WOWOW IS-mini Operating Instructions

OPERATING INSTRUCTIONS

IMAGE PROCESSING SYSTEM

IS-mini

2

For the customers in the U.S.A.

CAUTION:

Changes or modifications not expressly approved by the party responsible for compliance could void
the user's authority to operate the equipment.

NOTE:

This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his or her own expense.

For the customers in Canada

This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.

For the European customers only

The crossed out wheeled bin label that can be found on your product indicates that this product should
not be disposed of via the normal household waste stream. To prevent possible harm to the
environment or human health please separate this product from other waste streams to ensure that it
can be recycled in an environmentally sound manner. For more details on available collection facilities
please contact your local government office or the retailer where you purchased this product.

This information only applies to customers in the European Union, according to Directive
2002/96/EC OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL OF 27 January
2003 on waste electrical and electronic equipment (WEEE) and legislation transposing and
implementing it into the various national legal systems.For other countries, please contact
your local government to investigate the possibility of recycling your product.

This product does not connect to an antenna.This product is not a receiver.This product is purpose for

video data transformation.This product has HDMI , but audio data does not output.

HDMI,the HDMI Logo,and High-Definition Multimedia Interface are either trademarks or registered

trademarks of HDMI Licensing, LLC.

WOWOW Entertainment does not guarantee the operation of this product used in the network

configurations other than those specified in this manual.

1 The product and product specifications described in this document are subject to change without

notice due to reliability, function, and improvements in design.

2 This document, in whole or in part, may not be reprinted or copied without direct permission from

WOWOW Entertainment

3 WOWOW Entertainment does not assume responsibility for any damage, direct or indirect, caused by

the use of this product.

4 This document does not authorize the use of patent or any other rights of WOWOW Entertainment

or any third party.

5 Proper names mentioned in this document, such as the name of products, are registered trademarks

of each manufacturer.

3

Introduction

Before using this product, carefully read this manual to thoroughly understand how to set up and use IS-mini.
Follow the Safety Precautions during use. After reading this manual, keep it in location where it can be easily
accessed when needed.

For Safe Use

This product has been manufactured with special attention to safety. However, since this is an electrical
product, misuse may result in fire or electric shock, which may lead to death or severe injury. Please
follow the precautions in this manual and use the product as directed.

In Case of Failure, Discontinue Use

In case of a failure with the product, discontinue use, and contact the service center or a sales staff.

In Case of Abnormality

In Case of Smoke, Abnormal Smell, or Abnormal Noise

Immediately unplug the AC adapter and disconnect the AC adapter from the electrical outlet.
Disconnect any other electrical cables connected to the electrical outlet, and contact the service
center.

In Case of Fire

Immediately unplug the AC adapter and disconnect the AC adapter from the electrical outlet, or
trip the breaker, and quickly extinguish the fire.
Then, contact the service center promptly.

Warranty of This Product

A written warranty containing information regarding repair service and warranty regulations are attached
to this product. Thoroughly read and verify the contents, and keep this warranty in a secure place.
In the event of an accident within the terms of this warranty, repairs will be made according to the
warranty regulations.

Application to Radio Frequency Regulation

This product is for business purposes, and is not subject to radio frequency regulations.
Radio frequency regulations do not apply.

4

Contents

1 Safety Precautions ...................................................................................................... 5

1.1 Meaning of the Warning Signs ........................................................................................................ 5

1.2 Precautions during Use .................................................................................................................. 6

1.3 Precautions regarding the Power Supply .......................................................................................... 7

1.4 Precautions regarding Installation and Transport .............................................................................. 8

1.5 Precautions during Cleaning ........................................................................................................... 9

2 Installation .............................................................................................................. 10

2.1 Installation Conditions ................................................................................................................. 10

2.2 Unpacking .................................................................................................................................. 11

2.3 Main Unit ................................................................................................................................... 12

2.4 Name and Function of Each Part ................................................................................................... 13

2.5 Connecting and Disconnecting Cables ........................................................................................... 14

2.5.1 Connecting Cables ............................................................................................................... 14

2.5.2 Connecting the Electrical Cable ............................................................................................ 15

2.5.3 Disconnecting Cables ........................................................................................................... 15

3 Using IS-mini .......................................................................................................... 16

3.1 Starting ....................................................................................................................................... 16

3.2 Shutdown.................................................................................................................................... 16

4 Maintenance ............................................................................................................ 17

4.1 Cleaning ..................................................................................................................................... 17

4.2 Regular Checking ........................................................................................................................ 17

4.3 Warranty period ........................................................................................................................... 17

5 Specifications .......................................................................................................... 18

5.1 Product Specifications.................................................................................................................. 18

5.2 Supported Formats....................................................................................................................... 19

6 Troubleshooting ....................................................................................................... 20

5

1 Safety Precautions

This user manual uses the following warning and caution signs for the safe use of this product. Please
thoroughly understand the signs before reading this manual.

1.1 Meaning of the Warning Signs

Warning

Ignoring this warning or the misuse of this product may result in death or
severe injury.

Caution

Ignoring this warning or the misuse of this product may result in injury or
property damage.

Fire Hazard

Ignoring this warning may result in fire.

Electrical Hazard

Ignoring this warning or the misuse of this product may result in electrical
shock.

Do not Disassemble

Disassembly of the product is prohibited in order to avoid electrical shock
or failure of the product.

Specific Actions

Actions are specified to ensure safety.

Prohibited Actions

Specific actions are prohibited in order to avoid an electrical shock, failure
of the product, or injury.

6

1.2 Precautions during Use

Do not Disassemble or Modify

Do not disassemble or modify the product, unless directed in this manual.
To do so may result in injury, electrical shock, fire, or failure of the
product.

Do not insert or drop objects into the ports

Do not insert or drop any metal or flammable objects into the intake or
exhaust ports. This may result in electrical shock, fire, or failure of the
product.

Use under normal conditions

In the event a foreign object or liquid such as water gets inside the
product, or internal condensation builds up, stop using it. This may result
in electrical shock, fire, or failure of the product.

Follow the instructions

Only use this product in the manner directed in this manual. Misuse may
result in electrical shock, fire, or failure of the product.
