarm via trap ................................................ 48
5
W&T
Subject to errors and changes
3.10 Alarm via TCP (client mode) ......................................... 52
3.11 Sending alarms via FTP (Client Mode) ........................... 53
3.12 Syslog messages incl. alarm......................................... 57
3.13 ASCII command strings via TCP Port 80 ........................ 58
3.14 ASCII command strings via UDP ................................... 59
3.15 UP-/Download ............................................................. 60
4 Single querying of temperatures ...............................................62
4.1 Querying temperature via TCP/IP .................................... 62
4.2 Temperature querying via UDP ....................................... 62
4.3 Temperature querying using SNMP ................................. 63
5 Placing the temperature into your own web page ..............66
6 Data logger ........................................................................................71
7 Appendix ............................................................................................ 72
7.1 Alternate methods of IP address assignment ................... 72
7.2 Example for creating your own Web pages ...................... 76
7.3 Firmware Update ........................................................... 84
7.3.1 Where do I obtain the current firmware? .................. 84
7.3.2 Firmware-Update over the network
using Windows ............................................................ 84
7.3.3 LED indicators ...................................................... 86
7.4 Emergency access ......................................................... 88
7.5 Technical Data .............................................................. 89
7.6 Declaration of Conformity .............................................. 90
6
W&T
1 Quick-Start/Commissioning
Just a few steps are required to start up your W&T Web-ThermoHygrobarograph and to make it visible in your network.
1.1 Connecting the power supply 57612
Connect the AC adaptor provided to the terminal provided for the
12-24V AC/DC operating power. Polarity does not need to be
observed.
1.2 PoE power supply 57613
The Web-Thermo-Hygrobarograph PoE 57613 is designed for
use in PoE (Power-over-Ethernet) environments in accordance
with IEEE802.3af. Power is provided by the network
infrastructure using the RJ45 terminal. The device supports
both phantom power using data pairs 1/2 and 3/6 as well as
power feed using the unused wire pairs 4/5 and 7/8.
To enable power management for the supplying components,
the Web-Thermo-Hygrobarograph is identified as a Power Class
1 device with a power consumption of 0.44 to 3.84W.
7
W&T
Subject to errors and changes
As an alternative to PoE power supply, the Web-ThermoHygrobarograph PoE can also be powered by an external power
supply connected to the screw terminals on the underside of
the housing. DC voltage of any polarity as well as AC voltage
may be used.
!
Use of the model Web-Thermo-Hygrobarograph PoE is
also possible in networks without PoE power supply. In
this case simply use an external power supply attached
to the screw terminal as described above. No additional
configurations or settings are necessary.
1.3 Connecting the temperature-humidity-air pressure
sensor
Plug the sensor included in the scope of delivery into the 9-pin
IO terminal on the unit.
Serial Port
Power
Network
Status
Error
U
8
W&T
1.5 Ethernet connection
The Web-Thermo-Hygrobarograph incorporates an IEEE 802.3compatible network interface on a shielded RJ45 connector. The
pin assignments correspond to an MDI port, so that the
connection to the hub or switch is accomplished using a 1:1
shielded patch cable.
Power-over-Ethernet
The Web-Thermo-Hygrobarograph PoE 57613 can obtain power
as defined in IEEE802.3af/Power-over-Ethernet. Either the data
pairs or the unused wire pairs in 10/100BaseT may be used
(see also the section PoE power supply 57613).
Serial Port
Power
Network
Status
Error
U
9
W&T
Subject to errors and changes
5xxxx [Typ]
EN=00c03d004a05
OK xxxxxx
Ethernet-address
1.5 Assigning the IP address using „WuTility“
Once the hardware has been connected to the supply voltage
as described above, you must assign the IP address needed for
operation in a TCP/IP network. You can obtain the correct value
for this parameter from your system administrator.
!
The IP address must be unique throughout the network.
There are various ways of assigning the IP address. To make it
as convenient as possible, we have developed the „WuTility“
tool, which you can download from the WuT homepage at
http://www.wut.de. This procedure is described in the
following. A summary of the alternatives can be found in the
Appendix to this manual under 7.1.
Be sure that the PC you are using to assign the IP address is
located in the same sub-network as the module and that both
the PC and the module are connected to the network.
When it starts, WuTility automatically searches the local
network for connected W&T network devices and generates an
inventory list. This search process can be repeated manually as
often as desired by clicking the Scan button:
Select from the displayed list your Web-ThermoHygrobarograph based on the MAC address:
10
W&T
Click on the „IP address“ symbol:
In the resulting window enter the desired network parameters
for the device and confirm by clicking on „Continue“.
The DHCP client of the Web-Thermo-Hygrobarograph can be
activated in the following window.
Clicking on the Continue button assigns the network
parameters to the Web-Thermo-Hygrobarograph. All the
columns in the device list in WuTility are filled with information.
After clicking on the globe in the WuTility menu list your
standard browser is opened and you will see the start page for
the device.
11
W&T
Subject to errors and changes
1.6 IP assignment using DHCP protocol
Many networks use DHCY (Dynamic Host Configuration
Protocol) or its predecessor BOOTP described in the following
section for centralized, dynamic assignment of network
parameters. By default DHCP protocol is activated, so that in
network environments with dynamic IP assignment you only
need to connect the Web-Thermo-Hygrobarograph to the
network. The following parameters can be assigned using
DHCP:
• IP address
• Subnet mask
• Gateway address
• DNS server
• Lease time
1
To prevent undesired address assignment
or address changes, we recommend deactivating DHCP,
BOOTP and RARP unless these are expressly used in the
respective network environment. Web-Thermo-Hygrobarographs with incorrectly assigned IP address can be
conveniently found and reconfigured after the fact using the
scan function of the WuTility management tool.
1.6.1 Activating/deactivating DHCP
By default DHCP is activated. The following methods are
available for deactivating or later reactivating DHCP protocol.
• Management tool WuTility
Select the desired Web-Thermo-Hygrobarograph from the
device list and click on the IP address button. In the first
dialog window enter the new network parameters and then
click on Next.
12
W&T
In the following dialog window deactivate the options
BOOTP and DHCP. Click on Next to send the new
configuration data to the Web-Thermo-Hygrobarograph.
• Serial interface
As part of serial IP assignment you can specify the following
options for deactivating/activating the DHCP and BOOTP
protocols directly following the address string:
-0 r Deactivates DHCP and BOOTP
-1 r Activates BOOTP/RARP
-2 r Activates DHCP
A detailed description of this procedure can be found in the
section Alternative IP address assignment 7.1
• Web Based Management
In Config r Device r Basic Settings r Network you can
alternately activate or deactivate both the protocols. Detailed
information about this can be found in section Assigning the
basic network parameters 1.5.
1.6.2 System Name
To support any automated updating of the DNS system by the
DHCP server, the Web-Thermo-Hygrobarograph identifies itself
within the DHCP protocol with its system name. The factory
setting for this is WEBIO- followed by the last three places of
the Ethernet address. For example, the default system name of
a Web-Thermo-Hygrobarograph having Ethernet address
00:c0:3d:01:02:03 is WEBIO-010203. The system name of the
Web-Thermo-Hygrobarograph can be changed using Web Based
Management.
13
W&T
Subject to errors and changes
1.6.3 Lease time
The lease time determined and sent by the DHCP server
specifies how long the IP address will remain in use. After half
the lease time has expired the Web-Thermo-Hygrobarograph
attempts to extend the time for the assigning DHCP server and
to update the address. If this is not possible by the time the
lease time expires, for example because the DHCP server can
no longer be reached, the Web-Thermo-Hygrobarograph deletes
the IP address and starts a cyclical search for alternative DHCP
servers in order to assign a new IP address.
Because the clock is missing, the lease time associated with the
current IP address is no longer available after a reset. Therefore,
after the restart an update query is generated for the original
DHCP server. If it is not available at this time, the Web-ThermoHygrobarograph deletes the IP address and starts a cyclical
search for alternative DHCP servers.
If DHCP is activated, the remaining lease time together with the
current IP address is shown in seconds in the menu branch
Home r Doc r Property.
1
If after the assigned lease time has expired the DHCP
server cannot be reached, the Web-Thermo-Hygrobarograph deletes its IP address. All existing TCP/UDP connections
between the Web-Thermograph and other network clients are
closed. To prevent disturbances of this kind, we recommend
setting the lease time in the DHCP server to infinite.
14
W&T
1.6.4 Reserved IP addresses
The Web-Thermo-Hygrobarograph provides services which can
make use of other clients in the network as needed. To open a
connection they of course need the current IP address of the
Web-Thermo-Hygrobarograph, so that in these applications it
makes sense to reserve a particular IP address for the Web-Thermo-Hygrobarograph on the DHCP server. As a rule this is done
by joining the IP address to the worldwide unique Ethernet
address of the device, which can be found on the sticker on
the housing.
1.6.5 Dynamic IP addresses
Fully dynamic IP address assignment, in which the Web-Thermo-Hygrobarograph gets a different IP address after each
restart or after the lease time has expired, is only useful in
network environments with automatic cross-connection
between the DHCP and DNS services. This means when a new IP
address is assigned to the Web-Thermo-Hygrobarograph, the
DHCP server then automatically updates the DNS system as well.
The new address is assigned to the respective domain name.
For detailed information about your network environment,
consult your system administrator if in doubt.
Dynamic, changing IP addresses can also be used for time
server queries, sending of e-mails or other client applications
in which the device itself searches for active connection to
server services located in the network.
5xxxx [Typ]
EN=00c03d004a05
OK xxxxxx
Ethernet-address
15
W&T
Subject to errors and changes
On the next screen use the profiles to select the configuration path.
Select the „Basic network parameters“ profile and click on the
„Highlight profile“ button.
1.7 Assigning the basic network parameters
Select the menu item „Config“ to the left in the configuration tree.
You are now prompted to enter a password. As shipped, the unit
does not require a password, so that you can sinmply click on the
Login button without entering a password.
16
W&T
The device now automatically displays the necessary menu points
for this profile. Click on „Network“ in the configuration menu.
17
W&T
Subject to errors and changes
By then clicking on the „Save“ button, all your settings are saved
in the device and you quit your configuration session. After the
network parameters are changed, the unit automatically performs
a restart.
The device is now ready to operate in your network. For easy
handling, use the additional profiles for adapting the device to your
needs.
In the following screen enter all the necessary network parameters
and then click on the „Logout“ button.
18
W&T
2 Graph Display of the Measurements
2.1 Basic functions
The device provides a table of the current values and a graph
of the stored values.
By using the control buttons at the bottom of the page you can
do the following.
Scroll the graph to right or left by the size
of the display interval, to within one unit.
Scroll left or right in the graph in
increments of one unit of the X-axis.
Zoom the area of the graph indicated at
the lower right edge.
19
W&T
Subject to errors and changes
Zooms back to the previous zoom level.
Activates automatic refreshing of
the graph.
Value visualization:
Large marker: This measured value is
stored in the device data logger.
Small marker: This measured value is a
volatile value which is used only for
display but which is not stored in the data
logger.
!
When exiting the zoom level, these
measurements are lost. The
connectinglines are only displayed
in the zoom level which represents the
memory.
Refreshes the display
To print out the page containing the graph, it is necessary to
activate printing of background colors and images in the
Internet options. In Microsoft Internet Explorer this setting is
found in
Tools -> Internet options -> Advanced
Opens the configuration menu beneath
the graph
Displays the values currently displayed in the
graph in table form.
20
W&T
Design and positioning of the graph is configurable.
2.2 Config menu
21
W&T
Subject to errors and changes
The following functions are available from the configuration
menu beneath the graph:
Start: Here you specify the starting time for the X-axis.
End: Here you specify the ending time for the X-axis.
Polling Rate: Enter here the desired refresh rate for the graph.
The device provides a new value no sooner than after 4
seconds. Entering a value of less than 4 is not useful.
Active: Use this to turn the individual sensors on or off.
Display, Extreme: If a zoom level is selected in the graph in
which a display point represents a measuring interval and not
an individual measuring point, this function is used to display
the maximum and minimum measured in this interval. If the
zoom level is selected such that every measured value is
displayed, this function has no effect. If the function is
deactivated, the average value of the displayed interval is
displayed.
Apply changes: Immediately applies the changes made for the
graph.
22
W&T
2.3 Table
This function is used to show the currently represented values
in table format. As soon as not all stored values can be
displayed, the following values are shown in the table for each
sensor:
Max: The maximum value in the displayed interval
Min: The minimum value in the displayed interval
Ø: The average value of the displayed interval
23
W&T
Subject to errors and changes
3 Additional basic settings
3.1 Configuring port and device name
3.1.1 Text
Enter your personalized names and designations in the screen
provided and then click on the „Temporary Storage“ button.
24
W&T
3.1.2 Ports
Enter here a name for the sensor and a descriptive text. Then click
on „Logout“ and save your configuration.
Port 1 (Temperature):
Port 2 (rel. Humidity):
Port 3 (Air pressure):
25
W&T
Subject to errors and changes
3.2 Setting local time
3.2.1 Timezone
Here is where you define the time zone where the device is
located. The settings you make here are referenced to UTC
(Coordinated Universal Time). Then click on the „Temporary
Storage“ button.
26
W&T
3.2.2 Summertime
If you wish the device to automatically switch to summer time,
first enter the offset to UTC. The standard value (for Germany)
is two hours. Use „ „Apply Summer time“ to activate this
function and save the settings.
Start/Stop
Define when summer time begins and ends. The parameters are
already pre-configured:
Start:
Last Sunday in March at 02:00 hours
27
W&T
Subject to errors and changes
Stop:
Last Sunday in October at 03:00 hours
3.2.3 Device Clock
If you do not wish to use a time server, you can manually set the
clock here. Then click on „Logout“ and save your settings.
Loading...
